Used Alberti Machining Center for sale (70,974)

Condition: used, Year of construction: 2016, CNC machining center Manufacturer: Format4 Type: Profit H500S 16.56 Kdodpozux Rbsfx Ai Rsr Year of manufacture: 2016 Technical data Working area: X = 5540 mm Y = 1570 mm Z = 350 mm 5-axis main spindle Drilling head 12 vertical drilling spindles, 32 mm pitch 6 horizontal drilling spindles, 32 mm pitch, 4 in the X-axis and 2 in the Y-axis Dado head unit arranged in the X-axis Motor controlled via inverter up to 7,500 RPM 1 Becker vacuum pump 2 tool changers

Condition: used, Year of construction: 2007, - Working area: X = 4600 mm / Y = 1935 mm / Z = 275 mm - CE safety devices - 8 ATS plate holders - L = 1525 mm - 24 sliding rails - Automatic positioning of 8 plate holders and sliding rails (EPS X-Y) - Conveyor belt for removing chips and scrap - Pneumatic locking system, divided into 2 working areas in X - 8 rear reference stops with a stroke of 115 mm - 8 stops with a stroke of 140 mm, positioned at 1175 mm (L = 1280 - 1525 - 1800 mm) - 8 stops with a stroke of 140 mm, positioned at 770 mm (L = 1280, 1525, 1800 mm) - 4 lateral stops with a stroke of 140 mm (2 left + 2 right), including pneumatic system. - 4 removable center stops with a stroke of 140 mm (2 left + 2 right), including pneumatic system. - Sensor for detecting lowered stops. - Pneumatic system for lifting rod holders. - 6 lifting rod holders for easy loading - H = 74 mm modules. - Vacuum system for a 250 m3/h pump - 250 m3/h rotary vane vacuum pump for standard vacuum system Composition C3-A1 - Device for mounting a chip deflector with a pneumatic or inductive sensor on a 5-axis machining unit. - Flange for mounting aggregates on a work unit with 5 interpolating axes. *Aggregates can only be used if the spindle is in the vertical position. Composition C3-P2 - Additional Z-slide for rear work units, controlled by an independent Z-axis Kedjzux Nwopfx Ai Rsdr - 16 vertical and 4 horizontal drilling spindles in the Y direction - Chain-type tool changer with 22 positions at 180 mm center distance - Iron gripper for chip deflectors with pneumatic or inductive sensor, positioned in the chain-type tool changer - RH chip deflector with inductive sensor for standard spindle or 15 kW 5-axis spindle * requires the device for the chip deflector * requires the flange for mounting aggregates when using a 5-axis spindle * requires the C-axis when using a standard spindle - Liquid cooling unit for liquid-cooled systems, can cool two spindles or one spindle and a liquid-cooled drilling head. - Automatic lubrication system - Control unit with 5 interpolating axes. This unit enables numerically controlled interpolation of the spindle on 5 axes. The spindle has high power while simultaneously having reduced dimensions. Note: - Additional overhauled 5-axis main spindle - 8 horizontal drilling spindles, 12 vertical drilling spindles, and nut saw are out of order.

Condition: used, Year of construction: 2005, CNC machining center Manufacturer: Homag Type: PROFI BOF 722/58/18/F/K Year of manufacture: 2005 Kjdpfozux Imsx Ai Redr Technical data - Machining area: X = 6000 mm / Y = 1800 mm / Z = 380 mm from the suction cup - 5-axis swivel head (replaced in 2019) - Rear spindle with Flex5 unit - 2 traversing tool changers with 18 positions each - Computer with Windows 10 (new 1.5 years ago) - Woodwop 8.1 - 2nd vacuum pump, can be switched on/off separately

Condition: used, Year of construction: 2021, Technical Data Automatic Central Lubrication Working Area Axis Travel X = 4000 mm Y = 1670 mm Z = 500 mm Working Range X = 3300 mm Y = 1280 mm Z = 250 mm, clearance height depending on the clamping system Operator Terminal on the Left Side of the Machine Handheld Terminal for Controlling Axis Speed, Including an Emergency Stop Switch Machine Software: Woodflash Consisting of: Kjdpfx Aiszux Iae Rsdr - CNC Board - Tool Database - Program Editor Position Indicator for Workpiece Support and Vacuum Suction Cup Vacuum Connection for Template Milling on the Left Side of the Machine: Connection: 12 mm 1 Vacuum Pump with a Total Suction Capacity of 90 m3/h at 50 Hz or 108 m3/h at 60 Hz Milling Spindle 12 kW (S6) HSK F63 12 kW (S6) Full Rated Power at Approximately 12,000 RPM Speed: 1000 - 24,000 RPM Air-Cooled C-Axis 0-360 for Milling Spindle 12-Position Linear Tool Changer on the Left Side of the Machine Frame, Including a Pickup Station for Aggregates Max. Tool Diameter: 250 mm Max. Tool Length: 240 mm Drilling Head DH 16 4H 2S 12 Vertical Spindles 7 Spindles in the X-Direction and 5 Spindles in the Y-Direction 4 Horizontal Spindles 2 Spindles in the X-Direction and 2 Spindles in the Y-Direction Pre-Travel = 70 mm Drilling Length = 70 mm Shaft Diameter D = 10 mm 2 Nut Saws, One Each in the X and Y Directions Max. Saw Blade Diameter: 120 mm Max. Blade Thickness: 5 mm Max. Speed, Continuously Adjustable: 7500 RPM Safety System with Light Curtain on the Front

Condition: used, Year of construction: 2021, CNC machining center with a fixed worktable, double-sided driven gantry, and a 5-axis milling spindle with continuous interpolation. Machine for processing solid wood, wood-based materials, and various plastics. Base machine and gantry Machine base and gantry made of a ribbed, welded steel construction, offering very high rigidity. Guidance system and drives Gantry movement of the X and Y axes with rack and pinion and servo drive. DUAL GANTRY MOTORIZATION: Drive of the X-axis with two synchronized servo drive motors. Movement of the Z-axis via ball screw with servo drive. Dust-protected linear guide. Safety system Three-part safety floor mats allow for the placement of workpieces in the non-active area. Moving partial enclosure with a Lexan protective window for the machining units. Central lubrication Automatic central lubrication Vacuum system Vacuum system for pendulum machining with constant suction power in both work areas. Machine operation The machine is equipped with a cable-guided remote control for performing basic functions. Electrical equipment Dust-protected control cabinet (CE) according to IP 55 standard, including an air conditioning unit and a mobile control panel. Machine control OSAI Open Numerical Control 5-axis swivel head Z 700 Movement of the C-axis and B-axis via brushless servo drives - Maximum rotational speed: 750 /2 sec. - Rotation C-axis: Swivel axis: +/- 110 Technical data - max. travel speed X-axis: 60 m/min - max. travel speed Y-axis: 60 m/min Kjdjzux H Aepfx Ai Rjdr - max. travel speed Z-axis: 24 m/min - Vector speed: 80 m/min - max. workpiece height: 500 mm - Machining area: 4210 x 1605 mm (Extended working area) - Compressed air supply: 7 bar - Suction power: min. 2200 m3/h - Suction speed: min. 28 m/s - Suction nozzle: 160 mm Work table Comec Designed Phenolic resin table, designed as a grid table, grid dimension 50 x 50 mm, for accommodating Cosmec suction systems and templates. The work table is divided into two work areas. Threaded holes in the table to mechanically fix workpieces, 3 pcs. retractable stops Vacuum pump Vacuum pump 250/300 m3/h (50/60 Hz), power: 5.5 kW Main spindle 5-axis spindle: 18 kW main spindle, liquid cooling, tool interface HSK 63 F - 15 kW in S1 operation - 18 kW in S6 operation - Ceramic bearings - Direction of rotation: left/right - Spindle speed: 500 - 24000 rpm Extraction hood Extraction hood controlled via NC program, adjustable in height. 2 x Tool changer Moving 12-position tool changer for tool interface HSK 63 F - max. tool diameter 150 mm, if adjacent position is free - max. tool diameter 120 mm, if adjacent position is occupied - max. tool weight: 6 kg - max. weight of tool and holder: 40 kg Tool length measurement Station for automatic length measurement of the tool Note: Current status of the 5-axis simultaneous machining software through a maintenance contract.

Condition: used, Year of construction: 2019, CNC Machining Center FELDER FORMAT4 Profit H200 13.33 Year of manufacture: 2019 New machine (used only for demonstration purposes in a school) Number of axes: 4 X-axis travel: 4000 mm Y-axis travel: 1670 mm Z-axis travel: 500 mm Technical specifications Spindle power: 12 kW Spindle speed: 24,000 RPM Additional information Working area (maximum panel size) X: 3300 mm Y: 1280 mm Z-distance: 250 mm Spindle: Tool interface: HSK F63 Rated power at: approx. 12,000 RPM Cooling: Air-cooled Rotation: CW / CCW Tool magazine Linear tool magazine (mounted on the side): 12 positions Additional linear magazine on the gantry: 4 positions Max. tool diameter: 250 mm Max. tool length: 300 mm Drilling unit Model: DH 24 6H 2S Vertical spindles: 18 (12 in X, 6 in Y) Horizontal spindles: 6 (4 in X, 2 in Y) Max. drill length: 70 mm Max. tool diameter: 10 mm Dadoing machines: 2 (X and Y) Kdjdpfx Aiszuxi Re Rsr Max. saw blade diameter: 120 mm Max. speed: 6,000 RPM Vacuum table 6 supports (instead of 4) Two-circuit vacuum system Height of vacuum cups: 100 mm Pneumatic support locking Adjustable side stops (Y-axis) Axis system X-axis: Rack and pinion drive Y/Z-axis: Ball screw drive Linear guides in all axes Automatic central lubrication Control and software CNC control with CAD/CAM software 3D simulation preview DXF import capability Parametric programming Remote maintenance package (internet-enabled)

Condition: used, Year of construction: 2005, Technical specifications: - Machining area: 2500x1000 mm - Travel range X-axis: 2980 mm Kjdpfx Aiezuxhts Rodr - Travel range Y-axis: 1280 mm - Travel range Z-axis: 200 mm - Programmable speed in the X-axis: 25 m/min - Programmable speed in the Y-axis: 30 m/min - Programmable speed in the Z-axis: 22.5 m/min - Vector speed: 40 m/min - 16 spindles, 4000 rpm, 2.2 kW (10 vertical and 6 horizontal) - Electric spindle with 6.6 kW, 12000 - 18000 rpm, HSK-63 - Side tool magazine with 7 positions - Footprint (L x W x H): 6970x3000x2680 mm - Weight approx. 3295 kg

Condition: used, Year of construction: 2020, workpiece weight (max.): 5 kg, table width: 267 mm, table length: 1,466 mm, table load: 159 kg, tool diameter: 89 mm, Used Machining Center Brand: Haas Model: TM-2P Year: 08/2020 Serial Number: 1170479 Operating hours: Spindle on time: 12,000h Specifications: - Travels (X, Y, Z): 1016mm, 406mm, 406mm - Spindle to table distance (Min. - Max.): 102 - 508mm - Spindle speed: 6000 rpm - Spindle power: 5.6 kW Kdodpfoxqc H Sjx Ai Rer - Taper: BT 40 - Tool changer carousel: 10 positions - Maximum tool diameter: 89mm (adjacent) - Maximum tool weight: 5.4kg - Coolant pump kit - HAAS CNC - Table dimensions: 1466x267mm - Maximum table load: 159kg - Maximum feed rates on all three axes: 10.2m/min.

Condition: used, Year of construction: 2025, table length: 3,100 mm, table width: 2,100 mm, Technical data - Table size: 3100 x 2100 mm - 4-axis main spindle - Linear tool changer, 16 positions - 2 vacuum pumps Kdsdpfozuw Tzox Ai Rer - 12 vertical drilling spindles - 1 dado blade

Condition: used, Year of construction: 2012, - Machining area: 5300x1400 mm - Main spindle replaced 3 years ago - 18-position tool changer Technical data Machining area - In the X direction: 5300 mm - In the Y direction with main spindle + WZ-0: 20 mm: 1400 mm - In the Y direction with drilling unit: (all vertical drills) 890 mm - Single-position machining: X = 2 x 2550 mm - Free space in the center: X = 200 mm - Alternating field machining: X = 2 x 2250 mm - Free space in the center: 800 mm 1 automatic tool/adapter changer magazine - Arrangement: mounted on the support, moving in the X direction - Disc changer with 18 magazine positions Guidance system - All axes are equipped with pre-tensioned, surface-hardened precision roller guides. Central lubrication - Manual central lubrication for all main axis linear guides and Z ball screw. 1 vacuum pump, 90 m3/h Console table consisting of: - 2 work piece stops fixed on the right and 2 on the left in the X direction, for movement in the Y direction - 10 adjustable support arms in the X direction, each with a rear stop - All stops are controlled by the program - The suction plates are fixed via the patented 2-circuit clamping system, eliminating the need for hoses. - 8 smooth support rails, automatically retractable - 2 push buttons for the workpiece clamping/releasing function Additional 2nd vacuum pump, 90 m3/h 1 additional central stop row, for centering workpieces Chip conveyor 1 main spindle - Drive power: 10.0 kW in S-6 operation - 7.5 kW in S-1 operation - Tool holder: HSK F63, taper diameter = 38 mm, similar to DIN 69893 - Speed range: infinitely variable RPM, programmable Kdsdpfx Aiozuw Rtj Rjr 1 centrally integrated CNC axis, rotating 360 degrees - for all adapter units, with torque support on the main spindle and pneumatic interface 1 vertical drilling unit l14 with 6 spindles, horizontal and attachment unit for a dado cutter - Horizontal drilling units with 2 outputs each Attachment unit for a dado cutter - Swivel range: 0 or 90° Control system ICOS CNC Modern, powerful PC-based control system with: - User-friendly interface with Windows standards - Trajectory control of all servo axes - Job list / order processing - IMA backup and recovery system on two hard drives - Uninterruptible power supply (UPS) IMAWOP software package - for dialog-oriented creation of CNC machining programs - - 3D view and basic simulation of the programmed workpiece, the suction cups and consoles including tool and adapter display.

Condition: used, Year of construction: 2017, operating hours: 9,370 h, Technical Data Working Area Axis Travel - X-axis: 4000 mm - Y-axis: 1970 mm - Z-axis: 455 mm Machining Area - X-axis working area: 3000 mm - Y-axis working area: 1550 mm - Z-axis clearance: 150 mm Main Spindle - 5-axis electric spindle - 5-axis spindle with universal joint - Power: 12 kW (S6 operation) - Tool holder: HSK F63 - Maximum speed: 24,000 rpm - Speed range: 1,000 - 24,000 rpm - Ceramic bearings - Liquid-cooled spindle - Clockwise/counterclockwise rotation - Integrated tool changer interface - Electrically controlled extraction hood Kedpszuw H Iofx Ai Rsdr - Maximum tool weight: 6 kg - Maximum saw blade diameter: 350 mm Tool Changer System Linear Tool Changer - 12-position - Interface for tool holders - Maximum tool diameter: 250 mm - Maximum tool length: 240 mm Disc Tool Changer - 18-position - Mounted on the traversing portal - Maximum tool diameter: 250 mm - Maximum tool length: 280 mm Circular Saw Blade Changer - Maximum saw blade diameter: 350 mm Drilling Unit DH18 6H 2S Drilling Head - 12 vertical spindles: 7 in the X-direction, 5 in the Y-direction - 6 horizontal spindles: 4 in the X-direction, 2 in the Y-direction - Drilling stroke: 70 mm - Maximum drill length: 70 mm - Tool holder diameter: 10 mm - Individual drive for each spindle Dadoing Saws - 2 dado saw blades: 1 in the X-axis, 1 in the Y-axis - Maximum saw blade diameter: 120 mm - Maximum saw blade thickness: 5 mm - Speed adjustable up to 6,000 rpm Vacuum and Clamping System Console Table - 6 consoles - Front and rear programmable stops - Wireless dual-circuit vacuum system - Height of vacuum suction cups: 100 mm - Pneumatic console locking - 4 adjustable side stops - Additional support arms Vacuum Pump Flow Rate: - 90 m³/h at 50 Hz - 108 m³/h at 60 Hz Additional Vacuum Equipment - Vacuum connection for template machining (left side) - Additional vacuum connection for template milling (right side) - Controlled compressed air connections for frame clamps - Separate vacuum and compressed air control for all consoles WoodFlash Software Package Control Panel - Complete machine control - Loading and execution of programs - Tool and machining management - Sensor monitoring - Manual machine commands Mobile Control Panel - 24" LED monitor - Keyboard and mouse - USB port Handheld Control for Feedrate Control - Feedrate override - Emergency stop button - Manual feedrate adjustment during machining Safety Devices - CE safety system - Light curtain safety system - Emergency stop system - Protective fence on the left side - Safety monitoring of the doors - Vacuum and compressed air sensors - Additional safety mat system Operating Hours: 9370 hours

Condition: used, Year of construction: 2018, operating hours: 6,442 h, Technical Data Working Area Axis Travel - X-axis: 4000 mm - Y-axis: 1970 mm - Z-axis: 455 mm Machining Area - X working area: 3000 mm - Y working area: 1550 mm - Z clearance: 250 mm Axis Systems - X-axis: Helical rack and pinion drive - Y-axis: Precision ball screw drive - Z-axis: Precision ball screw drive - Linear guides on all axes - Automatic central lubrication Main Spindle - 5-axis electro spindle - Type: 5-axis spindle with universal joint - Power: 12 kW (S6 operation) - Tool holder: HSK F63 - Maximum speed: 24,000 rpm - Ceramic bearings with air cooling - Full power available at approximately 12,000 rpm - Speed range: 1,000 - 24,000 rpm - Clockwise rotation - Integrated tool changer interface - Liquid-cooled spindle - Electrically controlled extraction hood - Maximum tool weight: 6 kg Kedpszuw E Rsfx Ai Rodr - Maximum saw blade diameter: 350 mm Tool Changer System 12-position linear tool magazine - Mounted on the left side of the machine frame - Separate station for tool changers - Maximum tool diameter: 250 mm - Maximum tool length: 240 mm 18-position disc tool magazine - Mounted on the gantry - Suitable for drilling tools and tool changers - Maximum tool diameter: 250 mm - Maximum tool length: 280 mm Drilling Aggregated Head DH18 6H 1S drilling head - 12 vertical spindles: 7 spindles in the X direction, 5 spindles in the Y direction - 4 horizontal spindles in the X direction - 2 horizontal spindles in the Y direction - Drilling stroke: 70 mm - Maximum drilling depth: 70 mm - Tool holder: 10 mm - Individual control of the spindles - Integrated slotting saw - Saw blade diameter: 120 mm - Maximum slotting saw blade thickness: 5 mm - Speed up to 7,500 rpm Vacuum and Clamping System Console Table - 6 consoles with front and rear stops - Wireless two-circuit vacuum system - Height of vacuum cups: 100 mm - Pneumatic console locking - Programmable pneumatic stops - 4 adjustable side stops - Reinforced support arms - Load-bearing capacity of the support arms: 40 kg each Vacuum Pump Capacity: - 90 m³/h at 50 Hz - 108 m³/h at 60 Hz - Additional vacuum connection for template machining - Controlled compressed air connections for frame clamps - Separate vacuum and compressed air switching for all consoles WoodFlash Software Package Control Panel - Complete machine operation via the CNC panel - Program creation and editing - Tool and workpiece management - Manual machine commands - Monitoring of vacuum, compressed air and safety systems Mobile Control Panel - 24" LED monitor - Keyboard and mouse - USB connection Operator Device for Feed Rate - Manual feed override potentiometer - Variable feed rate adjustment during machining Safety Devices - CE safety system - Safety mats instead of light curtains - Emergency stop system - Protective fence on the left side - Safety monitoring of the doors - Sensors to monitor vacuum and compressed air Optional Equipment - External release switch - Protected energy chain system - Additional locking for A and C axes - Saw blade changing station on the gantry - Operating hours: 6442 hrs.

Condition: used, Year of construction: 2018, Vertical CNC boring and machining center Workpiece length 200 - 3,050 mm Workpiece width 70 - 850 mm Workpiece thickness 12 - 60 mm Ksdezuw Dtjpfx Ai Rjdr Milling spindle 1 unit Main spindle power 5 kW Max. speed 18,000-24,000 rpm (depending on configuration) Tool interface HSK-F63 or ETP25 Tool changer 4-position magazine Vertical boring spindles 13 Horizontal boring spindles X 4 Horizontal boring spindles Y 2 Nut saw X-direction Control system Homag powerTouch / Power Control PC 86 Software WOODWOP 7.x Total connected power 11.5 kW Compressed air requirement 7 bar Machine weight approx. 1,580 kg Installation dimensions (L W H) approx. 2,950 1,984 1,895 mm CE marking

Condition: used, Year of construction: 2017, The BIESSE ROVER A 1643 EDGE is a comprehensively equipped CNC machining center with a 5-axis machining head and an integrated edge banding unit. Working area, X-axis: 4,320 mm Swing machining in X: 1,620 mm Working area, Y-axis: approx. 1,580-1,660 mm Travel, Z-axis: 180 mm Edge banding Working area, X-axis: 3,300 mm Working area, Y-axis: 1,540 mm Maximum loading width in Y: 1,900 mm, expandable to up to 2,100 mm 5-axis unit 5-axis machining head C-axis: continuous 360° rotation B-axis: continuous 360° rotation B-axis speed: 18 rpm C-axis speed: 18 rpm Maximum spindle speed: 24,000 rpm Power 11 kW in S1 operation 13 kW in S6 operation Additional features Maximum undercut angle: -10° Collision monitoring for the 5-axis unit Prepared for the use of attachments on the 5-axis unit Work table and clamping system ATS work table 8 support rails 32 adjustable consoles 32 pneumatic vacuum cups Vacuum cups adjustable in 15 steps Pneumatic system divided into 2 working zones along the X-axis Vacuum system Vacuum pump capacity: 250 m³/h Additional equipment 6 lifting bars for easier loading and unloading 28 sensors for detecting lowered stops Stops and positioning 8 rear stops 8 center stops 4 side stops (2 left + 2 right) 2 additional side stops 4 removable center stops (2 left + 2 right) 2 additional center stops Pneumatic positioning and lowering of the stops Drilling unit Kdedpfozuwyzsx Ai Ror BH 24L drilling head 13 independent vertical spindles 5 independent horizontal spindles Grooving saw, 120 mm Maximum groove depth: 25 mm Programmable spindle speed up to 6,000 rpm Tool changer 16-position rotary magazine Mounted on the X-axis carriage For tools and attachments Capacities Maximum tool/attachment weight: 7.5 kg Maximum total load of the magazine: 55 kg Edge banding unit GU60A edge banding unit For workpieces up to 60 mm thick Edge banding speed up to 20 m/min Double pressure roller system Glue pot with hot melt system Edge heating lamp, 600 W CNC-controlled edge feeding system Automatic edge trimming Sensor for closed geometric shapes Accessories for edge machining Edge magazine 2-roller edge magazine mounted on the X-axis carriage Maximum roller diameter: 800 mm Maximum edge height: 65 mm Additional units Rounding tool 85 mm, HSK F63 Saw unit HSK F63 for cuts and grooves Maximum saw blade diameter: 215 mm Maximum saw speed: 8,400 rpm Maximum cutting depth with a 215 mm saw blade: 68 mm Post-processing Combined glue joint and edge trimming blade units Tool sets for different edge thicknesses Software bSolid basic module 2D CAD environment Import of DXF, CIX and BPP files 3D machine simulation Tool management Management of 5-axis machining through positioning Assistant-supported program creation

Condition: used, Year of construction: 2014, Main spindle power: 13.2 kW Drilling unit motor power: 7 kW 3-axis machine Drilling unit: Technical data - Nut saw - 2 horizontal drilling spindles in the X-axis (left/right) - 1 horizontal drilling spindle in the Y-axis (left/right) Kjdpfx Aozuwxdoi Redr - 10 vertical drilling spindles

Condition: used, Work area and workpiece capacity Travel range X-axis: 3110 mm Travel range Y-axis: 1620 mm Workpiece passage Y: 1,900 mm Workpiece passage Z: 180 mm Workpiece length in shuttle mode: 1,400 mm Table design: TV FLEX 1600 / FLEXMATIC Number of cross traverses: 6 Positions of traverses: 6 to 12 positions Axis speeds and drive data Maximum vector speed X/Y (PRO-SPACE): 56 m/min Maximum vector speed X/Y (PRO-SPEED): 78 m/min Speed of vertical drilling spindles: up to 8,000 RPM Speed of horizontal drilling spindles: up to 8,000 RPM Max. speed of main spindle: 24,000 RPM Speed of grooving unit/circular saw: frequency-controlled, approx. 2,500-8,000 RPM CNC control and software Operating system: Windows 7 Display: 21.5" LCD Full-HD (16:9) Operation: Keyboard, mouse and machine control panel Software: Maestro CNC Programming: Parametric programming, graphic programming, ISO code, DXF import Machining functions: Milling, drilling, tool management, machining programs Simulation: Graphic simulation of drilling and milling operations TECPAD: 7" touchscreen for machine functions and error messages Mobile operation: Portable control panel for operation along the machine Drilling and grooving unit F23L Vertical drilling spindles: 13 independent spindles (7 clockwise, 6 counterclockwise) Horizontal drilling spindles: 10 independent spindles Arrangement of horizontal spindles: 4 spindles in the X direction on one side, 3 spindles in the X direction on the opposite side, 2 spindles in the Y direction Integrated sawing unit: Grooving and circular saw unit in the X direction Saw blade diameter: 125 mm Motor power of sawing unit: 2.2 kW (approx. 3 hp) Stroke of vertical drilling unit: 75 mm pneumatic stroke Stroke of horizontal drilling unit: 75 mm pneumatic stroke Frequency inverter: Programmable speed control up to 8,000 RPM 5-axis milling unit and tool changing system Main unit: JQX 5-axis milling unit Spindle type: Hiteco HSK-F63 electric spindle Power: 10 kW rated power Peak power (S6): approx. 9.5-15 kW Maximum speed: 24,000 RPM Bearings: Ceramic bearings Cooling: Liquid-cooled spindle Lubrication: Central automatic lubrication system Rear tool magazine TRB 14 Magazine positions: 14 Travel range: 350 mm Pitch: 115 mm Max. tool diameter: 240 mm Max. total tool weight: 70 kg Front tool magazine FAST 14 Magazine positions: 14 Max. tool diameter: 130 mm Max. tool weight per position: 8 kg Max. total weight: 24 kg Vacuum system, workpiece clamping and positioning Vacuum cups: 12 pcs, permanently mounted Dimensions of cups: 145 x 145 mm Height of cups: 75 mm Vacuum pump: Standard 1 vacuum pump Additional vacuum pump: 90 m³/h Workpiece supports: 4 pneumatic workpiece supports Rear stops: 8 aluminum stops Intermediate stops: 8 aluminum stops Kedpfjzuwurox Ai Redr Side stop: Left reference stop with laser positioning Preparation for clamping cylinders: Prepared for 6 pneumatic clamping cylinders Extraction and compressed air Connection power: 23 + 28.5 kVA Compressed air consumption: 450 l/min Required extraction capacity: 4,500 m³/h Air velocity in extraction: 25 m/s Extraction nozzle: 250 mm

Condition: excellent (used), Year of construction: 2019, functionality: fully functional, machine/vehicle number: AA100264-11 / AA100264-12, travel distance X-axis: 2,000 mm, travel distance Y-axis: 920 mm, travel distance Z-axis: 635 mm, feed length X-axis: 2,000 mm, feed length Y-axis: 920 mm, feed length Z-axis: 635 mm, feed rate X-axis: 90 m/min, feed rate Y-axis: 60 m/min, feed rate Z-axis: 60 m/min, nominal power (apparent): 25 kVA, controller manufacturer: Siemens, controller model: 840 D, overall weight: 28,000 kg, spindle speed (min.): 20,000 rpm, spindle speed (max.): 20,000 rpm, spindle motor power: 25 W, number of spindles: 2, number of slots in tool magazine: 31, Equipment: chip conveyor, documentation/manual, BAZ and extrusion profile system for the production of car sill profiles consisting of: *Machining machines: - Anger machine SP2-X2000 (machine number AA100264-11) - Anger machine SP2-X2000 (machine number AA100264-12) - 2x coolant treatment units *Subassembly assembly (robot cell for sills): - Robot 1 KUKA KR120 R3200 PA - Gripper for robot 1 - Labeling station - Robot 2 KUKA KR120 R3500 - Gripper for robot 2 - Interface robot/machining center Kdedpfjyzh Uljx Ai Rer - Cleaning unit for components - Assembly machine, 2 lines - Robots 3 and 4 for handling - Drawer system with component inserts - Screwing station - Adhesive application station - Platform - Robot 5 - Gripper for robot 5 - Pallet placement station - Safety enclosure - Electrical control and integration Further information and videos available upon request.

Condition: used, Year of construction: 2007, operating hours: 9,500 h, functionality: fully functional, machine/vehicle number: 1054954, spindle speed (max.): 12,000 rpm, operating hours of spindle: 9,500 h, number of spindles: 1, number of slots in tool magazine: 24, input voltage: 400 V, type of input current: three-phase, Equipment: documentation/manual, Travel range: 1016 x 660 x 635; equipped with a Renishaw measuring system for tool and workpiece. The machine is in good condition, still in operation, and can be inspected at any time. Kdedpfx Aozu S A Dji Rsr

Condition: used, Year of construction: 2006, Working area X-Y-Z: 5300 x 1700 x 180 mm Travel length X-Y-Z: 6040 x 1810 x 280 mm Drilling head with 30 + 8 spindles Speed: 6000 rpm Power: 2.2 kW Automatic central lubrication Worktable TV with 10 supports L=1500 4 working zones 2 cross lasers Vacuum pump 250 m³/h PC control Windows Vertical milling unit ISO 30 7.5 kW with tool changer RAPID 14 and vector axis Additional drilling unit (E-axis) Dongle for XILOG software Location: Nattheim Kdjdpfx Aiox Twd Hs Rsr

Condition: used, Year of construction: 2016, MORBIDELLI AUTHOR M400 KEY FEATURES 5-AXIS MACHINING HEAD "PRISMA: QUALITY AND PRODUCTIVITY AT THE HIGHEST LEVEL" XILOG MAESTRO SOFTWARE: EXTREMELY SIMPLE PROGRAMMING MATIC WORKTABLE: ONE POSITIONING FOR MULTIPLE MACHINING OPERATIONS TECHNICAL DATA AUTHOR M400 AXES Working area X-axis (stop inner side) mm 3,680 Working area Y-axis (max. loadable workpiece on rear stops) mm 1,680 Workpiece passage Z / Number of Z axes mm 170 / 1 Workpiece length with pendulum machining mm 1,650 Traverse speed X-Y axes Pro-Speed m/min 85 Speed Z-axis m/min 30 INSTALLATION Installed power KVA 62 ÷ 82 Compressed air requirement NL/min 400 Extraction air requirement m³/h 4,430 Extraction air speed m/s 25 Extraction nozzle diameter mm 250 GENERAL FEATURES CNC-controlled drilling and milling center in a portal design and worktable with workpiece supports, for performing: - Vertical drilling on the panel surface - Horizontal drilling on all four workpiece sides - Groove milling with disc cutters - general milling operations 3-4-5 axes MACHINE STRUCTURE The base structure is a monolithic construction made of thick-walled steel. It is reinforced by welded-in supports over the entire machine bed, making it extremely stable. The table design, with a large base, is the secret to ensuring lasting precision and stability. The machine layout enables the user to have an optimal workflow with a minimum of space requirements. The mobile portal beam is made of a solid monoblock. It is positioned in the X direction on prismatic ground guides via ball screw slides. On this mobile aggregate carrier, the working aggregate is in turn attached to prismatic, ground guides and ball screw slides. AXIS MOVEMENT The displacement of all axes takes place on prism linear guides with a large cross-section and ball screw shoes with a large contact surface, which ensure optimal sliding even at the highest speeds and accelerations. The precise and fast positioning of the moving portal (X-axis) is achieved by a pinion and rack with helical teeth. Ball screws with a large cross-section ensure the accurate positioning of the work unit along the moving portal (Y and Z axes). MOTORS, DRIVES AND INVERTERS The perfect mechanical dynamics and maximum positioning accuracy are controlled by the high-quality drives and brushless motors, which are designed to achieve a speed of up to 90 m/min while maintaining the best surface finish. CONTROL The control unit consists of a numerical control for the milling and drilling machine with "Xilog Maestro" graphical user interface on a Windows 7 operating system - LCD color screen 17 - Qwerty keyboard - Swiveling control panel - Machine operating interface with Xilog Maestro software Xilog Maestro Features Programming - parametric graphical programming - Import of DXF files (2D; the geometries "SPLINE", "POLYLINE 3D", lines or circle interpolation in three axes, linear in space, spiral in the selected plane - supported programming with graphics and syntax aids for drilling and milling operations - automatic optimization of drilling operations and tool changes - cycles - possibility of panel zero-point shift to perform drilling on inclined or curved panel sides Kdjdpfxsy Dta Ss Ai Rer

Condition: used, Year of construction: 2007, Working area: 2780 x 1140 mm (vertical milling) 2500 x 950 mm (horizontal drilling) X-Y travel: 2980 x 1271 mm Z-axis travel: 200 mm Passage height: 180 mm The structure of the base body is a monolithic construction made of thick-walled steel. It is stiffened by welded triangular plates across the entire machine bed, making it extremely stable. The triangular shape used for load-bearing parts, with a large base, is the secret to ensuring lasting precision and stability. The machine layout allows the user optimal workflow despite minimal space requirements. The base body constructed in this way therefore offers the machining unit a balanced and secure base with particularly good load distribution. The mobile unit carrier is made of a solid monoblock. It is positioned in the X direction on prismatically ground guides via recirculating ball slides. On this mobile unit carrier, the working unit is mounted on prismatic, ground guides and the recirculating ball slide. Description of the units and accessories (basic) Drilling unit: Drilling head with 10 + 4 spindles · 6 individually accessible vertical spindles in X · 4 individually accessible vertical spindles in Y · 2 horizontal spindles in X (1 + 1) · 2 horizontal spindles in Y (1 + 1) · Speed: 4,000 rpm · Power: 2.2 kW · Grid: 32 mm · Drill chuck: M 10 with 11 mm fitting · Extraction nozzle: D = 160 mm Vertical milling unit (position 2) · Tool chuck HSK 63F · Speed 1,500 - 24,000 rpm continuously adjustable via inverter · Motor power 4.4 kW (6 HP) from 12,000 rpm (S1) · Right-hand / left-hand rotation · Ceramic bearings · Scope of delivery: 4 tool chucks (right) without collet chuck · Tool changer · Side-mounted tool magazine 7-way (TR7) with full encapsulation to prevent chipping · 7 tool positions for HSK 63F tool holder arranged in a row · maximum tool diameter D=120 mm · maximum weight per holder 4.5 kg · maximum tool weight of all tools 20 kg (TR7) · angular gears can be accommodated Horizontal milling unit (position 1) Horizontal unit with two opposite outputs for milling and grooving. · Speed 9,000 - 18,000 rpm continuously variable via inverter · 1 output for collet 3-20 mm (ER 32) · 1 output for saw/collet 3-12 mm (ER20) (For saw D = 120 mm / bore 50 mm) · Motor power 3 kW (4 HP) · Max. tool diameter front milling: 20 mm · Max. tool length front milling: 110 mm · Max. tool diameter rear milling: 12 mm · Max. tool length rear milling: 80 mm · Max. saw blade diameter: 100 mm · Bore saw blade (ER 32): 50 mm · Mandrel diameter saw blade (ER 20): 12 mm Work table The work table is designed to guarantee the operator maximum freedom of movement. The vacuum quick clamping system ensures maximum flexibility with precise positioning and optimal grip of the workpieces. · 4 supports 900 mm continuously adjustable in X · 8 vacuum suction cups round D = 110 mm continuously adjustable in Y (2 per support) · 2 stops in X (1 x left / 1 x right) · 1 stop in Y per support (total 6) · The retractable reference stops are controlled via CNC. · Scope of delivery: 4 plug-on adapters for suction cups · Pendulum machining standard (2 working areas) Axis movement The drive system in X, Y and Z is carried out via ground ball screws of the highest precision class. The ball drive screw of the X-axis is located exactly in the center Kdodpfxsx Twdyo Ai Ror

Condition: used, Year of construction: 2006, * Work area: 2,650 x 1,240 mm * X-Y travel: 2,995 x 1,385 mm * Z-axis travel: 200 mm * Clearance height: 180 mm C-axis deactivated - 3-axis machine The structure of the base body is a monolithic construction made of thick-walled steel. It is reinforced throughout the machine bed by welded triangular plates, making it extremely stable. The triangular shape used for the supporting parts, with a large base, is the key to long-lasting precision and stability. The machine's layout allows the user an optimal workflow despite minimal space requirements. The base body, constructed in this way, provides the machining unit with a balanced and secure base with particularly good load distribution. The mobile unit carrier is made from a solid monoblock. It is positioned in the X-direction on prismatically ground guides via ball screw slides. The machining unit is, in turn, attached to the mobile unit carrier on prismatic, ground guides and the ball screw slide. Description of units and accessories (base) Drilling unit: Drilling head with 12 + 6 spindles * 7 individually selectable vertical spindles in X * 5 individually selectable vertical spindles in Y * 4 horizontal spindles in X (2+2) * 2 horizontal spindles in Y (1+1) * Speed: 4,000 1/min * Power: 2.2 kW * Grid: 32 mm * Drill chuck: M 10 with Morse taper No. 11 Nut saw unit in "X": * Integrated in the drilling head * Nut saw blade with a diameter of up to max. 120 mm Main milling unit (Position 2): * Tool holder HSK 63F * Speed 1,500 - 24,000 1/min, stepless via inverter * Motor power 4.4 kW (6 hp) from 12,000 1/min (S1) * Motor power 6.6 kW (9 hp) from 12,000 1/min (S6) * Right/left rotation * Ceramic bearings * Scope of supply: 4 pcs. tool holder (right) without collet Tool changer R8L Automatic tool changing device for 8 tools. Mounted on the rear unit carrier for quick access to the tools. * Number of tool positions: 8 * Max. tool diameter: 120 mm * Max. weight per tool: 4.5 kg * Max. total weight of all tools: 22 kg * Holder for 1 angular gear * Mounted and moving in X Horizontal milling unit (Position 1) Horizontal unit with two opposite outlets for milling and grooving. * Speed 9,000 - 18,000 1/min, stepless via inverter * 1 outlet for collet 3-20 mm (ER 32) * 1 outlet for saw/collet 3-12 mm (ER20) (For saw D=120 mm / bore 50 mm) * Motor power 3 kW (4 hp) * Max. tool diameter, front milling: 20 mm * Max. tool length, front milling: 110 mm * Max. tool diameter, rear milling: 12 mm * Max. tool length, rear milling: 80 mm * Max. saw blade diameter: 100 mm * Bore in saw blade (ER 32): 50 mm * Arbor diameter, saw blade (ER 20): 12 mm Work table The work table is designed to guarantee the operator maximum "freedom of movement". The vacuum quick-clamping system offers maximum flexibility with precise positioning and optimal workpiece clamping. * 6 supports 1000 mm, stepless pneumatically adjustable in X * 12 vacuum suction cups, round D = 110 mm, steplessly adjustable in Y (2 pcs. per support) * 2 stops in X (1 x left / 1 x right) * 1 stop in Y per support (total 6 pcs.) * The retractable reference stops are CNC-controlled * Pendulum machining standard (2 working areas) --- other clamping systems are available as optional extras --- Kdedpfxex Twcco Ai Rsr Axis movement The drive system in X, Y and Z is via ground ball screws.

Condition: used, Year of construction: 2010, A KERN 5-axis CNC machining center with EROWA Robot Compact is offered. Travel X/Y/Z: 500mm/500mm/400mm, simultaneous 5-axis machining, hydrostatic guideways in the X and Y axes, swivel range: -10° to +110°, feed rate X/Y/Z: 30m/min, max. acceleration: 10m/s², max. spindle speed: 40000rpm, spindle power: 37kW, max. torque: 12000rpm, tool taper: HSK-E40, tool magazine: 50, tool change time: approx. 3s, control: Heidenhain iTNC 530 , laser tool measurement, workpiece touch probe, EROWA PowerChuck P, EROWA Robot Compact year of manufacture 2013 with 70 magazine positions, including 55 positions ITS 72 and 15 positions ITS 148, max. transfer weight pallet incl. workpiece: 30kg, automatic loading and unloading of the magazine also possible during machining, machining medium: oil, belt filter system and max. high-pressure supply 80bar, oil mist extraction system and fire extinguishing system available, machine power-on hours: approx. 86589h, spindle operating hours: approx. 66997h. The machine is available from November 2026. Documentation available. Inspection possible by arrangement. Kdodpjzu Szmofx Ai Rer

Condition: used, Year of construction: 2007, Travel X/Y/Z: 600mm/400mm/460mm, spindle-to-table distance: 200mm-660mm, table size X/Y: 700mm/410mm, max. table load: 250kg, rapid traverse X/Y: 72m/min, rapid traverse Z: 60m/min, max. spindle speed: 12000rpm, spindle power: 7.5kW, tool taper: BT40, tool magazine: 24+1, max. tool diameter: 80mm, max. tool length: 250mm, tool change time: 1.6s, control: Mitsubishi M64S, through-spindle coolant: 20bar, probing system: Renishaw, machine weight: approx. 4300kg. Including a tool cabinet with approx. 100 tool holders. Inspection possible by arrangement. Ksdpfx Aszu Sz Hei Redr

Condition: good (used), Year of construction: 2025, Universal machining center Machine type: DMG Mori DMX 60 U Control: Siemens Sinumerik One mit Celos X Year: 2025 SPECIFICATIONS X-Axis: 600 mm Y-Axis: 600 mm Z-Axis: 510 mm B-Axes: -15°/+110° C-Axis: 360° Rapid motion: (X/Y/Z): 42 m/min. Spindle speeds: 20 -15.000 rpm Spindle power: 20 / 14,5 kW Torque: 121 Nm Tool: SK 40 Tool capacity: 60 NC-panning and rotary Table Table size: 630 x 500 mm Kdjdpfezu R D Tox Ai Ror Equipment Chip conveyor Production Package Internal cooling: 40 bar Cooling tank: 600 l paper band filter Electronical handwheel Direct linear scales Preparation for Hydraulic and Pneumatic Connections Air blow Oil mist separator Caliper: Renishaw PP40 3D-Touch probe: 3d quickSET Working mode: 4
