Used Veneer Saw With Planing Head for sale (16,193)

Condition: used, Year of construction: 1970, used, good conditionmake Scheertype FM2 3000year of manufacture approx. 1970machine no. 102748cutting length 3000 mmsaw blade diameter approx. 180 mmrear support tablespace requirement approx. 3500 x 1000 x 1300 mmweight approx. 400 kgstorage location 97447 Gerolzhofen, free loaded, unpackedhandover in actual condition as inspected,without guarantee and warranty Nwodpfxsvwfpge Ag Djf

Condition: excellent (used), functionality: fully functional, cutting length (max.): 3,000 mm, type of input current: three-phase, saw blade diameter: 160 mm, total width: 1,000 mm, total length: 4,600 mm, total height: 1,400 mm, TOMESANI veneer saw with scorer 3.0 m Specification: • Condition – after comprehensive inspection, fully operational Nwedpfx Agjxb Dyzo Dof • Manufacturer – TOMESANI • Maximum working length of cut element – 300 cm • Main blade motor (160 mm diameter) – 2.2 HP • Scoring unit motor (100 mm diameter) – 0.17 HP • Pneumatic hold-down for the cut veneer • Integrated dust extraction system with built-in fan • Overall dimensions – 460 x 100 x 140 cm (L x W x H) Additional information: • The machine is in very good technical condition, ready for immediate use • The photos show the actual condition of the item for sale • Possibility to power up and test the device on site

Year of construction: 2019, condition: used, functionality: fully functional, machine/vehicle number: ADS550×5000, Power supply: 380–420 V / 50 Hz Total power: 5.5 kW Saw motors: 2 × 2.2 kW Saw blade: Ø550 mm Max. cutting length: 5000 mm Min. cutting length: 360 mm at 90° Cutting angles: 45° and 90° Repeatability: ±0.1 mm Air consumption: 60 L/min (0.5–0.8 MPa) Fully CNC controlled Two saw heads that can operate independently or synchronously Automatic positioning of the moving saw head via servo drive Nwsdjx R U Epepfx Ag Dsf Automatic height measurement system for increased precision at 45° Touchscreen control with clear interface Integrated label printer (traceability & workflow) Infinitely adjustable saw feed Very stable and heavy machine base

Condition: used, Year of construction: 1991, Cutting length 3100 mm Cutting height 45 mm Motor output 1,8 kW dimensions 4000 x 500 x 920 mm weight 450 kg Nsdpsr I E Hcjfx Ag Djwf

Condition: used, Veneer saw, veneer saw machine, jointing machine, fine cutting machine, fine cutting circular saw, Veneer saw drive motor -Veneer saw: SF Scheer drive motor EM 21 -Drive: 1.6 kW 2820 rpm -Dimensions: 265/270/H255 mm -Weight: 24 kg Nsdpfxsh Elzto Ag Dewf

Condition: used, Bore: 40 mm Cutting circle (ø): 125 mm Length: 170 mm Material: steel Blades: Planer strip knives Z2 + chamfer cutter Available: 2 pieces Nsdpfx Ajx Tu Rweg Dowf Price per piece: €239.00 + VAT

Condition: excellent (used), Year of construction: 2015, functionality: fully functional, Excellent technical condition of machine. Nsdpjwltqasfx Ag Dowf

Condition: good (used), Veneer saw, veneer sawing machine, jointing cutting machine, fine cutting machine, fine cutting circular saw -Cutting length: 3000 mm -with extraction Nsdpfx Aob A Hnhog Dowf

Year of construction: 2004, condition: reconditioned (used), Walter double saw with TRKS 200 feeder double saw blade cutting height 200 mm, engine power 40 kW, Nwedpfx Agsh R Tvts Def chain feeder with drivers with adjustable prism for different diameters. Gear to regulate the speed of feeding the material.

Condition: not inspected (used), functionality: unexamined, 5 kW 20 press cylinders 3 press cylinders individually with foot valve Each set of 5 cylinders individually disconnectable with hand valve Nedpfxex Hiqre Ag Dowf Assembly machine - cutting length: 9300 mm Total height: 2100 mm Pressing height: 1300 mm Extraction port: 120 mm

Condition: used, Year of construction: 2009, Year: 2009 - technically efficient, ready to work – after full service - discs: 500 mm - working length: 3700 mm - PC control (Windows XP) Nodpfox Ruv Iox Ag Dowf - online access - vertical and horizontal pneumatic clamps - automatic disc guards - roller feeder - support for longer profiles

Condition: excellent (used), Plane cutter head (28149) Make ISCAR type F 90 A - D160-40 M Weight 5 kg Nedpfx Ajg Er H Hjg Dswf

Condition: new, pinion heads for gang saw complete with ball joint pins and red brass bushes, spare part number 23 a + b or 235254-01 Nwjdpfjtq Eq Rjx Ag Djf

Condition: new, functionality: fully functional, Standard equipment: - Pneumatic clamping via 2 external clamping cylinders Nedpjxd Sf Refx Ag Dowf - Saw carriage guided by 2 high-precision linear guides - Extraction device for connection to a dust extraction system, connection diameter 100 mm - 1 carbide-tipped saw blade, diameter 200 mm - Front support, 250 mm wide, fixed installation, manually adjustable with planing unit - Maintenance unit Opening height: 57 mm Veneer pack cutting height: 32 mm Three-phase motor: 2.2 kW Operating voltage: 230/400 V Item no. 0174200

Condition: reconditioned (used), functionality: fully functional, machine/vehicle number: 081263, Connecting value 380V 1,85kW 4,8A pressure beam length 3100 mm pneumatic material clamping with hand lever valve chassis stop ruler 520 mm long Nedpfsh U Dbrjx Ag Dowf 6x support brackets

Condition: good (used), Year of construction: 1990, functionality: fully functional, Scheer joining and fine-cutting machine, built in 1990, machine number 83464, type FM 8- 3100 Nwsdpfx Aev Rvpkog Djf

Year of construction: 1980, condition: used, saw cutter for veneer CUTTING TOOLS ADVANTAGES - German production - almost - very good condition - guillotine used - high quality, low price cutting length 3100mm pneumatic clamp + cutting height 50mm up / down saw adjustment Njdpfx Asdnprdjg Dswf with cutter + manual travel of the aggregate + Equipped with a back panel + dimensions of the worktop 2450x800mm engine power about 2kW Dimensions Length / Width / Height 4670/900 / 1300mm weight 650kg

Condition: used, functionality: fully functional, cutting length (max.): 3,500 mm, cutting height (max.): 40 mm, type of input current: three-phase, saw blade diameter: 180 mm, – very good condition TECHNICAL SPECIFICATIONS: – cutting length: 3500 mm – cutting height: 40 mm – cutting width on the right side: 960 mm – saw motor: 3 kW – milling cutter motor: 1.5 kW – feed motor: 0.75 kW – stepless cutting speed adjustment – blade diameter: 180 mm – cutter diameter: 70 mm – extraction port diameter: 100 mm Nwedsw I Efgopfx Ag Djf – upper pressure beam – automatic milling cutter approach – possibility of manual or automatic cutting – overall dimensions (L/W/H): 530 / 205 / 130 cm – weight: ~ 800 kg

Year of construction: 1998, condition: used, functionality: fully functional, Rapid dgl the saw blades automatically adjust to the desired dimension, control via touch panel, blade diameter 500 mm Nsdsw I Hz Aopfx Ag Dewf rotation speed 2710 cutting angle 45-90° cutting length approx. 3000 mm pneumatic clamping air requirement 200 NI the saw is in excellent condition, ready for immediate use, testing possible, invoice issued

Condition: good (used), Cutting length 3050 Handwheel tension Chain feed Space required approx. L x W x H approx. 4200 x 800 x 1400 mm Nwodpfowkfqpsx Ag Djf All information is subject to change without notice.

Year of construction: 2019, condition: excellent (used), Double-head automatic saw for cutting aluminium and PVC profiles, equipped with electronic control and pneumatic tilting of the heads. Features a virtual tilting axis for the cutting heads. Cutting length: 5000 mm Control: Electronic with automatic feed of the movable head Njdpfswwtwqox Ag Djwf Tilting of heads: pneumatic, with adjustable angles (range 90° to 45°). Manual adjustment of heads: other angles up to 20°30'. Additional features: Hydropneumatic blade feed, profile clamping.

Year of construction: 2012, condition: excellent (used), Double-head saw with 3 controlled axes for aluminium, PVC, and light alloys, featuring automatic movement of the mobile head and electronic management of all angles from 45° (internal) to 15° (external), with precision up to 280 positions per degree. Nodsxqdu Depfx Ag Djwf

Condition: used, 6 head band saw IDC000078 - manufacturer: Forestor - 6 head band saw - complete with electric cabinet - complete with electric cabinet - With infeed table Nodpfxot D A Suj Ag Dowf - with band sharpener - used for block cutting

Condition: good (used), Year of construction: 2016, functionality: fully functional, Year: 2016 Nwedjtqmmdspfx Ag Def - technically efficient, ready to work - after full service - cutting length: 4000 mm - discs: 500 mm (feed from the rear) - pneumatic inclination of both heads: 90°, 45°, 22.5°, intermediate angles set manually - operator panel with Windows - cooling and lubrication installation for both heads - movable roller feeder - vertical and horizontal pneumatic clamps - automatic disc covers - delivery device for long elements - safety gates

Condition: ready for operation (used), Year of construction: 1978, Höfer veneer saw incl. joining milling unit Cutting and milling length 3550 mm Cutting height 45 mm Saw motor power 2.2 kW Milling motor power 1.1 kW Extraction channel Workpiece clamping by handwheel Nwodowq D Tpspfx Ag Dof Year of manufacture 1978 Price 2800.-
