Used Stolle Surface Plate for sale (18,123)

Condition: excellent (used), Year of construction: 1995, overall weight: 5,600 kg, total height: 400 mm, total length: 4,000 mm, total width: 1,875 mm, T slotted bed plate UNION - DT Cast iron floorplate 4000 x 1900 x 400 mm Floorplate Length: 4000mm Floorplate Width: 1875mm Gbodpfxezc Ihgj Aagon Height: 400mm No. Of T-slots: 6 Distance from T to T-slot / Jump:315mm T -slot size: 36mm Weight a plate approx.: 5600kg Number of matching pieces: 2 Length: 4000mm Width: 1875mm Height: 400mm Weight: 5600kg Please Note: The information on this page has been obtained to the best of our ability and belief, and from the manufacturers where possible. It is given in good faith, but its accuracy can not be guaranteed. Accordingly, it will not form a representation or constitute contractual terms. We advise you to check any vital details!

Condition: ready for operation (used), Year of construction: 1993, grinding length: 800 mm, grinding width: 420 mm, total height: 420 mm, dimensions: 800x420x420 mm Gedpfozcyy Uex Aagebn magnetic surface: 700x400 mm

Condition: good (used), Year of construction: 2008, sheet width 2050 mm plate thickness 20.0 mm ST pre-bending 16.0 mm ST diameter of upper rolls ca. 270 mm side roll diameter ca. 240 mm diameter of lower rolls ca. 250 mm Number of working hours ca. 7.800 h Control "EASY PRO" oil volume ca. 200 Liter voltage 380 V total power requirement 13.5 kW weight ca. 9.000 kg Dimensions (only the machine) 4000 x 2080 x 1800 mm Good condition (!!) Current list price approx. 150.000 euros Special price available upon request Features: - Robust electro-hydraulic 4-roll round bending machine * Arc-shaped feed of the side rollers (swing arm technology) - 4-roller design offers a wide range of bending and rounding options * Rolling process completed in a single pass - Mobile control unit * DAVI "DAVI EASY PRO" numerical control * Manual or automatic operation selectable * Programming "Self-Learning" mode available * Control of all rollers and machine axes * Digital position display for the rollers - Curved feed of the side rollers (DAVI "PSG" guide system) * Tight bending radii of up to 1.1 times the upper roller diameter possible * Instead of the usual 1.5 times with linear guides * Optimal bending = short sheet ends during bending - Conical rolling possible via roller tilt * Tight diameters possible due to low machine frame - Electronic roller parallelism - Stepless speed adjustment (max. 5.0 m/min) - Bending on both sides - Forged and hardened rollers with a hardness of 53-55 HRC - Low-maintenance, robust machine design Godpfozc Rv Tex Aagjbn - Easy sheet removal thanks to low machine frame - Sturdy welded steel construction - Electro-hydraulic swivel bearing for easy tube removal - Operating instructions

Condition: reconditioned (used), functionality: fully functional, Year of construction: 1997, sheet thickness steel (max.): 16 mm, cutting length (max.): 4,000 mm, HYDRAULIC SHEAR LVD MVSB 40/16 Serial number 24159 Yom 1997 Gbjdeuipu Eepfx Aagjn TECHNICAL SPECIFICATIONS Max. sheet thickness St45 16 mm Cutting length 4050 mm Distance between uprights 4250 mm Range back gauge 1000mm Min. cutting angle 0.5 ° Max. cutting angle 2.0 ° Min. number of strokes/min. 7 Max. number of strokes/min 26 Min. blade clearance 0.5 mm Max. blade clearance 1.6 mm Motor power 22 kW Approx weight 20500 Kg LxWxH 4800x2170x2750mm Accessories included; Electrical adjustment of back gauge 1000mm with Go-to controller blade clearance and cutting angle adjustable. 1 x Front support 1500mm, one with 90° square arm front support 1 x Front support of 1500mm Foot pedal

Condition: good (used), Year of construction: 2004, overall weight: 21 kg, T slotted bed plate BWF - RK-4 MACH-ID 8883 Make: BWF Type: RK-4 Year: 2004 Length:275mm Width:180mm Height:115mm Weight:21kg Gedpezcu I Tofx Aagsbn Please Note: The information on this page has been obtained to the best of our ability and belief, and from the manufacturers where possible. It is given in good faith, but its accuracy can not be guaranteed. Accordingly, it will not form a representation or constitute contractual terms. We advise you to check any vital details!

Condition: good (used), Year of construction: 2015, sheet width 3050 mm plate thickness 13.0 mm thickness at "Niro-steel" 8.0 mm work height max. 930 mm no. of strokes 9 - 17 Hub/min cutting angle 0.5 - 3.0 ° down holder 18 Stück Control SC 90 engine output 22.0 kW weight of the machine ca. 9500 kg range L-W-H 4270 x 2200 x 2250 mm Good / well-maintained condition (!!) Current list price approx. 80.000 euros Features: - Electro-hydraulic / slide-guided guillotine shear - HACO CNC control model "SC 90" * Preset positioning of the backgauge Gjdjzczgcjpfx Aagjbn * Digital display of actual position * Electro-hydraulic cutting angle adjustment * Electro-hydraulic cutting gap adjustment * LCD display * Emergency stop switch - NC electro-motorized backgauge, on ball screws - Hydraulic hold-down devices - Front finger guard - Ball bearings in the support table * Support table with recessed handles - 1x side stop, with mm scale - 1x front support arms - 1x freely movable foot switch - Rear safety guard (no light barrier) - Operating instructions in German (PDF)

Condition: good (used), Roughness measuring device, HOMMEL / Jenoptik, type Waveline 20 (Tester T1000), in fully functional condition. Gedpfx Ajzcy N Aeagsbn Plate size: 400 x 280 mm Column height: 400 mm Plate width: 280 mm Plate length: 400 mm Adjustment range, max.: 300 mm

Condition: excellent (used), Year of construction: 2018, functionality: fully functional, grinding length: 500 mm, grinding width: 250 mm, total height: 1,800 mm, total length: 2,250 mm, total width: 1,400 mm, feed rate X-axis: 25 m/min, grinding wheel diameter: 205 mm, table length: 500 mm, type of input current: three-phase, table width: 250 mm, grinding wheel width: 19 mm, spindle speed (max.): 2,900 rpm, overall weight: 1,350 kg, grinding spindle motor power: 1,500 W, rotational speed (max.): 2,900 rpm, grinding spindle speed: 2,900 rpm, power: 1.5 kW (2.04 HP), grinding wheel speed: 2,900 rpm, input voltage: 400 V, disc diameter: 205 mm, Metallkraft FSM 2550 Surface Grinder Machine Type: Surface Grinder with NC Controlled Vertical Feed Year: 2018 Control: NC Control Condition: Very Good Includes NC Controlled Vertical Feed Table Enclosure Guard Electro-Magnetic Chuck Wheel Dresser Coolant Equipment Halogen Light DRO Auto-Lube Technical Specifications Grinding Wheel Diameter: 180 to 205mm Grinding Wheel Width: 19 to 13mm Grinding Wheel Bore: 31.75mm Spindle Speed: 2900rpm Table Dimensions: 500 x 250mm X Axis Travel Speed: 5-25m/min Drive Motor Power: 1.5kW Electrical Connection: 400V/3Phase/50Hz Machine Dimensions: 2250x1400x1800mm Gbjdpfxov Iq Shj Aagsn Machine Weight: 1350kg Notes: *Specifications are given in good faith but not guaranteed*

Condition: excellent (used), Year of construction: 2000, control type: NC control, actuation type: hydraulic, controller manufacturer: Davi Smart, number of rollers: 4, roller (bottom) diameter: 340 mm, roller (top) diameter: 370 mm, side roll diameter: 320 mm, roller length: 3,100 mm, sheet thickness (max.): 25 mm, overall weight: 18,500 kg, total length: 5,900 mm, total width: 2,200 mm, total height: 2,300 mm, power: 30 kW (40.79 HP), 4 roll plate bender Davi Promau - MCB 3037 MACH-ID 9613 Make: Davi Promau Type: MCB 3037 Control: Davi Smart Year: 2000 Conical bending attachment Extended roll end for section bending jobs Digital read out position side rolls Central lubrication Rolling width: 3100mm Rolling thickness 3x toproll Ø:20mm Gsdpfx Aozcnuysagjbn Rolling thickness 5x toproll Ø:25mm Rolling thickness prebending: 22mm Top Roll Ø: 370mm Bottom Roll Ø: 340mm Side roll Ø: 320mm Number of rolls: 4 Rolling speed: 0-5 Adjustiment lower roll: 0-200mm/min. Adjustment side rolls: 0-200mm/min. Number of driven rolls: 2 Power: 30kW Length: 5900mm Width: 2200mm Height: 2300mm Weight: 18500kg Please Note: The information on this page has been obtained to the best of our ability and belief, and from the manufacturers where possible. It is given in good faith, but its accuracy can not be guaranteed. Accordingly, it will not form a representation or constitute contractual terms. We advise you to check any vital details!

Condition: excellent (used), Year of construction: 2016, functionality: fully functional, CNC Precision Surface and Profile Grinding Machine This machine is ideally suited for precision applications in tool and mold making. Technical Details: Grinding surface: 800 x 450 mm Grinding area: 800 x 400 x 375 mm Table load (max.): 700 kg X-axis = Longitudinal movement of worktable Table longitudinal stroke: 20 - 850 mm Table drive: Electromechanical with toothed belt drive Table speed: 5 - 35,000 mm/min Table setup: Electric handwheel and direction push button Y-axis = Vertical movement Distance from table to spindle center: 140 - 525 mm Vertical drive: Electromechanical with ball screw Vertical speed: 50 - 2,000 mm/min Vertical adjustment via electric handwheel and direction pushbuttons Minimum infeed 0.001 mm Measuring system: glass scale Gbodpfxszcyyhe Aagon Z-axis = Transverse movement Maximum transverse travel 400 mm Drive type: electromechanical with ball screw Transverse speed 50 - 2000 mm/min Transverse travel adjustment via electric handwheel and direction pushbuttons Measuring system: glass scale C-axis = Grinding spindle Grinding spindle motor 7 kW Grinding spindle speed 1400 rpm Grinding wheel standard 300 x 50 x 76.2 mm Spindle bearing: Precision roller bearing Lubrication: Lifetime lubrication Connected load: approx. 19 kVA Total weight: 3500 kg Equipment: - Electro-permanent magnetic chuck Clamping surface 800 x 400 mm, Pole spacing 18 mm, with 16-stage holding force control and automatic Magnetic pole reversal for demagnetization - Leveling blocks For setting up and leveling the machine - Grinding wheels and two flanges - Partial enclosure Open at the top for loading with a sliding door - Dressing system Consisting of a holder for a prism arm or fork dresser Practicle arm for single-point diamond (MK O) or shaped diamond - Grinding spindle speed control Peripheral speed 10-32 m/s The peripheral speed of the grinding wheel is kept constant (V-constant control) with a 7 kW grinding spindle motor - Universal paper belt filter unit UPF 100 Tank capacity approx. 280 liters, Pump capacity 20 liters/minute at 1.5 bar - Air purifier Flow rate approx. 1000 m³/h - Compressed air ports For easier removal of large workpieces with a manual compressed air valve in the machine's work area. - Mobile balancing unit With optical operator guidance for dynamic balancing of the grinding wheel directly in the machine. Imbalance size and position are calculated automatically. With transport case. - Cleaning set Hand-held impulse nozzle for cleaning the work area - Documentation/Manual For sale is our reliably operating grinding machine from mold making. The machine was purchased new in 2016 and is in good technical condition, having been used for a maximum of 20 hours per week. It runs perfectly and is being sold solely due to an investment in a larger model.

Condition: good (used), Year of construction: 2010, sheet width 4100 mm plate thickness 6.35 mm thickness at "Niro-steel" 4.00 mm cutting angle 0.5 - 2.5 ° cutting gap adjustment 0.05 - 0.8 mm no. of strokes 9 - 26 Hub/min back stop - adjustable 10.0 - 750 mm down holder 22 Stk. oil volume 200 ltr. engine output 7.5 kW weight 8000 kg. range L-W-H 5145 x 2200 x 1750 mm From a maintenance workshop Very well-maintained / good condition With very few operating hours (!!) Current list price approx. 60.000 euros Special price upon request Features: - Robust electro-hydraulic, slide-guided sheet metal shear - LVD control panel centrally located on the front of the machine (left) - Electro-hydraulic cutting angle adjustment * Includes digital display of actual values - Manual cutting gap adjustment * via handwheel from the front (left) * Includes analog value display - Electro-motorized backgauge with ball screws * Includes digital actual position display * Rapid traverse is possible - 1x extra-long side stop 3,000 mm, with support foot - 1x long support arm - Ball-bearing recessed handles in the support table - Front finger guard - Rear sheet metal chute - Safety device - rear (protective grille) - 1x freely movable foot switch - Machine lighting at the front (custom-built) - Operating instructions Godpfx Aezcqy Soagjbn

Condition: ready for operation (used), Year of construction: 1988, Horizontal surface grinding machine Okamoto Type PSG 63 – UAN Year of manufacture: 1988 Grinding length: 600 mm Grinding width: 320 mm Gsdpfszcv Tqsx Aagobn Max. workpiece height: 500 mm Table travel (longitudinal): 750 mm Table travel (cross): 340 mm Grinding wheel diameter: 350 mm Grinding wheel width: 40 mm Spindle speed: 1500 rpm Rapid vertical feed: 400 mm/min Power: 3.7 kW Automatic feed Magnetic chuck Coolant system Weight: 2500 kg Price: EUR 2,000—plus VAT, ex location

Condition: excellent (used), Year of construction: 2008, functionality: fully functional, STC-Ref:G-022-7715 Heidelberg Plattenabkante // Platebender, Year: 2008 equipped: - suitable for Heidelberg SM / CD - Plate bender Gbedpfxezcuzyj Aagon --> available: 06/2026

Condition: good (used), Year of construction: 1979, functionality: fully functional, machine/vehicle number: 1054, grinding length: 400 mm, grinding width: 150 mm, Table length: 400mm Table width: 150mm Maximum cutting length: 400mm Maximum grinding width: 150mm Maximum workpiece weight: 75kg Distance spindle to table: 400mm Table speed 1-24 m./min. Sharpening stone diameter: 25mm Spindle speed: 900 – 4500 rpm. Gbsdpfx Asr Eq U Ssagsn Year of construction: 1979

Condition: used, Year of construction: 2000, functionality: fully functional, OKAMOTO ACC 95DX Precision Surface Grinder – 400V For sale is an OKAMOTO ACC 95DX surface grinder. This is a robust industrial machine designed for precision surface grinding, making it ideal for toolmaking and manufacturing applications. The machine comes with a separate control console. Inspection and test run available by appointment. Machine Data: • Manufacturer: OKAMOTO Machine Tool Works, Ltd. Gjdjwtm Dijpfx Aagebn • Model: ACC 95DX (Nameplate: ACC95DXM) • Serial number: 690277 • Voltage: 400 V • Phases: 3 • Frequency: 50 Hz • Total connected load: 8.6 kVA • Control/Auxiliary voltage: AC 100 V, DC 22/24 V (as per nameplate) Equipment / Notes: • Side-mounted control console (see photo) • Grinding head/safety enclosures included • Availability: immediate / by arrangement • Sale ex stock, subject to prior sale

Condition: good (used), Year of construction: 1982, 1 used surface and guideway grinding machine Gbjdeynglbspfx Aagon Manufacturer: ELB Model: SWDE 30 U CNC Year of manufacture: 1982 / 1999 Control type: CNC Control: Mitsubishi 520 Location: NRW Country of origin: Germany Delivery time: short notice Delivery terms: ex stock TECHNICAL DATA Grinding length: 3000 mm Grinding width: 900 mm Workpiece height: 600 mm Electromagnetic chuck: 3000 x 900 mm Pole pitch: 18 mm Grinding wheel dimensions: Ø 500 x 100 mm Control: Mitsubishi 520 Total power requirement: 18.5 / 5.5 kW Machine weight approx. 19 t Space requirement approx. 9 x 4.5 x 3.5 m Shipping dimensions approx. 13 x 2.5 x 3.5 m

Condition: good (used), 2 used T-slot angle plates Gsdsy Iakfopfx Aagsbn Height: 1500 mm Width: 1000 mm Depth: 500 mm 10 transverse slots 3 longitudinal slots First-class surface finish

Condition: ready for operation (used), functionality: fully functional, Year of construction: 2008, roller (top) diameter: 130 mm, side roll diameter: 110 mm, working width: 1,030 mm, sheet thickness (max.): 6 mm, sheet thickness steel (max.): 6 mm, power: 2.2 kW (2.99 HP), number of digital displays: 3, Equipment: emergency stop, foot remote control, 4-Roll Round Bending Machine Manufacturer: Sahinler, Type: 4RM 10-130 HRC Year of Manufacture: 2008 Technical Data Manufacturer: Sahinler Type: 4RM 10-130 HRC Year of Manufacture: 2008 Usable Length: 1030 mm Top Roll Diameter: 130 mm Side Roll Diameter: 110 mm Sheet Thickness (without pre-bending): 6 mm Sheet Thickness (with pre-bending): 5 mm Total Power: 2.2 kW Dimensions: 2.4 x 1 x 1 m Weight: approx. 1.5 t Equipment • Hardened rolls • Digital display for roll positioning Gbjdjzcpu Ujpfx Aagjn All information without guarantee.

Condition: good (used), Year of construction: 2008, functionality: fully functional, HESSEMANN 3-HEAD SANDER: Abrasive belt dimensions: 2,620 x 1,400 mm 1 Longitudinal sanding unit (with contact roller for calibration work (steel)) Gbsdpfox Rdn Tex Aagjn Roller diameter: 250 mm Belt speeds: approx. 18 m/s 22 kW Anti-wear braking unit, automatic band length adjustment Dust extraction system controlled depending on the workpiece, counter-rotating abrasive belt, abrasive belt grit compensation by computer Belt speeds: 1.0 - 18 m/s Drive: 15 kW 1 Longitudinal sanding unit Belt speeds: 1.0 - 18 m/s Drive: 15 kW Includes continuously adjustable sanding speed via electronic frequency inverter, with double number of extraction holes for the dust extraction device. Anti-wear braking unit, automatic band length adjustment for abrasive belt edges potentially of different lengths; dust extraction controlled by workpiece detection, deactivatable, counter-rotating abrasive belt. 2 Pressure beams with selective pressure adjustment system – CSD® system Continuously adjustable individual pressure elements, for single and multiple workpiece feeding. Spacing: 32 mm. Tolerance compensation for workpieces up to 2 m by maintenance-free pressure magnets. Working width as well as start and end positions of the pressure beam are electronically adjustable. The pressure elements are driven by lifting electromagnets capable of continuously varying the force of each sanding pad as the workpiece passes through the machine. This innovative CSD® technology guarantees constantly proportionate pressure relative to pad overlap on the workpiece. The risk of sanding through on the edges is virtually eliminated by this dynamic, continuous pressure force control.

Condition: used, Year of construction: 2021, functionality: fully functional, grinding length: 6,000 mm, grinding width: 800 mm, total height: 800 mm, Technical specifications: • Application: Surface grinding and profile grinding • Grinding area: 6000 x 800 x 800 mm Gsdpozcyccsfx Aagjbn • Grinding wheel: 500 x 100 x 203.20 mm • Spindle power: 43 kW • Connected load: 89 kW • Operating hours: approx. 4,400 machine operating hours / approx. 1,600 spindle operating hours • Year of manufacture: 2021 The machine is currently fully functional and can be inspected at the supplier’s premises by appointment. Price is quoted ex works in Lower Saxony; the machine will be prepared/packaged for transport. The machine can be taken over immediately. Equipment: • CAM profile grinding software “WinWop” • Diamond roll dressing unit with 160 mm diamond wheel • Coolant recirculation system • Grinding mist extraction system • Automatic balancing • Spark detection system • Belt filter system with magnetic separator • VPN connection for remote diagnostics/remote maintenance

Condition: used, Year of construction: 2015, total width: 850 mm, total height: 1,200 mm, Weight: 1.250 kg Dimensions (LxBxH): 182 x 85 x 120 cm - Year: 2015 - Documentation available: No - CE certificate present: No - Serial number: 14053701 - Min. planing width [mm]: 10 - Max. planing width [mm]: 400 - Infeed table length [mm]: 880 - Outfeed table length [mm]: 880 - Total table length [mm]: 1820 - Work table width [mm]: 410 - Cutterhead diameter [mm]: 100 - Number of knives [pcs]: 4 Godpfx Asxz D Dtsagjbn - Number of height adjustment cylinders [pcs]: 1 - Rollers in table [pcs]: 2 - Diameter extraction nozzle [mm]: 110 - Height adjustment: Manual - Voltage [V]: 400 - Transport dimensions: 1820mm x 850mm x 1200mm (l x w x h) - Transport weight [kg]: 1250kg - Transport packages [pcs.]: 1 Financial information VAT: The price shown is exclusive of VAT VAT/margin: VAT deductible for entrepreneurs Delivery and trade-in always possible for everything in the industrial sectors Yorick Diebels

Condition: used, Year of construction: 2000, plate punches 1. Beil 780-S-St - 3-hole 780/425 - table 1000-1400 2. Bacher 2005 - 2-hole 425 - table 730-1000 3. Bacher 2045 - 2-hole 425 - table 730-1000 4. Beil 425-T-H - 2-hole 425 - table 520-770 5. Stanze 2-hole 425 - table 420-660 - metal frame - SOLD 6. Billows 2-hole 225 - table 650-950 7. Bacher 2032 2-hole 225 - table 300-400 (4) - 1x SOLD Gbsdpfx Aajcqxv Tjgon 8. Heidelberg SM52 - 425 plate punch 9. Heidelberg SM52 - plate bender - SOLD

Condition: used, length 450 mm width 140 mm height 100 mm 2 magnetic plates with control unit approx. 450 x 140 x 100 mm Godpfszcghrjx Aagjbn

Condition: used, length 900 mm width 505 mm height 110 mm weight 310 kg The electro-magnetic clamping plate is in good, ready-to-use condition. Length: 900mm Width: 505mm Height: 110mm Weight: 310kg We have two identical magnetic chucks with the same dimensions. See S9061 Gjdpfx Aezcgkysagsbn

Condition: used, length / mm width / mm Gbjdozcgiijpfx Aagen
