Used Weinig Profimat 23 Fortec for sale (5,243)

Condition: excellent (used), functionality: fully functional, Working width: 230 mm Working height: 160 mm Number of spindles: 5 Spindle configuration: Ndjdpfx Agjx Hzv Tsrob 1. Bottom 15 kW 2. Right 11 kW 3. Left 11 kW 4. Top 15 kW 5. Bottom 7.5 kW Spindle speed: 6000 rpm Spindle diameter: 50 mm 3 feed rollers in the work table Feed speed adjustable via inverter up to 60 m/min Feed driven by cardan shaft Pneumatic pressure rollers Technical documentation Machine dimensions: 300x180x170 cm (H) Weight: 3500 kg

Condition: excellent (used), Four-side planer Weinig Hydromat 23C Working width: 230 mm Working height: 160 mm Number of spindles: 7 Spindle arrangement: 1. Bottom 15 kW 2. Right 7.5 kW 3. Left 7.5 kW 4. Top 15 kW 5. Bottom 30 kW (multi-blade saw) 6. Bottom 7.5 kW (hydro support) 7. Top 7.5 kW (hydro support) Spindle speed: 6000 rpm Spindle diameter: 50 mm 4 feed rollers in the worktable Feed speed adjustable via frequency inverter up to 36 m/min Feed drive powered by cardan shaft Pneumatic pressure elements Ndsdpfx Aoxlcufjgrob Technical documentation

Condition: excellent (used), Year of construction: 1997, I sell the complete window profile production line: 1pc. 5-spindle fourside moulder with saw aggregate Weinig Unimat 23EL. - without HESS sanding machine - another machine for change available on agreement 2pcs. tenoning profiling centre Weinig Unitec 10 2pcs. profiling automat centre Weinig Univar 10 1pc. CNC drilling machine KOCH WinDoor - set of complete Weinig automation feeders and conveyors Year 1997. Nsdpfx Agsfzzidjrsdb Profile heads OERTLI. Available immediately. Uninstalled and loaded on original Pallets. Condition very good !

Condition: reconditioned (used), LEADERMAC THUNDERMAC 923T SPINDLES: 9 X 50MM X 6000 RPM Ndsdpfxszv S A Hj Agrob BOTTOM (22 KW) - RIGHT (15 KW) - LEFT (15 KW) - RIGHT (15 KW) - LEFT (15 KW) - TOP (22 KW) - BOTTOM (22 KW), TOP (22 KW) - BOTTOM (22 KW). WORKING WIDTH: 230 (245) MM, HEIGHT: 160 MM. MAX FEED SPEED 80M/MIN (POSSIBLE TO INCREASE TO 150M/MIN) STRAIGHT JOINTERS. PROFILE JOINTERS. CNC POSITIONING ON SPINDLES 3, 5, 6, 8 CONNECTION: 380 V / / 50 HZ 400 AMPS. FULL DOCUMENTATION INCLUDED.

Condition: excellent (used), Year of construction: 2011, functionality: fully functional, working width: 230 mm, planing height: 120 mm, spindle diameter: 40 mm, spindle speed (min.): 8,000 rpm, Weinig Powermat 400 4 Spindles 230 x 120 mm All Powerlock with 8000 rpm Feed speed 5–30 m/min Bottom 7,5 kW Right + Left combination motor 11,0 kW Top 11,0 kW Radiale CNC controlled setting of width and height in combination with Memory System Infeed table 2,5 m Automatic Waxilitpump Ndsdpfx Asz Dvh Hjgrsb Memory System

Condition: used, Year of construction: 2010, max. workpiece length 4500,6000 mm profile spindle 4 Stück main drive 30 kW Weinig Conturex C226 Machining Center ----- For sale on behalf of a client; includes software (Klaes) and tooling (Oertli) for IV68/IV78/IV92 and Wood/Alu 68–92 systems. Machine still is electrically connected. Technical specifications and window cross-sections available upon request! ----- Price of the above-mentioned machine available upon request! ----- Dismantling and reinstallation available upon request! (Technical specifications provided by the manufacturer – subject to change/no liability assumed!) Nodpfx Ajzqvnijgredb All prices are net, plus statutory VAT.

Condition: used, Year of construction: 2013, Number of spindles 5 St. Working width 20 - 230 mm Working height 8 - 120 mm Length of the planing table 2500 mm Feed motor 1,1 kW Feed speed stufenlos regelbar 2-12 m/min. weight of the machine ca. 2500 kg Control MemoryPlus 1 WEINIG VARIOMAT Planing and Moulding Machine ----- Nsdpfey Spvfox Agredb Brief Summary: ----- - 5 spindles - Powerful motors - Cycle-controlled jointing - MemoryPlus control system - Option: Stähle-Hess Saturn single-piece sanding machine Technical Manufacturer's Description: ----- Working width: 20 – 230 mm Working height: 8 – 120 mm 1st Spindle: Horizontal Bottom ----- Motor with brake: 7.5 kW Diameter: 40 mm Speed: 6000 rpm Tool cutting circle: 125 – 145 mm Axial adjustment range: 5 mm Rebating device incl. rebating cutters 2nd Spindle: Vertical Right ----- Motor with brake: 11.0 kW Diameter: 40 mm Speed: 6000 rpm Tool cutting circle: 93 – 232 mm Minimum tool diameter at fence level: 93 mm Maximum tool diameter behind fence level: 180 mm Maximum moulding depth: 45 mm Axial adjustment range: 30 mm Insert segment incl. additional fence lip: 125 mm Insert segment incl. additional fence lip: 150 mm 3rd Spindle: Vertical Left ----- Shared motor with 1st right spindle Diameter: 40 mm Shared speed with right spindle Tool cutting circle: 93 – 232 mm Maximum moulding depth: 45 mm Minimum moulding depth at 200 mm tool cutting circle: 20 mm Axial adjustment range below table: 30 mm Insert segment: 125 mm Insert segment: 150 mm 4th Spindle: Horizontal Top ----- Motor with brake: 11.0 kW Diameter: 40 mm Speed: 6000 rpm Tool cutting circle: 125–200 mm Maximum rebate depth: 30 mm Minimum rebate depth (for tool cutting circle up to 200 mm): 20 mm Axial adjustment travel: 30 mm 5. Horizontal Bottom Spindle ----- Motor with brake: 11.0 kW Diameter: 40 mm Speed: 6000 rpm Tool cutting circle: 125–200 mm Maximum rebate depth: 15 mm Axial adjustment travel: 10 mm Table plates with wooden inserts for the bottom spindle Additional outfeed plate above the bottom spindle for wooden inserts Feed System ----- Frequency-controlled feed: 1.1 kW, infinitely variable (2–12 m/min) Double-pendulum roller opposite the left spindle Axial adjustment travel of feed rollers opposite the left spindle: 35 mm Durofer-coated spiked feed rollers Pneumatic pressure for feed rollers (incl. water separator) Cycle-controlled jointing to support manual jointing. The infeed roller is released once the second feed roller has engaged the workpiece. After the workpiece clears the second feed roller, the infeed roller returns to its starting position for the next workpiece. Additional Features: ----- MemorPLUS Control System Width and height adjustment via controls (Spindles 3 and 4: radial CNC-axis controlled) ----- Price for the above-mentioned machine available upon request! ----- OPTIONAL ADD-ON (at extra cost) — Stähle-Hess Saturn #7008: Machine previously used in conjunction with the Stähle-Hess Saturn Duo Single-P...

Condition: used, Tenoning spindle 2 Stk. Number of milling agregates 5 St. Spindle diameter 50 mm Control Weinig, PC-Nexus Weinig Unicontrol 10 NC Window System — Optional: Extensive Tooling Set ----- Optionally available (at an additional cost): IV 68 Wood, Wood/Aluminum IV 78 Wood, Wood/Aluminum IV 68 Entrance Doors Manufacturer's Technical Description: ----- Nodezawizjpfx Agredb Item 1: Weinig Unicontrol 10 NC Window System ----- Cross-cut Saw ----- with laser alignment light; motor power: 3 kW; spindle diameter: 40 mm; spindle speed: electronically variable (with brake) from 3,000 to 6,000 rpm. Max. tool cutting circle: 400 mm Axial adjustment: 150 mm via NC axis Radial adjustment: pneumatic, to 8 positions for top edge rounding Horizontal bottom rounding unit ----- Axial adjustment travel: mechanically coupled with cut-off saw 1st Tenoning and Slotting Spindle ----- Motor power (with brake): 15 kW Spindle diameter: 50 mm Spindle speed: 2,925 rpm Max. tool cutting circle: 400 mm Tool clamping length: 640 mm Axial adjustment travel: NC axis Home position (below table): 5–10 mm Radial adjustment travel: fixed 2nd Tenoning and Slotting Spindle ----- Motor power (with brake): 11 kW Spindle diameter: 50 mm Spindle speed: 2,925 rpm Max. tool cutting circle: 400 mm Tool clamping length: 320 mm Axial adjustment travel: NC axis Radial adjustment travel: NC axis Home position (below table): 5–10 mm 1st Profiling Spindle (Climb and Conventional Milling) ----- Motor power (with brake): 11 kW Spindle diameter: 50 mm Spindle speed: 6,000 rpm Tool cutting circle: 140 mm Max. tool diameter: 232 mm Tool clamping length: 400 mm (with outboard bearing) Axial adjustment travel: 350 mm (NC axis) Radial adjustment travel: NC axis Home position (below table): 5–10 mm 2nd Profiling Spindle ----- Motor power: 11 kW Spindle diameter: 50 mm Spindle speed: 6,000 rpm Tool cutting circle: 140 mm Max. tool diameter: 232 mm Tool clamping length: 400 mm (with outboard bearing) Axial adjustment travel: 350 mm (NC axis) Radial adjustment travel: NC axis Home position (below table): 5–10 mm Horizontal Profiling Unit (Top) ----- Motor power (with brake): 3.0 kW Spindle diameter: 40 mm Clamping length: 40 mm Spindle speed: 5,850 rpm Max. tool cutting circle: 130 mm Pneumatic adjustment: 8 positions (axial and radial) 3rd Profiling Spindle ----- Motor power: 11 kW Spindle diameter: 50 mm Spindle speed: 6,000 rpm Tool cutting circle: 140 mm Max. tool diameter: 232 mm Tool clamping length: 400 mm (with outboard bearing) Axial adjustment travel: 350 mm (NC axis) Radial adjustment travel: NC axis Home position (below table): 5–10 mm Vertical Profiling Unit (Right, at Machine End) ----- Motor power (with brake): 3.0 kW Spindle diameter: 40 mm Clamping length: 160 ...

Condition: used, Year of construction: 2009, max. workpiece length 4500 mm profile spindle 1 Stück main drive 20 kW Control Siemens Weinig Conturex 2 C 114 ----- Working width: 40-260 mm Working height: 25-110 mm 2 x PowerGrip clamp tables, 2 x 2280 mm ----- Workpiece length 200 - 4,500 mm Workpieces over 2,700 mm in length are machined using a repositioning cycle. Main spindle 1: ----- Motor with brake 20 kW HSK 63F Electronically adjustable speed 2,000-18,000 rpm Maximum tool length from flat surface HSK 63 F: 290 mm With C-axis Tool magazine: ----- Number of pockets: 30 mm Pitch between pockets: 100 mm Permanently installed multi-spindle drilling head ----- For horizontal and vertical drilling and milling work without tool changes ----- Price ex-site Prices for disassembly and loading onto customer trucks Transport within Germany and abroad as well as reassembly Commissioning and, if required, new profiles are available upon request! Used tools included (drawings available upon request): ----- Wood: IV 68, 78, 88, opening inside and out, with hinged weatherboard Wood-aluminum: IV 68/68, 78/78, 87/68, 97/78 Lift-and-slide doors IV 68 and 78 Front doors IV 68 and 78 Pivot windows Corner connection: counter/dowel Technical specifications according to the manufacturer - no guarantee! Ndjdpewunwyofx Agrjb Detailed technical description available upon request!

Condition: used, Year of construction: 1999, Tenoning spindle 1 St. Number of milling agregates 4 St. Spindle diameter 50 mm Control Weinig PC-Nexus Weinig Unicontrol 6 with NC spindles ----- Machine available for inspection while still in operation until September 2026 Summary of technical data (please inquire about any additional accessories included) Item 1: Cross-cut saw ----- > Electronic cross-cut saw, horizontally continuously adjustable > Number of tools: 1 unit > Spindle speed: 2,800 rpm > Spindle diameter: 40 mm > Max. tool diameter: 400 mm > Motor power: 3.0 kW > Laser alignment light for identifying the cut position > NC length stop mounted on the slotting table included; positioning of the cross-cut saw integrated into the control system. > Length 3500 mm Item 2: Tenoning and slotting spindle ----- > Number of tools: variable, infinitely adjustable via NC axis > Tool clamping length: 320 mm > Vertical spindle stroke: variable, infinitely adjustable 254 mm via NC axis > Spindle speed: 3500 rpm > Spindle diameter: 50 mm > Max. tool diameter: 320 mm > Motor power: 11 kW Item 3: 1st profiling spindle (climb-cut and conventional-cut capable) ----- > Position: vertical right > Number of tools: 1 pc. > Tool clamping length: 120 mm > Spindle speed: 6000 rpm > Spindle diameter: 50 mm > Max. tool cutting circle: 232 mm > Motor power: 7.5 kW Item 4: 2nd profiling spindle ----- > Position: vertical right > Number of tools: variable, infinitely adjustable via NC axis > Tool clamping length: 320 mm > Vertical spindle stroke: variable, infinitely adjustable 254 mm via NC axis > Spindle speed: 6000 rpm > Spindle diameter: 50 mm > Max. tool cutting circle: 232 mm > Motor power: 11 kW Item 5: Horizontal profile milling unit (top) ----- > Clamping length: 40 mm > Spindle diameter: 40 mm > Motor power: 3.0 kW > Speed: 5,850 rpm > Max. tool cutting circle: 130 mm > Axial adjustment range: 2 positions > Radial adjustment range: 2 positions Item 6: 3. Profiling spindle (hardware groove spindle) ----- > Position: vertical, right > Tool clamping length: 160 mm > Axial adjustment range: 3 positions > Radial adjustment range: 2 positions > Spindle speed: 5,850 rpm > Spindle diameter: 40 mm > Max. tool cutting circle: 210 mm Nodpfxjz Euxae Agrsdb > Motor power: 3.0 kW Additional features ----- > Network-ready (online capability) > Rebating unit for tear-free rebating > Double-part processing package > Return conveyor system for one-man operation: slat conveyor > Screen-based control system > Angled window processing unit > Electronic angle display for angled windows > Industrial PC, PC control/NEXUS > Excluding machining tools Inclusive: 1 tool set of Stehle IV68 Wood tools also included ----- Price of the above-mentioned machine available on request! ----- Optional extra: EUR 6,500.00 Note regarding used tools: We currently have used "Gold" series tools in stock (Stock No. #2790) Window tools (Gold series) for IV78 Wood and IV78 Wood/Aluminum Previously used on a Weinig Unicontrol 10; a jointing cutter is additionally required for use on a Unicontrol 6. Tool set for fixed-stroke or CNC spindle machines (80 mm and 95 mm stroke), (Tool set prepared for I...

Condition: used, Tenoning spindle 1 St. Number of milling agregates 5 St. Spindle diameter 50 mm Control Weinig PC-Nexus Weinig Unicontrol 11 Window System with Extensive Tooling ----- Optionally available (at additional cost): - Weinig Univar 6 Rebating Machine (Price upon request!) - Götzinger PowerDrill Drilling and Milling Center for Windows and Doors (Price upon request) Manufacturer's Technical Description: ----- Item 1: Weinig Unicontrol 11 Window System ----- Ndsdpey T R Tusfx Agreb Includes existing tooling sets: - IV 67 (Wood and Wood-Aluminum) - IV 77 (Wood and Wood-Aluminum) - IV 90 (Wood) Cross-cut Saw ----- With laser alignment light; motor power: 3 kW; spindle diameter: 40 mm; electronically variable spindle speed with brake: 3,000–6,000 rpm. Max. tool cutting circle: 400 mm Axial adjustment: 150 mm via NC axis Radial adjustment: pneumatic, to 8 positions for top edge rounding Horizontal Bottom Rounding Unit ----- Motor with brake: 1.5 kW; Spindle diameter: 20 mm; Clamping length: 25 mm Spindle speed: 9,000 rpm Max. tool cutting circle: 130 mm Axial adjustment travel: mechanically coupled with cut-off saw Radial adjustment travel: pneumatically controlled Tenoning and Slotting Spindle ----- With hydraulically clamped outboard bearing Motor power with brake: 15 kW Spindle diameter: 50 mm Spindle speed: 2,800 rpm Max. tool cutting circle: 400 mm Tool clamping length: 640 mm Axial adjustment travel: NC axis Home position below table: 5–10 mm Radial adjustment travel: fixed 1st Profiling Spindle (Climb and Conventional Milling) ----- Motor power with brake: 11 kW Spindle diameter: 50 mm Spindle speed: 6,000 rpm Min. tool cutting circle: 140 mm; Max. tool cutting circle: 232 mm Tool clamping length: 400 mm (with outboard bearing) Axial adjustment travel: 350 mm (NC axis) Radial adjustment travel: NC axis Home position below table: 5–10 mm 2 feed rollers opposite the spindle; axial adjustment pneumatically controlled (8 positions) Horizontal Top Profiling Unit ----- Motor power with brake: 3.7 kW Spindle diameter: 40 mm Clamping length: 40 mm Spindle speed: 9,000 rpm Max. tool cutting circle: 130 mm Adjustment: pneumatic, to 8 positions (axial and...) radial 2. Profile Spindle ----- Motor power: 11 kW Spindle diameter: 50 mm Spindle speed: 6,000 rpm Tool cutting circle: min. 140 mm, max. 232 mm Tool clamping length: 400 mm (with outboard bearing) Axial adjustment travel: 350 mm (NC axis) Radial adjustment travel: NC axis Home position (below table): 5–10 mm Indexed guide fence with muntin support strip 2 feed rollers (opposite the spindle); axially pneumatically controlled (8 positions) Vertical Profile Milling Unit (Right-hand side, at machine end) ----- Motor power (with brake): 3.7 kW Spindle diameter: 40 mm Clamping length: 160 mm Spindle speed: 5,850 rpm Tool cutting circle: min. 112 mm, max. 210 mm Adjustment: Pneumatic (8 positions—axial a...

Condition: excellent (used), Number of spindles 5 St. Working width 230 mm Working height 120 mm Length of the planing table 2500 mm Feed motor 4 kW Feed speed 5-30 m/min. control Memory-Funktion Weinig Powermat 500 with grooved table ----- The machine arrives at the warehouse and is cleaned and fully inspected. Brief Summary: ----- - 5 Spindles - 8,000 rpm - Grooved table for short or difficult-to-guide workpieces, coated with Marathon PowerCoating - One driven roller in the outfeed table, hardened: 210 mm wide - Left and top spindles controlled for width and height - Quick-release spindle nut Detailed Description: ----- Technical Data: Working width: 20-230 mm Working height: 8-120 mm Number of spindles: 5 1st Spindle - bottom ----- Motor with brake: 7.5 kW Spindle diameter: 40 mm Speed: 8,000 rpm Tool circle: 125-180 mm Tool circle for rebate cutter: 130-160 mm Travel Axial: 17 mm Folding attachment MarathonCoatin for table insert in front of 1st lower tool holder 2nd Spindle - right ----- Motor with brake: 5.5 kW Spindle diameter: 40 mm Speed: 8,000 rpm Tool swing diameter: 93 - 200 mm Max. groove depth: 35 mm Axially travel: 80 mm Radial travel: Min. tool diameter at stop level: 93 mm Max. tool diameter behind stop level: 200 mm 3rd Spindle - left ----- Motor with brake: 7.5 kW Spindle diameter: 40 mm Speed: 8,000 rpm Tool swing diameter: 93 - 200 mm Tool swing diameter for straight cutter heads: max. 163 mm Max. Groove depth: 35 mm Axially travel: 55 mm Pressure shoe in front of left spindle, including 2 lateral pressure rollers, spring-loaded Spindle radially CNC-controlled 4th Spindle - top ----- Motor with brake: 11.0 kW Spindle diameter: 40 mm Njdozughzspfx Agrjdb Speed: 8,000 rpm Tool swing diameter: 93 - 200 mm Maximum tool swing diameter for straight cutter heads: 180 mm Maximum groove depth: 35 mm Axially travel: 40 mm Spindle radially CNC-controlled Split pressure shoe in front of upper tool holder, adjustable to the tool swing diameter and pivoting away from the tool, spring-loaded. 5. Spindle - Lower ----- Motor with brake: 5.5 kW Spindle diameter: 40 mm Speed: 8,000 rpm Tool swing diameter: 93 - 225 mm Max. throat depth: 15 mm Axially travel: 35 mm Radial travel: Min. tool diameter to table level: 93 mm Max. tool diameter 6 mm below table level: 225 mm Feed system ----- Frequency-controlled feed, infinitely variable with brake: 4 kW, 5 - 30 m/min Infeed roller in front of the first lower tool, pneumatically controlled up/down. Durofer pointed tooth rollers with depth limiter and self-cleaning. Feed roller adjustment travel relative to the left tool holder, axial 35 mm Reduced roller spacing relative to the right tool Machine electrical system ----- Operating voltage 400 V (voltage range 380 - 420 V), 50 Hz. Machine stand, tables, and stops ----- Infeed table: 2500 mm long (including jointing guide) Slotted guide for short or difficult-to-guide workpieces, coated...

Condition: used, Year of construction: 2004, operating hours: 3,142 h, total width: 2,400 mm, total height: 2,100 mm, Colour: Grey Empty weight: 5.000 kg Dimensions (LxBxH): 550 x 240 x 210 cm Price: On request - Year: 2004 - Documentation available: No - CE marking present: Yes - CE certificate present: No - Serial number: 102848 - Operating hours: 3142 - Number of spindles [pcs.]: 7 - └ Spindle 1: Njdpjzvcqzsfx Agrodb - - Spindle type: Bottom - - Motor power [kW]: 15 - - Tool present: Yes - └ Spindle 2: - - Spindle type: Right - - Motor power [kW]: 11 - - Tool present: Yes - └ Spindle 3: - - Spindle type: Left - - Motor power [kW]: 11 - - Tool present: Yes - └ Spindle 4: - - Spindle type: Top - - Motor power [kW]: 22 - - Tool present: Yes - └ Spindle 5: - - Spindle type: Bottom - - Motor power [kW]: 15 - - Tool present: Yes - └ Spindle 6: - - Spindle type: Top - - Motor power [kW]: 30 - - Tool present: Yes - └ Spindle 7: - - Spindle type: Bottom - - Motor power [kW]: 15 - Min. planing width [mm]: 20 - Max. planing width [mm]: 300 - Min. planing height [mm]: 3 - Max. planing height [mm]: 160 - Feed table length [mm]: 1000 - Feed roller diameter [mm]: 140 - Conveyor drive: Cardan drive - Lubrication system: Automatic - Diameter extraction nozzle [mm]: 160 - Options: Powered rollers in table, Powerlock - Feed speed: Manual - └ Min. feed speed [m/min]: 5 - └ Max. feed speed [m/min]: 33 - └ Feed speed control: Continuously adjustable - Voltage [V]: 400 - Current consumption [A]: 278 - Fuse [A]: 400 - Power [kW]: 128.0 - Transport dimensions: 5500mm x 2400mm x 2100mm (l x w x h) - Transport weight [kg]: 5000kg - Transport packages [pcs.]: 3 Financial information VAT: The price shown is exclusive of VAT VAT/margin: VAT deductible for entrepreneurs Delivery and trade-in always possible for everything in the industrial sectors Yorick Diebels

Condition: used, Year of construction: 2000, grinding length: 240 mm, feed length X-axis: 50 mm, feed length Y-axis: 50 mm, feed length Z-axis: 240 mm, grinding width: 300 mm, WEINIG RONDAMAT 970 – Profile and Tool Grinding Machine – Year of Manufacture 2000 For sale is a WEINIG Rondamat 970, year of manufacture 2000, a high-quality automatic profile and tool grinding machine from Michael Weinig AG. The machine is suitable for manufacturing and re-sharpening profile and planing knives, as well as for grinding tools and knife heads. Profile tools can be manufactured manually using a template and then automatically re-sharpened. The machine is also suitable for re-sharpening planing knives in the knife head. Technical Data * Manufacturer: Michael Weinig AG * Type: Rondamat R 970 * Year of Manufacture: 2000 * Machine No.: 91176 * Tool Diameter: 100–300 mm * Max. Tool Width: 240 mm * Grinding Wheel Diameter: 150–225 mm * Grinding Wheel Bore: 60 mm * Grinding Wheel Width: 2 / 3 / 4 / 10 mm * Grinding Spindle Speed: 1,500–3,000 RPM * Grinding Spindle Drive: 1.1 kW * Total Connected Load: approx. 2 kW * Coolant Tank: approx. 50 liters Ndodpez Evalefx Agrob * Operating Voltage: 380 V / 50 Hz * Back Angle: 10–30° * Lateral Clearance Angle (manual): 0–20° * Lateral Clearance Angle (automatic): 2.5 / 5 / 7.5 / 10° * Relief Angle for Planing Knives: 60° * Automatic Indexing: up to 16 knives * Precision: Grinding tolerance under 0.005 mm. Suitable for: * Profile knives * Planing knives

Condition: reconditioned (used), Number of spindles 6 St. Working width 230 mm Working height 120 mm Length of the planing table 2500 mm Feed motor 4 kW Feed speed 5-30 m/min. control Memory-Funktion Weinig Powermat 400 with HSK/Powerlock, axial/radial CNC controlled ----- The machine renovated and functionally checked ! Short summary: ----- 6 spindles with 8,000 rpm 5 x HSK/Powerlock Axial and radial CNC adjustment of the spindles via control CNC - controlled adjustment and positioning of the feed Detailed description: ----- Technical specifications: Working width: 20-230 mm Working height: 8-120 mm Number of spindles: 6 1. Tool holder - below ----- Motor with brake: 5.5 kW Spindle diameter: 40mm Speed: 6,000 rpm Tool flight circle: 93 - 160 mm Axial adjustment range: 5 mm Rebating device MarathonCoatin for table insert in front of 1st lower tool holder 2. Tool holder - PowerLock - right ----- Motor with brake: 11.0 kW Common motor with left tool holder Speed ??including high-performance ball bearing: 8,000 rpm Tool flight circle 40 mm below table level: 93 - 200 mm Tool flight circle 55 mm below table level: 93 - 180 mm Tool cutting circle for straight cutter heads max. 163 mm Max. tool diameter behind stop level: 180 mm Max throat depth: 35 mm Axial adjustment range: 55 mm Spindle axially and radially CNC controlled 3. Tool holder - PowerLock - left ----- Motor with brake: Common motor with the 2nd spindle Speed ??including high-performance ball bearing: 8,000 rpm Tool flight circle 40 mm below table level: 93 - 200 mm Tool flight circle 55 mm below table level: 93 - 180 mm Tool cutting circle for straight cutter heads max. 163 mm Max throat depth: 35 mm Axial adjustment range: 55 mm Spindle axially and radially CNC controlled 4. Tool holder - PowerLock - above ----- Motor with brake: 7.5 kW Speed ??including high-performance ball bearing: 8,000 rpm Nedpjuzaa Sjfx Agrodb Tool flight circle: 93 - 200 mm Tool cutting circle for straight cutter heads max.: 180 mm Max throat depth: 35 mm Axial adjustment range: 40 mm Divided pressure shoe in front of the upper tool holder, on tool flight circle adjustable and pivoting away from the tool, spring-loaded. Radial CNC-controlled spindle 5. Tool holder - PowerLock - above ----- Motor with brake: 7.5 kW Speed ??including high-performance ball bearing: 8,000 rpm Tool flight circle: 93 - 200 mm Tool cutting circle for straight cutter heads max. : 180 mm Max throat depth: 35 mm Axial adjustment range: 40 mm Divided pressure shoe in front of the upper tool holder, on tool flight circle adjustable and pivoting away from the tool, spring-loaded. Spindle axially and radially CNC controlled 6. Tool holder - PowerLock - below ----- Motor with brake: 7.5 kW Speed ??including high-performance ball bearing: 8,000 rpm Tool flight circle: 93 - 200 mm Max throat depth: 15 mm Axial adjustment range: 35 mm Radial CNC-controlled spindle feed system -----...

Condition: reconditioned (used), Tenoning spindle 1 St. Number of milling agregates 4 St. Spindle diameter 50 mm control Weinig, PC-Nexus Weinig Unicontrol 6 with NC spindles ----- Machine will be cleaned and completely checked before delivery Technical data summary (please enquire about any additional accessories included) Item 1: Cross-cut saw ----- > Electronic cross-cut saw, infinitely adjustable horizontally > Number of tools: 1 piece > Spindle speed: 2,800 rpm > Spindle diameter: 40 mm > Max. tool diameter: 400 mm > Motor power: 3.0 kW > Laser aiming light for detecting the saw section > NC length stop, mounted on slot table included Positioning of the cross-cut saw integrated in the control system. > Length 3500 mm Item 2: tenoning spindle ----- > Number of tools: variable, infinitely variable adjustment NC axis > Tool clamping length: 320 mm > Vertical spindle stroke: variable, infinitely variable adjustment 254 mm NC axis > Spindle speed: 3500 rpm > Spindle diameter: 50 mm > Max. tool diameter: 320 mm > Motor power: 11 kW Nedpfovu Hfqex Agrjdb Item 3: 1st profiling spindle (synchronous spindle and counter-rotation) > Position: vertical right > Number of tools: 1 pc. > Tool clamping length: 120 mm > Spindle speed: 6000 rpm > Spindle diameter: 50 mm > Max. tool flight circle: 232 mm > Motor power: 7.5 kW Item 4: 2nd profiling spindle ----- > Position: vertical right > Number of tools: variable, infinitely variable adjustment NC axis > Tool clamping length: 320 mm > Vertical spindle stroke: variable, infinitely variable adjustment 254 mm NC axis > Spindle speed: 6000 rpm > Spindle diameter: 50 mm > Tool flight circle max.: 232 mm > Motor power: 11 kW 2 feed rollers opposite the spindle, axially pneumatically controlled, 2 positions Rung guide consisting of: Guide ruler in the stop (area of ??synchronous spindle), Rung support bar from above in the area of ??profile milling unit vertical right and profiling spindle. Pos. 5: Profile milling unit horizontal top ----- > Clamping length: 40 mm > Spindle diameter: 40 mm > Motor power: 3.0 kW > Speed ??5,850 rpm > Tool flight circle max. 130 mm > Axial adjustment range 30 mm, 8 positions using pneumatic turret > Radial adjustment range 125 mm, 8 positions using pneumatic turret Pos. 6: 3rd profiling spindle (fitting spindle) ----- > Position: vertical right > Tool clamping length: 160 mm > Axial adjustment range 115 mm, 8 positions using pneumatic turret > Radial adjustment range 100 mm, 8 positions using pneumatic turret > Spindle speed: 5,850 rpm > Spindle diameter: 40 mm > Max. tool flight circle: 210 mm > Motor power: 3.0 kW Other features ----- > online-capable > rebating device for tear-free rebating > double parts package > return conveyor for 1-man operation: tilting belt > screen control > inclined window device > electronic angle display for inclined windows > industrial PC, PC control/NEXUS > Weinig type production program > without processing tools No original images available yet. Images show identical machines from our archive. ----- Price of the above-mentioned machine upon request! ----- Optional with additional charge: EUR 6.500,00 Note on used tools: We currently have used...

Condition: reconditioned (used), Number of spindles 5 St. Working width 20 - 230 mm Working height 8 - 120 mm Length of the planing table 2000 mm Feed motor 1,1 kW Feed speed stufenlos regelbar 2 - 12 m/min. Control Memory Funktion 1 WEINIG VARIOMAT planer and moulder including multifunction / slotting table ----- Machine will be cleaned and functionally tested before delivery ! Technical manufacturer's description: ----- Working width: 20 - 230 mm Working height: 8 - 120 mm 1st spindle horizontal, bottom ----- Motor with brake: 5.5 kW Diameter 40 mm Speed ??6000 rpm Tool radius 125 - 145 mm Axis adjustment range 5 mm Folding device including rebate cutter MarathonCoating for table insert before and after the 1st lower spindle 2nd spindle vertical, right ----- Motor with brake: 11 kW Common motor with left vertical spindle Diameter 40 mm mm Speed ??electronically adjustable 3000 - 6000 rpm (for 11 kW/15 HP) Tool cutting radius for longitudinal machining 93-232 mm Minimum tool diameter at stop plane: 93 mm Maximum tool diameter behind stop plane: 180 mm Maximum throat depth 45 mm Axially adjustable travel 30 mm Insertion segment, including additional stop lip 125 mm Insertion segment, including additional stop lip 150 mm 3rd vertical spindle, left POWERLOCK/HSK ----- Shared motor with 1st right spindle PowerLock tool holder Shared speed with right vertical spindle Tool cutting radius for longitudinal machining 93-232 mm Maximum throat depth 45 mm Minimum throat depth with tool cutting radius 200 mm: 20 mm Axially adjustable travel under table 30 mm Insertion segment 125 mm Insertion segment 150 mm 4th spindle, horizontal, top ----- Motor with brake: 5.5 kW Diameter 40 mm Speed ??6000 rpm Tool cutting radius 125-200 mm Maximum chamfering depth 30 mm Minimum chamfering depth with a tool cutting radius of 200 mm: 20 mm Axially adjustable range 30 mm Glazing bead removal after the upper spindle 5th spindle, second, horizontal, bottom ----- Motor with brake: 4 kW Diameter 40 mm Speed ??6000 rpm Tool cutting radius 125-200 mm Maximum chamfering depth 15 mm Axially adjustable range 10 mm Machine operation ----- Both axes of all spindles - with the exception of the first lower spindle - are equipped with mechanical digital displays. Central radial adjustment with mechanical digital display of the feed rate along with the pressure in front of the upper spindle. The pressure after the upper spindle can be adjusted separately. Memory function ----- For saving the setting values ??of profiles Tool holder axes and pressure elements before and after the upper tool holder with electronic dual displays: Function: -Saving the setting values ??of the finished profile at the touch of a button under a profile number - When the profile number is selected again, the electronic dual displays show the setting values - By manually adjusting the tool holders and pressure elements, the displays are aligned - 99 memory locations Nodpjwugpbefx Agredb 3 axial CNC-controlled adjustment and positioning of the spindles in conjunction with the memory fun...

Condition: reconditioned (used), Tenoning spindle 1 St Number of milling agregates 4 St. Spindle diameter 50 mm Njdpjxpi Duofx Agrsdb Control Weinig, PC-Nexus Weinig Unicontrol 10 CNC - Spindles radially and axially CNC-controlled ----- The machine was factory overhauled by Weinig in 2024. The control panel was also upgraded to a Siemens S 7 677 C, with a new membrane panel "Touch". With the following machining units: Crosscut saw ----- with laser alignment light, motor power 3 kW, spindle diameter 40 mm, spindle speed 3,000 Axially adjustable via NC axis Radial pneumatic adjustment to 8 positions for edge rounding from above Unit from below for edge rounding ----- Axially adjustable with crosscut saw Tenon and slotting spindle ----- Motor power 15 kW Spindle diameter 50 mm Spindle speed 2,925 rpm Tool travel radius min. 380, max. 400 mm Tool clamping length 640 mm Axially adjustable CNC axis Axially adjustable travel 580 mm Adjustment speed 100 mm/sec. 1. Profile spindle (up- and down-rotation) ----- Motor power 11 kW Spindle diameter 50 mm Spindle speed 6,000 rpm Tool clamping length 400 mm with counter bearing Axially and radially adjustable via CNC axis 2. Profile spindle ----- Motor power 11 kW Spindle diameter 50 mm Spindle speed 6,000 rpm Tool clamping length 400 mm with counter bearing Axially and radially adjustable via CNC axis Profile milling unit horizontally mounted on top ----- Motor power 3 kW Spindle diameter 40 mm Spindle speed 9,000 rpm Pneumatically adjustable to 8 axial and radial positions Profile milling unit vertically mounted on the right side Machine end ----- Motor power 3 kW Spindle diameter 40 mm Spindle speed 5,850 rpm Pneumatic adjustment to 8 axial and radial positions Additional accessories ----- CNC-controlled length stop, mounted on the slotting table for lengths up to 3,500 mm, including a positioned cross-cutting saw integrated into the control system. Studio window device, pivots 60° on both sides Double-part package with automatic separation and transfer Synchronization device with automatic window rebating Rebating carriage for rebating small sash widths Air conditioning unit in the control cabinet PC control NEXUS Automatic turning system Slat conveyor, including conveyor belt for returning the workpieces to the operator (Technical specifications according to the manufacturer - without guarantee).

Condition: excellent (used), Tenoning spindle 1 St. Number of milling agregates 4 St. Spindle diameter 40/50 mm Weinig Unicontrol 6 ----- Machine will be checked in our factory before delivery! Technical Data Summary (Please inquire about any additional accessories included) Item 1: Cut-off saw ----- > Number of tools: 1 pc. > Spindle speed: 2,800 rpm > Spindle diameter: 40 mm > Maximum tool diameter: 400 mm > Motor power: 3.0 kW > Laser guide light for identifying the saw cut CNC-controlled length stop ----- > Length: 3,600 mm > Electronic length stop including positioned cut-off saw Item 2: Tenoning spindle ----- > Number of tools: 3 (stroke 2 x 100 mm) or 4 (Stroke 3 x 80 mm) > Tool clamping length: 320 mm > Pneumatic vertical spindle stroke: 240 mm for wood thicknesses 68 - 92 mm > Spindle speed: 3000 rpm > Maximum tool swing diameter: 320 mm > Spindle diameter: 50 mm > Maximum tool diameter: 360 mm > Motor power: 11 kW Item 3: 1. Profiling spindle (co-rotation and conventional) ----- > Position: vertical right > Number of tools: 1 pc. > Tool clamping length: 120 mm > Spindle speed: 6000 rpm > Spindle diameter: 50 mm > Maximum tool swing diameter: 232 mm > Motor power: 7.5 kW Item 4: 2. Profiling spindle ----- > Position: Vertical right > Number of tools: 3 (stroke 2 x 100 mm) or 4 (stroke 3 x 80 mm) > Tool clamping length: 320 mm > Pneumatic vertical spindle stroke: 240 mm for wood thicknesses 68 - 92 mm > Spindle speed: 6000 rpm > Spindle diameter: 50 mm > Maximum tool swing diameter: 232 mm > Motor power: 11 kW 2 axially indexed feed rollers opposite the profiling spindle, for the production of narrow, short parts (e.g., glass-dividing muntins) Munch guide consisting of: Munch support strip from above in the area of ??the vertical right-han d profile milling unit and profiling spindle. Item 5: Horizontal top profile milling unit ----- > Clamping length: 40 mm > Spindle diameter: 40 mm > Motor power: 3.0 kW > Spindle speed: 5,850 rpm > Maximum tool swing diameter: 130 mm > Axial travel: 52 mm, indexed in 2 positions > Radial travel: 125 mm, indexed in 2 positions Item 6: 3rd profiling spindle (fitting spindle) ----- > Position: Vertical right > Tool clamping length: 160 mm > Axial travel: 90 mm, indexed in 3 positions > Radial travel: 100 mm, indexed in 2 positions > Spindle speed: 5,850 rpm > Spindle diameter: 40 mm > Maximum tool swing diameter: 210 mm > Motor power: 3.0 kW Further features ----- > Electric feed height adjustment including mechanical digital display and manual feed bar clamping > Rebating device for tear-out-free rebating > Double part package Nodpfsxtvgksx Agrjdb > Return conveyor for 1-person operation: swivel conveyor > Screen control > Angled window device > Electronic angle display for angled windows > Industrial PC with Windows PC control/NEXUS Extraction nozzle diameter: ----- Crosscut saw 80 mm Tenoning spindle 140 mm Profile spindle 1 140 mm Profile spindle 2 140 mm Grooving device from above 80 mm Hardware spindle 120 mm -----...

Condition: reconditioned (used), Year of construction: 2014, Number of spindles 5 St. Working width 230 mm Working height 120 mm Length of the planing table 2500 mm Feed motor 4 kW Feed speed 5-30 m/min. Control Memory-Funktion Weinig Powermat 600 Compact ----- The machine has been cleaned and fully inspected. Brief Summary: ----- - 5 Spindles Njdpfowzmu Rex Agrodb - Powerful Motors - Left and top spindles controlled for width and height Detailed Description: ----- Technical Data: Working Width: 20-230 mm Working Height: 10-120 mm Number of Spindles: 5 1st Spindle - Bottom ----- Motor with brake: 7.5 kW Spindle diameter: 40 mm Speed: 6,000 rpm Tool Circle: 125-145 mm Tool Circle for Rebating Cutter: 130-160 mm Axially Travel: 5 mm Rebating Device MarathonCoatine for table insert in front of the 1st lower tool holder Electronic digital display for rotary adjustment 2nd Spindle - Right ----- Motor with brake: 11.0 kW Shared motor with left-hand tool holder Spindle diameter: 40 mm Speed: 6,000 rpm Tool swing diameter 40 mm below table level: 93 - 200 mm Tool swing diameter 55 mm below table level: 93 - 180 mm Tool swing diameter for straight cutter heads max. 163 mm Max. tool diameter behind fence: 180 mm Max. groove depth: 35 mm Axially travel: 55 mm 3rd Spindle - Left ----- Motor with brake: Shared motor with the 2nd spindle Spindle diameter: 40 mm Speed: 6,000 rpm Tool swing diameter 40 mm below table level: 93 - 200 mm Tool swing diameter 55 mm below table level: 93 - 180 mm Tool swing diameter for straight cutter heads max. 163 mm Max. groove depth: 35 mm Axially travel: 55 mm CNC-controlled radial spindle 4th spindle - top ----- Motor with brake: 11.0 kW Spindle diameter: 40 mm Speed: 6,000 rpm Tool swing diameter: 93 - 200 mm Tool swing diameter for straight cutter heads max.: 180 mm Max. groove depth: 35 mm Axially travel: 40 mm CNC-controlled radial spindle Split pressure shoe in front of upper tool holder, adjustable to the tool swing diameter and pivoting away from the tool, spring-loaded. Pressure shoe in front of, and discharge after, the upper spindle with electronic digital displays, integrated into the memory function or the PowerCom 5. Spindle - bottom ----- Motor with brake: 7.5 kW Spindle diameter: 40 mm Speed: 6,000 rpm Tool travel: 93 - 200 mm Max. throat depth: 15 mm Axially travel: 35 mm Feed system ----- Electronic feed, infinitely variable with brake: 4 kW, 5 - 30 m/min Infeed roller in front of the first lower tool, pneumatically controlled up/down. Durofer pointed tooth rollers with depth limiter and self-cleaning. Adjustment travel of the feed rollers relative to the left tool holder, axial 35 mm Machine electrical system ----- Operating voltage 400 V (voltage range 380–420 V), 50 Hz. All spindles IE2 design. Electrical design according to DIN VDE 0113, electrical equipment of industrial machines EN 60204, IEC 204-1. Other electrical regulations are not considered. Machine stand, tables, and ...

Condition: not inspected (used), Year of construction: 2004, Tenoning spindle 2 St. Number of milling agregates 7 St. Ndedsyrtzkjpfx Agrob Spindle diameter 50 mm control Weinig PC-Nexus Weinig Uncontrol 12 with radial and axial CNC spindles and VARIO table ..... The machine has already been professionally dismantled and stored in 73447 Oberkochen Specifications summary (please inquire about any additional accessories included) ..... crosscut saw ..... > Crosscut saw electronically, horizontally infinitely adjustable > Number of tools: 1 pc. > Spindle speed: 3000-6000 rpm > Spindle diameter: 40 mm > Tool diameter max.: 400 mm > Motor power: 3.7 kW > Laser guide light for detecting the sawing section > Axial adjustment path 150 mm NC axis, electronically stepless > Adjustment path, radial, pneumatic, 8 positions, e.g. for edge rounding from above rounding aggregate ..... > Position: horizontally below > Axial adjustment path together with the crosscut saw. electronic length stop ..... > Length 4500mm 1. Tap and Slot Spindle ..... > Number of tools: variable > Motor power: 15 kW > Spindle diameter: 50 mm > Tool clamping length: 640 mm, with counter bearing > Axial adjustment range: 580 mm NC axis, stepless > Spindle speed: 2,800-4,000 rpm > Tool diameter: 380-400mm > Overrun counter, complete clamping length is countered 2. Tap and Slot Spindle ..... > Number of tools: variable > Motor power: 15 kW > Spindle diameter: 50 mm > Tool clamping length: 640 mm, with counter bearing > Axial adjustment range: 580 mm NC axis, stepless > Spindle speed: 2,800-4,000 rpm > Tool diameter: 380-400mm > Overrun counter, complete clamping length is countered transfer tape ..... Included for transferring the parts to longitudinal processing Separation of double parts before entering longitudinal processing. 1. Profiling spindle (synchronous and counter-rotating) ..... > Position: vertical right > Number of tools: variable > Motor power: 11 kW > Spindle diameter: 50 mm > Tool clamping length: 400 mm, with counter bearing > Axial adjustment range 350 mm NC axis, stepless > Radial adjustment range 80 mm NC axis, stepless > Spindle speed: 6000 rpm > Minimum tool flight circle: 140 mm > Tool flight circle max.: 232 mm 2. Profiling spindle ..... > Position: vertical right > Number of tools: variable > Motor power: 11 kW > Spindle diameter: 50 mm > Tool clamping length: 400 mm, with counter bearing > Axial adjustment range 350 mm NC axis, stepless > Radial adjustment range 80 mm NC axis, stepless > Spindle speed: 6000 rpm > Minimum tool flight circle: 140 mm > Tool flight circle max.: 232 mm 3. Profile milling unit (grooving device from above) ..... > Position: horizontally above > Motor power: 3.0 kW > Spindle diameter: 40 mm > Tool clamping length: 40 mm > Axial adjustment range 30 mm NC axis, stepless > Radial adjustment range 125 mm NC axis, stepless > Spindle speed: 9000 rpm > Tool flight circle max.: 130 mm ...

Condition: reconditioned (used), Number of spindles 5 St. Working width 230 mm Working height 120 mm Length of the planing table 2500 mm Feed motor 4 kW Feed speed 5-30 m/min. Control Memory-Funktion Weinig Powermat 400 with HSK/Powerlock, axial/radial CNC controlled ----- This machine is currently being refurbished at our facility! Pictures taken before dismantling and currently during the processing phase! Brief Summary: ----- - 5 spindles with 8,000 rpm - 4 x HSK/Powerlock - Axially and radial CNC adjustments of the spindles via control - CNC-controlled adjustment and positioning of the feed - Table tops with guide blades at spindles 2 and 3. - Includes Weinig/Neumann RF 15 return conveyor system Detailed Description: ----- Technical Data: Working width: 20-230 mm Working height: 8-120 mm 1st tool holder - bottom ----- Motor with brake: 5.5 kW Spindle diameter: 40 mm Speed: 6,000 rpm Tool swing diameter: 93 - 145 mm Axially travel: 5 mm Folding device MarathonCoatin for table insert in front of 1st lower Tool Holder 2nd Tool Holder - PowerLock - Right ----- Motor with brake: 7.5 kW Shared motor with left tool holder Speed ??incl. high-performance ball bearings: 8,000 rpm Tool swing diameter 40 mm below table level: 93 - 200 mm Tool swing diameter 55 mm below table level: 93 - 180 mm Tool swing diameter for straight cutter heads max. 163 mm Max. tool diameter behind stop plane: 180 mm Max. groove depth: 35 mm Axially travel: 55 mm Spindle: CNC controlled axially Table tops with guide blades 3rd Tool Holder - PowerLock - Left ----- Motor with brake: Shared motor with the 2nd spindle Speed ??incl. high-performance ball bearings: 8,000 rpm Tool swing diameter 40 mm below table level: 93 - 180 mm Table surface: 93 - 200 mm Nedsyy A Iqjpfx Agrodb Tool swing diameter 55 mm below table surface: 93 - 180 mm Tool swing diameter for straight cutter heads max. 163 mm Max. groove depth: 35 mm Axially travel: 55 mm Spindle axially and radially CNC controlled Table tops with guide blades 4. Tool holder - PowerLock - top ----- Motor with brake: 7.5 kW Speed ??incl. high-performance ball bearings: 8,000 rpm Tool swing diameter: 93 - 200 mm Tool swing diameter for straight cutter heads max.: 180 mm Max. groove depth: 35 mm Axially travel: 40 mm Split pressure shoe in front of upper tool holder, adjustable and pivoting away from the tool, spring-loaded. Pressure shoe in front of, and discharge after, the upper tool holder with electronic digital displays, integrated into memory functions CNC-controlled radial spindle 5. Tool holder - PowerLock - bottom ----- Motor with brake: 7.5 kW Speed ??incl. high-performance ball bearings: 8,000 rpm Tool swing diameter: 93 - 200 mm Max. throat depth: 15 mm Axially travel: 35 mm Feed system ----- Frequency-controlled feed, infinitely variable with brake: 4 kW, 5 - 30 m/min Infeed roller in front of the first lower tool, pneumatically controlled up/down. Durofer pointed tooth rollers (Weinig patent) wi...

Condition: reconditioned (used), working length 3600 mm Working width 1140 mm Working height 820 bis 1050 mm WEINIG RF15 Return Conveyor System ----- Suitable for use after a chamfering, planing, and milling machine with a maximum feed speed of approximately 22 m/min. For the continuous return transport of workpieces to the operator. After passing through the planer, the workpieces are transferred to a roller conveyor, where they are conveyed transversely and then taken over by a driven roller conveyor. This conveyor directs the workpieces onto a downstream longitudinal roller conveyor back to the operator and also serves as a parts buffer. Manufacturer’s technical specifications: Workpiece length: 250–3,600 mm Workpiece width: 30–230 mm Min. workpiece thickness: 10 mm Max. feed rate of the planer: 22 m/min Ndodpsxpn Tnsfx Agrsb Cross conveyor with 2 integrated roller conveyors: Cross conveyor length: 1,140 mm Constant conveyor speed: 30 m/min Max. cycles per minute: 40 Roller conveyor length: 2,200 mm Constant speed: 30 / 60 m/min Gear motor: 1 kW (1.3 PS) Operating voltage: 220/380 volts, 50 hertz Compressed air connection: 6 bar Longitudinal roller conveyor (non-driven): Length: 1,700 mm Width: 160 mm Swing-mounted, adjustable incline Special equipment: Extension of the longitudinal roller conveyor (non-driven) by 3,000 mm ----- Price of the above machine available upon request! ----- (Technical data according to the manufacturer—subject to change without notice!)

Condition: reconditioned (used), Number of spindles 6 St. Working width 230 mm Working height 120 mm Length of the planing table 2500 mm Feed motor 3 kW Feed speed 5-30 m/min. control Powercom Weinig Powermat 500 (Window Version for window producers) ----- The machine will be a partial renovated at our warehouse prior to delivery. The interior view photos of a similar machine from our archive serve to illustrate how the machine will be renovated. Technical Summary: ----- - 6 spindles, 5 of which are PowerLock - 8,000 rpm - Large PowerCom control system - Spindles 2, 3, and 4: CNC-controlled axial adjustment - Spindles 2, 3, 4, and 5: CNC-controlled radial adjustment - Window package for glazing bead separation: pneumatic cycling for right and top spindles for bead separation Detailed Description: ----- Tool arrangement no. 018 for window production Technical Data: ----- Working width: 20 – 230 mm (with tool cutting circle 93 – 125 mm) Working height: 8 – 120 mm (with tool cutting circle 93 – 125 mm) 1. Tool Spindle ----- First bottom spindle Diameter: 40 mm Motor with brake: 7.5 kW Speed: 8,000 rpm Tool cutting circle: 125 – 180 mm Tool cutting circle (rebate cutter): 130 – 160 mm Axial adjustment range: 17 mm Rebating device MarathonCoating for table insert before 1st bottom spindle 2. Tool Spindle POWERLOCK/HSK ----- First right spindle Motor with brake: 7.5 kW Speed: 8,000 rpm Includes high-performance ball bearings Tool cutting circle: 93 – 200 mm Maximum profiling depth: 35 mm Axial adjustment range (PowerLock): 55 mm Radial adjustment range: Min. tool diameter at fence level: 93 mm Max. tool cutting circle behind fence line 200 mm Right tool spindle: axial positioning (55 mm) pneumatically controlled via selector switch, max. saw blade diameter 180 mm CNC-controlled axial adjustment CNC-controlled radial adjustment 3rd tool spindle POWERLOCK/HSK ----- Nsdpfx Agszp Rxyerodb First left tool spindle Motor with brake 7.5 kW Speed ??8,000 rpm Includes high-performance ball bearings Tool cutting circle 93 – 200 mm Maximum profiling depth 35 mm Axial adjustment range for PowerLock 55 mm CNC-controlled axial adjustment CNC-controlled radial adjustment Pressure shoe in front of left tool spindle, incl. 2 spring-loaded lateral pressure rollers 4th tool spindle POWERLOCK/HSK ----- First top tool spindle Motor with brake 7.5 kW Speed ??8,000 rpm Includes high-performance ball bearings Tool cutting circle 93 – 200 mm Tool cutting circle for straight-knife cutterheads max. 163 mm Maximum profiling depth 35 mm Axial adjustment range 40 mm CNC-controlled axial adjustment CNC-controlled radial adjustment Top tool spindle: axial positioning (40 mm) pneumatically controlled via selector switch, max. saw blade diameter 180 mm 5th tool spindle POWERLOCK/HSK ----- Second top tool spindle Motor with brake 7.5 kW Speed ??8,000 rpm Includes high-performance ball bearings Tool cutting circle 93 – 200 mm Tool cut...

Condition: not inspected (used), Tenoning spindle 2 St. Number of milling agregates 7 St. Spindle diameter 50 mm control Weinig, PC-Nexus Weinig Unicontrol 12 with radial and axial CNC spindles as well as VARIO table and milling carriage ..... Ndsdpjx H Al Njfx Agrob Machine dismantled professionally and in our warehouse in 73447 Oberkochen. Video and pictures were taken before dismantling. Technical data summary (please inquire about any additional accessories included) ..... crosscut saw ..... > Electronic crosscut saw, horizontally infinitely adjustable > Number of tools: 1 piece. > Spindle speed: 2,800 rpm > Spindle diameter: 40 mm > Tool diameter max.: 400 mm > Motor power: 3.7 kW > Laser directional light to detect the saw section > Axial adjustment path 150 mm NC axis, electronically infinitely variable > Radial pneumatic adjustment path 8 positions for e.g. edge rounding from above Rounding aggregate ..... > Position: horizontally below > Motor power: 1.5 kW > Spindle diameter: 20 mm > Tool clamping length: 25 mm > Spindle speed: 9,000 rpm > Tool diameter: max. 130 mm > Axial adjustment path mechanically coupled with crosscut saw. > Radial adjustment pneumatically controlled on/off electronic length stop ..... > Length 4500 mm 1. Tap and slot spindle ..... > Number of tools: variable > Motor power: 15 kW > Spindle diameter: 50 mm > Tool clamping length: 640 mm, with counter bearing > Axial adjustment path: 580 mm NC axis, continuously variable > Spindle speed: 2,800 rpm > Tool diameter: max. 400 mm > Overtravel counter, complete clamping length is countered 2. Tap and slot spindle ..... > Number of tools: variable > Motor power: 15 kW > Spindle diameter: 50 mm > Tool clamping length: 640 mm, with counter bearing > Axial adjustment path: 580 mm NC axis, continuously variable > Spindle speed: 2,800rpm > Tool diameter: max. 400 mm > Overtravel counter, complete clamping length is countered Transfer tape ..... Included for transferring the parts to longitudinal machining Separation of double parts before the start of longitudinal processing. 1. Profiling spindle (synchronous and counter-rotation) ..... > Position: vertical right > Number of tools: variable > Motor power: 11 kW > Spindle diameter: 50 mm > Tool clamping length: 400 mm, with counter bearing > Axial adjustment path 350 mm NC axis, infinitely variable > Radial adjustment path 80 mm NC axis, infinitely variable > Spindle speed: 6000 rpm > Tool flight circle min.: 140 mm > Tool flight circle max.: 232 mm > 2 feed rollers axially pneumatically controlled opposite the spindle, 8 positions > Table top pneumatically controlled to the tool diameter 2. Profiling spindle ..... > Position: vertical right > Number of tools: variable > Motor power: 11 kW > Spindle diameter: 50 mm > Tool clamping length: 400 mm, with counter bearing > Axial adjustment path 350 mm NC axis, infinitely variable > Radial adjustment path 80 mm NC axis, infinitely variable > Spindle speed: 6000 rpm > Tool fli...
