Used Cnc Plate Drilling Machine for sale (72,556)

Condition: used, 4-axis CNC milling machine Manufacturer: Quick Type: UA-481 New machine Technical data: 380 V-3-phase Working area: 2100 x 3050 x 400 mm 9 kW HSD/HSK-F-63 spindle NC Studio control Ljdozvgmyspfx Agtjhk 10 linear tool changers Double-layer vacuum table with 6 zones Yaskawa servomotor 2 Becker pumps (250 m³/h) NC Studio control with German language Optionally available at an extra charge: - 10-position rotary tool changer on the gantry - 12-position rotary tool changer on the gantry - 2 pneumatic pressure rollers for multiple part clamping - Vacuum table with T-slot for manual fixing of components Other configurations available upon request.

Condition: new, 3-axis CNC milling machine Manufacturer: Quick Type: UE-481PL New machine Technical data: - PC with Windows 11 Lhsdpszvgmtofx Agtjk - CAD-CAM connection as desired - NC Studio control software - Heavy-duty machine base - Working area: 2100 x 3050 x 200 mm - Double-layer phenolic resin table - grid table - 9 kW HSD milling spindle with 24,000 RPM - 9-position HSD drilling unit - 90° rotatable sawing unit - 12-position linear tool changer - Automatic tool length measurement - Wireless control panel - 3 stops in X, 2 in Y - 2 units of 250 m3/h Becker vacuum pump - Automatic central lubrication - Safety via light curtain - Lifting table loading - Unloading table

Condition: new, CNC Machining Center Manufacturer: COMEC Type: MD TOP XL The ideal solution for CNC machining of narrow, complex workpieces. COMEC makes it easy for you. Head configurations can be individually configured for: - Sawing with a 360-degree axis - Milling heads for horizontal and vertical machining - Drilling heads with individually selectable spindles, vertical and horizontal - Multi-spindle row drilling heads, individually selectable, also horizontally - Horizontal milling head with a 360-degree C-axis Specially designed clamping table, travels in the X direction automatically and is program-controlled. Individual equipment options are available, for example: Base frame Heavy-duty base machine stand, electrically welded. Maximum workpiece sizes: X-axis 3350 mm (or 1500 + 1500 mm in two working areas) Y-axis 200 mm Z-axis 180 mm Traversing tool carrier 3 axes CNC controlled. Linear and interpolating. Positioning speed of the tool carrier max. 70 m/min. Vertical drive spindles 1 drive spindle for 1 drilling head with individually selectable drilling spindles 5 vertical drilling spindles, spacing 32 mm 3 horizontal double-output spindles on the Y-axis, spacing 32 mm 3 horizontal double-output spindles on the X-axis, spacing 32 mm 1 Vertical milling electro-spindle 8.0 KW, 12,000/18,000 RPM. Tool holder ISO 30 taper + ER 32 collet for manual tool change with quick release. 1 Milling / Sawing / Drilling spindle With motor 7.0 KW, 8,000 - 12,000 RPM. 360 C-axis, interpolating With attachment with 180 double output for saw blade and drilling/milling tool Horizontal electro-spindle 1 Milling spindle With motor 5.6 KW / 12,000 - 18,000 RPM With ER 32 collet Ledpfxszvgl No Agtohk 4 + 4 workpiece supports Adjustable on guides with 4+4 pneumatic clamping cylinders, with 2+2 horizontal clamping cylinders and front and side stops. Automatic magazine CA 2 Adjustable on linear guides, fixed on the left (zero) With easy access for the operator and a high degree of autonomous operation. With coated discharge chute for the machined workpieces. CONTROL UNIT - CAD CAM Free-standing control cabinet next to the machine Industrial PC with operator interface with 17" color touchscreen. SSD 120 GB, interface: Ethernet USB / RS 232 Programming with 3-D supported display Option for network connection for programming and remote support. Remote control console for controlling the machine by the operator during tests and setup. PROTECTIVE CABIN Surrounded with solid sheet metal panels With front protective screens, controlled by the work cycle Chip conveyor With outlet to the right side, with motor 0.37 KW Connection 400 V / 50 Hz Find it quickly Offer machines Subscribe to newsletter Unsubscribe from newsletter Contact us Overview

Condition: used, Year of construction: 2020, workpiece weight (max.): 35,000 kg, total length: 15,600 mm, total height: 6,000 mm, total width: 6,000 mm, overall weight: 155,000 kg, The Pittler WMZ PV4000 / 1-2 is a heavy CNC vertical turning machine with a portal design, featuring one workpiece spindle and two independently movable tool carriers. The machine enables turning, drilling, milling, and grooving. The right tool carrier is designed as a swiveling multifunction head with a B-axis and driven tools. Two separate chain magazines provide a total of 94 tool positions. Technical Data Machine Number: ZV029 Machine Concept: Portal machine with one workpiece spindle and two tool carriers Machining Processes: Turning, drilling, milling, and grooving Maximum Swing Diameter: 3800 mm Lhedpozu S U Hofx Agtsk Maximum Workpiece Diameter: 3800 mm Maximum Workpiece Speed: 100 min-1 Rated Speed: 36.7 min-1 Workpiece Clamping: Manual Chuck: Röhm Tool Holder: Capto C8 Tool Magazines: 2 chain magazines Tool Positions: 2 x 47 Total Number of Tool Positions: 94 Maximum Tool Diameter: 120 mm according to the operating manual Maximum Tool Diameter: 150 mm according to the order confirmation with appropriate magazine loading Maximum Tool Length: 400 mm Maximum Tool Weight: 20 kg Travel Paths X1-Axis Right Tool Carrier: 3200 mm X2-Axis Left Tool Carrier: 2800 mm Z1-Axis Right Tool Carrier: 1000 mm Z2-Axis Left Tool Carrier: 1000 mm Rapid Traverse X-Axes: up to 32 m/min Rapid Traverse Z-Axes: up to 20 m/min Workpiece Spindle Gear Reduction: 1 to 30 Maximum Speed: 100 min-1 Rated Speed: 36.7 min-1 Rated Power: 67.4 kW Short-Term Total Power: 202.2 kW Rated Torque: 52.65 kNm Maximum Drive Torque: 71.55 kNm Torque according to Order Confirmation: 67000 Nm at 40% duty cycle Motor Spindle Power according to Order Confirmation: 200 kW at 100% duty cycle Maximum Spindle Load Capacity including Chuck, Clamping Jaws, and Workpiece: 35000 kg Spindle Flange Diameter: 1900 mm Thrust Bearing Diameter: 1400 mm The workpiece spindle is designed as a water-cooled motor spindle with precision axial deep groove ball bearings. Tool Carrier and Multifunction Head The right tool carrier features a swiveling multifunction head with two Capto C8 holders for turning tools as well as drilling and milling tools. B-Axis for Stepless Positioning Swivel Range: 180 degrees Speed of Driven Tools: up to 6000 min-1 Tool Spindle Torque: approx. 120 Nm at 100% duty cycle Hydraulic Clamping Direct Measurement System Direct Coolant Supply High-Pressure Coolant Supply: up to 70 bar Tool Magazines Two chain magazines with 47 tool positions each Tool Holder: Capto C8 Maximum Tool Diameter: 120 mm Up to 150 mm with appropriate magazine loading Maximum Tool Length: 400 mm Maximum Tool Weight: 20 kg Tool Cleaning with Blowing Air Manual Magazine Loading Coolant and Chip Disposal Two Knoll Chip Conveyors Type 600 S-2/120 Knoll Band Filter Type KF400-2300 Additional Equipment Röhm Chuck Spindle Cooling Hydac FLKS-4S Hydraulic Unit Hydac TBM20 Electrical Data Operating Voltage: 3 x 400 VAC Protection Class: IP55 Maximum Power Consumption: 280 kVA Component weight max.: 35,000 kg Weight approx.: 155,000 kg Rotation height max.: 2,100 mm Table diameter: 3,800 mm Swing: 3,800 mm Control: Siemens SINUMERIK 840D sl Dimensions (LxWxH) approx.: 15600 x 6000 x 6000 mm Year of construction: 2,020 Condition: good Terms of payment: 100% prepayment before pick-up Terms of delivery: EXW EX Works under power: Yes

Condition: new, CNC machine Manufacturer: Comec Type: MD JAMB New machine 3 machining supports for cutting to miter angles, milling recesses for corner connectors, and door lock plates. A complete door frame element with decorative trim and rabbet trim is machined in a single clamping operation. This allows a complete door frame to be machined in approximately 2.5 to 3 minutes. The machining equipment can be individually adapted to customer requirements. Quick search Offer machines Sign up for newsletter Lsdpfxszvfl Is Agtehk Unsubscribe from newsletter Contact us Overview

Condition: used, Year of construction: 1998, WEEKE BP 150/K Manufacturer: WEEKE Type: BP 150/K Year of construction: 1998 Machine type: CNC machining center / Point-to-point cantilever machine Working area X approx. 3,645 mm* Ledpfx Aozvbhrogtjhk Working area Y approx. 1,250 mm* Working area Z approx. 250 mm* 1 main spindle power: 10 kW Main spindle speed max. 24,000 rpm Tool holder: HSK-F63 Tool changer: 8-position 4th axis 30 vertical drilling spindles 6 horizontal drilling spindles Table system: Console table Number of consoles: 8 Vacuum pump Safety device Control system: HOMAG HOMATIC 2000 / HOMATIC 2000 IPC* Software: HOMAG woodWOP 4.5 4th axis: C-axis / NC-controlled auxiliary axis*

Condition: ready for operation (used), functionality: fully functional, machine/vehicle number: 10056 196, number of rollers: 3, sheet thickness (max.): 30 mm, sheet thickness steel (max.): 30 mm, overall weight: 34,000 kg, Haeusler hydraulic roller, type RMA 2500/30. Ledpfxjzutixj Agtshk Machine in good working condition. Capacity: 30 mm steel x 2500 mm.

Condition: good (used), Year of construction: 1996, travel distance X-axis: 600 mm, travel distance Y-axis: 400 mm, travel distance Z-axis: 400 mm, Travel distances: X= 600, Y= 400, Z= 400 mm Table size: 900 x 480 mm Spindle speed: 40 - 4,000 rpm Dimensions LxWxH: 2500 x 2200 x 2200 mm Weight: approx. 3,000 kg Lodey Eyfwepfx Agtohk

Condition: used, Year of construction: 2012, total height: 4,500 mm, total length: 8,000 mm, total width: 6,000 mm, overall weight: 50,000 kg, Machine No.: 11720001123 Control Heidenhain iTNC 530 HSCI (3D path control) Travel Paths X: 1,850 mm Y: 2,100 mm Z: 1,250 mm B-axis: controlled universal swivel milling head C-axis: NC rotary table Ø 1,700 mm 5-axis simultaneous machining Spindle Motor spindle SK50 Speed: 20–12,000 min⁻¹ Power: 44 kW (40% duty cycle) / 32 kW (100% duty cycle) Torque: 288 / 187 Nm Tool holder: SK50 according to DIN 69871 Tool Changer 60-fold chain magazine Double gripper Equipment IKZ 40 bar Chip conveyor Tool measurement system Blum Laser NT Hybrid Heidenhain TS 640 infrared probe Electronic handwheel Minimum quantity lubrication (MQL) Oil/emulsion mist separator Coolant through spindle Coolant tank 980 l Rotating viewing window 3D quickSET Machine Protection Control (MPC) Adaptive Feed Control (AFC) ATC (Application Tuning Cycle) DMG MORI NetService DMG MORI SMARTkey Documentation and electrical schematic (German) Travel X-axis: 1850 - mm Dimensions (LxWxH) approx.: 8000 x 6000 x 4500 mm Travel Y-axis: 2100 - mm Weight approx.: 50,000 kg Travel Z-axis: 1250 - mm Year of construction: 2,012 Condition: in working order Terms of payment: 100% prepayment before pick-up Terms of delivery: EXW EX Works Lsdpfx Ajzv A Akjgtohk under power: Yes

Condition: good (used), Year of construction: 2008, Offer 26696 Lodpfezvnb Sox Agtshk Technical specifications (approximate): - CNC flame cutting machine with 2 torches, as shown in the image - 2 torches with adjustable height and inclination - Track gauge approx. 4.2 m - Track length approx. 7.5 m - Track height approx. 0.5 m - Support table - Space requirement approx. L 8 x W 7.5 x H 2.3 m - Weight approx. 3 tons

Condition: like new (used), Year of construction: 2011, machine/vehicle number: MA10110002, functionality: fully functional, SPECIFICATION Drilling capacity in mild steel 18mm Motor 0.45kW 415 volt Spindle 2MT Drive Belt, stepped pulleys Spindle speeds rpm 50Hz 400-700-1200-2100-3600 Spindle travel 75mm Throat depth 185mm Column diameter 70mm Table -working surface 250 x 164mm Table – slots width & centres 13 x 125mm Base – overall 240 x 360mm Max. distance chuck to table 330mm Overall height 865mm Ljdpfx Agezmuntetohk Overall width 280mm Overall depth 600mm Approx. Nett weight 77Kg Machine equipped with Chuck guard Table adjustment by rack Drill chuck

Condition: new, functionality: fully functional, Topking X-25 CNC Cylindrical Grinding Machine Topking “The X-25 CNC cylindrical grinding machine is the perfect answer for UK manufacturers facing space constraints,” explains Simon Rood. “Unlike traditional T-type base designs, the X-Series utilises a revolutionary cross-slide structure. This design allows the X-25 to reduce floor space requirements by over 30% while significantly enhancing stability. It is a superior choice when space is limited, making it ideal for busy production environments where every square metre counts.” Machine overview INTRODUCTION Compact CNC cylindrical grinding machine with an impressive capacity. The X series CNC cylindrical grinding machine integrates advanced design and innovative features, offering efficient, precise, and flexible machining solutions. This grinder can meet various processing needs and ensure high-quality results for small or large components. The X-axis and Z-axis of the X-series CNC cylindrical grinding machine adopt a cross-slide design, effectively reducing the footprint and axial travel, thereby saving production space. The high-rigidity machine body and the heavy-duty spindle and tailstock significantly increase the component load capacity. Lhedsubbqijpfx Agtek The high rigidity machine body ensures stability during grinding, providing high-quality machining results. The operating system is equipped with a high-performance CNC control system and a built-in graphical user interface (GUI), making setup easy and enabling users to operate with ease. The grinding applications are extensive, offering customers the most suitable machining solutions. Specification Swing (Max) 270mm Distance between centres 200mm Grinding Diameter (Max) 250mm Weight between centres (Max) 5kg CNC Control System FANUC or Mitsubishi CNC Controls

Condition: used, Year of construction: 2014, Working dimensions: X = 3425 mm, Y = 1287 mm, Z = 325 mm. Max. workpiece height: 180 mm. Max. clearance under the hood: Y = 1450 mm / Bumper version = 1370 mm. Includes CabinetControl Base, 1 machine license, and 1 office license. Milling head 7830, 1-stage, power 6.5 kW, air-cooled, n(max.) 1000 - 18000 min-1, infinitely adjustable. Max. power at 12000 min-1 to 18000 min-1 with HSK-F 63 tool holder, with collet chuck with HSK shank. Drilling unit 7884, 14 spindles, 10 vertical spindles individually accessible, arranged in an L-shape, 6 in the X direction and 4 in the Y direction. Drive power 3 kW, 32 mm pitch. Sawing unit: Integrated sawing unit for sawing/grooving in the X direction, n(max.) 1000 - 5650 min-1, infinitely adjustable. Tool holder: A = max. DM = 125 mm. Lhodpfoy Tpz Rox Agtek Location: Supplier.

Condition: good (used), Year of construction: 1980, functionality: fully functional, Gear-driven drill press, no belt changes required Very quiet and smooth operation - Drilling capacity in steel ST 60: 30 mm - Drill spindle mount: MK 3 - Drill spindle stroke: 160 mm Lsdszuxxfjpfx Agtshk - 9 drill spindle speeds: 90 - 1450 rpm - Overhang: 300 mm - Table with 2 T-slots - Table dimensions, swiveling: 500 x 450 mm - Table dimensions, base plate: 350 x 400 mm - Distance from base plate to spindle nose: 1100 mm - Max. distance table - drill spindle: 660 mm - Height adjustable via rack and pinion with hand crank - Column diameter: 120 mm - Drive: 380 V / 1.2 kW - Space requirement: approx. W 600 x H 2100 x D 670 mm - Weight: approx. 350 kg - Includes drill chuck

Condition: used, Year of construction: 2014, Used Machine Year of manufacture: 2014 Condition: The machine has been factory-overhauled by Ganner Features and Technical Specifications: Complete standard configuration including: - Support with linear guide consisting of: 1 single-spindle horizontal drilling unit, 0.65 kW motor, 70 mm stroke Tool speed selectable via operator software (3000/5000/8000 rpm) 1 blow-out, gluing, and dowel-driving station for dowels Ø 8 mm, dowel length 25–50 mm - Fully automatic, electronically controlled central lubrication - X-axis NC-controlled, with working length 1300 mm, travel speed max. 105 m/min. - Z-axis manually adjustable via mechanical digital counter, position adjustable via support table 5–40 mm - Dowel drive-in overhang adjustable from 7–20 mm via a mechanical digital counter; drilling depth from 0–35 mm (for drill bit length GL 70 mm) is automatically adjusted with the drive-in overhang - Closed glue system with 6 bar glue pressure via glue nozzle, for glues with a viscosity of 150 to 350 mPas - Glue quantity continuously adjustable via operator software - GLUE/WATER selector switch for flushing the glue system, each with: 1 stainless steel tank for 7.5 kg of glue and 7.5 l of water - Indicator light showing remaining glue levels in the glue tank - 1 left side stop, 1 right side stop, and 1 center stop (all removable) - 4 start buttons for individual processing of 1–4 workpieces - 4 pneumatic 10° angle clamping cylinders for workpiece thicknesses up to 80 mm, workpiece length (Y) min. 70 mm - 1 extraction funnel, connection Ø 80 mm - 1 TCT control unit with: Built-in industrial PC, including Beckhoff TWINCAT soft PLC, operating temperature range 0–50°C, 15-inch capacitive TFT industrial touchscreen, operating system: WINDOWS 7 - Programming via menu-driven user software, drilling distances freely programmable with ABSOLUTE, RELATIVE, or GRID dimensions, automatic workpiece mirroring and operation optimization, 4 work areas assignable to different programs, graphical workpiece display, parametric programming, zero-point offset, programmable worklists, error diagnosis with plain text Lhodjzlbrvopfx Agtjk Optional equipment: - 1 electronic, optical glue monitoring system G.I.C. (Glue Insert Control) for 1 glue nozzle - 1 Z-axis with NC-controlled, dynamic positioning for height adjustment of the drilling and dowel-driving station (programmable from 5–40 mm), travel speed max. 30 mm/sec. - 1 single-spindle vertical drilling unit drilling from the TOP, 0.65 kW, (3000/5000/8000 rpm), position (Y) manually adjustable via a mechanical digital counter from 5–40 mm, drilling depth (Z) max. 30 mm (with drill bit length GL 57 mm), Workpiece thickness (Z) max. 50 mm, workpiece length (Y) min. 130 mm (including drilling depth compensation, e.g., for Häfele Minifix) - 4 vertical 10° angle clamping cylinders with mount - 1 keypad with mount Availability: available shortly Location: DE-63934 Röllbach

Condition: good (used), WMW HECKERT BR 40/2 x 1250 radial drilling machine - Arm length: 1250mm - Maximum drilling diameter: 40mm - Morse taper: MK5 - Minimum speed: 20 RPM - Maximum speed: 1200 RPM - 3-speed gearbox with variable speed control - Dimensions of drilling head: (L x W x H) 710 x 710 x 500mm - Weight: 3000KG - Automatic feed Lsdpjzury Nsfx Agtohk - Dimensions (L x W x H): 2100 x 1000 x 2900mm

Year of construction: 2016, condition: used, overall weight: 300,000 kg, total length: 16,000 mm, total width: 9,000 mm, total height: 8,000 mm, Waldrich Coburg 17 S-10 FP 300 NC / 5 m – CNC Gantry Milling Machine Machine: 17-10 FP 300 NC / 5 m Serial Number: 2.8304.06 Original Year of Manufacture: 1983 In 2016, it was comprehensively overhauled and modernized by the manufacturer Waldrich Coburg. The machine is equipped with a modern Siemens SINUMERIK 840D sl control system and is ideally suited for heavy-duty machining of large and complex workpieces in machine, tool, mold, and power plant construction. The delivery includes a Universal Fork Milling Head USP 300 C 350 with B-axis as well as an additional Angle Milling Head WFU 500 SZ 400 F17, ensuring versatile machining capabilities for demanding milling tasks. The machine features a modern full protective enclosure, coolant system, chip conveyor technology, and extensive technical documentation including circuit diagrams and overhaul documentation. The system has been professionally dismantled and packed in containers. It is located at the Port of Hamburg and is immediately available and ready for worldwide shipment. Manufacturer: Waldrich Coburg Overhauled by Waldrich Coburg (2016) Siemens SINUMERIK 840D sl Universal Fork Milling Head USP 300 C 350 Additional Angle Milling Head WFU 500 SZ 400 F17 Workpiece weight up to 100 t Full protective enclosure Extensive technical documentation available Dismantled and ready for loading Location: Port of Hamburg, Germany Immediately available Tool holder type: ISO 50 Travel X-axis: 5700 - mm Movement B-axis: 0 - 180 ° Dimensions (LxWxH) approx.: 16000 x 9000 x 8000 mm Passage between the uprights: 3,500 mm 5-axis machining: Yes Travel Y-axis: 3500 - mm Weight approx.: 300,000 kg Travel W-axis: 800 - mm Travel Z-axis: 2050 - mm Year of construction: 2,016 Condition: unchecked Lhjdpfx Ajzc Sagegtjk Terms of payment: 100% prepayment before pick-up Terms of delivery: FOB Free On Board under power: No

Condition: used, Year of construction: 1972, Technical details: bore capacity in steel (diameter): 25 mm throat: 300 mm bore stroke: 630 mm spindle turning speed - continuous: 150 - 2860 U/min spindle taper MT: MK 4 Lodpfezfltdjx Agtohk Distance spindle/table max.: 630 mm table-size: 300 x 400 mm total power requirement: 1,65 kW weight of the machine ca.: 700 kg dimension machine approx.LxWxH: 0,6 x 0,8 x 2,10 m

Condition: ready for operation (used), Year of construction: 2012, functionality: fully functional, machine/vehicle number: 1205-H740-00, overall weight: 6,000 kg, travel distance X-axis: 500 mm, travel distance Y-axis: 100 mm, travel distance Z-axis: 50 mm, controller model: ANDRONIC 2060, No minimum price – guaranteed sale to the highest bidder! Submitting a bid obligates you to collect the item within the specified period, between October 7, 2026, and October 14, 2026! TECHNICAL DETAILS Travel range, X-axis: 500 mm Travel range, Y-axis: 100 mm Travel range, Z-axis: 50 mm Travel range, Z-axis: ±50 mm, relative to the central axis of the rotary indexing table / 200 mm Travel speed, X-axis: max. 30 m/min Travel speed, Y-axis: max. 20 m/min Travel speed, Z-axis: max. 30 m/min Acceleration, X/Y/Z-axis: 10 m/s² MACHINE DETAILS Control model: ANDRONIC 2060 Dimensions & Weight Ledpfxozu Iwwe Agtehk Dimensions (L x W x H): 2,500 x 1,650 x 2,700 mm Total weight: 6,000 kg Operating voltage: 230/400 V Frequency: 50 Hz Rated apparent power: 12 kVA Swivel radius, control panel: approx. 1,050 mm

Condition: used, Year of construction: 2011, Technical details: bore capacity in steel (diameter): 35 mm throat: 350 mm bore stroke: 180 mm threading: ST M 24 mm spindle taper MT: MK4 spindle speed:: 50 - 1450 U/min Distance spindle/table max.: 780 mm table clamping surface:: 560 x 560 mm Lhjdpfeyli Sfsx Agtek weight of the machine ca.: 500 kg dimension machine approx.LxWxH: 0,73 x 0,56 x 0,22 m · Heavy, solid cast construction · Automatic gear lubrication via oil pump · Smooth running due to ground gearbox gears operating in an oil bath · High concentricity thanks to hardened and ground main spindle · Thread cutting device · Lockable main switch and motor protection switch · Optidrill B 40GSM additionally with automatic quill feed · Electric · 2 feed rates: 0.1 / 0.2 mm/rev · Coolant system · Drilling depth stop · 18 speeds: 50 – 1,450 rpm · 9 selectable speeds via gearbox lever on the front of the drill head *

Condition: used, Year of construction: 1997, Technical details: bore capacity in steel (diameter): 32 mm x-travel: 750 mm y-travel: 520 mm drill capacity in cast iron: 45 mm revolution per minute: 90 - 4500 U/min feed steps: 6 Ledpfozgwgfjx Agtehk bore spindle stroke: 250 mm boring spindle diameter: 30 mm drill spindle - Morse Taper: MK4 vertical adjustment of the arm: 520 mm throat max.: 1000 mm throat min.: 250 mm column diameter: 400 mm swivel range of the arm: 180 ° table clamping surface LxW: 1150 x 800 mm total power requirement: 3,5 KW weight of the machine ca.: 2000 kg dimension machine approx.LxWxH: 1,7 x 1,07 x 2,61 m The KOVOSVIT VO 32 is a robust and versatile radial drilling machine designed for industrial applications. The machine is suitable for drilling, boring, countersinking, reaming, and tapping operations in steel, cast iron, and other materials. Thanks to its swiveling radial arm and large reach, even large and heavy workpieces can be machined conveniently without the need for complex repositioning. The machine features a massive cast-iron construction, a powerful main drive, and an automatic feed system. The drilling head can be moved along the radial arm, providing a large working area. Its solid design ensures high precision, reliability, and a long service life, even under continuous operation. Equipment: ·Including coolant pump ·1 × boring tool block (boring cube) ·1 × machine vise *

Condition: used, Year of construction: 1997, Technical details: sheet width: 3050 mm plate thickness: 16 mm pre-bending: 12 distance between columns: 5200 mm roll dia. top roll: 330 mm roll dia. bottom roll: 360 mm Total power requirement: 15 kW weight of the machine ca.: 18,0 t Ljdpfsyh D Nnjx Agtehk dimension machine approx.LxWxH: 5,3 x 2,4 x 2,0 m

Condition: used, Year of construction: 2019, - Magazine loading system - Clamping table for frame parts - 3 horizontal, longitudinal drilling units from the rear - 4 vertical drilling units from above 1 Drilling machine Manufacturer: KOCH Type: BL 2500 NC select line - used - Year of manufacture: 2019 Workpiece dimensions Workpiece length 150 - 2500 mm Workpiece width 20 - 300 mm Workpiece thickness 10 - 50 mm Material: Solid wood Magazine loading system 1 with workpiece return. Workpiece insertion via 2 Lhodjzuynhjpfx Agtjk parallel-controlled servomotors. The number of workpieces in the magazine depends on the workpiece weight. Manual workpiece insertion Clamping table for frame parts 1 By inserting 3 support segments into the longitudinal drilling units, workpieces can be inserted manually and clamped with clamping cylinders and templates. This also allows for special workpiece dimensions. Work cycle triggering via 2 manual controls on the swappable control panel. 3 horizontal, longitudinal drilling units from the rear Construction width 160 mm Drilling motor 2 kW Longitudinal adjustment (X) with LCD display Vertical adjustment (Z) With dust extraction 4 vertical drilling units from above (supported on one side in a linear guide) Adjustable over the entire working width (X), reading LCD display. Adjustable in working depth (Y), reading LCD display One vertical clamping cylinder mounted directly on the unit Counterpieces for through-holes are available as an option. Drilling motor 1.5 kW at 50 Hz Drilling stroke 50 mm Speed 2,800 rpm Total drill length 70 mm With 4 rotary indexing heads with quick adjustment (for vertical drilling units) with fixed stops at 0 and 90 degrees Positioning control KOCH NUMERIC Basic 1 Positioning control with Beckhoff C6920 industrial PC Intel Celeron 2.2GHz CPU 2.5 320GB HDD 1x RS232, 2x USB, 1x Ethernet available 15-inch touch panel Operating system Windows 7: English User interface in English Input of all machine commands via the touch panel Software is prepared for an online connection. The configuration of the online connection (network) and commissioning are carried out by the customer or their software company. USB port on the PC 4 x Dynamic NC axis (with bearing control) for Z axes Connection data 1 Electrical connection 400 V, 50 Hz, 3 phases Voltage fluctuations max. + 6 % to - 10 % If protected by an RCD (residual current device) on the customer's side, an all-current sensitive (R CCB, Type B) RCD with a rated residual current of /= 300 mA must be used. Air connection 7 bar Dust extraction air velocity min. 30 m/s Note: The technical data and descriptions are a transcript of the original order confirmation. The data is for informational purposes only and is not binding.

Condition: used, Year of construction: 2001, - X = 2 x 2,400 - Y = 1,800 mm - Main spindle 12 kW - 18-position tool changer - Gluing unit with 6-position coil magazine Used CNC machining center Manufacturer: IMA Type: BIMA P 480 V, 180/480 Year of manufacture: 2001 Alternative processing: - X = 2 x 2,400 - Y = 1,800 mm - Main spindle 12 kW - 18-position tool changer - Gluing unit with 6-position coil magazine Working area: For standard machines, Y = 1,800 mm Changing table area for alternating machining: X = 2 x 2,400 mm / Milling and drilling X = 2 x 2,100 mm / Gluing CNC line control IMATRONIC NT 231 Automatic adjustment table with clamping plates Main spindle 12 kW With integrated C-axis, 360 degrees Automatic tool/adapter unit changer, 18-position 1 edge banding unit VT100 With glue application device Edge thickness: 0.4 - 3 mm Lodpfxozux Uao Agtshk For 4-sided edge banding and all-round edge banding with butt joint 6-position roller magazine 1 trimming unit 0.8 kW Including adapter unit - Saw, fixed at 90 degrees - Horizontal milling unit (corner release) - Chamfer milling unit - Straight milling unit - Profile drawing blade Note: The technical data and descriptions are a transcript of the original order confirmation. The data is for informational purposes only and is not binding.

Condition: used, Year of construction: 2003, - Workpiece length: 800 - 3000 mm - Workpiece width: 350 - 1400 mm - Workpiece thickness: max. 70 mm with edge / max. 80 mm for milling - Main spindle 12 kW - Tool changer, 18-position CNC machining center Manufacturer: Homag Type: PROFI BAZ20/30/16/V/D Year of manufacture: 2003 Technical data Homatic - CNC control CNC programming system WOODWOP Postprocessor Workpiece dimensions - Workpiece length: 800 - 3000 mm - Workpiece width: 350 - 1400 mm - Workpiece thickness: max. 70 mm with edge / max. 80 mm for milling - Edge band width: min. 120 mm - Weight: max. 150 kg Throughfeed table - Longitudinal console 1, fixed installation - Longitudinal console 2, manually adjustable via width adjustment in the Y-direction - 8 vacuum clamps 125 x 50 x 100 mm - Working height, bottom edge of workpiece: 950 mm Motor, width adjustment, longitudinal console, traversing table - For different workpiece widths via servo drive for throughfeed table - Per longitudinal console Chip conveyor - Chip and waste disposal via integrated chip conveyor under the longitudinal traverse Stop pins for top layer overhang - Stop pins with lifting-rotating mechanism for workpieces with max. 20 mm top layer overhang - Individually selectable, end position monitored, stroke 110 mm - For manual placement of doors Vacuum pump 100/140 m3/h Unit for positioning the vacuum clamps - Mounted on the unit carrier with pneumatic extension console - For max. 4 vacuum clamps per longitudinal console Main spindle 12 kW - Tool holder HSK F63 - Extraction system for all tools and units - Three-phase asynchronous motor 12 kW at S1, water-cooled - Tool weight: max 6 kg incl. holder - Tool length: max. 200 mm from the motor spindle bottom edge - Tool diameter: max. 180 mm for milling tools / max 200 mm for sanding tools - Frequency converter: 15 kW - Speed range: 1500 - 18000 rpm, stepless, programmable - Full rated power from 12000 rpm Unit interface for the main spindle - For connecting the machining units - Pneumatic and swivel drive interface - C-axis with torque transmission and 3-point support Tool changer, 18-position For tools and units with HSK F63 Tool weight: 6 kg Tool length: max. 200 mm from the motor spindle bottom edge The following tool and unit configurations are possible - 18 x max. 130 mm - 9 x max. 180 mm and 9 x max. 70 mm - Tool diameter max. 200 mm for sanding tools - Tool changer can be raised for a moving pick-up station on the left side Drilling/milling unit, 4 spindles, for tool changer - For automatic changing in the main spindle - Collet holder ER25 up to max. 16 mm shank diameter - Tool protrusion max. 50 mm - Speed: max. 13500 rpm - Standard collet 10 mm - Infinitely swiveling via the C-axis - Without tool Lock case milling unit, 2 spindles, D=16/20 - With integrated blow-out nozzle - Two-sided spindle outlet with counter-rotating direction Lsdpfx Aozux Tpjgtehk - Speed: 12000 rpm - Infinitely swiveling via the C-axis - Without tool 1x Weldon chuck: 20 mm - Reducing sleeve for tool 16 mm - Total tool length: 180 mm - Tool protrusion: max. 135 mm 1x ER16 collet with 10 mm - Total tool length: max. 70 mm - Tool protrusion: max. 40 mm Sawing/drilling unit, swiveling, for tool changer - For miter cuts and angled drilling - Manually swiveling 0 - 90 degrees - Mounting flange 30 mm with countersunk head screws - Tool diameter 52 mm - Prepared for miter saw: max. 180 mm - Drill chuck with Weldon chuck: D=10 mm - Speed: max. 9000 rpm - Infinitely swiveling via the C-axis -
