Used Emco Turn 340 for sale (9,793)

Condition: used, Year of construction: 2018, Operating hours: 600 h Technical Data: Travel range X/Y/Z: 450 / 350 / 400 mm Distance spindle nose to table: 230 - 630 mm (horizontal milling spindle) Rapid traverse speed X/Y/Z: 5000 / 5000 / 5000 mm/min Feed rate X/Y/Z: 10 - 2000 mm/min, stepless Max. feed force in X/Y/Z: 10 / 10 / 15 kN Clamping surface: 800 x 400 mm (fixed angle table) Max. table load: 30 kg (fixed angle table) Vertical milling head: Speed range: 10 - 5000 rpm Power: 10 kW Dimensions (LxWxH), approx.: 1980 x 2030 x 1990 mm Weight, approx.: 2,270 kg Equipment: - Swiveling control panel - Digital display based on Sinumerik 828D - Forward/reverse rotation of main spindle - Linear guides Lhjdpfjxu I Txsx Akueg - Milling spindle with quadruple radial/axial bearing - Main motor with spindle brake - CE compliant

Year of construction: 1992, condition: new, New driver ISO40 for milling machines FN 20/32/40 Lhjdpfsk Nk I Nsx Akusg

Year of construction: 1998, condition: new, New trapezoidal spindle+nut X-axis, for FN20, FN32, FN40 Lhedek Nk Iwjpfx Akuog

Condition: ready for operation (used), Year of construction: 2007, operating hours: 11,261 h, functionality: fully functional, machine/vehicle number: M-077.084.07, empty load weight: 4,800 kg, Equipment: chip conveyor, MACHINE DETAILS Weight: 4,800 kg Operating Hours Spindle hours: 11,261 h Ljdpfx Akoxpvwzjujhg Control system on hours: 125,668 h EQUIPMENT Conveyor belt (FAMUP 405-1498-1, 352 kg)

Condition: good (used), Automatic perforator Kugler 340-2R Device in very good condition. Includes perforation tool 3:1 round hole and additional tools. Manufacturer description: Perforation device with a working width of up to 340 mm Device adapted for continuous operation and high loads Unique „Two-finger” system ensures excellent reception of sheets of various grammages Two-shelf feeder enabling continuous operation After perforation, sheets rotate around a special drum, thanks to which the correct sequence of pages is maintained at the receiving station Possibility of using two-part strips enabling perforation of both books and calendars Perforation up to 3 mm in one cycle Quick and easy replacement of perforation strips Possibility of using strips with / without a recess for the hanger. There is a shaker on the delivery. Maximum working width. 340 mm Format / Dimensions min. 120x105mm Format / Dimensions max. 340x340mm Maximum cutting thickness. 3mm Mechanical cycles per minute 80-100 cycles Lsdpfx Akswt Stvouehg Power supply 380V Weight 1580kg

Condition: used, weight approx.: 450messurements (LxWxH): 1250x1350x1550y-travel: 300z-travel: 200x-travel: 350speed range: 80-2200table diamension: 600x200 Description:  -)coolant equipment -)machine lamp Lhodpfxergvbpe Akujg Revs80 – 2200 (8) r.p.m.TaperDIN2078 ISO30 (Anzugsschraube M12)Working area300 x 200 x 350 mmTable600 x 200 mmFeeds stepless X,Y range20 – 200 mm/id traverse X,Y range1200 mm/ll travel45 mmMax. feed force1600 NmSpindle motor1,1/1,4 kWvertical table600 x 200 mmDistance vertical milling spindle - milling table20 – 370 mmDistance horizontal milling spindle - milling table84 – 434 mmFeed in X-axis (stepless)20 – 200 mm/minLength1250 mmWidth1350 mmHeight1550 mmWeight450 kg

Condition: ready for operation (used), Year of construction: 2006, operating hours: 19,067 h, functionality: fully functional, machine/vehicle number: 122616, travel distance X-axis: 500 mm, travel distance Y-axis: 95 mm, travel distance Z-axis: 1,650 mm, controller model: OKUMA OSP P200L, center width: 1,500 mm, TECHNICAL DETAILS Travel in X-axis: 500 mm Travel in Y-axis: 95 mm Travel in Z-axis: 1,650 mm Swing over bed: 550 mm Power: 22.0 kW Distance between centers: 1,500 mm Spindle bore: 80 mm Counter spindle speed: 4,500 rpm Lsdpfjy Rxprsx Akuohg Tool magazine: 44 tools Tool holder: HSK-F63 Spindle speed: 12,000 rpm MACHINE DETAILS Control system: OKUMA OSP P200L Dimensions & Weight Dimensions (L x W x H): 5,100 x 2,800 x 2,900 mm Shipping weight: 13,700 kg Shipping packages: 7 pieces Operating hours: 19,067 h EQUIPMENT Automatic workpiece loader with controlled arm from Pneumotec Automatic bar feeder from LNS Quick Load Servo III Counter spindle VAC-MB11 Milling head with automatic tool changer Turret: 12 tool positions Chip conveyor Turret head Powered tools Bar loader 3-jaw chuck Tool magazine C-axis Documentation CE marking

Condition: ready for operation (used), Year of construction: 1999, functionality: fully functional, turning length: 380 mm, turning diameter: 450 mm, spindle bore: 59 mm, rotational speed (max.): 5,000 rpm, controller model: Seicos 40L Multi, No minimum price – guaranteed sale to the highest bidder! TECHNICAL DETAILS Turning diameter: 450 mm Turning length: 380 mm Maximum machining diameter: 340 mm Travel X-axis: 215 mm Travel Z-axis: 400 mm Lhedpfx Akjy R Dmijusg Bar capacity: 51 mm Spindle speed range: 30 to 5,000 rpm Spindle drive power: 11 / 7.5 kW Spindle nose: A2-6 Spindle bore: 59 mm Bearing diameter: 100 mm Turret: 16 stations Feed rate: 0.001 to 500 mm/min Rapid traverse X/Z: 30 m/min Tool shank diameter: 25 x 25 mm Drill shank diameter: 40 mm Tailstock taper: MT 5 Tailstock quill stroke: 300 mm MACHINE DETAILS Control unit: Seicos 40L Multi Total power requirement: 23 kVA Dimensions & Weight Space requirement: approx. 5.5 x 2.8 x 2.2 m Machine weight: approx. 4.6 t EQUIPMENT Documentation Chip conveyor Tailstock Signal light Parts discharge chute Tool setting arm Work area illumination Tool holder

Condition: ready for operation (used), Year of construction: 2006, operating hours: 13,006 h, functionality: fully functional, machine/vehicle number: 190433, turning length: 1,050 mm, turning diameter: 660 mm, travel distance X-axis: 580 mm, travel distance Y-axis: 150 mm, travel distance Z-axis: 1,050 mm, controller model: Mazatrol Matrix, The technical data is based on manufacturer specifications. The seller cannot guarantee its accuracy! Operating times according to control system: Total: 5,025 h Automatic machining: 1,866 h Pure machining RV1: 1,037 h Pure machining RV2: 298 h Operating time: 13,006 h Tool type: Capto C6 Tool changer: 72 positions Turret: 9 positions TECHNICAL DETAILS Max. turning diameter: 660 mm Diameter over bed: 760 mm Turning length: 1,050 mm X-axis: 580 mm Y-axis: 150 mm Z-axis: 1,050 mm Main spindle speed: 5,000 rpm Counter spindle speed: 5,000 rpm Ledpfsy Slqfjx Akuohg Milling spindle: 12,000 rpm MACHINE DETAILS Control system: Mazatrol Matrix Main circuit: 3AC Main circuit voltage: 400 V Frequency: 50/60 Hz Control circuit AC: 100 V Control circuit DC: 24 V Main motor current draw: max. 84 A Main motor voltage: 400 V Rated power: 91.8 kVA Weight: 11,800 kg

Condition: ready for operation (used), Year of construction: 1999, operating hours: 12,500 h, functionality: fully functional, controller model: OSP 7000M, Equipment: chip conveyor, TECHNICAL DETAILS Tool changer: 24 BT40 Lhedjy S Sw Eopfx Akueg MACHINE DETAILS Control system: OSP 7000M HS: Big Bore GS: Standard Bore Coolant pump: 8 bar Spindle hours: 12,500 h EQUIPMENT Chip conveyor

Condition: ready for operation (used), Year of construction: 2008, operating hours: 10,500 h, functionality: fully functional, turning diameter: 630 mm, travel distance X-axis: 580 mm, travel distance Y-axis: 160 mm, travel distance Z-axis: 935 mm, controller model: Okuma OSP P200L, TECHNICAL DETAILS Diameter over slide: 630 mm Machining diameter: 630 mm Distance between centers: 900 mm Travel range X-axis: 580 mm Travel range Y-axis: 160 mm Travel range Z-axis: 935 mm Travel range W-axis: 1,000 mm Travel range C-axis: 360° Travel range B-axis: -30° to 195° Main spindle: 3,800 rpm Counter spindle: 5,000 rpm Milling spindle: 6,000 rpm Rapid traverse X-axis: 40,000 mm/min Lhsdpfx Akey S Swxouog Rapid traverse Z-axis: 40,000 mm/min Rapid traverse Y-axis: 26,000 mm/min Rapid traverse W-axis: 20,000 mm/min Rapid traverse C-axis: 200 rpm Rapid traverse B-axis: 30 rpm Tool diameter max.: 90 mm Tool diameter without adjacent tools max.: 130 mm Tool length max.: 300 mm Tool weight max.: 10 kg MACHINE DETAILS Number of axes: 6 Control system: Okuma OSP P200L Dimensions & Weight Footprint: 4,340 × 2,050 mm Height: 2,600 mm Weight: 10,300 kg Spindle hours: 10,500 h EQUIPMENT Documentation/Manual Speed infinitely adjustable Marpos tool sensor Chip conveyor & coolant system with small band filter system ATC 60 system HSKA-63 (60 tools)

Condition: ready for operation (used), Year of construction: 2007, operating hours: 5,426 h, functionality: fully functional, machine/vehicle number: 101098, travel distance X-axis: 400 mm, travel distance Z-axis: 200 mm, workpiece length (max.): 130 mm, TECHNICAL DETAILS Travel range, X-axis: 400 mm Working stroke, X-axis: 150 mm Travel range, Z-axis: 200 mm Chuck diameter: 160 mm Turning diameter: max. 200 mm Machining diameter: max. 130 mm Part length: max. 110 mm Main spindle Spindle flange according to DIN 55026: Size 5 Spindle bearing, diameter front: 80 mm Speed, hybrid bearing: max. 6,000/7,500 rpm Main drive Lhodjy T Iupopfx Akujg AC asynchronous motor: 1MB200E Indramat Low-voltage technology: Fanuc Power at 100/40 % duty cycle: 16/24 kW Torque at 100/40 % duty cycle: 102/153 Nm Rated speed: 1,500 rpm Feed drive Rapid traverse speed X: 60 m/min Rapid traverse speed Z: 30 m/min Feed force X and Z: 5 kN Ball screw diameter X and Z: 40 mm Acceleration X/Z: 5/5 m/s² Tool holder Cylindrical shank tool holder according to DIN 69880: 12-fold Shank diameter: 40 mm Tool length incl. holder: max. 190 mm Pitch circle diameter: max. 740 mm Pitch circle diameter Lifetool: max. 620 mm Tool holder with driven tools Cylindrical shank tool holder according to DIN 69880: 12-fold Shank diameter: 40 mm Speed: max. 6,000 rpm Rated speed: 3,000 rpm Torque at 10 % duty cycle: max. 37 Nm Torque at 25 % duty cycle: max. 26 Nm Torque at 100 % duty cycle: max. 14 Nm MACHINE DETAILS Closed standard automation Number of carrier bars with workpiece diameter 27 mm: 85 Number of carrier bars with workpiece diameter 18 mm: 130 Permissible total load: max. 120 kg Pick-up stroke depressed: 1 mm Pick-up stroke over-depressed EMERGENCY STOP: 5 mm Pick-up spring travel: max. 30 mm Chain length: 162 inches Chain pitch: 25.4 mm Chain tension with 27 carrier bars: 400 N Chain sprocket: Z = 30 Gear ratio: i = 100 Motor revolution/band revolution: 540 Loading time: 2–4 s Electrical equipment Operating voltage: 400–480 V Control voltage DC: 24 V Control voltage AC: 230 V Frequency: 50/60 Hz Connected load: 31 kW Supply line fuse: 50 A Design of the electrical system: VDE 0113 Operating hours: 5,426 h

Condition: ready for operation (used), Year of construction: 2006, operating hours: 91,318 h, functionality: fully functional, machine/vehicle number: 040033, rotational speed (max.): 5,000 rpm, working width: 120 mm, working height: 260 mm, working length: 360 mm, TECHNICAL DETAILS Work area X-axis: 360 mm Work area Y-axis: 120 mm Work area Z-axis: 260 mm Handling area X/Z: 490/260 mm Maximum spindle speed: 5,000 rpm Spindle bore: 65 mm Spindle diameter at front bearing: 110 mm Spindle nose, cylindrical: ∅ 140 mm Feed force X/Y: approx. 8,000/10,000 N Lhsdpfx Aksy T Itrsuog Feed force Z: 10,000 N Rapid traverse rate X/Z/Y: approx. 80/40/7.5 m/min Acceleration X/Z/Y: 7 m/s² MACHINE DETAILS Control system: SIEMENS Sinumerik Power at 100% duty cycle ED, main spindle: 20 kW Torque at 100% duty cycle ED: 105 Nm Power at 40% duty cycle ED: 27 kW Torque at 40% duty cycle ED: 145 Nm Dimensions & Weight Machine dimensions (L x W x H): 2,430 x 2,000 x 2,850 mm Machine weight: approx. 7,500 kg Rated power: 20 kW Apparent power: 25 kVA Rated current: 36 A Voltage: 400 V Frequency: 50/60 Hz Operating hours: 91,318 h EQUIPMENT Sliding door: Sheet thickness 5 mm

Condition: ready for operation (used), Year of construction: 2005, operating hours: 91,318 h, functionality: fully functional, machine/vehicle number: 040018, rotational speed (max.): 5,000 rpm, controller model: SIEMENS Sinumerik, working width: 120 mm, working height: 260 mm, working length: 360 mm, TECHNICAL DETAILS Work area X-axis: 360 mm Work area Y-axis: 120 mm Work area Z-axis: 260 mm Handling area X/Z: 490/260 mm Maximum spindle speed: 5,000 rpm Spindle bore: 65 mm Spindle diameter at front bearing: 110 mm Spindle nose, cylindrical: ∅ 140 mm Feed force X/Y: approx. 8,000/10,000 N Feed force Z: 10,000 N Rapid traverse rate X/Z/Y: approx. 80/40/7.5 m/min Acceleration X/Z/Y: 7 m/s² MACHINE DETAILS Lhodpfx Akey T Im Esusg Control system: SIEMENS Sinumerik Power at 100% duty cycle ED, main spindle: 20 kW Torque at 100% duty cycle ED: 105 Nm Power at 40% duty cycle ED: 27 kW Torque at 40% duty cycle ED: 145 Nm Dimensions & Weight Machine dimensions (L x W x H): 2,430 x 2,000 x 2,850 mm Machine weight: approx. 7,500 kg Rated power: 20 kW Apparent power: 25 kVA Rated current: 36 A Voltage: 400 V Frequency: 50/60 Hz Operating hours: 91,318 h EQUIPMENT Sliding door: Sheet thickness 5 mm

Condition: ready for operation (used), Year of construction: 2004, operating hours: 63,778 h, functionality: fully functional, machine/vehicle number: 06800002061, rotational speed (max.): 6,000 rpm, spindle bore: 56 mm, spindle diameter: 90 mm, empty load weight: 6,000 kg, TECHNICAL DETAILS Travel X-axis: 800 mm Travel Z-axis: 300 mm Rapid traverse rate X: 100 m/min Rapid traverse rate Z: 45 m/min Chuck diameter: 200 mm Spindle head, flat flange: F140 h5 Spindle diameter in the front bearing: 90 mm Spindle bore: 56 mm C-axis Speed range: 0–100 rpm Torque, holding torque brake: 240 Nm Accuracy when positioning: < 0.02 degrees Number of tool stations: 12 Cylindrical shank diameter: 40 mm Drive power, 40% duty cycle: 10.8 kW Torque: 28 Nm Speed: max. 6,000 rpm MACHINE DETAILS Lhodpfjy T Ikksx Akujg Power of the three-phase main drive: 25 kW Torque at 100% duty cycle: 160 Nm Speed range: 20–7,000 rpm Electrical data Power: 25/35 kW Voltage: 400 V / 50 Hz Control voltage: 24 V DC Hydraulics Total capacity: approx. 25 l Pressure: 80 bar Pressure for clamping device: max. 700 bar Coolant system Capacity: approx. 190 l Pump power: 1.7 kW Flow rate at 6 bar: 20 l/min Weight: approx. 6,000 kg Operating hours: 63,778 h

Condition: ready for operation (used), Year of construction: 2002, operating hours: 74,523 h, functionality: fully functional, machine/vehicle number: 06800001121, rotational speed (max.): 6,000 rpm, spindle bore: 56 mm, spindle diameter: 90 mm, empty load weight: 6,000 kg, TECHNICAL DETAILS Travel X-axis: 800 mm Travel Z-axis: 300 mm Rapid traverse rate X: 100 m/min Rapid traverse rate Z: 45 m/min Chuck diameter: 200 mm Spindle head, flat flange: F140 h5 Spindle diameter in the front bearing: 90 mm Spindle bore: 56 mm C-axis Speed range: 0–100 rpm Torque, holding torque brake: 240 Nm Accuracy at point positioning: < 0.02 degrees Number of tool stations: 12 Cylindrical shank diameter: 40 mm Drive power, 40% duty cycle: 10.8 kW Torque: 28 Nm Speed: max. 6,000 rpm MACHINE DETAILS Power of the three-phase main drive: 25 kW Torque, 100% duty cycle: 160 Nm Speed range: 20–7,000 rpm Electrical data Power: 25/35 kW Voltage: 400 V / 50 Hz Control voltage: 24 V DC Hydraulics Total capacity: approx. 25 l Pressure: 80 bar Ledpfxoy T Id De Akuohg Pressure for clamping device: max. 700 bar Coolant system Capacity: approx. 190 l Pump power: 1.7 kW Flow rate at 6 bar: 20 l/min Weight: approx. 6,000 kg Operating hours: 74,523 h

Condition: ready for operation (used), Year of construction: 2002, operating hours: 77,119 h, functionality: fully functional, machine/vehicle number: 06810000041, rotational speed (max.): 6,000 rpm, spindle bore: 56 mm, spindle diameter: 90 mm, empty load weight: 6,000 kg, TECHNICAL DETAILS Travel X-axis: 800 mm Travel Z-axis: 300 mm Rapid traverse rate X: 100 m/min Rapid traverse rate Z: 45 m/min Chuck diameter: 200 mm Spindle head, flat flange: F140 h5 Spindle diameter in front bearing: 90 mm Spindle bore: 56 mm C-axis Speed range: 0–100 rpm Torque, holding torque brake: 240 Nm Lsdpsy T Iddsfx Akushg Accuracy when positioning: < 0.02 degrees Number of tool stations: 12 Cylindrical shank diameter: 40 mm Drive power, 40% duty cycle: 10.8 kW Torque: 28 Nm Speed: max. 6,000 rpm MACHINE DETAILS Power of the three-phase main drive: 25 kW Torque, 100% duty cycle: 160 Nm Speed range: 20–7,000 rpm Electrical data Power: 25/35 kW Voltage: 400 V / 50 Hz Control voltage: 24 V DC Hydraulics Total capacity: approx. 25 l Pressure: 80 bar Pressure for clamping device: max. 700 bar Coolant system Capacity: approx. 190 l Pump output: 1.7 kW Flow rate at 6 bar: 20 l/min Weight: approx. 6,000 kg Operating hours: 77,119 h

Condition: good (used), Year of construction: 2022, machine/vehicle number: 25666, Equipped with: Hydraulic Unit Sinumerik 840D sl CNC Control Slim Line Operator Panel OP012 W/12 TFT-Color Display 19" Machine Control Panel 20 Tool ATC CAPTO C6 Multifunctional Tool Carrier For Turning and Driven Tools One Fixed Tool Unit Assembled To The Compound Slide W/Coolant Thru The Turning And Drilling Tools, Coolant For The Driven Spindle From The Outside Drilling Spindle Additional Drill Spindle For Orientation Chip Conveyor Coolant Equipment -Including piping and shut-off valve and flow control switch -To supply coolant to tools for coolant and flushing through the cutting tools -To supply coolant for flushing the work piece and chuck -To supply coolant for flushing the working area Paper Band Filter Immersion Cooler High Pressure Coolant Pump, 40 Bar Through Tools Flushing Pistol, Hand Held Air Cleaner - Mechanical Separation "Mist Collector" Tool Life Display Remote Diagnostics Signal Lamp Lhedpfx Akoy Tybzsuog Automatic Door For Loading W/Shuttle Load and Unload Shuttle Swivel Loader Automation Cell Tuned for Part Pallet Conveyor For 20 Raw And Finished Parts Pallets Pallets Designed for Part 596500 Handling System SPC Station (Maximum O 270 mm, Maximum H 150 mm, Maximum Wt. 12 kg) NIO Station (Closing forward leading gravity) Skiving Software (Hardware: Software and user surfaces for skiving technology) Measuring Probe (For measuring diameters and length of the workpiece in the machine) Measuring Software for Teeth Measuring (MDK and Flank Line, Software and User) Measuring Program (Automatically measuring program for measure the position of the two gears to each other, after using sister tools) SPC (Every X workpieces the MDK needs to be measured) Tool Changer (Precut, measurer and final cut) Skiving Tool Identification (Hardware, software for the identification of the skiving tool after tool change) Hydraulic Diagrams Coolant Diagrams Lubrication Diagrams Electrical Wiring Diagrams Hardcopy of Diagrams CF Certificates Specifications: Workpiece Spindle: -Speed: 0-7000 l/min -Power: 55,2 - 59,7 kW Tool: Capco C6 Tool Spindle: -Speed: 0-6000 l/min -Power: 29 - 41 kW Machine Weight, Floor Space and Voltage Supply: -Operating Voltage: 400V, 3 Phases, 50 Hz -Control Voltage: 24 V -Lighting Voltage: 240 V, 50 Hz -Floor Space: 2,700 x 2,600 mm -Height: 4,000 mm -Total Weight, Approximate: 16,000 kg Longitudinal, Z-Axis: -Stroke: 800 mm -Rapid Rate: 24 m/min -Feed Force: 12 kN Transverse, X-Axis: -Stroke: 900 mm -Rapid Rate: 24 m/min -Feed Force: 12 kN Tool Spindle, B-Axis: -Range: -20 / +90 Degree Y-Axis for Spindle Unit: -Stroke: 200 mm -Rapid Rate: 12 m/min -Feed Force: 6 kN C-Axis Main Spindle: -Positioning Accurace: 9" Multifunctional Tool Carrier: -Power: 29 kW at 100% ED -Power: 41 kW at 44% ED -Torque: 141 Nm at 100% ED -Torque: 212 Nm at 44% ED -Spindle Speed: 0-6000 min-1 -B-Axis for Stepless Motion in a Range Of: -20/+90 Degree Tool Magazine: -Maximum Tool Diameter: 100 mm -Approximate Tool Length: 300 mm -Approximate Tool Weight: 12 kg Swivel Loader: -Maximum Workpiece Diameter: 270 mm -Height: 150 mm -Weight: 16 kg

Condition: good (used), Year of construction: 2019, machine/vehicle number: 25667, Equipped with: Hydraulic Unit Sinumerik 840D sl CNC Control Slim Line Operator Panel OP012 W/12 TFT-Color Display 19" Machine Control Panel 20 Tool ATC CAPTO C6 Multifunctional Tool Carrier For Turning and Driven Tools One Fixed Tool Unit Assembled To The Compound Slide W/Coolant Thru The Turning And Drilling Tools, Coolant For The Driven Spindle From The Outside Drilling Spindle Additional Drill Spindle For Orientation Chip Conveyor Coolant Equipment -Including piping and shut-off valve and flow control switch -To supply coolant to tools for coolant and flushing through the cutting tools -To supply coolant for flushing the work piece and chuck -To supply coolant for flushing the working area Paper Band Filter Immersion Cooler High Pressure Coolant Pump, 40 Bar Through Tools Flushing Pistol, Hand Held Air Cleaner - Mechanical Separation "Mist Collector" Tool Life Display Remote Diagnostics Signal Lamp Automatic Door For Loading W/Shuttle Load and Unload Shuttle Swivel Loader Automation Cell Tuned for Part Pallet Conveyor For 20 Raw And Finished Parts Pallets Pallets Designed for Part 596500 Handling System SPC Station (Maximum O 270 mm, Maximum H 150 mm, Maximum Wt. 12 kg) NIO Station (Closing forward leading gravity) Skiving Software (Hardware: Software and user surfaces for skiving technology) Measuring Probe (For measuring diameters and length of the workpiece in the machine) Measuring Software for Teeth Measuring (MDK and Flank Line, Software and User) Measuring Program (Automatically measuring program for measure the position of the two gears to each other, after using sister tools) SPC (Every X workpieces the MDK needs to be measured) Tool Changer (Precut, measurer and final cut) Skiving Tool Identification (Hardware, software for the identification of the skiving tool after tool change) Hydraulic Diagrams Coolant Diagrams Lubrication Diagrams Electrical Wiring Diagrams Hardcopy of Diagrams CF Certificates Specifications: Lhedpfjy Tybnex Akuog Workpiece Spindle: -Speed: 0-7000 l/min -Power: 55,2 - 59,7 kW Tool: Capco C6 Tool Spindle: -Speed: 0-6000 l/min -Power: 29 - 41 kW Machine Weight, Floor Space and Voltage Supply: -Operating Voltage: 400V, 3 Phases, 50 Hz -Control Voltage: 24 V -Lighting Voltage: 240 V, 50 Hz -Floor Space: 2,700 x 2,600 mm -Height: 4,000 mm -Total Weight, Approximate: 16,000 kg Longitudinal, Z-Axis: -Stroke: 800 mm -Rapid Rate: 24 m/min -Feed Force: 12 kN Transverse, X-Axis: -Stroke: 900 mm -Rapid Rate: 24 m/min -Feed Force: 12 kN Tool Spindle, B-Axis: -Range: -20 / +90 Degree Y-Axis for Spindle Unit: -Stroke: 200 mm -Rapid Rate: 12 m/min -Feed Force: 6 kN C-Axis Main Spindle: -Positioning Accurace: 9" Multifunctional Tool Carrier: -Power: 29 kW at 100% ED -Power: 41 kW at 44% ED -Torque: 141 Nm at 100% ED -Torque: 212 Nm at 44% ED -Spindle Speed: 0-6000 min-1 -B-Axis for Stepless Motion in a Range Of: -20/+90 Degree Tool Magazine: -Maximum Tool Diameter: 100 mm -Approximate Tool Length: 300 mm -Approximate Tool Weight: 12 kg Swivel Loader: -Maximum Workpiece Diameter: 270 mm -Height: 150 mm -Weight: 16 kg

Condition: used, Year of construction: 2007, Citizen M32-V Mfd. 2007 Hours: 99,608 High Pressure Mist Collector Chip Conveyor Long work piece attachment Ledpeyzkb Ujfx Akuehg No tooling 338 Edge Patriot Loader (Accepts 8ft Bars) Machine came out of an Aerospace Company in Michigan.

Condition: excellent (used), Year of construction: 2022, Swiss CNC Chucker-Convertible Sliding Headstock Lathe W/ "B" Axis Lhedpfxoyq S Ute Akuog

Condition: excellent (used), Year of construction: 2019, operating hours: 13,000 h, functionality: fully functional, bar diameter (max.): 22 mm, INDEX MS22-8 Mfd. 2019 Lhjdpfx Akox H H Nrousg 2 NCU 2 Syncrons 2 Y-Axis Control: Siemens Solution Line Knoll System Bar Feed: IEMCA SIR rack loader (12-ft) 22,000 on-hours 10,000-15,000 Hours

Condition: excellent (used), Year of construction: 2019, machine/vehicle number: 14974, Tornos MultiSwiss 6x16  CNC Multi-Spindle Screw Machine Mfd. 2019 Lsdpsv S H Uyjfx Akushg 6 Motorspindles  5,5 kW max. speed 8’000 RPM Spindle capacity 16 mm, Z 50mm stroke (max. parts 40mm). 6 slides X 40mm stroke 1 counter-operation slide, 75mm stroke. Counter spindle with integrated motor 6 kW Max. speed 8’000 RPM, 150mm stroke. Numeric control Fanuc 30i Integrated PC with screen 17” Programming system TB DECO (DCS version) (requires 3003) contact us for more details

Condition: good (used), Year of construction: 2019, machine/vehicle number: 25728, Equipped with: Hydraulic Unit Sinumerik 840D sl CNC Control Slim Line Operator Panel OP012 W/12 TFT-Color Display 19" Machine Control Panel 20 Tool ATC CAPTO C6 Multifunctional Tool Carrier For Turning and Driven Tools One Fixed Tool Unit Assembled To The Compound Slide W/Coolant Thru The Turning And Drilling Tools, Coolant For The Driven Spindle From The Outside Drilling Spindle Additional Drill Spindle For Orientation Chip Conveyor Coolant Equipment -Including piping and shut-off valve and flow control switch -To supply coolant to tools for coolant and flushing through the cutting tools -To supply coolant for flushing the work piece and chuck -To supply coolant for flushing the working area Paper Band Filter Immersion Cooler High Pressure Coolant Pump, 40 Bar Through Tools Flushing Pistol, Hand Held Air Cleaner - Mechanical Separation "Mist Collector" Tool Life Display Remote Diagnostics Signal Lamp Automatic Door For Loading W/Shuttle Load and Unload Shuttle Swivel Loader Automation Cell Tuned for Part Pallet Conveyor For 20 Raw And Finished Parts Pallets Pallets Designed for Part 596500 Handling System SPC Station (Maximum O 270 mm, Maximum H 150 mm, Maximum Wt. 12 kg) NIO Station (Closing forward leading gravity) Skiving Software (Hardware: Software and user surfaces for skiving technology) Measuring Probe (For measuring diameters and length of the workpiece in the machine) Measuring Software for Teeth Measuring (MDK and Flank Line, Software and User) Measuring Program (Automatically measuring program for measure the position of the two gears to each other, after using sister tools) SPC (Every X workpieces the MDK needs to be measured) Tool Changer (Precut, measurer and final cut) Skiving Tool Identification (Hardware, software for the identification of the skiving tool after tool change) Hydraulic Diagrams Coolant Diagrams Lubrication Diagrams Electrical Wiring Diagrams Hardcopy of Diagrams CF Certificates Specifications: Workpiece Spindle: -Speed: 0-7000 l/min Lhodpfx Akew Iqumouog -Power: 55,2 - 59,7 kW Tool: Capco C6 Tool Spindle: -Speed: 0-6000 l/min -Power: 29 - 41 kW Machine Weight, Floor Space and Voltage Supply: -Operating Voltage: 400V, 3 Phases, 50 Hz -Control Voltage: 24 V -Lighting Voltage: 240 V, 50 Hz -Floor Space: 2,700 x 2,600 mm -Height: 4,000 mm -Total Weight, Approximate: 16,000 kg Longitudinal, Z-Axis: -Stroke: 800 mm -Rapid Rate: 24 m/min -Feed Force: 12 kN Transverse, X-Axis: -Stroke: 900 mm -Rapid Rate: 24 m/min -Feed Force: 12 kN Tool Spindle, B-Axis: -Range: -20 / +90 Degree Y-Axis for Spindle Unit: -Stroke: 200 mm -Rapid Rate: 12 m/min -Feed Force: 6 kN C-Axis Main Spindle: -Positioning Accurace: 9" Multifunctional Tool Carrier: -Power: 29 kW at 100% ED -Power: 41 kW at 44% ED -Torque: 141 Nm at 100% ED -Torque: 212 Nm at 44% ED -Spindle Speed: 0-6000 min-1 -B-Axis for Stepless Motion in a Range Of: -20/+90 Degree Tool Magazine: -Maximum Tool Diameter: 100 mm -Approximate Tool Length: 300 mm -Approximate Tool Weight: 12 kg Swivel Loader: -Maximum Workpiece Diameter: 270 mm -Height: 150 mm -Weight: 16 kg

Condition: good (used), Year of construction: 2008, functionality: fully functional, machine/vehicle number: 185273, turning diameter: 610 mm, spindle motor power: 26,000 W, spindle speed (min.): 35 rpm, spindle speed (max.): 4,000 rpm, spindle bore: 88 mm, travel distance X-axis: 740 mm, travel distance Y-axis: 410 mm, travel distance Z-axis: 1,838 mm, rotational speed (max.): 12,000 rpm, rotational speed (min.): 15 rpm, overall weight: 17,600 kg, Mazak Integrex E410H-II 2008mod Mazatrol Matrix Lhedpfx Akjy T Hxgoujg
