Used Cnc Lathe With Barfeeder Und C Axis for sale (67,860)

Condition: excellent (used), Year of construction: 2012, Manufacturer: HAAS Automation Inc., USA Model: ST-20 Year of Manufacture: 07/2012 Serial Number: 3092643 CNC Control: HAAS CNC Control Machine Type: CNC Turning Center Country of Origin: USA CE Marked: Yes Technical Specifications Specification Value Max. Turning Diameter 381 mm Max. Turning Length 533 mm Max. Swing Over Bed 806 mm Max. Swing Over Cross Slide 527 mm Chuck Size 210 mm (8.3") Bar Capacity 51 mm Gkedpoz R A S Tofx Afuoc Spindle Speed 4,000 rpm Spindle Motor Power 14.9 kW (20 HP) Spindle Nose A2-6 Spindle Bore Approx. 64 mm X-Axis Travel 236 mm Z-Axis Travel 533 mm Turret Capacity 12 Stations Rapid Traverse X-Axis 24 m/min Rapid Traverse Z-Axis 24 m/min Electrical Specifications Specification Value Voltage 360–480 V Phase 3-Phase Frequency 50/60 Hz Full Load Current 20 A Largest Load 35 A Short Circuit Interrupting Capacity 10,000 A

Condition: ready for operation (used), NIKKEN 5 AX -170 CNC / Rotary Table incl. Controllers Gedpfxozqg I He Afujkc -TYPE 5-axis -AX 170 CNC / Rotary Table -The NIKKEN / 5 AX -170 is a compact and robust CNC swivel table for precise drilling and milling operations in 4- and 5-axis machining. -Complete documentation available. -Well-maintained overall condition. Overall dimensions: L x W x H 780x340x280mm Errors and omissions excepted.

Condition: excellent (used), Year of construction: 1999, • FANUC 210i - T control (cycles) • Max. distance between centers: 1,250 mm • Max. turning diameter: 400 / 585 mm in offset • Spindle speed: 12 . . . 2,500 rpm • Spindle bore: 54 mm • X-axis: 210 mm • Z-axis: 1,181 mm • Cutting gap adjustment: 0.05 – 0.8 mm • Motor power: 7.5 kW Gjdpfew S E R Rex Afuokc • Weight: approx. 2,700 kg

Condition: used, Year of construction: 2005, Geminis GHT4 - 720 x 2000 CNC Centre Lathe with Fanuc Series 21iTB CNC Control, Distance between Centres 2000mm, Swing Over Bed 720mm, Swing Over Cross Slide 470mm, Spindle Bore Diameter 104mm, Spindle Speeds to 1600rpm. Max Workspiece Weight Between Centres 2560kg, Tailstock with 6MT, Main Motor Power 20.5kw, Fixed Steady, Swarf Conveyor, Various Tool Post Holdwers. S/No. 12029 (2005) Machine Size 2600mm x 2385mm x 1765mm, Weight 4100kg Location: This lot is located in Scotland, UK. A charge of £800 for dismantling and loading onto suitable transport will be automatically added to your invoice should you be successful in purchasing this item. Blocking and securing will be at the cost of the purchaser. Gksdpfxjz Rnxlo Afusc

Condition: excellent (used), Year of construction: 2018, functionality: fully functional, machine/vehicle number: XD-16III-CP-0073-H, spindle bore: 18 mm, spindle speed (min.): 10 rpm, spindle speed (max.): 1,500 rpm, type of input current: three-phase, overall weight: 2,200 kg, rotational speed (min.): 10 rpm, Equipment: documentation/manual, Hanwha XD16 III Gedpfszxhwrox Afuskc Few operating hours Barloader BMG-20 Chip conveyor with trolley and collector Fanuc control Bar diameter modified to Ø18mm

Year of construction: 1995, condition: excellent (used), Sliding headstock The machine is in very good condition Technical data in the last photo Gedpjgv U R Tefx Afujkc

Condition: new, Year of construction: 2025, functionality: fully functional, With a grinding diameter of 200mm x 300mm long, the JHP-2003CNC is the most compact plunge type grinding machine in the range and utilises the FANUC Oi-TF CNC control. Designed for heavier grinding applications, the JHP-2003CNC can accomadate workholding and components to 80kgs. This fully enclosed machine is supplied with Renishaw probing, full machine enclosure and mist collector. Jainnher CNC Plunge Cylindrical Grinding Machine Godenxk N Sjpfx Afujkc Description: JHP-2003 CNC Capacity Max ø work swing 200mm dia Max grinding length 300mm Max grinding dia. 200mm dia Max workpiece weight 80 kgs Distance between centres 300mm Centre height 100mm Grinding wheel Grinding wheel size Ø405 x 50 x 127 Max peripheral 33 m/sec Wheel speed 1780rpm Wheel head Feed angle 90 Swivel angle ±0 Rapid traverse speed 6m/min Max. travel 220mm Min. setting unit 0.0001mm Grinding feed rate 0.001~6000m/min Hydrodynamic pressure ----- Tailstock Retraction of sleeve 30mm Sleeve diameter D:48mm Centre taper MT.3 Hydraulic cylinder pressure 20kg Work head Spindle speed (variable) 10~500rpm/min Centre taper MT3 Spindle type Cartridge type Swivel angle 120 (90ºCCW;30ºCW) Work- table Min. setting unit 0.0001mm Swivel angle CCW/CW +10º/-3º Rapid traverse speed 8mm/min Max. travel 640mm Motor Grinding feed rate 0.001~6000mm/min Grinding wheel motor 5HP 4P(opt. 7.5HP) 4P Workhead motor 1.0KW Work table (Z axis) 1.2KW Work table (X axis) 1.2KW Hydraulic pump 1/4 HP 4P Wheel head pump ----- Coolant pump 1/8 HP 2P Magnetic coolant separator 1/25HP 2P Oil cooler ----- Oil tank Hyd. oil tank(slideways, screw ends & measurement) 30L Wheel head lubrication ----- Coolant tank 80L Machine N.W (Fully enclosed) 3800 kg G.W (Fully enclosed) 4100 kg Dimension (Fully enclosed) 3300 x 2100 x 2200mm Packing (Fully enclosed) 3500 x 2200 x 2200mm Jainnher CNC Plunge Cylindrical Grinding Machine Standard Accessories: JAINNHER JHP-2003CNC X-axis linear scale Work lamp Foot pedal Angle adjustment gauge Hydraulic tailstock with manual movement Grinding wheel and flange Tungsten carbide tipped centres (MT3) Automatic lubrication system Diamond dresser at lower worktable Magnetic separator MC-40/coolant tank/pump Levelling bolts and blocks Tool kits and toolbox Fully enclosed splash guard & oil mist device Touch probe gauge (Renishaw) Transformer

Condition: used, Year of construction: 1988, functionality: unexamined, machine/vehicle number: 0210.07382, turning length: 1,000 mm, turning diameter: 350 mm, spindle speed (max.): 3,000 rpm, chuck outer diameter: 315 mm, The Okuma LB 25 is a used CNC inclined-bed lathe, manufactured in 1988, equipped with an Okuma OSP 5020 control. According to the documentation we have, it can handle workpieces up to 1,000 mm in length and has an integrated Okuma Touch Setter. The machine comes with a chip conveyor and oil mist extraction system. It is located in the Düsseldorf area, along with an Okuma LB 15 from 1987. TECHNICAL DATA - Year of manufacture: 1988 Gkedsz H Ugyopfx Afuoc - Control: Okuma OSP 5020 - Turning length: 1,000 mm - Turning diameter according to documentation: 350 mm (please verify on the nameplate before purchase) - Chuck diameter according to documentation: 315 mm - Spindle speed max.: 3,000 rpm - Measuring device: Okuma Touch Setter (integrated) EQUIPMENT AND ACCESSORIES - Chip conveyor Knoll 320 S-1 with coolant cleaning - Extraction system Filtermist F21/8 - Tool turret with holders (as shown in the photos) - Turning and clamping tools CONDITION During our inspection on October 1, 2026, the machine was not in operation. We are therefore selling it as untested, in its current condition. We recommend an on-site inspection. AREAS OF APPLICATION For shafts and turned parts up to 1 m in length, suitable for maintenance and contract manufacturing. LOCATION AND PROCEDURE The machine is located in the Düsseldorf area. Inspection is possible by appointment. Disassembly, loading, and transport are organized by the buyer. Upon request, we can provide contact information for freight forwarders in the region. Price upon request. Please contact us via the contact form.

Year of construction: 2009, condition: used, X-axis travel: 360mm, Z-axis travel: 980/1580mm, rapid traverse X/Z: 15/24m/min, max. turning diameter: approx. 500mm, max. swing diameter: 800mm, spindle nose: A11, bar capacity: 110mm, power (100%/40%): 22/33kW, torque gear stage 1: 175/263Nm, torque gear stage 2: 700/1,050Nm, turret type: servo turret, tool stations: 12, tool holder: VDI 50, number of driven tools: 12, driven tool speed: 4,000rpm, power (100%/40%): 5/9.6kW, axial torque (100%/40%): 18/35Nm, radial torque (100%/40%): 15/28.8Nm, hydraulic tank: 11l, central lubrication reservoir: approx. 2-3l, mains connection: 3/PE~ 400V, frequency: 50/60Hz, operating current (I_B): 63A, rated current (I_N): 80A, length: 3,250mm, width: 1,980mm, height: 2,090mm, weight: 8.5t, operating hours: 27,271h, including Spinner SERVO-LOAD 110 1500 bar feeder and documentation. On-site inspection is possible. Gedpfxjz R A I Us Afuokc

Condition: used, Year of construction: 1987, Technical details: turning diameter over bed: 180 mm turning length: 490 mm swing diameter: 450 mm cross travel: Z-Weg: 168 mm control: Traub TX8D revolution per minute: 20 - 4000 U/min spindle passage: Ø 60 mm operating hours - idle run: 23.495 h tool turret: 12 tools Gjdpfx Afsu Ix N Seuskc total power requirement: 38 kW Weight approx.: 4,2 t dimension machine xH: 3,6 x 2,5 x 2,2 m Tool holder straight shank DIN 69880 (VDI 3425) Ø 40x63 Röhm lathe chuck Ø 200mm hydraulic clamping Operation via double foot switch and control panel/operating panel. Coolant device The Traub carries an integrated chip conveyor with an ejection height of 1,100mm (currently without function). Accessories: multiple small parts 8 x machine feet without tailstock i.D. *

Condition: good (used), Year of construction: 2012, CNC turning/milling center Spinner Type/Model TC 600 52 Control Siemens Sinumerik 840D sl; with SHOPTURN Condition Used Year of manufacture 2012 Technical data Max. swing diameter 600 mm Max. turning diameter 400 mm Max. turning length 650 mm Travel X/Y 275 mm / 700 mm Max. rapid traverse X/Z 15 / 24 Turning spindle Max. speed 5,000 rpm Chuck size 210 mm Spindle power 18 kW Max. torque 113 Nm Spindle nose A6 Max. bar diameter 52 mm Turret Tool positions 16 Gjdsz H If Njpfx Afuekc Tool holder VDI 30 / DIN 69880 Tailstock taper MT 4 Machine dimensions (L x W x H) approx. 2500 x 1600 x 2000 mm Machine weight approx. approx. 5,000 kg Equipment / Features Tool measuring arm Power chuck SMW Autoblok BH-D 210-52-3-A06 including jaw sets Chip conveyor TC600 Enlarged, L-shaped coolant tank, approx. 180 liters with centrifugal pump 50 l/min; 3.3 bar Foot switch for CNC tailstock Inquiry item: Transportation costs in a separate quote.

Condition: good (used), Year of construction: 2014, 900mm Swing, 650mm max. machining diameter, 992 mm maximum turning length, 1000rpm spindle, Spindle bore 275mm, 10 station turret 45kW spindle motor, Godjz D Axfepfx Afuekc FANUC Series 32i control, 24” 3 Jaw manual Chuck, Tailstock, Swarf Conveyor, Coolant,

Condition: excellent (used), Year of construction: 2002, functionality: fully functional, turning diameter over cross slide: 365 mm, spindle bore: 105 mm, turning length: 1,500 mm, turning diameter over bed slide: 600 mm, swing diameter over cross slide: 365 mm, quill diameter: 68 mm, spindle speed (max.): 2,200 rpm, feed rate X-axis: 10 m/min, feed rate Z-axis: 12 m/min, travel distance X-axis: 310 mm, travel distance Z-axis: 1,500 mm, spindle diameter: 250 mm, workpiece diameter between centers: 365 mm, distance between centers: 1,500 mm, CNC ECS 2400 Center height above the bed: 300 mm Spindle nose: CAM LOCK 8" Spindle bore diameter: 105 mm Spindle motor power – S1/S6: 9/13 kW Spindle speed ranges: 2 with automatic change Maximum spindle speed: 2200 rpm Spindle speed at constant power: 75/2200 rpm Spindle speed at constant power (I range): 10 + 75/430 rpm Gksdpsz Ig T Ijfx Afusc Spindle speed at constant power (II range): 40 + 380/2200 rpm Maximum spindle torque: 1650 Nm Maximum diameter on the bed: 600 mm Maximum diameter on the carriage: 365 mm Nominal distance between centers: 1,500 mm Controlled travel of axis "X": 310 mm Controlled travel of axis "Z": 1,500 mm Rapid traverse rate of axis "X": 10,000 mm/min Rapid traverse rate of axis "Z": 12,000 mm/min Continuous feed force of axis "X": 300 daN Continuous feed force of axis "Z": 1000 daN Tailstock bore diameter: 68 mm Tailstock travel: 220 mm Axial thrust of the tailstock: 1,200 daN Supply voltage: 400 V (50 Hz) Total installed power: 20 kW Machine complete with: • Self-centering chuck, Pinto, diameter 250, 3+3 jaws • Electric tool turret, 8 positions • Fixed steady rest • Operation and maintenance manuals • CE declaration of conformity

Condition: ready for operation (used), Year of construction: 2008, functionality: fully functional, turning length: 1,750 mm, spindle bore: 104 mm, spindle speed (max.): 1,800 rpm, type of input current: three-phase, Model:Prototurn 555 Swing Over Bed:560mm Distance Between Centres:1750mm Control: Prototrak SLX Gkedpfxszrnkrs Afuec Spindle Speeds: To 1800 RPM Spindle Bore:104mm With: 300mm 3 Jaw Chuck Fixed Roller Steady Quick Change Toolpost Toolpost Holders Dimensions: 3940 x 2250 x 1910mm high Weight: 4100 Kgs

Condition: used, machine/vehicle number: 008739, X axis working area: 6000 mm Y axis working area: 1400 mm Working Table: Pod and Rail Gsdpfx Aez N Swisfuokc Main Electrospindle power: 12 KW Number of controlled axes: 5 axes Total number of drilling spindles: 16 Total number of tool changer positions: 14

Condition: used, Year of construction: 1995, overall weight: 5,500 kg, center distance: 650 mm swing over bed: 520 mm Gkedpfez Eaiqsx Afusc bar capacity: 78 mm tool turret: 10 tools maximum spindle speed: 3500 rpm weight: 5500 kg

Condition: used, Year of construction: 1999, functionality: fully functional, Equipment: documentation/manual, Cincinnati Hawk machining center 2 axes: X and Z CNC: GE Fanuc Series 21i-T Year: 1999 Gedez I Tf Djpfx Afuskc Chip conveyor: included Documentation: included Video available Inspection possible

Condition: used, Year of construction: 2013, Brand : GEMINIS Model : GT5 G2 1200x1000 Manufacture year : 2013 Cnc : SIEMENS 840D-SL Center height: 615 mm Godpfx Afszn Axijuokc Swing over cross slide: 850 mm Swing over bed : 1200 mm Main spindle bore diameter: 104 mm Main spindle nose: DIN 55026-11 mm Spindle diameter on front bearing:150 mm Turning Speeds : 0-1400 rpm Spindle Ranges: 4 Headstock power: (S1/S6-60%) 30/37kw – (37/46kw Optional) Headstock torque: (S1/S6-60%) 4000/4850 Nm (4800/5950Nm) Guide width: 655 mm Height up to the plane guide: 800 mm

Condition: new, Year of construction: 2027, functionality: fully functional, turning diameter: 51 mm, This machine is a new lathe. STANDARD EQUIPMENT Main spindle 15 KW, 4,000 RPM with Mitsubishi M830 control Gkjdpfx Aeug Up Nsfujc with 4 cross slides on the main spindle with an 8-position servo turret VDI30x55 all stations can be used for rotary tools central milling drive 3.3 KW, 3000 RPM including stable multi-tool function (without tool holder) with full C-axis on the left spindle and on the sub-spindle with 48-position spindle locking as support for milling including sub-spindle with workpiece collection tray and finished part conveyor for falling cut-off parts or scrap pieces with swiveling finished part conveyor for finished part discharge after back-end machining 4 tool holders for the back end with programmable high-pressure coolant for cleaning clamping devices before the next workpiece is loaded with HD coolant pumps, 70 bar with separate coolant tank (300 liters) with handwheel coolant and hydraulic pumps bar feeder interface interface for Lico chip conveyor 1 set of slide base holders automatic lubrication system cutting force monitoring on all stations control cabinet with air conditioning unit 3-way signal lamp in addition, the machine is equipped with a turret for back-end machining. This turret is designed for solid tools only. BASIC MACHINE EQUIPMENT Interface for Lico/FMB bar feeder Programming support for Lico machines Color Door RAL 7015 Slate Gray Chip tray/frame RAL 7024 Graphite Gray Housing RAL 7035 Light Gray

Condition: refurbished (used), Centreless grinding machine GHIRINGHELLI M2200 CNC 5 axes grinding wheel 200x610 CNC FANUC 5 AXIS Variable speed drive on grinding wheel complete overhaul with electric / electronic retrofit Machine in our warehouse in Gussago BS Mimu machine tools (Italy) Centreless grinding is a procedure for grinding cylindrical bodies and is used for mass production of rollers Gkjdpowq Dn Tjfx Afusc cylindrical, conical rollers, jet needles, pump pistons, hydraulic sliders, crosses, drills etc. During centerless plunge grinding, the workpiece is ground in one pass thanks to the translation of the grinding wheel. For this purpose, the grinding wheels and the adjustment discs have a negative profile of the piece to work which is given to them with the aid of a tool. The through-feed grinding or also through grinding and longitudinal grinding: pieces to be worked proceed uninterruptedly with axial feed through the rectification gap. Grinding wheel width: 200 Grinding wheel diameter: 610 CNC: 4 axes

Condition: good (used), Year of construction: 2010, Ref. -No.: 10287 Manufacturer: DMG Type: DMC 210 FD Year of construction: 2010 Type of control: CNC-Steuerung Control: Heidenhain Mill Plus Storage location: Halberstadt Country of origin: Deutschland X-Travel: 2100 mm Y-Travel: 2100 mm Z-Travel: 1250 mm Machine length: 11.000 mm Machine width: 5.000 mm Machine Height: 3.500 mm Max. Workpiece diameter: 2500 mm Max. Workpiece Weight: 6.000 kg Max. rotary table diameter: 1.850 O Table speed range: 250 min/-1 Tool Taper: HSK-A100 Tool Piece Magazine With: 183 Pcs./pcs. Spindle Speed: 12.000 RPM Max. Torque On The Boring Spindle: 288 Nm Max. Torque: 2.000 Nm Feed Speeds X/Y/Z Axis: 30.000 mm / min Max. Workpiece height: 1.460 mm axes: 5 Further information: Turning and milling center incl. pallet changing system Gear spindle Coolant treatment system, with belt filter, 710 x 50mm 1 Knoll 600S2 chip conveyor 2 Losma oil mist extraction units 1 steel platform (storage space for clamping device): 5,300 x 2,900 mm - Axes renewed 11.2024 - New encoder, electrical components renewed - Geometry protocols available Gkodpszkpupsfx Afusc Machine is still in production and under power. The machine can be viewed at any time by appointment.

Condition: good (used), Year of construction: 2001, Max. machining diameter from bar mm 65 Max. machining diameter from take-up mm 250 Max. machining length mm 500 Max. rotating diameter mm 520 CNC Fanuc 18i-T Iemca Master 800 MP loader Gksdpfx Aem Hauaofuec counter spindle chip conveyor tool setter

Condition: used, Year of construction: 1996, X-axis: 500mm, Y-axis: 380mm, Z-axis: 380mm, B-axis: 180°, C-axis: 360°, max. spindle speed: 15,000rpm, feed and rapid traverse: 30m/min, tool changer: 24-position, tool holder: SK40, control: Deckel Maho MillPlus, spindle operating hours: 7,000h, the original screen is defective, therefore a separate monitor is used, replacement spindle has 7,000h, spindle module and E/R module replaced in 2023, C-axis table bearing repaired in 2023, Z-axis guideways repaired in 2024, hard drive replaced in 2024, without clamping systems or tools, an on-site inspection is possible. Gkodpfxsz Ea Rno Afujc

Condition: good (used), Year of construction: 2003, functionality: fully functional, machine/vehicle number: 12020, Fanuc 21i TB control 3 jaw SMW chuck 720mm swing 2000mm between centres Gjdpfx Aozaix Isfuokc 8 station turret Coolant pump and tank Swarf conveyor

Condition: good (used), Year of construction: 1999, Ref. -No.: 10443 Manufacturer: VDF BOEHRINGER Gsdpfx Ajy Ed Ddjfuokc Type: 16 M - G Year of construction: 1999 Type of control: CNC Control: REXROTH INDRAMAT SYSTEM 200 BTV 30 Storage location: Halberstadt Country of origin: Germany Turning Diameter: 520 mm Turning Diameter Over Slide Rest: 150 mm Spindle Speeds: 25 - 4.500 RPM Spindle Bore: 78 mm Tool Taper: VDI 40 Rapid Traverse: 15.000 mm / min Distance Between Centres: 1110 mm Spindle motor drive: 18 kW Turret places: 12 Pcs Machine length: 5000 mm Machine width: 2800 mm Machine Height: 3200 mm Weight Of The Machine Ca.: 14,5 t Further information: 2x revolver (12 places) Machine can be inspected under power by appointment.
