Used Multi-Spindle Head 14 Drill Bits for sale (31,524)

Condition: excellent (used), Year of construction: 2019, operating hours: 16,917 h, functionality: fully functional, machine/vehicle number: 11010081, bar diameter (max.): 22 mm, turning diameter: 22 mm, bar length: 3,000 mm, Equipment: documentation/manual, Year of manufacture: 2019 Operating hours: 16,917 h Control unit: C200 Solution Line, control panel with flat-screen monitor (47 cm diagonal) Maximum: 10 channels / 31 axes Based on SINUMERIK 840D sl Equipment: NC option synchronous spindle / polygon turning incl. electronic shaft Slide unit 1.1 (X-axis and Z-axis CNC-controlled) Slide unit 2.2 (X-axis and Z-axis CNC-controlled) Slide unit 3.1 (X-axis and Z-axis CNC-controlled) Slide unit 4.2 (X-axis and Z-axis CNC-controlled) Ppodpfx Aoyxnnaeg Der Slide unit 5.1 (X-axis and Z-axis CNC-controlled) Slide unit 6.1 (Z-axis CNC-controlled) – synchronisation module Slide unit 6.2 (X-axis and Z-axis CNC-controlled) – back-working unit at position 6.2 Main spindle max. clamping diameter 22 mm Parts discharge via chute from spindle position 6 to the right Conveyor belt outside the machine including coolant return Bar feeder: IEMCA SIR MS22, integrated loading magazine Flat loader, 50 Hz D9-13-19-26 Bar length 3300 mm Material storage 200 mm support surface Additional storage chain for 20 bars Profibus-DP slave interface Cooling unit: Cooling capacity 29 kW at 38°C room temperature Coolant R407c Chip conveyor: Hinged belt chip conveyor, 570 mm discharge height, left discharge, with lift pump for filtration system Chip trolley, fill volume 100 l Fire extinguishing unit: CO2 fire extinguishing system with optical fire detection, CO2 extinguishing tank with control unit Prepared for connection to a central oil mist extraction system Shut-off damper for central oil mist extraction system Electrics: Teleservice via VPN connection Chip breaking cycle "ChipMaster" Transport, dismantling, and collection are to be organized by the buyer.

Condition: used, TORNOS MULTIDECO 20/6b is a CNC Multi-spindle turning lathe engineered for high-precision machining with excellent accuracy and reliability. Key capacities: 17 axes total, 6 cross slides, 5 plain turning slides, longitudinal carriage way 160 mm, 6 spindles + 1 back spindle, round bar capacity Ø 5–20 mm, max workpiece length 100 mm, production rate 45 pcs/min. Technical specs: stepless spindle speeds up to 5000 rpm, spindle power 15 kW, total installed power 43 kVA, supply 3x 400 V 50 Hz, machine weight ≈8500 kg, dimensions L3500×W1600×H1950 mm. Equipment: ROBOBAR bar feeder type MSF 522/6, coolant system, chip conveyor, pick-up spindle, spindle stop device, lamp and status light. Delivers tight tolerances; suitable for automotive, watchmaking, toolmaking, aerospace and medical industries. Ppedpfjyxny Aox Ag Dor

Condition: used, Year of construction: 1987, Technical details: number of spindles: 8 spindle passage: 51 mm Article: multi spindle automatic lathe Manufacturer: Schütte Type: AF51 Yob: 1987 eight main spindles max. bar diameter D=51mm control SIEMENS SIMATIC S5 pick up in pos. 7, for rear machining thread cutting drive independent feed in positions 2/3 electronical trip dog control “Balluff” clear text display Wöhrle coolant pump Ppedpjiay Sfefx Ag Djr magnetic cartridge filter oil running incl. bar loader IEMCA PRA 40/37/F, yob 1987, (bundle type) Painting in light blue and light grey The configuration of tooling will be different like pictures. Please, contact us for getting more information and pictures on mail(at) or *

Condition: used, Year of construction: 1991, Technical details: number of spindles: 6 spindle passage: 51 mm Schutte SF51 DNT, yob. 1987, our ID #61868 Article: cam-controlled multi-spindle automatic lathe Manufacturer: Schütte Type: SF51 DNT Yob: 1987 Six-spindle automatic lathe with 6 main spindles max. nominal diameter D=51mm electronic cam control Balluff gripper in position 6 for backworking, sorting chute independent longitudinal feed layer 5 screw chip conveyor Tapping couplings Interface for: Bar feeder IEMCA PRA Bar feeder IEMCA PRA40/33/F Scope of delivery without the blue chip conveyor The tooling will differ from the scope of delivery! Please, contact us for getting more information and pictures on mail(at) or Pjdpjl Rmqpjfx Ag Dspr *

Condition: used, Year of construction: 1994, Technical details: number of spindles: 8 Ppedpfsl Su Rxex Ag Dor spindle passage: 32 mm Article: cam-controlled multi-spindle automatic lathe Manufacturer: Schütte Type: AF32 S DNT Yob: 1994 Eight-spindle automatic lathe with 8 main spindles max. nominal diameter D=32mm control: Siemens SIMATIC S7 electronic cam control Balluff gripper in position 8 for backworking CNC cross slide position 6 CNC cross slide position 7 Workpiece belt Coolant cooling Schimpke Chip conveyor with magnetic separator Tapping couplings The tooling shown may differ from the scope of delivery! Please, contact us for getting more information and pictures on mail(at) or *

Condition: used, Year of construction: 1993, Technical details: number of spindles: 8 spindle passage: 32 mm Article: cam-controlled multi-spindle automatic lathe Manufacturer: Schütte Type: AF32 Dnt Yob: 1993 eight-spindle automatic lathe eight main spindles for bars up to D=32mm Modernized control: Siemens Sinumerik Pedergt E Rspfx Ag Depr Motors: renewed modern motors suitable for modernized control system Electronic trip dog control: Balluff CNC cross slide position 5 cross CNC cross slide position 6 cross Preparation for gripper in position 8 (gripper optional) Independent feeds Thread cutting couplings integrated bar loader: Pietro CUCCHI; type: rack type magazine The scope of delivery regarding the tooling equipment could be different like pictures. *

Condition: used, Year of construction: 2002, Technical details: number of spindles: 8 spindle passage: 20 mm Article: cam-controlled multi-spindle automatic lathe Manufacturer: Schütte Type: AG20 Yob: 2002 eight-spindle automatic lathe Ppodpswutgasfx Ag Djr 8 main spindles for bars up to D=20mm control: Siemens 840D 1x polygonal turning/thread milling device (new 2011) 1x polygonal turning/thread milling device for long turning (new 2011) 1x thread cutting/quick drilling spindle (new 2011) 1x pick-up device incl. various pick-up collets 4 cnc-cross slides Double cross slide in position 7 Loading magazine PRA 52/P type 33 (bar length 3m), year 2004 High-pressure system Knoll SF 2000/Turbo-3 up to 100 bar, year 2004 Tool monitoring Brankamp Air conditioning unit Rittal in the front switch cabinet incl. spare parts package with various collets, cams and various tool holders for longitudinal and cross slides The machine has been run with oil and has processed brass Please, contact us for getting more information and pictures on mail(at) or *

Condition: used, Year of construction: 1992, SCHÜTTE SF 26 DNT Max. bar diameter round / square: 26 / 19 mm Spindle pitch circle diameter: 270 mm Bar feed: 125 mm Longitudinal slide travel (total / work): 80 / 63 mm Cross slide travel (total / work): Upper: 40 / 25 mm Middle: 40 / 25 mm Lower: 50 / 31 mm Ppodpsyxcvxofx Ag Dsr Spindle speeds (stepless): 530 – 3,750 rpm Main times (stepless): min. / max. 0.72 – 100 s Secondary times: 0.90 – 1.1 s Creep speed: 3 rpm Main drive: 22 kW Dimensions (incl. bar guidance): approx. L x W approx. 7.2 x 1.6 m Weight: approx. 6.8 t Voltage: 400 V / 50 Hz Scope of delivery: Machine SCHÜTTE SF 26 DNT bar feeder

Condition: used, Year of construction: 1988, SCHÜTTE SF 32 Maximum bar diameter round / square: 32 / 22 mm Spindle circle diameter: 300 mm Bar feed: 125 mm Longitudinal travel (total / working): 100 / 80 mm Cross slide travel (total / working): Top: 50 / 33 mm Middle: 50 / 30 mm Ppedpsyxcuuefx Ag Dor Bottom: 60 / 37.5 mm Spindle speeds (49 steps): Range I: 450 – 3,150 rpm Range II: 200 – 1,400 rpm Workpiece feed per cycle: Normal: 60 – 425 Short: 33.5 – 236 Long: 95 – 670 Main times (35) per spindle revolution: Min. / Max.: 0.63 – 200 s Normal: 1.12 – 125 s Short: 0.63 – 71 s Long: 1.8 – 200 s Secondary times: 0.7 – 1.25 s Main drive: 18.5 kW Dimensions (incl. bar guide): approx. L x W 6.5 x 1.5 m Weight: approx. 8.3 t Voltage: 400 V / 50 Hz

Condition: used, Year of construction: 1988, SCHÜTTE SF 32 Maximum bar diameter round / square: 32 / 22 mm Pedpfsyxcr Hox Ag Depr Spindle pitch circle diameter: 300 mm Bar feed: 125 mm Longitudinal travel (total / working): 100 / 80 mm Cross-slide travel (total / working): Upper: 50 / 33 mm Center: 50 / 30 mm Lower: 60 / 37.5 mm Spindle speeds (49 steps): Range I: 450 – 3,150 rpm Range II: 200 – 1,400 rpm Workpiece speeds per cycle: Normal: 60 – 425 Short: 33.5 – 236 Long: 95 – 670 Main times (35) per spindle revolution: Min. / Max.: 0.63 – 200 s Normal: 1.12 – 125 s Short: 0.63 – 71 seconds Long: 1.8 – 200 seconds Secondary times: 0.7 – 1.25 seconds Main drive: 18.5 kW Dimensions (incl. bar feeder): approx. L x W 6.5 x 1.5 m Weight: approx. 8.3 t Voltage: 400 V / 50 Hz Scope of supply: SCHÜTTE SF 32 machine Bar loader

Condition: used, Year of construction: 1986, SCHÜTTE SF 32 DNT Maximum bar diameter, round / square: 32 / 22 mm Spindle pitch diameter: 300 mm Bar feed: 125 mm Longitudinal travel (total / working): 100 / 80 mm Cross slide travel (total / working): Upper: 50 / 33 mm Middle: 50 / 30 mm Lower: 60 / 37.5 mm Pedpfjyxcplox Ag Depr Spindle speeds (stepless): 450 – 3,150 rpm Main times (stepless): min. / max. 0.8 – 100 s Secondary times: 1 – 1.25 seconds Creep speed: 3 rpm Main drive: 22 kW Dimensions (incl. bar loader): approx. L x W: 7.3 x 1.6 m Weight: approx. 8.3 t Voltage: 400 V / 50 Hz Scope of supply: SCHÜTTE SF 32 DNT machine Bar loader

Condition: used, Year of construction: 1989, SCHÜTTE SF 32 DNT Max. bar diameter round/square: 32 / 22 mm Pjdpfjyxckcex Ag Depr Spindle circle diameter: 300 mm Bar feed: 125 mm Longitudinal slide travel (total/operational): 100 / 80 mm Cross slide travel (total/operational): - Lateral: 50 / 33 mm - Center: 50 / 30 mm - Lower: 60 / 37.5 mm Spindle speeds (stepless): 450 – 3,150 rpm Main times (stepless): min. / max. 0.8 – 100 s Secondary times: 1 – 1.25 s Creep feed: 3 rpm Main drive: 22 kW Dimensions (incl. bar feeder): approx. L x W 7.3 x 1.6 m Weight: approx. 8.3 t Voltage: 400 V / 50 Hz Contents consist of: SCHÜTTE SF 32 DNT machine Bar loader

Condition: used, Year of construction: 1991, SCHÜTTE SF 42 DNT Maximum bar diameter round / square: 42 / 36 mm Spindle pitch circle diameter: 340 mm Bar feed: 125 mm Longitudinal slide travel (total / working): 125 / 100 mm Cross slide travel (total / working): Ppsdpfxeyxb Ums Ag Djr Top: 60 / 36 mm Middle: 60 / 36 mm Lower: 70 / 44 mm Spindle speeds (stepless): 315 – 2,240 rpm Main times (stepless): min. / max. 0.88 – 125 sec Secondary times: 1.1 – 1.4 seconds Creep speed: 3 rpm Main drive: 22 kW Dimensions (including bar guide): approx. L x W approx. 7.3 x 1.7 m Weight: approx. 10 t Voltage: 400 V / 50 Hz Scope of delivery: SCHÜTTE SF 42 DNT machine Bar loader

Condition: used, Year of construction: 1995, SCHÜTTE SF 26S DNT Maximum bar diameter, round / square: 26 / 19 mm Spindle pitch circle diameter: 270 mm Bar feed: 125 – 290 mm Longitudinal travel of slides (total / working): 125 / 98 mm Cross slide travel (total / working): Top: 40 / 25 mm Middle: 40 / 25 mm Bottom: 50 / 31 mm Spindle speeds (stepless): 530 – 3,750 rpm Pjdpfsyxb Ndox Ag Depr Main times (stepless): min. / max. 0.72 – 100 s Secondary times: 0.90 – 1.1 seconds Creeping speed: 3 rpm Main drive: 22 kW Dimensions (including bar guide): approx. L x W, approx. 7.2 x 1.6 m Weight: approx. 6.8 t Voltage: 400 V / 50 Hz Scope of delivery: SCHÜTTE SF 26S DNT machine Bar feeder

Condition: used, Year of construction: 2000, INDEX MS42C Maximum bar diameter: 42 mm Spindle pitch circle diameter: 320 mm Main spindle: Power clamping with INDEX spring-loaded hollow clamping cylinder and collet Maximum clamping stroke: 4 mm Clamping force: 26 kN Main spindle drive: Rated power: 5 kW Rated speed: 1,500 rpm Rated torque: 32 Nm Maximum speed: 5,000 rpm Synchronous spindle and rotary tool holder: Rated power: 5.3 kW Rated speed: 1,500 rpm Rated torque: 34 Nm Maximum speed: 5,000 rpm Cross slides: Max. number: 10 Travel (X): 70 mm Travel (Z): 140 mm Max. feed force +X: 11.4 kN Max. feed force −X: 7.9 kN Max. feed force +Z: 11.4 kN Max. feed force −Z: 7.9 kN Rapid traverse: 15 m/min Longitudinal spindles: Quantity: 6 Stroke (Z): 240 mm Max. feed force +Z: 15.1 kN Max. feed force −Z: 11.6 kN Rapid traverse: 15 m/min Longitudinal slide units: Max. number: 6 Ppsdpoymc S Uefx Ag Djr Travel (X): 70 mm Max. feed force +X: 11.4 kN Max. feed force −X: 7.9 kN Rapid traverse: 15 m/min Synchronous spindle: Chuck system: spring-loaded clamping cylinder Maximum clamping diameter: 42 mm Chuck outside diameter: 112 mm Jaw stroke: 1 mm Max. total clamping force: 13 kN Weight: approx. 11,000 kg Scope of delivery: KNOLL KTS 32-48-T hydraulic unit CUCCHI PLURIMANDRINO bar feeder, year 2000 Workshop cabinet with machine accessories KNOLL VRF 500 KNOLL 400 S-1/250 chip conveyor

Condition: used, Year of construction: 1994, operating hours: 62,283 h, bar diameter (max.): 26 mm, spindle bore: 230 mm, total width: 1,500 mm, total length: 7,000 mm, total height: 2,000 mm, INDEX MS 25E Maximum bar diameter round / square: 26 / 18 mm Spindle circle diameter: 230 mm Max. bar length: 100 mm Longitudinal slide travel (total / working / adjustment): 85 / 50 / 330 mm Cross slide travel (total / working / adjustment): 36 / 16 / 20 mm Spindle speeds (12 / 24 steps with 1.25 / 1.12): 366 – 5,020 rpm Ppjdpfx Asymdchsg Djr Main drive: 15 kW / 1,450 rpm Voltage: 400 V / 50 Hz Operating hours: 62,283 h Working hours: 4,916 h Dimensions (incl. bar guide): approx. L x W x H 7 x 1.5 x 2 m Weight: approx. 6 t Scope of delivery: INDEX MS 25E machine

Condition: used, Year of construction: 2007, operating hours: 26,721 h, number of spindles: 6, spindle speed (max.): 10,000 rpm, bar diameter (max.): 22 mm, total width: 1,800 mm, total length: 3,200 mm, total height: 2,850 mm, travel distance X-axis: 62 mm, travel distance Y-axis: 12 mm, travel distance Z-axis: 85 mm, rotational speed (min.): 10,000 rpm, overall weight: 6,500 kg, INDEX MS 22C Work Spindles: Quantity: 6 Maximum bar diameter: 22 mm Spindle pitch circle diameter: 230 mm X / Z travel: 62 / 85 mm Rapid traverse: 15 m/min Synchronous hollow spindle drives: Quantity: 6 Maximum speed: 10,000 rpm Nominal speed: 8,300 rpm Power: 15 kW at 18 Nm Chuck diameter: 110 mm Rotating synchronous spindles: Quantity: 2 Z stroke: 120 mm Feed force: 2.5 kN Rapid traverse: 15 m/min Rotational angle: 132° Counter spindle: Maximum speed: 10,000 rpm Nominal speed: 8,000 rpm Psdpfx Agoymaw Io Djpr Power: 9.2 / 12 / 14 kW at 11 Nm Tool carriers: Maximum quantity: 11 X / Y / Z travel: 62 / ±12 / 85 mm CNC control: C 200-4D (Siemens Sinumerik 840D) Dimensions (approx. L x W x H): 3.2 x 1.8 x 2.85 m Weight: approx. 6.5 t Operating hours: 61,997 h Machining hours: 42,235 h Scope of supply: INDEX bar feeder Bar feeder IEMCA SIR MS22 P, year 2008 Coolant unit with belt filter Chip conveyor KNOLL 400 S-1/290 Coolant filtration unit KNOLL FKA/1780 RSF 100 Workshop cabinet with machine accessories

Condition: used, Year of construction: 2002, Technical Details: SCHÜTTE SG 18 Ppodpjymdd Sefx Ag Djr Max. bar diameter round / square: 18 / 13 mm Spindle pitch circle diameter: 180 mm Bar feed: 80 mm Longitudinal slide travel (total / working): 63 / 50 mm Cross slide travel (total / working): 32 / 20 mm Spindle speeds (infinitely variable): 800 – 10,000 rpm Main cycle times (infinitely variable): min./max. 0.24 – 45 s Secondary times: 0.30 s Main drive: 11 kW Feed motor torque: 18 Nm Dimensions (including bar guide): approx. L x W approx. 5.5 x 1.3 m Weight: approx. 5 t Voltage: 400 V / 50 Hz Operating hours: 14,304 h Scope of delivery: - Bar feeder Pra 52 P IEMCA - RUEZ KF0WW2/312 DAS, year 2002

Year of construction: 1985, condition: excellent (used), machine/vehicle number: 2476, for spindle taper: MK 4 Max. Input speed: 1500 rpm Ppodpfxjd R Em Is Ag Djr Diameter up to: 10.2 mm Shank Diameter for quill: Construction height: 500 mm Weight:

Condition: ready for operation (used), Year of construction: 1967, functionality: fully functional, machine/vehicle number: 68-3-2329, spindle speed (max.): 855 rpm, spindle speed (min.): 137 rpm, turning length: 225 mm, disc diameter: 317 mm, No minimum price – guaranteed sale to the highest bidder! Submitting a bid obligates timely collection between 08.04.26 and 16.04.26. TECHNICAL DETAILS Spindle speed range: 137 - 855 rpm Maximum workpiece feed: 260 mm Maximum turning length: 155/225 mm Drive pulley diameter: 317 mm Drive pulley width: 170 mm MACHINE DETAILS Dimensions & Weight Dimensions (L x W x H): 7000 x 2000 x 2500 mm Machine weight: 18 t Operating voltage: 380V Frequency: 50 Hz Rated current: 120 A EQUIPMENT Configured for 6 spindles Ppjdpfx Ajyk A Hteg Djr External reference: 2

Condition: ready for operation (used), Year of construction: 1967, functionality: fully functional, machine/vehicle number: 67-3-2142, spindle speed (max.): 855 rpm, spindle speed (min.): 137 rpm, turning length: 225 mm, overall weight: 18,000 kg, disc diameter: 317 mm, No reserve price – guaranteed sale to the highest bidder! Placing a bid obligates you to timely collection between 08.04.26 and 16.04.26. TECHNICAL DETAILS Spindle speed range: 137 – 855 rpm Pjdsyk Alpjpfx Ag Djpr Maximum workpiece feed: 260 mm Maximum turning length: 155/225 mm Drive pulley diameter: 317 mm Drive pulley width: 170 mm MACHINE DETAILS Operating voltage: 380V Frequency: 50 Hz Rated current: 120 A Dimensions & Weight Dimensions (L x W x H): 7000 x 2000 x 2500 mm Machine weight: 18 t EQUIPMENT Configured for 6 spindles External reference: 1

Condition: ready for operation (used), Professional, heavy-duty version by HANG (German quality) in neat, complete condition. Highly suitable for binderies, printing shops, and print departments. ⸻ Specifications • Brand / Model: HANG 107-30 electronic • Serial number: 102553 • Year of manufacture: 2002 • Number of drilling heads: 4 pieces, individually adjustable • Electronic control, automatic drilling cycle • Power connection: 400V – 50Hz – 6A • CE certification present • Cast iron frame, extremely robust construction • Manual and automatic operation • Adjustable stops with fine adjustment • Machine is mounted on swivel casters (easily movable) ⸻ Condition • Removed from production in working order • Drill spindles and guides run smoothly • No damages, normal signs of use • Immediately ready for operation • Complete, as shown in the photos ⸻ Description The HANG 107-30 is one of the most robust paper drilling machines on the market. Heavier-duty and more professional version than the standard models, thanks to the sturdy drilling heads, automatic drilling cycle, and reliable electronic control system. Perfect for calendar production, book blocks, brochures, index tabs, and more. ⸻ Price 👉 € 3,250 net (0% VAT export possible) Podpex A Izljfx Ag Djpr

Condition: ready for operation (used), Year of construction: 2004, functionality: fully functional, turning length: 63 mm, rotational speed (max.): 3,750 rpm, overall weight: 6,800 kg, drilling depth: 63 mm, The machine comes complete with collets, holders, and other accessories! TECHNICAL DETAILS Max. turning length: 63 mm Max. drilling depth: 63 mm Max. workpiece passage: 26 mm Max. workpiece feed: 125 mm Ppsdpfeytf Ekox Ag Der Spindle speed range turning: 236 - 3,750 rpm Spindle speed range thread cutting: 13 - 1,875 rpm MACHINE DETAILS Required floor space: 7.16 x 2.3 m Height: 2 m Weight: 6,800 kg EQUIPMENT 6 cross slides 6 longitudinal slides 6 cams for cross slides 6 cams for longitudinal slides 4 change gears for main and feed drive Service tools

Condition: excellent (used), Attachment holders, standard holders and accessories, spiral drill bits, BILZ spiral drill bits, reaming bits, BILZ reamers, BILZ holders, tool holders, drill bit mounts, twist drills -Mounted tool holder: 8 pieces -Recordings: MK5, MK4, MK3 -Spiral drill bits: 35 pieces -Sizes: Ø38 mm - Ø95 mm -Dimensions: see photos -Submission/Price: complete -Transport dimensions: 550/300/H70 mm -Weight: 28 kg Ppjdpfx Ajyrgwxeg Dor

Condition: good (used), Standard holders and accessories, SASSEX spiral drill bits, Sassex spiral drill bits, reaming bits, Sassex reamers, Sassex holders, tool holders, drill bit mounts, twist drills -Manufacturer: Sassex, Spiral drill bit Ø 148.5 mm/H7 -Recording: SK50 -Tool: double-edged Ppodpjfndyvsfx Ag Dsr -Dimensions: Ø 148.5 x 630 mm -Weight: 16.5 kg
