Used Röhm Spanner for sale (297)

Condition: used, Year of construction: 1974, functionality: fully functional, Lead and feed screw lathe Make: Heidenreich & Harbeck Model M530K Year: 1974 Technical Data Manufacturer: Heidenreich & Harbeck Model: M530K Year of manufacture: 1974 Control: Conventional Centre distance: 2000 mm Swing over bed: 530 mm Swing over cross slide: 280 mm Spindle bore: 70 mm Spindle speed: 9 - 1800 rpm Dimensions (L x W x H): 4.05 x 1.50 x 1.40 m Isdpfeyyk Rasx Ab Nsib Machine weight: approx. 4 t Equipment - Röhm 3-jaw chuck, D 250 mm - 1 fixed steady rest - Removable gap bed over 400 mm length - 2-axis digital readout - 1 drill chuck - Coolant pump All data subject to change without notice. A powered demonstration is possible at any time in our showroom.

Condition: excellent (used), Year of construction: 1987, Schaublin 125 C precision lathe Year: 1987 Center height 125 mm Center width 500 mm Speed 45 - 3000 rpm Ijdpfx Abey Avyxo Njib Feed rate 4 - 260 mm/min Spindle nose Camlock D1-3" Tailstock cone MK 2 Turning diameter over bed 250 mm Turning diameter over face slide 120 mm Top slide travel 100 mm Cross slide travel 180 mm Dimension (W x D x H) 1500 x 850 x 1300 mm Weight approx. 950 kg Accessories/options: tool holders Röhm chuck 125mm documentations

Condition: ready for operation (used), Year of construction: 2004, functionality: fully functional, machine/vehicle number: 61062, bar passage: 24 mm, TECHNICAL DETAILS Spindle bore: 24 mm Bar loader Model: IEMCA PRA52 F33 Year of manufacture: 2004 Maximum bar length: 3300 mm Maximum bar diameter: 9.1 mm Control system: Siemens S7-200 Drive for parting unit Stroke per slide: 7.15 mm Actuation angle: 26.565° Facing chuck PKD 80 MACHINE DETAILS Operating voltage: 230 / 400V Frequency: 50 Hz EQUIPMENT Nordmann tool monitoring with touchscreen Tool Monitor Chip conveyor (Knoll 500 K-1/450, year 2004) Oil filtering system (Knoll FKA 150) Scraper conveyor with coolant system High-pressure unit FKA / 250 Tubes with coolant connections Hydraulic unit Central lubrication Hydraulic schematic and accessories Pressure intensifier HC3 - 4.0 - B Deflection plate T-T Pneumatic accessories (for 4 cylinders) Isdpfx Aboyx Ia Nj Neib Compressed air service unit DA 300 Clamping plate for chuck TK420 Oil distributor 2-jaw chuck (Röhm, ID no. 431074, stroke 4.25 mm) Cut-off saw with gear transmission Clamping flange (diameter: 100 mm) Spindle unit complete with toothed belt drive Coolant supply Cover plates for empty stations Material stop (stroke: 60 mm) Parting unit extended by 35 mm Measuring system Z-axis Spindle unit with hydraulic NC-axis Device for rinsing the clamping jaws Change parts for material clamping Stops for hydraulic unit carrier Change parts for bar loading magazine Tools Tool holders Additional clamping with collet Further details about the machine can be found in the attached documents.

Condition: good (used), Year of construction: 1998, Universally applicable frame dowel and slot drilling machine with angle adjustment Especially designed for stair construction, window manufacturing, and versatile applications thanks to pneumatic height adjustment. Angled dowelling and spindle drillings, such as for balusters, can be easily accomplished with the swiveling drilling unit. Motor with pole switching, two speeds Motor power: 1.0 / 1.5 kW, 1400 and 2800 rpm Iiedoxmatnopfx Ab Nsb Motor start via convenient handle switch Equipped with Röhm two-jaw chuck, 1 - 20 mm Linear laser for precise workpiece positioning Drilling unit can swivel 65 degrees left and right Pneumatic adjustment of working height allows dowelling on two levels without repositioning. Desired drilling heights can be set for each drilling level via digital counter, switching between levels is pneumatic and operated from the front Cross adjustment 340 mm, infinitely variable or in 12 mm increments via indexing rail Pneumatic clamping possible at any point, operated from the front Maximum height adjustment approx. 100 mm above table height Drilling stroke approx. 200 mm 2 pneumatic workpiece clamps, 1 clamping column repositionable to the front 2 swiveling workpiece supports Extraction funnel Central stop + 1 side stop Fixed mitre stop Length stop as round rod Assorted drill bits Operating manual CE mark Machine was partly repainted due to paint splashes. Pneumatic hoses replaced Dimensions: approx. 1200 x 1350 x 1600 mm (LxWxH), weight 380 kg. The machine can be viewed and demonstrated at our premises by appointment. We only offer machines that are ready for demonstration in our warehouse, see "more offers from this seller."

Condition: used, Year of construction: 1979, functionality: fully functional, Leadscrew and feed rod lathe Make: WEILER Model: COMMODOR Year: 1979 Technical Data Manufacturer: Weiler Model: Commodor Centre distance: 1000 mm Swing over bed: 400 mm Spindle bore: 50 mm Speed range: 63-2000 rpm Drive power: 4 kW Iodpoxt Ngqjfx Ab Njib Dimensions: approx. L 2.2 x W 1.0 x H 1.7 m Weight: approx. 1.5 t Equipment • 3-axis digital readout • Drill chuck • Röhm 3-jaw chuck, D 200mm • Multifix toolpost • The additional 3-jaw chuck shown on the machine is not included in the scope of delivery! All information without guarantee. A demonstration under power is possible at any time in our showroom.

Condition: ready for operation (used), Year of construction: 1998, travel distance X-axis: 398 mm, travel distance Z-axis: 214 mm, total height: 1,800 mm, total width: 1,900 mm, product length (max.): 2,200 mm, number of axes: 2, Horizontal turning machine manufactured in 1998. This DMG Mori Seiki CL-200B features an X-axis travel of 398 mm and Z-axis travel of 214 mm. It is equipped with a Renishaw tool setter and a workpiece catcher that has never been used. The machine has approximately 10,000 operating hours and has always been operated in a single-shift environment. If you are looking to get high-quality turning capabilities, consider the DMG Mori Seiki CL-200B machine we have for sale. Contact us for further details. • Operating hours: approx. 10,000 • Automatic cycle time counter has not reached its limit (indicates relatively low usage) • Operated in single-shift environment • Currently under power Additional equipment • Renishaw tool setter • Workpiece catcher (never used) Iijdeyxgg Ijpfx Ab Njb • Röhm chuck, approx. 1.5 years old Technical Specification Counter Spindle No Driven Tools No

Condition: ready for operation (used), Year of construction: 2005, operating hours: 21,600 h, functionality: fully functional, machine/vehicle number: 80439430900, turning diameter over cross slide: 465 mm, turning diameter: 680 mm, spindle speed (max.): 3,500 rpm, travel distance X-axis: 300 mm, travel distance Z-axis: 1,050 mm, distance between centers: 1,150 mm, TECHNICAL DETAILS Max. spindle speed: 3,500 rpm Centre distance: 1,150 mm Centre height: 360 mm Z-axis travel: 1,050 mm X-axis travel: 300 mm Isdpfx Abjyw H E Us Nsib Swing diameter over bed: 680 mm Swing diameter over cross slide: 465 mm Rapid traverse Z-axis: 30 m/min Rapid traverse X-axis: 30 m/min Linear axis X and Z measuring system resolution: 0.001 mm Max. workpiece weight between centres: 350 kg Centre taper: MK 5 MACHINE DETAILS Operating voltage: 400 V Frequency: 50 Hz Operating current: 80 A Machine weight: 7,500 kg EQUIPMENT Röhm power chuck (Röhm Duro-NC 260/3) Tool holders

Condition: excellent (used), Year of construction: 2015, WEINIG ISEL 3020 XYZ CNC TEMPLATE MAKER TOOL FOR PROFILE GRINDER TECHNICAL DATA: CNC ROUTER WITH 3 AXIS MOVEMENT Ijdeyxxnwspfx Ab Noib CLAMPING T SLOT TABLE CADCAM TEMPLATE MAKING SOFTWARE INCLUDED PC, SCREEN AND KEYBOARD INCLUDED FULLY ENCLOSED WORKING AREA WITH LOCKING DOOR SYSTEM LARGE CAPACITY WORKING AREA LOW VOLTAGE INTERNAL LIGHTING SET OF MOTOR COLLETS AND SPANNER SET TRAVEL AREA 300 x 200 MM Z AXIZ TRAVEL 90 MM SPINDLE SPEED 11000 & 25000 RPM DIMENSIONS 650 MM (L) x 610 MM (W) x 715 MM (H)

Condition: good (used), Year of construction: 1989, Offered from an insolvency is a ready to use tapping machine Manufacturer Fleet Model SB 15 GL year of manufacture 1989 Machine No. 34177063 Technical data: Cutting capacity M2-M12 Recording MK 2 Pinol stroke 80mm Throat 200mm Chucks Bilz WFP 1 + inserts drill chuck Röhm 0-10mm Foot switch Digital display Pinol stroke Single continuous cycle Emergency stop Iedpfx Aofm S Naob Noib Speeds from 80-3150 rpm 380 volts Engine power 0,75KW max. dimension between table and holder 380mm Total height approx. 1700mm Accessories: 8 pcs. Lead screw --pitches-1.5-1.25--1.75--0.8--0.7--0.5--0.45--1.0 Operating instructions weight approx. 200kg

Condition: used, Column Drill Gillardon Type GSB 32 V Machine No.: Year of manufacture approx. 1975 Drilling capacity: 32 mm Taper: MK 4 – long quill Throat: 350 mm Quill travel: 170 mm Table size: 570 x 470 mm Column diameter: 140 mm Spindle speed Motor speed step 1, Belt step 1: 50 – 300 rpm, stepless Spindle speed Motor speed step 2, Belt step 1: 100 – 600 rpm, stepless Spindle speed Motor speed step 1, Belt step 2: 100 – 500 rpm, stepless Spindle speed Motor speed step 2, Belt step 2: 150 – 1000 rpm, stepless Motor power: 1 / 1.5 kW Power supply: 380 Volt, 50 Hz - automatic feed approx. 0.1 / 0.16 / 0.25 mm/rev, 3 steps - spindle speed via 2 motor speeds, 2 V-belt stages and variator gearbox - adjustable drilling depth stop - table height adjustment via rack and hand crank - tiltable drilling table with angle scale - drill chuck RÖHM Ø 1 to 13 mm - machine lamp Isdpfjyhf Izex Ab Noib Required space (L x W x H): 1000 x 750 x 2000 mm Weight: 470 kg Good condition

Condition: used, L + Z Lathe TONGIL- SAEILO Type TIPL-4SP Machine No. 00570319 Year of manufacture: 1985 Iedpfx Abex Urbvj Noib Centre distance: 1000 mm Swing over bed: 400 mm Swing over cross slide: 210 mm Centre height over bed: 200 mm Centre height over cross slide: 105 mm Spindle bore: 58 mm Spindle speed: 55 - 1600 rpm, 16 steps Feed: Longitudinal and cross Tailstock taper: MT4 Chuck flange: Camlock, taper size 6 Motor power: 4 / 6 kW Electrical connection: 380 Volt, 50 Hz - Spindle speed via 2 motor speeds and 8 gear stages - 3-jaw scroll chuck RÖHM Ø 200 mm with stepped jaws - Multifix quick-change tool post size B with 2 exchangeable tool holders - Spindle brake via mechanical foot pedal - Coolant system - Emergency stop - Machine lamp Space required (L x W x H): 2250 x 1050 x 1220 mm Weight: 1500 kg

Condition: used, Year of construction: 2011, gebraucht 2011 010192 prompt, Zwischenverkauf v Deutschland 26700 € 1 320 mm 650 mm 160 mm 40 mm 192 mm 205 mm 5 5 MK 16 48 - 2500 1/min 24 0.02 - 0.63 mm/U 0.006 - 0.2 mm/U 0.25 - 8 mm 80 - 2 Gänge/" 0.2 - 4 200 - 5 150 mm 100 mm 40 mm 3 MK 85 mm 2,4 / 3 kW 1582 mm 715 mm 1245 mm 720 kg Heidenhain 3-axis digital readout NEW Röhm 3-jaw chuck, 160 mm diameter, with internal and external jaws Quick-change tool post with one rectangular insert and one round insert Quick-release collet chuck with collets from 3 to 29 mm diameter (in 1 mm increments) Live centre Iisdsyxxyaepfx Ab Njb Drill chuck Chuck guard Lead and feed screw guard Motor brake Coolant system Mounting feet Operating instructions in German with CE declaration of conformity

Condition: excellent (used), Year of construction: 2004, Please read the technical specifications thoroughly. If you are considering this machine as a potential investment, we kindly request your complete credentials with an accurate telephone number and email address in order to submit an offer. We are offering an exceptionally high-quality precision lathe. In its class, this is arguably the best German lathe ever built. BOEHRINGER Precision Lathe Model DUE 500 Year of manufacture: 2004, incl. CE certificate and central lubrication Machine no.: T1022.2027-00 Centre height: 240 mm Swing over bed: 500 mm Swing over cross slide: 285 mm Centre distance: approx. 1,200 mm Ijdow Rdthepfx Ab Neib Turning length (effective): approx. 1,000 mm Bar capacity: 62 mm Spindle nose: DIN 55027 size 6 Spindle diameter: 100 mm Drive power: 11 kW Max. torque: 2,000 Nm 24 spindle speeds: 11.2 – 2,240 rpm 60 cross feeds: 0.03 – 28 mm/rev 60 longitudinal feeds: 0.06 – 56 mm/rev Tailstock quill travel: 190 mm Tailstock taper: MK 5 Space requirement: approx. 4,000 x 1,525 mm (L x W) Weight: approx. 4,300 kg Accessories included: - 3-axis digital readout HEIDENHAIN - Central lubrication - Electrically interlocked chuck guard - Coolant system - Chip protection rear wall - Röhm lathe chuck T 250 mm incl. various clamping jaws - Telescopic cover for leadscrew and support to bed - Machine lamp - Multifix C tool post + 4 holders - Live centre - Operating manual - Circuit diagram - Rapid traverse in longitudinal and cross slide Condition: The machine is in very good technical and visual condition. Backlash in cross slide: approx. 0.3 mm, top slide: approx. 0.15 mm Spindle nose runout: approx. 0.006 mm Bed geometry: deviation approx. 0.01 mm over 750 mm of bed length (measured on flat guideway with dial indicator towards the chuck) The following parts have been renewed: - Oil change - New hoses for central lubrication - New wipers - Key for engagement lever replaced - Locking pin for engagement interlock replaced Net price EXW. Delivery with our own truck can be offered for an additional charge.

Condition: used, Year of manufacture: 1980s/90s Technical data: Centre height: 185 mm Centre distance: 750 mm Turning diameter over bed: 370 mm Spindle bore: 36 mm Bed width: 250 mm Speed range: 38 - 1600 rpm Tailstock taper: MT 3 Quill stroke: 110 mm Dimensions (W x D x H), approx.: 1950 x 900 x 1200 mm Weight, approx.: 800 kg Equipment: - 3-jaw chuck, make: Röhm, ø 200 mm - Quick-change tool post with 4 holders - Bed stop - Chip tray Iiodpfx Absydk Hhs Nsb

Condition: not inspected (used), functionality: unexamined, overall weight: 300 kg, total length: 2,000 mm, total width: 1,200 mm, total height: 1,500 mm, No minimum price – guaranteed sale to the highest bidder! Placing a bid requires timely collection between 04.05.26 and 07.05.26. Workbench including the following contents: Mounted vise, jaw width: 150 mm RÖHM three-jaw chuck, diameter: 110 mm Iiedpfjyr Hz Rex Ab Nsb Thread taps Parallel shims Marking plate (800 mm x 800 mm) Various micrometers Gauge blocks Other measuring instruments MACHINE DETAILS Dimensions & weight Dimensions (L x W x H): 2,000 x 1,200 x 1,500 mm Weight: 300 kg External reference: 34

Condition: used, L + Z Lathe WEILER Type Praktikant 800R Machine No. 3315 Year of manufacture: 1984 Center distance: 800 mm Swing over bed: 280 mm Swing over cross slide: 160 mm Center height over bed: 140 mm Center height over cross slide: 80 mm Spindle bore: 36 mm Feeds: longitudinal and face Chuck mount: short taper DIN 55027 size 5, 4x M10 Tailstock taper: MK 3 Quill travel: 90 mm Spindle speed: 42 - 2000 rpm Drive power: 1 / 1.6 kW Electrical connection: 380 Volt, 50 Hz - Spindle speed via 2 motor speeds and 8 gearbox steps - 3-jaw scroll chuck RÖHM ZS Ø 160 mm with 1 set of stepped jaws - MULTIFIX quick-change tool post size A with 3 tool holders Iodeyr R Dcopfx Ab Neib - Emergency stop - Hinged chuck guard - Operating manual with electrical diagram Required space (L x W x H): 1900 x 700 x 1300 mm Weight: 560 kg Good condition

Condition: ready for operation (used), Year of construction: 2013, functionality: fully functional, turning length: 532 mm, turning diameter over cross slide: 500 mm, turning diameter: 325 mm, spindle speed (max.): 3,500 rpm, spindle bore: 65 mm, travel distance X-axis: 195 mm, travel distance Z-axis: 430 mm, rapid traverse X-axis: 30 m/min, rapid traverse Z-axis: 30 m/min, rotational speed (max.): 5,000 rpm, total length: 2,875 mm, chuck outer diameter: 260 mm, total width: 1,675 mm, spindle nose: A2-8, overall weight: 4,650 kg, Equipment: documentation/manual, rotational speed infinitely variable, We have acquired this HWACHEON HI-TECH 200BL MC directly from production in working condition—see the video of the machine operating prior to dismantling. The machine is very comprehensively equipped and comes standard with: - C-axis + driven turret (both positions). - Renishaw probe. - Chip conveyor + collection bin. - Röhm 3-jaw chuck (DURO-NC 260/3) including 2 sets of top jaws. - 13 EWS toolholders, 4 of which are driven. - Various clamping sleeves and collets. - Original HWACHEON and FANUC documentation. The machine can be inspected under power in our showroom! Isdpfx Ajypc H Rob Njib

Condition: ready for operation (used), Year of construction: 2018, operating hours: 3,361 h, travel distance X-axis: 1,270 mm, travel distance Y-axis: 610 mm, travel distance Z-axis: 720 mm, controller manufacturer: HEIDENHAIN, controller model: TNC 530, table load: 1,200 kg, spindle speed (max.): 8,000 rpm, spindle motor power: 28,000 W, tool weight: 15,000 g, number of axes: 3, This 3-axis MAS MCV 1270 Power was manufactured in 2018. It features a Heidenhain TNC 530 control, SK50 spindle holder, and a tool magazine with 24 places. The machine offers a table size of 1500mm x 670mm, supporting a maximum load of 1200kg. Rapid traverse reaches up to 40m/min, with a maximum spindle speed of 8000 rpm. If you are looking to get high-quality milling capabilities consider the MAS MCV 1270 Power machine we have for sale. Contact us for more information. Additional equipment • 4 hydraulic vices from Röhm and various SK50 tool holders Machine Benefits Technical Machine Benefits • Table size: 1500 mm x 670 mm • Tool magazine: 24 places • Rapid traverse: 40 m/min • Feed rate: 1-15000 mm/min Extra Information Machine still under power Iiedpsx D Episfx Ab Neb

Condition: used, thickness of jaw 160 mm max. clamping width 302 mm weight ca. 60 kg length in total 770 mm Allmatic 160 hydraulic vice with adjustable clamping pressure Span S1/mm: 0-152 Span S2/mm (can be changed with locking pin): 147-302 Clamping force levels: 4 Max. clamping force in kN: 60 Design: Mechanical min. Clamping width/mm: 0 Workpiece: Pre-machined part Jaw width/mm: 160 Ijdjypwf Ispfx Ab Noib Max. clamping width/mm: 302 Max. clamping width: 302mm - incl. 2x clamping claws - Without vice spanner

Condition: used, thickness of jaw 160 mm max. clamping width 302 mm weight ca. 60 kg length in total 770 mm Allmatic 160 hydraulic vice with adjustable clamping pressure Span S1/mm: 0-152 Span S2/mm (can be changed with locking pin): 147-302 Clamping force levels: 4 Max. clamping force in kN: 60 Design: Mechanical min. Clamping width/mm: 0 Workpiece: Pre-machined part Jaw width/mm: 160 Max. clamping width/mm: 302 Max. clamping width: 302mm - incl. 2x clamping claws - Without vice spanner Isdpoypwfusfx Ab Noib

Condition: used, thickness of jaw 160 mm max. clamping width 302 mm weight ca. 60 kg length in total 770 mm Allmatic 160 hydraulic vice with adjustable clamping pressure Span S1/mm: 0-152 Span S2/mm (can be changed with locking pin): 147-302 Clamping force levels: 4 Max. clamping force in kN: 60 Design: Mechanical Iiodpfxeypwfhs Ab Nsb min. Clamping width/mm: 0 Workpiece: Pre-machined part Jaw width/mm: 160 Max. clamping width/mm: 302 Max. clamping width: 302mm - incl. 2x clamping claws - Without vice spanner

Condition: used, L + Z Lathe WEILER Type Condor 81 A Mach. No. 36553 Year of manufacture approx. 1985 Centre distance 750 mm Swing over bed 330 mm Centre height over bed 165 mm Swing over cross slide 180 mm Centre height over cross slide 90 mm Spindle bore 40 mm Chuck mounting: Short taper DIN 55027 size 5 Tailstock quill taper MK 3 Quill travel 110 mm Spindle speed 45 - 2800 rpm, 16 steps Drive power 3 kW Power supply 400 Volt, 50 Hz - Spindle speed through 16 gear steps - 3-jaw chuck Ø 160 mm RÖHM with hard and soft jaws - Multifix quick-change tool post size B with 3 holders - Automatic longitudinal and cross feed - Electro-mechanical spindle brake - Emergency stop - Coolant tank with pump integrated in the machine base, without feed hose to working area - Hinged chuck guard - Splash guard - 1 live center - Electric diagram and operating manual Space requirements L x W x H 1850 x 950 x 1400 mm Weight 1100 kg Good condition Iedsk S Ht Aopfx Ab Nsib

Condition: used, CNC cycle controlled lathe HARRISON type Alpha 400 Plus Machine No. P30180/150 Year of construction 1998 center distance 1250 mm turning diameter over bed 400 mm center height 200 mm Swing diameter over cross slide 245 mm Swing diameter in the bend 585 mm bed width 313 mm face travel (X-axis) 250 mm Tailstock spindle diameter 73 mm Tailstock quill stroke 140 mm Tailstock quill mount MK 5 spindle bore 54 mm spindle head size Camlock D1 size 6 Spindle speed 20-2500 rpm. Spindle speed range (stage 1) 15-275 rpm. Spindle speed range (stage 2) 35-795 rpm. Spindle speed range (level 3) 110-2500 rpm. Iisdpfxoh Hvk Ae Ab Nob Feed rate X and Z 0.03 - 0.6 mm/rev. Rapid traverse speed X axis max. 2000 mm/min. Rapid traverse speed Z-axis max. 4000 mm/min. Threading function Metric / Inch / Diametral / Module Spindle drive power 7.5 KW Mains connection 400 Volt, 50 Hz, 23,5 kVA - cycle control Harrison Alpha / GE FANUC - language in French (France) - automatic gear range shifting in 3 steps (15-275, 35-795, 110-2500 rpm.) - electronic handwheels with different transmission ratios (1/10/100) - 3-jaw face spiral lathe chuck FORKARDT Ø 250 mm type CSN, 1 set of soft top jaws - quick-change tool holder MULTIFIX size B with 2 inserts - 1 piece of centering point running with the tool - 1 piece quick-action drill chuck RÖHM, 3-16 mm - hinged lathe chuck guard - hinged working area protection doors - chip tray with coolant device under the machine bed - Switch cabinet fixed to the machine - Interface RS 232 Space requirement L x W x H 2600 x 1450 x 1550 mm weight 1950 kg good condition

Condition: used, Year of construction: 2020, turning diameter max. 3.800 mm diameter of spindle flange 1.900 mm max. swing diameter 3.800 mm control 840 D sl Siemens turning speed range - main spindle max. 100 min/-1 power capacity - main spindel 200 kW max. Torque 67.000 Nm gear box 1:30 tool taper Capto C8 swivellable B: 0 - 270 ° Spindle speed - driven tool pos. max. 6.000 min -1 max. Torque 120 Nm tool taper Capto C8 number of toolpositions 41 pos. max. tool weight 20 kg max. tool length 400 mm max. tool diameter 120 mm 0 125 mm tool taper Capto C8 number of toolpositions 25 pos. workpiece diameter at full load 150 mm max. tool weight 20 kg max. tool length 400 mm x-axis 1: 2.800 mm x-axis 2: 3.200 mm z-axis 1.000 mm rapid traverse X: 32 / Z: 20 m/min feed power X/Z: 22 kN total power requirement 280 kVA weight of the machine ca. 155 t dimensions of the machine ca. 10,4 x 6,3 x 5,7 m CNC Vertical Turning Machine PITTLER - PV 4000 - Control Expansion / Software SINUMERIK 828D/840D SL ProgramSYNC Software Option Iiodpfx Aoyrhl Dsb Nsb - 12-Jaw Compensating Chuck by RÖHM - Retractable Step Guards - Coolant Circulation - Coolant Conditioning - Oil Hose Skimmer - SIEMENS Safety Integrated - Network Interface / Data Transfer DNC Option - Remote Diagnostics for NC Functionality - Teleservice for Integrated PLC of the Sinumerik 840D - Ethernet Connection in the Control Cabinet - Variable Speed ??Range to Reduce Vibration - Air Purifier, Electrostatic Discharge - Probe for In-Process Workpiece Measurement - Walk-in Work Area

Condition: used, Year of construction: 2021, turning diameter max. 2.800 mm diameter of spindle flange 1.100 mm max. swing diameter 3.000 mm control 840 D sl Siemens turning speed range - main spindle max. 230 min/-1 power capacity - main spindel 206 kW Iijdpfx Abeyrhlwo Neb max. Torque 53.000 Nm tool taper Capto C8 swivellable B: 0 - 270 ° Spindle speed - driven tool pos. max. 6.000 min -1 max. Torque 120 Nm tool taper Capto C8 number of toolpositions 41 pos. max. tool weight 20 kg max. tool length 400 mm workpiece diameter at full load 150 mm tool taper Capto C8 number of toolpositions 25 pos. workpiece diameter at full load 150 mm max. tool weight 20 kg max. tool length 400 mm tool taper Capto C8 x-axis 1: 2.700 mm x-axis 2: 2.700 mm z-axis ( 2x 1.000 ) mm rapid traverse X: 40 / Z: 24 m/min feed power X/Z: 22 kN total power requirement 200 kVA weight of the machine ca. 120 t dimensions of the machine ca. 10,4 x 6,3 x 5,7 m CNC Vertical Turning Machine PITTLER - PV 2500 - Control Expansion / Software SINUMERIK 828D/840D SL ProgramSYNC Software Option - 12-Jaw Compensating Chuck RÖHM - Retractable Steps - Coolant Circulation - Coolant Conditioning - Oil Hose Skimmer - SIEMENS Safety Integrated - Network Interface / Data Transfer DNC Option - Variable Speed ??Range to Reduce Vibration - Air Purifier, Electrostatic Dispersal - Touch Probe for In-Process Workpiece Measurement - Walk-in Work Area
