Used Rotary Table Grinding Machine - Vertical for sale (68,613)

Year of construction: 2001, condition: good (used), table diameter 200 mm workpiece height 100 mm number of wheels 1 Control Robot CNC total power requirement 6 kW weight of the machine ca. 1,8 t dimensions of the machine ca. 1,83 x 2,04 x 2,1 m Technical data - Grinding capacity : Ø 0.025 –12.7 [mm] - Bar diameter : Ø 1.0 –12.7 [mm] - Grinding length : W15 (option W20) - Z-axis : 35[mm] Resolution : 0.5 [µm] – X- axis : 25 [ mm] Resolution : 0.1µm – Y-axis : 286[mm] Resolution : 0.5µm – U- Hodett Tb Dspfx Al Sel axis : 15 [mm] Resolution : 0.1µm Head Motor: 0.70 [kW] Rotation: 300 – 3000 [rpm] Grinding - Raw grinding : 1.5 [kW] Spindle : Ø 60 [mm] Grinding wheel diameter : Ø 200 [mm] Cutting speed : 30 m/sec. - Completion: 0.75 [kW] Spindle: Ø100 [mm] Grinding wheel diameter: Ø150 [mm] Cutting speed: adjustable - Dimensions (L x W x H): 1830 x 2040 x 2100 mm - Weight: approx. 1800 [kg] Accessories - Loading and unloading robots - Fire protection device CONTROL axes; 4 axes + 2 programmable robots - simultaneously linear interpolation of the 4 axes + cylindrical interpolation of 2 robot axes

Condition: used, Year of construction: 2008, control Siemens 840D Hodpfowzypnex Al Sol

Condition: ready for operation (used), Year of construction: 1998, A CNC vertical machining center Takumi is available. Travel X/Y/Z: 1800mm/850mm/750mm, spindle nose to table distance range: 200mm-950mm, spindle center to column distance: 920mm, table dimensions X/Y: 2000mm/800mm, max. table load: 2200kg, tool holder: NT50, speed: 6000rpm, feed rate: 5m/min, rapid traverse: 12m/min. Machine dimensions X/Y/Z: approx. 5700mm/3850mm/3350mm, weight: approx. 16500kg, control: Heidenhain, operating hours: approx. 50000h, spindle hours: approx. 25000h. Documentation available. An on-site inspection is possible. Hedpfx Alsy H I H Ee Ssl

Condition: ready for operation (used), Year of construction: 1991, A CNC vertical machining center Emco is available. Travel X/Y/Z: 420mm/330mm/400mm, table dimensions X/Y: 650mm/320mm, max. table load: 150kg, tool positions: 12, tool holder: SK40, speed: 4500rpm, rapid traverse: 12m/min. Machine dimensions X/Y/Z: approx. 2400mm/2300mm/2450mm, weight: approx. 2750kg, control: Emcotronic TM02. An on-site inspection is possible. Hsdpsy H I H Sjfx Al Sjl

Condition: used, Year of construction: 2001, Technical details: grinding diameter max.: 3-220 mm regulating wheel width: 400 mm max. width of grinding wheel: 400 mm grinding motor: 55 kW peripheral speed: max. 45 m/sec regulating wheel dimensions: 350 x 400 x 203 mm dimensions of grinding wheel: CBN 500 x 400 x 304 mm grinding wheel size: KORUND 600 x 400 x 304 mm total power requirement: 75 kVA weight of the machine ca.: 13 t. dimensions of the machine ca.: 4,47 x 2,77 x 2,49 m. Centerless Grindign Machine JUNKER JUPITER 500 CNC SIEMENS in good condition. Including: · 2 robots Kuka KR 16 Year 2007 · CNC loading and unloading device Promot EPL60NC Year 2007 The machine was lately used for grinding of guide bushes (through grinding). Plunge is possible. JUPITER's Centerless grinding, also available with CBN. Junker this circular grinding method with CBN grinding wheels, which opens up significant productivity benefits from the long service life of the grinding wheel, especially at high volumes. In addition, the simultaneous removal takes on the entire Schleswig-Holstein, which provides both in mass production and in small batches for significantly reduced processing times. The grinding process with JUPITER When centerless grinding, there are two grinding processes: the through grinding and plunge. Both methods are possible with the JUPITER. Hedpfx Ajttxg Isl Sjl Applications through grinding: Pin and Bushings Body, rings, smaller rings, piston parts (eg compressors), waves with constant diameter piston rods (eg shock), Small piston for hydraulic and fuel injection, precision wires and rods, piston pins. Applications Plunge: Rotor shafts, transmission parts, bearing surfaces of camshafts, tube and pipe fittings for composite camshafts, universal joints, parts for needle injection, valve stems, barrel rolls. *

Condition: used, Year of construction: 1996, Technical details: grinding length: 1370 mm grinding width: 560 mm Hedpfxow S Hy Hs Al Sjl workpiece height: 800 mm total power requirement: 50 kW dimensions of the machine ca.: 9 m ABA Z&B 2000, profile grinding machine with swivel dresser Mounting fixtures: magnet, dividing head E-axis dresser B-axis dividing head *

Condition: good (used), Year of construction: 1984, max. wheel diameter 250 mm gear width 275 mm max. module 6 weight of the machine ca. 5,5 t The gear hobbing machine ZFWZ 250 is suitable for the economical production of all hob-processable cylindrical gear types, such a: - spur and helical gear, wormgears and worms, splined shafts, keyed shafts, serrated profiles, chain wheels and ratchet wheels,as well as conical and crowned spur and helical gears. Interchangeable wheels and milling accessories Technical data: - Workpiece diameter (max): 250 mm - Module (max): 6 mm - Axial feed travel (max): 275 mm - Tangential feed travel (max): 100 mm - Tooth helix angle (max): 45 degrees - Milling cutter diameter (max): 145 mm - Milling cutter length (max): 170 mm - Table clamping surface (min): 195 mm - Table clamping surface (max): 470 mm Power Milling cutter speeds - Stepped in 2 ranges: 56 ... 250 rpm - (Standard version): 90 ... 400 rpm - Infinitely variable in 2 ranges: 63 ... 180 rpm - (special version DC motor): 140 ... 400 rpm Weights - Machine net: approx. 5000 kg - Electrical cabinet: approx. 800 kg - Hydraulic unit + coolant tank + chip transport: approx. 700 kg Hedpfjv T Nqajx Al Sol Overall dimensions (with oil mist filter) - Length: Standard version: 3950 mm DC drive: 3450 mm (or 3350 mm according to table) - Width: 3300 mm - Height: Machine: 1980 mm Machine with DC drive: 2150 mm Electrical cabinet: 2200 mm

Condition: used, Year of construction: 1989, max. wheel diameter 400 mm gear width 275 mm max. module 6 Overall size 300x310x245 cm weight of the machine ca. 5,0 t Specifications: - Maximum wheel diameter: 400 mm - Min. module: 1 - Max. module: 6 - Table diameter: 370 mm - Maximum wheel diameter: with counter support: 340 mm / without counter strut: 400 mm - Max. axial offset: 275 mm - Max. tangential adjustment: 100 mm - Max. tooth helix angle: 45 degrees - Max. cutter diameter: 145 mm - Max. hob length: 170 mm Performance - Cutter speed: 50-200 rpm - Axial feed continuously adjustable: 0.2-10 mm/rev - Tangential feed continuously adjustable: 0.1-5 mm/rev - Radial for spur gears: 0.1-4 mm/rev - Radial for worm gears: 0.025-1 mm/rev - Rapid traverse axial: 500 mm/min - Rapid traverse tangential: 250 mm/min - Radial for spur gears: 400 mm/rev - Radial for worm gears: 100 mm/rev - Motor power: 7.4 kW Gewicht - Machine 5000 kg - Electrical cabinet approx. 800 kg - Hydraulic unit, coolant tank, chip conveyor approx. 700 kg Dimensions Hedpfx Alou A I Elo Sjl - Length with chain drive (normal) 2950 mm with DC drive 3350 mm - Width: 3100 mm - Height Machine: 1980 mm Electrical cabinet approx.: 2200 mm Machine with DC drive approx.: 2150 mm

Condition: excellent (used), Year of construction: 2019, functionality: fully functional, Equipment: chip conveyor, Options: Left side chip conveyor Coolant temperature control 15,000 rpm spindle High-torque spindle Linear scales on axes Losma extraction Automatic door Detachable handwheel 3-color signal lamp Renishaw RMP 600 Continuous 5 axes Hodpfxoycr Nue Al Ssl ISO 5-axis function Performance package Memory extension Robot interface

Condition: used, Year of construction: 2009, Technical details: turning diameter: 1000 mm swing diameter: 1000 mm Machine type: Vertical lathe Manufacturer: Hessapp Type: DV 62 Serial no.: 14.2308 Working range of the spindle Largest diameter 1000 mm Largest swing diameter 1000 mm Cross slide travel Stroke of the vertical slide 900 mm Stroke of the horizontal slide 1810 mm Total travel 2315 mm Turning spindle Spindle head with centering cone according to DIN 55021 A15 Hjdpfot Rmdzex Al Sol Spindle diameter in the front bearing 203 mm Main drive Via a controlled asynchronous motor and gear transmission with range switching. Spindle speeds Speed ??range I: 5 - 350 rpm. Speed ??range II: 30 - 1000 rpm. Travel speed X/Z axis: 10 m/min. W1 axis: 8 rpm No C-Axis *

Condition: used, Year of construction: 1997, Technical details: max. module: 7 weight of the machine ca.: 5 t Hedpsx Aq Egjfx Al Ssl worm grinding diameter: 280-350 mm width of grinding worm: 84-104 mm min. number of teeth: 6 max. number of teeth: 600 max. top circle diameter: 360 mm max. workpiece weight: 60 kg without filter *

Condition: used, Year of construction: 1989, MAKE GER, MADE IN SPAIN MODEL RS 10/60 YEAR TABLE LENGTH 1300.0 mm TABLE WIDTH 600.0 mm TRAVEL X AXIS: 1600.0 mm Y AXIS: 600.0 mm MAX DISTANCE (TABLE TO WHEEL) 800.0 mm MAX WORKPIECIE WEIGHT 1000 KGS GRINDING WHEEL SIZE 400.0 x 100.0 x 127.0 mm SPINDLE SPEED MAX 1500 RPM MACHINE DIMENSIONS 4600.0 x 2700 x 2600.0 mm MACHINE WEIGHT 7600 KGS PLUS ELECTROMAGNETIC CHUCK SIZE: 1000.0 X 600.0MM HYDRAULIC PACK Hedpfx Aley Du N Uj Sel COOLANT SYSTEM WHEEL MOUNTED DRESSER

Condition: ready for operation (used), Year of construction: 2014, HAAS VF2 Year of manufacture: 2014 Hodpfey Icw Iex Al Ssl

Condition: used, Year of construction: 1998, Technical details: grinding diameter: 250 mm grinding length: 2710 mm max. module: min. module: Hedjudf E Aepfx Al Sol total power requirement: 45 kW weight of the machine ca.: 15 t space required L x W X H: 7,1 x 4,7 x2,7 m max. wheel dia.: 450 mm Spindle drives Arena Siemens For Worm grinding we have not module, but pitch. Pitch is freely programmable from 0.001 to big value i.e. 500mm *

Condition: good (used), Year of construction: 2000, functionality: fully functional, travel distance X-axis: 1,050 mm, travel distance Y-axis: 530 mm, travel distance Z-axis: 550 mm, controller manufacturer: Heidenhain, Immediately available. Price: €3,500, loaded free on truck. Hjdoyzgvnjpfx Al Ssl

Condition: good (used), Year of construction: 2008, functionality: fully functional, travel distance X-axis: 1,100 mm, travel distance Y-axis: 510 mm, travel distance Z-axis: 510 mm, controller manufacturer: Siemens, controller model: 840 D SL, spindle speed (max.): 12,000 rpm, Immediately available. Price: €13,500, loaded free onto truck. Hedpfsyzguwex Al Sol

Condition: not inspected (used), Year of construction: 2003, travel distance X-axis: 1,270 mm, travel distance Y-axis: 660 mm, travel distance Z-axis: 640 mm, Ultimax control BT 40 spindle, new in 2020 speed 10,000 rpm travels 1270X660X640 mm 24-tool changer chip conveyor Hedpjxu Ikqefx Al Sjl

Condition: ready for operation (used), Year of construction: 2005, grinding length: 400 mm, grinding width: 200 mm, capacity 400x200MM, manual table, magnetic chuck, external electrical cabinet Hsdpfexc Ivcjx Al Sol

Condition: ready for operation (used), Year of construction: 1987, total width: 200 mm, total length: 400 mm, ducts 400x200 mm, outdoor electrical cabinet Hedey E N Uhopfx Al Ssl

Condition: used, table length 1500 mm table width 1500 mm table load 10 t voltage 380 V Heidenhain D.R.O. Hedpfxoyuqf Eo Al Ssl Additional plate on rotary table: 2.000 x 3.000 x 3.000 mm

Condition: used, Year of construction: 2004, Machine Type: Vertical Machining Center (VMC) Travels X-axis: 1,270 mm (50") Y-axis: 508 mm (20") Hjdpsyfmttefx Al Sjl Z-axis: 635 mm (25") Table Table size: 1,321 × 495 mm (52" × 19.5") Max table load: 1,587 kg (3,500 lbs) T-slots: 5 slots, 16 mm Spindle Spindle taper: CAT 40 / BT40 Spindle speed: 8,100 rpm (optional 12,000 rpm) Spindle motor: 30 hp (22.4 kW) vector drive Drive type: Inline direct-drive Coolant Through Spindle (TSC): 300 psi (21 bar) standard for TSC version Tool Changer Automatic Tool Changer: 40 tools (side-mount ATC) Tool change time: ~2.8 sec (tool-to-tool) Max tool weight: 5.4 kg (12 lbs) Feedrates Rapid traverse: 25.4 m/min (1,000 ipm) Cutting feed: up to 16.5 m/min (650 ipm) Accuracy Positioning accuracy: ±0.005 mm Repeatability: ±0.0025 mm Control Control system: Haas CNC Control Memory: 1 GB Networking: Ethernet / USB Dimensions & Weight Machine weight: approx. 7,100 kg Footprint: approx. 4.1 × 2.8 m Height: approx. 3.1 m Electrical Power requirement: 208–240 / 360–480 V, 3-phase Air requirement: 6.9 bar (100 psi)

Condition: used, travel distance X-axis: 800 mm, travel distance Y-axis: 600 mm, travel distance Z-axis: 600 mm, overall weight: 6,500 kg, Fanuc 21IM Hjdpfx Aljyu Tkqj Sol BT40 spindle maximum speed 10,000 rpm 24-position tool changer

Condition: new, all stainless steel turn table new diameter 1.250 mm adjustable height 820 – 910 mm safety guard (height 10 mm) 1 speed (3 rpm) 0,12 kW Hjdpfx Aloytn Nxo Ssl also available with variable speed

Condition: new, The tube linishing / satin finishing machine – ML100 – is the perfect choice for finishing the surface of round, oval and elliptical tubes. The ML planetary system enables the work without rotating the tube - delivering the best results on both bent and curved tubes. The auto feeding system transports straight tubes safety and automatically through the finishing station, enabling a consistent and high productive tube polishing quality. Minimum tube vibration even on the biggest lengths: With the ML Planetary System the tube is not spinning. The abrasive belts rotate around the tube while it is safely transported by the feeding systems. Straight or curved tubes polishing: ML100 was designed to finish either straight tubes (automatically) or bent tubes (manually). Hsdpfxsd Hfnbo Al Sol Quick set-up: Simple to work with ML100 tube polishing machine. Automatic feeding is hinge mounted and easily removable for bent tube finishing. Low heat: The soft contact with abrasive belts with ML Planetary System has a very low heat on the tube surface, unlike other conventional systems. Oval tubes: Oval or elliptical tubes polishing or simply out-of-round tubes can be safety and consistently finished with ML100 Finishing after tube drilling: Maximum adaptability of the abrasive belt to holes or graps in the material surface. Technical Details - ML100: Working capacity (Ø mm) 10 - 114 No. Stations 1 Abrasive belt dimensions (mm) (2x) 50x940 Abrasive belt speed (m/s) 3-22 Feeding speed (m/m) 1-5 Abrasive belts motor (kw) 3 Wheel motor (kw) 1.5 Feeding motor (kw) (2x) 0.12 Total power (kw) 5 Consumption (A) 11 Dust extraction connection (Ømm) 80 Dimensions (mm) 750x1000x1300 Weight (kg) 250

Condition: used, Year of construction: 2008, functionality: fully functional, travel distance X-axis: 635 mm, travel distance Y-axis: 510 mm, travel distance Z-axis: 460 mm, rapid traverse X-axis: 30 m/min, rapid traverse Y-axis: 30 m/min, rapid traverse Z-axis: 30 m/min, controller manufacturer: Heidenhain, controller model: iTNC530, workpiece weight (max.): 600 kg, total height: 2,665 mm, total length: 2,440 mm, total width: 1,900 mm, table width: 790 mm, table length: 560 mm, table load: 600 kg, overall weight: 4,200 kg, spindle speed (min.): 20 rpm, spindle speed (max.): 10,000 rpm, operating hours of spindle: 6,651 h, coolant supply: 20 bar, spindle nose: SK40 (DIN69871), number of slots in tool magazine: 20, Equipment: chip conveyor, documentation/manual, rotational speed infinitely variable, A very well-equipped DMG Deckel Maho DMC 635 V with relatively low spindle hours. The machine is connected to power and can be seen in operation by appointment. Additional options & accessories: - Operation mode 4 - Internal cooling – 20 bar - Band filter system – 600L - Chip conveyor - Electronic handwheel Hedpfoy E N Dcex Al Sel - Original accordion cabin roof - Rinsing pistol - Approx. 30 pcs. SK40 tool holders (incl. 3D probe) - All original documentation Weight & dimensions: 4,200 kg 2440 (3500 incl. PLC) x 1900 x 2665 mm (LxWxH)
