Used Sawmill Machines for sale (66,594)

Condition: good (used), Year of construction: 2001, Equipped with: Power Stock Ledsrualpepfx Akuehg Fanuc 5-Axis CNC Control 160M 400mm Honing Wheel X Axis Pulse Generator Coolant System w/Twin Filters Magnetic Chip Separator Honing Tool Set up for Last Job is Still in Machine Internal Diameter of Honing Tool on Machine is 14" Work Light Power Door Auto Dress 5-Part Program Instruction Book for 16M Control Instruction Book for Set-Up and Operation Specifications: Maximum Outer Diameter: 250 (350) Minimum Outer Diameter: 30 Maximum Overall Length: 400mm Maximum Tooth Width: 45mm Module: 1.0-3.0 Cross Feed Device(Z Axis): 430mm Max. Travel Honing Wheel Cutting Feed Device(X Axis): 370 Max. Travel Honing Wheel Swing Device(C Axis): Swing Angle: +30 Degress Honing Wheel Rotation Drive Device(A Axis): Honing Wheel Spindle Speed R/Min: 500 Honing Wheel Outer Dia.: 300 (400) Maximum Honing Wheel Width: 50mm Crowning Device (Y Axis): Maximum Rocking Angle: 1.6 Degrees Motor Types: Z-Axis Drive Motor: 1.8Kw X-Axis Drive Motor: 1.8Kw Y-Axis Drive Motor: 0.7Kw C-Axis Drive Motor: 1.8Kw A-Axis Drive Motor: 2.2/3.7Kw Maximum Distance Between Centers: 600mm Center Height: 1,100mm Floor Space: 2,170W X 2,800D X 2,100H Mass Of Machine: 4,500Kg

Condition: excellent (used), Year of construction: 2019, machine/vehicle number: 32006, input voltage: 480 V, The Sprinter for Gears with Short Face Widths up to 100 mm The 100S Gear Shaping Machine is ideally suited for small face widths, for shaping spur and helical gears, internal and external, and for crowned and tapered gears. With only 6 m2 the 100S is one of the most compact machines of its class. Equipped with: Siemens Sinumerik 840D SL Control Hydraulic System 180 Degree Load System HSK-63 Spindle Auto Stroke Adjustment Chip Conveyor Chip Basket Flexlink Automation Festo Pneumatics Rittal Panel Conditioners Chiller 480/3/60, 35 KvA Motor & Controls Specifications: Workpiece With External Gear: -Largest Module (Steel W/Approximate 600 N/mm2): 3 mm -Maximum Width: 26 mm -Maximum Diameter: 100 mm Workpiece With Internal Gear: -Largest Module (Steel With Approximate 600 N/mm2): 3 mm -Maximum Width: 26 mm -Maximum Swing Diameter: 150 mm -Maximum Internal Diameter: 100 mm Tool: -Locating Cone In The Cutter Spindle: HSK-D63 -Diameter Shaping Spindle: 85 mm -Maximum Stroke Length: 30 mm Machine Travel Distances: -Radial (X-Axis): 180 mm -Column Tilting (B-Axis): -1 - +11 Degrees Machine Workpiece Table: -External Diameter: 220 mm -Clamping Diameter: 160 mm Lhedpfxsrtrvye Akusg -Bore: 63 mm Speeds: -Feed Rate X-Axis: 12,000 mm/min -Workpiece Table (C-Axis): 0-400 min-1 -Cutter (C2-Axis): 0-300 min-1 -Spindle Stroke (A-Axis): 500-3,000 min-1 Electrical Equipment: -Operating Voltage: 480V -Supply Voltage: 115V -Control Voltage: 24V -Frequency: 60 Hz -Connected Load of Machine: 35 kVA -Cable Cross-Sectional Area: 35 mm2 -Protection: 80 A Machine Overall Dimensions (L x W x H): 3,380 x 3,950 x 3,015 mm Weight of Machine: 7,800 kg

Condition: good (used), workpiece diameter between centers: 2,286 mm, The No. 61 Angular Hypoid Tester is designed to test large bevel and hypoid gears up to 90" diameter and with shaft angles from 0 - 135 degrees. Spur, helical and internal gears can also be accommodated. The drive or pinion spindle can be rotated in either direction at a recommended spindle speed of 600 RPM. It is mounted in a head which is vertically adjustable on a column, so that the spindle can be offset either above or below the center line of the gear spindle for testing hypoid gears. The pinion head column is adjustable angularly in a horizontal plane to permit testing of gears of any shaft angle from 0 - 135 degrees. Specifications: Centerline of Drive Spindle to Nose of Brake Spindle (90 degrees shaft angle and without face plate): 38-1/2" Max. / 7-5/8" Min. Centerline of Brake Spindle to Nose of Drive Spindle (90 degrees shaft angle and without face plate): 60" Max. / 10" Min. Centerline of Brake Spindle to Nose of Drive Spindle (90 degrees shaft angle and with 54" face plate): 60" Max. / 28" Min. Centerline of Brake Spindle to Centerline of Drive Spindle (For Spur Gears): 56" Max. / 6" Min. Distance Between Nose of Brake Spindle and Nose of Drive Spindle (for spur gears): 36-1/2" Max. / 0" Min. Offset of Drive Spindle Either Above or Below Centerline of Brake Spindle: 10" Range of Shaft Angles: 0 - 360 Degrees Maximum Diameter of Gear: 90" Diameter of Face Plate: 54" Outboard Bearing: 3" Diameter Hole Spindles: RPM of Drive Spindle Pulley Set No. 1: 100 - 400 RPM of Drive Spindle Pulley Set No. 2: 250 - 600 Diameter of Taper Hole (large end): 6" Taper Per Foot: 3/4" Depth of Taper: 8" Lhedpfxortrzde Akujg Hole Through Spindle: 5-1/2" Net Weight of Machine: 20,000# Net Weight of Machine W/Outboard Support and Bed Plate: 24,000#

Condition: good (used), Year of construction: 2013, total length: 3,990 mm, total height: 2,500 mm, total width: 2,280 mm, overall weight: 8,500 kg, INGERSOLL CM SYSTEMS AOHD AGILE OIL HOLE DRILL Equipped with: Siemens 840D Control (2) Drill Heads 20-Tool Rack HSK 50A Taper (2) 7" 3-Jaw Chucks (2) Tailstocks (2) Steady Rests Chip Auger Chip Conveyor Mist Collector Hydraulic System Q R 2 Lube System Air Compressor Specifications: Maximum Length: 1050 mm (41.3") Minimum Length: 180.0 mm (7.1") Maximum Stroke: 250.00 mm Maximum Main Journal Diameter: 115.0 mm (4.5") Maximum Pin Journal Diameter: 100.00 mm (3.9") Lhedpfsrtrx Rjx Akujg Maximum Swing Diameter: 250.0 mm (9.84") X-Axis Travel: 1450 mm (57.1") Y-Axis Travel: 150 mm (5.9")W/HSK 50 Z-Axis Travel: 305.0 mm (12.0") A-Axis Travel: 360 Degree B-Axis Travel: 90 Degree Feed Rate (Z): 1 m/min Maxim (40"/min max) Position Accuracy of X,Y,Z Axes: .010 mm (.00039") Position Accuracy of A & B Axes: .03 Degree Position Repeatability of X,Y,Z Axes: .005 mm (.0002") Position Repeatability of A & B Axes: .005 Degree Spindle Power: 5.5 kW (7.5 hp) Spindle Speed: 0-6,900 RPM Tool Adaption: HSK 50E or A Tool Storage (ATC): 20 Total - 10 Per Spindle W/HSK 50 Lubrication - Slides & Ball Screws: Automatic Central Lubricator Approximate Floor Space (LxWxH): 4.0 x 2.3 x 2.5 m (13.1 x 7.5 x 8.2 Ft) Approximate Machine Weight: 8,500 kg (18,740 #)

Condition: excellent (used), Year of construction: 2023, functionality: fully functional, type of input current: three-phase, total width: 1,321 mm, total length: 1,067 mm, total height: 2,692 mm, input voltage: 240 V, input frequency: 60 Hz, Equipment: documentation/manual, Model NRK-400 In-Line Screw Capping Machine complete with conveyor and guide rails, gripper chains and gripper blocks, four pairs of quills (cap tightening discs), Cap H-26 Hopper/Sorter, cap delivery and application system for 99.8% efficiency. This system can handle both Lug and Screw caps up to 350 caps per minute, depending on product size and condition. The machine can be equipped with steam heating of caps as well as Steam or Gas injection. Compatible with caps ranging from 10-70mm. Include touchscreen controls, power height adjustment, pneumatic "on-the-fly" adjustable clutches, power height adjustable gripper belts, electronically controlled safety switches, Allen-Bradley controls, locking safety interlock switches, container spacing unit, LED safety stack lights, lock out tag out systems. Ljdoyrkdpjpfx Akujhg

Year of construction: 2012, condition: ready for operation (used), functionality: fully functional, machine/vehicle number: BCOR12150, BIESSE BREMA EKO 902 CNC and vertical dowel insertion machine for reduced cycle times Equipment Features - Clamping grippers measure the thickness to adjust drilling depth - Laser-based measuring system for detecting the front and rear panel edges - Length tolerance compensation correcting the workpiece length in X - 5-position tool changer - Drilling head with individually retractable spindles and grooving saw - Diameter: 120 mm - Gluing and dowel insertion units mounted on Y and Z axes Options Lsdpfow Nytnox Akujhg - 4.5 kW electrospindle; 18,000 rpm - Special drilling unit for hinges Technical Data - Panel length: 160 - 3200 mm - Panel width: 35 - 900 mm - Panel thickness: 8 - 80 mm - X/Y/Z axis speed: 100 / 60 / 30 m/min - X axis travel: 3200 mm - Y axis travel: 900 mm - Main spindle power: 4.5 kW - Number of controlled axes: 3 axes - Number of drilling spindles: 20 - Number of tool positions: 5

Condition: used, Year of construction: 2012, Control Siemens 840 D weight of the machine ca. 13,5 t dimensions of the machine ca. 7m x 4m x 2,75m m Accessories: Coolant tank Grinding wheels Various spare parts Operating and maintenance instructions CE conformity Dimensions: 7x4x2.75 m ( LxWxH) TECHNICAL DATA: Workpiece data: max. outer diameter: 250 mm with max. grinding wheels Ø 450 mm max. diameter to be machined over table: 375 mm Profile depth for dressable grinding wheels: 40 mm max. workpiece length: 3,600 mm max. distance between centers (1): 2,800 mm Lhedoxh Rqtopfx Akujg max. bevel angle: +/- 90° Number of teeth of the workpiece: 1 - 999 max. weight of the workpiece: 250 kg Working area: Center distance between workpiece and tool spindle: 355-170 mm Radial travel: 185 mm Axial travel: 3,000 mm Swivel angle: +/- 90°

Condition: like new (used), Year of construction: 2021, operating hours: 200 h, functionality: unexamined, machine/vehicle number: S/ NOS : 248534, 248535, 248536, clamping force: 3,800 kN, screw diameter: 60 mm, displacement volume: 877 cm³, injection weight: 300 g, ejector stroke: 210 mm, plate length: 1,140 mm, plate width: 1,140 mm, overall weight: 20,400 kg, type of input current: three-phase, input frequency: 60 Hz, input voltage: 480 V, year of last overhaul: 2024, number of digital displays: 1, Equipment: CE marking, documentation/manual, unit sold as is where is Two colors injection molding machine (two shots) Three machines available , price is per machine Manf. : Engel Austria Model : e-Motion 740H / 50MV / 420 T Combi US S/ NOS : 248534, 248535, 248536 Year Built : 12/2021 Condition : very good Material : THERMOPLAST Clamping Force : 420 Ton Injection Unit 1 : 740/. H-arrangement Injection Unit 2 : 50/. MV-arrangement Machine Net W : 20 400 Kg Gross Dim of crate : 23’ x 8’ 10” x 9’ 7” (H) Capacity : 427 Ton Shot Size : 10.2 oz Second Shot Size : 0.45 oz Tie Bar Spacing : 30.7" x 30.7" Platen Size : 44.89" x 44.89" Min /Max Mold Height : 45.3"/61" Clamp Stroke : 27.55" Ejector Stroke : 8.26" Control : CC300 Voltage : 480 Min/Max Mold Height : 43.3" - 61.02" 2-Shot Injection Molding Press Main Injection Unit: 10.2 oz (45mm) Secondary Vertical Injection Unit: .45 oz. (18mm) Core Pull Pneumatic Valve Gate Including: Engel Viper Robot Lhjdpfex Szwhox Akusg

Condition: excellent (used), Year of construction: 2010, functionality: fully functional, Two machines in one, made by the best Swiss CNC manufacturer. 1. Log milling 2.Timber Framing. This machine produced machined log structures for 6 years, (dormant since), of high precision and quality, for very discerning buyers. For progressive builders who want to automate milled log structures up to 8" x 12" material, or use strictly for timber framing. Best suited for USA or Canada customer, for easy truck transport. Delivery, set-up, calibration, operational training arranged at cost. Self-contained Compact design, only 10 feet deep, 8 feet wide. All processes are performed inside the enclosure. Cut-offs fall into and are removed from a central pit. Mill shavings are extracted by air suction, leaving work area remarkably clean. Lhodowvwl Aepfx Akueg So quiet, you can have a conversation beside the working machine.

Condition: new, Year of construction: 2025, Entry-level sheet fiber laser metal cutting machine Lower laser cutting cost and easy operation The modular cutting machine table with stiffeners saves time for disassambly and improves convenience and rigidity. The special fiber laser nozzle and cutting process ensure faster carbon steel oxygen cutting, more gas-saving low-pressure stainless steel nitrogen cutting, and better-quality carbon steel air cutting. Fiber laser heads are able to detect jutting obstacles to effectively reduce the damage rate and save the maintenance cost of a laser cutter. Applicable Material: metal Condition: New Laser Type: Fiber Laser Laser Power: 1000W, 1500W, 2000W, 3000W Cutting Area: 3000*1524mm Positioning accuracy: ±0.05mm Repositioning accuracy: ±0.03mm Cutting Speed: 0-100m/min Graphic Format Supported: AI, BMP, Dst, Dwg, DXF, DXP, LAS, PLT Lodpfehwrgtjx Akushg CNC or Not: Yes Cooling Mode: WATER COOLING

Condition: used, functionality: fully functional, Specifications: - (54) 22'' x 8'' x 3'' - 7.5 kg capacity moulds on transfer chain - Propane burner Lhodjwtzpyopfx Akusg - CSA approved

Condition: good (used), Year of construction: 2006, voltage 110 - 230 V frequency 50 - 60 Hz Power connection 0,5 kVA weight 150 kg dimensions of the machine ca. 1,0 x 0,8 x 1,75 m Stick blade profile control unit - Control via PC control with Windows XP operating system - Digital drive amplifiers, linear motors and measuring systems - Fully automatic position determination of the cutting edges and axis position of the stick blade - Measurement of almost all single-part and continuous processes required for spiral bevel gears and hypoid gears - Machine concept designed for the shortest set-up and changeover lines and maximum measuring accuracy - Combination probe for measuring tip and surface measurement - Integrated drawer for accessories - Keyboard integrated in flat drawer - Operating elements and PC protected against unauthorized access with lockable Lhjdsymfz Sopfx Akuog cabinet element

Condition: good (used), Year of construction: 2002, Clampable cutter head type (max.) 460 mm Cutter head weight (max.) 150 kg Mounting disc diameter for cutter heads (Ø) 360 mm Mounting cone for cutter heads Nominal diameter Ø 58,227 mm travel -z axis 200 mm diagram-drawing enlargement ±10 - ± 500 µm weight of the machine ca. 2,3 t dimensions of the machine ca. 2 x 1,5 x 2,03 m In the manufacturing process for spiral-toothed bevel gears, the quality of the gear cutting gear cutting tools used plays a decisive role. Particularly in high gear cutting quality and a long service life can only be achieved with precisely can only be achieved with precisely adjusted cutterheads. The Oerlikon cutterhead setting and testing device CS 200 enables quick and easy setting of the individual knives and simple adjustment of the individual knives, it checks the position and documents the measurement results. The measuring sequence on the CNC-controlled testing device is partially automated: The individual actions for carrying out the actions for carrying out the sequence are displayed on the screen via the operator guidance. The positioning of the individual knives in the cutter head and the height of the knife tips is largely automatic thanks to a special sequence and is simultaneously documented by means of a run-out diagram. A subsequent measuring sequence checks the radial position of the inner and outer cutting edges of all knives in the cutterhead. If individual test parameters on the knives do not correspond to the the tolerance specifications, this can be individually repositioned. The combination of semi-automated setting sequence, operator-guided set-up actions and automatic operator-guided set-up actions and automatic measuring sequence, cutterheads can be can be set conveniently, quickly and with high precision. Lhsdpow N S E Aefx Akusg Operator-guided setting and test sequence - Graphic display of the cutter head design and the measurement results with tolerance check - Instructions for the operator in plain text Instructions for the operator in plain text (without coded information) - Simple assignment of the measurement results to the knives - Documentation of the setting and measurement results via printer- Setting and test sequence suitable for ARCON®, RSR, Spirapid, SPIRON®, TRI-AC® types - Interface for neutral data

Year of construction: 1994, condition: good (used), machine/vehicle number: 491P, Technical data: - Drilling capacity in steel ST 60 28 mm - Drilling capacity in steel ST 60 32 mm - Drilling spindle adaptor MK 3 - right - left rotation - Drilling spindle stroke 150 mm - drilling spindle speed infinitely variable 80 - 1170 rpm - 2 feeds 0,1 / 0,2 mm/rev - throat 290 mm - max distance table - drilling spindle 780 mm - table with 2 T-slots 480 x 400 mm - Height adjustable via toothed rack with hand crank - Drive 400 V / 0,9 / 1,3 kW Lhededkx Anopfx Akujg - Space requirement approx. W 600 x H 2100 x D 900 mm - Weight approx. 420 kg - with: - coolant device - quick-action drill chuck 1-13 - illumination

Condition: used, Year of construction: 1988, x-travel 870 mm y-travel 370 mm z-travel 400 mm table-size 310 x 1370 mm Ledpfx Aksxlkw Ujujhg distance vertical spindle / table 50 - 450 mm feed - longitudinal/cross 20 - 800 mm/min 9 - 355 mm/min rapid traverse longitudinal and cross 3000 / 1375 mm/min spindle taper SK 50 spindle turning speed range 40 - 1750 U/min spindle speed: 12 Stück total power requirement 5,5 kW weight of the machine ca. 2,4 t dimensions of the machine ca. 1,9 x 2,0 x 1,5 m - Powerful CNC universal milling machine - Includes Fanuc control system - Kneading milling head - Automatic feeds on X/Z/Y axes - Central lubrication system - Coolant system - Pivoting machine light - Splash guard tray - Separate transformer

Condition: new, Year of construction: 2022, Base sheet fiber laser metal cutting machine with full protection Maximum cutting area reaches up to 12000mm*2500mm, suitable for a variety of cutting options. The special fiber laser nozzle and cutting process ensure faster carbon steel oxygen cutting, more gas-saving low-pressure stainless steel nitrogen cutting, and better-quality carbon steel air cutting. Cutting performance and efficiency are improved by maintaining gas flow steady with little turbulence. Fiber laser heads are able to detect jutting obstacles to effectively reduce the damage rate and save the maintenance cost of a laser cutter. Lsdjhwhfqspfx Akuohg The cutting process works even at the edge of thin sheets, and ensures no chatter marks. With One-click Processing, one laser cutter is able to process multiple sheets in batches with a one-off setup, achieving batch processing. Condition: New Laser Type: Fiber Laser Laser Power: 1000W - 40000W Cutting Area: 3048*1524mm - 12500*2600mm Cutting Speed: 0-110m/min Positioning accuracy: ±0.05mm Repositioning accuracy: ±0.03mm Graphic Format Supported: AI, BMP, Dst, Dwg, DXF, DXP, LAS, PLT CNC or Not: Yes Cooling Mode: WATER COOLING

Condition: used, Year of construction: 1965, bore capacity in steel (diameter) 40 mm total power requirement 4 kW Lodpfx Ajv S Iqcokuohg

Condition: new, Year of construction: 2025, Entry-level sheet fiber laser metal cutting machine Lower laser cutting cost and easy operation The modular cutting machine table with stiffeners saves time for disassambly and improves convenience and rigidity. The special fiber laser nozzle and cutting process ensure faster carbon steel oxygen cutting, more gas-saving low-pressure stainless steel nitrogen cutting, and better-quality carbon steel air cutting. Fiber laser heads are able to detect jutting obstacles to effectively reduce the damage rate and save the maintenance cost of a laser cutter. Lhodpfx Akehv Hkaouog Applicable Material: metal Condition: New Laser Type: Fiber Laser Cutting Area: 3000*1500mm Cutting Speed: 0-40000mm/min Graphic Format Supported: AI, BMP, Dst, Dwg, DXF, DXP, LAS, PLT Cutting Thickness: 0-30mm CNC or Not: Yes Cooling Mode: WATER COOLING

Condition: used, Year of construction: 2006, input voltage: 400 V, input current: 7 A, input frequency: 50 Hz, We offer this used Varimixer Bear ERGO AE10UVL3 stirring and beating machine, year of construction 2006. Machine type: AE10UVL3 Machine number: 100006642 Motor power: 3.0 kW Ledpfxsy Nczcs Akuehg Motor current: 7.5 A Number of phases: 3 Frequency: 50 Hz Voltage: 230/400 V Production year: 2006 We have three Varimixer Bear Ergo Series Planetary Mixers available to close down our factory up north in Iceland (where the machines are located). These premium, Danish-built machines are designed for powerful, consistent mixing with top-tier ergonomics and safety, reducing operator strain and injury risk. With durable construction, hygienic design, and versatile attachments, they deliver long-term value for busy commercial kitchens and bakeries. We also have the following items listed on the side. Hoba B.v. HSA 5 (year 2012), Kemper Multimatic (year 2004), Rondo ZGP665.C (year 2000) All these items are available together, plus the mixers for 60,000 EUR, plus packaging and shipping. If you have any questions or need more information, feel free to send us a message or give us a call.

Condition: reconditioned (used), Year of construction: 1998, functionality: fully functional, Gietz FSA 790 EFF high speed foil stamping , embossing and die cutting machine Offered fully reconditioned by exclusive Gietz UK distributor Max format 790 x 560 mm : max speed 6,000 sheets / hr Lhjdpey T Ngtefx Akueg High speed MABEG suction feeder : 6 heating zones : 3 x electronic servo longitudinal foil feeds : 3 line hologram capability : Full impression and register tested before supply Carries distributor's warranty

Condition: excellent (used), Year of construction: 2013, operating hours: 11,000 h, functionality: fully functional, travel distance X-axis: 400 mm, travel distance Y-axis: 435 mm, travel distance Z-axis: 500 mm, rapid traverse X-axis: 36 m/min, rapid traverse Y-axis: 36 m/min, rapid traverse Z-axis: 30 m/min, feed rate X-axis: 15 m/min, feed rate Y-axis: 15 m/min, feed rate Z-axis: 15 m/min, nominal power (apparent): 54 kVA, torque: 117 Nm, controller manufacturer: Fanuc, controller model: i Series, workpiece height (max.): 200 mm, workpiece diameter (max.): 300 mm, total height: 300 mm, total length: 2,465 mm, total width: 2,835 mm, table width: 200 mm, table load: 60 kg, rotary table diameter: 200 mm, overall weight: 5,500 kg, spindle speed (min.): 120 rpm, spindle speed (max.): 12,000 rpm, operating hours of spindle: 11,000 h, coolant supply: 20 bar, spindle nose: DIN40, number of spindles: 1, number of slots in tool magazine: 30, tool length: 300 mm, tool diameter: 125 mm, tool weight: 8 g, input voltage: 400 V, type of input current: three-phase, Equipment: chip conveyor, documentation/manual, rotational speed infinitely variable, 2013 Doosan DNM 200/5AX 5 Axis CNC Machining Centre Used 2013 Doosan DNM 200/5AX (4+1) 5-axis CNC machining centre with Fanuc i Series control, probe, tool holders, spindle chiller, transformer, swarf conveyor and only 11,000 run time hours. Manufacturer: Doosan Model: DNM200/5AX Machine Type: 5 Axis (4+1) Machining Centre Year: 2013 Control: Fanuc Series i Control Hours: 11,000 Run Time Hours Machine Description 2013 Doosan DNM 200/5AX CNC Machining Centre, a compact, high-performance 4+1 - 5-axis vertical machining centre ideal for precision engineering, toolmaking, aerospace, medical, motorsport, mould and die, and complex component machining. This machine is fitted with a Fanuc i Series CNC control and has only 11,000 run time hours, making it an excellent opportunity for manufacturers looking for a reliable used 5-axis machining centre with strong capability, premium features and valuable accessories included. The Doosan DNM 200/5AX is well known for combining compact footprint, rigid construction and 5-axis positioning. It is ideal for reducing setups, machining complex parts and increasing productivity compared with conventional 3-axis machining. Key Features 2013 Doosan DNM 200/5AX Lhedpjy St Sdjfx Akueg 4+1 5 Axis CNC Machining Centre Fanuc i Series Control Only 11,000 Run Time Hours Includes Renishaw OMP60 probe Includes tool holders Includes spindle chiller Includes transformer Includes swarf conveyor Compact 5-axis machining solution Ideal for complex component machining Technical Specifications X Axis Travel: 400 mm Y Axis Travel: 435 mm Z Axis Travel: 500 mm A Axis Travel: 150 Deg (+30 to -120Deg) C Axis Travel: 360 Deg Table Diameter: 200 mm Max Load on Table: 60 kg Max Workpiece: 300mm Dia x 200mm High Spindle Speed: 12,000 rpm Spindle Taper: DIN40 Pullstud: Nikken PS-806 Tool Capacity: 30 Station ATC Rapid traverse (X, Y): 36000mm/min Rapid traverse (Z): 30000mm/min Rapid traverse: (A - tilt axis) 20 rpm Rapid traverse: (C – rotary axis) 30 rpm Maximum feedrate: (X, Y, Z) 15000mm/min Maximum feedrate: (A, C) 7200 deg/min Feedback system: Absolute encoder Max Tool Diameter: 125mm Max Tool Length: 300mm Max Tool Weight: 8kg Spindle motor AC: 11/18.5kW Axis motor (XYZ): AC 4.0kW Axis motor (A axis): AC 3.0kW Axis motor (C axis): AC 1.6kW Power Requirements: 54.0 kVA Air Pressure: 6kgf/cm2 Machine Dimensions: 2465 x 2835 x 3091mm Approx. Machine Weight: 5,500 kg Run Time Hours: Approx. 11,000 hours Included With This Machine Renishaw OMP60 Probe Tool holders Spindle chiller Transformer Swarf conveyor Fanuc i Series CNC control Why Buy This Doosan DNM 200/5AX? This machine is a strong choice for companies searching for a used 5 axis CNC machining centre, used Doosan machining centre, Doosan DNM 200/5AX for sale, or compact 5-axis vertical machining centre. The 4+1 machining capability allows users to machine multiple faces of a component in fewer setups, helping to reduce handling time and increase production efficiency. With a compact table, high spindle speed and Fanuc control, this machine is particularly suited to small to medium batch production and complex prismatic parts. Applications This Doosan DNM 200/5AX is suitable for: Aerospace components Medical components Motorsport parts Toolroom machining Mould and die work General subcontract machining Complex 4+1 machining Notes: *Specifications are given in good faith but not guaranteed*

Condition: excellent (used), Year of construction: 2018, operating hours: 1,000 h, functionality: fully functional, machine/vehicle number: 16236/1, nominal power (apparent): 480 kVA, Great framer Ledpfxsyngpge Akuohg

Condition: excellent (used), Year of construction: 2019, 2019 Holz-Her 7017K CNC Machining Center Lsdpfx Akoy Symnjuehg Serial Number: 207/1-903; Series: BAZ19V2; Machining Dimensions (Edge Routing): in X=3.540 mm / in Y = 1.287 mm (minus cutter radius): Cutter unit: 6.5 kW ceramic bearings, 1.000 - 18.000 RPM; Vector speed: 100 m/min; Protection equipment: Light grid (1-field machining); Workpiece support: 6 consoles, incl. 8 stops, Laser pointer; Drilling head: 14 Spindle (10V | 4 H), Incl, sawing unit for grooving in X-direction; Workpiece clamping: 100 m3/h vacuum pump, low maintenance dry-running pump; Tool changer: 12-compartment Pick-up tool changer with tool cover; Software: CAMPUS software package, incl. aCADemy, CAD/CAM module.

Condition: used, Year of construction: 2008, 2008 Hardinge Bridgeport XV710 CNC Vertical Machining Centre With Siemens 810D Control Table Dimension 760 x 420mm (3 'T' Slots). 'T'-Slot Dimension 16mm. Maximum Table Load Approx 450kg. Axis Travel 'X'=711mm, 'Y'=457mm, 'Z'=457mm. Spindle Nose To Table Min/Max 150-580mm. Rapid Traverse 'X'=36m/min, 'Y'=36m/min, 'Z'=36m/min. Maximum Cutting Feedrate 12,000mm/min. Maximum Spindle Speed 10,000rpm (10HP Motor). Spindle Taper ISO 40 BIG-Plus. 20 Position ATC. S/No. 080011WM (2008). Lhedpfey Sygujx Akusg With Coolant System, Renishaw NC4 Laser Tool Presetter, Filtermist FX4000 Mist Extraction Unit, Signal Tower, Lubrication Grease (Direct Drive). & Handwheel. Weight 3,900kg.

Condition: excellent (used), Year of construction: 2013, 2013 Quaser MF400 5 Axis CNC Vertical Machining Centre with Tilting Rotary Table with Siemens 828D CNC Control Tilting Rotary (Trunnion) Table Dimension Ø320mm (4 'T' Slots). Maximum Swing Ø400mm. Maximum Table Load 100Kg. Axis Travel 'X'=410mm, 'Y'=610mm, 'Z'=510mm, 'A'=+30/-120Deg, 'C'=360deg. Rapid traverse 'X/Y'=36 m/min, 'Z'=25m/min. MAximum Cutting Feedrate 20m/min. Maximum Spindle Speed 15,000rpm (Motor 15/20HP). Spindle Taper BT40. ATC Capacity 30 Tools. Maximum Tool Ø76mm (Ø125mm non Adjacent Tools), Maximum Tool Length 280mm. S/No. (TBC) (2013) Lhedpfxoy Sya Uo Akujg With Through Spindle Coolant, Filtermist FX6002 Mist Extraction Unit, Renishaw Spindle Probe Interface, Hand Wheel & Signal Tower. Note: Tooling & Work Holding Not Included.
