Used Angular Window Machining Center for sale (75,326)

Condition: good (used), Code: 0321 Brand: SCM Model: MULTIFLEX C - CE Standard Automatic working center for window frames for tenoning, profiling and contouring - Max workpiece thickness mm 140 - CE Standard Technical data Automatic carriage with chipbreaker Max working length 2800 mm Min/max workpiece thickness 30/140 mm End cutting saw diameter 400 mm - Motor Hp 4 Hnsdpfeytn U Iox Agyjk Tenoning spindle useful length mm 320 - Motor Hp 10 Spindle diameter mm 50 Max tool diameter mm 350 Profiling spindles: 1° Anti-splinter profiling spindle length 320 mm - Motor Hp 7,5 - Tool diameter mm 220 2° profiling spindle length mm 320 - Motor Hp 7,5 - Tool diameter mm 220 Min and max diameter of profiling spindles tools mm 100/220 Profiling spindles diameter 50 mm Tool group Zuani Variable speed feed Glazing bead recovery group - Motor Hp 3 - Diameter of suction mouth mm 50 Overall dimensions mm 2400 x 3300 x 2000 h Weight kg 2200

Condition: ready for operation (used), Year of construction: 1988, Window manufacturing machine Hsdpfxoyk Haqe Agysnk Manufacturer: Okoma Model: UF1 S Year of manufacture: 1988 with tool

Condition: used, Year of construction: 2005, functionality: fully functional, length stop: 3,200 mm, tool diameter: 400 mm, spindle diameter: 50 mm, spindle stroke: 640 mm, spindle speed (max.): 3,000 rpm, milling spindle length: 320 mm, saw blade diameter: 400 mm, height adjustment type: electric, type of input current: AC, working height: 130 mm, working width: 200 mm, SCM Windor 60/100 – Angle Processing Center Manufacturer: SCM Group Year of manufacture: 2005* 1. General Description of the System The system in question is a window and door production line of the type Windor 60/100 from the manufacturer SCM Group, built in 2005. It is a CNC-controlled angle processing center designed for the industrial machining of frame and sash components. The system is configured for series production and enables precise, repeatable machining in integrated process steps. 2. Main Components of the System 2.1 SCM Windor 60/100 Angle Processing Center The SCM Windor 60/100 features a modular design and is configured as an angle processing unit. Machining takes place on a tenoning side and a profiling side positioned at right angles to each other. The system combines several machining steps – such as milling, drilling, grooving, rebating, and tenoning – in a fully integrated, CNC-controlled process. Key Features: * CNC multi-sided machining * Multiple milling and processing spindles * Automated tool handling and changeover * High dimensional accuracy and repeatability 2.2 Fleximat Drilling Center The Fleximat drilling center is integrated into the system and is used for the precise execution of boreholes for joints and fittings. Machining is CNC-controlled with both vertical and horizontal drilling units. 2.3 Profiler Center The profiler center is designed for contour-forming milling operations and consists of two processing sides: Right side: * Lifting spindle with height adjustment * Suitable for variable profile and contour processing Hnedpsx Nqqxofx Agyok Left side: * 24-position tool changer * Automatic tool changing to minimize setup times * Suitable for complex profile milling 2.4 Löwer Surface Sanding Machine A surface sanding machine from Löwer is integrated into the production line. The machine is used exclusively for surface sanding, serving to improve the surface quality of the processed workpieces. 3. Control, Operation, and Safety The system is equipped with a CNC control unit that manages all machining operations, tool changes, as well as feed and spindle movements. Operation is semi- or fully-automated by trained personnel. The safety features are state-of-the-art as of the time of construction (2005) and include, in particular: * Mechanical guards and enclosures * Emergency stop devices * Safety locks on moving machine parts 4. Optional Expansion: SCM Topset XL Planer (10-spindle) For expansion of the existing machinery, provision has been made for a SCM Topset XL planer with 10 spindles. This machine will be operated as a standalone processing station at a separate location within the production hall and is not directly integrated into the CNC control of the Windor system. The system is available and can be dismantled at any time. Dismantling and transportation are to be organized by the buyer. Available from 07.01.2026

Condition: good (used), Year of construction: 2007, Technical characteristics : - Max machinable length 3200 mm - Minimum machinable length 200 mm - Maximum width 200 mm - Minimum width 40 mm - Maximum workpiece height 130 mm - Depth with max Ø to tenon 320 mm: 105 mm - Tenoning carriage speed min / max 0/100 m / min - Min / max profiling speed: 3/15 m / min Tenoning: 1- end cut saw 5.5 hp (4 kW) Saw Ø 400 mm 2- tenoning router Counter bearing 50 x 620 mm 15 hp (11.3 kW) Max tool Ø 320 mm Axle stroke 575 mm Automatic splinter guard 3- tenoning router Counter bearing 50 x 620 mm Hnjdpfx Ajt R T Hcjgysk 15 hp (11.3 kW) Max tool Ø 320 mm Axle stroke 575 mm Automatic splinter guard Vertical positioning with continuous axis 4- Digital angular adjustment clamp Profiling: 5-: router to be profiled on the right Shaft 50 x 320 mm 10 hp (7.5 kW) Ø tools 130/240 mm Axle stroke 280 mm Time-delayed anti-shattering intervention during calibration Double direction of rotation Vertical and horizontal positioning with continuous axis 6-: router to be profiled on the right Shaft 50 x 320 mm 10 hp (7.5 kW) Ø tool 130/240 mm Axle stroke 280 mm Vertical and horizontal positioning with continuous axis 7-: router to be profiled on the right Shaft 50 x 320 mm 10 hp (7.5 kW) Ø tool 130/240 mm Vertical and horizontal positioning with continuous axis 8-: close-out recovery group Vertical and horizontal positioning with continuous axis Device for extracting the shutter 9-: lower horizontal shaft for groove Vertical and horizontal positioning with continuous axis 88.5 hp (66.4kW) 10-: digital guide 11-: Return of parts to the operator NO TOOLS AVAILABLE OBTAIN ADDITIONAL PHOTOS NOTE: SUBJECT TO CHANGES IN TECHNICAL DATA

Condition: good (used), Year of construction: 2005, functionality: fully functional, feed length X-axis: 3,200 mm, spindle diameter: 60 mm, spindle speed (max.): 6,000 rpm, power of the milling unit: 7,500 W, rotational speed (max.): 6,000 rpm, total height: 600 mm, space requirement width: 8,000 mm, space requirement length: 7,000 mm, overall weight: 15,500 kg, milling spindle length: 600 mm, saw blade diameter: 400 mm, power: 70 kW (95.17 HP), input voltage: 380 V, height adjustment type: electric, power of feed motor: 7,700 W, working height: 120 mm, working width: 160 mm, high-performance window production machine, with 2 tappers and two right and one left profiling shaft, produces direct windows in thicknesses of 68-88-130 mm. Delivery by appointment Hsdotp Dngopfx Agyenk

Condition: excellent (used), Year of construction: 1995, functionality: fully functional, input voltage: 230 V, type of input current: three-phase, working height: 150 mm, We offer this very well-maintained SCM Multiflex C window and door machining center, year of manufacture 1995. Purchase date: June 1995 Tenoning carriage power: 15 hp Profiling spindle power: 10 hp each Tenoning spindle height: 320 mm Profiling spindle height: 320 mm Electrical connection: 3x230 V Glazing bead recovery system Hnedpfoyvhnuex Agysk The machine is still in very good working order. It has had only one owner throughout all these years, used exclusively in a family carpentry workshop (father and son). Therefore, the machine is certainly not worn out. Reason for sale is the modernization of the machinery fleet. A new SCM corner joint machine has been acquired. The machine remains fully operational and can be inspected and tested until June. All features and functions are still intact. Sold without tooling (cutters).

Condition: excellent (used), Year of construction: 1989, functionality: fully functional, WEINIG Unicontrol UC 10-5 Window Production Machine 1. Electronically controlled crosscut saw with laser switching between saw cutting and zero-point wheel, 3 kW motor 2. Grooving spindle 50 x 630 mm for tools 6 x 80 mm, 15 kW motor 3. Longitudinal/synchronous profiling spindle 50 x 320 mm for tools 4 x 80 mm, 11 kW motor 4. Grooving spindle (between 1st and 2nd lifting spindle), D = 40 x 40 mm, axially indexed, 3 kW motor 5. Longitudinal profiling spindle 50 x 320 mm for tools 4 x 80 mm, 11 kW motor 6. Longitudinal profiling spindle 50 x 320 mm for tools 4 x 80 mm, 11 kW motor 7. Clamping spindle 40 x 150 mm, 3-position axial cycle, 2-position radial cycle, 3 kW motor Saw and grooving spindle on the right side, 3 kW motor Hardware spindle 40 x 150 mm, 3 kW motor Adjustable feed speed 6-12 m/min, 1.1 kW motor 4-position counter changer Electronic length stop, 3600 mm Workpiece return system with automatic rotating mechanism Automation package Interval-controlled sash support Hjdpoxmr N Isfx Agyenk Double parts package Laminated fabric tables (for sanded surfaces) Pressure guide on the left, max. wood width difference 100 mm Machine in very good technical and visual condition

Year of construction: 1998, condition: ready for operation (used), An angular system for Weinig window and door production is available. Max. tool outside diameter: 320mm, max. tool flight circle: 232mm, slotted spindle length: 640mm, profiling and synchronized spindle length: 285mm-320mm, control: Siemens WS400. Including complete tooling and style window. Documentation available. Hsdpfotq U A Isx Agyonk

Condition: excellent (used), CNC Woodworking Center. Hnjdowmxkhspfx Agysk

Condition: new, Year of construction: 2025, table length: 900 mm, table width: 450 mm, number of spindles: 1, spindle speed (min.): 8,000 rpm, table load: 500 kg, VMC 650 CNC machining center, milling machine with CNC system VMC 650 machining center is a multifunctional equipment that allows you to perform milling, drilling, thread cutting, and turning operations in automatic mode (if these options are available in the machine). The VMC 650 milling machine can have 16- or 24-position tool magazine. Depending on the customer's wishes, the milling machine can be equipped with a GSK, Siemens or Fanuc CNC system. It is possible to optionally add a Y-axis drive. As a very convenient additional option, we recommend installing a chip conveyor that will save you time when working with the equipment. Technical parameters: Worktable size 900x450mm Maximum workpiece weight 500 kg Movement along the axes X/Y/Z 800/450/500 mm Maximum distance from the spindle to the table surface 120-620 mm Motor power 5.5-7.5 kW Maximum spindle speed 8000 rpm Spindle type BT40 Positioning accuracy ±0.008/300 mm Repeatability ±0.005 mm Machine dimensions 300022752550 mm Machine weight 4000 kg It is also possible to supply CNC milling machines, machining centers with other table sizes: VMC 850 table 1000x500 mm VMC 855 table 1000x550 mm VMC 1060 table 1200x600 mm VMC 1160 table 1200x600 mm VMC 1275 table 1300x700 mm VMC 1370 table 1400x700 mm VMC 1580 table 1600x800 mm VMC 1680 table 1700x800 mm Hodpfxoxc I Dgs Agyenk VMC 1890 table 2000x900 mm

Condition: good (used), Year of construction: 1997, functionality: fully functional, We offer an nice condition Matsuura with tools and accessoriess, very atractive machine for a serious work. Description Matsuura MC600VF Vertical Machining Centre in great working condition ready to use. COOLING TROUGH SPINDLE including Large Qty of BT40 Tooling (33 TOOLS, Universal 3D Tester. Country of Origin: Japan. Spindle Chiller WASTE CONVEYOR with Yasnac i80M Control Hjdpfxjvkx Rks Agyenk 20 Position: ATC BT40 : Taper Specifications Manufacturer MATSUURA Model MC600VF Year 1997 Condition Used Serial Number 970112285 Table size 870 x 400mm Coolant tank X = 600 Y = 410 Z = 470mm Spindle speeds 30 – 15000 rpm.

Condition: ready for operation (used), Year of construction: 2001, functionality: fully functional, travel distance X-axis: 510 mm, travel distance Y-axis: 510 mm, travel distance Z-axis: 460 mm, controller model: Mazatrol Fusion 640M, spindle speed (max.): 12,000 rpm, TECHNICAL DETAILS Travel X-axis: 510 mm Travel Y-axis: 510 mm Travel Z-axis: 460 mm Swivel range A-axis: +30° / -120° Rotation range C-axis: +/- 360° Feed rate range (X-/ Y-/ Z-axis): 1 - 50,000 mm/min Rapid traverse (X-/ Y-/ Z-axis): 50 m/min Indexing A and C: 0.001° Swivel time 90° A/C: 1.9 / 1.5 s Main spindle Max. spindle speed: 12,000 rpm Spindle drive power: 22/15 kW Tool holder: ISO 40 Spindle diameter: 80 mm Acceleration time to max. speed: 1.7 s Worktable Clamping surface: 500 x 400 mm Number of T-slots: 5 T-slot width: 18 mm T-slot spacing: 80 mm Distance from spindle to table: 190 - 650 mm Max. workpiece size: 500 x 500 x 405 mm Max. table load: 300 kg Hnjdpfxjyxmq Te Agysk Tool changer Max. number of tool positions: 40 Max. tool diameter: 80 mm Max. tool diameter with adjacent spaces free: 125 mm Max. tool length: 300 mm Max. tool weight: 8 kg Tool change time: 4.5 s MACHINE DETAILS Control: Mazatrol Fusion 640M Total power requirement: 51 kVA Dimensions & Weight Space requirement: 3.4 x 3.7 x 2.8 m Machine weight: 7.5 t EQUIPMENT Hydraulic unit Coolant system Chip tray Tool measurement Documentation

Condition: ready for operation (used), Year of construction: 1998, functionality: fully functional, travel distance X-axis: 1,250 mm, travel distance Y-axis: 880 mm, travel distance Z-axis: 800 mm, controller model: TNC 426 Heidenhain, spindle speed (max.): 12,000 rpm, TECHNICAL DETAILS Travel Range X-axis: 1,250 mm Travel Range Y-axis: 880 mm Hnsdpfx Agjyxmmnoyjk Travel Range Z-axis: 800 mm Main Spindle Max. Speed Range: 12,000 rpm Drive Power: 15 / 10 kW Max. Torque: 500 Nm Tool Holder: SK 40 Work Table Clamping Surface: 1,500 x 1,050 mm Max. Table Load: 2,500 kg Number of T-slots: 10 T-slot Width: 18 H7 mm T-slot Pitch: 100 mm Tool Changer Number of Tool Stations: 30 Max. Tool Diameter: 80 mm Max. Tool Diameter with Empty Adjacent Pocket: 160 mm Max. Tool Length: 315 mm Max. Tool Weight: 8 kg Max. Total Weight: 100 kg Feeds Rapid Traverse (X / Y / Z axis): 15 m/min Feed Rate: 10,000 mm/min MACHINE DETAILS Control Model: TNC 430 Heidenhain Total Power Requirement: 29 kW Dimensions & Weight Space Requirement: approx. 7.0 x 5.0 x 3.3 m Machine Weight: approx. 16.0 t EQUIPMENT Documentation Chip Conveyor Coolant System High-Pressure Coolant Measuring Probe (Manufacturer: Heidenhain) Internal Coolant Supply Note: The transport rigging must be arranged by the buyer!

Condition: ready for operation (used), Year of construction: 1999, functionality: fully functional, machine/vehicle number: 669, travel distance X-axis: 560 mm, travel distance Y-axis: 510 mm, travel distance Z-axis: 510 mm, controller model: MSC 502, rotational speed (max.): 12,000 rpm, TECHNICAL DETAILS Travel X-axis: 560 mm Travel Y-axis: 510 mm Travel Z-axis: 510 mm Distance spindle center to table: 50 – 650 mm Distance spindle nose to table center: 100 – 610 mm Main spindle Max. speed: 12,000 rpm Drive power: 22 / 18.5 kW Tool holder: MAS BT-40 Spindle bearing diameter: 70 mm Pallet changer Number of pallets: 2 Pallet size: 400 x 400 mm Hnsdpfx Agsyxm Irjysk Max. workpiece diameter: 580 mm Max. workpiece height: 650 mm B axis Indexing time 90°: 2.5 sec Pallet change time: 6.0 sec Tool changer Number of tool stations: 60 positions Max. tool diameter: 80 mm Max. tool diameter with adjacent station empty: 125 mm Max. tool length: 300 mm Max. tool weight: 8 kg Tool-to-tool change time: 1.5 sec Chip-to-chip time: 3.7 sec Rapid traverse (X/Y/Z): 32 m/min Feed rate: 1 – 24,000 mm/min Creep feed rate: 0 – 1,260 mm/min MACHINE DETAILS Control: MSC 502 Total power requirement: 63 kVA Dimensions & Weight Required space approx.: 5.5 x 4.5 x 2.7 m Machine weight approx.: 9.0 t EQUIPMENT Documentation Chip conveyor Coolant system High-pressure coolant Internal coolant supply Tool magazine: 60 positions Pallet changer Pallets: 2 Signal lamp B axis Hydraulic unit Spindle oil cooler Note: The loading shaft must be supplied by the buyer.

Condition: ready for operation (used), Year of construction: 1999, functionality: fully functional, travel distance X-axis: 1,250 mm, travel distance Y-axis: 880 mm, travel distance Z-axis: 800 mm, controller model: TNC 430 Heidenhain, spindle speed (max.): 12,000 rpm, TECHNICAL DETAILS Travel range X-axis: 1,250 mm Travel range Y-axis: 880 mm Travel range Z-axis: 800 mm Main spindle Max. speed range: 12,000 rpm Drive power: 15 / 10 kW Max. torque: 500 Nm Tool holder: SK 40 Work table Clamping area: 1,500 x 1,050 mm Max. table load: 2,500 kg Number of T-slots: 10 T-slot width: 18 H7 mm T-slot spacing: 100 mm Tool changer Number of tool stations: 60 Max. tool diameter: 80 mm Max. tool diameter with free adjacent station: 160 mm Max. tool length: 315 mm Max. tool weight: 8 kg Max. total weight: 100 kg Feeds Rapid traverse (X / Y / Z-axis): 15 m/min Feed rate: 10,000 mm/min Hnodpfoyxmd Tex Agyok MACHINE DETAILS Control model: TNC 430 Heidenhain Total power requirement: 29 kW Dimensions & Weight Space requirements: approx. 7.0 x 5.0 x 3.3 m Machine weight: approx. 16.0 t EQUIPMENT Documentation Chip conveyor Coolant system Tool changer Note: Transport tackle must be organized by the buyer!

Condition: not inspected (used), Year of construction: 2001, functionality: unexamined, machine/vehicle number: 822441, travel distance X-axis: 1,020 mm, travel distance Y-axis: 510 mm, travel distance Z-axis: 600 mm, controller model: HEIDENHAIN TNC 410 PA, spindle speed (max.): 6,000 rpm, No reserve price - guaranteed sale to the highest bidder! By placing a bid, you are obliged to collect the item on time, either between 11.05.2026 and 13.05.2026 or between 18.05.2026 and 21.05.2026! TECHNICAL DETAILS Travel distances Travel X: 1,020 mm Travel Y: 510 mm Travel Z: 600 mm Spindle speed range: 40–6,000 rpm Drive power: 13 kW Spindle taper: BT 40 Number of tool stations in the tool changer: 22 Rapid traverse X and Y axes: 40 m/min Rapid traverse Z axis: 30 m/min Work table Length: 1,150 mm Width: 490 mm MACHINE DETAILS Control system: HEIDENHAIN TNC 410 PA Dimensions & Weight Dimensions (L x W x H): 2,800 x 2,400 x 2,400 mm Weight: 4,800 kg EQUIPMENT 3D probe Note: The machine vices mounted on the work table and the tool holders, including the tools installed in the tool magazine and spindle, are not included in the scope of sale and delivery. The oil mist extractor, which may be visible in the photos, is also not included in the scope of sale and delivery. Hnodeyn Nvvspfx Agyjk

Condition: not inspected (used), Year of construction: 2000, operating hours: 8,523 h, functionality: unexamined, travel distance X-axis: 1,000 mm, travel distance Y-axis: 500 mm, travel distance Z-axis: 500 mm, spindle speed (max.): 10,000 rpm, number of slots in tool magazine: 22, No reserve price – guaranteed sale to the highest bidder! Bidding obligates the buyer to collect the machine on time, either between 11.05.2026 and 13.05.2026 or between 18.05.2026 and 21.05.2026! Hnodpfxjyn Nwte Agysk TECHNICAL DETAILS Travel distance X: 1,000 mm Travel distance Y: 500 mm Travel distance Z: 500 mm Table dimensions: 1,150 x 490 mm Number of tool positions in the magazine: 22 Spindle taper: SK 40 (DIN 69871-A40) Max. spindle speed: 10,000 rpm MACHINE DETAILS Control: HEIDENHAIN TNC 426 Dimensions & Weight Dimensions (L x W x H): 4,500 x 3,500 x 2,700 mm Weight: 4,200 kg Operating Hours Automatic operation: 8,523 h Control on-time: 71,860 h EQUIPMENT Technical documentation Spare parts (as shown in the pictures) Note: Only a 7.5t truck can turn around on the company premises. It is recommended to send a smaller truck for collection.

Condition: ready for operation (used), Year of construction: 2007, machine/vehicle number: 15507225, functionality: fully functional, operating hours: 9,980 h, travel distance X-axis: 700 mm, travel distance Y-axis: 420 mm, travel distance Z-axis: 610 mm, number of slots in tool magazine: 32, rotational speed (max.): 20,000 rpm, rotational speed (min.): 50 rpm, TECHNICAL DETAILS Travel X-axis: 700 mm Travel Y-axis: 420 mm Travel Z-axis: 610 mm Feed rates: 1 - 20 m/min Machine pallet Pallet dimensions: 1,260 x 490 mm T-slots: 9 x 12H8, 50 mm spacing Max. spindle speed: 50 - 20,000 rpm Tool system Tool holder: SK30 Number of tools in magazine: 32 MACHINE DETAILS Control: HEIDENHAIN iTNC 530M Dimensions & Weight Dimensions / Weight: 2,500 x 2,560 x 2,700 mm Installation dimensions: 4,300 x 2,950 x 3,012 mm Weight: 5,100 kg Connected load: 22 kVA Hnsdpfxsyznvcj Agyok Operating hours Spindle hours: approx. 9,980 h Control on-time: 78,165 h Machine on-time: 91,869 h Program run time: 54,682 h EQUIPMENT 3D touch probe, infrared Coolant system 3 bar / 30 l/min Oil mist extraction system Minimum quantity lubrication system with dual dispenser FEHLMANN HSC settings (Cycle 327) Note: The clamping devices and tools shown in the images are not included in the scope of delivery.

Condition: excellent (used), Year of construction: 2001, functionality: fully functional, travel distance X-axis: 1,600 mm, travel distance Y-axis: 1,000 mm, travel distance Z-axis: 780 mm, controller model: HEIDENHAIN TNC 426, spindle speed (max.): 2,500 rpm, TECHNICAL DETAILS Travel Range X-axis: 1,600 mm Travel Range Y-axis: 1,000 mm Travel Range Z-axis: 780 mm Number of machining axes (excluding parallel axes): 5 Table Clamping surface (left-right): 1,000 mm Clamping surface (front-back): 1,000 mm Max workpiece weight: 6,000 kg Rotary axis: C > Positioning accuracy: 0.001° Milling Spindle/Head Spindle type: Swivel head > Positioning accuracy: 2.5° Speed range: up to 2,500 rpm Tool holder: ISO SK 50 Drive power: 22 kW Tool Magazine Tool positions: 60 Hjdpoyztl Njfx Agysnk Workpiece Automation Number of storage slots: 2 Pallet length: 1,000 mm Pallet width: 1,000 mm Number of pallets: 2 MACHINE DETAILS Control: HEIDENHAIN TNC 426 Dimensions & Weights Space requirement (left/right): 6,400 mm Space requirement (front/back): 6,900 mm Overall height: 4,000 mm Total weight: approx. 26,000 kg

Condition: ready for operation (used), Year of construction: 1999, operating hours: 51,147 h, functionality: unexamined, travel distance X-axis: 1,250 mm, travel distance Y-axis: 880 mm, travel distance Z-axis: 800 mm, controller manufacturer: HEIDENHAIN, Equipment: chip conveyor, TECHNICAL DETAILS Travel X-axis: 1,250 mm Travel Y-axis: 880 mm Travel Z-axis: 800 mm MACHINE DETAILS Control: HEIDENHAIN Operating hours Machine hours: 93,440 h Spindle hours: 51,147 h EQUIPMENT Tool changer Hsdpfx Aoyxc Etegysnk Chip conveyor

Condition: ready for operation (used), Year of construction: 2002, operating hours: 41,245 h, functionality: unexamined, machine/vehicle number: 1113000335, travel distance X-axis: 880 mm, travel distance Y-axis: 630 mm, travel distance Z-axis: 630 mm, controller manufacturer: HEIDENHAIN, Equipment: chip conveyor, TECHNICAL DETAILS Hnsdpfsyxc Dcsx Agyek X-axis travel: 880 mm Y-axis travel: 630 mm Z-axis travel: 630 mm Number of axes: 4 MACHINE DETAILS Control: HEIDENHAIN Operating hours Machine hours: 74,780 h Spindle hours: 41,245 h EQUIPMENT Chip conveyor Filtration system

Condition: not inspected (used), Year of construction: 2000, functionality: unexamined, travel distance X-axis: 5,900 mm, travel distance Y-axis: 1,560 mm, feed rate X-axis: 80 m/min, feed rate Y-axis: 60 m/min, rotational speed (max.): 20,000 rpm, No reserve price – guaranteed sale to the highest bidder! TECHNICAL DETAILS X-axis working area: 5,900 mm Y-axis working area: 1,560 mm X-axis travel speed: 80 m/min Y-axis travel speed: 60 m/min Z-axis travel speed: 25 m/min Drilling spindles Vertical drilling spindles: 20 Horizontal drilling spindles in X-direction: 6 Horizontal drilling spindles in Y-direction: 2 Total number of vertical and horizontal spindles: 28 Milling spindles Number of controlled axes: 4 Motor power: 10 kW Spindle speed: 20,000 rpm Tool changer Number of positions: 10 Tool: head-mounted Hjdeyxm Swspfx Agyonk MACHINE DETAILS Total installed power: 24 kW Control system: WINDOWS Machine programming software: WRT EQUIPMENT Work table with suction cups Number of suction bar rows: 10 Suction cups for securing the workpiece Vacuum pump The machine is sold and delivered in its actual and legal condition ('as seen and approved') on the basis of photographic documentation and descriptive technical/commercial documents. The buyer is entitled to inspect the item before collection and is responsible for installation, securing and use of the machine at the final destination. External reference: 8173

Condition: ready for operation (used), Year of construction: 2002, functionality: fully functional, travel distance X-axis: 1,250 mm, travel distance Y-axis: 500 mm, travel distance Z-axis: 600 mm, spindle speed (max.): 6,000 rpm, number of slots in tool magazine: 32, TECHNICAL DETAILS Travel X-axis: 1,250 mm Travel Y-axis: 500 mm Travel Z-axis: 600 mm Maximum spindle speed: 6,000 rpm Spindle taper: SK 50 Spindle cooling: 15 bar Hnjdpfjyykhrsx Agysk Table dimensions: 1,400 x 550 mm Tool changer positions: 32 MACHINE DETAILS Spindle power: 18.5 kW Dimensions (L x W x H): 4,500 x 2,350 x 2,650 mm Note: The machine is sold without vises and tools.

Condition: ready for operation (used), Year of construction: 2012, machine/vehicle number: AA2-002032, functionality: fully functional, operating hours: 9,974 h, overall weight: 7,450 kg, feed length X-axis: 5,020 mm, feed length Y-axis: 1,680 mm, feed length Z-axis: 250 mm, TECHNICAL DETAILS X-axis travel: 5,020 mm Y-axis travel: 1,680 mm Z-axis travel: 250 mm Number of axes: 5 Software: SCM XILOG MAESTRO Control systems: SCM PRISMA K, SCM TTS System, SCM TecPad, MORBIDELLI TV Matic, SCM PRO-SPACE, SCM RAPID 12, SCM RAPID 24 Tool changer: 36 positions Drilling units: 24 x vertical MACHINE DETAILS Machine dimensions (LxWxH): 2,400 x 8,000 x 2,400 mm Total weight: 7,450 kg EQUIPMENT - Vacuum pump with 250 m³/h capacity Hsdpfxey Akgae Agyenk - Liquid-cooled milling spindle

Condition: ready for operation (used), Year of construction: 2005, operating hours: 1,476 h, functionality: fully functional, machine/vehicle number: 174275, travel distance X-axis: 1,050 mm, travel distance Y-axis: 510 mm, travel distance Z-axis: 510 mm, controller model: Mazatrol 640M, spindle speed (max.): 12,000 rpm, TECHNICAL DETAILS Travel X-axis: 1,050 mm Travel Y-axis: 510 mm Travel Z-axis: 510 mm Spindle speed: 12,000 rpm Hjdpsy Am Ndofx Agyonk Number of tool changer positions: 30 Table size: 1,700 x 750 mm MACHINE DETAILS Spindle motor power: 18.5 kW Control: Mazatrol 640M Weight: 7,100 kg Operating hours Counter 1: 43,723 h Counter 2: 1,476 h EQUIPMENT Chip conveyor
