Used Axa Cnc Machining Center for sale (71,413)

Condition: good (used), Year of construction: 1997, functionality: fully functional, We offer an nice condition Matsuura with tools and accessoriess, very atractive machine for a serious work. Description Matsuura MC600VF Vertical Machining Centre in great working condition ready to use. COOLING TROUGH SPINDLE including Large Qty of BT40 Tooling (33 TOOLS, Universal 3D Tester. Country of Origin: Japan. Spindle Chiller WASTE CONVEYOR with Yasnac i80M Control 20 Position: ATC BT40 : Taper Specifications Manufacturer MATSUURA Model MC600VF Year 1997 Condition Used Serial Number 970112285 Table size 870 x 400mm Coolant tank X = 600 Y = 410 Z = 470mm Blsdevkx Rkjpfx Aqwsl Spindle speeds 30 – 15000 rpm.

Condition: ready for operation (used), Year of construction: 2016, operating hours: 152 h, functionality: fully functional, machine/vehicle number: 665182, travel distance X-axis: 650 mm, travel distance Y-axis: 550 mm, travel distance Z-axis: 500 mm, spindle speed (max.): 42,000 rpm, number of slots in tool magazine: 40, No minimum price – guaranteed sale to the highest bidder! TECHNICAL DETAILS Travel distances Travel distance X-axis: 650 mm Travel distance Y-axis: 550 mm Travel distance Z-axis: 500 mm Feed rates Feed rate X-axis: 30 m/min Bedozquqcjpfx Aqwjll Feed rate Y-axis: 30 m/min Feed rate Z-axis: 30 m/min Spindle Spindle interface: HSK-E 40 Spindle speed: 42,000 rpm Spindle running time: 151 h 20 min 08 s Spindle replacement: 2025 Cost of spindle replacement: approx. EUR 40,000 Tool magazine Number of tool slots: 40 Pallet system Pallet dimensions: approx. 320 × 320 mm Pallet clamping: Rotary table MACHINE DETAILS Machine type: CNC machining center Manufacturer: OPS INGERSOLL Model: SPEED HAWK 650 Year of construction: 2016 Electrical connection data Mains voltage: 400 V Mains frequency: 50 Hz Control voltage: 24 V DC Maximum fuse rating: 63 A Connected power: 38 kVA Dimensions and weight Overall height: 2,850 mm Overall length: 3,300 mm Overall width: 2,400 mm Machine weight: 9,000 kg EQUIPMENT Technical documentation Manual HSK-E 40 tool holders 3 pallets

Condition: ready for operation (used), Year of construction: 2004, operating hours: 11,298 h, functionality: fully functional, machine/vehicle number: 665001, travel distance X-axis: 700 mm, travel distance Y-axis: 550 mm, travel distance Z-axis: 450 mm, workpiece weight (max.): 2,000 kg, spindle speed (max.): 42,000 rpm, number of slots in tool magazine: 40, No minimum price – guaranteed sale to the highest bidder! Submitting a bid obligates you to collect the item within the period of September 21st to October 1st! TECHNICAL DETAILS Travel in X-axis: 700 mm Travel in Y-axis: 550 mm Travel in Z-axis: 450 mm Feed Axes Max. travel speed X, Y, and Z axes: 30 m/min Max. acceleration X, Y, and Z axes: 15 m/s² Bledjzqupxepfx Aqwjl Positional accuracy TP according to DIN ISO 230-2: 0.005 mm Repeatability: 0.002 mm Work Table Table length: 850 mm Table width: 700 mm Number of T-slots: 5 T-slot dimensions: 18 H12 Table load: 2,000 kg Max. workpiece weight: 2,000 kg Distance spindle center – table: 550 mm Spindle Spindle mount: HSK-E 40 Spindle speed: 3,000 - 42,000 rpm Spindle power: 17 kW Tool Changer Tool magazine positions: 40 MACHINE DETAILS Machine type: CNC HSC machining center CNC control: Andronic Electrical Connection Data Supply voltage: 400 V Supply frequency: 50 Hz Fuse rating: 32 A (?) Dimensions and Weight Overall length: 3,300 mm Overall width: 2,300 mm Overall height: 2,300 mm Overall weight: 7,700 kg Operating Data Machine operating time: 275 d 5 h 13 min 39 s Spindle operating time: 11,297 h 20 min 11 s EQUIPMENT - Full enclosure - Dust and fluid-proof guides - Oil mist extraction - Compressor cooler - Frequency inverter - Heidenhain glass scales in X, Y, and Z axes - Work light in the interior - Technical documentation - Workbench - HSK-E-40 tool holders - Tools - Workbench dimensions: approx. 1,500 × 900 × 1,100 mm External Reference: Demo - Lot 2

Condition: ready for operation (used), Year of construction: 2009, operating hours: 4,247 h, functionality: fully functional, machine/vehicle number: 655118, travel distance X-axis: 550 mm, travel distance Y-axis: 400 mm, travel distance Z-axis: 400 mm, spindle speed (max.): 42,000 rpm, swivel angle A-axis (min.): -120 °, swivel angle A-axis (max.): 60 °, No minimum price – guaranteed sale to the highest bidder! Bledpfx Aszquprsqwol Submitting a bid obligates you to collect the item on time between September 21st and October 1st! TECHNICAL DETAILS Travel range X-axis: 550 mm Travel range Y-axis: 400 mm Travel range Z-axis: 400 mm Swivel angle A-axis: -120° to +60° Swivel angle C-axis: n x 360° Distance from HSK-E tool holder to table: 450 mm Clamping area: 650 x 800 mm Pallet dimensions for 4th and 5th axes: approx. 300 x 300 mm Spindle Spindle mounting: HSK-E 40 Spindle speed: 0 to 42,000 rpm Spindle power S1: 15 kW Spindle power S6: 17 kW Axes and Accuracy Drive type: Digital AC servo motors, fully synchronized Travel speed: max. 30 m/min Acceleration: max. 15 m/s² Repeatability: 0.002 mm Digital display: 0.001 mm or 0.0001 mm, selectable Nominal speed in NC axis operation A-axis: 40 min⁻¹ Nominal speed in NC axis operation C-axis: 40 min⁻¹ Tool Changer Type: Pick-up disc magazine Magazine slots: 32 MACHINE DETAILS Machine operating time: 484 d 11 h 24 min 06 s Spindle operating time: 4,246 h 55 min 36 s Type: 5-axis CNC machining center Connected load: 38 kVA Input voltage: 400 V AC, 3-phase, 50 Hz Control voltage: 24 V DC Fuses: max. 63 A Overall length: 3,300 mm Overall width: 2,200 mm Overall height: 2,300 mm Machine weight: 7,400 kg EQUIPMENT - Technical documentation and manual - Three spare pallets - HSK-E-40 tool holders - Pallets with attached specific fixtures External reference: Demo - Lot 1

Condition: used, Year of construction: 2013, 2013 SMC Group Routech Accord 30FX CNC machining center, high performance multi-function work table, 400V, 3 phase, X-axis 20' 10", Y-axis 5' 4.7", dual machining heads, rotation speed 6-18,000 RPM, onboard Rapid 12-tool changer, Rapid 16 rear tool changer, work table, pod, and rail, gantry type, has SMC Group CNC control with remote pendant control, 480V, 3 phase, Becker, model 271407, rotary vane vacuum pump, and (1) Texa, model SAW50RBSBCC000, chilling unit with transformer, winning bidder responsible for proper removal. Bodpfexdc T Ssx Aqwsll

Condition: used, Year of construction: 2014, Colour: Grey Empty weight: 4.000 kg - Machine available from: 2026-01-26 - Year: 2014 - Documentation available: No - CE marking present: Yes - CE certificate present: No - Serial number: 89867 - Number of milling spindles [pcs.]: 1 - └ Milling spindle 1: - - Number of controlled axes [pcs.]: 3 Bodpfxsxr Evle Aqwsll - Type milling table: Flat table - Tool holder: HSK-F63 - Drilling unit present: Yes - Saw unit present: Yes - Tool changer positions [pcs.]: 12 - System/software: BiesseWorks - Safety feature: Safety mat - CNC options: Label machine, Unloading system, Loading system - Table length [mm]: 3600 - Table width [mm]: 1800 - Working range X [mm]: 3765 - Working range Y [mm]: 1875 - Z-axis working range [mm]: 324 - Transport weight [kg]: 4000kg - Transport packages [pcs.]: 1 Financial information VAT: The price shown is exclusive of VAT VAT/margin: VAT deductible for entrepreneurs Delivery and trade-in always possible for everything in the industrial sectors Yorick Diebels

Condition: good (used), Year of construction: 2000, High-performance CNC vertical machining center with SIEMENS 840 D, dual pallet changer, internal coolant system, linear guides, and 30-tool automatic tool changer. Table size: 2 x 1000 x 450 mm Tool holder DIN 69871: ISO 40 Travel ranges: X-axis: 1100 mm Y-axis: 500 mm Z-axis: 640 mm Spindle speed range: 50 – 10,000 rpm Table load: 600 kg Feed rate range, X/Y/Z, stepless: -10,000 mm/min Rapid traverse in all axes: 30 m/min Drive power: 18.5 kW Machine dimensions L x W x H: approx. 3605 x 3041 x 3220 mm Weight: approx. 6700 kg Accessories / Special features: Bsdpfx Asd I R E Nsqwoll • CNC control system SIEMENS 840 D • Dual pallet changer • 30-tool automatic tool changer • Full enclosure with safety doors, electrically secured • High spindle speed up to 10,000 rpm and drive power of 18.5 kW • Linear guides with double roller recirculating bearing, allowing high torques to be absorbed evenly in all directions • Ball screws in all 3 axes • The entire machine bed is made of Meehanite cast iron, ensuring precision, rigidity, and vibration damping • Tool holder DIN 69871, ISO 40 • Chip conveyor with integrated coolant system • 4th axis pre-configured • CE compliant Siegfried Volz Werkzeugmaschinen Rüschebrinkstr. 151-153 D - 44143 Dortmund - Wambel

Condition: used, Year of construction: 2025, functionality: unexamined, Homag Centateq P110 PROFI BMG110/3115/F/K CNC machining centre (2025) with  Almig Combi XP15 receiver mounted air compressor (2025) Bjdpozc Rzpjfx Aqwell Air Plants Dust Extraction Ltd dust extraction system (2025)

Condition: used, Year of construction: 2007, X-axis: 500mm, connected load: 30.8kVA, length: 1624mm, width: 1560mm, height: 2829mm, weight: 2.4t, operating hours: 8,840h, power-on time: 89,352h, total operating hours: 28,840h, an on-site inspection is possible. Bjdpfx Aozytcpeqwoll

Condition: excellent (used), Year of construction: 2016, operating hours: 13,100 h, travel distance X-axis: 450 mm, travel distance Y-axis: 400 mm, travel distance Z-axis: 400 mm, controller manufacturer: Heidenhain, controller model: TNC 620, overall weight: 3,500 kg, spindle speed (max.): 15,000 rpm, coolant supply: 20 bar, number of spindles: 1, Equipment: chip conveyor, documentation/manual, 3-axis machining center Manufacturer: Spinner Type: VC-450 Year of manufacture: 2016 Control system: Heidenhain TNC-620 Operating hours: approx. 13,100 h Serial number: BV XXXX Technical parameters: ----- • Travel ranges X-Y-Z: 450 x 400 x 400 mm • Work table 770 x 410 mm • Max. workpiece weight: 200 kg • Spindle: 15,000 rpm • Tool magazine: 24 x HSK-A63 • Coolant system 20 bar including internal coolant supply, bed flushing, ..paper band filter with 300L additional tank volume • LED work area lighting • Oil mist extraction • 3D touch probe Bedozytzfspfx Aqwell • Chip conveyor • Machine weight: approx. 3.5 t • Dimensions: 2,400 x 1,700 x 2,500 mm Accessories: ----- • Documentation

Condition: used, CNC Turning and Machining Cente: Gildemeister/DMG Mori CTX2500/700 Year: 2019 Bjdpfx Aqezwn Sgowell Serial No.: 02620000651 2 driven spindles, rated speed 4,000/5,000 rpm, net weight 6,360 kg, accumulated operating hours 44,087 h, spindle hours: 27,832 h, cooling unit, chip conveyor, coolant treatment system, control system model: Ergoline, tool turret, 14 positions, for driven tools

Condition: excellent (used), Year of construction: 2002, CNC Machining Center DECKEL MAHO DMU 80 T Year of manufacture: 2002 Control: Heidenhain iTNC 530 Spindle: replaced on 14.11.2018, approx. 17,000 hours Technical data: Bledpfxoylk Syj Aqwol Travel paths: X: 880 mm Y: 630 mm Z: 630 mm Controlled B-axis in milling head: -15° to 90° Spindle speed: 12,000 rpm Tool changer capacity: 32 positions Tool holder: SK 40 Coolant system: available

Condition: used, Year of construction: 2004, machine/vehicle number: IntNr231232, Hermle C600 U, year of manufacture 2004 Spindle new, with commissioning report Control system: - Heidenhain iTNC 530 Bjdpfozx Rvksx Aqwoll - Control system operating hours: 68026 - Machine operating hours: 81237 - Spindle operating hours: 12429 Spindle: - Speed: 16,000 rpm - Tool holder: SK-40 - 30 tool magazine positions Equipment: - Rigid clamping table - NC rotary table, 4th axis (iTNC) - Coolant system - Chip conveyor: none - Electronic handwheel (iTNC) - Tool breakage monitoring - Chip flushing nozzle - Foot switch for clamping/unclamping - Hydraulic unit for clamping/unclamping Travel paths: - X-axis (longitudinal): 600 mm - Y-axis (transverse): 450 mm - Z-axis (vertical): 450 mm Table: - Clamping area: 800 mm x 465 mm - Maximum table load: 250 kg Axes: - Axis rapid traverse: 35 m/min - Acceleration: 5 m/s² - Measuring system X/Y/Z: 0.1 µm Dimensions & Weight: - Machine weight: approx. 6.8 t - Machine dimensions (W x D x H): 2.5 m x 2.4 m x 2.43 m The machine can be inspected under power by appointment. Subject to changes, errors in technical data and specifications, and prior sale!

Condition: good (used), Year of construction: 2006, Parts shown by hand not come. Bodpfxezyakmj Aqwjll

Condition: used, Year of construction: 2011, Base Machine M800 X5 TV 1 WORKING RANGE X: 5,020 mm Y: 1,830 mm Z: 675 mm Clearance Height: 300 mm (from 50 mm suction cup height) MACHINE STRUCTURE The base structure is a monolithic construction made from thick-walled steel. It is reinforced across the entire machine bed with welded components, providing exceptional stability. The table design, with its large base, is the key to ensuring lasting precision and stability. The machine’s layout enables the operator to achieve optimal workflow with minimal space requirements. The mobile gantry is built as a solid monoblock. It is positioned in the X direction on prismatic, ground guides with recirculating ball carriages. The machining unit is mounted on this mobile support carriage, also on prismatic, ground guides and recirculating ball carriages. AXIS MOVEMENT All axes travel on prismatic linear guides with large cross-section and recirculating ball shoes with a wide contact surface, which ensures optimal sliding, even at high speeds and accelerations. The precise and fast positioning of the movable gantry (X-axis) is achieved via helical rack and pinion. Large cross-section recirculating ball screws ensure accurate positioning of the machining unit along the movable gantry (Y and Z axes). The perfect mechanical dynamics and maximum positioning accuracy are controlled by high-quality drives and brushless motors. Max. axis speeds: · X-axis = 90 m/min · Y-axis = 90 m/min · Z-axis = 30 m/min Safety device with bumper and light barrier 1 Bumpers with sensors are fitted to the movable upright, and a light barrier system is installed at the front of the machine. If the operator enters the active zone, the X-axis travel speed is reduced to a lower value of 25 m/min without stopping the machine. This system allows parts to be loaded during pendulum operation without the limitation of access areas, as seen with pressure mat systems. This prevents unwanted interruptions in the machining cycle and offers greater freedom of movement around the worktable. CE certification for the safety system 1 Safety protection fence 1 Side and rear protection fence Automatic central lubrication controlled via CNC 1 The lubrication of the X, Y, and Z axes is controlled by the CNC; intervals are regulated automatically, without manual intervention. Central extraction connector 1 All individual extraction connections of the machining units are collected into a central extraction port. Inside the port, there are various slider valves controlled by the NC. This reduces the required extraction air volume. Chip conveyor 1 Maxi – 5-axis electrospindle 11 kW HSK-63 “Prisma K 1 5-axis electrospindle, 11 kW at 20,000 rpm S1 (100% duty cycle) Speed: max. 20,000 rpm Rotation direction: left/right Liquid cooling Tool interface HSK 63F Inverter 18 kW, stepless, smooth power delivery Max. rotation B-axis = 200° (+-100°) C-axis = 650° Thanks to the non-orthogonal axes, it is possible to perform complex horizontal positioning in a small workspace. This enables the machining of complex geometries without the risk of collision. Bedpsxy Tmnofx Aqwsll

Condition: used, Year of construction: 2016, Working area: X=3300 mm Y=1280 mm Z=150 mm Clearance height Operator terminal: 24" LED colour display Handheld terminal for axis speed control Software: "Woodflash Vacuum pump 90 m³/h/50 Hz or 108 m³/h/60 Hz Milling spindle 12 kW HSK F63 (12,000 rpm) 12-position linear tool changer on the left of the machine frame + pickup station Drilling head DH 16 4H 2S: Vertical 12 spindles Horizontal 4 spindles 2 grooving saws Storage location: Nattheim Bsdpfx Aqexy Tlwowell

Condition: used, Year of construction: 2011, AXES Working area X-Y-Z axes * mm 3050-1300-180 Workpiece length in swivel machining mm 1390 Stroke X-Y-Z axes mm 3460-1735-250 Max. travel speed of the X-Y axes m/min 60 WORKING TABLE Number of workpiece supports and vacuum cups 6 / 2 Standard type Blsdpfeyymz Ujx Aqwjl Standard End stops / Position 1 / rear Vacuum pump m3/h 90/108 DRILLING UNIT Vertical spindles Std/Number/Speed 1/min 12 (8X-5Y) / 4000 Horizontal spindles Std/Number/Speed 1/min 6 (4X-2Y) / 4000 Integrated slotting/sawing unit in X Ømm/1/min 120 / 6000 Motor power kW (HP) 2.2(3) ELECTROSPINDLE Motor power Std. / Opt. (S6) kW (HP) 7.5(10) / 11(15) Max. speed 1/min 24000 Tool changer mounted on the unit carrier in X 4 positions, pneumatic INSTALLATION Installed power KVA 23÷28.5 Compressed air requirement Nl/min 450 Extraction air requirement m3/h 1900+1900 (3400) Required extraction air velocity m/sec 30 Extraction nozzle diameter mm 150+150 (200) Machine weight Kg 3000 * X Distance between the stops - Y Milling center as reference point; Z Workpiece passage GENERAL FEATURES CNC-controlled boring and milling center, in C-frame design and working table with adjustable workpiece supports and vacuum cups, for performing: - Vertical drilling on the surface of the panel - Horizontal drilling on all four sides of the workpiece - Slot milling with disc cutter in "X" direction - General milling operations Self-supporting structure and working table Structure made of a steel welded construction with the control cabinet integrated into the machine frame. Available in two different lengths and with standard workpiece supports or TV supports. Movable unit carrier Box construction made of cold-rolled steel with internal reinforcing ribs, protective devices with bumpers. Working unit Consisting of a drilling head with vertical spindles, horizontal spindles, an integrated slotting and sawing unit and an SCM electrospindle with tool quick-change system type HSK 63 F. Travel paths of the portal and the unit carrier Movement in the X, Y and Z axis takes place on linear prismatic ball-bearing guides with the aid of pre-tensioned linear guides. The power transmission of the X-axis (movable stand) takes place via a pre-tensioned, backlash-free rack and pinion drive with diagonal movement. The movement of the unit carrier in Y and Z direction takes place via pre-tensioned linear guides. The positioning of the working units and the control of the machine functions takes place via "Brushless" three-phase servomotors and digital drives. CNC CONTROL The control unit consists of a numerical control for the milling and drilling machines and a pre-connected personal computer with a graphical user interface "XILOG PLUS". PC -Office- operating system Windows XP - LCD color screen 17 - Qwerty keyboard - Swiveling control panel - Machine interface software Xilog Plus Xilog Plus features Programming - parametric, graphical and ISO programming - Import of DXF and ASCII files - Linear or circular interpolation in three axes, linear in space, spiral in the chosen plane - Supported programming with graphic and syntax aids for drilling and milling operations - Automatic optimization of drilling operations and tool changes - cycles - Possibility of plate zero-point shift for performing drilling on inclined or curved plate sides - Complete compatibility with CAD/CAM Routocam (SCM) - AlphaCam Integrated additional functions - Calculator for direct transfer of the calculated data.

Condition: excellent (used), Year of construction: 2021, X-axis: 850 mm Y-axis: 700 mm Z-axis: 500 mm A-axis: +31 to -139 degrees C-axis: 360 degrees Rotary table diameter: 650 x 540 mm Tool interface: HSK-A63 Tool changer: 88 positions Spindle speed: 18,000 rpm Control system: Heidenhain TNC 640 Bsdpozyu N Rsfx Aqwoll Includes: coolant system 40 bar Includes: compressed air through the spindle center Includes: Heidenhain measuring probe Includes: BLUM LC 50 Type 200 tool measurement / tool breakage detection Includes: BLUM LC 50 DIALOG technology Includes: Rotoclear Includes: Documentation

Condition: used, Year of construction: 2021, operating hours: 7,246 h, travel distance X-axis: 550 mm, travel distance Y-axis: 550 mm, travel distance Z-axis: 510 mm, rotational speed (min.): 10,000 rpm, spindle speed (min.): 20 rpm, Equipment: chip conveyor, CNC machining center, used Manufacturer: DMG MORI Type: M1 - Plus Year of manufacture: 2021 Purchase / Acceptance: May 26, 2022, as a demonstration machine Operating hours: Spindle: 4,049 h Total: 7,246 h Control system: Siemens Sinumerik 828D + Job Shop Working area: X-axis travel: 550 mm Y-axis travel: 550 mm Z-axis travel: 510 mm Spindle: Speed: 20 - 10,000 rpm Bsdpfx Aszbvqgeqwell Power: 13/9 kW Mount: SK 40 DIN 69871 Tool changer: 24-position Equipment: - Renishaw 3D probe - Renishaw tool probe - Chip conveyor, left side - Coolant gun

Condition: used, Year of construction: 2022, total height: 2,400 mm, total length: 5,300 mm, total width: 2,350 mm, Colour: Grey Empty weight: 4.000 kg What are Presale Items at Second Owner? Presale items are machines that we sell in their current condition ("as-is"). We have purchased these machines based solely on photos and sell them with the information provided in the advertisement. Unfortunately, we do not have additional details, such as exact dimensions or machine specifications. Additionally, these machines are often not yet in stock and have not been inspected by us. These machines are offered at competitive prices, which means the prices are lower than usual, but the risk lies entirely with the buyer. Please carefully review the information in the advertisement before making a purchase. If you have any questions, feel free to contact us! - Year: 2022 - Documentation available: Yes - CE marking present: Yes - CE certificate present: No - Serial number: 30B.11.040.22 - Number of milling spindles [pcs.]: 1 - └ Milling spindle 1: - - Number of controlled axes [pcs.]: 4 - - Max. spindle speed [rpm]: 24000 - - Main motor power [kW]: 11 - Type milling table: Beam table - Tool holder: HSK-F63 - Material clamp system: Pneumatic - Drilling unit present: Yes - └ Horizontal drill spindles [pcs.]: 4 - └ Vertical drilling spindles [pcs.]: 12 - Saw unit present: Yes - Tool changer positions [pcs.]: 12 - System/software: WoodFlash - Safety feature: Safety light curtain - Vacuum pump present: Yes Bjdpfx Aqezwul Hewjll - └ Number [pcs.]: 1 - └ Brand: Becker - └ Type: PICCHIO 2200 - └ Year of manufacture: 2022 - Tools included: Yes - CNC options: Manual control - CNC documentation available: User keys/licenses, USB stick - Table length [mm]: 3300 - Table width [mm]: 1280 - Working range X [mm]: 3300 - Working range Y [mm]: 1280 - Z-axis working range [mm]: 250 - X-axis maximum stroke [mm]: 4000 - Y-axis maximum stroke [mm]: 1670 - Z-axis maximum stroke [mm]: 500 - Voltage [V]: 400 - Current consumption [A]: 40 - Power [kW]: 18.0 - Installed length [mm]: 6250 - Installed width [mm]: 3494 - Installed height [mm]: 2300 - Transport dimensions: 5300mm x 2350mm x 2400mm (l x w x h) - Transport weight [kg]: 4000kg - Transport packages [pcs.]: 2 Financial information VAT: The price shown is exclusive of VAT VAT/margin: VAT deductible for entrepreneurs Delivery and trade-in always possible for everything in the industrial sectors Yorick Diebels

Condition: good (used), Year of construction: 2008, Ref. -No.: 10660 Manufacturer: DECKEL MAHO Type: DMC 835 V Year of construction: 2008 Type of control: CNC Control: Siemens 840D mit Shopmill Storage location: Halberstadt Country of origin: Germany X-Travel: 835 mm Y-Travel: 510 mm Z-Travel: 510 mm Main spindle drive power: 14 kW Table Dimensions (Lengthxwidth): 1000 x 560 mm Table Load: 800 kg Tool Taper: SK 40 Numbers Of Tools In Magazin: 20 Turning Speeds: 10000 RPM Bodszw Txfopfx Aqwell Max. Workpiece Weight: 4,5 t Further information: - Chip conveyor - Handwheel The machine can be inspected while powered on by prior arrangement.

Condition: good (used), Year of construction: 2012, Ref. -No.: 10659 Manufacturer: DECKEL MAHO Type: DMC 835V Year of construction: 2012 Type of control: CNC Control: Haidenhein iTNC 530 Storage location: Halberstadt Country of origin: Germany Machine-No.: 1541XXX X-Travel: 835 mm Y-Travel: 510 mm Z-Travel: 510 mm Number of T-slots: 5 Max. Tool Weight: 6 kg Max. Tool Length: 250 mm Max. Tool Diameter: 80 mm Tool change time: 1,6 s T - groove width: 14 mm T - slot spacing: 100 mm Tool Taper: SK40 Numbers Of Tools In Magazin: 30 Spindle Speed: 12000 RPM Bsdpfx Aqszw Tw Uewsll Max. Torque: 130 / 87 Nm Turning Speed Range - Stepless: 30 mm / min Total Power Requirement: 35 kW Dimensions Of The Machine Ca.: 4,5 x 3,5 x 2,7 m Weight Of The Machine Ca.: 5 t Changeover time chip - chip: 6 sec Feed rate: 1 - 20.000 (X / Y / Z) High pressure cooling: 20 bar Further information: The machine can be inspected while powered on by prior arrangement.

Condition: used, Year of construction: 2018, Startech cn MAIN FEATURES FLEXIBLE AND CUSTOMIZED PRODUCTION COMBINED WITH SPEED AND PRECISION DRILLING FROM ABOVE WITH REFERENCE TO THE TOP OF THE PLATE ALLOWS ABSOLUTELY PRECISION MACHINING NUMERICAL CONTROL WITH 7" COLOR SCREEN: SIMPLE AND INTUITIVE TECHNICAL DATA Startech CN AXES Max. workpiece dimensions X-Y-Z mm 3050 x 800 x 50 Min. workpiece dimensions X-Y-Z mm 300 x 90 x 10 Drilling/slotting work area mm 0 x 800/0 x 800 X-axis stroke mm 750 Max. travel speed of the X-Y axes m / min 25 DRILLING UNIT Vertical spindles number 7 (4X-4Y one of them common) Horizontal spindles (along the Y axis) Number 2 (1+1) Horizontal spindles (along the X axis) Number 1 Fixed groove saw (direction) X Diameter of the groove saw mm 100 Max. thickness of the groove saw mm 5 Motor power kW (HP) 1.5 (2) Spindle speed rpm 3350 Speed of the groove saw rpm 4300 INSTALLATION Power supply V (Hz) 380 / 400 (50 / 60) Installed power KVA 4.5 Compressed air demand bar 6 Compressed air consumption Nl/cycle 90 Extraction demand m3 / h 1200 Extraction air speed m / sec 20 Extraction nozzle diameter mm 120 GENERAL CHARACTERISTICS Universal CNC drilling machine with work table with fixed gantry and movable workpiece for performing the following machining operations: - Vertical drilling on the panel surface - Horizontal drilling on all four sides of the workpiece - Groove Milling with integrated groove saw in the "X" direction. Self-supporting structure. Machine frame made of tubular steel to provide a large base for the work table. The structure is positioned on three self-leveling feet. The electrical control cabinet is integrated into the machine frame. "Easy Motion" central Bakelite support table: - an MDF sector for through-hole drilling, automatically pivoting for horizontal drilling - an infeed roller that facilitates panel loading - a rear roller conveyor that facilitates panel sliding - left and right stops - a central aligner with manual adjustment. The left and right stops are required to drill the two opposite sides of the panel horizontally in the "X" direction. Panel positioning along the X axis is achieved by means of suction cups. Unit support. This is a gantry structure made of tubular steel. The main machining unit is installed on the gantry. F10L drilling unit includes: - 7 independent vertical spindles - Drill chuck D10 mm - Distance between spindles 32 mm - 2 horizontal drilling heads, 1 in X direction with a single drill, 1 double drilling head in Y direction (1 + 1 drill chuck D10 mm) - Speed 3350 rpm - 1 integrated sawing unit in X (max. diameter 100 mm) - Saw blade speed 4300 rpm - Motor power 1.5 kW - Vertical pneumatic travel per spindle 70 mm - Horizontal pneumatic travel of the drilling unit Positioning of the workpiece and drive of the machining unit A CNC-controlled suction cup clamps the workpiece and positions it sequentially under the machining unit during machining. The movement in X and Y axis is carried out on THK guides with transmission on reinforced toothed Movement in Z axis is carried out pneumatically on "ball-bushing" guides with positioning on stop adjustable via the positioning of the working units is carried out via technology and drives with -CONTROL The control was specially developed for use Bjdpfevwbp Asx Aqwell

Condition: used, Year of construction: 2011, Working size in X-direction: 2770 mm Working size in Y-direction: 1220 mm Working thickness (Z-dimension): 80 mm Machine design: Gantry-type machine Blsdpfx Aevvi Htoqwel Main spindle power: 11.0 kW Main spindle speed: 1500 - 24000 rpm Vector controlled spindle: Yes Clamping system: HSK 63 F Spindle cooling: Air cooling Number of axes: 3 Tool changer: Yes Tool changer positions: 10 Keyboard: Yes Mouse: Yes Programming system: Xilog Plus DXF interface: Yes Online connection possible: Yes CD-ROM drive: Yes Table type: Matrix table Stop system: Stop cylinders Number of vacuum pumps: 1 Vacuum pump capacity: 250 m³/h Safety: Safety tread mats Storage location: Sonnefeld

Condition: used, Year of construction: 2004, Storage location: Nattheim Bjdpfxsvvi Hye Aqwjll
