Used Bütfering Optimat Sko 213/ Cc for sale (5,320)

Condition: used, Year of construction: 2005, Number of belts: 2-belt Max. pass-through height: 150 mm Max. working width: 1350 mm 1st unit: combined sanding unit Design of 1st unit: steel contact roller Sanding pad 1st unit: electronic segmented shoe, 35 mm Abrasive belt length 1st unit: 1900 mm Abrasive belt width 1st unit: 1370 mm Abrasive belt speed 1st unit: 18 m/sec 2nd unit: combined sanding unit Design of 2nd unit: rubberized contact roller, 65° Shore Sanding pad 2nd unit: electronic segmented shoe, 35 mm Abrasive belt length 2nd unit: 1900 mm Abrasive belt width 2nd unit: 1370 mm Abrasive belt speed 2nd unit: variable 2 - 18 m/sec Belt cleaning unit: for 2nd unit Cleaning brushes: Yes Suitable for lacquer sanding: Yes Vacuum conveyor: Yes Feed speed: infinitely variable from 2.5 to 13 m/min Control: touch-screen Nwedpfjytrf Rex Akusg Elect./pneumatic belt oscillation: yes Infeed height: fixed (top section moves) Table display: digital Working height / feed table height: 900 mm Motor power: 36 kW Location: Supplier

Condition: excellent (used), Year of construction: 2006, Technical data: - working width 1350mm - pneumatic oscillation Nwsdpfx Asvdtxijkueg - vacuum table - Stand alone machine ( Table raise/fall ) 1 Combi unit: - motor power 18,5kW - steel calibrating roller - stepless adjustment of the belt speed - sectional pad (52 sections of 26mm each) 2 Combi unit: - sectional pad (52 sections of 26mm each) - motor power 7,5kW - stepless adjustment of band speed - brush on the exit of the material - stepless regulation of feed speed - pneumatic cleaning of belts

Condition: used, Year of construction: 2002, Passage width: 1350 mm Passage height: 3 - 150 mm Feed rate: 2.5 - 13 m/min Motor power: 15 kW / unit 2 combination units with link pressure beam Weight: 3300 kg Dimensions (LxWxH): 2000 x 1735 x 2485 mm Machine loaded free on truck Njdpfx Asy R Edpokuowg

Condition: like new (used), Working width 1350 mm Nsdpfeuuitgsx Akuowg The machine is in excellent, new condition as shown in the pictures.

Condition: ready for operation (used), Year of construction: 1996, Bütfering Classic 213 CE Wide Belt Sander Sanding width 1300 mm Tolerance-accurate calibration with the contact roller Sanding of solid wood Sanding of veneered workpieces with both articulated pressure beams Sanding belt width mm 1370 Sanding belt length mm 1900 Extraction capacity m³/h 3650/4500 min./max. mm 3-150 Compressed air connection bar 6-8 Total connected load kW 24 Air consumption l/min 20 Weight kg 3300 1. Unit Type C, combined contact roller sanding head with: - Steel contact roller, profiled. - Electronically controlled articulated sanding shoe, element width 50 mm - Motor power 11 kW Nsdjy Tu Sujpfx Akuewg 2. Unit Type E - Sanding shoe unit - Electronically controlled articulated pressure beam, element width 25 mm - Motor power 11 kW - Infinitely variable sanding belt speed from 2 to 18 m/s via frequency inverter - Forward and reverse operation - Belt blowing device Transport carpet with infinitely variable feed rate 2.5 - 13 m/min Control of the extraction slides Roller tables at the infeed and outfeed Workpiece cleaning: Rotating cleaning brush 0.75 kW Machine tested for functionality Price 12,500.- Year of manufacture 1996

Condition: used, Year of construction: 2002, Grinding width: 1350 mm Grinding belt width: 1370 mm Grinding belt length: 1900 mm Workpiece thickness: 3 - 150 mm Feed speed: 2.5 - 13 m/min (infinitely adjustable) Drives: Grinding unit: 15 kW Total connected load: 17 kW Weight: approx. 2400 kg Dimensions: 2000 x 1850 x 2100 mm Storage location: Nattheim Nsdsytrfkjpfx Akujwg

Condition: used, Year of construction: 2006, Technical data: Nwjdpfxsv Ecy So Akujg - Manufacturer: Bütfering - Type: Optimat SCO 113/C/DIA - Year of construction: 2010 - Sanding belt width: 1370 mm - Sanding belt length: 2150 mm - Suction volume: approx. 3,530 m3/h - Suction nozzle: 1 x Ø 180 mm (sanding unit) 1 x Ø 140 mm (finishing brush) 1 x Ø 100 mm (suction fan) - Combined sanding unit with switchable sanding sanding drum and sanding pad. Dqlu3Z - Automatically adjustable, profiled steel steel contact roller with grain equalisation for calibration an electronically controlled pressure beam with lacquer sanding package. - Infinitely variable frequency-controlled sanding belt speed sanding belt speed 2 - 18 m/s. - Vacuum clamping device, fan integrated in the machine stand - Drive motor: 15 kw - Total connected load: approx. 19 kw - Operating voltage: 400 V / 50 HZ. - 1 pc. of UNI-BLOWER on outfeet side - 2 pc. of LIROS/SEOT 09 anti static units on outfeed side ( top/bottum )

Condition: excellent (used), Year of construction: 2003, Bütfering Optimat SBC 111 C Sandy Working width: 1100 mm Abrasive belt width: 1120 mm Abrasive belt length: 1900 mm Upper section adjustment, constant table height Sanding unit type C Nwjdpey E Rt Eofx Akueg - 1 combined contact roller sanding unit, with abrasive belt grit compensation and calibration device SWP – steel contact roller (profiled) EG 25 – electronically controlled segmented pressure beam in compact design, element width 25 mm A 3 – triple pole-changing drive motor 3.7/7.5/15 kW Abrasive belt speed: 4.5/9/18 m/s BV – belt blow-off device TE 1 – terminal with 50 freely programmable sanding programs for automated machine control STV – belt feed (carpet feed) driven by continuously adjustable gear motor, feed speed 2.5 - 13 m/min RTE – roller tables at infeed and outfeed FB – rotating cleaning brush on the outfeed side Total connected load approx. 16 kW Operating manual Year of manufacture: 2003 New conveyor belt Price

Condition: excellent (used), Year of construction: 2008, Working width: 1100 mm Workpiece thickness: 3 – 160 mm Abrasive belt dimensions: 1,120 x 1,900 mm Variable feed speed: 2.6 - 13 m/min Feed motor output: 1.10 kW, 400 V, 50 Hz Extraction port diameter: 2 x 160 mm Compressed air supply: 6 bar Nwedpfxoychqzj Akujg Dimensions (L x W x H): 1705 x 1545 x 1905 mm 1st unit: Steel contact roller, diameter 160 mm Motor output: 15 kW, 400 V, 50 Hz 2nd unit: Combination unit with rubber-coated contact roller (Sh 65), rigid sanding shoe Motor output: 11 kW, 400 V, 50 Hz Abrasive belt cleaning via compressed air 3rd unit: Cleaning brush Multi-function display Multi-function lever (conveyor belt, workpiece thickness adjustment) Electronic belt oscillation Pneumatic conveyor carpet oscillation Motorized workpiece thickness adjustment with LED display in 0.1 mm increments Units with emergency braking system Emergency stop button at infeed & outfeed Motor protection switch Roller table extension at infeed with 2 loose rollers Automatic star/delta start Complete documentation Note for used machines: • Specifications and prior sale subject to change. • Stated prices are ex works – loaded free of charge! • The machine has been cleaned and functionally tested. • All machines are sold as seen, without any warranty or guarantee. Buyers are welcome to inspect the machine on site. • Special agreements are only possible in written form. (We only respond to inquiries providing your address and telephone number!)

Condition: used, Year of construction: 2008, machine/vehicle number: 0-411-49-1873, Technical data: - Manufacturer: Bütfering - Type: Optimat SGO 211/RC - Number of grinding units: 2 - Year of manufacture: 2008 - Working width: 1.100 mm - Grinding belt width: 1.120 mm - Grinding belt length: 1.900 mm - Workpiece thickness: 3-160 mm - Feed speed: 2,5-13 m/min. - Table height adjustment Standard equipment: - Automatic workpiece thickness adjustment - Stepless feed speed via requency converter. - 125 grinding programs can be stored - Wear-free braking system 1. Grinding unit (R) - Calibration roller - Profiled steel contact roller - Diameter 160 mm - Drive motor: 15 kW 2nd grinding unit (C) - Combination unit with roller and grinding shoe - Rubberized contact roller 65 Shore - Contact roller diameter 160 mm - Electronic link pressure bar with segment width 35 mm. - Belt speed: 12 and 21 m/s - Tolerance compensation up to 1 mm - Suitable for veneered surfaces and solid wood. - Drive motor: 11 kW Njdpfjyh Hwuex Akujwg - Total connected load: approx. 28 kW - Operating voltage: 400 V / 50 Hz. - Compressed air consumption at 6 bar, 20 L/min. - Belt blow-off device per pressure surge 440 L/min. - Extraction volume: approx. 2,880 m3/h/ at 20 m/s - Extraction connection: Dedusting: 1 x Ø 160 mm (grinding unit, roller) 1 x Ø 160 mm (grinding unit, shoe) Dimensions: - Length: 1,700 mm - Width: 1,850 mm - Height: 2,100 mm - Location: not in stock - Available from April 2026

Condition: used, Year of construction: 1983, Used machine Year of manufacture: 1983 Features and technical data: with 2 combination units with 2 contact rollers, 1 x 65° shore, 1 x 85° shore and 2 air sanding shoes Sanding width: 1350 mm Abrasive belt dimensions: 1360 x 1900 mm Maximum workpiece thickness: 150 mm 1st unit with 15 kW 2nd unit with 15 kW Cleaning brush Roller table at infeed Roller table at outfeed Nwsdpjy Dkhgsfx Akusg Infinitely variable feed speed: 2.5 to 12.5 m/min Weight approx. 3700 kg Availability: approx. May/June Location: Thuringia

Condition: used, Year of construction: 1997, Number of belts: 1 belt, max. clearance height: 150 mm, max. working width: 1100 mm. 1st unit: Combination unit. 1st roller diameter: Steel roller. 1st unit design: Roller/shoe unit. 1st sanding shoe design: Electronic individual links. Segment width: 50 mm. 1st sanding belt length: 1900 mm. 1st sanding belt width: 1120 mm. Motor: 1 kW. Feed speed: 4 and 8 m/min. 2nd unit: Dust brush. Approx. weight: 2000 kg. Dimensions: 1800 x 1450 x 2120 mm. Storage location: Nattheim Njdpovvkkajfx Akuewg

Condition: excellent (used), WIDE BELT SANDER – Buffering sanding width 950 mm, 1 combination unit with a metal roller and sanding block, 11 kW motor, two feed speed settings, electric table adjustment, electronic display of table position, oscillation, the sander is in very good condition and ready for use, Nedpfx Akjy S Ryfouswg machine dimensions: width 150 cm, length 110 cm, height 185 cm.

Condition: used, Year of construction: 2001, Used machine Year of manufacture: 2001 Features and technical data: - Constant working height - Equipped with combination unit featuring steel contact roller and electronic CPS segmented pressure beam with 25 mm divisions - Sanding width: 1100 mm - Sanding belt length: 1900 mm - Workpiece thickness min./max.: 3 - 150 mm - Feed speed: infinitely variable, 2.5 - 13 m/min - Sanding unit: 11 kW Njdpswka Snjfx Akujwg Paint package: - Infinitely variable belt drive speed via frequency inverter - Belt air-blast device - Vacuum conveyor belt with blower Control: - Terminal with 50 program memory slots - Simple menu guidance with plain text display - Visual indication of active elements during operation - Fully automatic PLC-controlled start sequence for all drives - Digital recording of operating hours Includes cleaning brush Roller table at infeed Roller table at outfeed Extraction capacity: 1850 m³/h Extraction connectors: 1 x 180 mm, 1 x 140 mm, 2 x 100 mm Compressed air connection: 6-8 bar Air requirement: 10 l/min Weight: 2,200 kg Availability: by arrangement Location: Röllbach

Condition: new, Catalog number: O222 ADVANTAGES – grinding length 2600mm – electric table height adjustment – new machine – warranty – CE certificate TECHNICAL DATA table size 2600x800mm table lift 570mm pulley 250mm electric table height adjustment 0.37kW belt speed 18m/sec sanding belt size 120 x 150mm belt length 7050mm engine 3kW exhaust port diameter 120mm weight 400kg Nwsdpfxey R A H Is Akuog PRODUCT FEATURES The Optimat SD 260 long belt sander has been designed for processing smaller and medium-sized elements. The electrically controlled table certainly increases the precision and efficiency of work. Standard equipment: Electric table height adjustment Extraction nozzle User manual Automatic engine braking Protections compliant with standards Ergonomic emergency switch Electronic table stops Net price: PLN 21,000 Net price: EUR 5,000 Net price calculated according to the exchange rate of PLN 4.2/EUR (in case of larger exchange rate fluctuations, the price may change)

Condition: used, Year of construction: 1992, Used machine Year of manufacture: 1992 Features and technical data: - Suitable for craft enterprises, equipped with 1 combi unit for top-side sanding - Working width: 950 mm - Sanding belt dimensions: 970 mm wide, 1700 mm long - 1 combined contact roller and sanding shoe unit, drive motor 7.5 kW, with 85 Shore contact roller and sanding shoe with felt pad and sliding coating - DFL veneer sanding device - Workpiece-controlled air cushion sanding shoe - Protected storage for sanding shoe within the machine - Sanding belt drive with automatic star-delta starter and maintenance-free, wear-free electric braking system - Additional storage for a second sanding tongue - Safety shutdown when door is opened - Pneumatic sanding belt tensioning system - Feed belt mechanism driven by a worm gear motor, feed speeds of 4 and 8 m/min, and automatic belt tracking control - LED digital display for workpiece thickness adjustment - Safety shutdown at machine infeed for over-thick workpieces - Indicator lights for operation status - Optimally arranged dust extraction hood with port (D=160 mm) for the sanding belt - Roller table at infeed - Complete pneumatic control system, including automatic pressure monitor, control, and monitoring devices - All main electrical switchgear—main switch, fuses, contactor control with motor protection relay, indicator devices—in VDE-compliant design - Total connected load: approx. 9 kW - Operating voltage: 380 V, 50 Hz - Dimensions: approx. 1500 x 1650 x 2000 mm Nedpey R E U Uefx Akuswg - Weight: approx. 1200 kg Availability: by arrangement Location: 63934 Röllbach

Condition: used, Year of construction: 1976, Used machine Year of manufacture: 1976 Nodpfx Akswpm I Teuswg Equipment and technical data: - Underside sanding - Material feed via rubber rollers - Non-contact oscillation control - Quick-change pressure beam - Electromotive adjustment of the tool thickness with an easily readable digital display - Push-button control with contactor - Sanding width: 1350 mm - Maximum workpiece thickness: 150 mm - Sanding belt width: 1360 mm - Sanding belt length: 1900 mm - Feed rollers switchable: 10 + 20 m/min - Compressed air connection: 6 bar - Air requirement: approx. 180 NL/min - Motor power: 17.5 kW - Dimensions (W x D x H): 1800 x 1100 x 1520 mm - Weight: 2600 kg Availability: short notice Storage location: 63934 Röllbach

Condition: excellent (used), Catalogue number 7431 TECHNICAL DATA - Max workpiece width: 950mm - Max workpiece height: 150mm Top: - Metal pressure roller - Unit (profiled rubber roller for calibration + pad shoe + metal roller) - Smooth, metal sliding roller Bottom: - Feed belt - Pneumatic oscillation of belts with photocells - Electric table lifting - 2 feed speeds - Main motor: 7.5 kW - Feed motor: 0.6 kW - Table lifting motor: 0.18 kW - Working pressure: 8 bar - Extraction connection diameter: 150mm - Dimensions (L/W/H): 1600x1250x2000mm - Weight: 1109 kg ADVANTAGES – German manufacturing – Additional pad shoe included – Used sander, in very good condition Net price: 23,900 PLN Net price: 5,690 EUR (at exchange rate 4.2 PLN/EUR) (Prices may change depending on exchange rate fluctuations) Nwsdpfx Akjy Rtalsujg

Condition: new, Catalogue number O231 - New machine, in stock - CE certificate TECHNICAL DATA - Main motor power: 5.5 kW (7.5 HP) - Feed motor power: 0.5 kW (0.75 HP) - Shaft diameter: 120 mm - Spindle speed: 5,500 rpm - Feed speed: 4 – 20 m/min - Max. working width: 630 mm - Min. working length: 280 mm - Max. working height: 300 mm - Min. thickness: 5 mm - Max. cutting depth: 8 mm - Number of knives: 4 pcs - Extraction port diameter: 160 mm - Machine dimensions: 1250 x 1270 x 1180 mm - Weight: 870 kg Original photos Net price: 35,000 PLN Net price: 8,300 EUR (based on exchange rate 4.2 EUR) (Prices may vary depending on larger fluctuations) Nodpfoy Rr Etsx Akuowg

Condition: used, Bütfering ECO 111 Electronic Wide-Belt Calibration and Fine Sanders Contact roller unit 85 SH CPS electronically controlled segmented pad Working width 1100 mm Terminal for various operating programs with selector switch and LED display Motor power approx. 11 kW Brush cleaning unit RTE additional compact roller table at infeed RTA additional compact roller table at outfeed Machine is FULLY REFURBISHED and in TOP CONDITION Available ex-stock Lieboch Nwjdpey Rzf Asfx Akuog

Condition: ready for operation (used), Year of construction: 2005, functionality: fully functional, working width: 950 mm, sheet thickness (max.): 120 mm, working height: 120 mm, control type: CNC control, Equipment: CE marking, TECHNICAL DETAILS Station 1: Sanding belt Station 2: Rotary brush Station 3: Rotary brush Min. sheet thickness: 0.5 mm Max. sheet thickness: 120 mm Working width: 950 mm Working height: 0.5-120 mm Nwjdpjy Hhp Tjfx Akuog MACHINE DETAILS Power: 39 kW Control: CNC Number of stations: 3 Dimensions & Weight Dimensions (L x W x H): 3,940 x 1,980 x 2,010 mm Net weight: 7,000 kg Transport packages: 4 EQUIPMENT CE marking

Condition: used, Used machine Long belt sander Motor power: 4 PS / 3 kW Engine speed 2890 rpm Table dimensions approx. 2460 mm x 900 mm Manual table height adjustment Transport dimensions approx. 3600 x 1600 x 1450 mm Weight approx. 500 kg Nsdpfewka I Aox Akuewg Availability: at short notice Location: Röllbach

Condition: used, Year of construction: 1984, Used machine Year of manufacture: 1984 Condition: fully checked and serviced Equipment and technical data: - Incl. combination unit with contact roller and sanding pad - With height-adjustable contact roller for calibration - With air cushion pressure shoe controlled by the workpiece - 4-way adjustable grit compensation - With pneumatic belt tensioning device - With rotating structuring brush at the machine's outfeed side - Sanding width: 1350 mm - Sanding belt length: 1900 mm - Pass-through height: 150 mm - Main motor: 15 kW - Feed speed steplessly adjustable 2.5 - 12.5 m/min - With roller table at the infeed - With separate additional structuring brush - With roller table at the outfeed - With digital display unit for the electromotoric workpiece thickness setting - With automatic workpiece thickness adjustment - Extraction ports: 2 x 200 mm - Feed belt is ok; has a defect in one spot (see photo) Dimensions: approx. 2300 x 2000 x 2300 mm Weight approx.: 2500 kg Pictures show the machine in unchecked condition! Availability: short-term Location: Röllbach Nsdpfx Akew R Hh Usuewg

Condition: used, Year of construction: 1983, Used machine Year of manufacture: 1983 Njdpfswka T Sox Akujwg Condition: fully checked and serviced, including new feed belt Equipment and technical data: - Including combination unit with contact roller and sanding pad - With height-adjustable contact roller for calibration - With air-cushion pressure pad controlled by the workpiece - 4-way adjustable grit compensation - With pneumatic belt tensioning device - With rotating cleaning brush on the outfeed side of the machine - Belt oscillation via photoelectric sensor for automatic monitoring and regulation of lateral belt alignment, ensuring uniform belt wear - With roller table at the infeed - With digital display unit for the motorized workpiece thickness setting - With additional veneer sanding pad - Including 2x spare sanding pads - Sanding width: 1350 mm - Sanding belt length: 1900 mm - Workpiece height: 150 mm - Main motor: 15 kW - Infinitely variable feed speed: 2.5 - 12.5 m/min - Extraction ports: 2 x 200 mm Dimensions: approx. 2300 x 2000 x 2300 mm Weight: approx. 2300 kg Availability: short-term Location: 63934 Röllbach

Condition: used, Year of construction: 2000, Working width .- mm With 1 sanding unit consisting of:- combination unit with electronic shoe for lacquer sanding- lacquer sanding- dust brush- roller table at infeed 270 mm- program control electronic f. 50 programswith brand-new feed carpetusedmake Bütferingtype Classic 111 Cyear of construction 2000machineNo. 63608Working width 1100 mmPassage height 160 mmCE type-testedGS wood dust testedBelt dimensions 1120 mm x 1900 mmFeed speed 4 8 m/min.1 piece combi unit 3.7/7.5 15 kW , 3 belt speeds with autom. steel rollerdiameter 130 mmbelt speed approx. 4,5 9 18 m/selectronic link shoesegment pitch 50 mmfor lacquer sanding workpiece controlledstorage location 97447 Gerolzhofen, free loaded, unpackeddelivery as seen,without guarantee and warranty Nsdpevwfl Usfx Akujwg
