Used Biesse Rover B 1650 for sale (39,840)

Condition: used, Year of construction: 2019, Numerical control with bSolid software The multi-document software application in Windows environment allows the design of the finished product, the definition of its processes, the definition of the work plan, the simulation of the piece machining operations on the 3D model of the machine and generation of the necessary machine programs. bSolid - 3-Axis Machining bSolid - 5-Axis Machining Module for surface machining with 5-axis units and interpolation movements on all 5 available axes (X,Y,Z,C,B). The module includes the following commands: · assignment to surfaces three-dimensional roughing and finishing operations · spread or project a path onto a curved surface machining lying on a plane · follow 2D or 3D curves with any type of tool bSolid - 3D Engraving bSolid - Import external formats Fields of work: X = 5055 mm; Y = 1650 mm (may vary depending on configuration) Z = 200 mm with modules H=74 mm Z = 245 mm with modules H=29 mm Loadable piece in Y: * 1650 mm, with thickness up to 60 mm on H=74 mm modules * 1600 mm, with thickness over 60 mm on H=74 mm modules. 10 ATS floors – 40 trolleys The code includes: • 2 aluminium bars (n. 1 left and n. 1 right) on which the lateral stops slide. • 10 aluminum worktops. The worktops slide on hardened and ground linear guides using recirculating ball bearing slides. Locking occurs on both linear guides, front and rear, by means of four pneumatic cylinders. The control is activated by a button located in front of the work surface. The carriages slide on steel guides positioned above the extrusion. Pneumatic locking system divided into 2 locking zones in X Automatic positioning (EPS) for worktops. "EPS" (Electronic Positioning System) device for the automatic positioning by NC of the work surfaces and trolleys complete with locking devices capable of eliminate possible operator errors. Rear row stop, with 140 mm stroke Intermediate row stop, positioned at 405 mm, with 140 mm stroke. Front row stop, positioned at 1460 mm, with 140 mm stroke 4 lateral stops, with 140 mm stroke (2 right + 2 left) with system 2 additional side stops, with 140 mm stroke (1 right + 1 left). Sensor for checking whether the stops have descended 12 clamping devices for clamping narrow workpieces 6 loading aid bar lifts, for H=74 mm modules Configuration 5A, for Rover B. Configuration for high productivity and flexibility, thanks to the two operating groups 4 and 5 axes and the possibility of performing tool changes in concurrent time. It includes the axes and carriages for the movement of the main operating groups. Includes 2 inverters. Second Y-axis. Introduces the separation of the front and rear Y-carriages, with independent motorization. The two Y-carts have a maximum speed of 118 m/min. 13.2 kW (17.7 HP) electrospindle, HSK F63 connection, air-cooled. Main features: • 11 kW (14.7 HP) from 12,000 to 15,000 rpm in S1 service. • 13.2 kW (17.7 HP) from 12,000 to 15,000 rpm in S6 service. • Bearings ceramics. • Right and left rotation. • Rotation speed from 1,000 to 24,000 rpm programmable by NC. • The release pneumatic operation is carried out via a prismatic linear guide and recirculating ball bearings. A cover is included for chip extraction, with 6 different positions in Z managed by the NC, depending on the length of the tool, or by program. The suction mouth is automatically closed when the electrospindle is not working. Provision for subsequent installation of the 360° operating group (C-axis) Revolver tool maga... Ncedpfx Acsw D E A Ee Tou

Condition: used, machine/vehicle number: 008013, X axis working area: 5780 mm Y axis working area: 1650 mm Working Table: Pod and Rail Main Electrospindle power: 13.2 KW Number of controlled axes: 4 axes Ncjdpfx Acjwuz Eke Tju Maximum edge height: 60 mm Total number of drilling spindles: 16 Total number of tool changer positions: 16

Condition: excellent (used), Year of construction: 2018, functionality: fully functional, CNC machining center X working area: 3855 mm Y working area: 1650 mm Z working area: 245 mm 5-axis electrospindle, 13 kW power, HSK63F interface, liquid-cooled 12-position turret tool changer mounted on carriage 16-position tool changer mounted on X carriage Vertical drilling heads: 20 Horizontal drilling heads X: 4 Horizontal drilling heads Y: 4 Saw blade unit for grooving 8-rail worktable Software: bSolid Heat exchanger for coolant 250 m3/h vacuum pump Safety photocells Chip conveyor Only 3377 hours of program execution with EPS for automatic positioning of rails and suction cups Suction cups and Uniclamps included Ncedpeyuuw Eefx Ac Tou Available in July

Condition: excellent (used), Year of construction: 2015, functionality: fully functional, Working area X: 6,400 mm Working area Y: 1,500 mm Number of milling spindles: 1 Main motor: 13 kW Maximum rotation speed: 24,000 rpm Tool clamping system: HSK-F63 Tool change positions: 8 Vertical drilling heads: 20 Horizontal drilling units X: 4 Nedjwlcqvepfx Ac Tjcu Horizontal drilling units Y: 4 2 vacuum pumps, each 360 m³/h Nesting Remote control Software: BIESSE WORKS Overall dimensions: 11,004 × 5,334 mm Weight: 4,900 kg

Condition: used, Year of construction: 2017, machine/vehicle number: 1000025340, functionality: fully functional, travel distance X-axis: 6,735 mm, travel distance Y-axis: 1,650 mm, travel distance Z-axis: 245,290 mm, workpiece height (max.): 60 mm, controller manufacturer: Biesse BH 660, bSolid, bEdge, rapid traverse Z-axis: 30 m/min, rapid traverse X-axis: 85 m/min, rapid traverse Y-axis: 85 m/min, Assembly of the the machine could be done by our subcontractor on the agreed price. Ncsdpfx Aceycvcxj Tsu

Condition: used, machine/vehicle number: 008370, X axis working area: 5055 mm Y axis working area: 1930 mm Working Table: Pod and Rail Nodpsx A Tk Sofx Ac Tocu Main Electrospindle power: 19 KW Number of controlled axes: 5 axes Maximum edge height: 60 mm Total number of drilling spindles: 28 Total number of tool changer positions: 31

Condition: used, Year of construction: 2005, 2005 BIESSE ROVER B 4.40 FT 3-axis CNC machining center Technical features in the last photo Engine hours on: 45,343 Machine hours in automatic operation (work): 27,267 Nodsy Ud Sgjpfx Ac Tecu

Condition: used, machine/vehicle number: 008389, X axis working area: 8417 mm Y axis working area: 1930 mm Working Table: Pod and Rail Main Electrospindle power: 13.2 KW Nsdpfjyqxxrex Ac Tjcu Number of controlled axes: 4 axes Maximum edge height: 60 mm Total number of drilling spindles: 40 Total number of tool changer positions: 22

Condition: used, machine/vehicle number: 008470, X axis working area: 4300 mm Y axis working area: 2205 mm Working Table: Flat table Main Electrospindle power: 11 KW Ncedpfxeyzyrvs Ac Teu Number of controlled axes: 5 axes Total number of drilling spindles: 46 Total number of tool changer positions: 22

Condition: excellent (used), Working center with edgebanding unit in very good condition. Nodpoylcgpofx Ac Tjcu Technical data will be updated soon.

Condition: excellent (used), C.N.C. WORKING CENTER with 4 axes (X-Y-Z-C) for routering, boring, cutting and edge banding Nsdpfx Acjy Nk R Ej Tocu Goose-neck type Numerical Control Type ?? / Software Biesse Works N. 1 Working table with N. 10 supports ATS (L = mm 1800) Automatic Tools Changing System (Store /14 folds-positions) Useful working area (X - Y - Z) mm 6735 x 1650 x 290 Useful working area (X - Y - Z) in edge banding mm 5780 x 1650 x 60 N. 2 Working areas n. 1 Vacuum pump (capacity m3/h) 250 Front emergency carpets - Motorized carpet to evacuate the wastes from the working process Total power installed KW 31.13 Working group (top): N. 20 Independent vertical boring spindles N. 8 Independent horizontal boring spindles N. 1 Circular Saw N. 1 Vertical electro-spindle HSK F63 (Kw 13,2) Edge Banding group on board, with Glueing Unit (Hot Melt glue) Edges (tape) thickness in rolls (min/max) mm 0,4 - 3 Edge coils supporting unit (N. 4 reels)

Condition: not inspected (used), functionality: unexamined, travel distance X-axis: 3,200 mm, travel distance Y-axis: 1,300 mm, number of spindles: 21, rapid traverse X-axis: 80 m/min, rapid traverse Y-axis: 60 m/min, No reserve price – guaranteed sale to the highest bidder! TECHNICAL DETAILS X-axis travel: 3,200 mm Y-axis travel: 1,300 mm Travel speed X-axis: 80 m/min Travel speed Y-axis: 60 m/min Ncjdoytr Ryspfx Ac Tju Travel speed Z-axis: 25 m/min Number of suction traverses: 6 Spindles Number of spindles for vertical drilling: 15 Number of spindles for horizontal drilling in X-direction: 4 Number of spindles for horizontal drilling in Y-direction: 2 Total number of spindles: 21 Milling unit Number of axes: 3 Max. spindle speed: 24,000 rpm Motor power: 9 kW Tool changer Number of tool positions: 10 MACHINE DETAILS Total power: 26 kW EQUIPMENT Vacuum pump WINDOWS control system WRT machine programming software Note: Cones and milling cutters are not included in the scope of delivery. Safety fences will be supplied subject to availability (right side missing). The machine is sold and delivered in its actual and legal condition ("as seen and agreed") based on photo documentation and technical/commercial documents for descriptive purposes. The buyer has the right to inspect the goods before collection and assumes responsibility for the installation, securing, and use of the machine at the destination. External reference: 8174

Condition: used, CNC machining center for drilling and milling operations on wood panels and derivatives, plastics and non-ferrous alloys. Working area X - Y - Z: 3685 - 1508 - 150 mm Continuous worktable Lateral and frontal reference stops Pendular working mode 2 independent working areas allowing simultaneous machining of 2 identical, mirrored or different parts Njdpfxoywxc So Ac Tocu Five-sided machining of the workpiece “Gantry” structure 4-axis milling unit, HSD brand Tool holder: HSK F63 Max rotation speed: 24,000 rpm Inverter 10-position tool magazine on the head Max tool diameter: 215 mm Max tool weight: 4 kg BiesseWorks software Easy programming File import capability Control panel / remote console Teleservice and video diagnostics: real-time support Automatic guide lubrication Vacuum pump: 1 x 250 m³/h Centralized suction pipe diameter: 250 mm Safety devices Side protection strips for the unit Safety photocells instead of mats Perimeter guards with access door Compressed air consumption: 400 NI/min Operating pressure: 7–7.5 bar Air consumption for extraction: 5300 m³/h Machine weight: 4,600 kg Machine documentation: user and maintenance manual, software manual, spare parts catalogue, electrical diagram, CE conformity declaration.

Condition: used, Year of construction: 2006, Numerical Control XP 600 Working range on X-axis mm 3060 Working range on Y axis mm 1140 Working range in Z axis mm 160 N ° 2 work fields Bar worktop No. 6 adjustable bars for suction cup support No. of pneumatic bakelite bars for panel lifting (?) No. 2 adjustable suction cups for each bar with vacuum seal for fixing the panel during processing No. 1 vertical electrospindle with C-axis 12 kW motor 10-position tool change system - positioned on the drilling head of the machine, ISO 30 type cones BH19L drilling head with 18 spindles arranged as follows: - No. 7 verticals on X axis - N° 6 verticals in Y axis - N° 4 horizontal on X axis - No. 2 horizontals on Y axis - No. 1 independent blade group for making grooves on the X axis Front protection and safety system with photocells Automatic lubrication system (?) Air conditioning system for cooling and cleaning of machine control Vacuum pump mc/h 250 TECHNICAL DETAILS TO BE CHECKED Ncjdpfjv Aacfsx Ac Tou

Condition: used, Year of construction: 2013, Working center with automatic robot for panel loading and unloading management Biesse XP600 Numerical Control with Biesse Works ADVANCE graphic interface software - machine version and version office - WRT technology (Widows real time) the machine control logic is processed directly on the PC and not on a dedicated special device Working field in X axis 6200 mm Working range in Y axis mm 1552 Working field in Z axis 180 mm Z axis travel mm 235 N ° 2 work fields in X axis Bar worktop \ console No. 10 EPS electronically adjustable bars for suction cup support N° 8 pneumatic bakelite bars for lifting the panel - loading / unloading aid N° 4 EPS electronically adjustable suction cups for each bar with vacuum seal for fixing the panel during the processing N° 1 vertical electrospindle, with automatic tool change, motor KW 12 - 12000 RPM - flange for aggregates - preparation for C-Axis Vector Ncedpfx Ajkvrxuoc Tou Automatic tool change system with 12 positions - positioned on the machine head BH35L boring head with spindles arranged as follows: - N° 14 verticals in X axis - N° 10 vertical in Y axis - N° 6 horizontal in X axis - N° 4 horizontal in Y axis Independent blade for making grooves in the X axis - diam. 120 mm Front protection and safety system with carpets Perimeter protection grids Automatic lubrication system Machine control cooling and cleaning system with conditioner Vacuum pump mc / h 250 Kuka industrial robot with 6 articulated axes with point-to-point positioning. Independent control panel Panel alignment table Barcode reader on the robot arm Panel introduction system via: * 1 motorized roller conveyor for panel stack preloading * 1 translating motorized roller conveyor * 1 motorized panel stack unloading roller conveyor Technical features: * Type : KR210-2 * Number of axles : 6 * Admissible nominal load : Kg 210 * Machine weight : Kg 1267 * Sound level: 75dB * Installed power: 25.8 kW * Panel dimensions - Min\max length: mm 300\3000 * Panel dimensions - Min\max width: 180\1500 mm * Panel dimensions - Min\max thickness: 8\60 mm * Max panel weight: Kg 90

Condition: new, Year of construction: 2022, axis stroke (X,Y,Z) 6735 x 1930 x 245 mm Number of spindle head vertical 0 St. Number of spindles head horizontal 0 St. Number of tools 39 St. Dust suction hood 2x 250 mm Number of milling agregates 2 St. Year 2022 Speed 18.000 / 24.000 U/min. Required air-pressure 7 bar Motor output 16,5 / 19,2 kW Ncjdjxf Dwzepfx Ac Tou Capacity 250 m³/h Control BH660

Condition: ready for operation (used), Year of construction: 2016, machine/vehicle number: 1000012445, functionality: fully functional, travel distance X-axis: 3,600 mm, travel distance Y-axis: 1,800 mm, overall weight: 4,000 kg, TECHNICAL DETAILS Working area X-axis: 3,600 mm Working area Y-axis: 1,800 mm Number of working zones: 2 Tool change positions on the rear: 16 Tool change positions on the machine: 8 Vacuum pump: 250 m³/h Drilling head BH 10 configuration: 15 vertical spindles on the X-axis 17 vertical spindles on the Y-axis MACHINE DETAILS Electrospindle power: 13.2 kW Electrospindle type: ISO 30 Control: CNC with B-Solid software Weight: 4,000 kg Nsdpfx Acjydk Aij Tscu EQUIPMENT Nesting work table Automatic loading system with side lift table Label printing system with automatic application on the loading table Panel separation system with suction cups Automatic unloading system with motorized conveyor belt Worktable cleaning system Protection and safety system with perimeter fencing Safety system with bumper Automatic lubrication system Air-conditioning system for cooling and cleaning the machine control unit

Condition: excellent (used), Year of construction: 2015, For sale: 4 units of CNC ROVER BIESSE 2231. Years of manufacture: 2013, 2014, 2015, 2016. In very good condition. Nedpfxox Tbk Ro Ac Tscu

Condition: not inspected (used), Year of construction: 2000, functionality: unexamined, travel distance X-axis: 5,900 mm, travel distance Y-axis: 1,560 mm, feed rate X-axis: 80 m/min, feed rate Y-axis: 60 m/min, rotational speed (max.): 20,000 rpm, No reserve price – guaranteed sale to the highest bidder! TECHNICAL DETAILS X-axis working area: 5,900 mm Y-axis working area: 1,560 mm X-axis travel speed: 80 m/min Y-axis travel speed: 60 m/min Ncedpfxjyxm Swe Ac Tou Z-axis travel speed: 25 m/min Drilling spindles Vertical drilling spindles: 20 Horizontal drilling spindles in X-direction: 6 Horizontal drilling spindles in Y-direction: 2 Total number of vertical and horizontal spindles: 28 Milling spindles Number of controlled axes: 4 Motor power: 10 kW Spindle speed: 20,000 rpm Tool changer Number of positions: 10 Tool: head-mounted MACHINE DETAILS Total installed power: 24 kW Control system: WINDOWS Machine programming software: WRT EQUIPMENT Work table with suction cups Number of suction bar rows: 10 Suction cups for securing the workpiece Vacuum pump The machine is sold and delivered in its actual and legal condition ('as seen and approved') on the basis of photographic documentation and descriptive technical/commercial documents. The buyer is entitled to inspect the item before collection and is responsible for installation, securing and use of the machine at the final destination. External reference: 8173

Condition: used, Year of construction: 2006, power: 31 kW (42.15 HP), input voltage: 400 V, input current: 53 A, input frequency: 50 Hz, travel distance X-axis: 3,685 mm, travel distance Y-axis: 1,575 mm, travel distance Z-axis: 265 mm, number of axes: 3, number of slots in tool magazine: 8, overall weight: 5,700 kg, Equipment: CE marking, Biesse Rover C 6.40 Config 1 FT CNC machining centre Description ROVER C 6.40 FT - numerically controlled machining center Working fields - configuration 1 - X= 3685 mm; Y = 1575 mm; Z = 265 mm CE Safety devices FT Work Table - dimensions X = 3685 Y = 1560 mm 6 Stops with a stroke of 115 mmBack work station 6 Stops with a stroke of 115 mmFront work station 4 Side stops with a stroke of 115 mm (2 Lh + 2 Rh) inclusive of the pneumatic system Vacuum system for 2 300 m3/h pumps 300 m3/h vacuum pump Configuration 1 Composition C1-A1 Boring head BH 22 L SLOT 1 9 kW (12.2 HP) Electrospindle, HSK F63 adaptor, air cooling Prearrangement for the assembly of a 360° operating unit (C axis) Revolving tool changer with 8 places Composition C1-P1 Automatic lubrication system Colour LCD in replacement of the standard LCD. Ncodpfx Ajzgwa Ssc Teu Software update from BiesseWorks (machine version) to BiesseWorks Advanced (machine version) BiesseWorks - Advanced programming system CE (Despite our great care all changes, mistakes in technical data, prices and all information is subject to (typing) errors. No guarantee on printed data! Availability subject to prior sales). (Trotz größter Sorgfalt bleiben Änderungen, Irrtümer bei technischen Daten, Preisen und allen Angaben (Tipp-)Fehler vorbehalten. Keine Gewähr auf gedruckte Daten! Verfügbarkeit vorbehaltlich Zwischenverkauf). Prices excl. advertisement cost MachineSeeker / Preise exkl. Inserierungskosten MaschinenSucher Best woodworkingmachines from the Netherlands Holland Die besten holzbearbeitungsmaschinen aus die Niederlande De beste gebruikte machines uit Nederland

Condition: used, Year of construction: 1992, Used machine Ncsdpfx Acjydf Nds Tju Year of manufacture: 1992 Working area: X-axis: 2310 mm, Y-axis: 628 mm, Z-axis: 90 mm Max. programmable speed: X-axis: 100 m/min; Y-axis: 75 m/min; Z-axis: 15 m/min Drill holder: diameter 10 mm Spindle speed: 4000 rpm Grooving saw: diameter 120 mm Drill spindles: 4 horizontal spindles on the X-axis, 12 vertical spindles in the X-line Operating air pressure: 6 bar Maximum compressed air consumption: 0.75 NL/cycle Installed power: max. 7.5 kW Vacuum tool capacity: 40 m³/h CNC: Display: monochrome 9" Floppy disk drive PLC for machine cycle control Availability: short-term Stock location: Röllbach

Condition: good (used), Code: 0420 Brand: BIESSE Model: ROVER 13 - CE Standard Nodszgtivspfx Ac Tocu CNC Working center with 3 controlled axis for furniture, custom-made furniture , panels, kitchens, wooden doors and various - CE Standard Working area X axis mm 1600 Working area Y axis mm 850 Stroke Z axis mm 70 X axis speed 75 mt/min Y axis speed 60 mt/min Z axis speed 15 mt/min Milling group Kw 2,2 18.000 rpm Vertical boring unit 8 spindles Horizontal boring bits X nr. 2 Horizontal boring bits Y nr. 2 Tool shank diameter 10 mm Spindle rotation speed 4000 rpm Blade group for milled diameter mm 120 Work table: 4 bar plans Vacuum pump 40 m3/h Total power Kw 10 Numerical control NC 400: 6-inch alphanumeric and high-resolution colour graphic display Full-coverage safety cabin Compressed air 6 atm Machine overall dimensions mm 2450 x 1550 x 1900 h Overall dimensions with guard mm 3500 x 1900 x 2000 h Weight about kg 1550

Condition: used, Year of construction: 2002, For sale: Junget / Biesse Rover 24 L CNC milling machine / machining center. The machine is designed for professional processing of furniture panels, wooden components, plastics, and production components. It is suitable for carpentry workshops, companies producing furniture, kitchen elements, fronts, structural panels, PEHD components, and other parts requiring precise milling and drilling. The Biesse Rover 24 L is a robust CNC machining center equipped with a vacuum table, automatic tool changer, and a set of drilling spindles. The machine enables quick and repeatable performance of milling, vertical and horizontal drilling, and grooving operations. Technical specifications: Model: Junget / Biesse Rover 24 L Type: CNC milling machine / CNC machining center Machine dimensions: approx. 5.8 × 2.45 × 2.5 m Work table: vacuum X-axis travel: 4500 mm Y-axis travel: 1300 mm Z-axis travel: 180 mm Vacuum pump: 120 m³/h Control system: NC1000 Operating system: Windows XP Automatic tool changer: yes Vertical drilling spindles: 7 pcs Horizontal drilling spindles: 8 pcs Circular saw: for making grooves / slots, e.g., in fronts or furniture components Safety features: safety grid / safety mat Ncsdpfezf E E Hex Ac Teu Tools installed in the machine: included Applications: The machine is particularly well-suited for the production of furniture, kitchen cabinets, fronts, carcasses, base panels, and components requiring serial drilling and milling. The drill array allows for the simultaneous execution of several holes, which speeds up production and ensures dimensional repeatability. The machine was mainly used for processing PEHD1000 plastic, which confirms its versatility and the ability to work not only with wood-based materials but also with engineering plastics. Technical condition: The machine has been used. According to information from the previous owner, the device is functional, starts up, and has no known defects or reservations. The equipment is sold as used and is subject to verification by the buyer upon collection. Key advantages: * robust industrial construction, * large working area, * vacuum table, * automatic tool changer, * vertical and horizontal drilling spindles, * circular saw for grooves and slots, * ability to process panels, wood, and plastics, * good machine for the production of furniture and serial components. The machine is suitable for continued operation in a production plant, carpentry workshop, or company engaged in CNC machining.

Condition: ready for operation (used), Year of construction: 2007, travel distance X-axis: 4,600 mm, travel distance Y-axis: 1,935 mm, travel distance Z-axis: 275 mm, number of axes: 5, This 5-axis Biesse Rover C9.50 was manufactured in 2007. It features a large working area (X=4600 mm, Y=1935 mm, Z=275 mm), an automatic lubrication system, and a control unit for 5-axis interpolation. The machine includes a vacuum system, a conveyor belt for chip removal, and a liquid cooling unit. If you are looking to get high-quality CNC machining capabilities, consider the Biesse Rover C9.50 machine we have for sale. Contact us for more information. Worktable and clamping • 8 ATS plate holders (L = 1525 mm) and 24 slide rails • Automatic positioning of plate holders and slide rails (EPS X-Y) • Pneumatic locking system, divided into 2 working areas in X • 8 rear reference stops, stroke 115 mm • 8 stops, stroke 140 mm, positioned at 1175 mm (L = 1280 / 1525 / 1800 mm) • 8 stops, stroke 140 mm, positioned at 770 mm (L = 1280 / 1525 / 1800 mm) • 4 side stops, stroke 140 mm (2 left + 2 right), with pneumatic system • 4 removable center stops, stroke 140 mm (2 left + 2 right), with pneumatic system • Sensor for detecting lowered stops • Pneumatic system for lifting bar holders • 6 lifting bar holders for easy loading (H = 74 mm modules)Vacuum • Vacuum system for a 250 m3/h pump • 250 m3/h rotary vane vacuum pump for standard vacuum systemMachining units and configuration • Composition C3-A1: • Device for mounting chip deflectors with pneumatic or inductive sensors on a 5-axis machining unit • Flange for mounting units on a work unit with 5 interpolating axes (units usable only when the electric spindle is vertical) • Composition C3-P2: • Additional Z slide for rear work units, controlled by an independent Z axis • 16 vertical and 4 horizontal boring spindles in Y-direction • Chain tool changer with 22 positions (180 mm center distance) • Iron gripper for chip deflector with pneumatic or inductive sensor, positioned in the chain tool changer • RH chip deflector with inductive sensor for standard electric spindle or 15 kW 5-axis electric spindle (requires device for chip deflector; requires flange for mounting units when using a 5-axis electric spindle; requires C-axis when using a standard electric spindle)Systems • Automatic lubrication system • Control unit with 5 interpolating axes Ncedox D H Hcspfx Ac Teu Additional equipment • additional refurbished 5-axe main spindel available • Conveyor belt for removing chips and scrap pieces (chip conveyor) • Liquid cooling unit for liquid-cooled systems (can cool two electric spindles, or one electric spindle plus one liquid-cooled drilling head)Note: The technical data and descriptions are taken from the original order confirmation and are for information only; they are not binding.

Condition: good (used), Year of construction: 2002, functionality: fully functional, 4-axis CNC machining center with milling spindle, drilling head, and tool changer Machining area: X-axis: 3,060 mm Y-axis: 1,380 mm Z-axis stroke: 250 mm Clamping table: 6 ATS workpiece supports 3 vacuum cups per workpiece support One digital display per workpiece support for displaying the position of the workpiece support itself or the 3 vacuum cups Vacuum cup positions are stored in the program 4 linear guides for heavy workpieces Vacuum pump capacity: 90 m³/h Tooling: Milling unit with 7.5 kW motor, Speed 1,500 - 20,000 rpm Tool holder ISO 30 Rotation direction: right / left 360-degree C-axis for mounting adapter units Tool magazine with 10 positions, mounted on the support and moving in the X-direction Nodpfxjzdnyks Ac Tocu Vertical drilling: X-axis: 7 spindles, spacing 32 mm Y-axis: 7 spindles, spacing 32 mm Horizontal drilling: X-axis: 2 + 2 spindles Y-axis: 1 + 1 spindles Nut saw unit fixed in the X-direction Control: NC 1000 with NC HOPS programming software Safety features: * Floor mats in front of the machine * Protective fencing on the right with access door Connection values: 380 V, 50 Hz, 3 phases Weight approx. 3,500 kg Machine supplied without tools and adapter holders.
