Used Chiron Vertical Processing Machine for sale (71,268)

Condition: used, Year of construction: 1998, x-travel 1120 mm y-travel 510 mm z-travel 510 mm control Mazatrol M Plus spindle turning speed range 0-7000 U/min tool taper Cat 40 tool piece magazine with 24 Plätzen Lhsdpfoy Ty Easx Aiijg max. table load 500 kg table dimensions (lengthxwidth) 1460 x 510 mm Overall size 3600x2700x2590 mm machine weight ab. 5850 kg Equipment/Accessories: - 4 vices - 1 chuck - 18 tool holders with tools - Transport locks - USB flash drive with data backup - Technical documentation

Condition: used, Year of construction: 2015, x-axis 1250 mm y-axis 840 mm z-axis 550 mm control Siemens 840D turning speed range - main spindle 12000 min/-1 drive capacity - main spindle 22,5 kW Torque max. 140 Nm Number of tools 24 St. max. tool length 320 mm spindle taper HSK 63 Number of working hours 56000 h spindle hours 17500 h weight of the machine ca. 9,7 t This machine can be viewed under power by appointment and is in our estimation in very good condition. Lhsdpfx Aiey Tbtlsieg Furnishing: - IKZ - chip conveyor - Glass measuring rods in all axes - automatic door - Swivel axis with counter bearing, Fibro There are 4 identical machines available. The machines were used for light countersinking and drilling work. Changes and errors in the technical data and information, as well Subject to prior sale!

Condition: used, Year of construction: 1998, x-travel 500 mm y-travel 420 mm z-travel 500 mm spindle taper SK 40 Lhedsw Inrvopfx Aiijg table surface area 700 x 400 mm table load capacity 800 kg control Heidenhain TNC 426 rated capacity 40 kVA voltage 400 V weight of the machine ca. 6,5 t dimensions of the machine ca. 3,4 x 3,7 x 2,9 m DECKEL-MAHO machining centres are suitable for manual and automatic operation. --> Area of application MILLING: --> DRILLING: --> Face milling --> Face countersinking --> Circular milling --> Circular drilling --> Screw milling --> Screw drilling --> Gear milling --> Profile drilling --> Profile milling --> Form drilling --> Form milling --> Including vertical tool changer with double gripper --> Tool magazine, variable space coding (VPC): --> Number of tools: 20 --> Standard tool - max. Ø: 90 mm --> Special tool - max. Ø with free neighbouring spaces: 140 mm --> Max. tool length from spindle nose: 300 mm --> Max. tool weight: 12 kg

Condition: used, Year of construction: 2005, Weight 350 kg Dimensions (L/W/H) 1930,0 × 1850,0 × 2490,0 mm x-axis 610 mm y-travel 305 mm Ledpswg Huujfx Aiijhg z-travel 520 mm table length 760 mm table width 360 mm

Condition: new, functionality: fully functional, Year of construction: 2025, The VSI (Vertical Shaft Impactor) sand making machine is a type of crusher designed to accelerate the crushing of aggregate and produce cubical-shaped sand. It is widely used in the field of construction, mining, and other similar industries. Here are key features and information about VSI sand making machines: 1. Working Principle: - The VSI sand making machine operates on the principle of stone impacting stone or stone impacting iron. Material is fed into the center of the rotor, which accelerates to high speed to throw the material outward against a wear-resistant lining. 2. Rotor and Crushing Chamber: - The rotor is a crucial part of the VSI machine and is often designed with multiple pockets to facilitate material throwing and crushing. - The crushing chamber is lined with wear-resistant materials to endure the impact and abrasion during the crushing process. 3. Feedstock Control: - The feedstock (material to be crushed) can be controlled using a variable speed control system, allowing for adjustments to achieve the desired particle size. 4. Material Types: - VSI machines are suitable for processing various materials, including hard and abrasive materials such as rocks, ores, and minerals. 5. Cubical Shaping: - One of the significant advantages of VSI machines is their ability to produce cubical-shaped end products, which is desirable for high-quality concrete and asphalt production. 6. Adjustable Discharge: Lodpfeq Nd U Hsx Aiiohg - The machine usually has an adjustable discharge opening, allowing for customization of the final product size. 7. Sand Production: - VSI sand making machines are primarily used to produce manufactured sand (M-sand) and crushed sand, which are essential components in the construction industry. 8. Maintenance: - Regular maintenance is required to ensure optimal performance and extend the machine's lifespan. This includes checking wear parts, lubrication, and addressing any issues promptly. 9. Variations: - Different manufacturers may offer variations of VSI machines with unique features or specifications. Common variations include open rotor and closed rotor designs. 10. Environmental Considerations: - VSI sand making machines are generally considered environmentally friendly as they produce less dust and noise compared to traditional crushers. 11. Manufacturers: - Well-known manufacturers produce VSI sand making machines, and it's crucial to choose a reputable supplier with a track record of providing reliable equipment. When considering a VSI sand making machine, factors such as feed size, capacity, and the desired end product specifications should be taken into account. Additionally, check the reputation of the manufacturer, and consider customer reviews and feedback regarding the specific model you are interested in.

Condition: ready for operation (used), Year of construction: 2009, functionality: fully functional, machine/vehicle number: 675002, travel distance X-axis: 650 mm, travel distance Y-axis: 1,100 mm, travel distance Z-axis: 500 mm, Equipment: chip conveyor, TECHNICAL DETAILS Travel X-axis: 650 mm Travel Y-axis: 1,100 mm Travel Z-axis: 500 mm C-axis rotation: 360° Lsdpfx Aiey Rxryoijhg MACHINE DETAILS Control: CNC Dimensions & Weight Dimensions (L x W x H): 3,500 x 1,800 x 2,800 mm Net weight: 13,000 kg EQUIPMENT Chip conveyor Tool magazine Probe

Condition: ready for operation (used), Year of construction: 1989, functionality: fully functional, machine/vehicle number: 1764, controller manufacturer: Fanuc, No minimum price – guaranteed sale to the highest bidder! Ledpfx Asy Sluqjiijhg MACHINE DETAILS Control: Fanuc EQUIPMENT Accessories as shown in the pictures

Condition: ready for operation (used), Year of construction: 2012, functionality: fully functional, travel distance X-axis: 1,300 mm, travel distance Y-axis: 600 mm, travel distance Z-axis: 700 mm, controller model: Heidenhain iTNC 530, spindle speed (max.): 12,000 rpm, No minimum price – guaranteed sale to the highest bidder! TECHNICAL DETAILS Travel X-axis: 1,300 mm Travel Y-axis: 600 mm Travel Z-axis: 700 mm Max. spindle speed: 12,000 rpm Taper: HSK 63 - A ICS (internal coolant supply): 20 bar Tool changer: 80 positions MACHINE DETAILS Lhedpsy R Ur Ajfx Aiieg Control: Heidenhain iTNC 530 EQUIPMENT Electronic handwheel Paper band filter Fully enclosed work area Direct measuring systems Chip conveyor Bellows with steel lamellae 3D measuring probe Laser measuring system

Condition: not inspected (used), Year of construction: 2004, functionality: unexamined, machine/vehicle number: 10651-7, travel distance X-axis: 600 mm, travel distance Y-axis: 450 mm, travel distance Z-axis: 300 mm, table load: 800 kg, spindle speed (max.): 42,000 rpm, No minimum price – guaranteed sale to the highest bidder! TECHNICAL DETAILS Travel distance X-axis: 600 mm Travel distance Y-axis: 450 mm Travel distance Z-axis: 300 mm Rapid traverse X-axis: 30 m/min Rapid traverse Y-axis: 30 m/min Rapid traverse Z-axis: 30 m/min Maximum spindle speed: 42,000 rpm Spindle taper: HSKE40 Number of spindles: 1 Table width: 405 mm Table length: 405 mm Max. table load: 800 kg Number of tool magazine slots: 26 MACHINE DETAILS Control system model: RMS6, version 3.18 Input voltage: 400 V Dimensions & Weight Dimensions (L x W x H): 4,210 x 2,350 x 2,600 mm Weight: approx. 7,000 kg EQUIPMENT Documentation/manual Infinitely variable spindle speed control Chip conveyor Blum laser 3D tool setter Hirschmann 9000 zero-point clamping system Electronic handwheel Extor extraction system Lhsdpfxjy Nzuho Aiisg

Condition: ready for operation (used), Year of construction: 2011, operating hours: 37,463 h, functionality: fully functional, machine/vehicle number: M34216027081EHC, travel distance X-axis: 750 mm, travel distance Y-axis: 510 mm, travel distance Z-axis: 510 mm, controller model: Hurco Winmax, spindle speed (max.): 15,000 rpm, TECHNICAL DETAILS X-axis travel: 750 mm Y-axis travel: 510 mm Z-axis travel: 510 mm Table width: 1,000 mm Table length: 510 mm Max. spindle speed: 15,000 rpm Max. table load: 1,350 kg Number of tool changer positions: 24 MACHINE DETAILS Control model: Hurco Winmax Tool holder: SK 40 Dimensions & Weight Installation dimensions (W x D x H): approx. 2.80 m x 2.30 m x 2.75 m Ledsy R Rn Hopfx Aiijhg Transport weight: approx. 4,700 kg EQUIPMENT 4th CNC rotary axis Chip conveyor Coolant unit

Condition: ready for operation (used), Year of construction: 2001, operating hours: 8,200 h, functionality: fully functional, machine/vehicle number: 28850018432, TECHNICAL DETAILS Tool diameter: max. 140 mm Speed at maximum diameter, max.: 6,500 rpm Balancing quality according to DIN ISO 1940: G 6.3 Tool Magazine Number of tools: 24 Tool diameter, standard tools: max. 80 mm Tool diameter, special tools with adjacent positions free: max. 140 mm Tool length: max. 300 mm Tool weight: max. 7 kg Magazine load: max. 72 kg Table Clamping surface with T-slots DIN 650-14: 800 x 500 mm Loading height, top of table: 850 mm Workpiece height: max. 240 mm Table load capacity: max. 500 kg Coolant System Tank capacity with standard chip container: 150 l Tank capacity with spindle cooling: 80 l Pump performance standard, flow rate: 30 l/min Pump performance standard, pressure: 1.2 bar Tank capacity with chip conveyor option: 750 l Pump performance, chip conveyor option, flow rate: 40 l/min Pump performance, chip conveyor option, pressure: 3.0 bar Tank capacity including chip conveyor: 750 l Pump performance, internal coolant supply, flow rate: 30 l/min Pump performance, internal coolant supply, pressure: 15 bar Chip Disposal Chip conveyor discharge height: 850 mm Chip conveyor type: scraper belt MACHINE DETAILS Rated power: 30 kVA Rated current: 42 A Delayed main fuse: 3 x 50 A Operating voltage: 400 V Frequency: 50 Hz Compressed air connection: 6 bar Required system delivery rate: 38 Nm³/h Ambient temperature: +5 to +40 °C Average temperature over 24 h: +35 °C Relative humidity: 30–95 % Dimensions & Weight Transport dimensions of the machine with table (L x W x H): 3.1 x 2.1 x 2.4 m Transport weight: approx. 4,200 kg Mounting elements: 4 x BNV 150/4 EQUIPMENT Lsdpfjy Rta Ejx Aiiehg Fixed station coding Vertical tool changer Pick-up system via work spindle Coolant system Spindle cooling Chip conveyor Internal coolant supply Mounting elements BNV 150/4

Condition: defective spare-parts repository (used), functionality: not functional, controller manufacturer: Siemens, table width: 470 mm, table length: 990 mm, overall weight: 5,500 kg, spindle speed (max.): 10,500 rpm, No reserve price – guaranteed sale to the highest bidder! Note: The machine is defective. The control system does not power up, so it requires repair or can be used as a source of spare parts. Otherwise, the machine is in good mechanical condition. Lhedpfey Ni Agjx Aiisg TECHNICAL DETAILS Spindle speed: 10,500 rpm Table length: 990 mm Table width: 470 mm MACHINE DETAILS Control manufacturer: Siemens Machine weight: 5,500 kg

Condition: ready for operation (used), Year of construction: 2001, functionality: fully functional, machine/vehicle number: 5351126, controller model: Siemens 840D, number of slots in tool magazine: 42, An optional tool package worth €10,000 can be purchased for €3,500! TECHNICAL DETAILS Tool holder: SK-40 Tool magazine: 42 positions Lsdsy S S N Iopfx Aiiohg MACHINE DETAILS Control system: Siemens 840D EQUIPMENT Tool breakage monitoring Filter unit: Knoll, type VRF 300/800 Chip conveyor: Knoll, type 340 K-1/100

Condition: ready for operation (used), Year of construction: 2002, operating hours: 9,675 h, functionality: fully functional, controller model: U100M, spindle speed (max.): 12,000 rpm, number of slots in tool magazine: 32, number of axes: 3, An optional tool package worth €10,000 can be purchased for €3,500! TECHNICAL DETAILS X-axis travel: 1,050 mm Y-axis travel: 560 mm Z-axis travel: 460 mm Main spindle: 12,000 rpm MACHINE DETAILS Control system: U100M Axes: 3 Tool changer (ATC): 32 SK40 Cutting time: 9,675 h EQUIPMENT Documentation/Manual Speed infinitely adjustable Chip conveyor Coolant system Preparation for A-axis (4th axis) Lsdpfxey S S Nns Aiijhg

Condition: ready for operation (used), Year of construction: 1986, functionality: fully functional, travel distance X-axis: 1,250 mm, travel distance Y-axis: 650 mm, travel distance Z-axis: 750 mm, controller model: Heidenhain iTNC 320, table load: 2,500 kg, rotational speed (max.): 6,000 rpm, No minimum price – guaranteed sale to the highest bidder! TECHNICAL DETAILS Travel in X-axis: 1,250 mm Travel in Y-axis: 650 mm Travel in Z-axis: 750 mm Rapid traverse rate X-axis: 15 m/min Rapid traverse rate Y-axis: 15 m/min Rapid traverse rate Z-axis: 15 m/min Table load: 2,500 kg Maximum spindle speed: 6,000 rpm Number of tool positions in tool magazine: 40 MACHINE DETAILS Control model: Heidenhain iTNC 320 EQUIPMENT Ljdpfx Ajy Sxmtjiishg Chip conveyor

Condition: ready for operation (used), Year of construction: 1997, functionality: fully functional, travel distance X-axis: 1,020 mm, travel distance Y-axis: 510 mm, travel distance Z-axis: 500 mm, controller model: HEIDENHAIN TNC 426 P, spindle speed (max.): 10,000 rpm, TECHNICAL DETAILS Travel X-axis: 1,020 mm Travel Y-axis: 510 mm Travel Z-axis: 500 mm Rapid traverse X-axis: 40 m/min Rapid traverse Y-axis: 40 m/min Rapid traverse Z-axis: 25 m/min Lsdpfx Asy R Am Usiishg Workpiece weight (max.): 900 kg Spindle speed (max.): 10,000 rpm Spindle taper: ISO 40 Spindle power: 19 kW Clamping surface: 1,150 x 490 mm T-slots: 5 at 100 mm pitch Number of tool magazine positions: 30 Tool change time: 3.5 sec Max. tool weight: 6 kg Max. tool length: 250 mm Max. tool diameter: 80 mm MACHINE DETAILS Control: HEIDENHAIN TNC 426 P EQUIPMENT Chip conveyor Operating manual CE Declaration of Conformity

Condition: used, machine/vehicle number: 006488, X axis working area: 2500 mm Y axis working area: 850 mm Main Electrospindle power: 5 KW Ljdpfx Aiowuclxeiehg Number of controlled axes: 3 axes Total number of drilling spindles: 11

Condition: used, machine/vehicle number: 008255, X axis working area: 3050 mm Y axis working area: 850 mm Main Electrospindle power: 9 KW Number of controlled axes: 3 axes Lhodpfx Aox A Td Ejiiog Total number of drilling spindles: 19 Total number of tool changer positions: 4

Condition: used, Year of construction: 2021, EMAG VMC 450 MT Mfd. 2021 Control: Siemens 840D SL Machine has no production hours Description CHUCK DIAMETER: 24" MAX WEIGHT: 1100 LBS. MAX SWING DIAMETER: 31" MAX TURNING DIAMETER: 23.5" X STROKE: 30" Z STROKE: 19" MAIN DRIVE: POWER: 100 HP FULL POWER AT 800 RPM MAX SPINDLE RPM: 2,000 C AXIS POSITIONIONG TO .01MM ANGULAR DEGREES FEED DRIVE: Lhodpfxoyzkdvj Aiijg RAPIDS Z / Z: 60 / 30 M / MIN. FEED FORCE X / Z 4 / 15 kN BALL SCREW DIAMETER X / Z: 40 / 50 MM MILLING SPINDLE: POWER: 100 HP MAX SPINDLE SPEED: 7000 RPM SPINDLE TAPER: CAPTO C8 TOOL MAGAZINE: 60 EQUIPPED WITH: MINERALIT MACHINE BED SIEMENS 840 D SL FULL ENCLOSURE LEVEL PADS TURN MILL DRIVE EMAG WORKPIECE CORRECTION SYSTEM EMAG OPERATING AND SETTINGS MASKS EMAG REMOTE DIAGNOSIS Y AXIS B AXIS +/- 95 DEGREE 1000 PSI COOLANT THROUGH TOOL X-AXI CLAMPING FOR GEAR TOOTH FORMING SWARF CONVEYOR, CHAIN TYPE - REAR DISCHARGE LIFTING PUMP PAPER FILTER LOW PRESSURE COOLANT HIGHT PRESSURE COOLANT 1000 PSI PROGRAMMABLE COOLANT PRESSURE COOLANT MIST EXTRACTOR AIR BLAST CHIP FLUSH QUALITY CONTROL: WIRELESS GAUGING CALIBRATION BLK FOR PROBE TOOL GAUGING - BLUM LASER

Condition: used, Spinner MICROTURN 52 LTBS Sub-Micron Turn Mill Center with Y / B-Axis and Twin Spindles AUTOMATION READY - MC0122 Less than 300 hours No bar feed Tools and probes included—for all 3 spindles? BMT 45 Probe would stay. No tooling Chucks etc. included Yes Coolant: used Water Based What kind of facility is it in? R and D for performance parts for injector and turbos Specifications Work Area: Swing Diameter: 23.9 in (608 mm) Turning Diameter (max): 5.9 in (150 mm) Turning Length(max): 9.8 in (250 mm) Travels: X: 23.6 in (600 mm) Z:13.8 in (350 mm) Y1 Turret: +/- 1.9 in (50 mm) Y2 Milling Spindle: +/- 1.9 in (50 mm) B Rotary: 180 degrees Feedrate: Rapid Traverse X: 944.8 ipm (24 m/min) Rapid Traverse Y: 590.6 ipm (15 m/min) Rapid Traverse Z: 944.8 ipm (24 m/min) Spindle #1 Left / #2 Right: Liquid cooled motorized spindle with C-axis servo drive and encoder for synchronous machining. Lhjdsyzkdcepfx Aiieg Spindle Bore Capacity: 52mm (2.0 in) Speed: 5,200 rpm Performance (S6 40%): 22.1 hp (16.5 kW) Torque (S6 40%): 81.1 ft-lb (110 Nm) Spindle Nose: DIN 55026-A6 B-Axis Milling Spindle: Speed (max): 12,000 rpm Performance (S6 40%): 12 hp (9 Kw) Torque (S6 40%): 15.4 ft-lbs (21 Nm) Swivel Angle: +/- 180 degrees Positional Measurement: Rotary Encoder Clamping: Hydraulic Turret: Stations: 12 / BMT45 Live Tooling Speed: 8,000 rpm Performance (S3 25%): 5.8 hp (4.3 kW) Torque (S3 25%): 10 ft-lb (13.6 Nm) Tool Magazine: Station Quantity: 72 Holder Type: HSK40 Tool Length (max): 4.1 in (105 mm) Tool Diameter (max): 3.5 in (88 mm) Tool Diameter (max) - Adj Pocket Empty: 3.9 in (100 mm) Size & Electrical: Technical design according to CE standards. Machine Dimensions: 119.3 in (3030 mm) x 111.8 in (2840 mm) x 113.8 in (2890 mm) Machine Weight: 16,976 lbs (7,700 kg) Operating Voltage: 3 x 400V (+/-10%) Main Frequency: 60 Hz (+/- 2%) Electrical connection: TN network (5-wire) Standard Equipment • 72-station tool magazine mounted on top of the machine • Hydraulic spindle brake on spindle 1 • Hydraulic spindle brake on spindle 2 • Spindle rinsing on spindle 1 (switchable between coolant or compressed air) • Spindle rinsing on spindle 2 (switchable between coolant or compressed air) • CNC Clamping Force Setting on Spindle 1 - recommended for convenient setting of clamping force from the CNC program, or on the screen. • CNC Clamping Force Setting on Spindle 2 - recommended for convenient setting of clamping force from the CNC program, or on the screen. • Linear tool slide with coolant supply • Signal lamp • Rear exit chip conveyor - includes feed pump rated at 5 bar at 20l/min or 3.7 bar at 83l/min • High pressure coolant system with additional 61 gallon (230 liter) tank. Maximum 319 psi (22 bar) • Renishaw tool probe for measuring tools in the X/Y/Z axis • Preparation for mist collector unit • Automatic operator door that opens at the end of the program and closes with the start. Includes necessary safety technology. Suitable for manual loading or automation access. • UNIROB universal robot interface via a common plug on the machine control cabinet with the following signals: • Safety signals (emergency stop/door signals, etc.) • Standard signals via Profinet PN bus coupler on RJ45 module. Otherwise according to the Unirob-V2021 functional description CNC Control System

Year of construction: 2012, condition: ready for operation (used), functionality: fully functional, machine/vehicle number: BCOR12150, BIESSE BREMA EKO 902 CNC and vertical dowel insertion machine for reduced cycle times Equipment Features - Clamping grippers measure the thickness to adjust drilling depth - Laser-based measuring system for detecting the front and rear panel edges - Length tolerance compensation correcting the workpiece length in X - 5-position tool changer - Drilling head with individually retractable spindles and grooving saw - Diameter: 120 mm - Gluing and dowel insertion units mounted on Y and Z axes Options - 4.5 kW electrospindle; 18,000 rpm - Special drilling unit for hinges Technical Data - Panel length: 160 - 3200 mm - Panel width: 35 - 900 mm - Panel thickness: 8 - 80 mm - X/Y/Z axis speed: 100 / 60 / 30 m/min - X axis travel: 3200 mm - Y axis travel: 900 mm - Main spindle power: 4.5 kW - Number of controlled axes: 3 axes - Number of drilling spindles: 20 Ljdpew Nytnofx Aiiehg - Number of tool positions: 5

Condition: excellent (used), Year of construction: 2013, operating hours: 11,000 h, functionality: fully functional, travel distance X-axis: 400 mm, travel distance Y-axis: 435 mm, travel distance Z-axis: 500 mm, rapid traverse X-axis: 36 m/min, rapid traverse Y-axis: 36 m/min, rapid traverse Z-axis: 30 m/min, feed rate X-axis: 15 m/min, feed rate Y-axis: 15 m/min, feed rate Z-axis: 15 m/min, nominal power (apparent): 54 kVA, torque: 117 Nm, controller manufacturer: Fanuc, controller model: i Series, workpiece height (max.): 200 mm, workpiece diameter (max.): 300 mm, total height: 300 mm, total length: 2,465 mm, total width: 2,835 mm, table width: 200 mm, table load: 60 kg, rotary table diameter: 200 mm, overall weight: 5,500 kg, spindle speed (min.): 120 rpm, spindle speed (max.): 12,000 rpm, operating hours of spindle: 11,000 h, coolant supply: 20 bar, spindle nose: DIN40, number of spindles: 1, number of slots in tool magazine: 30, tool length: 300 mm, tool diameter: 125 mm, tool weight: 8 g, input voltage: 400 V, type of input current: three-phase, Equipment: chip conveyor, documentation/manual, rotational speed infinitely variable, 2013 Doosan DNM 200/5AX 5 Axis CNC Machining Centre Used 2013 Doosan DNM 200/5AX (4+1) 5-axis CNC machining centre with Fanuc i Series control, probe, tool holders, spindle chiller, transformer, swarf conveyor and only 11,000 run time hours. Manufacturer: Doosan Model: DNM200/5AX Machine Type: 5 Axis (4+1) Machining Centre Year: 2013 Control: Fanuc Series i Control Hours: 11,000 Run Time Hours Machine Description 2013 Doosan DNM 200/5AX CNC Machining Centre, a compact, high-performance 4+1 - 5-axis vertical machining centre ideal for precision engineering, toolmaking, aerospace, medical, motorsport, mould and die, and complex component machining. This machine is fitted with a Fanuc i Series CNC control and has only 11,000 run time hours, making it an excellent opportunity for manufacturers looking for a reliable used 5-axis machining centre with strong capability, premium features and valuable accessories included. The Doosan DNM 200/5AX is well known for combining compact footprint, rigid construction and 5-axis positioning. It is ideal for reducing setups, machining complex parts and increasing productivity compared with conventional 3-axis machining. Key Features 2013 Doosan DNM 200/5AX 4+1 5 Axis CNC Machining Centre Fanuc i Series Control Only 11,000 Run Time Hours Includes Renishaw OMP60 probe Includes tool holders Includes spindle chiller Includes transformer Includes swarf conveyor Compact 5-axis machining solution Ideal for complex component machining Technical Specifications X Axis Travel: 400 mm Y Axis Travel: 435 mm Z Axis Travel: 500 mm A Axis Travel: 150 Deg (+30 to -120Deg) C Axis Travel: 360 Deg Table Diameter: 200 mm Max Load on Table: 60 kg Max Workpiece: 300mm Dia x 200mm High Spindle Speed: 12,000 rpm Spindle Taper: DIN40 Pullstud: Nikken PS-806 Tool Capacity: 30 Station ATC Rapid traverse (X, Y): 36000mm/min Rapid traverse (Z): 30000mm/min Rapid traverse: (A - tilt axis) 20 rpm Rapid traverse: (C – rotary axis) 30 rpm Maximum feedrate: (X, Y, Z) 15000mm/min Maximum feedrate: (A, C) 7200 deg/min Feedback system: Absolute encoder Max Tool Diameter: 125mm Max Tool Length: 300mm Max Tool Weight: 8kg Spindle motor AC: 11/18.5kW Axis motor (XYZ): AC 4.0kW Axis motor (A axis): AC 3.0kW Axis motor (C axis): AC 1.6kW Power Requirements: 54.0 kVA Air Pressure: 6kgf/cm2 Machine Dimensions: 2465 x 2835 x 3091mm Approx. Machine Weight: 5,500 kg Run Time Hours: Approx. 11,000 hours Included With This Machine Renishaw OMP60 Probe Tool holders Spindle chiller Transformer Swarf conveyor Fanuc i Series CNC control Why Buy This Doosan DNM 200/5AX? Lhedpfxjy St Sde Aiieg This machine is a strong choice for companies searching for a used 5 axis CNC machining centre, used Doosan machining centre, Doosan DNM 200/5AX for sale, or compact 5-axis vertical machining centre. The 4+1 machining capability allows users to machine multiple faces of a component in fewer setups, helping to reduce handling time and increase production efficiency. With a compact table, high spindle speed and Fanuc control, this machine is particularly suited to small to medium batch production and complex prismatic parts. Applications This Doosan DNM 200/5AX is suitable for: Aerospace components Medical components Motorsport parts Toolroom machining Mould and die work General subcontract machining Complex 4+1 machining Notes: *Specifications are given in good faith but not guaranteed*

Condition: used, Year of construction: 2008, 2008 Hardinge Bridgeport XV710 CNC Vertical Machining Centre With Siemens 810D Control Table Dimension 760 x 420mm (3 'T' Slots). 'T'-Slot Dimension 16mm. Maximum Table Load Approx 450kg. Axis Travel 'X'=711mm, 'Y'=457mm, 'Z'=457mm. Spindle Nose To Table Min/Max 150-580mm. Rapid Traverse 'X'=36m/min, 'Y'=36m/min, 'Z'=36m/min. Maximum Cutting Feedrate 12,000mm/min. Maximum Spindle Speed 10,000rpm (10HP Motor). Spindle Taper ISO 40 BIG-Plus. 20 Position ATC. S/No. 080011WM (2008). Lhedpey Sygujfx Aiijg With Coolant System, Renishaw NC4 Laser Tool Presetter, Filtermist FX4000 Mist Extraction Unit, Signal Tower, Lubrication Grease (Direct Drive). & Handwheel. Weight 3,900kg.

Condition: excellent (used), Year of construction: 2013, 2013 Quaser MF400 5 Axis CNC Vertical Machining Centre with Tilting Rotary Table with Siemens 828D CNC Control Tilting Rotary (Trunnion) Table Dimension Ø320mm (4 'T' Slots). Maximum Swing Ø400mm. Maximum Table Load 100Kg. Axis Travel 'X'=410mm, 'Y'=610mm, 'Z'=510mm, 'A'=+30/-120Deg, 'C'=360deg. Rapid traverse 'X/Y'=36 m/min, 'Z'=25m/min. MAximum Cutting Feedrate 20m/min. Maximum Spindle Speed 15,000rpm (Motor 15/20HP). Spindle Taper BT40. ATC Capacity 30 Tools. Maximum Tool Ø76mm (Ø125mm non Adjacent Tools), Maximum Tool Length 280mm. S/No. (TBC) (2013) Lsdjy Sya Uopfx Aiiohg With Through Spindle Coolant, Filtermist FX6002 Mist Extraction Unit, Renishaw Spindle Probe Interface, Hand Wheel & Signal Tower. Note: Tooling & Work Holding Not Included.

Condition: used, Year of construction: 2007, 2007 Haas Super Minimill Vertical Machining Centre with Haas CNC Control Lodpfxsy Sx Uqe Aiiohg Table Dimensions 914mm x 305mm with (3) T Slots. Max Table Load 227kg. 'X' Axis Approx 405mm, 'Y' Axis Approx 305mm, 'Z' Axis Approx 250mm. BT40 Spindle Taper. Spindle Speeds 0-10,000 RPM. Spindle Motor 11.25kW. Spindle Nose to Table Min/Max Approx 102mm/350mm. 10 Station ATC. S/No. 1060226. With 150mm Width of Jaw Machine Vice. Programmable Backstop. Coolant System. Machine Light. Dimensions of Machine Approx 1,700mm x 1,550mm x 2,200mm High. Weight Approx 1,560kg. Power Supply 415 Volt, 3 Phase. Includes (7) Assorted BT 40 Arbors with Cutters & Assorted Machine Fixtures.
