Used Column Drilling Machine - Pillar Drilling Machine for sale (67,846)

Condition: new, Year of construction: 2026, Power: 1.1 kW Drilling capacity in steel / continuous drilling capacity: 30 mm / 25 mm diameter Speed range: continuously variable, 120 - 3000 min⁻¹ Spindle mount: MK-4 Drilling stroke: 120 mm Spindle overhang: 254 mm Table size: 475 mm x 425 mm Tilting/rotating of the drilling table: 45° to the left / 360° Column diameter: 80 mm Quick-change toolholder: 1 - 16 mm Hedpfezhm D Asx Adzor Weight: 132 kg

Condition: used, Box column drilling machine WEBO Series- No 132 Machine No: 9 Drilling capacity 50 mm Spindle cone MK 5 - long quill throat 430 mm spindle stroke 280 mm Height adjustment of drill head 500 mm Table size Ø 725 mm Distance between drill spindle and table max. 740 mm Distance between drill spindle and clamping surface on machine base max. 1240 mm Spindle speed 55-820 rpm Feed rate level 1 0.13 - 0.2 - 0.27 - 0.4 mm/rev. Feed rate stage 2 0.6 - 0.83 - 1.17 - 1.8 mm/rev. Column diameter 300 mm Motor power 2.8 / 3.6 kW pole-changing Mains connection 380 Volt, 50 Hz - Spindle speed via 2 motor speeds and infinitely variable via variator - Manual drill head height adjustment via hand crank, clamping with clamping screws Hsdpfx Adjqa Txqjzjr - Rotatable drill table with mechanical clamping - Table height adjustment via hand crank - Clamping surface on machine base 600 x 550 mm Top height of drill head 3020 mm Overall height drill head bottom 2520 mm Space requirement L x W x H 1400 x 780 x 2520 mm Weight 1600 kg good condition

Condition: used, Bench drilling machine, Table Drill Press GILLARDON Type GT 16 Serial No. Year of manufacture approx. 1985 Hodpfoy N Duwox Adzsr Drilling capacity 16 mm Spindle taper MK 2 Spindle speed 300 to 3000 rpm Throat depth 250 mm Quill stroke 140 mm Table size 400 x 400 mm Table height 850 mm Distance spindle – table plate max. 680 mm Column diameter 105 mm Motor power 0.75 kW Power supply 380 Volt, 50 Hz - Spindle speed via variator belt drive and 2 V-belt stages - Drill head height adjustment via hand crank approx. 430 mm - Lighting unit - Cabinet base with door - Quick-action drill chuck 1 to 16 mm Space requirement L x W x H 900 x 550 x 1650/2080 mm Weight 250 kg Very good condition

Condition: used, Column drilling machine ALZMETALL, type AB 3 ESV Machine no. 15967, year of manufacture 1977 Drilling capacity 32 mm Spindle mount MK 3 – short quill Distance from spindle nose to table 545 mm (short quill) Distance from spindle adapter to table 395 mm (MK adapter) Overhang 290 mm Quill stroke 160 mm Table size Ø 545 mm Column diameter 220 mm Spindle speed 55 – 1450 rpm, continuously variable Hodpfxeharwve Adzjr Motor power 1 / 1.6 kW Power connection 380 volts, 50 Hz - Spindle speed controlled via 2 gear stages, 2 motor speeds, and continuously variable via a variator gearbox - Pre-selection stage for high torque at low speeds - MK adapter from MK3 to MK4 - Automatic feed 0.1 - 0.2 - 0.3 mm/rev - Rotatable drilling table - Table height adjustment via hand crank - Heavy machine base with machined workpiece support surface (not original Alzmetall) - Lighting for the work area Space requirement L x W x H 1150 x 650 x 2000 mm Weight 850 kg Good condition

Condition: good (used), Year of construction: 1982, machine/vehicle number: 340, Offer 25032 Technical data: Hodpfx Aeyk Dp Nodzjr - Drilling capacity in steel ST 60: 50 mm - Maximum drilling capacity in steel ST 60: 65 mm - Thread cutting device up to: M 60 - Drill spindle taper: MK 5 - Drill spindle stroke: 240 mm - Throat depth: 400 mm - Table with 2 T-slots: 720 x 560 mm - Max. distance table – drill spindle approx.: 850 mm - 4 feeds: 0.1 - 0.2 - 0.3 – 0.4 mm/rev - Feed gearbox infinitely variable with change gearbox - Spindle speeds infinitely variable: 40 - 1,600 rpm - Drive: 400 V / 5.5 kW - Space requirement approx.: W 850 x H 2,480 x D 1,350 mm - Weight approx.: 1,450 kg

Condition: used, Column Drilling Machine ALZMETALL Type AB 3 ES Machine No. 21703 Year of manufacture: 1981 Drilling capacity: 32 mm Spindle taper: MK 3 - long quill Throat depth: 290 mm Quill stroke: 160 mm Table size: 510 x 300 mm Column diameter: 115 mm Spindle speed: 55 - 1450 rpm, stepless Motor power: 0.9 and 1.3 kW, pole-changeable - Spindle speed via 2 gearbox stages, 2 motor speeds, and stepless through variator gearbox - Intermediate gear stage for high torque at low speeds - RPM counter for spindle speed - Table height adjustable by handwheel - Machine lamp - Emergency stop via foot switch and kick switch - Quick-action drill chuck 1 to 13 mm Space requirement L x W x H: 1200 x 650 x 1900 mm Weight: 400 kg Hjdsvu Dv Hspfx Adzer Very good condition Machine tested with 30 mm drill diameter in steel - runs very well

Condition: new, Year of construction: 2022, Power: 1.1 kW Drilling capacity in steel / Continuous drilling capacity: 30 mm / 25 mm diameter Speed range: 120 - 1810 rpm Hsdpfxogulr He Adzor Speed settings: 9 Spindle mount: MK-4 Drilling stroke: 120 mm Spindle overhang: 254 mm Table size: 475 mm x 425 mm Tilting / rotating of the drilling table: 45° to the left / 360° Column diameter: 80 mm Quick-change drill chuck: 1 - 16 mm Weight: 132 kg

Condition: as good as new (ex-display), Year of construction: 2025, Power: 0.85, 1.5 kW Speed range: 300 - 4000 rpm Speed settings: stepless Spindle mount: MK-3 Drilling stroke: approx. 105 mm Hjdshpmbbepfx Adzsr Spindle overhang: 200 mm Weight: 152 kg

Condition: used, Year of construction: 1965, bore capacity in steel (diameter) 40 mm Hjdpfx Aov S Iqcodzsr total power requirement 4 kW

Year of construction: 1994, condition: good (used), machine/vehicle number: 491P, Technical data: - Drilling capacity in steel ST 60: 28 mm - Drilling diameter in steel ST 60: 32 mm - Drill spindle mount: MK 3 - Right/left rotation - Drill spindle stroke: 150 mm - Drill spindle speeds, stepless: 80 - 1170 rpm - 2 feed rates: 0.1 / 0.2 mm/rev - Overhang: 290 mm - Max. distance table - drill spindle: 780 mm - Table with 2 T-slots: 480 x 400 mm - Height adjustable via rack and pinion with hand crank - Drive: 400 V / 0.9 / 1.3 kW - Space requirement, approx.: W 600 x H 2100 x D 900 mm - Weight, approx.: 420 kg - Includes: - Coolant system - Quick-change drill chuck 1-13 - Lighting Hedpfx Aedkx Ansdzjr

Condition: ready for operation (used), spindle mount: MK 4, rotational speed (max.): 3,500 rpm, rotational speed (min.): 130 rpm, throat depth: 300 mm, Alzmetall AB 35 / S Drill press, column drill Pinole travel: 180mm Overhang: 300mm Spindle: MK 4 Drill chuck: 3-16mm Hsdozqy I Tepfx Adzer Variable speed: 130 - 3500 rpm Feed rate: 0.1 - 0.2 - 0.3 mm/rev Threading device Coolant unit Vise You are welcome to visit us for an inspection. We will gladly arrange cost-effective shipping for you! You will receive a proper invoice. For foreign customers, a net invoice can also be issued. A valid VAT identification number is required. Subject to prior sale. Visit our shop and view our other offers. The company names and trademarks mentioned are the property of their respective owners and are used only for identification and description of the products. Deviations from technical data and errors in the description of the item may occur and are subject to change.

Condition: good (used), Year of construction: 1980, machine/vehicle number: 622336, Offer 22681 Technical Data: - Drilling capacity in steel ST 60: 30 mm - Drill spindle mounting: MK 3 - Drill spindle stroke: 160 mm Hjdpfxszp E Uco Adzsr - 9 drill spindle speeds: 90 - 1450 rpm - Overhang: 300 mm - Table with 2 T-slots - Table dimensions: 400 x 450 mm - Max. distance table - drill spindle: 660 mm - Height adjustable via rack and pinion with hand crank - Drive: 400 V / 1.2 kW - Space requirement: approx. W 600 x H 2100 x D 850 mm - Weight: approx. 300 kg - Including: - Drill chuck - 10 HSS drill bits, 8 – 20 mm

Condition: good (used), Year of construction: 2015, bore capacity in steel (diameter) 40.0 / 50.0 mm throat 300 mm bore stroke 160 mm turning speeds 100 - 1600 U/min Hsdsznng Eepfx Adzer table: 615 x 430 mm bore spindles - Morse Taper 4 Kurzspindel MK column diameter 145 mm feed 0.1-0.2-0.3-0.4 mm/U distance spindle /table 147 / 688 mm engine output 1.8 / 2.9 kW weight 450 kg Current list price: approx. 20,000 euros Special price available upon request Features: - Heavy-duty column drill press * Drive: V-belt - VARIO - Automatic spindle feed * with electromagnetic feed clutch * and electric cross-handle control - 4x feed rates: 0.1/0.2/0.3/0.4 mm/rev - stepless speed adjustment - Digital speed display - Pole-reversible drive motor - Right/left rotation of the drill spindle - Spindle guard with electrical safety lock - Coolant system with separate reservoir - User manual (PDF)

Condition: as good as new (ex-display), Year of construction: 2019, bore capacity in steel (diameter) 35,0 mm bore capacity in cast iron 40,0 mm threading M 24 in Stahl throat 320 mm morse taper 4 MK bore stroke 160 mm turning speeds 65 - 3250 U/min table: 500 x 420 mm throat 320 mm weight 375 kg range L-W-H 600 x 870 x 2.170 mm 2019 showroom model (!!) Approx. 1 hour of operation Special price on request Furnishing: - Infinitely variable speed, ideal for - Set the desired cutting speed. - Automatic tool ejector and thread cutting device as standard - Electromechanical drilling feed, adjustable from 0.1 - 0.3 mm / rev - Solid gray cast iron table with rotating and swiveling support surface - T-slots in the machine base enable high workpieces to be clamped - Guaranteed concentricity 0.02 mm, measured in the quill - Hardened and ground gears ensure smooth running - Adjustable drilling depth stop with an easily readable scale Scope of delivery: - Key chuck 1 - 13 mm / B 16 - Drill chuck arbor MK 4 / B 16 - Reducing sleeve MT 4/3, MT 4/2 - coolant device - Thread cutting device - Electromagnetic spindle feed Hsdpfxjxaabro Adzor - Automatic tool ejector - LED machine light - First filling with Shell Tellus 46 - Digital speed display - Height-adjustable protective cover

Condition: good (used), Year of construction: 1995, ALZMETALL AB4/SV Column Drilling Machine For sale is a used ALZMETALL column drilling machine, model AB4/SV, manufactured in 1995. Hedsznkyzjpfx Adzor The machine is suitable for professional drilling tasks in workshops, production, metalworking, maintenance, and mechanical engineering. Thanks to its robust construction, it is also suitable for regular industrial use. Product Data Manufacturer: ALZMETALL Model: AB4/SV Product Type: Column drilling machine / Pillar drill Year of Manufacture: 1995 Spindle Taper: MK4 (MT4) Operating Voltage: 400 V Rated Current: 10 A Fuse Protection: 16 A gG Design: Stationary floor-standing machine Condition: Used The ALZMETALL AB4/SV is suitable for drilling, countersinking, reaming, and similar machining operations. Its solid construction provides a stable foundation for precise work on various workpieces. Signs of wear consistent with age and use are present. Please refer to the images for the exact condition, equipment details, and scope of delivery. "Everything from a single source: We would be happy to offer you suitable bank financing for your project." komplett-konzept.leasingo.de You can find more drilling machines and machine tools—both new and used—in our shop! PD

Condition: used, Year of construction: 2017, bore capacity in steel (diameter) 40 mm throat 285 mm bore stroke 160 mm Spindle Speed 150-2.000 U/min. spindle taper MK4 column diameter 115 mm total power requirement 1,5/2,2 kW Hsdpozpzdaefx Adzer weight of the machine ca. 275 kg dimensions of the machine ca. 1000x700x1900 mm

Condition: ready for operation (used), Alzmetall AB 35 HST / Bench drill press & Walter Gras Arbo3 quick-change head -Drilling capacity / steel approx. 40mm -Drilling capacity / cast iron approx. 45mm -Threading capacity max. M25 -Spindle taper MK 4 -Spindle stroke 180mm -Speed range (VARIABLE) 65 - 1750 rpm -Switchable speed range 130-480 / 480-1750 rpm -Automatic feed rates 0.1-0.2-0.3mm/rev -Drilling depth adjustable via depth scale -Speed indicator -Right / left rotation -Swiveling drill head with tool -Height-adjustable work table via hand crank -Coolant system -Emergency stop Hjdpfjzn Unvex Adzsr -Work light Dimensions: L x W x H 1 x 0.8 x 2.1 meters / Weight approx. 1200KG Errors and omissions excepted.

Condition: used, High-performance drilling machine ALZMETALL, type Abomat 20 Production drilling machine Serial No. 452, Year of manufacture 1996 Drilling capacity in steel ST 60: 25 mm Drilling capacity in cast iron GG 20: 30 mm Spindle mount: SK 40 - M16 Overhang: 280 mm Drill slide stroke: 500 mm Distance from spindle nose to table: 185 - 685 mm Table size: 490 x 400 mm Spindle speed: 50 - 500 rpm, infinitely variable Drill slide feed: 20 - 224 mm/min, infinitely variable Drill slide rapid traverse: 4.5 m/min Feed motor power: 0.18 kW Rapid traverse motor power: 0.75 kW Drill spindle motor power: 1.1 kW (speed 1000 rpm) Mains connection: 400 volts, 50 Hz - Spindle speed infinitely variable via frequency inverter - Drill slide feed infinitely variable via frequency inverter - 2 operating modes: setup and automatic operation - Central lubrication - Control cabinet on the back of the machine - Swiveling control panel - Mounted on a steel plate (700 x 650 x 40 mm) with precise height adjustment Space requirement L x W x H: 1200 x 700 x 2530 mm Weight: approx. 1000 kg Good condition Hsdjikrtqjpfx Adzjr

Condition: ready for operation (used), Bench drill – ALZMETALL AB 35 S - Drilling capacity in steel approx. 45 mm - Drilling capacity in cast iron approx. 48 mm - Spindle mount MK 4 - Arm reach approx. 350 mm - Drilling stroke approx. 180 mm - Spindle speeds / 2 stages / 65 - 1450 rpm (VARIABLE) - Automatic feed rates 0.1-0.2-0.3-0.4 mm/rev - Drilling depth stop - Table clamping surface approx. 600x460 mm - Table adjustment approx. 600 mm - Table height adjustable via crank - Column diameter approx. 200 mm Hsdpfx Asznlf Eodzor - Motor power approx. 3.5 kW - Coolant system - Work light - Speed indicator Dimensions: L x W x H 1.1 x 0.7 x 2.1 meters / Weight approx. 1200 kg Errors and omissions excepted.

Condition: used, Column Drilling Machine PRECIS Ø 23 mm Cone: CM2 Maxi diameter: Ø 23 mm Rotation: from 165 to 4400 RPM Table size: 390 x 190 mm Spindle travel: 100 mm Column diameter: Ø 120 mm Throat depth: 240 mm 2 speed motor Mini chuck/table height: 100 mm Maxi chuck/table height: 350 mm Hedszmxzkspfx Adzer Manual descent Manual hydraulic lifting of the table Voltage: 380 V Width: 700 mm Depth: 1000 mm Total height: 1800 mm Weight: approx 800 kg

Condition: used, Workbench Column Drilling Machine FLOTT type 16 STG/R2 Spindle: CM2 Spindle exit: 100 mm Spindle speed: from 80 to 2000 RPM Table size: Length 340 mm x Width 280 mm Hedpfezmxymjx Adzjr Maxi distance spindle nose/table (lower table): 400 mm Throat depth: 240 mm 2 speed motor 2,2 kW Drilling/tapping function Adjustment by belt variator Electronic RPM speed not working Voltage: 380 V Width: 500 mm Depth800 mm Total height: 1100 mm Weight: approx 150 kg

Condition: used, Year of construction: 1982, Column Drilling Machine GSP type 205 R Spindle: Ø 100 mm Cone CM4 Spindle exit: Ø 300 mm Rotation: from 12 to 1800 RPM Table size: 800 x 400 mm Year of construction: 1982 Maxi distance spindle nose/tablein low position: 700 mm Mini distance spindle nose/table: 250 mm Hsdpfezmxygjx Adzsr Throat depth: 400 mm Cross-table 1150 x 400 mm Drilling/tapping function Automatic spindle advance The manual descent of the spindle is hard (works perfectly in automatic advance) Manual raising/lowering of the table Voltage: 380 V Width: 1300 mm Depth: 1700 mm Total height: 2700 mm Weight: approx 1,5 T

Condition: used, Year of construction: 1997, Workbench Column Drilling Machine CINCINNATI PE 32 Year of construction: 1997 Spindle: CM3 Hsdpfx Adezmxx Nozer Spindle exit: 150 mm Spindle speed: from 100 to 3800 RPM Table travel X: 290 mm / Travel Y: 150 mm Speed variator by belt variator Maxi height base/spindle nose: 500 mm Mini height base/spindle nose: 260 mm Throat depth: 300 mm Spindle sleeve diameter: Ø 80 mm Equipped with one cross table dimensions: L 430 x W 240 mm Voltage: 380 V Width: 900 mm Depth: 1100 mm Total height on base: 2000 mm Weight: approx 400 kg

Condition: good (used), Column Drilling Machine ALZMETALL AB3 ESV Spindle: CM3 Rotation: 1 range 220 -800 RPM + 1 range 800-2900 RPM Table size: Length 615 mm x Width 470 mm Spindle travel: 160 mm Throat depth: 280 mm Speed adjustment by belt drive Rotative table at 360° Automatic Descent 3 speeds: 0,006 - 0,12 - 0,18 mm/min. Lubricant pump Hedjzmxw Espfx Adzer Voltage: 380 V Width: 800 mm Depth: 1300 mm Total height: 1900 mm Weight: approx 800 kg

Condition: good (used), Year of construction: 1972, Drilling capacity in steel 70 mm Drilling capacity in cast iron 80 mm Hedpfxjt Uzk Ro Adzjr Spindle holder MK 5 Spindle projection 400 mm Spindle stroke 240 mm Column diameter 250 mm Speed range, infinitely variable 45 - 1325 rpm 5 feeds 0.1, 0.14, 0.2, 0.28, 0.4 mm/rev Table size 880 x 660 mm Motor power 3 kW Dimensions L x W x H 880 x 1200 x 2500 mm Machine weight 1400 kg Accessories / Special features: - Infinitely variable speed adjustment via PIV gearbox and reduction gear - Large clamping table 880 x 660 mm - Feed via cross lever - Large drilling depth adjustment with 240 mm fixed stop - Swivel table - Emergency stop switch - Coolant system Siegfried Volz Machine Tools Rüschebrinkstr. 151-153 DE - 44143 Dortmund - Wambel
