Used Erlo Drilling Machines for sale (67,664)

Condition: good (used), Year of construction: 1990, power: 3 kW (4.08 HP), rotational speed (max.): 1,280 rpm, total width: 2,000 mm, total length: 2,000 mm, total height: 2,300 mm, table width: 400 mm, table length: 1,200 mm, Drilling machine Erlo - TCA 45 BV MACH-ID 9361 Make: Erlo Type: TCA 45 BV Year: 1990 Max. drill Ø steel:45mm Max. drill Ø cast: 50mm Max. tap Ø: 40M Ijdpfxezcnnae Aaystk Stroke pinole: 280mm Throat: 470mm Spindle Taper: 5ISO/Bt/Mk Speeds / ranges: 1280Rpm Table Length: 1200mm Table Width: 400mm Power: 3kW Length: 2000mm Width: 2000mm Height: 2300mm Weight: 2800kg Please Note: The information on this page has been obtained to the best of our ability and belief, and from the manufacturers where possible. It is given in good faith, but its accuracy can not be guaranteed. Accordingly, it will not form a representation or constitute contractual terms. We advise you to check any vital details!

Condition: ready for operation (used), Year of construction: 1965, functionality: fully functional, travel distance X-axis: 1,600 mm, travel distance Y-axis: 1,200 mm, travel distance Z-axis: 1,150 mm, spindle speed (max.): 6,000 rpm, table load: 6,000 kg, No minimum price – guaranteed sale to the highest bidder! TECHNICAL DETAILS Travel range, X-axis: 1,600 mm Travel range, Y-axis: 1,200 mm Travel range, Z-axis: 1,150 mm Spindle speed: 20–6,000 rpm Work table: 1,200 × 1,400 mm Table load: max. 6 t Please note the following: The height and weight of the asset must be taken into account when selecting the transport vehicle. There is no loading dock on site. However, a forklift or an overhead crane is available for loading. Itedpfx Aaszuzpaeyok If the asset is not collected on time, a storage fee of €20.00 per lot and per day (or part thereof) will be charged. The fee must be paid before collection. The sale is made without any warranty or guarantee. The information on the technical data is based on the original offer. No liability is accepted for typographical or measurement errors. In case of doubt, please compare the information with the provided photos or inspect the item on site before the auction ends.

Condition: used, machine/vehicle number: 008013, X axis working area: 5780 mm Y axis working area: 1650 mm Working Table: Pod and Rail Main Electrospindle power: 13.2 KW Number of controlled axes: 4 axes Maximum edge height: 60 mm Total number of drilling spindles: 16 Itjdpfx Aaswuz Eksyok Total number of tool changer positions: 16

Year of construction: 1994, condition: good (used), machine/vehicle number: 491P, Technical data: - Drilling capacity in steel ST 60: 28 mm Ijdpfx Ajdkx Aneaystk - Drilling diameter in steel ST 60: 32 mm - Drill spindle mount: MK 3 - Right/left rotation - Drill spindle stroke: 150 mm - Drill spindle speeds, stepless: 80 - 1170 rpm - 2 feed rates: 0.1 / 0.2 mm/rev - Overhang: 290 mm - Max. distance table - drill spindle: 780 mm - Table with 2 T-slots: 480 x 400 mm - Height adjustable via rack and pinion with hand crank - Drive: 400 V / 0.9 / 1.3 kW - Space requirement, approx.: W 600 x H 2100 x D 900 mm - Weight, approx.: 420 kg - Includes: - Coolant system - Quick-change drill chuck 1-13 - Lighting

Condition: used, Year of construction: 1965, bore capacity in steel (diameter) 40 mm total power requirement 4 kW Iodpfx Aasv S Iqcoyjtk

Condition: good (used), Year of construction: 2013, total length: 3,990 mm, total height: 2,500 mm, total width: 2,280 mm, overall weight: 8,500 kg, INGERSOLL CM SYSTEMS AOHD AGILE OIL HOLE DRILL Equipped with: Siemens 840D Control (2) Drill Heads 20-Tool Rack HSK 50A Taper (2) 7" 3-Jaw Chucks (2) Tailstocks (2) Steady Rests Chip Auger Chip Conveyor Itedpfjrtrx Rox Aaysk Mist Collector Hydraulic System Q R 2 Lube System Air Compressor Specifications: Maximum Length: 1050 mm (41.3") Minimum Length: 180.0 mm (7.1") Maximum Stroke: 250.00 mm Maximum Main Journal Diameter: 115.0 mm (4.5") Maximum Pin Journal Diameter: 100.00 mm (3.9") Maximum Swing Diameter: 250.0 mm (9.84") X-Axis Travel: 1450 mm (57.1") Y-Axis Travel: 150 mm (5.9")W/HSK 50 Z-Axis Travel: 305.0 mm (12.0") A-Axis Travel: 360 Degree B-Axis Travel: 90 Degree Feed Rate (Z): 1 m/min Maxim (40"/min max) Position Accuracy of X,Y,Z Axes: .010 mm (.00039") Position Accuracy of A & B Axes: .03 Degree Position Repeatability of X,Y,Z Axes: .005 mm (.0002") Position Repeatability of A & B Axes: .005 Degree Spindle Power: 5.5 kW (7.5 hp) Spindle Speed: 0-6,900 RPM Tool Adaption: HSK 50E or A Tool Storage (ATC): 20 Total - 10 Per Spindle W/HSK 50 Lubrication - Slides & Ball Screws: Automatic Central Lubricator Approximate Floor Space (LxWxH): 4.0 x 2.3 x 2.5 m (13.1 x 7.5 x 8.2 Ft) Approximate Machine Weight: 8,500 kg (18,740 #)

Condition: good (used), *FOR SALE: Cincinnati Milacron PTC 40 Column Drill – 1982* *Price:* €2,200 – Negotiable *Location:* Les Ponts-de-Cé, 49130, Pays de la Loire *Description:* Industrial column drill *CINCINNATI MILACRON PTC 40*, manufactured in 1982. Isdpfezvgr Aox Aayjtk French made. Very robust machine for drilling and tapping in mechanical and sheet metal workshops. Column with cross table mounted on slides. Remote control + foot pedal. Complete and fully operational machine. *Specifications:* - *Make / Model*: CINCINNATI MILACRON PTC 40 380V - *Year*: 1982 - Serial No. 45117 - *Type*: Column drill on a base - *Table*: Cross table mounted on slides - *Feed*: Spindle descent via handwheel + lever - *Equipment*: Remote electrical cabinet, Foot pedal, Vises - *Mounting*: On a pallet for removal

Condition: good (used), functionality: fully functional, drilling depth: 600 mm, workpiece weight (max.): 2,000 kg, travel distance X-axis: 750 mm, travel distance Y-axis: 630 mm, travel distance Z-axis: 300 mm, spindle speed (max.): 3,000 rpm, drill diameter: 35 mm, drill spindle length: 600 mm, spindle mount: MK 2, spindle stroke: 600 mm, number of spindles: 1, Equipment: rotational speed infinitely variable, Driling capacity: Ø 35 mm Driling depth: 600 mm X-axis: 750 mm Y-axis: 630 mm Z-axis: 300 mm Spindle speeds: 0 - 3000 rpm Tabel size: 1100 x 650 mm Load on table: 2000 kg max Isdpfx Aaozu Sp Reyetk Turning table: 360° Controller: Degen AE30 Including: - Cabinet + pallet with drills - Coolingunit - Machine manuals Country of origin: Germany Motor power: 11,2 kVA Machine LxWxH: 350 x 120 x 175 cm Machine weight: 1300 kg

Condition: excellent (used), Year of construction: 1994, tool diameter: 60 mm, spindle mount: MK 5, rotational speed (max.): 1,460 rpm, total width: 1,100 mm, total length: 2,300 mm, total height: 2,400 mm, table width: 580 mm, table length: 1,400 mm, overall weight: 2,700 kg, Arm length: 1200 mm Max. drilling diameter in cast iron: 60 mm Max. tapping diameter: 40M Max. drilling diameter in steel: 50 mm Stroke of quill: 110 mm Max. distance spindle to table: 1165 mm Min. distance spindle to table: 300 mm Floor/table area: 1400 x 580 mm Speeds/ranges: 1460 rpm Spindle taper: 5ISO/BT/MK Length: 2300 mm Width: 1100 mm Height: 2400 mm Weight: 2700 kg Itjdpfx Aezvfn Noayek

Condition: used, Year of construction: 1994, bore capacity in steel (diameter) 35 mm throat 300 mm bore stroke 180 mm turning speeds 55 - 1450 U/min taper MK 4 column diameter 145 mm total power requirement 2,2 kW weight 500 kg dimensions 800 x 1000 x 2000 mm Features: - Heavy-duty pillar drill - Infinitely variable speed control (V-belt) - Automatic spindle feed * with electromagnetic engagement - Pole-changing motor - Right/left rotation of the drill spindle - Fixed drilling depth stop - Machine table with 2 T-slots * height-adjustable via hand crank - Coolant system - Machine vise Iedpfx Aszu Tk Neayjtk - Drill chuck - Emergency stop

Condition: new, 6-sided drilling machine Manufacturer: Quick Type: KQ-63E New machine Technical data: - Workpiece length: 70 - 2800 mm - Workpiece width: 50 - 1220 mm - Workpiece thickness: 9 - 60 mm - Min. workpiece to be processed: 70 x 50 mm - Feed rate in X: 135 m/min - Feed rate in Y: 90 m/min - Feed rate in Z: 25 m/min - Individually controllable spindles: Top: 2 x 12 vertical, 4 horizontal / Bottom: 1 x 7 vertical - Machine control: Higerman (German) - Milling spindle (top): 9 kW, 24000 rpm - Tool changer (top): 5-position - Milling spindle (bottom): 3.5 kW, 18000 rpm - Motors: Brushless servo motors - Positioning accuracy: 0.03/1000 - Repeatability: 0.02/1000 Optional: - Machine with workpiece return Quickly found Offer machines Register for newsletter Unsubscribe from newsletter Contact us Itedpfx Aozvgn Djaysk Overview

Condition: new, Six-sided drilling machine Iodpfx Aaezvgndeyetk Manufacturer: Quick Type: KQ-62Lite New machine Technical data: - Workpiece length: 70 - 2,400 mm - Workpiece thickness: 9 - 60 mm - Workpiece width: 30 - 1,220 mm - Min. processing size: 50 x 70 mm - Transport speed in X: 138 m/min - Transport speed in Y: 90 m/min - Transport speed in Z: 28 m/min - Machine control: Higerman - Working height: 890 mm - Milling spindle: 2 x 3.5 kW, 18,000 RPM, manual tool change - Drilling unit: Top 9 vertical and 4 horizontal / Bottom 7 vertical - Positioning accuracy: 0.03/1000 - Repeatability: 0.02/1000 - Power consumption: 25.8 kW Optional - Machine including workpiece return Other configurations available upon request.

Condition: new, Year of construction: 2023, machine/vehicle number: 320542/B, functionality: fully functional, number of axes: 3, controller manufacturer: TPA, CNC Drilling and Milling Machine Manufacturer: Vitap Type: K3 New machine Through-feed processing, workpiece machining from below, and automatic workpiece return to the operator Develop an individual class: - With this machine, you can perform many different milling operations in addition to grooving and drilling, from simple edge milling to milling shapes and letters. - We do not limit your creativity. Easy entry into CNC technology: - TPA makes it easy for you: Whether drilling, grooving, linear milling, contour milling, or milling letters. - The CAD software clearly displays the machining operations. - Particularly clear is the programming of the work steps on the individual workpiece sides. - You can mirror machining operations with a mouse click. - You can either enter the starting points precisely or determine them by clicking on the virtual workpiece. Vitap Bar Nesting - efficient and time-saving - This patented software produces entire corpus elements from a long workpiece. - You insert the long workpiece, and when you remove the first finished element, the machining of the next element continues directly. The DDT feed system (double dynamic transport) - 2 clamps enable uninterrupted workpiece transport. - The operator inserts the workpiece until it reaches the stop. - Both clamps then grip the workpiece and position it precisely. - During machining, both clamps communicate with each other, so that clamp 2 grips before clamp 1 releases. - This ensures a constant feed rate even during linear milling. 3 controlled axes: - X axis - DDT feed - Y axis - Drilling head travel - Z axis - Drilling - Double "0" reference: New laser generation for detecting the beginning and end of the workpiece. The program can readjust the drilling from below to achieve perfect alignment in vertical and horizontal workpieces. The laser consists of a transmitter and receiver to avoid errors with dark edge material. - Side stops with rollers, consisting of a fixed and a movable part, mechanical digital readout with automatic alignment to the 0 stop for removal of up to 3 mm on the 0 line - Constant side pressing device for precise positioning to the 0 line - Automatic 4-position tool changer - Adjustable zero point - No workpiece length limitation - Monitor LCD TFT 20" - Industrial PC - Operator interface WSC with Lister, parametric tool, and parametric setup - Graphical programming CAD TPA EDI32, basic version - USB port - Storage of all files - Macro programming - Import DXF files Technical data - Number of independent, vertical spindles: 12 - Number of independent, horizontal spindles on the X axis: (2+2) - Number of horizontal drilling spindles on the Y axis: (2+2) - 1 saw (100mm) - Electro spindle 5 kW with ISO30 taper (RPM [contact removed]) - Max. workpiece weight: 40 kg - Max. workpiece dimensions: X unlimited, Y 1250 mm, Z 50 mm - Min. workpiece dimensions: X 270, Y 150 (70op), Z 3 mm - Feed rate: 25 m/min - Spindle speed: 3600 RPM Iodpfx Aozvduueaystk - Saw speed: 7000 RPM - Max. horizontal tool: 12mm - Max. drilling depth horizontally on the X and Y axis: 35mm - Max. drilling depth vertically: 43 mm - Max. vertical tool: 35mm - Motor: 1.7 kW - Adjustable zero point for 4-sided formatting - CE compliant Optional against additional charge

Condition: ready for operation (used), Year of construction: 1960, Available immediately ex-works: Bench drilling machine, Scharmann Type FB 125 b Itedpfxjzu I Eue Aayek Year of manufacture 1960 Complete retrofit in 2010 Spindle 125 mm Metric 80 / SK 50 spindle mount Quill stroke 800 mm Table 1600 x 1200 mm Table traverse 2000 mm Spindle / table installation height 1400 mm Table longitudinal travel 2500 mm Spindle speeds 5 – 740 rpm, 7.5 – 1100 rpm For Wohlhaupter machining: 5 – 74 rpm 3-axis Heidenhain digital display Vertical head Large Wohlhaupter boring head Various other accessories Weight 21 tons Price: EUR 9,500.00 plus VAT, ex-works.

Condition: good (used), Year of construction: 1980, functionality: fully functional, Gear-driven drill press, no belt changes required Very quiet and smooth operation - Drilling capacity in steel ST 60: 30 mm - Drill spindle mount: MK 3 - Drill spindle stroke: 160 mm - 9 drill spindle speeds: 90 - 1450 rpm - Overhang: 300 mm - Table with 2 T-slots Isdpfxozuxxfj Aayotk - Table dimensions, swiveling: 500 x 450 mm - Table dimensions, base plate: 350 x 400 mm - Distance from base plate to spindle nose: 1100 mm - Max. distance table - drill spindle: 660 mm - Height adjustable via rack and pinion with hand crank - Column diameter: 120 mm - Drive: 380 V / 1.2 kW - Space requirement: approx. W 600 x H 2100 x D 670 mm - Weight: approx. 350 kg - Includes drill chuck

Condition: used, Year of construction: 2014, Used Machine Year of manufacture: 2014 Condition: The machine has been factory-overhauled by Ganner Features and Technical Specifications: Complete standard configuration including: - Support with linear guide consisting of: 1 single-spindle horizontal drilling unit, 0.65 kW motor, 70 mm stroke Tool speed selectable via operator software (3000/5000/8000 rpm) 1 blow-out, gluing, and dowel-driving station for dowels Ø 8 mm, dowel length 25–50 mm - Fully automatic, electronically controlled central lubrication - X-axis NC-controlled, with working length 1300 mm, travel speed max. 105 m/min. Itedpfx Aajzlbrvjyok - Z-axis manually adjustable via mechanical digital counter, position adjustable via support table 5–40 mm - Dowel drive-in overhang adjustable from 7–20 mm via a mechanical digital counter; drilling depth from 0–35 mm (for drill bit length GL 70 mm) is automatically adjusted with the drive-in overhang - Closed glue system with 6 bar glue pressure via glue nozzle, for glues with a viscosity of 150 to 350 mPas - Glue quantity continuously adjustable via operator software - GLUE/WATER selector switch for flushing the glue system, each with: 1 stainless steel tank for 7.5 kg of glue and 7.5 l of water - Indicator light showing remaining glue levels in the glue tank - 1 left side stop, 1 right side stop, and 1 center stop (all removable) - 4 start buttons for individual processing of 1–4 workpieces - 4 pneumatic 10° angle clamping cylinders for workpiece thicknesses up to 80 mm, workpiece length (Y) min. 70 mm - 1 extraction funnel, connection Ø 80 mm - 1 TCT control unit with: Built-in industrial PC, including Beckhoff TWINCAT soft PLC, operating temperature range 0–50°C, 15-inch capacitive TFT industrial touchscreen, operating system: WINDOWS 7 - Programming via menu-driven user software, drilling distances freely programmable with ABSOLUTE, RELATIVE, or GRID dimensions, automatic workpiece mirroring and operation optimization, 4 work areas assignable to different programs, graphical workpiece display, parametric programming, zero-point offset, programmable worklists, error diagnosis with plain text Optional equipment: - 1 electronic, optical glue monitoring system G.I.C. (Glue Insert Control) for 1 glue nozzle - 1 Z-axis with NC-controlled, dynamic positioning for height adjustment of the drilling and dowel-driving station (programmable from 5–40 mm), travel speed max. 30 mm/sec. - 1 single-spindle vertical drilling unit drilling from the TOP, 0.65 kW, (3000/5000/8000 rpm), position (Y) manually adjustable via a mechanical digital counter from 5–40 mm, drilling depth (Z) max. 30 mm (with drill bit length GL 57 mm), Workpiece thickness (Z) max. 50 mm, workpiece length (Y) min. 130 mm (including drilling depth compensation, e.g., for Häfele Minifix) - 4 vertical 10° angle clamping cylinders with mount - 1 keypad with mount Availability: available shortly Location: DE-63934 Röllbach

Condition: used, Year of construction: 2011, Technical details: bore capacity in steel (diameter): 35 mm throat: 350 mm Itodpfjyli Sfex Aayek bore stroke: 180 mm threading: ST M 24 mm spindle taper MT: MK4 spindle speed:: 50 - 1450 U/min Distance spindle/table max.: 780 mm table clamping surface:: 560 x 560 mm weight of the machine ca.: 500 kg dimension machine approx.LxWxH: 0,73 x 0,56 x 0,22 m · Heavy, solid cast construction · Automatic gear lubrication via oil pump · Smooth running due to ground gearbox gears operating in an oil bath · High concentricity thanks to hardened and ground main spindle · Thread cutting device · Lockable main switch and motor protection switch · Optidrill B 40GSM additionally with automatic quill feed · Electric · 2 feed rates: 0.1 / 0.2 mm/rev · Coolant system · Drilling depth stop · 18 speeds: 50 – 1,450 rpm · 9 selectable speeds via gearbox lever on the front of the drill head *

Condition: used, Year of construction: 1997, Technical details: bore capacity in steel (diameter): 32 mm x-travel: 750 mm y-travel: 520 mm drill capacity in cast iron: 45 mm revolution per minute: 90 - 4500 U/min feed steps: 6 bore spindle stroke: 250 mm boring spindle diameter: 30 mm drill spindle - Morse Taper: MK4 vertical adjustment of the arm: 520 mm throat max.: 1000 mm throat min.: 250 mm column diameter: 400 mm swivel range of the arm: 180 ° table clamping surface LxW: 1150 x 800 mm total power requirement: 3,5 KW weight of the machine ca.: 2000 kg Itodpozgwgfefx Aayek dimension machine approx.LxWxH: 1,7 x 1,07 x 2,61 m The KOVOSVIT VO 32 is a robust and versatile radial drilling machine designed for industrial applications. The machine is suitable for drilling, boring, countersinking, reaming, and tapping operations in steel, cast iron, and other materials. Thanks to its swiveling radial arm and large reach, even large and heavy workpieces can be machined conveniently without the need for complex repositioning. The machine features a massive cast-iron construction, a powerful main drive, and an automatic feed system. The drilling head can be moved along the radial arm, providing a large working area. Its solid design ensures high precision, reliability, and a long service life, even under continuous operation. Equipment: ·Including coolant pump ·1 × boring tool block (boring cube) ·1 × machine vise *

Condition: good (used), WMW HECKERT BR 40/2 x 1250 radial drilling machine - Arm length: 1250mm - Maximum drilling diameter: 40mm - Morse taper: MK5 - Minimum speed: 20 RPM - Maximum speed: 1200 RPM - 3-speed gearbox with variable speed control Itodpfszury Njx Aayok - Dimensions of drilling head: (L x W x H) 710 x 710 x 500mm - Weight: 3000KG - Automatic feed - Dimensions (L x W x H): 2100 x 1000 x 2900mm

Condition: used, Year of construction: 2019, - Magazine loading system - Clamping table for frame parts - 3 horizontal, longitudinal drilling units from the rear - 4 vertical drilling units from above 1 Drilling machine Manufacturer: KOCH Type: BL 2500 NC select line - used - Year of manufacture: 2019 Workpiece dimensions Workpiece length 150 - 2500 mm Workpiece width 20 - 300 mm Workpiece thickness 10 - 50 mm Material: Solid wood Magazine loading system 1 with workpiece return. Workpiece insertion via 2 parallel-controlled servomotors. The number of workpieces in the magazine depends on the workpiece weight. Manual workpiece insertion Clamping table for frame parts 1 By inserting 3 support segments into the longitudinal drilling units, workpieces can be inserted manually and clamped with clamping cylinders and templates. This also allows for special workpiece dimensions. Work cycle triggering via 2 manual controls on the swappable control panel. 3 horizontal, longitudinal drilling units from the rear Construction width 160 mm Drilling motor 2 kW Longitudinal adjustment (X) with LCD display Vertical adjustment (Z) With dust extraction 4 vertical drilling units from above (supported on one side in a linear guide) Adjustable over the entire working width (X), reading LCD display. Adjustable in working depth (Y), reading LCD display One vertical clamping cylinder mounted directly on the unit Counterpieces for through-holes are available as an option. Drilling motor 1.5 kW at 50 Hz Drilling stroke 50 mm Speed 2,800 rpm Total drill length 70 mm With 4 rotary indexing heads with quick adjustment (for vertical drilling units) with fixed stops at 0 and 90 degrees Positioning control KOCH NUMERIC Basic 1 Positioning control with Beckhoff C6920 industrial PC Intel Celeron 2.2GHz CPU 2.5 320GB HDD 1x RS232, 2x USB, 1x Ethernet available 15-inch touch panel Operating system Windows 7: English User interface in English Input of all machine commands via the touch panel Software is prepared for an online connection. The configuration of the online connection (network) and commissioning are carried out by the customer or their software company. USB port on the PC 4 x Dynamic NC axis (with bearing control) Itjdpfxszuynhe Aayok for Z axes Connection data 1 Electrical connection 400 V, 50 Hz, 3 phases Voltage fluctuations max. + 6 % to - 10 % If protected by an RCD (residual current device) on the customer's side, an all-current sensitive (R CCB, Type B) RCD with a rated residual current of /= 300 mA must be used. Air connection 7 bar Dust extraction air velocity min. 30 m/s Note: The technical data and descriptions are a transcript of the original order confirmation. The data is for informational purposes only and is not binding.

Condition: used, Year of construction: 2018, operating hours: 500 h, Throughfeed machining, workpiece machining from below, and automatic workpiece return to the operator. 3 controlled axes: X axis - uninterrupted workpiece transport via DDT (double dynamic transport system) with a brushless motor Y axis - drilling head travel Z axis - drilling - Double "0" reference: new laser generation for detecting the start and end of the workpiece. The program can adjust the drilling from below to achieve perfect alignment in vertical and horizontal workpieces. The laser consists of a transmitter and receiver to avoid errors with dark edge materials. - Side stops with rollers consisting of a fixed and a movable part, mechanical digital readout with automatic alignment to the 0 stop for removal of up to 3 mm on the 0 line - Constant side pressing device for precise positioning on the 0 line. - Rear workpiece outlet - Automatic 4-position tool changer - No workpiece length limitation - Monitor LCD TFT 19" 5/4 - Industrial PC - Operator interface WSC with Lister, parametric tool, and parametric setup - Graphical programming CAD TPA EDI32, basic version - USB port - Storage of all files - Macro programming - Import DXF files Technical data Number of independent, vertical spindles: 12 Number of independent, horizontal spindles on the X axis: (2+2) Number of horizontal drilling spindles on the Y axis: (2+2) 1 saw (Ø 100mm) Electric spindle 5 kW with ISO30 taper (RPM 12000-24000) Max. workpiece weight: 80 kg Max. workpiece dimensions: X unlimited, Y 1200 mm, Z 50 mm Min. workpiece dimensions: X 270, Y 185 (70op), Z 4 mm Feed rate: 25m/min Spindle speed: 3500 RPM Max. horizontal tool Ø 12mm Max. drilling depth horizontal on the X and Y axis 30mm Max. drilling depth vertical: 45 mm Iodpfx Aozuxdbeayjtk Max. vertical tool Ø 35mm Air consumption 2000 m3/h Extraction speed 30 m/s Extraction nozzle 2xØ. 100mm + 1xØ.50 mm Motor: 1.7 kw Compressed air: 7 bar Max. air consumption: 60 nlt/min CE STANDARDS - Office software - license - Adjustable zero point for 4-sided formatting - CE compliant - Status: 05/28/2026: approx. 500 operating hours and a new PC has been installed.

Condition: used, Year of construction: 2012, - Work area: X: 9000 mm / Y: 2700 mm - Gantry 1: 5-axis milling spindle 20/26 kW - 32-position tool changer - Gantry 2: 2x13 spindle drilling unit Technical data - Heavy-duty gantry system with 2 gantries - Gantries with drives on both sides (gantry drive) - CNC control SIEMENS 840D sl / PCU 50 with NCU 730 - Operator panel OP 15 with 15" display, mounted on a guide rail along the longitudinal axis Work area / machinable cube size with tool length/diameter of 160 mm - X-axis: 9000 mm with both gantries - Y-axis: 2700 mm - Z-axis: (Standard cube size 420 mm) - Customer-specific design for workpiece thicknesses up to 60 mm - 5-axis head Equipment, Gantry 1 - 1 universal head for 5-axis milling - Milling spindle power: 20/26 kW (S1/S6) - Speed adjustable up to 24,000 rpm - Water-cooled - Tool interface HSK F63 for automatic tool changes - Thread cutting is possible! - 1 chain-type tool magazine with 32 positions - With rotary gripper for fast tool changes - Magazine fixed on the operator side Equipment, Gantry 2 - 2 head mounting brackets - Equipped with 2 heavy-duty multi-spindle drilling units each - With common dust extraction hood - Each drilling unit with 13 drilling spindles (total of 26 drilling spindles) - Individually selectable vertically - Arrangement in an L-shape - 2 angled drilling spindles adjustable from 0 - 25° - 1 right, 1 left, each approx. 2.2 kW, n= 2800 rpm Itodpfezuw Ixox Aaysk - Drill chuck collet Rego Fix ER 25 M Machine table - Base frame with linear guide - 12 table traverses on a linear guide for positioning in the X-direction, individually driven and positionable via NC drives - Vacuum supply integrated into the table traverse - Each traverse is individually vacuum-monitored and linked to the machine control system Workpiece infeed function - 1 belt conveyor consisting of 4 belt strands - Width 40 mm, each traverse with lifting devices - Lifting device NC-controlled - Stroke 110 mm (+10 mm, -100 mm) - The machine should be installed in a foundation pit of approx. 300 mm - Vacuum pump Bush type: Mink MM 1322 - Suction capacity 250 m³/h - With intermediate tank 500 l for rapid vacuum generation - 2 chip transport belts under the machining area for the removal of chips and/or small swarf up to a size of max. 100 x 100 x 100 mm - Automatic central lubrication Work safety - Moving protective cabin on both gantries - Protective cabin with safety bumpers and safety light curtain system on the operator and rear sides (due to automatic table adjustment)

Year of construction: 1985, condition: used, Drilling process: single-lip gundrilling, operating method: rotating tool, number of working spindles: 1, nominal drilling depth: approx. 750mm, drilling range for solid drilling in steel: approx. 30mm, drilling range for counterboring in steel: approx. 40mm, spindle drive: 11kW, max. spindle speed range I: 1800rpm, max. spindle speed range II: 5700rpm, max. feed rate range I: 320mm/min, max. feed rate range II: 160mm/min, rapid traverse: 3.5m/min, clamping table X/Y: 420mm/1280mm, cross-slide table manually operated, max. transverse travel: 400mm, table clamping surface X/Y: 600mm/600mm, high-pressure coolant system for deep-hole drilling oil with 1000l coolant tank, flow rate: approx. 2-94l/min, max. pressure at max. flow rate: 45bar, pump power: 11kW, separate control cabinet. The machine underwent an extensive partial overhaul in 2018, during which the machine was disassembled and cleaned, all guideways and support surfaces were ground and partially scraped, motors were inspected and fitted with new bearings, the drilling spindle was fitted with new bearings, the ball screw incl. nut was replaced, the pump motor was overhauled, the wiper set was replaced, and the machine was repainted and all functions were checked and rectified. Including extensive accessories. Documentation available. Inspection possible by arrangement. Iodpfxozu Szyj Aaystk

Condition: good (used), Please refer to the images for all technical specifications. Transport and loading can be arranged throughout Europe for an additional charge upon request. Prices are subject to VAT. Viewing is possible by appointment. Contact us—our team looks forward to assisting you. Machinery purchase / sale PURCHASE / SALE OF PRODUCTION & METALWORKING MACHINES, MACHINE TOOLS, AND MUCH MORE. Do you need a high-quality yet affordable machine for your production? Or are you looking to sell yours? For further information or contact options, please reach us via the contact form. Itodpfszvnnfex Aayek

Condition: ready for operation (used), Year of construction: 2012, WAGNER PRC 40 – Outrigger drilling machine / Radial drilling machine - Year of manufacture: 2012 - CE marking - COMPLETE TECHNICAL DATA – SEE PHOTO - Automatic feed - Morse taper MK 4 Iedszi Av Dspfx Aayotk - Speed range: 25-2000 RPM - Coolant system - Rotary table - Documentation Dimensions: L x W x H 2.5 x 1.1 x 2.65 meters / Weight: 3500 kg Errors and omissions excepted.
