Used Fadal Vmc 4020 Fx for sale (543)

Condition: ready for operation (used), Fadal vertical machining center, model VMC 4020FX, table size 1200x500 mm, travels: X1000 mm, Y500 mm, Z500 mm. 10,000 rpm, high-pressure coolant through spindle, spindle taper CAT 40. 24-position automatic tool changer. CNC Fanuc type Oi-MC. Pgodeympgfjpfx Ag Djk

Condition: used, Year of construction: 1995, x-axis 1000 mm Psdpfx Ajyqwccjg Dogk y-axis 500 mm z-axis 500 mm dividing head CNC Axles 4 spindle taper ISO 40 table surface area 1200x508 mm control Fadal CNC 88 HS Table load 600 kg turning speeds 40-7500 U/min Number: 9505858 Tool changer 21 The tech. Data are manufacturer or operator information and therefore non-binding. We reserve the right to prior sale; Our terms and conditions of sale apply exclusively. About us More than 400 of our own machines in stock Over 15,000 m² of storage space, 70 t crane capacity More than 10,000 items and accessories for your workshop If you are interested in selling machines, production lines, or your business, please contact us. You can find further offers on our website. Tours are possible by appointment. We look forward to your visit. Your Markus Hirsch Team

Condition: ready for operation (used), Year of construction: 2007, travel distance X-axis: 1,016 mm, travel distance Y-axis: 508 mm, travel distance Z-axis: 508 mm, table load: 1,652 kg, overall weight: 4,990 kg, spindle speed (max.): 8,000 rpm, spindle motor power: 16,000 W, tool weight: 6,800 g, number of axes: 3, This 3-axis FADAL 4020 FX vertical machining centre was manufactured in 2007. It features an impressive X-axis travel of 1,016 mm, Y-axis travel of 508 mm, and Z-axis travel of 508 mm. The machine includes a robust table size of 1,219 x 508 mm and a maximum table load of 1,652 kg. If you are looking to get high-quality machining capabilities, consider the FADAL 4020 FX machine we have for sale. Contact us for further details. • Table • Size: 48" x 20" (1,219 x 508 mm) • T-slots: 5 x 18 mm x 95 mm • Feed rates • Cutting feed (X/Y/Z): 800 ipm (20.32 m/min) • Rapid traverse: 1,000 ipm (25.4 m/min) • Accuracy • Positioning accuracy: ±0.0002" (±0.0050 mm) • Repeatability: ±0.0001" (±0.0025 mm) • Spindle • Orientation: Electromechanical • Drive: AC vector drive • Power Pgedpfsyn Eh Iex Ag Djk • Spindle motor: 17.75 HP (22.1 HP peak) • Torque: 39 ft-lbs (78 ft-lbs peak) • Optional high torque: 15 HP / 227 ft-lbs • Tool changer (ATC) • Capacity: 21 tools (30 optional) • Selection: Random, bi-directional • Max tool diameter: 76 mm (114 mm without adjacent tools) • Max tool length: 381 mm • Machine data • Power requirement: 76 A, 230 V, 3-phase • Air requirement: 120 psi, 15 scfm Technical Specification Taper Size ISO 40

Condition: good (used), Year of construction: 2000, functionality: fully functional, travel distance X-axis: 1,016 mm, travel distance Y-axis: 500 mm, travel distance Z-axis: 700 mm, For Sale: Fadal VMC 4020 Vertical Machining Center Well-equipped and reliable vertical machining center — ideal for precision production and toolroom work. Specifications: Pgodpoxp Unxsfx Ag Dek Spindle: BT-40, 10,000 rpm, 22 HP Travel: X = 1,016 mm (40"), Y = 508 mm (20"), Z ≈ 700 mm (extended Z-axis) Table size: 1,219 × 508 mm (48" × 20"), load capacity 680 kg Tool changer: 24-position automatic tool changer (ATC) Control: Fadal 32MP – dependable and easy to use (compatible with FANUC G-codes) Machine equipped with the extended Z-axis for greater flexibility and capable of handling a wide range of machining applications.

Condition: used, travel distance X-axis: 762 mm, travel distance Y-axis: 406 mm, travel distance Z-axis: 508 mm, Milling machine, second-hand Make: Fadal Model: 904-1 VMC 3016 Podpetud Utjfx Ag Djgk Year of manufacture: Serial No. 9401487 Technical data: X-travel 762 mm Y-travel 406 mm Z-travel 508 mm Spindle holder: SK 40 Spindle speed 8000 rpm Machine weight: 3800 kg

Condition: ready for operation (used), Year of construction: 2000, A CNC vertical machining center Fadal with increased torque is available. Travel X/Y/Z: 1140mm/635mm/61mm, table dimensions X/Y: 1350mm/635mm, rapid traverse X/Y: 25m/min, rapid traverse Z: 17m/min, max. feed rate: 15m/min, positioning accuracy: +/-0.004mm, repeatability: +/-0.0015mm, spindle speed: 10000rpm, tool interface: SK40, max. spindle torque: approx. 360Nm, tool stations: 24. Machine dimensions X/Y/Z: approx. 3300mm/2600mm/3050mm, weight: approx. 6000kg, control: Siemens. Documentation available. On site inspection is possible. Podpfx Aeyhgpgsg Djgk

Condition: repair required (used), Year of construction: 1995, functionality: not functional, travel distance X-axis: 762 mm, travel distance Y-axis: 406 mm, travel distance Z-axis: 711 mm, feed length X-axis: 762 mm, feed length Y-axis: 406 mm, feed length Z-axis: 711 mm, feed rate X-axis: 10,000 m/min, feed rate Y-axis: 10,000 m/min, feed rate Z-axis: 10,000 m/min, torque: 166 Nm, controller manufacturer: Fadal, table width: 406 mm, table length: 990 mm, rotational speed (min.): 150 rpm, rotational speed (max.): 7,500 rpm, overall weight: 2,700 kg, spindle speed (min.): 150 rpm, spindle speed (max.): 7,500 rpm, spindle motor power: 11,187 W, spindle nose: ISO 40, number of slots in tool magazine: 21, tool length: 380 mm, tool diameter: 76 mm, tool weight: 7,000 g, input voltage: 400 V, type of input current: three-phase, Equipment: documentation/manual, rotational speed infinitely variable, We offer this in need of repair Fadal VMC15XT vertical machining center, year of construction 1995. Manufacturer: Fadal Model: VMC15XT Year of construction: 1995 Bought new by us back in the time. Was in working condition when we stopped using it (about 10y ago) because of production changes. Now it won't start. We didn't invest any time troubleshooting the issue as the machine needs to go to make room. This is the XT version, also extended Z-axis travel (711mm) Travels (X-Y-Z): 762-406-711mm Table 990x406mm Spindle 15HP, 150-7500RPM Psdpfxjy Eni Ro Ag Degk Spindle taper size ISO 40 Machine weight 2700kg Machine is complete including 4th axis, all documentation and manuals. Nice project machine or spare parts source for another Fadal. Price is EXW. Loading to be discussed and arranged. Category ID: 1451 Type ID: 4156 Machine type: vertical machining center If you have any questions or need more information, feel free to send us a message or give us a call.

Condition: used, We are offering used shelving units for sale. TECHNICAL DATA Manufacturer: FX Rauscher Model: P30 Condition: used Frame height: approx. 2,500 mm Shelf dimensions: 1,220 x 400 x 33 mm Shelf load capacity: 100 kg Number of levels: 6 Boltless assembly Usage: single-sided Material: galvanized steel PRICE €1,216.25 net (5 starter bays + 20 add-on bays) €1,447.34 gross incl. VAT Tiered pricing Starter bays: 1 - 5 units: €70.00 net 6 - 20 units: €66.63 net 21 - 50 units: €63.25 net from 51 units: €59.88 net Add-on bays: 1 - 5 units: €50.00 net 6 - 20 units: €47.50 net 21 - 50 units: €45.00 net from 51 units: €42.50 net Large quantities available directly from stock. YOUR CONTACT PERSONS AT OUR COMPANY: Oliver Kopp Rainer Nürenberg Tanja Henkelmann TRANSPORT & ASSEMBLY We are happy to assist you with transport and assembly of the goods. This item is available for collection. Delivery or shipping is available at an additional charge, depending on the destination and the size of the shipment. Please contact us for a customized quote. PROJECT PLANNING Our sales team will be happy to prepare a non-binding offer tailored to your requirements. TRANSPORT & ASSEMBLY We are happy to assist you with transport and assembly of the goods. Psdpfey Hqt Isx Ag Dogk PAYMENT TERMS Payment terms will be agreed upon in case of an order. The price is the unit/net price unless otherwise stated in the description (plus VAT). Of course, you will receive an invoice showing VAT separately. ABOUT US DLK, based in Nordhorn, deals in new and used products in the fields of warehouse logistics, conveyor technology, mezzanines, textile storage systems, as well as machinery for commerce, industry, and trades. We continuously offer attractive second-hand equipment from various manufacturers and brands at competitive conditions. If you have any questions, please feel free to contact us. ‘Four wins’—the four success factors from DLK: Storage Technology | Levelmaker® | Logistics | Solutions

Condition: used, We offer used shelving racks here. TECHNICAL DATA Manufacturer: FX Rauscher Type: P30 Condition: used Frame height: approx. 2,500 mm Shelf size: 1,220 x 400 x 33 mm Compartment load capacity: 100 kg Number of levels: 6 pcs Boltless assembly Use: single-sided Material: galvanized steel PRICE €85.20 net (1 starter bay) Pgodjy Hqtnspfx Ag Djk €101.39 gross, incl. VAT Quantity discounts Starter bays: 1 - 5 units: €70.00 net each 6 - 20 units: €66.63 net each 21 - 50 units: €63.25 net each from 51 units: €59.88 net each Add-on bays: 1 - 5 units: €50.00 net each 6 - 20 units: €47.50 net each 21 - 50 units: €45.00 net each from 51 units: €42.50 net each Large quantities available directly from stock. YOUR DIRECT CONTACTS AT OUR COMPANY: Oliver Kopp Rainer Nürenberg Tanja Henkelmann TRANSPORT & ASSEMBLY We are happy to assist you with transport and assembly. This item is available for collection. Delivery or shipping can be arranged at an additional charge. The extra costs depend on the delivery location and order volume and can be quoted individually on request. PROJECT PLANNING Our sales team will gladly prepare a non-binding, tailored quotation according to your specifications. PAYMENT TERMS Payment terms are to be agreed upon at the time of order. The price is per unit/net price as described above (plus VAT). You will, of course, receive an invoice with VAT shown. ABOUT US The company DLK in Nordhorn trades in new and used products from the areas of warehouse logistics, conveyor technology, mezzanine floors, textile storage, as well as machines for trade, industry, and craft sectors. We continuously offer interesting used equipment from various manufacturers/brands at attractive conditions. Please do not hesitate to contact us with your questions. Vier gewinnt – The Four Success Building Blocks of DLK – Warehouse Technology | Levelmaker® | Logistics | Solutions

Condition: used, We are offering used shelving systems for sale here. TECHNICAL DATA Manufacturer: FX Rauscher Type: P30 Condition: Used Frame height: approx. 2,500 mm Shelf dimensions: 1,220 x 400 x 33 mm Shelf load capacity: 100 kg Number of levels: 6 pcs Boltless assembly Usage: single-sided Material: Galvanized steel PRICE €270.00 net (1 starter bay + 4 add-on bays) €321.30 gross incl. VAT Tiered pricing Starter bays: 1 - 5 pcs: €70.00 net each 6 - 20 pcs: €66.63 net each 21 - 50 pcs: €63.25 net each from 51 pcs: €59.88 net each Add-on bays: 1 - 5 pcs: €50.00 net each 6 - 20 pcs: €47.50 net each 21 - 50 pcs: €45.00 net each from 51 pcs: €42.50 net each Large quantities available ex-stock. YOUR CONTACT PERSONS: Oliver Kopp Rainer Nürenberg Tanja Henkelmann Pedpoy Hqr Rsfx Ag Dogk TRANSPORT & ASSEMBLY We are happy to assist you with transport and assembly. This item is available for collection. Delivery or shipping is available at an additional charge. Additional costs depend on the delivery location and shipment size and can be provided upon request. PROJECT PLANNING Our sales team will gladly prepare a non-binding offer tailored to your requirements. TRANSPORT & ASSEMBLY We are happy to assist you with transport and assembly. PAYMENT TERMS Payment terms are to be agreed upon order placement. Prices are quoted per item/net price or as specified in the description (plus VAT). You will, of course, receive an invoice showing VAT. ABOUT US DLK, based in Nordhorn, deals in new and used products for warehouse logistics, conveyor technology, mezzanine platforms, textile storage, as well as machinery for trade, industry, and crafts. We regularly offer attractive used equipment from various manufacturers/brands at competitive terms. If you have any questions, please feel free to contact us. Four wins – The success modules of DLK – Warehouse technology | Levelmaker® | Logistics | Solutions

Condition: used, We are offering used shelving units here. TECHNICAL DATA Manufacturer: FX Rauscher Type: P30 Condition: Used Frame height: approx. 2,500 mm Shelf dimensions: 1,220 x 400 x 33 mm Shelf load capacity: 100 kg Number of levels: 6 pcs Boltless assembly Use: single-sided Material: galvanized steel PRICE €506.50 net (2 starter bays + 8 extension bays) €602.74 gross incl. VAT Tiered Pricing Starter bays: 1 - 5 pcs: €70.00 net y6 - 20 pcs: €66.63 net 21 - 50 pcs: €63.25 net from 51 pcs: €59.88 net Extension bays: 1 - 5 pcs: €50.00 net 6 - 20 pcs: €47.50 net 21 - 50 pcs: €45.00 net from 51 pcs: €42.50 net Large quantities are available directly from stock. YOUR CONTACT PARTNERS: Oliver Kopp Rainer Nürenberg Tanja Henkelmann TRANSPORT & INSTALLATION We can assist you with transport and assembly of the goods. This item is available for collection. Delivery or shipping is available at an extra charge. Additional costs vary depending on delivery location and order volume and can be individually quoted upon request. PROJECT PLANNING Our sales team will gladly provide you with a non-binding, tailor-made offer according to your requirements. Pgodpfx Aey Hqrkog Djk TRANSPORT & INSTALLATION We are happy to assist you with the transport and installation of the goods. PAYMENT TERMS Payment terms are to be agreed upon in the case of an order. The indicated price is per unit/net price or as stated in the description (plus VAT). You will of course receive an invoice with VAT shown separately. ABOUT US DLK in Nordhorn trades in new and used products from the fields of warehouse logistics, conveyor technology, mezzanine floors, textile storage, as well as machines for commerce, industry, and trade. We continuously offer attractive used equipment from various manufacturers/brands at competitive conditions. If you have any questions, please feel free to contact us. Four wins – The success building blocks of DLK – Warehouse Technology | Levelmaker® | Logistics | Solutions

Condition: excellent (used), For sale: Professional CNC rotary table from the renowned brand Fadal Engineering (USA, subsidiary of Giddings & Lewis Inc.), model VH65. Equipped with a Röhm ZG Ø125 mm lathe chuck, significantly expanding application versatility. Technical specifications: • Model: VH65 • Table diameter: 165 mm (6.5”) • Ratio: 90:1 • Pneumatic brake (M60 ON / M61 OFF) • Röhm ZG Ø125 mm lathe chuck – max 4000 rpm, torque 80 Nm • Serial number: 6660297 • Industrial multipin connector Condition: used, fully mechanically functional, normal signs of use. Sturdy, heavy-duty construction guarantees precision and long service life. Ready for use as an additional 4th axis in a machining center. Pgsdpfxow R Syis Ag Dek

Condition: used, Year of construction: 1995, functionality: fully functional, - CNC Milling Machine Fadal, Model VMC 15XT A CNC vertical machining center by Fadal, model VMC 15XT. Here are some key specifications and features: Manufacturer/Model: Fadal VMC 15XT. Travels (typical for VMC 15XT): approx. (762 × 406 × 508) mm (X/Y/Z). Equipment: Features an automatic tool changer and a spindle designed for precision machining. Origin: The machine was manufactured in the USA. - NDM-40 with Siemens SINUMERIK System 6 This machine comes from an industrial environment and is of robust construction. It is equipped with an enclosed work cabin and a tool turret. Ideally suited for metalworking, workshops, training centers, or as a reliable production machine. Features: CNC Control: Siemens SINUMERIK System 6. Tool turret. Enclosed cabin. Emergency stop and full operator panel. Industrial-grade design. Optical condition consistent with age (signs of use present, see photos). - CNC Lathe NDM-25 Technical Data & Features of the Georg Fischer NDM 25 The NDM 25 was designed as a robust machine for precision manufacturing, including applications in the automotive and aerospace industries. Manufacturer: Georg Fischer (+GF+). Machine type: CNC lathe. Control unit: Most commonly equipped with Siemens 820 T control, but other older units such as General Electric or Kongsberg have also been installed or retrofitted. Axes: 2 axes. Turning length: 600 mm. Swing over bed: 400 mm. Turret: 12 positions. Chuck capacity: 250 mm. Equipment: Typically features a tailstock and a chip conveyor. Availability and Maintenance. - CNC Lathe NDM-16 The NDM 16 is a CNC lathe manufactured by the Swiss company Georg Fischer (+GF+) and typically equipped with Siemens controls. Technical Details Pgsdpjyl I Tujfx Ag Dok The Georg Fischer NDM 16 is designed for shaft machining and is frequently used in industrial metalworking environments. Machine type: CNC lathe / turning center Manufacturer: Georg Fischer (+GF+), Switzerland Control: Various CNC controls have been used, including Siemens 840 C or older models such as General Electric Mark Century 1050 HL or Siemens Sinumerik 5 TS. Capacity: Turning diameter up to 250 mm and turning length up to 800 mm, depending on specific machine configuration. RhyMech AG lists specific capacities of 450 mm diameter and 500 mm length (170 x 500). Power: Rated at around 22 kW (30 HP). Tool system: Fitted with a 12-position VDI tool disc. The NDM 16 was produced in the 1990s and is now primarily found on the used machinery market. There are also other machines with similar nomenclature, such as the SCHIESS PENSOTTI NDM 160 vertical lathe, which is, however, a different type of machine. - EXCEL-810 CNC Vertical Machining Center "CNC" stands for Computerized Numerical Control, meaning the machine is computer-controlled. "Vertical" refers to the spindle orientation, which in this case is vertical. These machines are widely used in manufacturing and mechanical engineering for producing complex parts. Fully functional and equipped with a range of different tools. Various tools are also available (see pictures).

Condition: excellent (used), For sale: CNC rotary table from the renowned brand Fadal Engineering (USA), model VH65. Professional 4th axis designed for machining centers, especially Fadal VMC, but integration with other CNC machines is also possible using the appropriate controller. Technical specifications: • Model: VH65 • Table diameter: 165 mm (6.5”) • Gear ratio: 90:1 • Pneumatic brake (M60 ON / M61 OFF) • Industrial multipin connector • Serial no.: 4630298 Condition: used, mechanically functional, normal signs of operation. Solid and heavy construction – ideal for precise 4-axis machining. Pgodpfx Aew R St Nog Dok

Condition: used, Year of construction: 2016, feed length X-axis: 711 mm, feed length Y-axis: 406 mm, feed length Z-axis: 394 mm, Traverses X Y Z ; 711 x 406 x 394mm, Table size 864 x 381mm, table load 113 kgs, rapid feedrates 61m/min, spindle power 15Hp, spindle speed 15,000rpm, spindle taper BT40, 18 station ATC, Haas control, coolant, swarf auger. Pedpsv Sut Rjfx Ag Dogk

Condition: used, Year of construction: 2006, 2006 Hurco VM1 Vertical Machining Centre YOM: 2006 Technical Information – Hurco VM1 VMC General Data Measurements width: 1800 mm Measurements depth: 1900 mm Measurements height: 2600 mm Machine weight: 2700 kg Main drive Number of spindles: 1 Spindle speed range: 40-8000 1/min Spindle motor power: 11 kW Movement X-AXIS Movement: 660 mm X-AXIS Working Feed: 8 m X-AXIS Rapid traverse: 20 m X-AXIS Accuracy: 0.005 Y-AXIS Movement: 350 mm Pgedpfxjv Suwij Ag Dsk Y-AXIS Working Feed: 8 m Y-AXIS Rapid traverse: 20 m Y-AXIS Accuracy: 0.005 Z-AXIS Movement: 450 mm Z-AXIS Working Feed: 8 m Z-AXIS Rapid traverse: 20 m Z-AXIS Accuracy: 0.005 Workpiece Workpiece weight: 350 kg Table Outer length: 762 mm Outer width: 356 mm Delivery & Siting available at extra charge – Please ask for price.

Condition: used, machine/vehicle number: 008407, X axis working area: 6700 mm Y axis working area: 1520 mm Working Table: Pod and Rail Main Electrospindle power: 12 KW Number of controlled axes: 5 axes Total number of tool changer positions: 48 Pgsdpfx Agjycdaxs Dek

Condition: used, machine/vehicle number: 008471, X axis working area: 6360 mm Y axis working area: 1680 mm Pgedpfx Agsywaf Uj Dsk Working Table: Pod and Rail Main Electrospindle power: 12 KW Number of controlled axes: 5 axes Total number of drilling spindles: 10 Total number of tool changer positions: 36

Condition: used, machine/vehicle number: 008473, X axis working area: 4900 mm Pedpsywaf Iefx Ag Djgk Y axis working area: 1680 mm Working Table: Pod and Rail Main Electrospindle power: 12 KW Number of controlled axes: 5 axes Total number of drilling spindles: 10 Total number of tool changer positions: 36

Condition: used, Year of construction: 2021, EMAG VMC 450 MT Mfd. 2021 Control: Siemens 840D SL Machine has no production hours Description CHUCK DIAMETER: 24" MAX WEIGHT: 1100 LBS. MAX SWING DIAMETER: 31" MAX TURNING DIAMETER: 23.5" X STROKE: 30" Z STROKE: 19" MAIN DRIVE: POWER: 100 HP FULL POWER AT 800 RPM MAX SPINDLE RPM: 2,000 C AXIS POSITIONIONG TO .01MM ANGULAR DEGREES FEED DRIVE: Podpfx Ageyzkdvs Dsgk RAPIDS Z / Z: 60 / 30 M / MIN. FEED FORCE X / Z 4 / 15 kN BALL SCREW DIAMETER X / Z: 40 / 50 MM MILLING SPINDLE: POWER: 100 HP MAX SPINDLE SPEED: 7000 RPM SPINDLE TAPER: CAPTO C8 TOOL MAGAZINE: 60 EQUIPPED WITH: MINERALIT MACHINE BED SIEMENS 840 D SL FULL ENCLOSURE LEVEL PADS TURN MILL DRIVE EMAG WORKPIECE CORRECTION SYSTEM EMAG OPERATING AND SETTINGS MASKS EMAG REMOTE DIAGNOSIS Y AXIS B AXIS +/- 95 DEGREE 1000 PSI COOLANT THROUGH TOOL X-AXI CLAMPING FOR GEAR TOOTH FORMING SWARF CONVEYOR, CHAIN TYPE - REAR DISCHARGE LIFTING PUMP PAPER FILTER LOW PRESSURE COOLANT HIGHT PRESSURE COOLANT 1000 PSI PROGRAMMABLE COOLANT PRESSURE COOLANT MIST EXTRACTOR AIR BLAST CHIP FLUSH QUALITY CONTROL: WIRELESS GAUGING CALIBRATION BLK FOR PROBE TOOL GAUGING - BLUM LASER

Condition: used, machine/vehicle number: 007669, Max. panel width: 1200 mm Max. panel length: 2400 mm Pgodpfx Agou Huv Se Dok Movement system: collet

Condition: good (used), Year of construction: 1998, Bridgeport VMC1000 CNC Vertical Machining Centre (1998) Description: Type of CNC Heidenhain, Table Size: 1150 mm × 490 mm, X-Axis Travel: 1000 mm, Y-Axis Travel: 500 mm, Z-Axis Travel: 500 mm, Spindle Taper: BT 40, Spindle Speed: 8000 RPM, Number of tool pockets: 22 Psdpfxjy Hx Igo Ag Dsgk

Condition: excellent (used), Year of construction: 2012, travel distance X-axis: 2,600 mm, travel distance Y-axis: 700 mm, travel distance Z-axis: 700 mm, feed rate X-axis: 40,000 m/min, feed rate Y-axis: 40,000 m/min, feed rate Z-axis: 40,000 m/min, controller manufacturer: HeidenHain iTNC530, total height: 2,620 mm, total length: 8,400 mm, total width: 3,423 mm, table width: 750 mm, table length: 2,900 mm, table load: 2,150 kg, rotary table diameter: 750 mm, rotational speed (max.): 8,000 rpm, overall weight: 16,000 kg, operating hours of spindle: 8,295 h, coolant supply: 20 bar, spindle motor power: 35,000 W, 5-axis CNC machine (VMC) DMG MORI - DMF 260-7 MACH-ID 9609 Make: DMG MORI Type: DMF 260-7 Control: HeidenHain iTNC530 Year: 2012 Pendel screen to split working area C1 + C2 Duo (NC) Rotary table Ø 750 mm Rotation speed table 50 Rpm indexing 360 Degrees Paper filter with IKZ 40 Bar Rapid feeds in all direction 20.000 mm/Min Work load 8000 Kg Spindel (cutting) hours 8295 H X - Travel: 2600mm Y - Travel: 700mm Z - Travel: 700mm A - Axis: 360000° B - Axis: - 110 to + 110° Table Length: 2900mm Table Width: 750mm Table load: 2150 Table Ø: 750mm Feed rate X-Axis: 40000mm/min. Feed rate Y-Axis: 40000mm/min. Feed rate Z-Axis: 40000mm/min. Spindle Taper: 40ISO/Bt/Mk Power on spindle: 35kW Speeds / ranges: 8000Rpm ATC / revolver: 30 Psdpfxey Hq Tne Ag Dogk Coolant through spindle / Bar:20 Number of controlled axis: 5 Chip conveyor: Yes Coolantsystem: Yes Length: 8400mm Width: 3423mm Height: 2620mm Weight: 16000kg Please Note: The information on this page has been obtained to the best of our ability and belief, and from the manufacturers where possible. It is given in good faith, but its accuracy can not be guaranteed. Accordingly, it will not form a representation or constitute contractual terms. We advise you to check any vital details!

Condition: like new (used), Year of construction: 2020, operating hours: 250 h, functionality: fully functional, 1.1 TECHNICAL DATA 1 x Waterjet cutting machine, NCP 4020 D 1 x FANUC 31iB d 1 x IGEMS Professional 1 x BevelJet cutting heads for AWJ abrasive waterjet cutting 1 x Fixed cutting heads for AWJ abrasive waterjet cutting 2 x SM3000 feed systems 1 x KMT, Jetline 50 HP, 3.8 l/min, 4100 bar 1 x Cooling unit control cabinet 1 x Hose reel with spray nozzle 1 x Tool kit 1 x Machine zone safety guard 1 x PanelOne HMI operator interface "EDGECUT" 1 x Remote control for high-pressure pump 1 x Remote maintenance system 2 x Diaphragm pumps and 2 x extraction units 1 x Waste container 1000 l 1 x Pressure vessel 200 l or 2-ton abrasive online conveyor/online abrasive hopper 1 x Head protection package (zero-point measurement head 1) 1 x IGEMS 5X CAM 1 x MPG, portable handheld pendant 1 x Rotary unit SS (chuck 240 mm) Price €21,000 1.1.1 MACHINE DATA Table size (W x D): 4200 x 2275 mm - Machining area (W x D): 3980 x 2010 mm - X-axis travel 2D: 3530 mm - X-axis travel 3D: 3220 mm Pgsdpjxgua Aefx Ag Dek - Y-axis travel 2D: 2010 mm - Y-axis travel 3D: 1405 mm - Z-axis travel: 250 mm - Positioning accuracy (X/Y): +/- 0.050 mm/m - Repeatability (X/Y): +/- 0.025 mm - Rapid traverse (X-axis): 30,000 mm/min - Rapid traverse (Y): 15,000 mm/min - Rapid traverse (Z): 5,000 mm/min - Minimum distance between nozzles: 450 mm - Maximum distance between nozzles: 2,010 mm 1.2 CONNECTION DATA 1.2.1 MACHINE CONNECTION • Electrical connection: 3 x 400 V+PE, 16 A, 50 Hz • Pneumatic supply volume (incl. pressure vessel): 500 l/min • Pneumatic supply pressure: min. 6.5 bar 1.2.2 HP PUMP DATA/CONNECTION HP pump data: - KMT 50, Jetline, 4100 bar - 37 kW, circuit breaker at 400/50 Hz, 80 A CAD/CAM software: - IGEMS Professional

Condition: used, Year of construction: 2020, max. workpiece length 6360 mm profile spindle 1 Stück main drive 13 kW Control CNC SCM CNC Machining Center ACCORD 40 FX for windows and doors ----- INCLUDES extensive window and door tooling among others (window cutting available upon request!): Wooden windows IV 68, 78, 92 Wooden "style" windows Wood-aluminum windows Front doors Lift-and-slide doors Box windows Machine still in operation, available for viewing! Technical Summary (detailed description available upon request!): ----- - ??Working area X-Y = 6360 x 1905 Z = 350 - Automatic table with 8 support rails MATIC - L1825 - 5-axis spindle MAXI - Prisma T, HSK 63 E, 13 kW - RTCP Setting - Self-calibration system for Prisma work unit - Adjustable chip removal device on the electric spindle - Preparation for "Prisma T-S" angle gearbox - BRC - Working unit: Saw blade for face machining, 1 vertical milling cutter connection 3 vertical, independent drill heads, center distance 32 mm 3 vertical drill heads (not independent), center distance 21.5 mm, for mortise drilling 4 horizontal drill heads (2 per side, not independent), center distance 21.5 mm 2 horizontal milling heads (1 per (Page) - TRC 48 - Rear Tool Magazine 48 tool positions (excluding tool holders) Center-to-center distance between positions: 104 mm Max. tool diameter: 350 mm Max. tool length: 320 mm Max. weight per tool: 10 kg (15 kg with HSK 63 E spindle) Max. total weight on the magazine: 250 kg - MACH 5 - Quick-change system: Allows tool changes on the electric spindle in just a few seconds. Pgedpfxjy Hl Iye Ag Dsk - Pendulum operation - Automatic lubrication of the axes - eye-M operating console with integrated PC - Additional fixed control panel - TECPAD - Remote control of machine functions - Clamping jaw preparation H145 for worktable with 8 support rails - Front stop row H110 for worktable with 8 support rails - Rear stop row H110 for worktable with 8 support rails - Suction cup H110 145x145 mm - Swivel suction cup H110 145x55 mm - Swivel suction cup H110 180x65 mm - First side stop row H145 for worktable with 8 support rails Second side stop row H145 for worktable with 8 support rails Clamp H145 with round base Clamp H145 with square base N.6 Lifting devices with double stroke H145 Laser and reference stop H145 for sheet (left) - PRO-SPEED safety system - Maestro CNC - Machine operator interface and programming - Maestro ProView - Simulation software Tools are sold in the condition, scope, and with accessories as they are currently in stock. Note regarding window cutouts, tool drawings, and tool system listings: Engelfried GmbH does not guarantee that the tools actually available correspond to the systems listed and drawn. (Technical specifications according to the manufacturer - without guarantee!)
