Used Frame Grinding Machine for sale (70,442)

Condition: used, functionality: unexamined, Rated voltage 380V, 15A Grinding motor 5.5 kW Feed motor 0.37 kW Grinding belt width 200 mm Grinding belt length 1800 mm Lrodpfeznv Uwjx Am Uop Pneumatic connection 6 bar Feed speeds 6 / 11 / 16 m/min Electric table height adjustment Belt air blast Dust extraction connection 140 mm

Condition: used, Year of construction: 2014, functionality: fully functional, grinding width: 180 mm, space requirement height: 3,300 mm, grinding height: 150 mm, total height: 2,300 mm, total length: 2,700 mm, total width: 1,100 mm, input current: 35 A, input voltage: 400 V, We are offering this used Stähle-HESS Gloria frame grinding machine, manufactured in 2014, for sale. Model: Gloria Machine number: 3977 Year of manufacture: 2014 Lrjdpfszixgfex Am Usp Identification number: 3977 Frequency: 50 Hz Voltage: 400 V Current: 35 A Maximum power consumption: 4 If you have any questions or require further information, please do not hesitate to send us a message or call us.

Condition: ready for operation (used), functionality: fully functional, DESCRIPTION OF MACHINE INCLUDED A LOT BELTS A Löser abrasive belt grinding machine offers the most flexible grinding / linishing on the market today. The combination of basic machine plus a variety of contact arms and attachments offers dozens of possible Lrjdpswxrnwefx Am Usp applications for many different purposes. There are over 20 standard attachments available for this machine allowing it to be used for centerless grinding, internal polishing, grinding of hollow bodies and small radius and turbine blade finishing to name but a few. Fields of application of these abrasive belt grinding machines include: *Foundries *Medical engineering *Aircraft industry *Vehicle construction *Mechanical engineering *Specifications Abrasive belt grinding machine, type KS 350 *Grinding belt length 3000-4000 mm *Grinding belt width 5 - 75 mm Loser KS 350 Belt design features:: *Drive motor 4 kW (standard design) with fitted variable speed inverter drive *Drive wheels of 100 - 280 mm diameters = 3 - 46 mtr./sec. belt speed *Mechanical belt tensioning *In case of a belt break the drive is immediately disconnected. Therefore, the risk of an accident is eliminated. *Contact disks of 50 - 400 mm diameters, with a wide choice of grinding attachments for any kind of surface finishing * DC injection breaking unit fitted. *Maintenance-free, dust-proof contact disk bearing with permanent lubrication, contact disk change in less than 1 minute. *LÖSER abrasive belt grinding machines open up new fields of application for belt linishers that in the past could not be processed with normal belt grinders. *When using 3 to 4 m long grinding belts, the 3-contact wheel system ensures the constant and optimal belt speed no matter which contact disk diameter is being used. *Driven by the motor pully, the three pully system allows the belt which is constantly tensioned a higher degree of torque at the same motor rating. *When working with Scoth-Brite disks or belts or with felt polishing belts, the drive can be infinitely adjusted even for speeds as low as 3 mtr. /sec. Due to the advantages offered by the 3-contact point system, any required surface finishing is possible using contact disks from 50 to 400 mm, contact rolls or contact rollers from 15 to 50 mm, contact belts of 6 or 30 mm width, polishing brushes, polishing disks and polishing belts.

Condition: ready for operation (used), Year of construction: 1999, machine/vehicle number: 6624, total width: 1,000 mm, total length: 3,200 mm, total height: 1,800 mm, input voltage: 400 V, table length: 1,300 mm, power: 13.5 kW (18.35 HP), No minimum price – guaranteed sale to the highest bidder! The machine has been cleaned, repainted, and tested for functionality. Lredpfx Aezlfm Djm Uop TECHNICAL DETAILS Length of magnetic grinding table: 1,300 mm Drive: 13.5 kW Magnetic table: swiveling MACHINE DETAILS Dimensions (L x W x H): 3,200 x 1,000 x 1,800 mm EQUIPMENT Water cleaning with filter cloth Guide rail Separate control cabinet Separate control panel

Condition: used, Year of construction: 2005, machine/vehicle number: 25748, Equipped with: Central Lubrication Machine Flushing Coolant Filtering Equipment 480V, 60 Hz Electrics Headstock W/Center Tailstock W/Center Auto Loading Hydraulic System Pneumatic System Central Lubrication Coolant Filtering Equipment Specifications: Working Range of the Machine: -Centering Width: 600 - 1250 mm -Maximum Workpiece Diameter: 320 mm -Oscillation Stroke: +/-1 mm in relation to the oscillation frequency -Oscillation Frequency: 0-200 double strokes/min infinitely adjustable -Spindle Rotation Speed: 0-150 min -1 infinitely adjustable -Loading Height Above Floor: 1,050 mm Horizontal Axis Machine Column Travel: 1650 mm Headstock - Rotation: -Workpiece Rotational Speed: n2= 0-200 min-1 limited to n2=0-150 min -1 Headstock - Oscillation: -Oscillation Frequency: n2 = 800 double strokes/min -Oscillation Amplitude: =/- 1 mm Tailstock - Hydraulic Axis: -Stroke: 250 mm -Analog Transducer: Measuring length 300 mm Machine Weight: Approximate 8 Tons Approximate Space Requirements (Width x depth x height): Lrodpfxezn Az Ds Am Ujp -Machine: 3,6 x 3,3 x 3,3 meters -Switch Cabinet: 2,4 x 0,6 x 2,1 meters -Hydraulic Aggregate: 0,9 x 1,3 x 1,9 meters -Coolant Filtering Equipment: 1,3 x 1,0 x 2,0 meters Approximate Total Space Requirements: 35,5 meters

Condition: good (used), Year of construction: 1998, grinding wheel diameter: 915 mm, overall weight: 14,000 kg, GIUSTINA Grinder R242 to ground big bearings (up to 800mm). All machine's actions are controlled by Bosch Control. Beside controlling parts grinding process, the NC programs are also an operator guide for the machine set up and a source of information about wheel wear, thus allowing the operator to check wheels without opening the hood. Equipped with: Bosch CNC Control Specifications: Wheel Rotation Axis: Horizontal Grinding Wheel Size (OD): 915 mm Grinding Wheel Size, Usable Width: 65 mm Grinding Wheel Size, Peripheral Speed: 30 ms Spindle Motors: 75 kw Grinding Feedrate: 0.1 - 1000 mm/min Spindle Type: Moving Quill Angular Contact Spindle Bearings (Precision): ABEC-7 (ISO4) Slide Position Accuracy: 0.001 mm Coolant Flow Rate: 600 l/min Work Capacity (Approx) Rotary: 20 -200 Dia. In. Lodpfxsrtr D Io Am Uerp

Condition: good (used), Year of construction: 2011, LANDIS LT-2 TWIN WHEEL CNC ORBITAL CRANK GRINDER Equipped with: Landis 6400 CNC Control Siemens TOUCH HMI Arobetech Steady Rest Marposs P7 Gage System Lateral Locator Twin CBN Grinding Wheels Rotary Dresser Headstock Tailstock Rittal AC Units Specifications: Maximum Center Distance: 680 mm Lsdpfx Amsrtrxxo Ujrp

Condition: used, Year of construction: 2012, Control Siemens 840 D weight of the machine ca. 13,5 t dimensions of the machine ca. 7m x 4m x 2,75m m Accessories: Coolant tank Grinding wheels Various spare parts Operating and maintenance instructions CE conformity Dimensions: 7x4x2.75 m ( LxWxH) TECHNICAL DATA: Workpiece data: max. outer diameter: 250 mm with max. grinding wheels Ø 450 mm max. diameter to be machined over table: 375 mm Profile depth for dressable grinding wheels: 40 mm max. workpiece length: 3,600 mm max. distance between centers (1): 2,800 mm max. bevel angle: +/- 90° Number of teeth of the workpiece: 1 - 999 max. weight of the workpiece: 250 kg Ledpfx Amsxh Rqtj Ujrp Working area: Center distance between workpiece and tool spindle: 355-170 mm Radial travel: 185 mm Axial travel: 3,000 mm Swivel angle: +/- 90°

Condition: refurbished (used), Kellenberger 1500 U-175 – High-Precision Universal Cylindrical Grinding Machine Universal cylindrical grinding machine for external and internal grinding (internal grinding attachment included). - Centre distance: 1,500 mm - Centre height: 175 mm - Complete retrofit, fully dismantled and rebuilt component by component: guideways reconditioned, bearings replaced, new electrical installation and control cabinet, complete repaint, and machine geometry restored to original factory precision. - Equipped with Siemens servo motor, frequency inverter and Fagor digital readout (Fagor). - Condition comparable to a new machine, ready for immediate production. - Available with a wide range of accessories. - Inspection and live demonstration under power available. Availability: Immediate. Ledpswqlykofx Am Usrp 1000U version: Currently undergoing refurbishment.

Condition: ready for operation (used), functionality: fully functional, Brierley Universal Automatic Drill Grinder Lrjdpszlhlpofx Am Ujp Model: ZB 32 Capacity: 2.5-32mm With Cams

Condition: ready for operation (used), functionality: fully functional, total width: 355 mm, total length: 381 mm, total height: 1,270 mm, grinding wheel diameter: 203 mm, Dormer Automatic Drill Grinder Lodpfx Aszlg Szem Ujrp Model: 108

Condition: used, Year of construction: 2000, grinding length 300 mm grinding width 500 mm Lrodpfxszpf Ucj Am Uop

Condition: good (used), Year of construction: 1989, ELB HK-Orion Precision Surface Grinding Machine A high-quality, robust horizontal surface grinding machine from the premium brand ELB-Schliff. This machine is ideally suited for workshops, toolmakers, and demanding users who require absolute precision in surface grinding. Equipment & Condition: Electromagnetic chuck: Fully functional, including the associated 130V DC control system operated via the control panel. Coolant system: Separate, external settling tank including a functional coolant pump and return chute. Lredpfx Asznt Hdjm Usp Operation: Clear, swiveling control panel for managing axis movements. Technical Data Manufacturer: ELB-Werkzeug- u. Maschinenbau Machine No.: 20600 Operating voltage: 3x 380 V / 50 Hz (three-phase current) Rated current / Fuse rating: 20 A / 25 A Control voltage: 220 V / 24 V Magnetic chuck DC voltage: 130 V / 4 A Year of manufacture: 08/1989 "Everything from a single source: We would be happy to offer you suitable bank financing for your project." komplett-konzept.leasingo.de You can find more items—both new and used—in our shop! International shipping costs available upon request!

Condition: as good as new (ex-display), Year of construction: 2025, operating hours: 2 h, functionality: fully functional, type of input current: three-phase, warranty duration: 12 months, product height (max.): 100 mm, space requirement height: 1,750 mm, space requirement length: 1,200 mm, input frequency: 50 Hz, workpiece weight (max.): 300 kg, Equipment: type plate available, Alpha Brush KS-WBM Sanding Machine, Texture Brushing Machine This machine gives surfaces, such as profile boards for facades or wall cladding, a noticeably more sophisticated and rustic look! With up to 400 mm working width and customizable configuration for both softwoods and hardwoods, this machine is a versatile tool for carpentry workshops, planing mills, or joineries. Lodjw Avrhepfx Am Usrp We offer not only the texture brushing machine itself, but also the appropriate extraction unit and a variety of brush heads to equip the machine, allowing you to achieve your desired effect on wooden surfaces. In addition to this sanding automaton, we also supply coating machines that allow you to stain or finish boards and panels in one step. Do you have questions? We are happy to advise you individually on your requirements.

Condition: good (used), Year of construction: 2000, Degen FSM 300 Surface Grinding Machine High-quality precision surface grinding machine from the renowned German manufacturer Willy Degen, model FSM 300. The machine is characterized by its compact design and extreme precision, making it ideal for tool and mold making. It is perfect for workshops with limited space that refuse to compromise on accuracy. Extensive accessories & highlights included: Digital Readout (DRO): For precise operation and error-free infeed. Original extraction & wet grinding unit: Ready for immediate connection, ensuring a clean working environment and optimal workpiece cooling. Magnetic chuck: Pre-installed for immediate operation. Technical specifications (according to nameplate): Manufacturer: Willy Degen (Schömberg) Type: FSM 300 Machine No.: 1309 Lodpszniriefx Am Ujrp Year of manufacture: 2000 Power supply: 400 V / 50 Hz (three-phase) Power rating: 2.7 kVA / 5.6 A Control voltage: 24 V (secondary) "A complete solution from a single source: We would be happy to offer you suitable bank financing for your project." komplett-konzept.leasingo.de Find more items—both new and used—in our shop! International shipping costs available upon request!

Condition: excellent (used), Year of construction: 1970, functionality: fully functional, table length: 900 mm, table width: 300 mm, Travel distances: Travel – X: 500 mm Travel – Y: 350 mm Travel – Z: 400 mm Grinding wheel: 400 x 50 x 127 Table size: 900 x 300 mm Installation dimensions: approx. Ledpfx Amjznly No Uorp Width: 2500 Depth: 2000 Height: 2100

Condition: excellent (used), Year of construction: 2003, functionality: fully functional, Travel ranges: Travel X: 1000 mm Travel Y: 600 mm Travel Z: 400 mm Ljdpfeznlnmox Am Uorp Table size: 1100 x 600 mm Grinding wheel: 400 x 50-100 x 127 Installation dimensions: approx. Width: 3300 Depth: 2320 Height: 2660

Condition: good (used), grinding length 600 mm grinding width 200 mm max. dia. of grinding wheel 220 mm magnetic clamping plate 500 x 200 mm Lsdpjxb Eg Aofx Am Uerp total power requirement 4,2 kW dimensions of the machine ca. 2 x 1,3 x 1,8 m

Condition: good (used), grinding diameter 450 mm Lsdoxcblqspfx Am Uorp grinding length 600 mm centre height 140 mm workpiece dia. 280 mm number of turns of spindle head 63 - 400 U/min grinding wheel speeds 20-35 m/s dimensions of the machine ca. 2,4 x 1,9 x 2,1 m

Condition: excellent (used), Year of construction: 2023, working width 1300 mm workpiece height max. 3 - 140 mm Control Xinje XD5 min/max. pitch cone length 200 - mm total power requirement 13,4 kW Lrodoylp A Dopfx Am Usp weight of the machine ca. 4,5 t dimensions of the machine ca. 5,1 x 2 x 2,3 m

Condition: as good as new (ex-display), Year of construction: 2020, operating hours: 200 h, functionality: fully functional, workpiece weight (max.): 150 kg, grinding length: 500 mm, grinding wheel diameter: 455 mm, grinding diameter: 300 mm, workpiece weight between centers: 150,000 g, type of input current: three-phase, workpiece diameter between centers: 500 mm, grinding wheel width: 75 mm, spindle speed (max.): 500 rpm, spindle speed (min.): 10 rpm, grinding spindle motor power: 7,500 W, overall weight: 4,600 kg, Demonstration CNC cylindrical grinding machine with automation setup Brand OKAMOTO Model OGM-350 P NCIII Year of manufacture 2020 Control: Fanuc Oi Model D Operating hours: approx. 200 hours Technical specifications Maximum swing diameter: 320 mm Maximum distance between centers: 500 mm Maximum workpiece diameter to be ground: 300 mm Maximum workpiece weight between centers: 150 kg Maximum workpiece weight: flange + chuck + workpiece: 40 kg Grinding wheel: Diameter x width x bore: 455 x 75 x 127 mm Wheel speed: Continuously variable Circumferential speed: 45 m/sec Grinding headstock (x-axis) Maximum travel: 300 Swivel angle: Non-swivel Workpiece table (z-axis) Lrsdpfx Ajzn U S Ism Usp Travel: 870 mm Swivel angle: 0 – 10° Workhead Fixed/Live Center Design MK 4 Taper Chuck Spindle Bore Diameter 20 mm Spindle Speed ​​10 – 500 rpm Swivel Angle: Non-Swivel Tailstock Tailstock Type: Manual Fine Taper Adjustment Quill Travel 30 mm MK 4 Taper Chuck Drive Power Grinding Wheel Drive 5.5 kW Total Power 20 kVA Dimensions/Weight Length x Width x Height approx. 3400 x 2330 x 1950 mm Machine Weight approx. 4,600 kg Standard Equipment: 2 Carbide Centers Full FANUC Keyboard with Radius Compensation for Creating ISO Programs Workshop Programming: Graphic Software for Grinding and Dressing Cycles with Teach-in Function GAP Eliminator Shoulder Positioning Constant Table coolant flush 3 color LED lamp Documentation Leveling screws and support plates Operating tool set Accessories Automation preparation Automatic door Automation interface Grinding wheel guard fully open when door is open Miscellaneous Signal lamp Tailstock with electric quill retraction 1 flange 1 grinding wheel Options upon request: Paper belt filter on request Clamping devices on request Commissioning and training on request (Commissioning by Okamoto is required for warranty purposes) Transport on request

Condition: ready for operation (used), A Koebau centerless cylindrical grinding machine is offered for the high-precision grinding of cylindrical workpieces. Main motor power: 18.5kW, min./max. grinding diameter: 2mm/100mm, max. workpiece length: approx. 600mm, grinding wheel dimensions X/Y: 600mm/200mm, regulating wheel dimensions X/Y: 300mm/200mm, grinding speed: 45m/s. The machine is equipped with a material feeding system, a singulation unit, a robust base frame and a stepped platform. Overall dimensions X/Y/Z: approx. 2500mm/2100mm/2200mm, weight: approx. 4200kg. An on-site inspection is possible. Lrsdpjzpa R Sefx Am Uep

Year of construction: 1996, condition: ready for operation (used), Offered is a WALTER 5-axis CNC tool grinding machine for the production and resharpening of rotationally symmetrical cutting tools such as drills, milling cutters, reamers and special tools. Travels X/Y/Z: 400mm/250mm/580mm, C-axis swivel range: +/-200°, A axis: 360°, rapid traverse X/Y/Z: max. 15m/min, linear axis resolution: 0.0001mm, center height range: 130mm-165mm, max. workpiece diameter: 190mm, workpiece mounting: ISO 50, spindle motor power: 4.4kW, grinding spindle speed: 6000rpm, spindle diameter: 70mm, max. grinding wheel diameter: 200mm, control: WALTER HMC 400. Overall dimensions X/Y/Z: approx. 1420mm/2010mm/2150mm, weight: approx. 3100kg. An on-site inspection is possible. Lrodpfx Aozpa Scom Ujp

Condition: good (used), Year of construction: 2001, Electrical Connection: 380/400 V, 50 Hz Working Height: 970 mm Width: 2650 mm Depth: 1200 mm Height: 1750 mm Weight: approx. 800 kg Lrsdpfezpa Rlex Am Uep Condition: good, second-hand

Condition: ready for operation (used), Year of construction: 1988, Horizontal surface grinding machine Okamoto Type PSG 63 – UAN Year of manufacture: 1988 Grinding length: 600 mm Grinding width: 320 mm Max. workpiece height: 500 mm Table travel (longitudinal): 750 mm Table travel (cross): 340 mm Grinding wheel diameter: 350 mm Grinding wheel width: 40 mm Spindle speed: 1500 rpm Rapid vertical feed: 400 mm/min Power: 3.7 kW Automatic feed Ledjznhwkopfx Am Uerp Magnetic chuck Coolant system Weight: 2500 kg Price: EUR 2,000—plus VAT, ex location
