Used Geibel + Hotz Surface Grinding Machine - Horizontal for sale (67,804)

Condition: used, Year of construction: 1990, grinding length 600 mm grinding width 375 mm Kljdsy Tpqrspfx Agpjt workpiece height 350-375 mm

Condition: good (used), Year of construction: 2007, functionality: fully functional, Technical details grinding length 600 mm grinding width 400 mm workpiece height 375 mm Additional information CNC Precision Surface and Profile Grinding Machine Grinding area: 600 x 400 x 375 mm Grinding spindle motor: 3.7 kW Table drive: hydraulic Cross-axis drive: electromechanical Grinding wheel: 300 x 50 x 76.2 mm Peripheral speed: 10 - 32 m/s Electromagnetic plate: 600 x 400 mm with holding force control and automatic magnetic pole reversal for demagnetizing Features: Partially enclosed, open-topped loading compartment with a sliding door Cleaning kit for cleaning the work area with hand-held impulse nozzle Holder for prism arm with single-point diamond, MK 0 Kjdjy Tt Hqepfx Agpelt Grinding spindle speed control with V-constant controller Universal paper filter unit UPF 100, tank capacity approx. 280 liters Coolant pump: 20 liters/minute at 1.5 bar With mud box Machine light Grinding wheel flanges

Condition: good (used), Year of construction: 1992, functionality: fully functional, Technische Details Werkstückdurchmesser 1000 mm Werkstückgewicht - kg Werkstückhöhe - mm Steuerung Schleifspindelmotor 11 kW Gesamtleistungsbedarf 25 kW Maschinengewicht ca. 6500 kg Raumbedarf ca. 4100 x 3200 x 2600 mm Zusatzinformationen Maschine kommt aus einer Betriebsschließung Ausstattung: Kledpjy Tlrrsfx Agpjt Kühlmitteleinrichtung 500 Liter mit Papierbandfilter 4 Stück Schleifscheiben (3 Stück unbenutzt) Technische Daten: Rundtischdurchmesser 800 mm Max. Abstand Rundtisch zu Schleifspindelmitte 850 mm Schleifscheibendurchmesser 400 mm Schleifscheibenbreite 80 mm

Condition: good (used), grinding length 600 mm grinding width 200 mm max. dia. of grinding wheel 220 mm magnetic clamping plate 500 x 200 mm total power requirement 4,2 kW Kljdexb Eg Aopfx Agpjt dimensions of the machine ca. 2 x 1,3 x 1,8 m

Condition: used, Year of construction: 1996, grinding length 600 mm grinding width 250 mm workpiece height ca. 385 mm table surface area 600 x 200 mm table speed -stepless- 2 - 35 m/min table load capacity max. 250 kg grinding wheel size ø 225 x 25 mm grinding wheel hole diameter 50,8 mm vertical feed autom. 0,001 - 0,099 mm rapid traverse vertical 600 mm/min Kjdpfx Agst Tqrnjpolt cross feed of table continual 10 - 1000 mm/min rapid traverse cross 1000 mm/min total power requirement 6 kVA dimensions of machine L x W x H 2,65 x 1,70 x 2,28 m Accessories: DRO on Y-and Z-axis, magnetic plate 600 x 200 mm, grinding wheel with flange, wheel trueing attachment, wet grinding attachment with paper band filter

Condition: used, grinding length 1000 mm grinding width 750 mm workpiece height 700 mm Control SIEMENS, SIMATIC S 7-1500 table surface area 1050 x 640 mm table height over floor 1000 mm table speeds 3.000 - 30.000 mm/min cross feed of table continual 5 - 5.000 mm/min Kodpfxexukqys Agpjlt cross feed of table intermittent 0,1 - 65,0 mm vertical adjustment, 1 graduation 0,002 mm rapid traverse vertical 0,25 m/min grinding spindle speed 50 - 2.500 U/min grinding wheel size ø 400 x 50 x ø 127 mm workpiece weight max. 1.000 kg table load max. 1600 kg total power requirement 33,2 kW weight of the machine ca. 9,3 t dimensions of machine L x W x H 4,50 x 2,37 x 2,65 m - complete electronic / electric renewed in 2018 Accessories: magnetic plate 1000 x 650 mm, grinding wheel with flange, wheel trueing attachment, extraction

Condition: used, Year of construction: 1990, grinding length 900 mm grinding width 510 mm workpiece height 400 mm table surface area 800 x 400 mm longitudinal feed of the table max. 980 mm table speed -stepless- 1 - 35 m/min grinding wheel size 355 x 51 x 127 mm cross feed of the table 460 mm cross feed 1 - 40 mm/Hub vertical feed autom. 0,005 - 0,04 mm/Hub rapid traverse vertical 0,5 m/min grinding spindle speed 1450 U/min grinding spindle drive 5,6 kW table load capacity max. 1000 kg total power requirement 10 kW weight of the machine ca. 4,4 t Kedpfxstqqm Ao Agpelt Accessories: magnetic plate 800 x 400 mm, various grinding wheels with and without flanges, wet grinding attachment with paper band filter

Condition: used, Year of construction: 1967, grinding length 1650 mm grinding width 700 mm Klodpfx Ajtt S Uajgpet workpiece height 600 mm table surface area 1500 x 500 mm table speeds 0 - 20 m/min cross feed autom. 0 - 20 mm/Hub grinding spindle speed 2000 U/min grinding wheel diameter 300 mm total power requirement 19 kW weight of the machine ca. 5 t dimensions of machine L x W x H 5,92 x 3,12 x 2,65 m Accessories: 2 magnetic plates, each 750 x 600 mm; grinding wheel with flange, various grinding wheels and flanges separate, wet grinding attachment

Condition: used, Year of construction: 1999, grinding length 800 mm grinding width 400 mm workpiece height 375 mm table surface area 840 x 400 mm table speeds m/min spindle speeds (infinitely variable) 1000 - 3000 U/min grinding wheel motor 3,7 kW grinding wheel size 300 x 50 x 76,2 mm cross adjustment 100 - 1250 mm/min rapid traverse vertical 180 mm/min Klsdpotz Evkofx Agpst table load max. 700 kg distance spindle center to table max. 525 mm weight of the machine ca. 2,8 t dimensions of machine L x W x H 3,14 x 1,78 x 2,50 m Accessories: magnetic plate 800 x 400 mm, grinding wheel with flange, wheel dressing attachment, wet grinding attachment with paper band filter

Condition: used, grinding length 1000 mm grinding width 300 mm workpiece height 230 mm table surface area 1000 x 240 mm x-travel 1000 mm y-travel 270 mm z-travel 350 mm grinding wheel diameter 240 mm grinding spindle speed 2180 U/min table speed -stepless- 3 - 30 m/min total power requirement 4,5 kW weight of the machine ca. 2,8 t dimensions of machine L x W x H 2,36 x 1,37 x 2,0 m Accessories: magnetic plate 680 x 200 mm, grinding wheel with flange Ksdpfx Aju Dn Txjgpslt (ø 240 x 25 mm), wet grinding attachment

Condition: used, grinding length 600 mm grinding width 200 mm workpiece height 250 mm grinding wheel diameter 200 mm grinding wheel width 20 mm weight of the machine ca. 1000 kg Ksdpfx Aeu N I Nkegpelt dimensions of the machine ca. 2000 x 1200 x 1650 m

Condition: used, Year of construction: 1993, Technical details: rotary table diameter: 2x700 mm grinding height: 200 mm Klsdeu Ngp Nepfx Agpst grinding head - power requirement: 15 kW max. dia. of grinding wheel: 400 mm grinding spindle speed: 1400-2800 stufenlos /continous U/min automatic feeds: 0,001-0,02 weight of tools max.: 650 kg table speed: 5-10 m/min rotary table revolutions per minute : 5-10 stufenlos U/min rotary table: Querbewg. 0,2...10 m/min total power requirement: 49 kW weight of the machine ca.: ca. 12,0 t dimension machine xH: 6,0x3,0x2,8 m dimensions electric cabinet LxWxH: 2,0x0,55x2,2 m ROTARY TABLE SURFACE GRINDING MACHINE - 2 magnetic rotary tables each Ø=700mm - diamond roller dressing device - without coolant unit i.D. *

Condition: used, Year of construction: 2001, grinding length 600 mm grinding width 400 mm workpiece height 375 mm digital readout 2 Achsen HEIDENHAIN table-size 650 x 350 mm max. table load 400 kg magnetic clamping plate 600 x 350 mm dist. center of grinding spindle - table 525 mm table travel longitudinal 650 mm table travel cross 350 mm table feed 2 - 28 m/min grinding wheel size 300 x 30 x 76,2 mm Kodpfey Ehw Iex Agpslt dressing device Kopfabrichter voltage 400 V total power requirement 11,0 kW weight of the machine ca. 2,1 t dimensions of the machine ca. 2,20 x 1,70 x 2,25 m band filter unit 1,00 x 0,75 x 0,80 m electric cabinet 0,90 x 0,40 x 2,25 m - Serial-No.: 18090201 - Automatic vertical feed - Electric handwheel - HEIDENHAIN digital display, 2 axes - Head dresser - Coolant device - Belt filter system

Condition: used, Year of construction: 1996, grinding length 1.000 mm grinding width 550 mm workpiece height 400 mm table surface area 1.580 x 550 mm table load capacity 950 kg Kodpfoxx A Dmsx Agpslt magnetic clamping plate 1.000 x 550 mm x-Travel 1.200 mm table feed 1 - 30 m/min vertical feeds: 1 - 300 mm/min z-axis 470 mm cross feed 1 - 2.000 mm/min dimensions of grinding wheel 400 x 100 x 127 mm grinding wheel speeds 1.500 - 3.500 U/min grinding spindle drive 11,00 kW total power requirement 23,00 kW weight of the machine ca. 7,50 t dimensions of the machine ca. 4,50 x 3,20 x H2,90 m Coolant system with coolant pump integrated in the hydraulic tank, exhauster.

Condition: excellent (used), grinding length 600 mm grinding width 300 mm workpiece height 350 mm magnetic clamping plate, electical 500 x 200 mm grinding wheel diameter 225 x 25 x 51 mm total power requirement 4 kW Klodpfx Aeyyqt Iegpot weight of the machine ca. 2,1 t dimensions of the machine ca. 1,5x1,5x1,8 m

Condition: excellent (used), Year of construction: 1986, grinding length 800 mm grinding width 375 mm workpiece height 375 mm magnetic clamping plate, electical 900 x 300 mm spindle turning speed range 1500 - 3000 U/min table surface area 1550 x 370 mm table longitudinal travel 100 - 1000 mm max. workpiece weight 350 kg dimensions of grinding wheel 300 x 50 mm total power requirement 9 kW weight of the machine ca. 4,6 t dimensions of the machine ca. 4,0 x 2,3 x 2,6 m Klsdpfx Ajunt Iusgpst

Condition: used, Year of construction: 1980, grinding length 500 mm grinding width 200 mm workpiece height 290 mm Machine from the German Federal Institute of Physics and Metrology - geometrically revised - electrics tested, fully functional, relevant parts replaced - all wear parts replaced - colour light grey, colour condition good Equipment: Kjdpfewb Hygex Agpelt - electro magnet 500x200mm - grinding spindle overhauled 2-axis display for Y and Z axes Automatic delivery for Y and Z axes Y-axis with zero shutdown Manual hand dresser Stepless speed for grinding wheel V-constant via disc wear Paper band filter system, used Max. height with 250 disc diameter 290mm max. grinding area 600x250mm max. load incl. magnet 100kg Warranty: 1 year on geometry and electronics, Germany-wide Delivery: ex works Shipping time: immediately Payment: before pickup Acceptance at our premises Shipping according to your specifications

Condition: as good as new (ex-display), Year of construction: 2025, functionality: fully functional, grinding length: 500 mm, grinding width: 250 mm, Young, like-new demonstration machine: High-precision surface grinding machine, "Optimal" series, available at a special net price. Grinding area: 500 x 250 mm Features: ● Surface grinding machine with automatic vertical feed ● Grinding sequence: roughing – finishing – spark-out ● Siemens S700 touchscreen panel and electronic handwheel for Y-axis ● Digital display for vertical axis Y and cross axis Z ● Table cover and splash guards in stainless steel design ● Electrical cabinet fitted predominantly with Siemens components ● Includes manual dressing device, electro-magnetic chuck, and coolant filtration system Main technical data: Grinding length mm 500 Grinding width mm 250 Distance table surface to spindle center mm 450 Table drive Hydraulic Table load kg 180 Longitudinal movement X Table speed, steplessly adjustable m/min 7 – 23 Max. longitudinal travel mm 560 Cross movement Z Max. travel speed mm/min 990 Max. cross travel mm 275 Vertical movement Y Max. travel speed mm/min 460 Grinding spindle / Grinding wheel Spindle power kW 2.2 Wheel dimensions mm 200x20x31.75 Spindle speed (speed control optional) min⁻¹ 2850 Dimensions Machine weight (net) kg 1800 Machine dimensions (inc. reciprocation) Width mm 2300 Depth mm 1650 Height mm 1680 Power connection kW 3.7 All model series include standard accessories: ● 1 standard grinding wheel ● 1 wheel flange ● 1 dressing block with diamond ● 1 balancing arbor ● 1 balancing stand ● 1 machine lamp ● 1 set of machine tools ● 1 set of documentation with spare part list ● Machine in CE-conform (metric version) Precision and surface quality at optimal price. Fully equipped for universal use in a wide range of industrial and application areas. Machine comes with a 12-month parts warranty. By the way, aside from affordable new and certified used machines, we offer even more: • On-site consultation and solution finding • Organization of machine transport to your facility • Installation, commissioning, and turnkey handover • Spare parts supply • Control training for Siemens, Heidenhain, and Fanuc • Trained service staff available in your area and more Kljdpfsyak Dlox Agpjt • 24/7 telephone support • Tax-optimized trade-in of your old machine • Attractive financing options, even without down payment

Condition: good (used), Year of construction: 1988, voltage 380 V connected load 7,5 kVA dimensions 2725 x 1930 x 1773 mm weight of the machine ca. 2500 kg --> Technical data Main data: --> Table surface: 605 x 300 mm --> Table longitudinal movement max. (manual): 750 mm --> Table transverse movement: 340 mm --> Grinding height between table/new grinding wheel min/max: 22.5 / 322.5 mm --> Standard size of magnetic clamping plate: 600 x 300 mm --> Workpiece weight incl. magnet: 420 kg --> X-axis / longitudinal movement: --> T-slots (number x width): 3 x 17 mm --> Table feed, hydraulic: 0.3 - 25 m/min --> Travel per handwheel revolution: 47 mm --> Y-axis / height movement: --> Automatic vertical feed - coarse in 12 steps: 0.001 - 0.03 mm --> Automatic vertical feed - fine in 8 steps: 0.001 - 0.01 mm --> Distance per handwheel revolution (x1/x10): 0.1 / 1.0 mm --> Graduation on handwheel (x1/x10): 0.001 / 0.1 mm --> Trigger strokes: 0 - 5 --> Rapid traverse: 400 mm/min --> Z-axis / transverse movement: --> Automatic transverse feed intermittent: 0.5 - 20 mm --> Automatic transverse feed / rapid traverse continuous: 0.1 - 1.0 m/min --> Distance per handwheel revolution: 5.0 mm --> Scale mark on handwheel: 0.02 mm --> Standard grinding wheel: --> Ø x width: Ø 355x38 (50) mm --> Bore: Ø 127 mm Kjdpsw Dvkajfx Agpolt --> Speed: 1500 rpm --> Accessories Various grinding wheels --> Documentation

Condition: used, Year of construction: 1992, grinding length 0800 mm grinding width 500 mm workpiece height 400 mm Kjdpfxewgnz Aj Agpjlt table-size 800 x 400 mm table speeds 1 - 25 m/min cross feed autom. 0 - 60 mm/Hub grinding wheel size 400 x 100 x 127 mm grinding spindle speed 1400/2800 U/min total power requirement 10 kW voltage 380 V weight of the machine ca. 6 t Machine has cooling arrangement, auto. vert. feed, dressing arrangement and wheel flanges.

Condition: used, Year of construction: 2015, control Grind-X Kodsyiu Sxjpfx Agpolt weight of the machine ca. 2900 kg

Condition: used, Year of construction: 2000, grinding length 600 mm grinding width 300 mm magnetic clamping plate 600x200 mm wheel diameter 220-300 mm machine weight ab. 2200 kg Klodpfx Agsx U A Ugepjt

Condition: used, Year of construction: 2000, grinding length 600 mm grinding width 300 mm magnetic clamping plate 600x250 mm Kedow Hg Uzepfx Agpelt wheel diameter 220-300 mm weight 2200 kg

Year of construction: 1987, condition: used, grinding length max. 630 mm grinding width max. 200 mm workpiece height . mm x-axis max. 250 mm y-axis max. 710 mm distance spindle center to table max. 500 mm table surface area 0,25 mm table load max. 1,1 t table speed -stepless- 2 - 18 m/min cross feed autom. . dust exhaust 0,25 kW coolant pump 0,09 kW total power requirement ca. 4,5 kW weight of the machine ca. 1,3 t dimensions of the machine ca. 2400 x 1600 x 1900 mm Kjdpfx Agegbgawspolt Adjustments Y axis: 1 scale value = 0.005 mm Z axis: 1 scale value = 0.002 mm Manual adjustment (within the range of 250 mm of the Y axis): 80 mm Speeds: automatic cross feed Adjustment path in Y direction: - intermittent 0.2 - 20 mm per stroke; - continuous: 0 - 4 m/min Grinding wheel Ø max. 200 mm Grinding wheel bore: 51 mm Grinding wheel width: 20 mm Diamond dressing unit Digitaldisplay for 2 advertisement vertical infeed

Condition: ready for operation (used), Year of construction: 1992, functionality: fully functional, rotary table diameter: 800 mm, overall weight: 6,500 kg, grinding wheel diameter: 400 mm, workpiece diameter (max.): 1,000 mm, grinding wheel width: 80 mm, TECHNICAL DETAILS Workpiece diameter: 1,000 mm Rotary table diameter: 800 mm Max. distance from rotary table to grinding spindle center: 850 mm Grinding wheel diameter: 400 mm Grinding wheel width: 80 mm MACHINE DETAILS Total power requirement: 25 kW Grinding spindle motor: 11 kW Kjdpoxr U R Esfx Agpolt Dimensions & Weight Space requirement (L x W x H): approx. 4,100 x 3,200 x 2,600 mm Machine weight: approx. 6,500 kg EQUIPMENT Coolant system 500 liters with paper band filter 4 grinding wheels (3 unused)
