Used Gleason Phoenix 1000 Hc for sale (10,050)

Condition: excellent (used), Year of construction: 1996, functionality: fully functional, machine/vehicle number: 25734, wheel diameter: 700 mm, gear diameter: 1,000 mm, wheel width: 152 mm, workpiece spindle speed (max.): 67 rpm, feed length X-axis: 610 mm, feed length Y-axis: 610 mm, feed length Z-axis: 725 mm, pivoting range: 95 °, spindle bore: 203 mm, travel distance X-axis: 610 mm, travel distance Z-axis: 725 mm, Equipment: rotational speed infinitely variable, Equipped with: Fanuc 150MB Control Hydraulic Chucking Work Spindle Large Bore Work Spindle #80 Taper Stock Divider Helical Motion Modified Roll Hansen Coolant Chiller & Filtration Coolant Tank & Pumps Chip Conveyor Chip Hopper Reven Mist Collector Hydraulic System Transformer Cutter Bolt Work Light Operator Platform Hand Tools Documentation Specifications: Extreme Ratio: Face Milling: 10:1, Face Hobbing: 10:1 Full Depth: Maximum: Face Milling:1.25" (31.75mm), Face Hobbing: 0.93" (23.50mm) Face Width: Maximum: Face Milling:6.00" (152.00mm),Face Hobbing: 3.00" (76.20mm) Range of Tooth Numbers: 1-300 Inclusive Gear Pitch Diameter, Maximum: 1000 mm (39.37") Cutter Size, Maximum: 18" (diameter) Face Milling Cutter Size, Maximum: 350 mm (radius) Face Hobbing Root Angle Range (B-Axis) 5 deg.to 90 deg., Face Hobbing:5 deg. to 90 deg. Machine Center to Work Spindle Face:9.00"Fixed, 229mm (Fixed) A-Work Spindle: 0 to 67 RPM, 0 to 333 RPM B-Swinging Base: 0 to 30 deg./sec, N/A C-Cutter: 0 to 500 deg., Same Knedpfx Ahsxaqa Ssisc X-Horizontal: +/-305mm (+/-12") Y-Vertical: +/-305 mm (+/-12") Z-Sliding Base: -25/+700mm (-1/+28") B-Root Angle: -5 Degree/+90 Degree Diameter of Taper Hole at Large End: 8" (#80 Taper) to 6" (#60 Taper) Taper Per Foot:3/4", Same Depth of Taper Front:6", 152.40 mm Depth of Bore: 678 mm (26.7") Diameter of Taper Bore: 140 mm (5.5") Diameter Through Spindle of Hole:7.125", 180.98 mm MACHINE DIMENSIONS: Length x Width:233"x 209", 5920 mm x 5310 mm Height: 129", 3280 mm Weight: 65,000 lbs., 29,484 kg

Condition: used, Year of construction: 2003, max. wheel diameter 275 mm gear width 58 mm max. module 13 min. module 2 Control SINUMERIK 840 D number of teeth 5 - 200 ratio of transmission 10:1 cutter diameter max. 228 mm x-axis 25 - 350 mm y-axis +/- 175 mm z-axis 125 - 600 mm b-axis -5 / +90 ° total power requirement 75 kW weight of the machine ca. 11,7 t dimensions of the machine ca. 12,5 x 3,0 x 3,0 m Both Spindles retrofitted in 07/2026 Knodpfx Ahox R U E Njiec Equipped for dry milling Pressure deburrer Deburring device with driven brush Integrated magnetic chip conveyor Promot Cellmaster Cartridge pulse filter system User interface control works with Gleason Summary

Condition: good (used), Year of construction: 2000, gear diameter: 449 mm, Equipped with: Fanuc 150MB CNC Control Dry Cutting Cutter Shroud Chip Evacuation System Auto Doors Hydraulic System Lubrication System Work light Stack Light Specifications: Kedpfx Aheruakgeienc Largest Speed Ratio: 10:01 Work Area (Continuous): Largest Depth of Teeth: 15.24 mm Largest Width of Tooth Face: 50.8 mm Work Area Axis: Horizontal Movement X Axis: -114 - 178 mm Vertical Movement Y Axis: -178 - 190 mm Movement of the Carriage Baseplate Z-Axis: -10.16 - 500 mm Workpiece Headstock Swiveling Range B-Axis: -3 - 90 Degree Maximum Distance Machine Center to Spindle Side: 165 mm Number of Teeth: 5-200 Inclusive Max. Gear Pitch Dia. of Typical 35 Deg. Spiral Angle Gear Using Max. Cutter Dia. 12" Cutter at the Following Ratios: Face Milling 1 x 1 - 13.5" - 342.9mm 2 x 1 - 16.0" - 406.4mm 5 x 1 - 17.7" - 450.0mm Face Hobbing (210mm Dia. Cutter) 1 x 1 - 10.560" - 268.22mm 2 x 1 - 10.286" - 275.00mm 5 x 1 - 11.810" - 300.00mm Milling Head Diameter: Helixact: 100,125,169,200,250,320mm Continuous Gumption Procedure, Teichloroethylene: 102 - 210 mm Workpiece Spindle: Drilling of Large Diameters: 5 3/64" Cone Upward Gradient on 304.8 mm (1 Foot): 21/32" Deep One of the Cone: 5.29" Diameter of the Whole Spindle Perforating: 3.35" Speeds: B-Axle Workpiece Headstock Drag Axis: 30 Degrees A-Axle Workpiece Spindle Number of Revolutions: 0 83 min-1 X-Axis Horizontal: 80 mm/sec Y-Axis Vertically: 80 mm/sec Z-Axis Carriage Baseplate: 80 mm/sec Space Requirement L x W x H (Approximate): 4.75 x 3.40 x 2.54m / 188" x 134" x 100" Machine Weight (Approximate): 10980 kg / 24,156#

Condition: like new (used), Year of construction: 2016, functionality: fully functional, machine/vehicle number: 25582, Equipped with: Fanuc 30ia Control Hydraulic System Coolant System Chip Conveyor Pneumatics Lube System Jib Crane Change Gears Mist Collector Transformer Work Light Stack Light Specifications: Extreme Ratio: 10:1 Root Angle Range (B-Axis): -5 deg. TO 90 deg. Equivalent Root Angle Range: -8 deg. to 90 deg. (Equivalent refers to cradle type machine.) Face Hobbing: Examples of Maximum Gear Pitch Diameter -35 Degree Spiral -152 mm TRI-AC Cutter w/13 Blade Groups Max. Full Depth: 0.550" Max. Face Width: 1.6" Face Milling: Examples of Maximum Gear Pitch Diameter -35 Degree Spiral -7.5" Diameter Cutter Max. Full Depth: 0.625" Max. Face Width: 1.6" Max. Swinging Base Travel (B-Axis): -5 deg. to 90 deg. Max. Vertical Travel (Y-Axis): -4" to 7" Max. Horizontal Travel (X-Axis): -6" to 4" Sliding Base Travel (Z-Axis): 2" to 12" Machine Center to Work Spindle Face (Fixed): 4.5" Tooth Number: 5 to 200 Inclusive Cutting Diameters: Conventional Face Milling: 1.1" to 7.5" Helixact: 100mm to 200mm Fine Pitch: 102mm to 152mm Coarse Pitch: 152mm only Speeds: B-Axis--Swinging Base (Degrees per Second): 30deg./sec. A-Axis--Work Spindle (Face Milling)(RPM): 0-75 Kjdpfx Aezn Aymehionc A-Axis--Work Spindle (Face Hobbing)(RPM): 0-375 C-Axis--Cutter Spindle (RPM): 30-500 X-Axis--Horizontal (Inches per Second): 4.92"/sec. Y-Axis--Vertical (Inches per Second): 4.92" Z-Axis--Sliding Base (Inches per Second): 4.92"/sec. Work Spindle: Diameter of Taper at Large End (#39 Taper): 3-29/32" Taper per Foot: 39/64" Depth of Taper: 3" Floor Space: 95.75" x 63.5" Height (less mist collector): 90.75" Approx. Weight: 22,000 lbs

Condition: used, Year of construction: 2006, ratio of transmission 10:1 min. number of teeth 3 max. number of teeth 200 range of tooth size 20 mm tooth width max. 58 mm spindle speeds (infinitely variable) 6000 U/min Knjdpfxevxwr As Ahioc work piece spindle speed 1200 U/min diameter of tools max. 230 mm diameter of tools min 69,85 mm x-axis 325 mm y-axis 350 mm z-axis 470 mm b-axis + 90,1 / - 1 ° work piece table - Ø 212,71 mm Control SIN 840 D SIEMENS total power requirement 75 kW weight of the machine ca. 10,00 to dimensions of the machine ca. 6,10 x 4,40 x 3,30 m coolant filtering unit Hoffmann HSF 100 V

Condition: used, Year of construction: 2007, ratio of transmission 10:1 min. number of teeth 3 max. number of teeth 200 range of tooth size 20 mm diameter of tools min 69,85 mm tooth width max. 58 mm diameter of tools max. 230 mm x-axis 325 mm y-axis 350 mm z-axis 470 mm work piece table - Ø 212,71 mm b-axis + 90,1 / - 1 ° Control 160 i - MB FANUC total power requirement 75 kW weight of the machine ca. 10.000 Kg dimensions of the machine ca. 6,10 x 4,40 x 3,30 m Knjdpfx Aeynbdlshioc WAGURI With EWAB robot cell (KUKA robot) without coolant filter system Fire extinguishing system without CO2 bottles Cooling oil return with various pumps / collecting basins Threading device A1/B2 axes with measuring probe Clamping device for a pinion shaft External spindle oil cooler Extraction system "pinion shaft"

Condition: used, Year of construction: 2005, ratio of transmission 10:1 min. number of teeth 3 max. number of teeth 200 range of tooth size 20 mm tooth width max. 58 mm diameter of tools min 69,85 mm diameter of tools max. 230 mm x-axis 325 mm y-axis 350 mm z-axis 470 mm work piece table - Ø 212,71 mm b-axis + 90,1 / - 1 ° Control SIN 840 D SIEMENS total power requirement 75 kW weight of the machine ca. 10.000 Kg Knedpfxsynmm Ej Ahisc dimensions of the machine ca. 6,10 x 4,40 x 3,30 m WAGURI with EWAB load cell built in 2012 (Linear loader) no coolant filter system available

Condition: used, Year of construction: 2008, ratio of transmission 10:1 min. number of teeth 3 max. number of teeth 200 Knsdpfjvxwmtsx Ahijc range of tooth size 20 mm tooth width max. 58 mm spindle speeds (infinitely variable) 6000 U/min work piece spindle speed 1200 U/min diameter of tools max. 230 mm diameter of tools min 69,85 mm x-axis 325 mm y-axis 350 mm z-axis 470 mm b-axis + 90,1 / - 1 ° work piece table - Ø 212,71 mm Control SIN 840 D SIEMENS total power requirement 75 kW weight of the machine ca. 10.000 Kg dimensions of the machine ca. 6,10 x 4,40 x 3,30 m Internal probe Renishaw LP2 (axis X2;Y2) Hoffmann coolant filter system HSF 100SE/K (built in 2008) Tank capacity 2500L VT oil mist filter system

Condition: excellent (used), working width: 240 mm, planing height: 160 mm, spindle diameter: 50 mm, planing width: 240 mm, working height: 160 mm, total width: 240 mm, spindle speed (max.): 7,000 rpm, spindle speed (min.): 7,000 rpm, Weinig Unimat 1000 with grooved table Knjdpfxezbz Uko Ahiec Working width: 240 mm, working height: 160 mm, 5 spindles Spindle diameter: 50 mm Spindle arrangement: 1-Bottom (7.5 kW) 7000 RPM 2-Right (7.5 kW) 7000 RPM 3-Left (7.5 kW) 7000 RPM 4-Top (7.5 kW) 7000 RPM 5-Bottom (5.5 kW) 7000 RPM Feed rate: 4 kW / 6-36 m/min, one driven roller in the table at the outlet.

Condition: used, Year of construction: 1997, max. wheel diameter 215 mm gear width 40,65 mm max. module total power requirement 20 kW weight of the machine ca. 10 t Max. external Ø of workpiece 215 mm Tooth profile, height x width 16 x 40.65 mm No. of teeth 5 - 200 Max. tooth ratio 1 : 10 Grinding wheel Ø 51 - 190 mm Grinding wheel speeds 1,000 - 6,000 rpm X Axis (horizontal) 152 mm Y Axis (vertical) 178 mm Z Axis (slide base plate) 304 mm Distance from middle of machine to middle of workspindle 115 mm Kedpfx Aet Hwxhshionc Axial speed 125 mm/sec Workpiece speeds 0 - 30 rpm Workspindle bore, conical 3 29/32 inch Total electrical load 20 kW - 380 V - 50 Hz Weight, approx. 10,000 kg Accessories / Special Features * FANUC CNC Control, Model 150 MB, for 7 axes, with monitor and direct input. Automatic calculation of all workpiece and grinding parameters. * Extensive coolant equipment with filter system, band filter, etc. * Driven grinding wheel dressing device with CNC dressing control for automatic compensation of form and diameter after every dressing. * Gear grinding is effected either in single component operation using a conical cup wheel (Gleason 30°), or with a cylindrical cup wheel. These grinding wheels can be made of CBN, or of traditional "dressable" aluminium oxide material (question of cost). Grinding with a conical grinding wheel is of advantage with regard to heat build-up and quality of tooth contact pattern. Therefore these pairs of bevel gears (for automotive industry) can be generated in high quality with consistent accuracy, economically, and with short set-up times. Condition : Very good - machine can be inspected here under power Delivery : Ex stock, as inspected Payment : Net, after conclusion of contract Thank you for your interest. We always have a good selection of gear machines available. Please let us know what you need.

Condition: new, functionality: fully functional, Year of construction: 2021, input voltage: 380 V, type of input current: three-phase, warranty duration: 12 months, working height: 650 mm, machine/vehicle number: SM20215245, Equipment: documentation/manual, Well-maintained Lantech C-1000, right-hand stainless steel model, 2011 Stainless steel version Knedpst Dn Hqofx Ahiec Speed: approximately 25 boxes per minute, suitable for right-hand American folding boxes/Fefco 0200/0201 Also available: Lantech C-2000, C-1000, C-300, C-400, CS-300, MFC-2000, hotmelt, Nordson, Robatech.

Condition: new, Year of construction: 2025, functionality: fully functional, load capacity: 1,000 kg, table load: 1,000 kg, 3-axis turning and tilting positioner with 1000 kg load capacity, clamping plate diameter 0.65 meters Height adjustment 1000 - 1500 mm Suitable for welding, assembly, processing, etc. With its stable and robust construction, flexible positioning via three axes including overhead, and user-friendly operation, it facilitates welding, assembly, and handling of large workpieces. Optimal positioning of the workpiece improves welding quality and allows higher specified loads in any position. Thanks to the endless rotation of the two rotary axes and additional height adjustment, all workpiece positions (including overhead) are possible. Turntable speed infinitely adjustable from 0.1 to 1.0 rpm. With wireless remote control Rotation range 360° infinite Swivel range 360° infinite Knedpfjxbh Dqox Ahioc Lift: 1000 - 1500 mm Arm outreach radius: 1 meter

Condition: excellent (used), Year of construction: 2004, SCHULER HYDRAP Year of manufacture: 2004 Press force: 10,000 kN Stroke length max.: 1,650 mm Knodpoz Ei A Tjfx Ahisc Installation height: 2,400 mm Closing speed: 420 mm/s Working speed max.: 68 mm/s Working speed at rated force: 21 mm/s Tool base area max.: 3,900 x 2,400 mm Tool base area min.: 1,800 x 1,200 mm Tool installation height: 750 mm Tool weight max.: 50,000 kg

Condition: ready for operation (used), Phoenix Contact VL PPC 3000 industrial panel PC 2400184 SN:L100015408, used, normal signs of wear, 100% fully functional, scope of delivery as per photos. Kjdpjx Et T Iefx Ahijnc

Condition: ready for operation (used), Phoenix Contact VL PPC 3000 industrial panel PC 2400184 SN:L100015397, used, normal signs of wear, 100% fully functional, scope of delivery as per photos. Ksdpfsx Et Tzox Ahienc

Condition: good (used), Year of construction: 2011, functionality: fully functional, Max. diameter = 450 mm and module = 10 Knsdpfez Rm Hzox Ahisc Min. diameter = 69 mm and module = 0.9

Condition: like new (used), Year of construction: 2019, CAP 30 APPLICATOR 1000 SLIM FOR HELICAP 23 PRO: Kedpfxoyynd Re Ahijnc YOM 2019 VERSION 400v 9.000 RUNNING HOURS NEW CONDITION

Condition: ready for operation (used), Year of construction: 1962, machine/vehicle number: E 557, functionality: fully functional, pressing force: 40 t, stroke length: 125 mm, table width: 400 mm, table length: 1,000 mm, overall weight: 3,900 kg, No minimum price – guaranteed sale to the highest bidder! TECHNICAL DETAILS Press force Max. press force: 40 t Stroke: 125 mm Knsdjz Izdnjpfx Ahijc Max. operating pressure: 15.7 MPa Installation height: 650 mm Stand extension: 400 mm Ram adjustment: 125 mm Work table Table length: 1,000 mm Table width: 400 mm MACHINE DETAILS Machine type: Hydraulic press brake Type: E 40-1000 Year of manufacture: 1962 Factory number: E 557 Total weight: 3,900 kg Condition: Used, fully functional

Condition: excellent (used), functionality: fully functional, Year of construction: 2023, Operating hours: approx. 3,000 h Knedpfx Ahjy Nl U Seijc

Condition: good (used), Manfred Rachner RD 1000 P pile turner Unit in like-new condition, ready for operation. Technical specifications: Format: 1285 x 800 mm Stack height: 1330 mm Load capacity: 1000 kg Machine weight: 850 kg Power supply: 380 V Knjdjz S Unvepfx Ahisc Controlled via a control panel; fast operation; hydraulic drive. Quiet operation. Compact design; requires minimal space.

Condition: used, Year of construction: 2018, max. wheel diameter 450 mm max. module 4 mm Control Siemens 840 D sl internal diameter 100-300 mm weight of the machine ca. 11 t dimensions of the machine ca. 5,85 x 8,30 x 3,80 m GLEASON-PFAUTER 300 PS Gear Skiving Machine – Year 2018 For sale is a high-performance CNC gear skiving machine type GLEASON-PFAUTER 300 PS, built in 2018. The machine is ideally suited for the precise machining of internal gears and offers excellent dynamics, advanced CNC technology, and a robust machine design. Equipped with a powerful Siemens 840D sl CNC control, this machine provides optimal conditions for efficient and repeatable gear manufacturing processes. Technical Specifications - Max. gear diameter: 450 mm - Max. module: 4 mm - Internal diameter range: 100 – 300 mm - Max. allowable skiving cutter diameter: 175 mm - Mounting surface diameter: 125 mm - Axis Travels: X-axis travel: 350 mm Y-axis travel: 300 mm Z-axis travel: 440 mm - Max. skiving head swivel angle: ±25° - Workpiece table outer diameter: 570 mm - Max. table load capacity: 5 kN - Feed Rates and Speeds X-axis feed rate: 12,000 mm/min Y-axis feed rate: 5,000 mm/min Z-axis feed rate: 8,570 mm/min - Tool speed: 0 – 3,000 rpm Knodpfxezupl Nj Ahisc - Workpiece table speed: 0 – 1,500 rpm Additional Equipment / Information - CNC Siemens 840D sl - Swivel gripper slide travel: 180° - Operating voltage: 400 V - Machine weight: approx. 11 t - Space requirement: approx. 5.85 × 8.3 × 3.8 m - Hydraulic oil capacity: 150 l - Coolant capacity: 850 l - Motor and hydraulic cooling: 100 l The machine is in very good condition and is ideally suited for demanding series production and high-precision gear manufacturing applications. Inspection by appointment possible.

Condition: good (used), Polar Mohr LW 1000-4 paper stack lift The unit is in excellent technical and visual condition. This is a currently manufactured model. Hydraulic drive. Power supply: 380V. Features an automatic lifting cycle controlled by a photocell, as well as a manual mode; high-speed operation. Knjdpfxoz S Upas Ahioc Load capacity: 1000 kg. Pallet dimensions: 1200 × 800 mm.

Condition: used, Year of construction: 2007, x-travel 900 mm y-travel 300 mm z-travel 1000 mm control Siemens Sinumerik 840D max. workpiece diameter 1600 mm max. module 20 mm tip circle diameter 350 mm Milling arbour diameter 375 mm Total closing value 80 kVa weight of the machine ca. 33,5 t dimensions of the machine ca. 10,530 x 6,375 x 4,680 m Feed rate: - X-axis 1 to 3000 mm/min - Y-axis 1 to 3000 mm/min - Z-axis 1 to 4000 mm/min Spindle speeds in rpm: - Tool 26 to 265 Kedpfxjw Rrb Hs Ahionc - Workpiece table 0 to 8 Equipment/accessories: - M 2 motor milling head - Milling mandrels - Oil cooler - Technical documentation

Condition: ready for operation (used), Year of construction: 1985, Available for immediate pickup at our location: Radial drilling machine TOA Knedpfx Aj Aa Inwohisc Type TRD 1000 F Year of manufacture 1985 Outreach 1000 mm Installation height 800 mm Taper shank MK 4 Spindle speeds 50 – 1230 rpm Drive power 4 kW Rotary table Vise Weight 2 tons Price: EUR 1,750.00 plus VAT, ex works

Condition: refurbished (used), Year of construction: 2027, functionality: fully functional, position of the milling head: Schwenkbar (40°), total length: 6,100 mm, gear diameter: 180 mm, total height: 3,450 mm, total width: 2,975 mm, input frequency: 50 Hz, type of input current: three-phase, spindle speed (max.): 4,000 rpm, spindle speed (min.): 300 rpm, travel distance X-axis: 100 mm, travel distance Y-axis: 200 mm, travel distance Z-axis: 300 mm, overall weight: 8,400 kg, tool diameter: 80 mm, controller manufacturer: Siemens Sinumerik ONE, drive type: Sinamics S120, control type: CNC control, Equipment: documentation/manual, rotational speed infinitely variable, A high-performance machine for series production: the horizontal Gleason-Pfauter P 210 L, built in 2003, mills shafts, pinion shafts, and small gears up to module 4 and 180 mm in diameter at speeds of up to 4,000 rpm on the cutter and 1,000 rpm on the workpiece – designed for short cycle times and dry machining. Serwema Retrofit Solutions, Chemnitz, completely overhauls the machine and delivers it with Siemens Sinumerik ONE, the latest generation of control systems with full spare parts and support availability. Modern Gleason-Pfauter kinematics, new electrical system, new drives, new safety technology: you get the performance of a new machine at a fraction of the price, and we will inspect it together with you in Chemnitz. The horizontal design makes the P 210 L ideal for shaft machining: workpieces up to 830 mm are clamped between the spindle and tailstock, with 300 mm of axial travel and 100 mm of radial travel (center distance 30–130 mm). The milling head pivots by ±40°, and the tangential travel of 160 mm utilizes the full cutter length of 170 mm for long tool life. The high workpiece speed allows for multi-tooth hobbing cutters and thus the cutting performance required in the gearbox and automotive component supply sector. The machine is prepared for connection to a loading portal or a robot. Technical data: max. workpiece diameter 180 mm, max. module 4, working area radial 100 mm (30–130 mm), axial 300 mm (260–560 mm), tailstock 350 mm (480–830 mm), max. cutter diameter 180 mm, max. cutter length 170 mm, tangential travel 160 mm, cutter speed 300–4,000 rpm, max. workpiece speed 1,000 rpm, swivel angle ±40°, total connection value 50 kVA. Installation dimensions approx. 6.1 × 3.0 × 3.5 m, weight approx. 8.4 t. Ksdpfx Ahez Et Rzjionc The machine will be delivered with a new Siemens Sinumerik ONE control system and Sinamics S120 drives in an air-conditioned control cabinet manufactured in-house. The user-friendly interface makes setup and programming possible without in-depth G-code knowledge. Geometry acceptance is carried out according to the manufacturer's standard or DIN with a protocol. The scope of delivery also includes the complete machine enclosure with state-of-the-art safety technology, a new coat of paint in RAL 5015/7035, a magnetic chip conveyor, circulation and loss lubrication, a hydraulic unit, a coolant system, and the operating manual.
