Used Grefe Shank Slotter for sale (425)

Condition: used, Year of construction: 1965, functionality: fully functional, machine/vehicle number: M18L/6138, Offer Number: M18L/6138 Machinetype: shank slotter Make: GREFE Type: shank master Constr. year: 1965 diameter range: 6 mm shaft length under head: 25 mm Laedjwi Tbtspfx Acfef output pieces/min: 100 Location: In our warehouse

Condition: used, Year of construction: 1970, functionality: fully functional, machine/vehicle number: M18L/8717, Offer Number: M18L/8717 Machinetype: shank slotter Make: EIGENBAU Lajdewi Sufepfx Acfjf Type: Constr. year: 1970 diameter range: 8 mm shaft length under head: 60 mm output pieces/min: 100 Location: In our warehouse

Condition: excellent (used), Year of construction: 2021, functionality: fully functional, working width: 2,700 mm, Kryma SK2800 automatic slotter with vacuum autofeeder, machine have been used very little and is in perfect condition and available anytime. Speed is approx. 2000pcs per hour. Machine can do up to 10m long sheets. Video can be sent upon request. Also available Kryma flat bed roller die cut like new, and Sunthinks SC860 single pass printer with auto feeder. Lasdpfxstth Iaj Acfof * We can arrange transport within Europe, and give offer with transport included if of an interest.

Condition: used, Shank cutters and drill bits in mint condition, unused, sharpened and second-hand, for CNC machines, as shown in the examples. Technical data: - Length: Various Lasdpozrybpofx Acfof - Diameter: Various - Shank: Various - Weight: 12 kg - Application: Woodworking

Condition: excellent (used), Year of construction: 2023, functionality: fully functional, For sale: Boxmaker 2500 working width, fully automatic, 2 flexo printers 500x200 mm, 2 die cutters for hand holes, or depending on the installed die, year of manufacture 2023. Lajdpfjxgbycox Acfsf

Condition: excellent (used), Year of construction: 2025, operating hours: 230 h, functionality: fully functional, Rotary die-cutting machine for cardboard packaging, size 2500x1600, using dies. The machine is additionally equipped with a stacker, a vibratory feeder, and a stacking system. Lodpfx Acozi Apqsfsaf

Condition: excellent (used), Year of construction: 2020, functionality: fully functional, EDF Flexy Feed Prefeeder Casemaker EDF 821 FD Full Servo Swing no crash feeder N. 6 colors flexo printing units from top, fixed type (they can be opened for maintenance) N. 6 infrared dryers Vacuum transport between printing units made by steel platform and belts Double-shaft slotting unit Rotary die cutter with upward disengagement for die cutting replacement when machine is running Stripper transfer unit before folder gluer Folder gluer vacuum transfer full servo controls Ledpfswhy Absx Acfsaf Valco clear vision gluing unit Counter ejector EDF Unipal palletizer with automatic sheets and pallet inserter Siemens Electronics Available August 2027

Condition: like new (used), functionality: fully functional, 5 pcs drill rod adapters SANDVIK Model: T51 HL1000PE D52 L840 Part no.: 7306-6019-02 Total length: 840 mm Ledpeyr Iqgefx Acfsaf Suitable for drilling rigs with long extractor (52 mm bearing diameter)

Condition: ready for operation (used), Year of construction: 2008, functionality: fully functional, number of spindles: 2, spindle speed (max.): 4,500 rpm, turning length: 145 mm, turning diameter: 240 mm, travel distance X-axis: 130 mm, travel distance Z-axis: 145 mm, Horizontal, twin-spindle CNC lathe with 2 turrets in two working areas and 2 loading portals! The machine underwent an overhaul in 2023! TECHNICAL DETAILS Turning diameter max.: 240 mm Turning length max.: 145 mm Travel X-axis: 130 mm Travel Z-axis: 145 mm Distance between spindles: 340 mm Rapid traverse X/Z-axis: 24 m/min Guidance X-axis: Roller linear guide Guidance Z-axis: Round guide, 145 mm Number of spindles: 2 Spindle drive power: 11 / 7.5 kW Max. spindle speed: 4,500 rpm Torque: 93 Nm Spindle nose: JIS A2-5 Chuck size: 210 mm (8 inches) Lajdpfoztxlcsx Acfef Number of turrets: 2 Turret type: BT turret Tool positions per turret: 8 Shank size for external turning tools: 20 × 20 mm Max. shank diameter for boring bars: 40 mm MACHINE DETAILS Control: Fanuc 32i-B Working areas: 2 Power connection: 30 kVA Dimensions & Weight Footprint: 4,500 × 2,440 mm Overall height with loader: 2,550 mm Weight: 4,400 kg Loading portal GT Twin with two independent portals Dual gripper for raw and finished parts Turning station Control unit with cable Max. workpiece diameter: 120 mm Max. workpiece length: 80 mm Max. workpiece weight: 3 kg EQUIPMENT Stack magazine, on the left side Parts conveyor belt, on the right side Chip conveyor, on the rear side Coolant tank Coolant supply through both spindles for flushing the clamping devices Various tool holders Various clamping devices Documentation and wiring diagrams

Condition: excellent (used), Year of construction: 2007, functionality: fully functional, travel distance X-axis: 1,250 mm, travel distance Y-axis: 660 mm, travel distance Z-axis: 540 mm, rapid traverse X-axis: 40 m/min, rapid traverse Y-axis: 40 m/min, rapid traverse Z-axis: 32 m/min, feed rate X-axis: 32 m/min, feed rate Y-axis: 32 m/min, feed rate Z-axis: 32 m/min, controller manufacturer: Okuma, controller model: OSP P200M-H, rotary table diameter: 500 mm, Equipment: chip conveyor, documentation/manual, rotational speed infinitely variable, Okuma MU500VA CNC Vertical Machining Centre (2007) Equipped with OKUMA OSP P200M-H CNC CONTROL 20" ROTARY PLATEN 4TH AND 5TH AXIS BUILT IN TRUNION 32 POSITION AUTOMATIC TOOL CHANGER COOLANT THRU SPINDLE TOOL LENGTH MEASURING Travels X-axis (saddle left/right) – 1250mm, Y-axis (pallet front/back) – 660mm, Z-axis (spindle up/down) – 540mm, A-axis – +20~-110 deg., C-axis – 360 deg., Table surface to spindle nose – 127~667mm Table Table size – ø500mm, Max work size – ø730xh500, Floor to table top – 1073mm, Max load capacity – 500kg Spindle Spindle speed – 15000rpm, Turning specification – C-axis table 1000rpm , No. of spindle ranges – Infinitely variable, Tapered bore – 7/24 taper No.40, Bearing dia – ø70mm Feed Rapid traverse – X-Y: 40m/min, Z:32m/min, Rapid traverse (A-C) – 18,000 deg/min, Cutting feed rate – X-Y-Z: 32m/min Motors Spindle (10min/cont) – 11/7.5kW Laedpfxeyf Ncqe Acfef ATC Tool shank type – MAS BT40 Big plus, Retention knob type – MAS 2, Tool capacity – 32, Max. tool dia (w/ adjacent tool) – ø90mm, Max. tool dia (w/o adjacent tool) – ø125mm, Max. tool length – 400mm, Max. tool mass – 8kg, Tool selection – Memory random ATC Retention knob type – MAS 2, Tool capacity – 32, Max. tool dia (w/ adjacent tool) – ø90mm, Max. tool dia (w/o adjacent tool) – ø125mm, Max. tool length – 400mm, Max. tool mass – 8kg, Tool selection – Memory random

Condition: like new (used), Year of construction: 2017, max. wheel diameter 100 mm gear width 26 mm max. module 31 min. module 0,1 Control Siemens 840 D SL Number of working hours 9598 h Ledpfev Ehbbjx Acfsaf total power requirement 45 kW weight of the machine ca. 7,8 t dimensions of the machine ca. 4,40x3,95x3,01 m Gleason 100S gear shaping machine for the production of internally and externally toothed cylindrical gears and other cylindrical workpiece circumference regularly occurring profiles and moulds as well as for the production of profiles using the single part process. Technical data: Nominal workpiece diameter 100 mm Largest circumferential diameter 150 mm Machine nominal module approx. 3 mm (Guide value depending on the respective machining task.) Shaping spindle stroke speed range 0 - 3,000 1/min Stroke position adjustment range (manual) 20 mm Largest toothing width 26 mm Smallest pitch height of the hydrostatic inclined guide 400 mm Smallest/largest distance between tool axis - 20/+ 180 mm and workpiece axis Stand inclination range (manual) - 1/+ 11° Tool holder (manual clamping) HSK-D63 (hollow shank taper according to DIN 69063) Weight of the machine approx. 7,000 kg with robot cell

Condition: good (used), Year of construction: 2012, operating hours: 7,360 h, Doosan Lynx 220B CNC Slant Bed Lathe With Doosan-Fanuc I Series Control With Ø135mm Collet Chuck. Maximum Swing Ø510mm. Maximum Swing Over Cross Slide Ø290mm. Maximum Turning Ø320mm. Maximum Turning Length 305mm. Bar Capacity Ø51mm. Axis Travel 'X'=175mm, 'Z'=330mm. Rapid Feedrates 'X'=30m/min, 'Z'=36m/min. Spindle Nose A2-6. Maximum Spindle Speed 5,000rpm (15kW Motor). Spindle Nose A2-6. Spindle Through Bore Ø61mm. 12 Station Turret. Tailstock Quill Ø80mm, Quill Travel 80mm, Taper MT4. Tool Shank 25 x 25mm. Boring Bar Sleeve Ø40mm. S/No. ML0014-005414 (2012). Low Running Hours 7,360. Lasdpfxezt R U No Acfef With Coolant System, Tool Setter, Parts Catcher, Seoam CAH-08 3 Jaw Power Chuck, Tailstock, Foot Switch, Quantity Of Assorted Hard/Soft Jaws & Manuals. Approx Dimensions L2,325 x W1,600 x H1,600mm. Weight 2,900kg.

Condition: excellent (used), Year of construction: 2017, operating hours: 2,728 h, Doosan Puma GT2100 CNC Slant Bed Lathe With Doosan-Fanuc I Series Control Lajdpfx Aszt R Ucecfef With Samchully MH-208 V1 Ø203mm 3 Jaw Power Chuck. Maximum Swing Ø600mm. Maximum Swing Over Cross Slide Ø390mm. Maximum Turning Ø390mm. Maximum Turning Length 562mm. Bar Capacity Ø65mm. Axis Travel 'X'=230mm, 'Z'=580mm. Rapid Feedrates 'X'=24m/min, 'Z'=30m/min. Spindle Nose A2-6. Maximum Spindle Speed 4,500rpm (18.5kW Motor). 12 Station Turret. Programmable Tailstock Travel 580mm, Tailstock Quill Ø80mm, Quill Travel 80mm, Taper MT4. Tool Shank 25 x 25mm. S/No. ML0228-001618 (2017). Note: Low Running Hours 2,728. With Coolant System, Tool Setter, Parts Catcher, Ø165mm Collet Unit, Foot Switch, Quantity Of Assorted Hard/Soft Jaws & Manuals. Approx Dimensions L2,940 x W1,632 x H1,700mm. Weight 3,500kg.

Condition: ready for operation (used), Year of construction: 2014, travel distance X-axis: 650 mm, travel distance Y-axis: 765 mm, travel distance Z-axis: 510 mm, table load: 500 kg, overall weight: 18,000 kg, spindle speed (max.): 20,000 rpm, number of slots in tool magazine: 30, number of axes: 5, This 5-axis Hyundai Wia HI-MOLD 750-5A vertical machining centre was manufactured in 2014. It features a spindle speed of 20,000 RPM, a tool magazine with 30 slots, and a rapid traverse rate of 50 m/min in all axes. The table can handle up to 500 kg, tilting from +30˚ to -120˚. Consider the opportunity to buy this Hyundai Wia HI-MOLD 750-5A vertical machining centre. Contact us for more information about this machine. Machine Benefits Technical Machine Benefits • Table size: Ø630 mm Lajdpjzvv Dbofx Acfjf • Tilting angle: +30˚ ~ -120˚ • Tool change time (c-c): 6. 5 sec • Tool shank: hsk-a63 Extra Information Machine still under power

Year of construction: 2012, condition: ready for operation (used), overall weight: 15,000 kg, spindle motor power: 45,000 W, This INGRAMATIC RP72 L was manufactured in 2012. It features a double starter unit with TR7 dies, capable of threading diameters from M14 to M20. The machine operates at speeds up to 120 rpm, powered by a robust 45 kW motor. Weighing 15,000 kg, it is in very good condition and ready for immediate shipment. CE compliant and includes Brankamp control process. Contact us for more information about this machine. • Starter unit: Double • Dies type: TR7 • Die dimensions: • Fixed die length: 280 mm • Moving die length: 305 mm • Die thickness: 50 mm • Die height: 162.5 mm Ledezvvqhopfx Acfeaf • Threading capacity: • Thread diameter: M14–M20 • Shank length: 300 mm • Thread length: 160 mm • Performance: • Speed range (up to): 120 rpm • Condition: Very good, fully operational • Compliance: CE • Availability/Delivery: Ready for immediate delivery; ready for shipment Additional equipment • Brankamp process control system included

Condition: ready for operation (used), Year of construction: 2008, controller manufacturer: FANUC, controller model: Fanuc 310, This 4-axis DMG Gildemeister SPEED 32/10 linear was manufactured in 2008. It features a CNC Fanuc 310iS control, a main spindle with a bar capacity of 33 mm, and a maximum speed of 8,000 rpm. The machine offers robust multitasking capabilities with a total of 16 driven tool stations and a turret for efficient processing. If you are looking to get high-quality turning capabilities, consider the DMG Gildemeister SPEED 32/10 machine we have for sale. Contact us for more information. • CNC: Fanuc 310iS • Panel type: SlimLine • Screen: 15" TFT Color • Controlled spindles (including C axes): 2 • Controlled axes: 8 • Channels: 3 • Bar capacity: 33 mm (36 mm max) • Draw tube inner diameter: 46 mm • Maximum speed: 8000 rpm • Nominal torque (S1): 24 Nm • Nominal power (S1): 5.5 kW • Draw tube inner diameter: 38 mm • Maximum speed: 8000 rpm • Nominal torque (S1): 9.4 Nm • Nominal power (S1): 3.7 kW • Axis X1 • Travel: 50 mm • Maximum speed: 40 m/min • Maximum acceleration: 10 m/s² • Nominal thrust (S1): 1200 NAxis Y1 • Travel: 350 mm • Maximum speed: 30 m/min • Maximum acceleration: 5 m/s² • Nominal thrust (S1): 5000 NAxis Z1 • Travel: 320 mm • Maximum speed: 40 m/min • Maximum acceleration: 5 m/s² • Nominal thrust (S1): 2500 NAxis X2 • Travel: 310 mm • Maximum speed: 40 m/min • Maximum acceleration: 5 m/s² • Nominal thrust (S1): 2500 NAxis Z2 • Travel: 320 mm • Maximum speed: 40 m/min • Maximum acceleration: 5 m/s² • Nominal thrust (S1): 2500 NAxis X3 • Travel: 80 mm • Maximum speed: 40 m/min • Maximum acceleration: 5 m/s² • Nominal thrust (S1): 1200 NAxis Y3 • Travel: 60 mm (±30 mm) • Maximum speed: 18 m/min • Maximum acceleration: 5 m/s² • Nominal thrust (S1): 5000 NAxis Z3 • Travel: 150 mm • Maximum speed: 40 m/min • Maximum acceleration: 5 m/s² • Nominal thrust (S1): 2500 NTurret • Total stations: 16 • Fixed external tools: 8 • Tool shank size: 16×16 mm • Driven tool stations: 16 • Collet type: ESX/ER 20 Lasdpjzvvp Rjfx Acfjf • Maximum driven speed: 5000 rpm • Nominal torque (S1): 4.8 Nm • Nominal power (S1): 1.5 kWToolsToolholder Slide 1 • Total stations: 10 • Fixed external tools: 6 • Tool shank size: 16×16 mm • Driven tools: 4 • Collet type: ESX/ER 20 • Maximum driven speed (GEO 7–9): 5000 rpm • Nominal torque (S1): 2.19 Nm • Nominal power (S1): 0.55 kW • Secondary driven speed (GEO 8–10): 3333 rpm • Nominal torque (S1): 3.28 Nm • Nominal power (S1): 0.55 kWBack Working Slide • Total stations: 4 + 2 • Internal fixed tools: 3 • Toolholder diameter: 25 mm • External fixed tools: 1 • Driven stations: 2 • Collet type: ESX/ER 16 • Maximum driven speed: 6000 rpm • Nominal torque (S1): 1.75 Nm • Nominal power (S1): 0.55 kWMediaLubrication System • Tank capacity: 2.9 L • Operating pressure: 30 bar • Stop time: 7 minutes • Operating cycle time: 30 seconds • Lubricant type: Castrol Magna BD 68Pneumatic System • Minimum operating pressure: 5 bar • Maximum operating pressure: 6 bar • Consumption: 60 NL/min

Condition: like new (used), amount 1 Palette Milling, drilling, and cutting tools for CNC and conventional machine tools. These include: -> Face mills — large milling heads with multiple indexable inserts, ideal for facing large surfaces. -> Cylindrical end mills — cylindrical mills with face and peripheral teeth, often used for grooves and contours. -> Disc cutters — thin, round cutters for cutting or for deep grooves. -> Drills — various twist drills for metalworking. -> Gear hobs — gear-like cutters for producing gear teeth. -> Tool shanks (SK/ISO/BT) — the tapered tool holders on which the cutters are mounted. -> Collet chucks — holders for smaller tools, such as drill bits or end mills. -> End mills — smaller cutters with multiple cutting edges for contouring, pocketing, and 3D machining. -> Indexable-insert cutters — cutters with replaceable carbide inserts. Laedpfozhcf Njx Acfjf -> Circular saw blades — round saw blades for cutting or slotting. -> Adapters and spacers — for adapting different tool holders. Complete package price

Condition: ready for operation (used), functionality: fully functional, Year of construction: 2024, total length: 1,250 mm, total height: 1,900 mm, total width: 2,000 mm, overall weight: 1,850 kg, No minimum price – guaranteed sale to the highest bidder! Lease return due to factory closure. Machine for the automatic and precise separation or singulation of printed circuit boards from a PCB panel. MACHINE DETAILS New price 2024: €149,000.00 net Processed printed circuit boards: 42,680 pieces Dimensions of pallet (L x W x H): 1,250 x 2,000 x 1,900 mm Machine weight: approx. 1,850 kg Lajdpfx Aszvb I Eecfef EQUIPMENT Cutter diameter control Wear parts package DIVISIO Automatic transport width adjustment SMEMA transport height Separation module, shank cutter 500 W Hardware module, camera Software module, teach function for camera Software module, fiducial mark recognition Extension, 8-position tool changer Extraction hose, manual Monitoring of suction power ASYCAM CAD data conversion A Adrep Offset main switch ESD energy chains and P-hoses, standard Packaging size, group 3 pallet • The height and weight of the asset must be taken into account when selecting the transport vehicle. • A forklift is available for loading. • If the asset is not collected on time, a storage fee of €20.00 per lot and commenced day will be charged. The fee must be paid before collection. • The sale is made without any guarantee or warranty. • No liability is accepted for typing or measurement errors. If in doubt, please compare the information with the provided photos or inspect the goods on site before the auction ends.

Condition: used, Year of construction: 2018, turning diameter max. 356 mm turning length 705 mm control M730 UM Mapps CELOS greates pass round over bed 920 mm Swing dia. over traverse guideway 742 mm turning speed range - main spindle 4.000 min/-1 power capacity - main spindel 18,5 / 15 kW spindle nose JIS A2-8 spindle bore 80 (91) mm C-Axis 0,001 ° Spindle speed range subspindle 6.000 min/-1 power capacity - Sub spindle 11 / 7,5 kW spindle bore 43 mm C-Axis 0,001 ° x-travel 260 mm z-travel 795 mm Y - Axis +/-50 mm rapid traverse ( X / Y / Z ) 30 / 10 / 30 m/min number of toolpositions 12 pos. Schank height for square tool 25 mm Drill shank diameter 50 mm turret change time 0,27 sec. Spindle speed - driven tools max. 10.000 min -1 power capacity - driven tools 5,5 / 4,2 kW total power requirement 41 kVA weight of the machine ca. 6,4 t dimensions of the machine ca. 5,0 x 3,0 x 2,3 m CNC - Turning- and MillingCenter DMG MORI - NLX 2500 SY / 700 - Subspindle - Tool-Drive - C, Y-Axis Lajdpfovy Ig Hox Acfjf - approx. 12,000 operating hours

Condition: used, 1 piece of drill chuck, ALBRECHT, clamping range up to 10 mm Ljdpszvyphofx Acfeaf 2 pieces of Morse taper with driving lugs, MK 1 2 pieces of collet chuck with cap nut, ER 11, length 70 mm 1 piece of collet chuck with cap nut, ER 11, length 40 mm 1 piece of milling chuck, shank 20 mm

Condition: used, 1 piece drill chuck, ALBRECHT, clamping range up to 10 mm 1 piece drill chuck, RÖHM, clamping range from 3 - 13 mm. For quick-change system SF 32: 1 piece collet chuck with locknut, ER 32 2 pieces collet chuck with locknut, ER 25 1 piece milling arbor, shank 32 mm Laedpfx Acozvyn Rofef

Condition: excellent (used), Year of construction: 2021, GANNOMAT "PROTEC 571" (drilling, grooving, milling) with Clamex and milling tools In top condition Base machine complete in standard configuration for drilling and grooving, including: - Additional safety device via louver curtain - Prerequisite for horizontal Lamello P-system milling - Prerequisite for milling diameters > Ø 16 mm, as well as for the use of multi-part milling tools Laodpszu A D Eefx Acfof Detailed technical data can be found in the data sheet for ProTec Type 0571 Machining unit with: PowerBlock with 21 spindles and 1 dado saw - 13 vertical drilling spindles - 6 horizontal drilling spindles in Y / 2 horizontal drilling spindles in X - 1 grooving unit in Y Workpiece sizes and weights - Workpiece width (X): min. 60 mm / max. 1000 mm - Workpiece thickness (Z): min. 6 mm / max. 60 mm - Workpiece length (Y): min. 250 mm in continuous mode max. 5600 mm programmable workpiece length in software - Workpiece weight: max. 75 kg 1 Milling unit Profit HSK63F with 3-way magazine for automatic tool change, motor 5.5 kW (S1), 1000-18000 rpm with frequency inverter, clockwise and counterclockwise rotation, for tool holder HSK63F with collet 462E/OZ25, cutter length up to 130 mm including options 1 Roller table 765 mm (Y-axis) foldable, for the front of the machine, width 500 mm 1 Roller table 765 mm (Y-axis) foldable, for the rear of the machine, width 500 mm 1 Auxiliary stop 600 mm with integrated rollers for roller tables 1 SET OF TOOLS: Drill set for ProTec 1 Carbide grooving cutter  125/30 mm, grooving cutter width (SB) 4 mm, Z=12, LI, by Leitz 1 Tools for milling unit Profit HSK63F and HSK63F with 3-way magazine with collet 462E up to shank diameter 25mm, HSK and cutter set 1 HSK mounting set 1 Mounting device HSK63F, easiest operation with maximum user comfort thanks to roller clamping system, no clamping or tightening required, mounted on a stable base or workbench, 1 Hook wrench for HSK63F collet 462E, 1 Extraction distributor Ø 160 mm / Ø 80-80-80 mm, pitch 196 mm 1 Counterpressure device from above 1 Tool for vertical Lamello P-system milling Machine in very good condition with many drills and tools included. The machine can be viewed and demonstrated at our showroom. Location: available from stock in 54634 Bitburg - immediately available -

Condition: used, Year of construction: 2014, Working dimensions: X = 3425 mm, Y = 1287 mm, Z = 325 mm. Max. workpiece height: 180 mm. Max. clearance under the hood: Y = 1450 mm / Bumper version = 1370 mm. Includes CabinetControl Base, 1 machine license, and 1 office license. Milling head 7830, 1-stage, power 6.5 kW, air-cooled, n(max.) 1000 - 18000 min-1, infinitely adjustable. Max. power at 12000 min-1 to 18000 min-1 with HSK-F 63 tool holder, with collet chuck with HSK shank. Drilling unit 7884, 14 spindles, 10 vertical spindles individually accessible, arranged in an L-shape, 6 in the X direction and 4 in the Y direction. Drive power 3 kW, 32 mm pitch. Sawing unit: Integrated sawing unit for sawing/grooving in the X direction, n(max.) 1000 - 5650 min-1, infinitely adjustable. Tool holder: A = max. DM = 125 mm. Lodpfx Aoy Tpz Recfoaf Location: Supplier.

Condition: excellent (used), Year of construction: 2010, grinding length: 330 mm, grinding wheel diameter: 250 mm, total width: 1,765 mm, total length: 1,830 mm, total height: 2,441 mm, grinding diameter: 20 mm, type of input current: three-phase, workpiece diameter between centers: 20 mm, spindle speed (max.): 10,000 rpm, feed length X-axis: 29 mm, feed length Y-axis: 350 mm, feed length Z-axis: 100 mm, feed rate X-axis: 29 m/min, feed rate Y-axis: 350 m/min, feed rate Z-axis: 100 m/min, grinding spindle motor power: 9 W, grinding spindle speed: 7,600 rpm, overall weight: 3,000 kg, input frequency: 50 Hz, rapid traverse X-axis: 15 m/min, rapid traverse Y-axis: 15 m/min, rapid traverse Z-axis: 15 m/min, input voltage: 400 V, workpiece spindle speed (max.): 3,000 rpm, Equipment: rotational speed infinitely variable, Rollomatic ShapeSmart NP5 — CNC cylindrical grinding machine (pinch/peel) with 3-axis loading robot Year of manufacture 2010 · CNC pinch/peel cylindrical grinding machine · Ø 0.025–20 mm · 3-axis loading robot Five-axis pinch/peel cylindrical grinding machine from Rollomatic SA (Le Landeron, Switzerland) for the rough and finish machining of cutting tools, punches, micro-drills, and forming and ejector pins. The original factory invoice from Rollomatic from 2010 for this machine is available, which documents the design, drives, axis travels, and included equipment. KEY DATA - Grinding diameter Ø 0.025 – 20.0 mm · Shank diameter Ø 1.0 – 20.0 mm · Grinding length max. 330 mm - Control system GE FANUC 320iA, 8 axes (5 machine axes + 3 robot axes), NanoGrind user interface on PC - Roughing spindle 8.5 kW, wheel Ø 250 mm, max. 7,600 min⁻¹ · Finishing spindle 1.4 kW, wheel Ø 150 mm, max. 10,000 min⁻¹ - Workpiece spindle with collet chuck W20, 0 – 3,000 min⁻¹ - Axis travels Y 350 mm · Z 100 mm · X and V each 29 mm with glass scale, resolution 0.00005 mm - Loading robot 3 axes, workpieces Ø 1.0 – 16.0 mm, length 30 – 300 mm, magazine 150 – 1,000 pieces - 1830 × 1765 × 2441 mm · approx. 3,000 kg · 3 × 400 V, 50 Hz, max. 15 kW WHAT MAKES THIS MACHINE SPECIAL - Pinch/peel process: Roughing and finishing wheels engage with the workpiece simultaneously — high accuracy of roundness and short cycle times in one pass SCOPE OF DELIVERY - Machine complete: Machine bed, full splash guard, electrical cabinet, pneumatics unit, control panel with 15" screen and PC keyboard - Control system GE FANUC 320iA with 8 axes, Rollomatic NanoGrind user interface on PC - P4Smart software for offline programming and simulation - Roughing station with 8.5 kW spindle (90° design) and finishing station with 1.4 kW direct drive spindle, both with PerfectArbor mounting - Monoblock shank guide with pneumatic pressure lever Ledpfxszvh Uxs Acfsaf - Workpiece spindle with collet chuck W20 - Integrated three-axis loading robot with base plate for Rollomatic cassettes - Cassettes and collet chucks from the machine's inventory — the exact scope will be listed definitively for the shipping date - Transport-safe packaging on a wooden pallet, loading onto your truck included - Coolant filter and cooling system as well as extraction are not included in the scope of delivery — both were centrally installed at the previous owner - Fire extinguishing system and grinding wheels are not included in the scope of delivery AVAILABILITY AND INSPECTION Availability: End of September 2026, ex warehouse Velten. Demonstration, trial grinding and measurement only after prior appointment — installation and commissioning will be carried out by an external service partner. PROCESSING Location 16727 Velten near Berlin (Germany) · FCA Velten incl. loading · 100% prepayment · Delivery 1–2 working days after payment receipt · Price on request · All technical data in the attached data sheet. Technical data according to manufacturer's documents (Rollomatic factory invoice from 2010 for this machine and series catalog) — information provided, no agreement on characteristics within the meaning of §§ 434, 443 BGB. We will confirm individual values definitively during the inspection or upon specific request. Subject to errors and prior sale.

Condition: ready for operation (used), Year of construction: 2021, spindle motor power: 22,000 W, spindle speed (max.): 4,200 rpm, travel distance X-axis: 325 mm, travel distance Z-axis: 840 mm, total height: 2,300 mm, total width: 2,140 mm, overall weight: 6,200 kg, controller manufacturer: FANUC, controller model: 32i-B, product length (max.): 3,000 mm, number of axes: 6, This 6-axis Takisawa TS-4000YS was manufactured in 2021. It features a maximum swing diameter of Ø 600 mm and a turning diameter of Ø 370 mm with a length of 750 mm. The machine includes a powerful 22 kW main motor and a counter spindle with a speed of 6000 rpm. If you are looking to get high-quality turning capabilities, consider the Takisawa TS-4000YS turn-mill centre we have for sale. Contact us for further details. • Capacity: • Max. swing diameter: Ø 600 mm • Max. turning diameter x length: Ø 370 x 750 mm • Bar capacity: Ø 82 mm • Main spindle: • Spindle centerline height from floor: 1140 mm • Bearing/bore diameter: Ø 140 / Ø 90 mm • Spindle nose: A2-8 • C-axis resolution: 0,001° • Counter spindle (Included): • Spindle centerline height from floor: 1140 mm • Bearing/bore diameter: Ø 90 / Ø 53 mm • Spindle nose: F-140 • Speed: 6000 rpm (1/min) • C-axis resolution: 0,001° • Strokes: • Y: -50 ~ +70 mm • A: 780 mm • Rapid traverses: Laedpszu S Akofx Acfjf • X: 30 m/min • Z: 30 m/min • Y: 10 m/min • A: 30 m/min • Power: • Main spindle motor (30 min. / 100% ED): AC 22 / 15 kW • Max. torque (main spindle): 618 Nm (S3 25%) • Counter spindle motor (30 min. / 100% ED): AC 11 / 7,5 kW • Max. torque (counter spindle): 175 Nm (S3 25%) • Driven tools (Included): • Turret stations: 12 pcs • Max. speed: 6000 rpm (1/min) • Drive power (S3 25% / 100% ED): 7,5 / 3,7 kW • Max. torque: 48 Nm • Tooling: • Tool shank cross-section: 25 x 25 mm • Boring bar diameter: Ø 50 mm • Control: CNC path control FANUC 32i-B Technical Specification Counter Spindle Yes Driven Tools Yes
