Used Guideway for sale (382)

Condition: ready for operation (used), Year of construction: 2018, operating hours: 14,396 h, travel distance X-axis: 350 mm, travel distance Y-axis: 550 mm, travel distance Z-axis: 510 mm, controller manufacturer: MAZATROL, controller model: SmoothX, workpiece height (max.): 350 mm, total height: 2,840 mm, total width: 1,900 mm, table load: 200 kg, overall weight: 7,100 kg, spindle speed (max.): 12,000 rpm, number of slots in tool magazine: 30, tool weight: 8,000 g, product length (max.): 3,060 mm, number of axes: 5, This 5-axis Mazak VARIAXIS J-500/5X was manufactured in 2018. It features a maximum workpiece diameter of 500 mm and a maximum table load of 200 kg. The machine is equipped with a 19-inch colour touchscreen and a maximum spindle speed of 12,000 rpm. If you are looking to get high-quality simultaneous 5-axis machining capabilities, consider the Mazak VARIAXIS J-500/5X vertical machining centre we have for sale. Contact us for further details. • Cutting time (“cutting only”): 14,396 h 54 min • Working capacity and travels • Max workpiece diameter: 500 mm; height: 350 mm • A-axis tilt: -120° to +30°; C-axis rotation: ±360° • A/C indexing increment: 0.0001° • Rapid traverse X/Y/Z: 30,000 mm/min • Max cutting feed X/Y/Z: 30,000 mm/min • A-axis indexing time: 0.6 s per 90° • C-axis indexing time: 0.55 s per 90° / 1.05 s per 180° Bwsdoz Ipzuopfx Ahmou • Guideways: Roller linear guideways • Table and clearances • Tilting/rotary table with A and C axes • Table size: 500 × 400 mm • T-slot table (as specified in final configuration) • Spindle nose to table surface, table horizontal: 50–560 mm • Spindle nose to table, table vertical: 40–550 mm • Spindle • Spindle chiller; spindle cooling oil tank: 16 L • Programmable spindle orientation in 1° increments • Tool changer and magazine • ATC with recovery function; digital magazine display; external magazine operating panel • Tool selection: fixed magazine addresses with automatic shortest-path selection • Max tool length: 300 mm • Max tool diameter with adjacent tools: 90 mm; with adjacent pockets empty: 130 mm • Chip-to-chip time: 6.20 s • Measuring and probing • Automatic tool length measurement and tool breakage detection • G37 automatic tool length measurement function • Absolute positioning system • MAZA-CHECK system • Preparation for RMP600 workpiece probe • Coolant and thermal management • Through-tool high-pressure coolant (~15 kgf/cm² ≈ 14.7 bar), flow ~35 L/min • Coolant tank: 300 L • Coolant washdown system • Cooling for X/Y/Z-axis ball screws • Control and software • MAZATROL conversational and EIA/ISO programming; simultaneous 5-axis control in EIA/ISO • G00 Slope Constant; Smooth restart; Tilted machining plane; Inverse Time Feed • Extended work offsets: 300 pairs; Variable macros: 600 variables • Polar coordinate programming; Tornado machining cycle • High-speed machining and smoothing; Geometric compensation for rotary axes • Seamless Corner Control; Variable Acceleration Control • Interfaces: USB, LAN, SD memory card • Safety, enclosure, compliance • Full working-area enclosure with top cover • Interlocked operator door; working-area lighting • Intelligent Safety Shield (ISS) • CE marking • Automation/operation aids • Automatic machine power on/off and warm-up Additional equipment • Right-side hinged-belt chip conveyor for steel machining • European-market power transformer • Machine installation kit • Polish manuals and safety labels Technical Specification Taper Size SK 40 Through-spindle Coolant Yes

Condition: ready for operation (used), Year of construction: 2023, operating hours: 3,613 h, spindle speed (max.): 3,250 rpm, travel distance X-axis: 308 mm, travel distance Z-axis: 1,240 mm, spindle motor power: 33,000 W, overall weight: 7,200 kg, controller manufacturer: SIEMENS, controller model: 840D with ShopTurn, number of slots in tool magazine: 12, number of axes: 3, This 3-axis DMG MORI CLX 550 V3 was manufactured in 2023. It features a maximum turning diameter of 480 mm and a turning length of 1240 mm. The machine is equipped with a powerful spindle capable of 3,250 rpm and a 12-position tool turret. If you are looking to get high-quality turning capabilities, consider the DMG MORI CLX 550 V3 horizontal turning machine we have for sale. Contact us for further details. • Control panel: DMG MORI SLIMline Multi-Touch, 19" touchscreen • Axes: 3 (X, Z, C); no Y-axis; no counter spindle • Spindle operating hours: approx. 3613 hWorking capacity and axes • Max turning diameter: 480 mm • Max turning length: 1,240 mm • Swing over bed: 700 mm • Swing over cross slide: 500 mm • Rapid traverse X/Z: 30 m/min • C-axis: main spindle CMain spindle and chuck • Spindle nose: A2-8 • Bar capacity: 102 mm (upgraded main spindle) • Spindle power: 33 kW @ 40% DC / 22 kW continuous • Spindle torque: 630 Nm @ 40% DC / 420 Nm continuous • Chuck: SMW BH-D 320 / A2-8, D103 mm (as specified) • Function: differential clamping pressureTurret and driven tools • Turret: 12-position VDI40 with 6 additional BT stations • Driven tools: up to 4,000 rpm Bedpfoz Ipilox Ahmjwu • Driven-tool power/torque: 5.44 kW @ 40% DC; 20 Nm @ 40% DCTailstock • Travel: 1,200 mm • Centre taper: MT5 • Max thrust: 12 kNEquipment and options (machine) • Setup package • Tropical climate package • 12-bar coolant supply • Manual working-area washdown gun • Variable spindle speed software option • DMG MORI IoTconnector • Digital Manufacturing PackageConstruction • Inclined cast-iron bed • Linear guideways, 45 mm width Additional equipment • Mechanical oil mist extraction unit, 1,100 m³/h • Tooling: • Set of 12 tool holders • Set of 6 boring tool holders • ALGra driven-tool holder set Technical Specification Counter Spindle No Driven Tools Yes

Condition: ready for operation (used), Year of construction: 2020, operating hours: 20,292 h, spindle speed (max.): 3,250 rpm, travel distance X-axis: 308 mm, travel distance Z-axis: 1,240 mm, spindle motor power: 33,000 W, overall weight: 7,200 kg, controller manufacturer: SIEMENS, controller model: Siemens 840D with ShopTurn, number of slots in tool magazine: 12, number of axes: 3, This 3-axis DMG MORI CLX 550 V3 was manufactured in 2020. It features a maximum turning diameter of 480 mm and a turning length of 1240 mm. The machine is equipped with a 12-position VDI 40 turret and a maximum spindle speed of 3250 rpm. If you are looking to get high-quality turning capabilities, consider the DMG MORI CLX 550 V3 horizontal turning machine we have for sale. Contact us for further details. • Control panel: DMG MORI SLIMline Multi-Touch, 19-inch touchscreen • Controlled axes: 3 (X, Z, C) Bwedpfx Ahjz Ipawsmou • Spindle operating hours: approx. 20,292 hWorking capacity and axes • Max turning diameter: 480 mm • Max turning length: 1,240 mm • Swing over bed: 700 mm • Swing over cross slide: 500 mm • Rapid traverse X/Z: 30 m/min • Main spindle C-axisMain spindle and chuck • Spindle nose: A2-8 • Upgraded bar capacity: 102 mm • Spindle power: 33 kW @ 40% / 22 kW continuous • Spindle torque: 630 Nm @ 40% / 420 Nm continuous • Hydraulic chuck: SMW BH-D 320 / A2-8, D103 mm • Differential clamping pressure functionTool turret and driven tools • Turret: 12-position VDI 40 with 6 additional BT stations • Driven tools: yes • Max driven-tool speed: 4,000 rpm • Driven-tool power: 5.44 kW @ 40% • Driven-tool torque: 20 Nm @ 40%Tailstock • Tailstock travel: 1,200 mm • Centre taper: MT5 • Max thrust: 12 kNEquipment and options • Setup package • Tropical climate package • 12-bar coolant supply system • Manual working-area washdown gun • Variable spindle speed function • DMG MORI Service Agent • DMG MORI Messenger V2 • DMG MORI NETservice • DMG MORI IoTconnector • Screen languages: German/PolishConstruction • Inclined cast-iron bed • Linear guideways, width 45 mm Additional equipment • Mechanical oil mist extraction unit, 1,100 m³/h • WTO VDI 40 driven-tool holder set • Set of three soft jaws for BH-D315 chuck Technical Specification Counter Spindle No Driven Tools Yes

Condition: ready for operation (used), Year of construction: 2020, travel distance X-axis: 350 mm, travel distance Y-axis: 550 mm, travel distance Z-axis: 510 mm, controller manufacturer: MAZATROL, controller model: SmoothG, total height: 2,840 mm, total width: 1,900 mm, overall weight: 7,100 kg, spindle speed (max.): 18,000 rpm, number of slots in tool magazine: 30, tool weight: 8,000 g, product length (max.): 3,060 mm, number of axes: 5, This 5-axis Mazak VARIAXIS J-500/5X was manufactured in 2020. It features a maximum spindle speed of 18,000 rpm and a rapid traverse rate of 30,000 mm/min. The machine includes a tool magazine capacity of 30 tools and a robust table size of 500 x 400 mm. If you are looking to get high-quality machining capabilities, consider the Mazak VARIAXIS J-500/5X vertical machining centre we have for sale. Contact us for further details. • CNC control: MAZATROL SmoothX with 19-inch colour touchscreenWorking capacity and travels • A-axis tilt: -120° to +30° • C-axis rotation: ±360° • A/C indexing increment: 0.0001° • Rapid traverse X/Y/Z: 30,000 mm/min • Max cutting feed X/Y/Z: 30,000 mm/min • A-axis index time: 0.6 s per 90° • C-axis index time: 0.55 s per 90° / 1.05 s per 180°Table and clearances • Tilting/rotary table (A/C axes) • Table size: 500 × 400 mm • Table with T-slots (as per final configuration) • Spindle nose to table surface (table horizontal): 50–560 mm • Spindle nose to table centre (table vertical): 40–550 mmSpindle • Spindle chiller with 16 L cooling oil tank • Programmable spindle orientation in 1° incrementsTool magazine and ATC • ATC with recovery function; digital magazine display and external operating panel • Tool selection: fixed addresses with automatic shortest-path selection • Pull stud: Yamazaki ANSI • Max tool length: 300 mm • Max tool diameter with adjacent tools: 90 mm • Max tool diameter with adjacent pockets empty: 130 mm • Chip-to-chip time: 6.20 sMeasuring and probing • Renishaw RMP600 radio workpiece probe • MAZA-CHECK system • Automatic tool length measurement and tool breakage detection • G37 automatic tool length measurement • Absolute positioning systemCoolant and chip management • Through-tool high-pressure coolant: approx. 15 kgf/cm² (≈14.7 bar), approx. 35 L/min • Coolant tank: 300 L • Coolant washdown system and manual washdown gun • Cooling for X/Y/Z ball screws • Workpiece air blastControl and software • MAZATROL SmoothX CNC • EIA/ISO programming package • Simultaneous 5-axis control Bwsdpfxsz Iqgro Ahmeu • Additional 5-axis machining package for SmoothX • 3D coordinate rotation • Smooth synchronous tapping • G00 Slope Constant (rapid optimization) • Smooth restart • Tilted machining plane • Inverse Time Feed • Extended work offsets: 300 pairs • Variable macros: 600 variables • High-speed machining and smoothing • Geometric compensation for rotary axes • Interfaces: USB, LAN, SD cardConstruction, safety, and other features • Electronic handwheel • Three-colour signal tower • Automatic machine power on/off and warm-up • Roller linear guideways • Full enclosure with top cover; interlocked operator door • Work area lighting • Intelligent Safety Shield (ISS) • CE marking Additional equipment • CROWTHER right-side hinged-belt chip conveyor (for steel machining) • GX500 mist extraction unit with extraction preparation • European-market power transformer • Machine installation kit • Polish manuals and safety labels Technical Specification Taper Size SK 40 Through-spindle Coolant Yes

Condition: used, functionality: fully functional, grinding length: 10,000 mm, grinding width: 1,250 mm, FRITZ HECKERT SFBP 1250/10000 – Long-Bed Surface / Guideway Grinding Machine – 10,000 × 1,250 mm METALEX offers for sale a large industrial FRITZ HECKERT SFBP 1250/10000 surface grinding machine, designed for the precision grinding of very long and heavy workpieces. The machine has been used in our own workshop primarily for grinding machine tool beds and guideways, especially POREBA lathe beds during complete overhauls carried out by METALEX. With this machine design, the workpiece remains stationary during the grinding process, while the grinding unit travels longitudinally along the machine. This makes the machine particularly suitable for machining very long and heavy components without having to move the workpiece during grinding. Technical data and capabilities Manufacturer: FRITZ HECKERT / VEB Werkzeugmaschinenfabrik Type: SFBP 1250/10000 Bedpjzzcpzjfx Ahmowu Maximum grinding length: approx. 10,000 mm Maximum grinding width: approx. 1,250 mm Heavy-duty, very rigid industrial construction Stationary workpiece during the grinding process Longitudinal movement of the grinding unit Suitable for very long and heavy workpieces Particularly suitable for grinding machine beds, guideways, machine frames and other long flat surfaces Very good grinding performance and surface quality The machine has been used by METALEX for our own production and machine rebuilding work. Among other applications, we have used it for precision grinding of POREBA lathe beds as part of our complete machine overhaul projects. The machine is located in our workshop in Bydgoszcz, Poland. The machine can be inspected at our facility in Bydgoszcz. Further technical information can be provided upon request. Details regarding dismantling and loading can also be discussed with interested buyers. Location: Koronowo, Poland Price: On request / negotiable

Condition: ready for operation (used), Year of construction: 2011, operating hours: 12,214 h, functionality: fully functional, machine/vehicle number: 111146, travel distance X-axis: 1,100 mm, travel distance Y-axis: 610 mm, travel distance Z-axis: 610 mm, controller model: Heidenhain 530, spindle speed (max.): 10,000 rpm, Equipment: chip conveyor, TECHNICAL DETAILS Travel range, X-axis: 1,100 mm Travel range, Y-axis: 610 mm Travel range, Z-axis: 610 mm Spindle nose – table: 120–730 mm Table size: 1,250 × 610 mm T-slots in table: 5 T-slot width: 18 mm T-slot spacing: 100 mm Speed: 60–10,000 rpm Torque: 332 Nm Power: 13 kW (40 %) Rapid traverse rate X/Y/Z: 32 m/min Feed rate: 1–12,000 mm/min Positioning accuracy: ±0.005 mm Repeatability: ±0.003 mm Tool holder: SK40 Pull stud: DIN 69871/72 Tool changer: 30 stations Tool change time: 1.5 s Tool weight: max. 7 kg Tool diameter: max. 76 mm Tool diameter with free magazine slot: max. 140 mm Tool length: max. 300 mm MACHINE DETAILS Control system: Heidenhain 530 Central lubrication: R68 (ISO 68) Bsdpfsz Im Tnox Ahmjwu Hydraulic oil: R32 (ISO 32) Compressed air: 3/8″, 6–8 bar Power supply: 400 V / 75 A / 35 kVA Coolant tank: 250 l Guideways X/Y/Z: 45/45/45 mm Machine weight: 7,500 kg Internal cooling (IKZ): 22 bar Program runtime: 12,214 h Spindle hours: 14,123 h Machine operating hours: 39,242 h Control system operating hours: 34,987 h EQUIPMENT Chip conveyor Electronic handwheel Internal cooling (IKZ) 22 bar Oil-cooled spindle Linear guideways X/Y/Z Machine bed made of cast iron Note: Machine is sold without tools and vise.

Condition: good (used), Year of construction: 1972, Slideway grinding machine WMW SFBZ 2200/6000 Manufactured by WMW Germany in 1972 Main technical data: Bwedew U A Rmjpfx Ahmou Table size: 2240x6000 mm Max. grinding width: 2200 mm Max. grinding length: 6000 mm Max. grinding height: 2000 mm Max. workpiece weight: 15000 kg Machine weight: 130 tons The machine underwent a general overhaul in 2022. The feed boxes with electromagnetic couplings were replaced with motors and gearboxes for both heads. The bearings for the universal grinding head were also replaced. For more information, please contact us.

Condition: used, Year of construction: 1961, grinding length 4000 mm grinding width 1100 mm workpiece height 1100 mm weight of the machine ca. 21 t Modernisierte Präzisions-Flach-und Führungsbahnschleifmaschine aus Überholungsbetrieb. Geschliffen wurden unter anderem Betten für neue KERN Drehmaschinen. Bwedpfx Asvk Nlljhmou -Digitalanzeigen nachgerüstet -Umbau auf Kugelrollspindeln in der Querachse -Schleifspindel für Umfangsschliff -schwenkbare Schleifspindel für Untergriffe -Originalschabbild in der Längsachse -Elektrik erneuert -Aufspannfläche 4300 x 1500 mm Bei Nutzung einer Grube können wesentlich höhere Werkstücke geschliffen werden!!!

Condition: ready for operation (used), Year of construction: 2023, operating hours: 7,032 h, spindle speed (max.): 4,000 rpm, travel distance X-axis: 271 mm, travel distance Z-axis: 830 mm, spindle motor power: 25,500 W, overall weight: 5,900 kg, controller manufacturer: SIEMENS, controller model: 840D SLIMline Multi-Touch, number of slots in tool magazine: 12, number of axes: 3, This 3-axis DMG MORI CLX 450 V3 was manufactured in 2023. It features a maximum turning diameter of 400 mm and a turning length of 800 mm, with an X-axis travel of 271 mm and Z-axis travel of 830 mm. The machine includes a 12-position VDI 40 turret and a maximum spindle speed of 4,000 rpm. If you are looking to get high-quality turning capabilities, consider the DMG MORI CLX 450 V3 horizontal turning machine we have for sale. Contact us for further details. • Number of controlled axes: 3 (X, Z, C) • Spindle operating hours: approx. 7,032 hWorking capacity • Max turning diameter: 400 mm • Max turning length: 800 mm • Swing over bed: 700 mm • Swing over cross slide: 500 mmAxes • Rapid traverse X/Z: 30 m/min • Main spindle C-axis • No Y-axis, no counter spindleMain spindle • Spindle nose: A2-8 • Bar capacity: 80 mm • Spindle power: 25.5 kW (40% duty) / 17 kW (continuous) • Spindle torque: 426 Nm (40% duty) / 283 Nm (continuous)Tool turret and driven tools • Turret: 12-position VDI 40 with 6 additional BT stations • Driven tools: max 4,000 rpm, 5.44 kW (40% duty), 20 Nm (40% duty)Tailstock • Tailstock travel: 800 mm • Centre taper: MT5 • Max thrust: 8 kNConstruction • 45° inclined cast-iron bed • Linear guideways Technical Specification Counter Spindle No Bwjdpfx Asz Inc Dohmou Driven Tools Yes

Condition: like new (used), Year of construction: 2019, operating hours: 3,500 h, functionality: fully functional, bar passage: 117 mm, overall weight: 8,500 kg, The Hyundai WIA L400MC is in like-new condition. Inspection under power is possible at any time. Model: Hyundai WIA L400MC Design: Standard Bore Swinging diameter over bed: Ø 780 mm Swinging diameter over slide: Ø 535 mm Max. turning diameter: Ø 560 mm Max. turning length: 1,180 mm Bar capacity: Ø 117 mm Chuck size: Ø 381 mm (15") Max. spindle speed: 2,000 rpm Spindle motor power (max./continuous): 37 / 30 kW Spindle torque (max./continuous): 3,073 / 2,490 Nm Spindle drive: Belt drive with 2-speed gearbox Spindle taper: A2-11 C-axis: 0.001° Travel distances X-axis: 320 mm Z-axis: 1,200 mm Rapid traverse X/Z: 20 / 25 m/min Guideways X/Z: Box guide / Flat guideways Number of tool stations: 12 Tool holder, outer diameter (OD): □ 32 mm Tool holder, inner diameter (ID): Ø 63 mm Turret indexing time: 0.2 s Mount: BMT75P Driven tools Motor power (max./continuous): 7.5 / 5.5 kW Max. speed: 4,000 rpm Torque (max./continuous): 44.7 / 35 Nm Collet size: Ø 26 mm (ER40) Tailstock Tailstock taper: MK5 (integrated) Quill diameter: Ø 150 mm Quill stroke: 132 mm Tailstock travel: 1,100 mm Additional technical data Coolant tank: 300 liters Lubricant tank: 2 liters Bwjdpoz Ibaijfx Ahmou Electrical connection: 46 kVA Recommended cable cross-section: > 50 mm² Voltage / Frequency: 220 V / 60 Hz or 200 V / 50 Hz Footprint (L x W): 4,202 x 2,207 mm Machine height: 2,153 mm Machine weight: approx. 8,500 kg Control: HYUNDAI WIA FANUC i Series / FANUC 32i-B

Condition: good (used), Year of construction: 2004, operating hours: 16,651 h, functionality: fully functional, machine/vehicle number: M342-06204054DFA, travel distance X-axis: 760 mm, travel distance Y-axis: 510 mm, travel distance Z-axis: 610 mm, feed length X-axis: 760 mm, feed length Y-axis: 510 mm, feed length Z-axis: 610 mm, feed rate X-axis: 30 m/min, feed rate Y-axis: 30 m/min, feed rate Z-axis: 20 m/min, nominal power (apparent): 18 kVA, torque: 236 Nm, controller manufacturer: Hurco, controller model: Ultimax 4, workpiece length (max.): 1,020 mm, workpiece width (max.): 510 mm, workpiece height (max.): 610 mm, workpiece weight (max.): 750 kg, total height: 2,700 mm, total length: 280 mm, total width: 2,300 mm, table width: 510 mm, table height: 850 mm, table length: 1,020 mm, table load: 1,000 kg, rotational speed (min.): 10 rpm, rotational speed (max.): 10,000 rpm, overall weight: 4,500 kg, spindle speed (min.): 10 rpm, spindle speed (max.): 10,000 rpm, coolant supply: 6 bar, spindle nose: Steilkegel Gr. 40, number of spindles: 1, number of slots in tool magazine: 24, input voltage: 400 V, type of input current: three-phase, Equipment: chip conveyor, documentation/manual, Excellent condition: Hurco VMX 30 with extremely low operating hours! For sale is a very well-maintained, vertical 3-axis machining center, a Hurco VMX 30, manufactured in 2004. The machine is in exceptionally good condition for its age. As can be easily seen from the operating hours, the machine has only been used very little by us. It was used exclusively for light-duty operation/toolmaking and was not subjected to heavy series production. The mechanical components (guideways, ball screws, and spindle) are correspondingly only slightly worn and offer high precision. The machine is equipped with the popular Ultimax 4 dual-screen control system, which is highly regarded worldwide for its extremely fast and easy dialog programming directly on the machine. Bwsdpfjzudd Tsx Ahmsu

Condition: excellent (used), Year of construction: 2017, operating hours: 2,742 h, functionality: fully functional, machine/vehicle number: MV0061-000661, travel distance X-axis: 762 mm, travel distance Y-axis: 516 mm, travel distance Z-axis: 570 mm, controller manufacturer: Fanuc, workpiece length (max.): 800 mm, workpiece width (max.): 550 mm, workpiece height (max.): 460 mm, total height: 2,580 mm, total length: 3,260 mm, total width: 3,130 mm, table width: 570 mm, table height: 880 mm, table length: 860 mm, overall weight: 9,200 kg, distance table center to spindle nose: 720 mm, spindle motor power: 15,000 W, number of slots in tool magazine: 30, input voltage: 380 V, type of input current: AC, Equipment: chip conveyor, documentation/manual, Doosan VC 510 (2017) – Vertical Machining Center with APC High-productivity 40-taper vertical machining center featuring a heavy-duty column-moving design and an integrated 2-pallet automatic pallet changer (APC). Key Specifications: Year: 2017 Control: Fanuc Travels (X / Y / Z): 762 × 516 × 570 mm Pallet Size (×2): 860 × 570 mm (Rotary APC, ~6 sec swap) Max Workpiece Size: 800 × 550 × 460 mm Max Table Load: 350 kg per pallet Spindle Motor (kW): 15(30min)/11(CONT.) Bwjdpez Atqrefx Ahmeu Max. Torque (Nm): 191.1(30min) Tool Changer (ATC): 30 Tools Rapid Traverse (X/Y/Z): 40 / 40 / 32 m/min Guideways: Heavy-duty Roller LM Guides Machine Weight: ~9,200 kg Excellent condition, fully maintained, and built for continuous high-speed production. Contact for inspection and further details.

Condition: used, Year of construction: 1999, functionality: fully functional, machine/vehicle number: 9909220, travel distance X-axis: 1,016 mm, travel distance Y-axis: 508 mm, travel distance Z-axis: 508 mm, controller manufacturer: FADAL, workpiece weight (max.): 800 kg, total height: 2,200 mm, total length: 2,900 mm, total width: 2,400 mm, table width: 508 mm, table length: 1,220 mm, overall weight: 4,800 kg, number of spindles: 1, number of slots in tool magazine: 21, input voltage: 230 V, type of input current: three-phase, Equipment: documentation/manual, For sale: a reliable American CNC milling machine. This machine is from the renowned HT series – the most powerful and sought-after Fadal version. It features dovetail guideways, is rigid, heavy-duty, and designed for machining steel. The machine is in working order and can be inspected while powered on in Środa Wielkopolska. Bsdpfx Aeztcz Iehmswu

Condition: used, Year of construction: 2022, operating hours: 2,000 h, functionality: fully functional, machine/vehicle number: 3232, working width: 1,500 mm, working length: 6,000 mm, travel distance X-axis: 6,000 mm, travel distance Y-axis: 1,500 mm, For sale is a MicroStep CNC cutting system from the MG series, model MG 6001.15PrkGB+CH500P, manufactured in 2022, with approximately 2,000 operating hours. Equipment: - Plasma rotator for weld preparation with Kjellberg Q 3000 plasma power source - Fully automatic oxy-fuel support - Fully automatic drilling spindle MG-40-P26 with 26.8 kW - Pipe cutting device RSV 30-300 - Filter system TEKA ZPF 6H with 11 kW Technical data: Working area approx. 6,000 x 1,500 mm + 500 mm clearance Max. travel height approx. 150 mm Max. table load approx. 100 mm Bodpfxsz A Tk No Ahmjwu Guideways in the X-axis: Linear guideways with helical gear racks Drives: Digital, maintenance-free AC servo motors with IRC Positioning speed up to 40,000 mm/min. Positioning accuracy ≤ 0.06 mm/m Bidirectional repeatability 0.05 mm/m Inspection: An inspection is possible at the location in Wörth a. d. Isar. Interested? The machine is offered in an online auction. Further information and documents are available upon request. Simply contact us!

Condition: excellent (used), Year of construction: 1992, functionality: fully functional, DECKEL FP 4 MK Year of manufacture: 1992, with TNC 113 active digital control with positional programming Spindle speeds: 50 - 2500 rpm Bodpfjzxwz Tjx Ahmewu Travel ranges: X 500, Y 400, Z 400 Feed rate: stepless + rapid traverse Hydraulic tool clamping system SK 40 Hydraulic machine vice Allmatic 125 Universal table Central lubrication, electric, lighting, machine feet, coolant system. Condition: original, not repainted Smooth and quiet operation at all spindle speeds Guideways and axis movements are in perfect condition. Weight approx. 1500 kg Can be inspected while powered on. Free loading D - 88433 Schemmerhofen

Condition: good (used), Year of construction: 1996, functionality: fully functional, machine/vehicle number: VM0429, turning diameter over cross slide: 196 mm, spindle bore: 42 mm, turning diameter over bed slide: 350 mm, center height: 170 mm, turning length: 650 mm, quill stroke: 140 mm, total length: 1,900 mm, total width: 1,100 mm, total height: 1,300 mm, spindle speed (max.): 3,250 rpm, spindle speed (min.): 20 rpm, metric thread steps: 51, type of input current: three-phase, overall weight: 1,350 kg, quill mount: MK 4, Equipment: rotational speed infinitely variable, Lead and feed screw lathe with digital display Colchester Master VS 3250 Digital display, 3 axes, Heidenhain Center height: 170 mm Distance between centers: 650 mm Swinging diameter over bed: 350 mm Swinging diameter over cross slide: 196 mm Bjdpfjzp Nknex Ahmewu Spindle speed, stepless, from 20-3250 RPM (3 gear stages) Year of manufacture: 1996 Spindle bore: 42 mm Spindle mounting D1 4“ Camlock Tailstock taper MK 4 Tailstock quill travel: 140 mm Coolant pump Central lubrication of guideways Electromagnetic spindle brake Halogen lamp Longitudinal feeds from 0.036 to 1.2 mm/revolution Cross feed: half of the longitudinal values 51 metric thread pitches from 0.2 to 14 mm 56 Whitworth thread pitches from 2 to 56 threads/inch 20 module thread pitches from 0.2 to 3.5 module 20 diametral pitch thread pitches from 8 to 56 D.P. Operating manual and spare parts list, English Weight: 1350 kg L x W x H: 1900 x 1100 x 1300 mm Motor: 7.5 KW Including accessories: 3-jaw chuck, brand Pratt Burnerd 4-jaw chuck, Ø 200, brand Bison Quick-change collet chuck with lever 15 pcs. collets, Ø 1/1.5/2/3/4/5/6/7/8/9/10/12/13/14/15 mm 16 sets of soft jaws for 4-jaw chuck Quick-change tool holder Multifix with 5 tool holders incl. facing tool, cutoff tool, and internal turning tool 1 pcs. center punch 1 pcs. drill chuck, Ø 1 to 13 mm

Condition: good (used), Year of construction: 2017, functionality: fully functional, machine/vehicle number: 4480, total length: 14,500 mm, total width: 7,800 mm, total height: 3,500 mm, overall weight: 20,000 kg, Reichenbacher Machining Center VISION III-TT-L – 5-Axis, 3-Axis, MBG8, 5x SNA Equipment: 5-Axis Unit with Cardanically Mounted Spindle: Max. speed: 24,000 rpm Nominal speed: 10,000 rpm Power in S1*: 15 kW Max. power in S6: 20 kW Torque in S1*: 14.5 Nm Torque in S6: 19 Nm Nominal voltage: 380 V Nominal current: 37 A Nominal frequency: 380 Hz Speed freely programmable from 0 – 24,000 rpm, in 1 rpm increments Clockwise/counterclockwise rotation selectable via program Driven by frequency inverter Maintenance-free Water-cooled Hybrid bearings Automatic spindle stop in case of emergency stop Orientated stop for thread cutting Tool holder: HSK-F63 hollow shaft taper according to DIN 69893-6 Max. tool length usable from spindle nose: 240 mm Max. tool weight: 6 kg 3-Axis Unit with Vertically Mounted Spindle: Max. speed: 24,000 rpm Nominal speed: 10,000 rpm Power in S1*: 15 kW Max. power in S6: 20 kW Torque in S1*: 14.5 Nm Torque in S6: 19 Nm Nominal voltage: 380 V Nominal current: 37 A Nominal frequency: 380 Hz Speed freely programmable from 0 – 24,000 rpm, in 1 rpm increments Clockwise/counterclockwise rotation selectable via program Driven by frequency inverter Maintenance-free Water-cooled Hybrid bearings Bwedpsywzq Sjfx Ahmeu Automatic spindle stop in case of emergency stop Orientated stop for thread cutting Tool holder: HSK-F63 hollow shaft taper according to DIN 69893-6 Max. tool length usable from spindle nose: 240 mm Max. tool weight: 6 kg 8-Spindle Drilling Unit (1 unit): L-Shape, Grotefeld Drill spindles: individually selectable Rotation direction: clockwise/counterclockwise Pitch: 32 mm Power: 2.5 kW Speed: 5,000 rpm fixed Z-axis stroke: +75 mm Holder: D = 10 mm H7 Plunge stroke: 80 mm Grooving Unit (5 units): GROTEFELD Angle Saw Unit F100-S The working/milling stroke is pneumatic. Drive: three-phase motor with multi-ribbed belt LEFT version Drive rotation direction: clockwise/counterclockwise Speed reduction: 1:2.86 – belt drive Power: 2.20 kW – 220-240/380-415 V – 50 Hz Speed: n1 = 2,800 rpm, n2 = 8,011 rpm at 50 Hz Spindle power: 2.2 kW Feed: 150 mm Tool holder: Ø30 x 1.5 mm – 5.0 mm Tool holder rotation: opposite to drive rotation direction Feed force: 2565 N Underfloor Drilling Unit in Machine Bed (1 unit): GROTEFELD Angle Milling Head G06-1.1-P The working/drilling stroke is pneumatic. Drive motor: 1.1 kW 220-240/380-415 V 50-100 Hz Drive rotation direction: clockwise Speed reduction: 1:1.55 gear drive Drive speed: 2,800 – 5,600 rpm Tool spindle speed: 4,340 – 8,680 rpm Tool holder: 1x HI-Q/ERM25 DIN6499-C (8°) For ER25 collet DIN 6499-B Ø0.5–16 mm max. Tool holder rotation direction: clockwise Flange clamping piece: FK45 Feed slide: with pneumatic cylinder and double steel guideways Feed: 80 mm

Year of construction: 2009, operating hours: 1,629 h, condition: excellent (used), functionality: fully functional, Technical Description – Wintersteiger DSG Sonic Main Features: - Designed for thin-cutting of boards and panels in lamella/parquet production. - High-precision blade guidance without tolerances (no "play"), ensuring improved cutting accuracy. - Symmetrical saw frame construction provides uniform blade tensioning. - Revolutionary drive concept with servo-controlled precision feed. - High stroke frequency of the saw frame: 550 strokes/minute. - Modular and ergonomic design: split construction for easy access and simple maintenance. DSG Sonic — Maximum element cutting height: - For 380 mm saw: cutting height 30–88 mm (or 45–88 mm, depending on configuration) - For 420 mm saw: cutting height 30–128 mm (or 45–128 mm) Bwodjx Avzyjpfx Ahmeu - For 500 mm saw: cutting height 80–210 mm (or 45–210 mm) - For 550 mm saw: cutting height 80–254 mm (or 45–254 mm) Machine specifications and requirements: - Machine weight (basic unit): approx. 3,000 kg - Dust extraction/exhaust: two connections required — Ø 120 mm and Ø 150 mm; extraction capacity: approx. 3,200 m³/h (air velocity ~ 30 m/s). - Compressed air pressure: minimum 6 bar; air consumption: approx. 200 l/min. - Lubrication: central lubrication system with guideway monitoring. - Machine year: 2009 - Operating hours: 1,629 - Condition: very well maintained.

Condition: excellent (used), Year of construction: 2019, operating hours: 7,000 h, functionality: fully functional, MACHINE CONSTRUCTION: - Cast iron bed, spindle head, and saddle system developed through computer-aided design and analysis (CAD/CAE), ensuring high rigidity and vibration damping - Fully supported table guide in every working position - X-axis (table movement) on 2 precision cylindrical roller guides, supported by 6 runner blocks each - Y-axis with 2 precision cylindrical roller guides - Z-axis with hardened and ground guideways, with TURCITE-B coating - Guideway protection via metal telescopic covers - Hydraulic counterweight / balance system - CE conformity Axes: - Preloaded ballscrews with large pitch for long-lasting precision - Digitally controlled, liquid-cooled ballscrew on the X-axis - Gear-driven ballscrews, ballscrew nuts with centralized lubrication, and lifetime-lubricated bearings CONTROLLER & ELECTRONICS + CAPACITY: - High-speed CNC, 1 ms block processing time - Storage capacity: 120 GB SSD - Technology program memory: 100 GB SSD - Number of processor cores: 4 CNC operating system: - User interface operating system: Windows 10 - Technology program storage: WINDOWS file system - Total storage capacity (system program, PLC, parameters, technology program memory) on a single SSD - New user interface (40-00005216-00w) Bsdpfxozzf Ruj Ahmswu SCREEN: Color graphical LCD touchscreen COMMUNICATION: USB, Ethernet, EtherCAT MEASURING SYSTEM: - HEIDENHAIN absolute EnDat 2.2 - PROGRAMMING: ISO, myNCT TECHNICAL DATA: - X-travel: 2100 mm - Y-travel: 1500 mm - Z-travel: 1000 mm Distance from spindle nose to table surface: 200~1000 mm Distance between columns: 1650 mm Distance between table and gantry/crossrail: 1710 mm AXES: - Rapid traverse speed X / Y / Z axis: 20 / 20 / 15 m/min - Max. working speed: 10 m/min - Motor power: 4 kW ACCURACY (according to JIS6338): - Positioning accuracy: +/- 0.01 mm (In the entire working area!) - Repeatability: +/- 0.004 mm TOOLING: - Max. tool diameter / with adjacent tool omitted: 125 / 215 mm - Max. tool length: 400 mm - Max. tool weight: 20 kg - Optional tool taper: SK50 Accessories & Equipment: - Angle head (manual) - Chip conveyor - Coolant flush gun - 15 pcs of SK50 tool holders - Machine leveling feet - Manuals The machine is in good used condition and operates accurately.

Condition: used, Year of construction: 2011, functionality: fully functional, machine/vehicle number: p1276453, measuring range X-axis: 1,200 mm, measuring range Y-axis: 700 mm, measuring range Z-axis: 600 mm, workpiece weight (max.): 650 kg, total height: 2,650 mm, type of input current: AC, total width: 1,271 mm, total length: 2,081 mm, travel distance X-axis: 1,200 mm, travel distance Y-axis: 700 mm, travel distance Z-axis: 600 mm, overall weight: 1,750 kg, input voltage: 220 V, table height: 800 mm, compressed air connection: 6 bar, year of last overhaul: 2025, ambient temperature (max.): 20 °C, Equipment: documentation/manual, type plate available, Measuring volume: 1200x700x600 mm, measuring accuracy: MPEe = (2.2 + U350) µm, MPEp = 2.5 µm. Includes a base frame with integrated dual passive vibration damping, highly precise granite guideways, bellows covers. Automatic rotary swivel head RTP20 from Renishaw, with TP20 probe. Probe changer magazine MCR202. Probe module TP20 Standardforce (Serial No.: MCR20 39E429, TP20StdF 49F352, TP20 StdF: 11C613). Measuring software ThomControl. Bwodozl Ebhepfx Ahmsu TERRA PC Business 7000 i7. One-hand joystick MCU-Lite from Renishaw. CNC control UCC-T3 PLUS.

Condition: used, Year of construction: 2006, functionality: fully functional, Equipment: rotational speed infinitely variable, Manufacturer: 600 Lathes Model: Harrison V350 Centre Height: 170 mm Swing over Bed: 350 mm Swing over Cross Slide: 196 mm Swing in Gap: 535 mm Width in front of Face Plate: 165 mm Distance between Centres: 650 mm Spindle Speeds (stepless via potentiometer across 3 ranges, with digital readout): 15 - 340 rpm 45 - 1010 rpm 150 - 3250 rpm Spindle Mount (Camlock): D1-4 Spindle Bore: 54 mm Spindle Motor: 7.5 kW Carriage Guideway Width: 318 mm Cross Slide Travel: 250 mm Top Slide Travel: 140 mm Tailstock Quill Travel: 140 mm Tailstock Quill Taper: MT4 Quill Diameter: 63 mm Metric Version Machine Threads: Metric: 0.2 - 14 mm (51) Imperial TPI: 2 - 56 (56) Module: 0.2 - 3.5 (20) Diametral Pitch: 8 - 56 (20) Drive Power: 7.5 kW Equipment: 3-Axis Digital Readout 3-jaw Chuck Röhm D:200 mm 4-jaw Chuck D:160 mm Collet Chuck System Steady Rest 4-position Quick Change Toolpost Live Centre Chuck Guard Additional Chip Shield on Carriage Coolant System Rear Splash Guard Machine Documentation incl. Schematics Dimensions: Floor to Spindle Centre: 1050 mm Overall Length: 1900 mm Bwjdpfx Asxcuulehmeu Overall Width: 1100 mm Overall Height: 1300 mm Weight: 1350 kg The machine can be demonstrated under power on site by arrangement. All details without guarantee. Errors and prior sale reserved.

Condition: used, Guide rail and surface grinding machine WMW FRITZ HECKERT Aschersleben Type SZ 1000 x 1250 x 3000 / 344 Manufacturer's No. 13.2236.2 Year of manufacture 1989 Nominal grinding area 3000 x 1250 mm Table clamping surface 3240 x 1000 mm Grinding length max. 3300 mm Processing width 1250 mm Processing height 1250 mm Grinding wheel diameter (surface grinding support) max. 600 mm Grinding wheel width (surface grinding support) max. 100 mm Grinding wheel diameter (swiveling support) max. 450 mm Bsdpshv A A Dofx Ahmjwu Mains connection 400 Volt, 50 Hz - Swiveling grinding support, motor power 16.5 kW, infinitely variable speed - Grinding support for surface grinding, motor power 15 kW, infinitely variable speed - New electrical control system, based on SIEMENS S7, year of manufacture 2001 - New electrical control cabinet located nearby, year of manufacture 2001 - Infinitely variable grinding wheel speed on both grinding supports - Swiveling grinding spindle for guide rail and profile grinding - Control panel swiveling and height-adjustable - Coolant system located nearby - Hydraulic system located nearby - Oil circulation lubrication system located nearby - Various grinding wheels and arbors Space requirement (complete) L x W x H 11900 x 7700 x 4600 mm Weight 45 tons Very good condition

Condition: excellent (used), Year of construction: 2024, Wood-Mizer CNC5003 CNC Machining Center – practically unused Key data • Category: CNC machining centers / CNC routers for wood (nesting) • Year of manufacture: [2024] • Condition: practically unused, demo / showroom unit • Location: [KOŁO], Poland • Availability: 2 units in identical specification — discount available if both are taken • Sold directly by the manufacturer, no intermediaries Description An industrial-grade CNC machining center at a mid-range machine price. Why this machine is worth considering • Only premium, branded components — no generic parts: FANUC, HSD, HIWIN, ATLANTA, FESTO, BECKER. Each of these components is serviceable and supported worldwide, independently of us as the machine builder. • FANUC control — the world's most widely used CNC platform, standard ISO G/M code, ready to interface with any CAM system. Support, training, and service are available from any authorized FANUC partner or CNC integrator. • Gantry design with dual drive — high stability and accuracy, high-resolution digital servos, low vibration. • 3095 × 1535 mm working area accommodates a full 3050 × 1530 mm panel — an entire sheet is machined in one setup, with no pre-cutting and no repositioning. • 6-zone vacuum nesting table with 216 vacuum points — exceptional flexibility in work-holding: panels, irregular parts, and porous materials. • The machine is on-site and available for inspection and a test cut before purchase, along with the available technical documentation. Technical data Specification Value Actual working area X / Y 3095 × 1535 mm (max. raster table area) Z-axis travel 200 mm Rapid traverse X / Y / Z 60 / 30 / 15 m/min Spindle HSD 11 kW, HSK63F, 24,000 rpm, inverter-driven, ceramic bearings Tool changer ATC — 12-position carousel on the gantry, service access hatch Drives and guideways ball screw, linear guides, and carriages by HIWIN; rack and pinion by ATLANTA Control FANUC, ISO G/M code, PC and CAM interface, built-in server Table grey extruded polypropylene raster table; 6 zones × 36 points = 216 individual vacuum points, each zone with its own valve Vacuum pump BECKER, 126 m³/h, 4 / 5.5 kW, max. vacuum 0.9 bar Pneumatics FESTO Chip extraction articulated extraction hood Control panel movable, on wheels — access from 3 sides of the table; local operation or via network Frame size (footprint) 1570 × 4150 mm Total length / width / height 4460 / 3000 / 2400 mm Bwjdpfx Aeyr Dawjhmeu Materials: wood, sheet materials, plastics, foam, composites, light alloys (aluminum). Terms of sale — stated openly • Sold as-is, without a manufacturer's warranty and without service support from our side — our CNC project has been discontinued. This is the only reason for this price. • Service and wear parts are available directly from the component manufacturers (FANUC, HSD, HIWIN, BECKER, FESTO) and from independent CNC integrators. • Inspection and a test run on-site are welcome — bring your own material and file. • Net price, EXW [KOŁO]. Loading is our responsibility; transport and unloading are the buyer's responsibility. Intra-community supply (0% VAT) for EU buyers with a valid VAT ID. • We can connect you with companies offering commissioning and operator training (third-party service, priced separately).

Condition: used, Year of construction: 2017, functionality: fully functional, machine/vehicle number: P17XZG 044, Technical characteristics: # Machining workspace: X 500 mm; Y 400 mm; Z 330 mm # Axis description: 3 LINEAR AXES (X, Y, Z) + 1 rotary table axis A (indexing divider head) with direct angular measuring system, max. rotational speed 50 rpm, precision +/- 5 seconds # Axis A swivel range: +/-170˚ # Maximum clamping/workpiece dimensions: 650 x 400 mm; max. weight 300 kg # Rapid traverse speed (X/Y/Z): 54 m/min # Spindle speed: 100–10,000 rpm; spindle motor power: 11 kW # Spindle interface: BBT30 (with through-spindle coolant) # Automatic tool changer: 1x21 tools / chip-to-chip average time 1.5 sec # Maximum tool size: Ø40 mm / length max. 200 mm / 2 kg Electrical connection: # Voltage: 3x400V/50Hz # Installed power: approx. 20 kVA / 22A Dimensions: # Installation space: approx. 1.65 x 3.2 (with chip conveyor) x 2.8 m # Weight: approx. 8,500 kg Equipment includes: # This 4-axis FANUC Robodrill α-D21LiB5 was manufactured in 2016. Ideally suited for precision machining, this vertical machining center delivers robust performance and high reliability. # CNC control: FANUC Series 31i-B5 # 4th axis and tailstock: FANUC DDR-TiB 178DU039 (2017/08) and TSUDAKOMA tailstock # Chip conveyor & high-pressure coolant filtration unit (max. 40 bar): Mosnic model 1641/2010 Bwodsxxrb Iopfx Ahmsu # Spindle cooling system, guideways and control cabinet cooling # Oil mist extraction/recovery system: Bristol model B 1000 EF # Fire suppression system: Kraft & Bauer # Part presence detection: with low-pressure air sensors # Automation: automatic side door and interface, automation-ready # In-process control: Renishaw TRS2 # Documentation: incomplete Machine status: WORKING

Condition: used, Year of construction: 1991, Used Machine Year of manufacture: 1991 Condition: overhauled; photos show the machine as it was when acquired. Features and Technical Specifications: - Designed for all window tooling systems with tool diameters up to 400 mm - Thanks to the standard braking systems (foot brake for the slotted spindle, automatic electronic safety brake for the saw), the machine can be brought to a stop in just a few seconds Bwsdpozk Npysfx Ahmeu - The protective covers for the slotted spindle and crosscut saw are designed so that the tools can be easily and conveniently without having to remove the guards themselves - The crosscut saw can be conveniently adjusted from the workstation using a quick-adjustment mechanism. A six-position turret allows for quick adjustment to various dimensions - The height of the 40 mm slotted spindle can be precisely adjusted using an ergonomically positioned handwheel with 0.1 mm graduations - The sturdy roller table, in combination with hardened and ground guideways, can be easily moved with minimal effort - Slotted spindle motor: 5.5 kW - Slotted spindle speeds: 3000/4500 rpm - Spindle diameter: 40 mm - Clamping length: 140 mm - Slotted spindle height adjustment: 100 mm - Exhaust port: 120 mm - Crosscut saw motor: 2.2 kW - Cutting-off saw speed: 2,950 rpm - Saw blade shank: 30 mm - Max. saw blade diameter: 400 mm - Max. cutting height: 125 mm - Pneumatic tool clamping - With Festo LAS stop Weight: approx. 600 kg Current photos coming soon! Availability: available shortly Location: Röllbach
