Used Hexagon Measuring Machine for sale (67,484)

Condition: ready for operation (used), functionality: fully functional, repeat accuracy: 0.002 mm, table load: 50 kg, rotary table diameter: 500 mm, The offer consists of the following components: VL-770 Probe Head – High-resolution optical 3D scanner VL-700 Control Unit – Control and evaluation unit, including software interface VL-C35 Cover – Light protection hood VL-A3D Software Package – Measurement and evaluation software (German) OP-88145 Calibration Plate – Reference plate VL-H3G Module – Geometric dimensioning and tolerancing (GD&T) module VL-H3R Module – CAD conversion module VL-B1 Accessory – Calibration ball gauge OP-99031 Cable – AC power cable TECHNICAL DETAILS Repeatability (σ): 2 µm Measurement accuracy: ±10 µm Measurement resolution: 9 million measurement points Measuring range Low magnification: Ø300 × H200 mm High magnification: Ø70 × H50 mm Ncodpsy Eglqefx Akyjr Work Table Rotary table: 500 mm Rotation mechanism: 360° XY movement of object stage: Ø200 mm Tilting mechanism: up to 45° Maximum load capacity: 50 kg MACHINE DETAILS Weight Weight of control unit: 3.7 kg Weight of object table: 26 kg Weight of cover: 5.5 kg Weight of measuring unit: 19.6 kg EQUIPMENT Original software and manuals Calibration plate Protective hood Monitor, PC, keyboard, and accessories

Condition: good (used), Year of construction: 2006, voltage 110 - 230 V frequency 50 - 60 Hz Power connection 0,5 kVA weight 150 kg dimensions of the machine ca. 1,0 x 0,8 x 1,75 m Stick blade profile control unit - Control via PC control with Windows XP operating system Nedpfx Akeymfz Sjyecr - Digital drive amplifiers, linear motors and measuring systems - Fully automatic position determination of the cutting edges and axis position of the stick blade - Measurement of almost all single-part and continuous processes required for spiral bevel gears and hypoid gears - Machine concept designed for the shortest set-up and changeover lines and maximum measuring accuracy - Combination probe for measuring tip and surface measurement - Integrated drawer for accessories - Keyboard integrated in flat drawer - Operating elements and PC protected against unauthorized access with lockable cabinet element

Condition: used, Year of construction: 2002, Universal coordinate measuring / milling machine Ncodpfx Akjwtq Iloyjr

Condition: excellent (used), Year of construction: 1999, functionality: fully functional, measuring range X-axis: 700 mm, measuring range Y-axis: 900 mm, measuring range Z-axis: 500 mm, Zeiss CNC coordinate measuring machine Prismo MP5 Year of manufacture: 8/1999 Last calibration: 9/2023 Measuring range: X = 700 mm, Y = 900 mm, Z = 500 mm Features, Equipment: C98 control system with control panel RDS sensor system with RST 5-way probe change magazine RST 5x probe system Reference probe Probe accessories Ncsdpfxjufgbno Akyjr Calibration sphere Computer with monitor Calypso Basic 5.4 software Loading system Further accessories and options available Complete retrofit of the C99 and the current Calypso version possible Available at short notice

Condition: excellent (used), The probe was used on a Zeiss Prismo Ultra as a replacement probe with few operating hours. Njdpfxjy Epm Io Akyecr

Condition: excellent (used), Year of construction: 2007, functionality: fully functional, measuring range X-axis: 1,000 mm, measuring range Y-axis: 3,000 mm, measuring range Z-axis: 800 mm, Measuring Range X Axis: 1,000 mm Y Axis: 3,000 mm Z Axis: 800 mm Granite Guides Air-bearing Axes Measuring Accuracy Linear measurement deviation approx. 1.3 µm plus L/400 depending on configuration and calibration status Probing Systems Renishaw probe heads possible Touch trigger and scanning PH10, TP20, SP25, SP80 depending on equipment Ncsdpfx Aksy Ewgxeysr Workpiece Weight Permissible table load up to approx. 2,000 kg depending on configuration Control CNC control with handheld operating unit Software Metrosoft CM version 3.112 WENZEL Quartis R16 Electrical Supply 230 V 50/60 Hz Power consumption approx. 1 kVA Pneumatic Supply Compressed air 6 to 10 bar filtered and dry

Year of construction: 2021, condition: as good as new (ex-display), functionality: fully functional, Single-head cutting machine OMC GIOBI 600 with measuring roller conveyor FOM INDUSTRIE ASSOMAK VS 6m and inlet conveyor PORTER 4,2m Year 2021 Condition: ex-demo, like new - Saw blade D 600 mm - Hdro-pneumatic feed - Inclination is pneumatic on both sides, with fixed graduations of 22.5° - 45° - 90°. For intermediate gradations, with manual mechanical stop Ncodpfjy Erwfjx Akyor - 2 vertical and 2 horisontal clamps - Spray mist blade lubrication system - Integral pneumatic protection - ASSOMAK VS 6m: measuring roller conveyor with digital display and manual length stop positioning - Minimum cut 0 mm - Maximum cut 6000 mm - Measurement reading by encoder - Positioning precision ± 0,5 mm - Loading capacity per linear meter: 10 Kg - Width of bar resting surface: 200 mm - PORTER 4,2m: inlet roller conveyor - Loading capacity per linear meter: 10 Kg - Width of bar resting surface: 200 mm

Condition: like new (used), Year of construction: 2014, functionality: fully functional, measuring range X-axis: 1,000 mm, measuring range Y-axis: 2,000 mm, measuring range Z-axis: 800 mm, Aberlink Coordinate Measuring Machine Zenith II Measuring ranges: 1000 x 2000 x 800 mm Nsdpfx Akoy Hcb Rsyscr Measurement uncertainty: 3.8 +4L/1000 Renishaw PH10M probe with TP200 and SCR200 changer Optional camera unit, manually changeable (+ €3,500) Aberlink 3D measurement software, latest version, Win 10 PC Optionally available with CMM Manager software Installation and training available on request

Condition: used, Year of construction: 2003, Coordinate Measuring Machine Wenzel LH 54 (Year of Manufacture 2003) in well-maintained and fully functional condition. The machine is built on a stable granite structure combined with air-bearing guides. This allows the portal and axes to move almost frictionlessly and smoothly over the granite—a proven foundation for high measurement accuracy and repeatability. The LH 54 is designed for reliable use in quality assurance as well as in series production and delivers consistent measurement results even during continuous operation. Before delivery, the machine is inspected and test-run by our service technicians in Remscheid, ensuring full functionality. The system is currently powered on and can be viewed and demonstrated at any time. PC System (modernized): After purchase, a completely new PC system will be installed, meeting WENZEL’s current requirements. This system is fully up to date and thoroughly tested before the machine is finally handed over to the buyer. Optional Services (upon agreement): Nedsy Dcivopfx Akyocr - Installation and commissioning of the measuring machine within NRW - Issuance of a factory calibration certificate - Determination of length measurement uncertainty - Determination of probing uncertainty - Determination of repeatability range - Execution in accordance with DIN EN ISO 10360-2:2010-06 - Maximum measuring volume diagonal: 4,660 mm - Determination of probing uncertainty according to DIN EN ISO 10360-5:2020-11 - Including full documentation - DAkkS calibration by the accredited Klostermann calibration laboratory - Accreditation number: D-K-17518-01-00 - Accredited according to DIN EN ISO/IEC 17025:2018 - Training for the WM | Quartis measuring software - Custom programming for your components Additional Information: On request, the machine can be retrofitted with the proven Renishaw SP25M probe. The retrofit includes additional service work and complementary hardware components, which will adjust the purchase price accordingly. Additional software modules, custom adaptations, as well as individual accessories and clamping systems are available on request—optimally tailored to your specific measurement requirements. Measuring range X: 500 mm Measuring range Y: 1.000 mm Measuring range Z: 400 mm Measurement uncertainty: Eo = 2,5 + L/300 [μm] Installed software: WM | Quartis R2026-1 Controller: WPC2040 Basic PC System: Windows 11 (current configuration) Probing system: TP20 Probe head: PH10T Probe module: 1 × TP20 Standard Force Module head interface: PHC10-3 PLUS Probe interface: PI200 (Combi) Joystick: HT400 Exchange bridge: MCR20 (empty) Accessories: Stylus kit M2 | Mouse & keyboard | 2 × 24" TFT monitors | Printer Included services: Final inspection upon purchase | Disassembly and transport preparation | Packing | Loading onto customer-provided truck Included transport frame: On loan

Year of construction: 2002, condition: used, z-travel 200 mm Clamping diameter of the cutter heads max. 550 mm Max. permissible cutter head weight 150 kg Mounting plate diameter for cutter heads 360 mm Mounting cone for cutter heads Nominal diameter 500 mm weight of the machine ca. 2,3 t dimensions of the machine ca. 2 x 1,5 x 2,03 m Cutter Head Set-Up- and -Measuring Machine In the manufacturing process for spiral-toothed bevel gears, the quality of the gear cutting gear cutting tools used plays a decisive role. Particularly in dry milling, high gear cutting quality and a long service life can only be achieved with precisely adjusted cutterheads. The Oerlikon cutterhead setting and testing device CS 200 enables quick and easy setting of the individual knives and simple adjustment of the individual knives, it checks the position and documents the measurement results. The measuring sequence on the CNC-controlled testing device is partially automated: The individual actions for carrying out the actions for carrying out the sequence are displayed on the screen via the operator guidance. The positioning of the individual knives in the cutter head and the height of the knife tips is largely automatic thanks to a special sequence and is simultaneously documented by means of a run-out diagram. A subsequent measuring sequence checks the radial position of the inner and outer cutting edges of all knives in the cutterhead. If individual test parameters on the knives do not correspond to the the tolerance specifications, this can be individually repositioned. The Ncedsy A S U Sspfx Akyor combination of semi-automated setting sequence, operator-guided set-up actions and automatic operator-guided set-up actions and automatic measuring sequence, cutterheads can be can be set conveniently, quickly and with high precision. Operator-guided setting and test sequence - Graphic display of the cutter head design and the measurement results with tolerance check - Instructions for the operator in plain text Instructions for the operator in plain text (without coded information) - Simple assignment of the measurement results to the knives - Documentation of the setting and measurement results via printer- Setting and test sequence suitable for ARCON®, RSR, Spirapid, SPIRON®, TRI-AC® types - Interface for neutral data

Condition: used, Year of construction: 2006, voltage 110 - 230 V frequency range 50 - 60 Hz Power connection 0,5 kVA Dimensions (HxWxD) 1000 x 800 x 1750 mm weight 150 kg Measuring machine for bar knives. Equipment/accessories: -Measuring tools -Clamping devices -Computer -Monitor -Printer Ncsdpsyhq T Asfx Akyjr -Cabin -Technical documentation

Condition: used, Year of construction: 2011, length 300 mm centre height ca. 30 mm diameter 0,5 - 52 mm weight of the machine ca. 0,103 t dimensions of the machine ca. H 0,84 x L 1,00 x P 0,435 m Serviced and calibrated by Studenroth on 24.07.2024 Length and diameter measuring device: Ncedpfxjwmwwao Akyor Equipment/accessories: -Software -monitor and computer -Technical documentation

Condition: excellent (used), Year of construction: 2008, functionality: not functional, Faro Gage Plus measuring arm with 6 axes Arm length: 4 ft (approx. 1.2 m) Accuracy: 5+8L/1000µm Includes measuring table, accessories, and corresponding transport case User manual and manuals included No software included!!! Ncsdpoy A Tgpjfx Akyer

Condition: used, Year of construction: 2023, controller manufacturer: Sonstige, controller model: MCOSMOS, _____ Description: Year of manuf. : 2023 Control : Sonstige MCOSMOS Movement X/Y/Z : mm Technical Data: Measuringrange in X/Y/Z:500 x 500 x 500 mm Tablesize:755 x 730 mm Workpieceweight (max.):120 kg Equipment/Accessory: Njdpfx Aoy Ea Hzskyecr Probesystem:Renishaw PH 10MQ Measuringhead:Renishaw SP25M Scanningmodul:Renishaw SM25 Changesystem:Renishaw FCR25 Operation:Joystickbox-M Further Accessory:Misc. stylus, calibration sphere, clampingsystems

Condition: ready for operation (used), X-axis: 505mm, y-axis: 405mm, z-axis: 405mm, number of M8 threaded holes: 9, max. workpiece height: 545mm, max. table load: 180kg, accuracy: ISO 10360-2, resolution: 0.1µm, guide system: air bearings on all axes, traverse speed CNC mode: 8-300mm/s (max. 520mm/s), joystick rapid traverse: max. 80mm/s, slow: 0.05mm/s, measuring speed: 1-8mm/s (CNC), acceleration: 0.13g (max. 0.23g), measuring table material: granite, table dimensions: 638x860mm, compressed air consumption: approx. 50l/min at 0.4MPa, length: 1122mm, width: 1082mm, height: 2185mm, weight (incl. table and control): 515kg. An on-site inspection is possible. Ncsdpsy Duq Eefx Akyjr

Condition: good (used), total height: 1,360 mm, total width: 1,100 mm, total length: 1,000 mm, -KOM 3179- Offered here is a measuring and inspection plate made of hard stone. Dimensions: approx. 1100 mm x 1000 mm x 1360 mm. Table height: approx. 900 mm. Ncjdpfx Ajy Auvlskyor

Condition: used, Year of construction: 2015, We offer this used Mitutoyo QVT1-X404P1L-D coordinate measuring machine, year of manufacture 2015. Model: QVT1-X404P1L-D Code No.: 364-180SY SO No.: Serial No.: 60866040 Year of manufacture: 2015 Software: version 13.2 including FORMPAK v5.4 The machine includes 7 different measuring heads as well as mounting materials for sample holders. Nedpfx Aksx Tiihsyjcr If you have any questions or need further information, please feel free to send us a message or call us.

Condition: used, Year of construction: 2010, Mobile articulated measuring arm / Measuring machine / Measuring device Manufacturer: Zett Mess Model: AMPG 2400 Precision Year of manufacture: 2010 – unused Nsdpjwu E D Rsfx Akyscr Measuring Ø: 2,400 mm

Condition: good (used), Year of construction: 2015, functionality: fully functional, Hexagon Metrology Optiv Classic 432 coordinate measuring machine in good, fully functional condition. Ncodpsx H T Emofx Akyjr Measuring range (single sensor): 400x300x200mm Dimensions: 1232x910x1663mm Weight: approx. 800kg Maximum workpiece weight: glass plate approx. 30kg Accuracy: MPEE = 2.9 + L/100 [μm] No additional software included. A PC is provided, but it is unknown to what extent the PC-DMIS 2020 R1 software can still be used.

Condition: excellent (used), Year of construction: 2023, Mobile 3D coordinate measuring device Ncodpfxey Aypkj Akyor Camera, manual probe with display Max. measuring length 10000/3500/3500 mm Certified measuring range 3000/1500/1500 mm Triple camera Integrated probe camera Measuring accuracy ±(28 + 5 L/1000) μm* Repeatability ±10 μm* Accessories

Condition: used, functionality: fully functional, measuring range X-axis: 700 mm, measuring range Y-axis: 700 mm, measuring range Z-axis: 600 mm, Equipment: type plate available, Mitutoyo Crysta Apex C776 coordinate measuring machine Temperature compensation on all axes Active vibration isolation system from BILZ X-axis measuring range = 700 mm Y-axis measuring range = 700 mm Z-axis measuring range = 600 mm Measurement uncertainty = 1.9 + 3L/1000 (µm) Renishaw PH10MQ probe head Renishaw SCR200 interchangeable rack Renishaw TP200 sensor Renishaw TP200 modules = 6 units MCosmos measuring software WIN10 PC system, 27" monitor Ncedpfswhfh Aex Akyjr Reference sphere / calibration sphere Optional software upgrade Optional hardware upgrade Full service available upon request

Condition: like new (used), Year of construction: 2013, functionality: fully functional, Equipment: type plate available, Mitutoyo Coordinate Measuring Machine Type Crysta Apex S544 Multisensor wiring (analog scanning) Temperature compensation for all axes Measuring range X-axis = 500 mm Measuring range Y-axis = 400 mm Measuring range Z-axis = 400 mm Measurement uncertainty = 1.7 + 3L/1000 (µm) Mitutoyo UC400 controller Renishaw PH6M probe head Renishaw SP25M sensor Renishaw SM25-1 module (scanning) MCosmos-3 v.3.4 measuring software PC system WIN10 and 27" monitor Reference sphere / calibration sphere Adapter clamping plate Optional software upgrade Nsdpfx Asvvlrljkyjcr Optional hardware upgrade Full-service available on request

Condition: used, functionality: fully functional, measuring range X-axis: 700 mm, measuring range Y-axis: 700 mm, measuring range Z-axis: 600 mm, Equipment: type plate available, Mitutoyo Coordinate Measuring Machine Type Crysta Apex C776 First installation: 2007 (precision measurement room) Temperature compensation for all axes Measuring range X-axis: 700 mm Measuring range Y-axis: 700 mm Measuring range Z-axis: 600 mm Measurement uncertainty: 1.9 + 3L/1000 (µm) Renishaw probe head PH10MQ Renishaw probe rack SCR200 Renishaw sensor TP200 Renishaw TP200 modules: 6 units Measuring software MCosmos-3 v3.4 including GEOPAK including CAT1000P including CAT1000S including SCANPAK including CAD converter PC system and monitor Reference sphere / calibration sphere Delivery free domicile (Germany) Including installation by qualified personnel Including calibration by qualified personnel Including on-site training at customer premises Nsdpfxjxnl Nke Akyscr After-sales service (optional)

Condition: used, Year of construction: 2005, functionality: fully functional, measuring range X-axis: 700 mm, measuring range Y-axis: 1,000 mm, measuring range Z-axis: 600 mm, Equipment: type plate available, Mitutoyo Crysta Apex C7106 coordinate measuring machine Temperature compensation on all axes Active vibration isolation system from BILZ X-axis measuring range = 700 mm Y-axis measuring range = 1000 mm Z-axis measuring range = 600 mm Measurement uncertainty = 1.9 + 3L/1000 (µm) Renishaw PH10MQ probe head Renishaw SCR200 interchangeable rack Renishaw TP200 sensor Nodpfx Akewhb A Nsyjcr Renishaw TP200 modules = 6 units MCosmos measuring software WIN10 PC system, 27" monitor Reference sphere / calibration sphere Optional software upgrade Optional hardware upgrade Full service available upon request

Condition: refurbished (used), Year of construction: 1999, functionality: fully functional, measuring range X-axis: 1,200 mm, measuring range Y-axis: 2,415 mm, measuring range Z-axis: 1,000 mm, The machine was around 6 years complete overhauled and its control technology was brought to the newest status. Technical details: Distance between portal columns: 1440mm X-travel (cross): 1200mm Y-travel (longitudinal): 2415mm Z-travel (vertical): 1000mm Feeler head: Vast Gold Ncedpfxoy Amfrj Akysr Regularly maintenanced through company Zeiss With housing
