Used Krause Y 32 Um/2 for sale (88,083)

Condition: used, Year of construction: 1970, Schlitzmaschine / Slot machine Krause-Y-32-UM-2-69Schlitztiefe / slot depth max. 32cm Normal Schlitzbreite / Normal slot width 3mm Hub des Druckstückes / stroke of the pressure piece ca. 30mm Stanzhübe / punch strokes per minute ca. 84 Online-Video-Inspection by Skype-Video We would be very pleased with your visit - more machines on Stock Hedsiiduajpfx Ab Tst Available Immediately - Can be inspect On Stock Emskirchen / Nürnberg - Can be test

Condition: used, Punching machine for, e.g., slipcases with many punching dies Hjdpexw N Ntefx Ab Tet

Condition: used, Year of construction: 2006, greates pass round over bed 960 mm swing diameter over bed slide o: 860 / u: 730 mm turning diameter over bed slide o: 860 / u: 400 control SIEMENS - 840 D forward bearing diameter 200 mm CNC Turning- and Milling Center | HEYLIGENSTAEDT - HEYNUMAT 24 UK-2 / 2000 Hedpexcbkmefx Ab Tjt equipped with a turret for driven tools as well as tailstock. The machine is in a well-maintained condition. Please refer to further technical details in the attachement of the offer. - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - #Tags: HEYNUMAT 24 UK | HEYNUMAT 24-UK | HEYNUMAT 24 UK 2 2000

Condition: used, This listing is for 1 of 2 Ortho Biovue System Heat block-32 Hsdpfjxzh Rksx Ab Tot

Condition: used, Year of construction: 1999, total length: 13,000 mm, total width: 7,000 mm, total height: 6,000 mm, overall weight: 120,000 kg, spindle motor power: 50,000 W, HEYLIGENSTAEDT HEYMUNILL 3200-P in heavy-duty portal design with fixed crossrail, suitable for machining large and heavy workpieces. Large working area with travels of X 6,000 mm / Y 5,000 mm / Z 1,500 mm, as well as a table size of approx. 5,000 x 3,000 mm and a table load capacity of approx. 50,000 kg. Portal clearance approx. 3,220 mm width / 2,050 mm height. 5-axis machining / milling heads A- and B-axis (swivel axes in the milling head) C-axis (360° rotation) Simultaneous 5-axis machining possible (with fork head) Milling heads: Straight milling head FK 120/340 90° angle head WFK 100/750M Fork head FK 100/2D Milling head magazine: 5 positions Automatic milling head change Additional equipment: Internal cooling (IKZ) approx. 7 bar Tool changer 32 positions (SK50, Fibro ATC 32/50) Hedpfx Aoy Anrteb Tjt Tool holder SK50 (DIN 69871) Tool measuring system (laser) Chip conveyor Coolant system Adaptive feed control Heidenhain linear scales X/Y/Z Spindle performance: 50 kW Control: Heidenhain TNC 430 Spindle speed: 5000 - rpm Travel Y-axis: 5000 - mm Dimensions (LxWxH) approx.: 13000 x 7000 x 6000 mm Weight approx.: 120,000 kg Travel Z-axis: 1500 - mm Travel X-axis: 6000 - mm Year of construction: 1,999 Condition: unchecked Terms of payment: 100% prepayment before pick-up Terms of delivery: From foundation under power: Yes

Condition: used, Year of construction: 2008, turning diameter: 275 mm, spindle bore: 80 mm, spindle speed (max.): 4,000 rpm, travel distance X-axis: 260 mm, travel distance Z-axis: 1,345 mm, total height: 2,232 mm, total length: 4,339 mm, total width: 2,232 mm, overall weight: 7,600 kg, Equipment: documentation/manual, CNC Lathe with Y-axis, driven tools an 2nd spindle CNC Control MSX-850-lll (mitsubishi 720 BM) Turning diameter 275 / 366 mm Spindle bore diameter 80 mm Spindle speed 4000 R/min Spindle motor 18.5/15 Kw Movement X-axis 260 mm Movement Y-axis +50 / -50 mm Movement Z-axis 1345 mm Movement W-axis (subspindle to mainspindle) 1275 mm Min indexing C-axis main spindle 0,001 ° Number of tools on turret 12x Number of driven tools 12 x Tool Taper BMT Bar feeder LNS Quick Load Servo lll Spindle motor driven tools 6000 R/min If you have any questions concerning the machine, please do not hesitate to contact us by phone or e-mail. Feel free to view our other advertisements for a complete overview of our stock. Hjdpfozv Sf Uex Ab Tet

Condition: excellent (used), Year of construction: 2008, This Haul-off saw from our renowned brand SICA S.p.a. is in machine storage at Plastima Used Machinery. The saw is from 2008 and is in used but good condition. Brand: SICA S.p.A. Type: TRS/SY 32-250 C 2000 Hedpstpg Avjfx Ab Tst Serial number: 0817501 Year of construction: 2008 Voltage: 400 V Power: 6 kW Pipe diameter max. 32 - 250 Ø (mm)

Condition: excellent (used), Year of construction: 2003, operating hours: 27,900 h, functionality: fully functional, clamping force: 1 kN, screw diameter: 32 mm, Type: HL120 RS35/32 Year : 2003 Auger ø 32 mm Hours: 27.900 h Hjdpfx Absu E Unfj Tot

Condition: excellent (used), functionality: fully functional, Year of construction: 2024, operating hours: 200 h, total length: 1,590 mm, total height: 2,130 mm, total width: 1,610 mm, type of input current: AC, input voltage: 230 V, input current: 30 A, travel speed (max.): 6,000 mm/min, space requirement length: 2,000 mm, space requirement height: 2,500 mm, space requirement width: 3,800 mm, Array – Your Solution for Industrial 3D Printing Production Array is a scalable platform for additive manufacturing, designed for the production of end-use polymer parts directly on your shop floor. Featuring integrated robotics, intelligent software, and high-performance FFF printing, Array reduces labor costs, increases productivity, and delivers series-quality components—on-site and exactly when you need them. Hjdpfx Aoxl Ry Aob Tjt Your benefits: Efficient & Cost-saving: Automated processes reduce personnel costs Fast & Flexible: High throughput for your production Industrial Quality: End products in series quality, available immediately Act now: Discover our pre-owned Array systems—inspected, reliable, and offered at attractive prices. ✅ Request your quote now ✅ Immediately available—fast delivery

Condition: used, Year of construction: 2019, Holz-Her Dynestic 7532 10.5 automatic CNC nesting machining center with Holz-Her Store-Master 5110 panel storage system Used machine Hjdpfx Ajzlbrpeb Tst Year of manufacture: 2019 Features and Technical Specifications: - Designed for classic nesting machining with a wear plate - Welded machine frame with ground and hardened prismatic guides for the traveling column, toolhead, and consoles - Gantry-style moving column - Rack-and-pinion drive, helical teeth, in the X and Y directions; ball screws in the Z direction for precise positioning - Machining dimensions: - Max. support area on nesting table: X = 3100 mm Y = 1560 mm - Max. travel ranges: X = 4695 mm Y = 2100 mm Z = 293 mm - Max. clearance height of DYNESTIC table Z = 100 mm from top edge of table (without wear plate) - Maximum programmable speed Vector speed: 128 m/min X = 80 m/min, Y = 100 m/min, Z = 25 m/min - DYNESTIC table: - Rigid, continuous machining table with grid markings - continuous slots in the X and Y directions - Slot spacing: 50 mm - Includes 25 meters of sealing cord for securing the wear plate - Vacuum fields: 1-circuit vacuum system - Drilling unit 7877: - 19 spindles - Drive power: 1.7 kW - 13 vertical spindles: - individually controllable - U-shaped arrangement - 5 in the X direction and 4 in the Y direction - 32 mm pitch - max. drill bit diameter: 35 mm - Total drill length: 70 mm from the mounting end (depending on panel thickness) - Spindle extension stroke: 70 mm - Rotation direction: Alternating clockwise and counterclockwise - n(max): 1000–4400 rpm, continuously adjustable - Mounting: M10 thread – 11 mm interference fit - Tool-free, without mounting adapter - 6 horizontal spindles: - 2 double drilling spindles in the X direction - 1 double drilling spindle in the Y direction - Mounting: M 10 thread, 11 mm interference fit - Total drill length: max. 63 mm from mounting end - Tool-free, without chuck - Milling unit 7842: - Power: 12.0 kW (S6) - n(max) = 1,000–24,000 rpm, continuously variable - Max. power at 12,000 rpm to 24,000 rpm - Air-cooled - With HSK-F 63 tool holder - With right-hand threaded nut (for right-hand rotating tools) - With collet chuck with HSK shank - Ceramic ball bearings (hybrid bearings) - Max. tool weight: 6 kg (including holder) - Tools: Milling and grinding tools, max. Ø 160 mm - Safety guarding in accordance with CE standards - Protective fencing on the sides and rear - Vacuum pump: 500 m³/h, dry-running - Operator safety via light curtains in the front area of the machine - Handheld control unit for remote control of the machine with the following operating functions: - Start/Stop of the machining program - Speed control of the machining cycles - Reset button - Manual feed/rapid traverse for all axes - Emergency Stop - CAMPUS V7 CAD/CAM software, 1 machine license consisting of: - CAMPUS NC-HOPS: - Graphical variant system with WOP and CAD/CAM features for creating part variants using macro technology - CAMPUS MT-Manager - CAMPUS Workcenter - CAMPUS DXF interface - Automatic centralized lubrication - Automatic lubrication according to defined lubrication intervals - Additional dust sealing via positive pressure in each guide carriage - Simultaneous lubrication: - for all linear guides in the X, Y, and Z directions - for all ball screws in the Y and Z di...

Condition: used, functionality: limited functionality, travel distance X-axis: 900 mm, travel distance Y-axis: 300 mm, travel distance Z-axis: 450 mm, total height: 2,500 mm, overall weight: 3,000 kg, Conventional milling machine - Documentation available: Yes - CE certificate available: No - Serial number: 6029 - FYD 32 JM, year of manufacture: 1989 - Control system: Conventional - Spindle head: Vertical - Power [kW]: 12.8 - Number of axes: 3 - X-axis travel [mm]: 900 - Y-axis travel [mm]: 300 - Z-axis travel [mm]: 450 - Table length [mm]: 1250 - Table width [mm]: 315 - Tool holder: ISO40 - Min. spindle speed [rpm]: 56 - Max. spindle speed [rpm]: 1800 Hjdozxinxjpfx Ab Tst - Transport dimensions: 1720mm x 2170mm x 2200mm - Weight approx. 3000kg

Condition: good (used), Year of construction: 2016, spindle speed (max.): 3,500 rpm, overall weight: 6,000 kg, Equipment: documentation/manual, rotational speed infinitely variable, Main parameters: Controller: FANUC 0iD/31iA Chuck.: SAMCHULLY 10" Spindle bore: 86mm With jacket tube.:78mm Turret head: 12 main positions 12 secondary positions, BMT65 connection, Programmable hydraulic tailstock: MT5 Main spindle power: 22kW S1max=3500 1/min Living tool power: 5.5kw S2max=5000 1/min Hsdpjwtg Inefx Ab Tjt X movement range: 260mm Z axis movement range: 830mm Y axis movement range: + - 52mm (104mm) C axis Maximum turning length: L=760 Largest turning diameter: D=376mm Fast travel speed: 30m/min Automatic tool measurement with probe arm Weight: 6000 kg

Condition: like new (used), Year of construction: 2009, functionality: fully functional, temperature: 60 °C, Available immediately! Hjdpfx Aex Izwmob Tjt Function Easy operation thanks to a fully automatic cleaning process, allowing professionals to focus on other important tasks. The wash tank is filled with a mixture of water and water-soluble IBS special cleaner (washing solution). The contaminated items are placed in the rotating washing basket, and the lid is closed. After setting the desired washing temperature and time, the unit is switched on and the solution in the tank is heated. Inside the closed unit, the basket rotates at a constant speed around its own axis. The pump units draw the washing solution from the tank and distribute it through 6 stainless steel jet pipes with overlapping flat spray nozzles. The items are intensively sprayed from all sides with the hot solution due to the uniform rotation of the motor-driven basket. Once the cleaning process is complete, the unit shuts off automatically. Advantages - 2 horizontally mounted pumps - 6 three-dimensional stainless steel jet pipes - Robust stainless steel construction - Additional small parts cleaning basket made of stainless steel (Ø 170 mm) - Rotating stainless steel wash basket, V-belt drive via separate motor - Steam extraction - Stainless steel sieve plate with filter basket above the wash tank - Suction filter in front of the pump chamber - Water shortage safety feature - Individually height-adjustable feet Technical Data Capacity dipping tank / basket: 280 l Diameter dipping tank / basket: 1150 mm Load capacity: 350 kg / optional 500 kg Temperature min. - max.: 0-60 °C Working height: 700 mm Dimensions (W x D x H): 1570 x 1510 / 1830 x 1495 / 2175 mm Weight: 250 kg Heating power: 10 kW Spray amount: 2x10800 l/h Pump pressure: 2.3 bar Material: Stainless steel Electrical connection: 13.5 kW / 400 V / 50 Hz / 32 A

Condition: reconditioned (used), functionality: fully functional, Year of construction: 2018, controller model: Rexroth IndraMotion MTX, laser type: CO₂ laser, laser power: 3,200 W, punching force: 22 t, Standard equipment: Machine - Work area 3050 x 1550 mm - Drives with maintenance-free three-phase motors - Stable, easily accessible C-frame - Coordinate guidance - Linear magazine with 25 positions for clamping dies and tools - Follow-up device with programmable pressure clamp - Flap for stamped parts 500 x 500 mm incl. sensor - 2 scrap containers (=> not included with part conveyor belts) - Foot pedal for die closing - FocusLine - NitroLine - FastLine - FlyLine - PlasmaLine - Additional Xp and Yp axis - Ejection cylinder for laser parts - Fast flap for laser parts 500x500 mm incl. sensor - Adjustable laser cutting support - Slag cone detection TRUMPF Laser - Laser TruFlow 2700 incl. LensLine and optimized standby mode - High-frequency excitation - Closed beam guidance - Fine filtration of compressed air for beam pipe ventilation Cutting Head - Lens cutting head with 170 mm focal length - Universal cutting head quick-change device (UTI) - LensLine with condition monitoring - ControlLine Punching Head - Electro-hydraulic punching head - Rotatable mono-tool holder - Programmable pressure clamp position - Tool length compensation - Scrap extraction - Calculation of filling level in the punching console - Stroke counter for punches - Spray lubrication for punches - Level monitoring for tool lubrication Control System - Open control system based on Bosch Rexroth IntraMotion MTX Hodpfx Abozv Twxo Tet - Integrated technology data - 160 GB hard drive capacity - External control panel with 15" TFT touchscreen - Programmable cutting gas pressure - Teleservice interface via the internet - Automatic shutdown with wake-up function - Production plan Data Transfer - USB interface - RJ45 network connection - Wireless Operation Point (basis for Visual Online Support) Safety - CE marking - Multi-beam light barriers - Rapid shutdown of drives - Warping detection - Protection against stray radiation - Compact dust extraction system Extended Standard Equipment - Hydraulic clamping die (4 pieces) - Ball tables (=> not included with brush tables) - Chip container (=> not included with chip conveyor) - Cooling unit (water-air) + Laser TruFlow 3200 incl. LensLine and optimized standby mode + MultiTool function + Thread forming function + MultiShear function + Roll technology function + Softpunch function + StripLine function + Active die + Height-adjustable clamping die (4 pieces) + Follow-up cylinder - Vibration-damped installation + Chip conveyor with tilting container + Brush tables with loading and unloading assistance SheetMaster N0140A0054 automation: - Suction frame with 36 suction cups (y-axis = 400 mm) - Movable suction bars (v-axis = 170 mm) - Peeling suction cup - Vacuum sensor - Sheet thickness gauge for double-sheet detection - Central lubrication - TRUMPF control system based on Rexroth IndraMotion MTX - Automatic die closing of the machine + Extended guide rail + Table extension (brush design) + Fixed additional support table on the left (brush design) + Automatically adjustable additional support table on the right (brush design) + Large C-frame for processing oversized parts + Parallel loading and unloading of the SheetMaster during main processing time + Unloading monitoring + Lowerable GripMaster for large formats (3000 x 1500mm) + Scissor lift table (3000 x 1500)

Year of construction: 1988, condition: ready for operation (used), A Krämer & Grebe rotary cutter is available. Bowl volume: 325l, knife speed: 3000rpm, knife peripheral speed: 120m/s, steam pressure: 2-4bar, steam temperature: 120°C-150°C, cooking temperature: 65°C-85°C, cooling temperature: 45°C-50°C, machine dimensions X/Y/Z: approx. 3000mm/2250mm/2050mm, weight: approx. 4300kg. Including accessories such as knives, plastic parts and assembly wrench. The machine is dismantled and the control cabinet and the motor are located in the hall. An on-site inspection is possible. Hedpfx Absyypl Aj Tot

Year of construction: 2007, condition: ready for operation (used), Cutting dimensions X/Y: 2000mm/3000mm, Z-axis stroke: 230mm, machine tolerance: +/-0.05mm/m, repeatability: +/-0.025mm/m, simultaneous movement: 56m/min, max. cutting speed: 30m/min, max. material thickness: 200mm, max. load capacity: 790kg/m², max. workpiece weight: 4740mm, max. clamping material thickness: 50mm, max. pump pressure: 3800bar, max. working pressure: 3600bar, machine weight: approx. 11300kg, working hours: 18111h. Documentation available. An on-site inspection is possible. Hodpfxeyttwuj Ab Tjt

Year of construction: 2019, condition: ready for operation (used), A belt washing machine is available for pre-washing and feeding food into downstream machines. Input height: 1000mm, output height: 1000mm, machine dimensions X/Y/Z: approx. 4600mm/1500mm/1500mm, weight: approx. 1000kg. Documentation available. On-site inspection is possible. Hsdpju Tiyvsfx Ab Tst

Condition: excellent (used), Year of construction: 2022, Turning diameter 376mm, turning length 760mm, bar capacity 76mm, Y axis -/+ 52.5mm, C axis 0.001 degrees on both spindles, Hjdpfxozt Spno Ab Tjt 24 station turret, 22KW Motor, Main spindle 4000rpm, sub-spindle 4500rpm, Fanuc I series, 3 jaw chucks, swarf conveyor, tool setter, LNS barfeed unit.

Condition: used, Year of construction: 2013, Used machine Year of manufacture: 2013 Equipment and technical data: - machine has been completely overhauled: - new Glue Jet 301 glue system (top part 1 mm) - all units inspected - all cutters sharpened - all knives replaced - feed speed: 10 - 18 m/min - workpiece length: min. 160 mm - workpiece width: min. 60 mm - workpiece thickness: 8 - 60 mm - edge thickness: 0.4 - 8 mm - electrics for infinitely variable feed: 400 V / 50 Hz, 2.2 kW - motorised pressure beam adjustment - automatic chain lubrication - PPC 315 control with 15" touchscreen Hsdpfxozlbpzs Ab Tot - ECO MODE energy-saving mode - infeed fence 1350 mm, motor-adjustable - jointing/trimming unit 1802: - 2 x 2.0 kW, 200 Hz, 12000 rpm with 2 milling units for jointing the panel edge - cutter, diamond Ø 70 x 64 x 30 mm, Z2, counter-clockwise for jointing unit - cutter, diamond Ø 70 x 64 x 30 mm, Z2, clockwise for jointing unit - edge feed 1901 fully automatic - adhesive application station Glu Jet GJ301 automatic: - 2.3 kW; 50 Hz - storage hopper for granulate - pressure unit 1913 MOT - end-trimming unit 1918 (60 mm) pneumatic - multifunction milling unit 1826 MOT4 (2 x 0.65 kW): - Air Stream System cutter, diamond Ø 58 mm x 24 mm, Ø 20 mm Z = 2 R = 2.5 mm counter-clockwise - Air Stream System cutter, diamond Ø 58 mm x 24 mm, Ø 20 mm Z = 2 R = 2.5 mm clockwise - profile milling unit 1833 MOT4: - cutter, diamond Ø 72.5 mm x 19 mm, Ø 20 mm Z = 4 radius R = 2.5 mm, counter-clockwise with CM technology - cutter, diamond Ø 72.5 mm x 19 mm, Ø 20 mm Z = 4 radius R = 2.5 mm, clockwise with CM technology - scraper unit 1929 MOT2: - carbide indexable inserts for scraper holder R = 2.5 mm (2 pcs. required) - flat scraper 1964 - buffing unit 1940 (2 x 0.12 kW, 50 Hz, 1400 rpm) Availability: at short notice Location: 63934 Röllbach

Condition: used, Year of construction: 1993, Max. bending length: 3240 mm Max. sheet thickness: 2 mm steel Manual and automatic bending process possible Bending angle adjustable via potentiometer Hsdpfsyhqhtjx Ab Tjt Lifting height of the upper beam and material thickness can be preselected via dip switch Bent rail and machine in top condition Weight: approx. 3000 kg

Condition: ready for operation (used), * Brand: Derrick Corporation Hodpfeywmzcox Ab Tst * Type: F36-126D-3DD * Surface: 3200 x 800 mm - 2 Decks * Driving: 1 vibration motor * On stock: 2 pieces

Condition: excellent (used), Year of construction: 2007, functionality: fully functional, machine/vehicle number: PT20SY0117, total height: 2,500 mm, total length: 4,100 mm, total width: 2,240 mm, overall weight: 12,000 kg, Control: Fanuc 18i - TB Swing over cross slide: Ø800 mm Max. cutting diameter: Ø620 mm Max. turning length: 740 mm Main spindle: speeds 50-5,000 rpm Spindle bore/Spindle nose: Ø76.2 / Ø68 Number of turrets: 12 B-axis: Ø810 mm Rotary tools: speed 50 – 4,000 rpm Rotary tool motor (turret one/turret two): 7.5/5 HP Hsdpfx Abszq A Dkj Tot Rapid traverse (X/Z/Y): 790 / 20 m/min Sub spindle rapid traverse: 20 m/min Dimensions: Floor space: L = 4100 x W = 2240 x H = 2500 Machine weight: 12000 kg.

Condition: excellent (used), functionality: fully functional, pressing force: 3 t, Force 32 kN, stroke 100 mm Hjdpfjzxmhpjx Ab Tot

Condition: good (used), functionality: fully functional, Year of construction: 2009, controller model: Siemens Sinumerik 840D, laser type: CO₂ laser, laser power: 3,200 W, punching force: 22 t, Standard equipment: Machine - Working area 3050 x 1550 mm - Hi-Las high-pressure cutting - Cutting head quick-change system - Programmable cutting gas selection/pressure adjustment - Capacitive height control APC - Function: ContourLas - Slag cone detection - Compact dust extraction system - Tank heating - Automatic tool changer with 19 stations (21 – clamping jaws) - 2 clamping jaws - Rotation of all tools - NC-controlled, digitally operated, maintenance-free three-phase drives - Automatic repositioning Hodpfx Abezv Sare Tot - Tool length compensation - Rapid shutdown of the hydraulics - Automatic shutdown - Automatic indexing slides, each 500 x 500 mm - Sensors for both indexing slides - Slug extraction - Forming capability - Programmable stamping tool lubrication - Programmable clamping device - Adaptive stroke length control - Safety devices - RJ 45 network connection - 3.5'' floppy disk drive + 5'' cutting head + 9" cutting head + FocusLine + MultiTool function + Thread forming function + Signing/quick beading function + Deburring and rolling technology function + Softpunch function + Additional clamping jaw + Repositioning cylinder + Vibration-damped installation + Blow-out device for small parts + Chip conveyor with tilting container

Condition: ready for operation (used), Year of construction: 2021, operating hours: 15,000 h, functionality: fully functional, Equipment: documentation/manual, 2021 Star SR32 JII Type A (15,000 hours) 4m FMB Turbo 3-36, Hydrajet UB20 High Pressure Coolant, LNS Swarf Conveyor, FireTrace Suppression, JBS Guide Bush System, Fully inspected & serviced, 30 Day Warranty # Star SR-32JII CNC Sliding Head Lathe Machine Hours: Approx. 15,000 hours Maximum Machining Diameter: Ø32 mm standard / Ø34 mm optional CNC Control: Fanuc 32i-B ## Machine Configuration * Twin-spindle CNC sliding head lathe * Main spindle and sub-spindle * Main and sub-spindle full C-axis control * Gang-type tooling system * Cross-working driven tooling * Back-working tooling * X1, Y1, Z1, C1, X2, Z2 and C2 controlled axes * Type B configuration additionally incorporates Y2 control on the back-working unit Hodpfx Abozuxfrj Tet ## Main Spindle * Maximum spindle speed: 8,000 rpm * Spindle motor: 7.5 kW continuous / 11 kW short-time rating * Maximum headstock stroke: 320 mm * Full C-axis contouring capability ## Sub-Spindle * Maximum spindle speed: 8,000 rpm * Spindle motor: 3.7 kW continuous / 5.5 kW short-time rating * Full C-axis contouring capability * Maximum chucking diameter: Ø32 mm / Ø34 mm optional ## Main Tooling * 6 × turning tool positions * Tool size: 16 mm square * 5-spindle sleeve holder * Maximum drilling capacity: Ø13 mm * Maximum tapping capacity: M12 × P1.75 ## Cross-Working / Driven Tooling Configuration options include: * 3 × ER20 cross-milling positions + 2 cartridge-type positions * Or 6 × ER16 cross-milling positions * Maximum milling capacity: Ø10 mm * Maximum driven tapping capacity: M8 × P1.25 * Cross-milling spindle speed: 6,000 rpm * Cartridge-type driven tooling speed: up to 8,000 rpm * Driven-tool motor: 2.2 kW continuous / 3.0 kW short-time rating ## Back-Working * Maximum chucking diameter: Ø32 mm / Ø34 mm optional * Maximum front ejection length: 125 mm * Maximum projecting component length: 45 mm * Back-working tool positions: * 6 positions – Type A * 8 positions – Type B * Stationary drilling capacity: Ø13 mm * Driven drilling capacity: Ø8 mm * Stationary tapping capacity: M10 × P1.5 * Driven tapping capacity: M6 × P1.0 * Maximum back-working driven-tool speed: 6,000 rpm ## Rapid Traverse * X1 / X2 / Y1 / Z1 / Z2: 35 m/min * Y2: 24 m/min on applicable Type B machines ## Ancillary Equipment Included * 4 metre FMB Turbo 3-36 Magazine Bar Feeder * Hydrajet UB20 High-Pressure Coolant System * LNS Swarf Conveyor * FireTrace Automatic Fire Suppression System * JBS Guide Bush System ## Machine Condition & Support * Approx. 15,000 operating hours * Fully inspected and serviced * Supplied ready for production * 30 Day Warranty * Warranty valid within the UK only ## General Specification * Coolant tank capacity: 255 litres * Approximate machine dimensions: 2,690 × 1,345 × 1,780 mm * Approximate machine weight: 4,100 kg * Power requirement: 8.8 kVA * Maximum sound pressure level: 77 dB
