Used Masterwood B 1/V for sale (104,597)

Condition: good (used), Code: 0476 Brand: MASTERWOOD Model: B 1/V - CE Standard Vertical chisel mortising machine for cutting recesses and grooves in wooden joinery, doors, beams and other items – CE Standard Technical data: Vertical stroke 150 mm Longitudinal stroke 260 mm Transverse stroke 70 mm Motor power 3 Hp Max workable height of solid wood component 170 mm Min/max workable height of assembled window or door frame 740/1030 mm Work surface 140 x 470 mm Tilt +/- 45° Pneumatic workpiece clamping Suction inlet diameter 60 mm Compressed air 6 bar Overall dimensions mm 1000 x 850 x 1750 h Nledpfxozqzhbe Aiief Weight kg 440

Condition: ready for operation (used), Year of construction: 2010, This 3-axis MASTERWOOD OM B1 CN3KF was manufactured in 2010. It features a Bedano head and a horizontal milling motor, ideal for creating slots for shutters or blinds. With a working length of 2600 mm and a very good condition, it includes a PC with integrated software running Windows XP. Consider the opportunity to buy this MASTERWOOD OM B1 CN3KF CNC Wood Machining Centre. Contact us for more information. Machine Benefits Nledozugu Uopfx Aiijf Technical Machine Benefits • Working length: 2600 mm • The machine has a bedano head + horizontal milling motor to make slots for shutters or blinds. • The software is integrated into the supplied pc and can make slots with bedano and slots for shutters. • Supplied pc with windows xp operating system. • Very good condition and does not have many working hours. Extra Information Machine still under power

Condition: as good as new (ex-display), Year of construction: 2024, functionality: fully functional, used wet polishing machine from PERS, model Vibra-Line B 150 l, with buffer tank, in combination with PERS dryer Vibra-Dry A 200 l - both demo machines Technical data / Vibra-Line B 150 l: U-shaped work container with automatic discharge Capacity (gross): 150 l Usable volume (depending on workpiece geometry and material): 80 l Year of manufacture: 2024 Diameter, external: 1,170 mm Height: 860 mm Lining in the bowl: 22 mm, yellow or brown PU Total weight (empty): 320 kg Drive power: 2.2 kW Electrical connection: 3 x 400 V, 16 Amp. CEE Device color: RAL 7015/7035 Control cabinet with touch panel and frequency inverter Buffer tank – 90 l: The compound (soap solution) itself flows through the filter basket into the buffer tank, from which a submersible pump pumps the water back to the rotary vibrator. Dimensions of the buffer tank (L x W x H): 700 x 400 x 460 mm 1 submersible pump and 1 filter basket (630 µm) are included Technical data / Vibra-Dry A 200 l: Corn/grain dryer with automatic discharge - vibration dryer Year of manufacture: 2024 Volume: 220 l Njdsy A N U Aspfx Aiislf Motor power: 1.5 kW Heating: 3 kW per element (PTI temperature control) Capacity, workpieces: up to 65 kg Capacity, corn: 25-35 kg Speed: 1400 rpm Heating effect: 6 x 1.5 kW Length: 1,141 mm Width: 1,200 mm Height: 905 mm Internal dimensions of the bowl: 240 mm Electrical connection: 3 x 400 V, 16 Amp. CEE Device color: RAL 7015/7035 Corn granule temperature: +30 to +50 degrees Digital temperature control pneumatically controlled outlet valve For commissioning, 25 kg of corn kernels of type GM 16 or GM 20 must be used.

Condition: ready for operation (used), Year of construction: 2019, travel distance X-axis: 610 mm, travel distance Y-axis: 350 mm, travel distance Z-axis: 460 mm, controller manufacturer: SIEMENS, controller model: 828 D SL, total height: 1,987 mm, total width: 1,720 mm, table width: 350 mm, table length: 710 mm, overall weight: 2,600 kg, spindle speed (max.): 10,000 rpm, spindle motor power: 7,000 W, tool weight: 6,000 g, product length (max.): 1,880 mm, number of axes: 3, This 3-axis PreMill V 610 B was manufactured in 2019. It features an X-axis travel of 610 mm, Y-axis travel of 350 mm, and Z-axis travel of 460 mm. The machine has a robust table size of 710 x 350 mm and a maximum workpiece weight of 350 kg. If you are looking to get high-quality machining capabilities, consider the PreMill V 610 B vertical machining centre we have for sale. Contact us for further details. - Distance Spindle Center to Table Surface: 100 - 560 mm- Max. Workpiece Weight: 350 kg- Rapid Traverse Speed (X/Y/Z): 12 m/min- Feed Speed: 10 m/min- Positioning Accuracy: +/- 0.008 mm- Repeatability: +/- 0.005 mm- Tool Changer Type: Carousel- Tool Storage Capacity: 16 slots- Max. Tool Diameter: 100 mm (150 mm without adjacent tools)- Max. Tool Length: 300 mm- Spindle Motor Power (100% ED): 7 kW- Feed Motor Power (X/Y/Z): 2.3 kW- Power Supply: 12 kVA- Compressed Air Supply: 6 bar- Coolant Tank Capacity: 100 L- additional features available: ShopMill, 3D Simulation, Auto Power Off, Rigid Tapping, Flat Guideways in X/Y/Z, Chip Conveyor (Screw type) with Chip Cart, Spindle Ring Flushing, Prepared for CTS (IKZ), Prepared for 4th Axis, Central Oil Lubrication, LED Signal Lamp & Workspace Light, Vice Nlsdpfx Aozn Urhjiiof Technical Specification Taper Size SK 40 Through-spindle Coolant Yes

Condition: used, Year of construction: 2019, Numerical control with bSolid software The multi-document software application in Windows environment allows the design of the finished product, the definition of its processes, the definition of the work plan, the simulation of the piece machining operations on the 3D model of the machine and generation of the necessary machine programs. bSolid - 3-Axis Machining bSolid - 5-Axis Machining Module for surface machining with 5-axis units and interpolation movements on all 5 available axes (X,Y,Z,C,B). The module includes the following commands: · assignment to surfaces three-dimensional roughing and finishing operations · spread or project a path onto a curved surface machining lying on a plane · follow 2D or 3D curves with any type of tool bSolid - 3D Engraving bSolid - Import external formats Fields of work: X = 5055 mm; Y = 1650 mm (may vary depending on configuration) Z = 200 mm with modules H=74 mm Z = 245 mm with modules H=29 mm Loadable piece in Y: * 1650 mm, with thickness up to 60 mm on H=74 mm modules * 1600 mm, with thickness over 60 mm on H=74 mm modules. 10 ATS floors – 40 trolleys The code includes: • 2 aluminium bars (n. 1 left and n. 1 right) on which the lateral stops slide. • 10 aluminum worktops. The worktops slide on hardened and ground linear guides using recirculating ball bearing slides. Locking occurs on both linear guides, front and rear, by means of four pneumatic cylinders. The control is activated by a button located in front of the work surface. The carriages slide on steel guides positioned above the extrusion. Pneumatic locking system divided into 2 locking zones in X Automatic positioning (EPS) for worktops. "EPS" (Electronic Positioning System) device for the automatic positioning by NC of the work surfaces and trolleys complete with locking devices capable of eliminate possible operator errors. Rear row stop, with 140 mm stroke Intermediate row stop, positioned at 405 mm, with 140 mm stroke. Front row stop, positioned at 1460 mm, with 140 mm stroke 4 lateral stops, with 140 mm stroke (2 right + 2 left) with system 2 additional side stops, with 140 mm stroke (1 right + 1 left). Sensor for checking whether the stops have descended 12 clamping devices for clamping narrow workpieces 6 loading aid bar lifts, for H=74 mm modules Configuration 5A, for Rover B. Configuration for high productivity and flexibility, thanks to the two operating groups 4 and 5 axes and the possibility of performing tool changes in concurrent time. It includes the axes and carriages for the movement of the main operating groups. Includes 2 inverters. Second Y-axis. Introduces the separation of the front and rear Y-carriages, with independent motorization. The two Y-carts have a maximum speed of 118 m/min. 13.2 kW (17.7 HP) electrospindle, HSK F63 connection, air-cooled. Main features: • 11 kW (14.7 HP) from 12,000 to 15,000 rpm in S1 service. • 13.2 kW (17.7 HP) from 12,000 to 15,000 rpm in S6 service. • Bearings ceramics. • Right and left rotation. • Rotation speed from 1,000 to 24,000 rpm programmable by NC. • The release pneumatic operation is carried out via a prismatic linear guide and recirculating ball bearings. A cover is included for chip extraction, with 6 different positions in Z managed by the NC, depending on the length of the tool, or by program. The suction mouth is automatically closed when the electrospindle is not working. Provision for subsequent installation of the 360° operating group (C-axis) Revolver tool maga... Nljdpfew D E A Ejx Aiijf

Condition: used, machine/vehicle number: 008013, X axis working area: 5780 mm Y axis working area: 1650 mm Working Table: Pod and Rail Main Electrospindle power: 13.2 KW Number of controlled axes: 4 axes Maximum edge height: 60 mm Total number of drilling spindles: 16 Total number of tool changer positions: 16 Nedswuz Ekspfx Aiijlf

Year of construction: 2006, condition: ready for operation (used), A complete Battenfeld compact extrusion line for the production of PVC profiles is available. 1) Twin-screw extruder Battenfeld MBEX 2-50-16 V, year of manufacture: 2006, output capacity: 15kg-60kg/h, screw diameter: 52mm, screw length: 16×D, barrel zones: 4, barrel cooling zones: 3, adapter zones: 1, die heating zones: 9, control system: BMCtouch. Including dry vacuum pump, pressure measuring points, clamping flange, water-air separator, blow-off device, mounting elements and hopper cover. 2) Calibration table Battenfeld KP 125 V 2/4m, mounting frame length: 4100mm, mounting rail width: 320mm, longitudinal adjustment: 500mm, transverse adjustment: +/-15mm. 3) Speck vacuum system, pumps: 2, motor power: 2×4kW, operating pressure: 200mbar, max. air capacity: 2×140m³/h. 4) Battenfeld RP 125 SE caterpillar haul-off, passage height: 100mm, contact length: 1100mm, pad width: 160mm, haul-off speed: 15m/min, max. haul-off force: 7kN. 5) Battenfeld SP 63 E underfloor saw, max. cross-section capacity X/Y: 200mm/300mm, sawing accuracy: +/-0.5mm. Overall line dimensions X/Y/Z: approx. 12000mm/1200mm/2000mm, weight: approx. 4500kg, operating hours: approx. 319h. Including chip extraction. The line touchscreen is defective (nothing is visible), however, the line can be operated using an external monitor, mouse and keyboard. Documentation available. An on-site inspection is possible. Nlsdpozg Iqhsfx Aiief

Condition: used, Battenfeld BEX-1-150-32-D-V / BEX 45-25E / 89-9436-3201 extruder machine. Manufacturer: Battenfeld-cincinnati Germany GmbH. Year of manufacture: 1999 Year of installation: 1999 Rated voltage: … V Maximum current consumption: … A Frequency: 50 Hz Required pressure: 6 bar Total weight: … kg Noise level: … dB Hydraulic pressure for the screen changer: Nlodszump Espfx Aiiof Extrusion material output: 1000-1200 kg (filter-limited output: approx. 850 kg) Possible thickness: 1 – 5 mm Maximum width: approx. 1450-1480 mm Machine dimensions: as described in the layout. Battenfeld BEX-1-150-32-D-V / BEX 45-25E / 89-9436-3201 extruder machine Consisting of: Screw and barrel assembly, motor and drive system, control interface, and supporting auxiliary systems for feeding, thermal regulation, and downstream processing. Details: Feed station - 2x silos. 2 x metal separators - Degacan HE degassing elements, co-extruder Type BEX-1-150-32-D-V and BEX 45-25E / 89-9436-320 to produce sheets or coils. Main extruder composed of 7 heating zones and one vacuum zone. Co-extruder composed of 3 heating/cooling zones to control the polymer. Followed by 3 calenders with temperature controllers. Extrusion die - To be confirmed if included. Calender line setup. Betacontrol Mk1 thickness measuring system. Radioactive source has been removed. Calvatron corona treatment system. Kalvar Calvtron automatic coil changing system. Rollers and calibration table. End-of-line sheet separation and side cutting (slitting) machine. BC touch control interface. Full workshop manuals.

Condition: like new (used), Year of construction: 2013, functionality: fully functional, travel distance X-axis: 700 mm, travel distance Y-axis: 530 mm, travel distance Z-axis: 560 mm, torque: 115 Nm, controller manufacturer: Fanuc, total height: 2,750 mm, total length: 2,200 mm, total width: 2,360 mm, table width: 500 mm, table length: 900 mm, table load: 500 kg, overall weight: 6,400 kg, spindle speed (min.): 50 rpm, spindle speed (max.): 12,000 rpm, spindle motor power: 15,000 W, Year of manufacture: 2013 CNC Fanuc TABLE Table size: 900 x 500 mm Five T-slots: 18 H 8 mm Maximum permissible weight on the table: 500 kg WORKING CAPACITY X-axis: 700 mm Y-axis: 530 mm Z-axis: 560 mm Spindle nose – table surface distance: 150 / 710 mm Spindle axis – column surface distance: 550 mm SPINDLE Spindle diameter: 70 mm Spindle taper connection Big Plus: ISO 40 DIN 69871 Spindle speed: 50/12,000 rpm Spindle motor: 15/11 kW Maximum torque: 115 Nm FEED RATES Rapid traverse rates for X/Y/Z axes: 32 m/min Working feed rates: 20 m/min TOOL MAGAZINE Number of tools: 30 Tool taper: ISO 40 Maximum tool diameter (without adjacent tools): 76 / 125 mm Maximum tool weight: 7 kg Njdozr Uq Sspfx Aiislf MACHINE DIMENSIONS Height: 2,750 mm Footprint: 2,200 x 2,360 mm Weight: 6,400 kg Machine complete with: •Presetter •Probe •Vise •Tool cabinet •Instruction manuals and CE declaration

Year of construction: 2008, condition: ready for operation (used), A mechanical centrifugal dryer B+B Anlagenbau for plastic flakes and washed materials is available. 1) Mechanical dryer B+B Anlagenbau FH 50/150-V, year of manufacture: 2008, power: 30kW, max. relative humidity: 60%, machine dimensions X/Y/Z: approx. 4050mm/1150mm/3850mm, weight: approx. 1250kg. 2) Separation tank Weiss, material: stainless steel, machine dimensions X/Y/Z: approx. 3000mm/1500mm/1800mm. The motors and slides need to be overhauled. 3) Friction separator B+B Anlagenbau FAS 40-300, power: 22kW, speed: 1470rpm, max. relative humidity: 60%, separated material: PET/PE/PP. Total system dimensions X/Y/Z: approx. 6500mm/2100mm/3200mm, design: modular, cyclones: 2/bunker, process: conveying/separation/friction drying/final dewatering. Documentation available. An on-site inspection is possible. Nodexl Eltopfx Aiislf

Condition: new, Year of construction: 2025, Panel Saw ALTENDORF F 35 Type 1 - 1000 Top for Solid Wood - New machine - immediately available from stock Bitburg - Motor power: 7.5 kW, 400 V, 50 Hz, 3 speeds Motorized height and tilt adjustment Large safety hood Double roller carriage, 3,200 mm Scoring unit-ready Rip fence, cutting width 1,000 mm Njdpfexyl Epjx Aiiolf Angle/miter fence 3,450 mm, without length compensation Table extension/widening: Powder-coated surface Saw blade tilting range: 0 - 46° Carriage length: 3,200 mm Cutting length: 3,100 mm Cutting width: 1,000 mm Cutting height: 154 mm Max. saw blade diameter: 450 mm Display size: 15 inch Working table height: 910 mm Extraction port diameter: 80 + 120 mm Options included: M45102 Rip fence 1000 mm Digit_X Location: ex-stock 54634 Bitburg - immediately available -

Condition: new, bore capacity in steel (diameter) 32,0 mm throat 255 mm bore stroke 120 mm morse taper 4 MK table: 385 x 335 mm turning speeds 80 - 2130 U/min Njdpfx Aoxaaqgoiislf total power requirement 1,1 / 2,2 kW weight 125 kg range L-W-H 460 x 900 x 1730 mm Furnishing: - Surface-machined work table - Height adjustable via rack and hand crank - Ground base plate with T-slots for clamping high workpieces - V-belt drive with balanced drive pulleys for smooth running - Adjustable drilling depth stop for precise infeed of the quill - Powerful 2-stage motor, speed range from 80 - 2130 rpm - Direction of rotation switch for clockwise and counterclockwise rotation included in the scope of delivery - Cross line laser device for comfortable work - Compact, stable cast iron construction in a modern design - Stable and polished steel column, designed for heavy use Scope of delivery: - Drill chuck arbor MK 4 / B 18 - Keyless chuck 1 - 16 mm / B 18 - Cam switch for right-left rotation - Cross line laser device - T-nuts - Height-adjustable protective cover

Condition: excellent (used), Year of construction: 2004, machine/vehicle number: 87, functionality: fully functional, EBERL vacuum dryer, manufactured in 2004. Underwent a major overhaul in 2024, performed by Eberl (purchased directly from Eberl). Fully operational, complete documentation available. Nlsdpfoy Uc I Hox Aiijf

Condition: excellent (used), Year of construction: 1997, Battenfeld BA 1300V/315 V-R / Vertical injection molding machine with rotary table Year of construction: 1997 Injection unit: Screw diameter: 40 mm Injection weight: 182.9 g Injection pressure: 1575 bar Dosing volume: 201 ccm Clamping unit: Clamping force: 130 t Distance between tie bars: 454x740 mm Size of the clamping platens: 815x1010 mm Nsdpfx Aijzc Nuneijlf Ejector: hydraulic Clamping unit: hydraulic Control system: UNILOG 4000 Additional equipment: Air valve x 5 Hydraulic core pull x 1 Turntable: 1250 mm The vertical injection unit - screw diameter fi 35 mm Dimensions: Weight: 7500 kg Length/width/height: 3.83x2.33x4.16 m Drive: Pump/motor: 18.5 kW Heating output: 8.98 kW Total output: 27.48 kW All offered machines are started by our service technicians before sale. It is possible to obtain a video of the technical tests of the selected machine or participate in live technical tests at our company in Łódź. Price: On request

Condition: excellent (used), I offer an industrial inverter, the SEW EURODRIVE MOVIDRIVE B, designed for controlling high-power motors in demanding industrial applications. This device is used in industrial automation, production lines, conveyors, industrial machinery, and drive systems. Technical specifications: • Manufacturer: SEW EURODRIVE • Series: MOVIDRIVE B • Type: MDX61B0450-503-4-0T • Supply voltage: 3 × 380–500 V AC Nlodpszcf D Sefx Aiijf • Frequency: 50/60 Hz • Motor power: 45 kW • Output current: 89 A AC • Protection class: IP20 • Country of manufacture: Germany Applications: • Production lines • Conveyors and conveyor systems • Industrial machinery • Industrial automation systems • High-power drives Device advantages: • Smooth motor speed control • Advanced control and diagnostics functions • Built-in operator panel with display • High reliability and durability • Professional industrial design Condition: • Used • Dismantled from an industrial installation • Normal signs of use and storage • Visual condition as shown in the photos • Sold exactly as shown in the photos Included: • SEW EURODRIVE inverter MDX61B0450-503-4-0T • Operator panel mounted on the device

Year of construction: 2020, condition: new, Exhibition machine with AD 2000 Year of construction 2020 Compressor system HOS Suction capacity approx. 650 l/min Filling capacity approx. 520 l/min Explanation Filling capacity at 6 bar working pressure Maximum pressure 10 bar Tank capacity 270 l Number of cylinders 2 Nodpfx Aexg Ux Ejiijlf Number of compression stages 2 PU 1 Dimensions and weights Length approx. 720 mm Width/depth approx. 720 mm Height approx. 1770 mm Weight approx. 160 kg Electrical data Output power 4 kW Supply voltage 400 V Mains frequency 50 Hz Noise emission Sound pressure level Lp 80 dB(A) Explanation Sound pressure level Sound pressure level at 1 m distance according to DIN 45635 T 13 Availability: short term Storage location: Flörsheim

Condition: used, Year of construction: 1996, - Double-sided IMA COMBIMA for longitudinal machining - Swiveling device - Double-sided IMA COMBIMA for transverse machining 1 used edge processing line IMA COMBIMA / K/ II/ R75 / 1075 / V / R3 Year of manufacture: 1996 Consisting of: - Double-sided IMA COMBIMA for longitudinal machining: Double edging unit 2 x milling units Gluing unit with granular pre-melting device 6-position roller magazine for edge material 1 x main pressure roller and 4 x follow-up pressure rollers Cutting unit Flush trimming 2 x fine milling units Profile trimming blade Surface trimming blade Buffing unit Smoothing unit - Swiveling device from longitudinal to transverse - Double-sided IMA COMBIMA for transverse machining Protective milling Double edging Grooving milling unit Gluing unit with granular pre-melting device 6-position roller magazine for edge material 1 x main pressure roller and 4 x follow-up pressure rollers Capping at the top pressure (retrofit to current model) Flush trimming Fine milling 2 x MFA milling units Grooving milling unit Profile trimming blade Surface trimming blade Nlsdpfxjzuypxs Aiisf Copy buffing (4 motors) Buffing (2 motors) Smoothing unit Note: The technical data and descriptions are a transcript of the order confirmation at the time. Data is for informational purposes only and is not binding.

Condition: good (used), Year of construction: 1997, machine/vehicle number: 885258, Offer 25514 Technical Data: - Max. working length: 3060 mm - Frame opening: 2690 mm - Max. pressing force: 1300 kN - Max. distance table/ram: 535 mm - Throat depth: 410 mm - Ram stroke: 215 mm - Stroke speeds: - Downward idle speed: max. 200 mm/sec - Upward speed: 135 mm/sec - Pressing speed (downward): 1 to 11 mm/sec - Total drive power: 18 kW - Pneumatic connection: 6 bar - Required space: approx. W 3800 x H 2700 x D 2400 mm - Weight: approx. 11,500 kg Nlodpfx Aiox Ew Dqoiof Features: - 6-axis CNC control system DELEM - Two-hand control panel with foot pedal - Crowning system - CNC-controlled backgauge with height adjustment 5 - 860 mm - Hydraulic upper and lower tool clamping - Pneumatically assisted die table shifting

Condition: good (used), Year of construction: 2010, travel distance X-axis: 1,000 mm, travel distance Y-axis: 400 mm, travel distance Z-axis: 500 mm, quill stroke: 105 mm, spindle speed (max.): 1,800 rpm, spindle speed (min.): 40 rpm, table length: 1,400 mm, table width: 400 mm, total height: 2,150 mm, total length: 2,300 mm, total width: 1,800 mm, overall weight: 3,600 kg, table load: 400 kg, Universal Milling Machine, capacity Ø 80 mm, swiveling head +/- 30, feed range X/Y/Z 1000/400/500 mm, table size 1400x400 mm, motor 7,5 KW, speeds 40-1800 rpm. stepless, ISO 50, quill travel 105 mm, depth 510 mm, digital readout on 3 axis, automatic and rapid feeds, coolant system, dimensions 2300x1800x2150 mm, weight ca. 3600 kg; accessoires into cabinet Nlodpfxjyzacbe Aiief

Condition: reconditioned (used), Year of construction: 2000, functionality: fully functional, Equipment: CE marking, IMA BIMA 410 V CNC WORKING CENTRE FOR BORING + ROUTING + EDGE BANDING • Industrial machine with heavy-duty structure • Working area: X:4000 mm Y:1200 mm Z: 100 mm • Travel speed: X:100 m/min Y:80 m/min Z: 25 m/min • 2 Working areas • 8 movable work tables to support the panels. SCHMALZ system • 23 SCHMALZ suction cups with vacuum system for the locking of the working piece • 4 loading device through pneumatic bars assembled on the work tables that lift the pieces • 1 SIEMENS vacuum pump ROUTING UNIT: • 10 HP. Refrigerated router head • Automatic change of the tool • Tool holders: HSK F-63 • C AXIS that allows to turn and 360° angle drive heads with rotation regulation in automatic by numerical control • 0 to 20.000 rpm • Tool magazine 12 positions MULTI-BORING UNIT: • 7 independent spindles for vertical boring in X direction • 5 independent spindles for vertical boring in Y direction • High revolution speed: 9.000 rpm Nsdpfx Aijzc E A Isijlf EDGE BANDING UNIT: • Automatic device to apply the edge into straight profiles of shaped panels • Applicable banding material in coils: thin edge and PVC up to 3 mm • Independent unit to edge band shaped panels. It's installed on the main frame of the machine - hot-melt glue pot and premelter - spreading roller to regulate the quantity of apllied glue - edge pression roller • Lamp zone to pre-heat the side of the panel • Multiple magazine for edge coils with 2 positions, to automatically change the edge type • Top and bottom edge trimming head-unit • Top and bottom edge scraping head-unit CONTROL OF THE MACHINE: • IMATRONIC • Software IMAWOP • Command board installed on a separated electrical cabinet to control the machine PROTECTION ENCLOSURE OF THE WORKING UNITS PROTECTION FENCES SECURITY CARPETS SECURITY NORME CE MARK

Condition: excellent (used), functionality: fully functional, Year of construction: 2010, machine/vehicle number: BN2222, Demag chain hoist crane lifting mechanism 3200 kg DC-Pro 16-3200 H8 V4/1 Nljdpezhtfmofx Aiief Load capacity 3200 kg / 3.2 t, lifting capacity – 2-strand with trolley drive (beam width approx. 25-33 cm) with 2 lifting speeds, lifting height approx. 8 m!!! incl. control valve block Total weight approx. 160 kg, connection to 400 V 50 Hz Very good condition, hardly used Item location is 75053 Gondelsheim See pictures

Condition: good (used), Application: Lisec/VFL glass processing machines Width: 35 mm Height: 100 mm Depth: 165 mm Nsdpfx Aijy I Urqoiolf Weight: 135 g Condition: good, second-hand

Condition: used, TECHNICAL DETAILS - Number of axes : 4 - Number of spindles : 2 MAIN SPINDLE - Max. bar diameter : 12 [mm] - Max. machining length : 135 [mm] - Spindle speeds : 8000 [rpm] - Spindle power : 2.2 [kW] - C axis indexing precision : 0.001 [°] COUNTER-SPINDLE - Max. bar diameter : 12 [mm] - Z stroke : 120 [mm] - Spindle speeds : 7000 [rpm] GUIDE BUSH HOLDER 1 - Number of positions : 5 END ATTACHMENT - Number of positions : 3 SECONDARY OPERATION - Number of positions : 3 POWER SUPPLY - Supply voltage : 400 [V] WEIGHT & DIMENSIONS Njdpfjuhaw Isx Aiislf - Machine floor space : 1500 X 770 [mm] - Machine weight : 1400 [kg] EQUIPMENT - CNC : Fanuc - 3 colors status lamp - Rotating guide bush - Parts catcher - Ejection of workpiece - Coolant tank - Electric transformer

Condition: ready for operation (used), Year of construction: 1996, travel distance X-axis: 4,000 mm, travel distance Y-axis: 1,200 mm, number of axes: 3, number of slots in tool magazine: 5, total height: 3,100 mm, overall weight: 7,500 kg, table length: 4,000 mm, table width: 1,200 mm, spindle motor power: 7,500 W, spindle speed (max.): 18,000 rpm, This 3-axis IMA BIMA 610 V CNC Wood Machining Centre was manufactured in 1996. It features a working area of 4000 mm in the X-axis and 1200 mm in the Y-axis, with a maximum drilling diameter of 45 mm. The machine is equipped with 5 drilling spindles in the X direction and 11 in the Y direction. If you are looking to get high-quality wood machining capabilities, consider the IMA BIMA 610 V machine we have for sale. Contact us for further details. • CNC Control: NUM CNC Control • Drive System: Siemens SIMODRIVE 611 • Maximum Workpiece Length: 4000 mm • Minimum Workpiece Length: 150 mm • Maximum Workpiece Width: 1650 mm • Minimum Workpiece Thickness: 10 mm • Maximum Workpiece Thickness: 65 mm • Drilling Spindles (X): 5 • Drilling Spindles (Y): 11 • Maximum Drilling Diameter: 45 mm • Main Spindle Power: 7.5 kW • Main Spindle Motor: Water-cooled • Tool Holder: HSK F63 DIN 69893 • Feed Drive Motor Power: 4 kW • Feed Speed: 1,500–18,000 mm/min • Maximum Tool Weight: 5 kg • Maximum Tool Clamping Force: 10,000 N • Operating Voltage: 400 V ±5% • Supply Voltage: 3/N/PE, 400 V, 50 Hz • Frequency: 50 Hz • Total Connected Load: 33 kVA • Rated Power: 41 kW • Rated Current: 62 A • Connection Cross Section: 16 mm² • Control Voltage: 24 V • Control Current: 52 A • Compressed Air Pressure: 6–10 bar • Air Connection: 1/2" • Required Air Consumption: 28 m³/h • Dust Extraction Connection: Ø100–300 mm • Air Flow Ø100: 14 m³/min Nsdpezug Alefx Aiijlf • Air Flow Ø140: 28 m³/min • Air Flow Ø160: 36 m³/min • Air Flow Ø180: 46 m³/min • Air Flow Ø200: 56 m³/min • Air Flow Ø280: 105 m³/min • Air Flow Ø300: 127 m³/min • Number of Dust Extraction Ports: 1 • Machine Condition: Disassembled but fully functional Optional Equipment, not included: • Vacuum block suction cups (aluminum) and sliding console • Two milling spindles for synchronous milling with integrated tool changers • Safety fence with associated safety mats • Control cabinet and operating unit • Waste conveyor belt for milled sections

Condition: excellent (used), For sale: Mannesmann Demag AF06-L-M-0-145-1 geared motor with a three-phase Demag ZBA90 A4 B020 motor. The unit is fully functional, tested, and ready for operation. The visual condition is good, with normal signs of use. Notes: * One mounting lug has been cut – this does not affect the operation or correct mounting of the geared motor. * There is a small crack on the plastic motor cover, which does not affect the operation of the unit. Technical data: Manufacturer: Mannesmann Demag AG Gearbox model: AF06-L-M-0-145-1 Motor model: Demag ZBA90 A4 B020 Power: 1.1 kW Supply: 3×400 V AC, 50 Hz Brake voltage: 180 V DC Rated current: 2.80 A Motor speed: 1400 rpm Output speed: approx. 23 rpm Gear ratio: i = 60.1 Brake torque: 20 Nm Cos φ: 0.75 Ingress protection: IP54 Insulation class: F Weight: 21.2 kg Nodpfxezpbufo Aiislf
