Used Mecal Machining Center for sale (69,237)

Condition: good (used), Year of construction: 1997, functionality: fully functional, We offer an nice condition Matsuura with tools and accessoriess, very atractive machine for a serious work. Iodpevkx Rkjfx Anwjau Description Matsuura MC600VF Vertical Machining Centre in great working condition ready to use. COOLING TROUGH SPINDLE including Large Qty of BT40 Tooling (33 TOOLS, Universal 3D Tester. Country of Origin: Japan. Spindle Chiller WASTE CONVEYOR with Yasnac i80M Control 20 Position: ATC BT40 : Taper Specifications Manufacturer MATSUURA Model MC600VF Year 1997 Condition Used Serial Number 970112285 Table size 870 x 400mm Coolant tank X = 600 Y = 410 Z = 470mm Spindle speeds 30 – 15000 rpm.

Condition: new, Year of construction: 2025, table length: 900 mm, table width: 450 mm, number of spindles: 1, spindle speed (min.): 8,000 rpm, table load: 500 kg, VMC 650 CNC machining center, milling machine with CNC system VMC 650 machining center is a multifunctional equipment that allows you to perform milling, drilling, thread cutting, and turning operations in automatic mode (if these options are available in the machine). The VMC 650 milling machine can have 16- or 24-position tool magazine. Depending on the customer's wishes, the milling machine can be equipped with a GSK, Siemens or Fanuc CNC system. It is possible to optionally add a Y-axis drive. As a very convenient additional option, we recommend installing a chip conveyor that will save you time when working with the equipment. Technical parameters: Worktable size 900x450mm Maximum workpiece weight 500 kg Movement along the axes X/Y/Z 800/450/500 mm Maximum distance from the spindle to the table surface 120-620 mm Motor power 5.5-7.5 kW Maximum spindle speed 8000 rpm Spindle type BT40 Positioning accuracy ±0.008/300 mm Repeatability ±0.005 mm Machine dimensions 300022752550 mm Iasdsxc I Dgepfx Anweu Machine weight 4000 kg It is also possible to supply CNC milling machines, machining centers with other table sizes: VMC 850 table 1000x500 mm VMC 855 table 1000x550 mm VMC 1060 table 1200x600 mm VMC 1160 table 1200x600 mm VMC 1275 table 1300x700 mm VMC 1370 table 1400x700 mm VMC 1580 table 1600x800 mm VMC 1680 table 1700x800 mm VMC 1890 table 2000x900 mm

Condition: ready for operation (used), Year of construction: 1998, functionality: fully functional, travel distance X-axis: 500 mm, travel distance Y-axis: 400 mm, travel distance Z-axis: 400 mm, table width: 700 mm, table length: 500 mm, No minimum price – guaranteed sale to the highest bidder! Machining center with a manually rotatable and swiveling machine table! TECHNICAL DETAILS Travel ranges x-axis: 500 mm y-axis: 400 mm z-axis: 400 mm Table Table surface: 700 x 500 mm Spindle Tool holder: 40 SK/ISO Spindle speeds: 20 - 4,500 rpm Spindle drive: 12 kW Feed rates Feed rates: 5,000 mm/min Iasdezb Uz Djpfx Anwsu Control system: Heidenhain TNC 124 MACHINE DETAILS Total power requirement: 13 kW Machine weight: approx. 2,800 kg Space requirement: approx. 3 x 2 x 2 m

Condition: ready for operation (used), Year of construction: 2007, operating hours: 36,012 h, functionality: fully functional, travel distance X-axis: 635 mm, travel distance Y-axis: 460 mm, travel distance Z-axis: 510 mm, controller model: 3D Heidenhain i TNC 530, spindle speed (max.): 10,000 rpm, TECHNICAL DETAILS Travel range, X-axis: 635 mm Iedpjzb Dzmsfx Anweau Travel range, Y-axis: 460 mm Travel range, Z-axis: 510 mm Spindle speed range: 20 - 10,000 rpm Table dimensions: 790 x 560 mm Table load capacity: 600 kg Tool holder: SK 40 Number of tool magazine slots: 20 MACHINE DETAILS Control system: 3D Heidenhain i TNC 530 Total power consumption: 13.9 kW Operating hours (according to counter) Spindle hours: 36,050 h Power-on hours: 91,000 h Dimensions & Weight Dimensions (L x W x H): 3,000 x 2,000 x 2,150 mm Machine weight: 3.6 t

Condition: ready for operation (used), Year of construction: 2007, functionality: fully functional, machine/vehicle number: 80.4308.0097, travel distance X-axis: 900 mm, travel distance Y-axis: 800 mm, travel distance Z-axis: 970 mm, controller model: FANUC Professional 3, spindle speed (max.): 12,000 rpm, TECHNICAL DETAILS Travel range, X-axis: 900 mm Travel range, Y-axis: 800 mm Travel range, Z-axis: 970 mm Pallet size: 630 mm × 630 mm Number of pallets: 2 Max. workpiece weight: approx. 1,200 kg Spindle connection: HSK-A100 Max. spindle speed: 12,000 rpm Tool magazine: 188 positions Tool change time: approx. 1.7 s Rapid traverse: up to 50 m/min Iaedezb Efyopfx Anwou MACHINE DETAILS Control system: FANUC Professional 3 Machine weight: approx. 18 t EQUIPMENT Dual-pallet system Large 188-position tool magazine Automatic tool changer Through-spindle coolant / coolant system Chip conveyor NC rotary table Network/DNC connection Note: The machine was previously connected to a pallet loading station. The pallets can, of course, also be loaded manually.

Condition: ready for operation (used), Year of construction: 1999, functionality: fully functional, travel distance X-axis: 1,660 mm, travel distance Y-axis: 760 mm, travel distance Z-axis: 660 mm, table load: 1,200 kg, rotational speed (max.): 8,000 rpm, No minimum price – guaranteed sale to the highest bidder! TECHNICAL DETAILS Travel range X-axis: 1,660 mm Travel range Y-axis: 760 mm Travel range Z-axis: 660 mm Table size: 760 x 2,000 mm Table load capacity max.: 1,200 kg Tool holder: SK 40 Tool changer: 2 x 24 Tool diameter max.: 80 mm Tool diameter with free adjacent slot max.: 110 mm Tool length max.: 350 mm Iedpfozb D N Rsx Anwjau Rapid traverse (X/Y/Z): 24 / 24 / 30 m/min MACHINE DETAILS Control system: MAZATROL M-PLUS Dimensions & Weight Space requirement: approx. 6.0 x 4.0 x 3.5 m Machine weight: approx. 8.1 t Total power requirement: 32.8 kVA The machine has been regularly serviced.

Condition: ready for operation (used), Year of construction: 2002, machine/vehicle number: 0-250-08-1590, functionality: fully functional, travel distance X-axis: 3,250 mm, travel distance Y-axis: 1,220 mm, travel distance Z-axis: 125 mm, controller model: Homatic 2000 IPC, number of spindles: 28, spindle speed (max.): 24,000 rpm, No reserve price – guaranteed sale to the highest bidder! TECHNICAL DETAILS Working area X-axis: 200 – 3,250 mm Working area Y-axis: 70 – 1,220 mm Working area Z-axis: 12 – 125 mm (clearance 150 mm) Tool changer positions: 18 Spindles Total number of drilling spindles: 28 Vertical drilling spindles: 22 Horizontal drilling spindles in X-axis: 4 Horizontal drilling spindles in Y-axis: 2 Milling spindle power: 12 kW Milling spindle max. speed: 24,000 rpm C-axis: 360° interpolation MACHINE DETAILS Vacuum pump capacity: 100 m³/h Control model: Homatic 2000 IPC Control software: WoodWop 4.5 incl. MDE and production list software FEATURES 4 axes Console table 8 manually adjustable supports in X direction 3 vacuum cups per console Vacuum connection for templates Laser positioning aid for vacuum cups Laser projection for cup positioning Liquid circulation cooling Iajdpfszcda Sex Anwou Operator terminal Note: The sale does not include the pictured adapter units, tools, or HSK holders.

Condition: used, Year of construction: 2005, machine/vehicle number: 107.32.99.158, travel distance X-axis: 530 mm, travel distance Y-axis: 450 mm, travel distance Z-axis: 450 mm, controller model: Heidenhain iTNC 530, spindle speed (max.): 12,000 rpm, No minimum price – guaranteed sale to the highest bidder! The machine spindle was replaced in July 2025! TECHNICAL DETAILS Travel range X-axis: 530 mm Travel range Y-axis: 450 mm Travel range Z-axis: 450 mm Rotary table Table diameter: 400 mm Table load: 200 kg Swivel range: degrees Swivel speed: 20 rpm Rotational speed: 30 rpm Tool holder: SK40 Maximum speed: 12,000 rpm Recommended maximum working feed rate: 15 m/min Rapid traverse speed: 22 m/min Feed force X and Y/Z: 5,000 N Iasdszara Uspfx Anweu Magazine capacity: 30 Maximum tool diameter: 90 mm Maximum tool length: 250 mm (manually 350 mm) Maximum tool weight: 6 kg MACHINE DETAILS Control system: Heidenhain iTNC 530 with digital control Positional tolerance according to DIN/ISO 230-2/97: 0.008 mm Machine weight: 6,500 kg EQUIPMENT RENISHAW MP 12 measuring probe Blum tool monitoring system

Condition: ready for operation (used), Year of construction: 2005, functionality: fully functional, travel distance X-axis: 700 mm, travel distance Y-axis: 1,000 mm, travel distance Z-axis: 500 mm, spindle speed (max.): 18,000 rpm, No minimum price – guaranteed sale to the highest bidder! TECHNICAL DETAILS Travel range, X-axis: 700 mm Travel range, Y-axis: 1,000 mm Travel range, Z-axis: 500 mm Spindle speed: 1 - 18,000 rpm Tool holder: HSK-A63 Tool magazine capacity: 70 Tool-to-tool change time: 2.5 s Acceleration: 20 m/s² Travel speed: 120 m/min MACHINE DETAILS Number of pallets: 6 EQUIPMENT Integrated workpiece changer system High-dynamic 5-axis machining Weight-optimized kinematics Iaedpezd R R Eefx Anwju Linear motor drives

Condition: excellent (used), Year of construction: 2021, operating hours: 11,514 h, functionality: fully functional, machine/vehicle number: 20210202, travel distance X-axis: 670 mm, travel distance Y-axis: 820 mm, travel distance Z-axis: 600 mm, controller model: Heidenhain TNC 640, spindle speed (max.): 18,000 rpm, TECHNICAL DETAILS Isdpfxjzb A Eko Anwjau Travel X-axis: 670 mm Travel Y-axis: 820 mm Travel Z-axis: 600 mm Spindle speed (min.): 18,000 rpm Spindle operating hours: 11,514 h Coolant supply: 40 bar MACHINE DETAILS Apparent power rating: 90 kVA Control manufacturer: Heidenhain Control model: TNC 640 Total weight: 20,000 kg Input voltage: 400 V Full load current: 125 A Max. current load: 200 A Short-circuit resistance: 25 kA Voltage: 400.50 V/Hz Net weight: 20,000 kg Machine number: 20210202 EQUIPMENT Documentation/Manual Chip conveyor

Condition: ready for operation (used), Year of construction: 1998, operating hours: 26,000 h, functionality: fully functional, machine/vehicle number: J0124, travel distance X-axis: 1,800 mm, travel distance Y-axis: 850 mm, travel distance Z-axis: 750 mm, controller model: Heidenhain iTNC 426, rotational speed (max.): 6,000 rpm, TECHNICAL DETAILS Travel range X-axis: 1,800 mm Travel range Y-axis: 850 mm Travel range Z-axis: 750 mm Spindle nose to table distance range: 200 mm - 950 mm Spindle center to column distance: 920 mm Table dimensions X: 2,000 mm Table dimensions Y: 800 mm Max. table load: 2,200 kg Tool interface: SK50 Magazine capacity: 30 Spindle speed: 6,000 rpm Feed rate: 5 m/min Rapid traverse: 12 m/min MACHINE DETAILS Control system: Heidenhain iTNC 426 Dimensions & Weight Dimensions (L x W x H): approx. 5,700 x 3,850 x 3,350 mm Weight: approx. 16,500 kg Operating Hours Total operating hours: approx. 51,000 h Iajdpfxezdpqwe Anwsu Spindle operating hours: approx. 26,000 h EQUIPMENT 4th axis installed as a rotary table Documentation/Manual Spindle speed infinitely adjustable Chip conveyor Coolant system Vices

Condition: ready for operation (used), Year of construction: 2003, functionality: fully functional, machine/vehicle number: 15744, travel distance X-axis: 800 mm, travel distance Y-axis: 600 mm, travel distance Z-axis: 600 mm, controller model: Heidenhain iTNC 530, table load: 1,500 kg, TECHNICAL DETAILS Travel range, X-axis: 800 mm Travel range, Y-axis: 600 mm Travel range, Z-axis: 600 mm Table length: 1,000 mm Table width: 560 mm Table load: max. 1,500 kg Spindle connection: HSK63 Tool changer: 30 positions Rapid traverse rate: 35 m/min Acceleration: 5 m/s² Iasdpfx Anjzcymzowju MACHINE DETAILS Control system: Heidenhain iTNC 530 Dimensions & Weight Dimensions (L x W x H): 4,200 x 2,500 x 2,800 mm Weight: 7,200 kg Total connected load (including cooling unit): 42 kVA

Condition: ready for operation (used), Year of construction: 2003, functionality: fully functional, machine/vehicle number: NH501CD0388, travel distance X-axis: 650 mm, travel distance Y-axis: 600 mm, travel distance Z-axis: 730 mm, controller model: Fanuc MGS-501, rotational speed (max.): 8,000 rpm, TECHNICAL DETAILS Travel range, X-axis: 650 mm Travel range, Y-axis: 600 mm Travel range, Z-axis: 730 mm Rapid traverse rate, X-axis: 50 m/min Rapid traverse rate, Y-axis: 50 m/min Rapid traverse rate, Z-axis: 50 m/min Maximum workpiece height: 900 mm Maximum workpiece diameter: 730 mm Maximum workpiece weight: 500 kg Table dimensions: 500 x 500 mm Table load capacity: 500 kg Maximum spindle speed: 8,000 rpm Distance from table center to spindle nose: 100 mm Number of spindles: 1 Torque: 302 Nm Number of tool positions in the tool magazine: 60 Tool length: 500 mm Tool diameter: 120 mm Tool weight: 30 g Tool holder type for turret 1: ISO 50 MACHINE DETAILS Iajdpfozcla Hjx Anweu Control system: Fanuc MGS-501 Rated apparent power: 73 kVA Input voltage: 380 V Type of input current: Three-phase Dimensions & Weight Dimensions (L x W x H): 4,900 x 2,595 x 2,770 mm Total weight: 13,200 kg Operating hours (according to diagram): 28,877 h Power-on time (according to diagram): 94,850 h EQUIPMENT CE marking Documentation/Manual Spindle speed infinitely adjustable Chip conveyor

Condition: ready for operation (used), Year of construction: 2004, operating hours: 61,297 h, functionality: fully functional, travel distance X-axis: 2,800 mm, travel distance Y-axis: 2,200 mm, travel distance Z-axis: 800 mm, controller model: HEIDENHAIN TNC 426, Equipment: chip conveyor, No minimum price – guaranteed sale to the highest bidder! A new spindle was installed in January 2025! The machine has been regularly maintained! TECHNICAL DETAILS Travel range X-axis: 2,800 mm Travel range Y-axis: 2,200 mm Travel range Z-axis: 800 mm Feeds Rapid traverse: 35,000 mm/min Spindle speed S1 (continuous operation) Vertical: 10,000 rpm Spindle speed S1 (continuous operation) Universal swivel head 2-axis: 18,000 rpm MACHINE DETAILS CNC control: HEIDENHAIN iTNC 530 Electrical data Supply voltage: 400 V (-15 %, +10 %) Iodszb D Aqopfx Anweau Frequency: 50 Hz Current consumption: 101.1 A Installed total power: 59.8 kW Operating hours Switch-on hours: 99,222 h Program runtime: 61,297 h EQUIPMENT High-rigidity gantry design Precise linear guides and ball screws Generous work area with 2.8 m X-axis travel High feed rates for efficient machining Ideal for tool, mold and machine construction Documentation and acceptance certificate according to ISO standards Tool changer Cooling system Chip conveyor Indexing milling head with 4th/5th axis

Condition: used, Year of construction: 1996, functionality: limited functionality, travel distance X-axis: 630 mm, travel distance Y-axis: 600 mm, travel distance Z-axis: 650 mm, controller model: Fanuc MSX-516, rotational speed (max.): 12,000 rpm, The P8 power supply, valued at €1,500, was only replaced in August 2024! The spindle was repaired in 2017 and has mostly only been used for single-layer operation since then! TECHNICAL DETAILS Travel range X-axis: 630 mm Travel range Y-axis: 600 mm Travel range Z-axis: 650 mm Feed length X-axis: 630 mm Feed length Y-axis: 600 mm Feed length Z-axis: 650 mm Table width: 500 mm Iodpfx Anjzcuyiswsau Table length: 500 mm Number of pallets: 2 Maximum speed: 12,000 rpm Number of tool magazine slots: 60 (BT40) MACHINE DETAILS Control: Fanuc MSX-516 Phases: 3 Frequency: 50 Hz Voltage: AC 200 V Full load current: 181 A Note: The rapid traverse rate of the X-axis is reduced by 20% to extend the service life of the telescopic guides. The sealing ring during pallet changes is likely defective. The seller temporarily resolved this by inserting a ball valve in between when the pallets needed to be changed. EQUIPMENT Documentation/Manual Chip conveyor

Condition: ready for operation (used), Year of construction: 2005, functionality: fully functional, machine/vehicle number: 15125250184, travel distance X-axis: 2,500 mm, travel distance Y-axis: 920 mm, travel distance Z-axis: 820 mm, controller model: Heidenhain iTNC 530, spindle speed (max.): 18,000 rpm, TECHNICAL DETAILS Number of axes: 3 Travel in X-axis: 2,500 mm Travel in Y-axis: 920 mm Travel in Z-axis: 820 mm B-axis rotation: 105° Table length: 3,100 mm Table width: 900 mm Iedpfxjzdkhks Anwoau Table length: 3,100 mm Table width: 900 mm Tool holder: SK40 Max. spindle speed: 18,000 rpm MACHINE DETAILS Control system: Heidenhain iTNC 530 Dimensions & Weight Dimensions (L x W x H): 7,500 x 4,500 x 300 mm Net weight: 22,000 kg Shipping packages: 3 EQUIPMENT External coolant system Chip conveyor Tool magazine (30 pieces)

Condition: ready for operation (used), Year of construction: 2010, functionality: fully functional, machine/vehicle number: 216327, travel distance X-axis: 1,660 mm, travel distance Y-axis: 510 mm, travel distance Z-axis: 510 mm, controller model: Mazatrol 640M, spindle speed (max.): 12,000 rpm, TECHNICAL DETAILS Number of axes: 3 Travel range, X-axis: 1,660 mm Travel range, Y-axis: 510 mm Travel range, Z-axis: 510 mm Table length: 2,000 mm Table width: 510 mm Tool holder: ISO40 Max. spindle speed: 12,000 rpm MACHINE DETAILS Control system: Mazatrol 640M Operating time according to control system display: 40,843 h Dimensions & Weight Dimensions (L x W x H): 5,120 x 3,000 x 2,800 mm Unladen weight: 8,250 kg Iodpfx Anozdf Dhsweau EQUIPMENT Chip conveyor Tool magazine with 30 positions Tools included

Condition: ready for operation (used), Year of construction: 2009, operating hours: 3,275 h, functionality: fully functional, travel distance X-axis: 1,100 mm, travel distance Y-axis: 600 mm, travel distance Z-axis: 510 mm, table load: 1,000 kg, rotational speed (max.): 12,000 rpm, No minimum price – guaranteed sale to the highest bidder! Machine with only 3,275 spindle hours! Ijdpfx Ajzdkgajnwjau TECHNICAL DETAILS Travel in X-axis: 1,100 mm Travel in Y-axis: 600 mm Travel in Z-axis: 510 mm Table size: 1,300 x 600 mm T-slots: 6 (size 18) Maximum table load: 1,000 kg Spindle speed range: 60 - 12,000 rpm Drive power: 10 / 17 kW Spindle mounting: ISO 40 / DIN 69871A Magazine: 32 positions MACHINE DETAILS Drive power: 10 / 17 kW Internal cooling (IKZ): 20 bar Coolant tank volume: 480 l Spindle hours: 3,275 h Machine operating hours: 15,883 h Control operating hours: 17,706 h

Condition: used, Spinner MICROTURN 52 LTBS Sub-Micron Turn Mill Center with Y / B-Axis and Twin Spindles AUTOMATION READY - MC0122 Less than 300 hours No bar feed Tools and probes included—for all 3 spindles? BMT 45 Probe would stay. No tooling Chucks etc. included Yes Coolant: used Water Based What kind of facility is it in? R and D for performance parts for injector and turbos Specifications Work Area: Swing Diameter: 23.9 in (608 mm) Turning Diameter (max): 5.9 in (150 mm) Turning Length(max): 9.8 in (250 mm) Travels: X: 23.6 in (600 mm) Z:13.8 in (350 mm) Y1 Turret: +/- 1.9 in (50 mm) Y2 Milling Spindle: +/- 1.9 in (50 mm) B Rotary: 180 degrees Feedrate: Rapid Traverse X: 944.8 ipm (24 m/min) Rapid Traverse Y: 590.6 ipm (15 m/min) Rapid Traverse Z: 944.8 ipm (24 m/min) Spindle #1 Left / #2 Right: Liquid cooled motorized spindle with C-axis servo drive and encoder for synchronous machining. Spindle Bore Capacity: 52mm (2.0 in) Speed: 5,200 rpm Performance (S6 40%): 22.1 hp (16.5 kW) Torque (S6 40%): 81.1 ft-lb (110 Nm) Spindle Nose: DIN 55026-A6 B-Axis Milling Spindle: Speed (max): 12,000 rpm Performance (S6 40%): 12 hp (9 Kw) Torque (S6 40%): 15.4 ft-lbs (21 Nm) Swivel Angle: +/- 180 degrees Positional Measurement: Rotary Encoder Clamping: Hydraulic Turret: Stations: 12 / BMT45 Live Tooling Speed: 8,000 rpm Performance (S3 25%): 5.8 hp (4.3 kW) Torque (S3 25%): 10 ft-lb (13.6 Nm) Tool Magazine: Station Quantity: 72 Holder Type: HSK40 Tool Length (max): 4.1 in (105 mm) Tool Diameter (max): 3.5 in (88 mm) Tool Diameter (max) - Adj Pocket Empty: 3.9 in (100 mm) Size & Electrical: Technical design according to CE standards. Machine Dimensions: 119.3 in (3030 mm) x 111.8 in (2840 mm) x 113.8 in (2890 mm) Machine Weight: 16,976 lbs (7,700 kg) Operating Voltage: 3 x 400V (+/-10%) Main Frequency: 60 Hz (+/- 2%) Electrical connection: TN network (5-wire) Standard Equipment • 72-station tool magazine mounted on top of the machine • Hydraulic spindle brake on spindle 1 • Hydraulic spindle brake on spindle 2 • Spindle rinsing on spindle 1 (switchable between coolant or compressed air) • Spindle rinsing on spindle 2 (switchable between coolant or compressed air) • CNC Clamping Force Setting on Spindle 1 - recommended for convenient setting of clamping force from the CNC program, or on the screen. • CNC Clamping Force Setting on Spindle 2 - recommended for convenient setting of clamping force from the CNC program, or on the screen. • Linear tool slide with coolant supply • Signal lamp • Rear exit chip conveyor - includes feed pump rated at 5 bar at 20l/min or 3.7 bar at 83l/min • High pressure coolant system with additional 61 gallon (230 liter) tank. Maximum 319 psi (22 bar) Ijdpfxjyzkdco Anwjau • Renishaw tool probe for measuring tools in the X/Y/Z axis • Preparation for mist collector unit • Automatic operator door that opens at the end of the program and closes with the start. Includes necessary safety technology. Suitable for manual loading or automation access. • UNIROB universal robot interface via a common plug on the machine control cabinet with the following signals: • Safety signals (emergency stop/door signals, etc.) • Standard signals via Profinet PN bus coupler on RJ45 module. Otherwise according to the Unirob-V2021 functional description CNC Control System

Condition: excellent (used), Year of construction: 2014, Willemin-Macodel SA Model 308B 5 Axis Machining Center Mfd. 2014 X 160 mm Y 120 mm Z 150 mm # Axis 5 Power 7 hp RPM 30,000 RPM # ATC 28 Taper HSK E32 Willemin-Macodel SA Model 308B 5 Axis Machining Center (2014) X1 6.300" Y1 4.720" Z1 5.910" A1 360.000° B1 130.000° Taper HSKE32 Rapid Feeds 1,181ipm Iodpfey Abcxsx Anwjau Equipped With 5 Axis 28 Position ATC 30000 RPM Pallet Recognition Fire Protection Auto Fire Suppression Filter Mist Extraction

Year of construction: 2020, condition: excellent (used), machine/vehicle number: 101262, Porta Solutions MULTICENTER 3 SPINDLE 3 Spindle Machining Center Iajdpfxevn T Das Anweu Mfd. 2020 SN: 101262 Control: Fanuc Panel i Chip Conveyor

Condition: used, Year of construction: 2021, EMAG VMC 450 MT Mfd. 2021 Control: Siemens 840D SL Machine has no production hours Description CHUCK DIAMETER: 24" MAX WEIGHT: 1100 LBS. MAX SWING DIAMETER: 31" MAX TURNING DIAMETER: 23.5" X STROKE: 30" Z STROKE: 19" MAIN DRIVE: POWER: 100 HP FULL POWER AT 800 RPM MAX SPINDLE RPM: 2,000 C AXIS POSITIONIONG TO .01MM ANGULAR DEGREES FEED DRIVE: RAPIDS Z / Z: 60 / 30 M / MIN. FEED FORCE X / Z 4 / 15 kN BALL SCREW DIAMETER X / Z: 40 / 50 MM MILLING SPINDLE: POWER: 100 HP MAX SPINDLE SPEED: 7000 RPM SPINDLE TAPER: CAPTO C8 TOOL MAGAZINE: 60 EQUIPPED WITH: MINERALIT MACHINE BED SIEMENS 840 D SL FULL ENCLOSURE LEVEL PADS TURN MILL DRIVE EMAG WORKPIECE CORRECTION SYSTEM EMAG OPERATING AND SETTINGS MASKS EMAG REMOTE DIAGNOSIS Y AXIS B AXIS +/- 95 DEGREE 1000 PSI COOLANT THROUGH TOOL X-AXI CLAMPING FOR GEAR TOOTH FORMING SWARF CONVEYOR, CHAIN TYPE - REAR DISCHARGE LIFTING PUMP PAPER FILTER LOW PRESSURE COOLANT HIGHT PRESSURE COOLANT 1000 PSI PROGRAMMABLE COOLANT PRESSURE COOLANT MIST EXTRACTOR AIR BLAST CHIP FLUSH QUALITY CONTROL: WIRELESS GAUGING CALIBRATION BLK FOR PROBE Iajdpfoyzkdvsx Anweu TOOL GAUGING - BLUM LASER

Condition: excellent (used), Year of construction: 2007, functionality: fully functional, travel distance X-axis: 1,250 mm, travel distance Y-axis: 660 mm, travel distance Z-axis: 540 mm, rapid traverse X-axis: 40 m/min, rapid traverse Y-axis: 40 m/min, rapid traverse Z-axis: 32 m/min, feed rate X-axis: 32 m/min, feed rate Y-axis: 32 m/min, feed rate Z-axis: 32 m/min, controller manufacturer: Okuma, controller model: OSP P200M-H, rotary table diameter: 500 mm, Equipment: chip conveyor, documentation/manual, rotational speed infinitely variable, Okuma MU500VA CNC Vertical Machining Centre (2007) Equipped with OKUMA OSP P200M-H CNC CONTROL 20" ROTARY PLATEN 4TH AND 5TH AXIS BUILT IN TRUNION 32 POSITION AUTOMATIC TOOL CHANGER COOLANT THRU SPINDLE TOOL LENGTH MEASURING Iasdpfx Aeyf Ncqsnweu Travels X-axis (saddle left/right) – 1250mm, Y-axis (pallet front/back) – 660mm, Z-axis (spindle up/down) – 540mm, A-axis – +20~-110 deg., C-axis – 360 deg., Table surface to spindle nose – 127~667mm Table Table size – ø500mm, Max work size – ø730xh500, Floor to table top – 1073mm, Max load capacity – 500kg Spindle Spindle speed – 15000rpm, Turning specification – C-axis table 1000rpm , No. of spindle ranges – Infinitely variable, Tapered bore – 7/24 taper No.40, Bearing dia – ø70mm Feed Rapid traverse – X-Y: 40m/min, Z:32m/min, Rapid traverse (A-C) – 18,000 deg/min, Cutting feed rate – X-Y-Z: 32m/min Motors Spindle (10min/cont) – 11/7.5kW ATC Tool shank type – MAS BT40 Big plus, Retention knob type – MAS 2, Tool capacity – 32, Max. tool dia (w/ adjacent tool) – ø90mm, Max. tool dia (w/o adjacent tool) – ø125mm, Max. tool length – 400mm, Max. tool mass – 8kg, Tool selection – Memory random ATC Retention knob type – MAS 2, Tool capacity – 32, Max. tool dia (w/ adjacent tool) – ø90mm, Max. tool dia (w/o adjacent tool) – ø125mm, Max. tool length – 400mm, Max. tool mass – 8kg, Tool selection – Memory random

Condition: excellent (used), Year of construction: 2007, machine/vehicle number: 126937, functionality: fully functional, travel distance X-axis: 762 mm, travel distance Y-axis: 460 mm, travel distance Z-axis: 460 mm, number of slots in tool magazine: 32, controller manufacturer: Okuma, controller model: P200M-H, rotary table diameter: 400 mm, OKUMA MU-400VA 5-AXIS CNC VERTICAL MACHINING CENTER, FROM AEROSPACE COMPANY, 16" ROTARY PLATEN, 4TH AND 5TH AXIS BUILD IN TRUNION, 15,000 RPM 32 POSITION TOOL CHANGER, OSP P200M-H CNC CONTROL Okuma MU400VA CNC Vertical Machining Centre (2007) Description: Control OSP P200 Iaedeu Illajpfx Anwou Table working surface - 15.75", Max table load - 600lbs, X Axis travel - 30", Y Axis travel - 18.11", Z Axis travel - 18.11", A Axis trunnion tilt - +20 to -110deg, B Axis table rotation - 360deg, Table surface to spindle nose - 3.94" - 22.05", Rapids X & Y - 15.75 IPM, Spindle taper - CAT 40, Spindle speeds - 16000 RPM, Spindle Motor - 20HP, Tool magazine capacity - 32 Table Size 15.75" Dia Table Load Capacity 660 LBS # Axis 5 X-Axis (Longitudinal Travel) 30" Y-Axis (Cross Travel) 18.11" Z-Axis (Vertical Travel) 18.11" A-Axis (Trunnion Tilt Range) (±25°) +20° to -110° C-Axis Table Rotation Positioning 360,000° Max/Min Clearance Table Top to Spindle Nose 22.05" / 3.94" Distance Floor to Table Top 41.34" Rapid Traverse Rate (X, Y, & Z Axis) 1,574 IPM Spindle Horsepower 20 HP Max Spindle Speed 15,000 RPM Spindle Taper MAS BT40 Big plus Coolant Thru Spindle yes Automatic Tool Changer Capacity (ATC) 32 Electrics 220/3/60 Approximate Machine Dimensions 114" x 160" Approximate Machine Height 116" Approximate Machine Weight 17,000 LBS OKUMA OSP P200M-H CNC CONTROL BUILT IN 4TH AND 5TH AXIS 16" DIAMETER TRUNION TABLE 15,000 RPM SPINDLE LASER TOOL SETTER 32 POSITION AUTOMATIC TOOL CHANGER COOLANT THRU SPINDLE CHIP CONVEYOR

Condition: used, Year of construction: 2013, 2013 SMC Group Routech Accord 30FX CNC machining center, high performance multi-function work table, 400V, 3 phase, X-axis 20' 10", Y-axis 5' 4.7", dual machining heads, rotation speed 6-18,000 RPM, onboard Rapid 12-tool changer, Rapid 16 rear tool changer, work table, pod, and rail, gantry type, has SMC Group CNC control with remote pendant control, 480V, 3 phase, Becker, model 271407, rotary vane vacuum pump, and (1) Texa, model SAW50RBSBCC000, chilling unit with transformer, winning bidder responsible for proper removal. Iasdpfexdc T Sex Anweu
