Used Microcut Universal Machining Center for sale (73,133)

Condition: used, Year of construction: 2019, functionality: fully functional, Control System (Standard) - HEIDENHAIN TNC-640 HSCI control unit with software option 1&2 (see control system options), DCM collision protection function - 5-axis simultaneous operation - Block processing time 0.5 sec. - NC memory capacity 21 GB on SSDR memory card Iedpfx Aezwxicjcpobc - USB interface - Ethernet network interface - 1024-block look-ahead function - 3D tool length compensation function - DCM (Dynamic Collision Monitoring) - TSC (Spindle Thermo-Compensation) - Tool center point control (TCPC) - smarT.NC (alternative operating mode for dialog and plain text programming in a mix, particularly suitable for beginners) Linear axes: - Travel ranges X/Y/Z: 600/600/500 mm Linear roller guides: - Manufacturer: INA - Size: 45x45 mm Linear axis accuracy: - Manufacturer: HEIDENHAIN length measuring systems - Resolution linear glass scale: 0.0001 mm - Positioning accuracy X/Y/Z axis: 0.005 mm - Repeatability X/Y/Z axis: ±0.0025 mm Rotary axis accuracy: - High-precision angle encoder for A- and C-axis - A-axis positioning accuracy: ± 30" - C-axis positioning accuracy: ± 5" Ball screw (oil-lubricated): - Manufacturer: INA - Pitch: 12 mm - Max. speed X/Y/Z axis: 36,000 mm/min Swivel and rotary axis: - Swivel axis (A): - Swivel range: +120° / -120° - Drive: Worm gear (optional: direct drive) - Brake: hydraulic (1,200 Nm / 50 bar) - Speed: 16.6 min-1 - Rotary axis (C): - Rotation angle: 360° (0.001° increments) - Drive: Direct drive (torque motor) - Brake: hydraulic (2,900 Nm / 50 bar) - Speed: 90 min-1 Swivel and rotary table: - Table diameter: Ø500 x 420 mm - Max. table load: 600 kg - Max. load height: 430 mm - T-slots (number / size / slot spacing): 7 x 14 mm x 75 mm Spindle: - Manufacturer: ROYAL Precision Tools Corporation - Drive type: direct - Spindle motor / SIEMENS motor 1PH8133 - Power S1/S6 (40%): 25/35 kW - Max. torque S1/S6 (40%): 134/261 Nm - Max. speed 15,000 min-1 - Spindle taper: DIN SK-40 / MAS BBT-40 (Option: HSK-A63) - Spindle oil cooler Coolant management: - External coolant supply around the spindle nose - Internal coolant supply through the spindle 20 bar with cartridge filter 40 µm, pumps adapted in the coolant tank - Number of magazine positions: 30 (optional: chain with 32, 48, or 60) - Magazine type: Carousel / Fixed position, coded - with tool change arm (double gripper) - Max. tool length: 300 mm - Max. tool diameter: Ø78 mm - Max. tool diameter: Ø120 mm with locked neighboring positions - Max. tool weight: 7 kg Chip management: - Hinged band chip conveyor Other standard equipment features: - Automatic central lubrication - High-pressure chip flushing / chip shower - Coolant gun - Control cabinet air conditioning - Coolant flushing gun - Work area lighting - 3-color warning light (cycle active / completed / alarm message) - Hand tool kit, leveling bolts, nuts, shims - EMC and safety modules for CE compliance - Portable, electronic handwheel - CE compliant with European directives - Hydraulic and pneumatic supply prepared through the table (3x 80 bar hydraulic and 1x 6 bar pneumatic connection). - Oil skimmer

Condition: like new (used), Year of construction: 2024, functionality: fully functional, machine/vehicle number: 1786, travel distance X-axis: 3,000 mm, travel distance Y-axis: 825 mm, travel distance Z-axis: 1,100 mm, rapid traverse X-axis: 30 m/min, rapid traverse Y-axis: 30 m/min, rapid traverse Z-axis: 30 m/min, controller manufacturer: Siemens, controller model: Sinumerik One, table load: 1,500 kg, rotary table diameter: 800 mm, rotational speed (min.): 25 rpm, spindle speed (min.): 20 rpm, spindle speed (max.): 15,000 rpm, coolant supply: 20 bar, number of spindles: 1, tool length: 460 mm, tool diameter: 200 mm, tool weight: 10,000 g, input voltage: 400 V, Equipment: chip conveyor, documentation/manual, rotational speed infinitely variable, MATEC-30HV X = 3,000 mm Y = 825 mm Z = 1,100 mm / Horizontal Z = 975 mm / Vertical - 1-axis CNC swivel head Swivel radius 300 mm, maximum swivel angle +/- 105 degrees Direct path measuring system +/-3, optionally continuous or settable with clamping Clamping forces: 2,400 Nm unclamped, 4,200 Nm clamped Isdjxg Dhcopfx Acpebc - Bellows with steel lamellae - Direct path measuring system on X, Y, Z axis - Chip conveyor - Rinsing gun - Centralized oil lubrication - Work area lighting - Siemens Sinumerik ONE control Modern CNC system for highly productive machine tools, consisting of: NCU 1740 22" ITC2200 V3 display MCP 2200 machine control panel - Electronic handwheel (portable) HT2 - Telephone diagnostics / remote maintenance - Motor spindle 15,000 rpm Motor spindle with 30 kW (40% duty cycle) 17 kW (100% duty cycle) Torque 191 Nm (40% duty cycle) 108 Nm (100% duty cycle) - Internal coolant supply 20 bar Tank capacity of paper filter system 900 l Filter capacity 160 l/min. - High-pressure coolant at external nozzles High-pressure coolant pump switchable via M-function in the part program to the external nozzles at the spindle head. #20 bar# - IK-compressed air through the tool - Partition wall for double-station system - 3D wireless probe - RTS table probe for measuring and inspection - UT-Tec collision monitoring - Automatic safety doors

Condition: ready for operation (used), Year of construction: 2023, operating hours: 362 h, functionality: fully functional, machine/vehicle number: 12430021383, travel distance X-axis: 750 mm, travel distance Y-axis: 650 mm, travel distance Z-axis: 560 mm, controller model: Siemens 840D sl Operate, spindle speed (max.): 20,000 rpm, Auction of a DMG DMU 75 Monoblock + Pallet Handling PH150! Only 362 spindle hours! TECHNICAL DETAILS Travel in X-axis: 750 mm Travel in Y-axis: 650 mm Travel in Z-axis: 560 mm Main drive and spindle Main drive: AC motor, digitally controlled Motor spindle: speedMASTER Warranty period of the motor spindle: 36 months Speed range: max. 20,000 rpm Spindle mount: HSK-A 63 Acceleration time: approx. 2.6 s Deceleration time: approx. 2.6 s Drive power at 40% duty cycle: 35 kW Drive power at 100% duty cycle: 25 kW Spindle torque at 40% duty cycle: 130 Nm Spindle torque at 100% duty cycle: 86 Nm Spindle bearing inner diameter (front): 80 mm Spindle bearing inner diameter (rear): 55 mm Number of T-slots: 4 × 14 H12 T-slot spacing: 63 mm Centering bore: 50 mm Thread: 8 × M12 Tilting axis A Tilting angle towards the working spindle: +120° Tilting angle away from the working spindle: −120° Torque of tilting axis: 3,400 Nm Holding torque of tilting axis: 3,400 Nm Holding torque of tilting axis with hydraulic clamping: 6,200 Nm Rapid traverse of tilting axis: 40 rpm Feed rate of tilting axis: 20 rpm Input and display resolution: 0.001° Bidirectional accuracy of tilting axis A: A ≤ 9 arc seconds Permissible moment of inertia of tilting axis: max. 59 kg·m² Rotary axis C Rotary range of C-axis: 360° Torque of rotary axis: 2,000 Nm Holding torque of rotary axis: 2,000 Nm Ibodpez I Tcijfx Acpec Feed rate of rotary axis: 7,200°/min Bidirectional accuracy of rotary axis C: A ≤ 7 arc seconds Table load: max. 600 kg Permissible moment of inertia of rotary axis: max. 48 kg·m² Workpiece diameter: max. 840 mm Machinable diameter: 650 mm Workpiece height: 500 mm MACHINE DETAILS Control system: Siemens 840D sl Operate Cooling system: Liquid cooling Lubrication: Oil-air lubrication Operating hours Power-on hours (according to counter): 1,166 h Spindle hours (according to counter): 362 h Further technical data can be found in the attached offers.

Condition: excellent (used), Year of construction: 2014, operating hours: 11,440 h, DMG 5 axis Simultaneous HSC 30 Linear Year 2014 Heidenhian TNC640 Control Travel X320 / Y 300 / Z280mm B axis +/- 120 degree C axis 360 x 0.001 degree HSK-E40, 40,000rpm Swivel rotary table Touch Probe BLUM Tool Measuring system 3D Quick Set Application Tuning Cycle Ibodpfew Hxiwjx Acpoc Air Blast through spindle Super Fine filter system c/w tooling ----- Clearance Sales -----

Condition: like new (used), Year of construction: 2015, operating hours: 1,000 h, functionality: fully functional, Equipment: documentation/manual, DMG MORI / SAUER GmbH ULTRASONIC 20 Machine Data Control system Heidenhain Axes 5 (X / Y / Z / A / C) Travel ranges X / Y / Z 200 / 200 / 280 mm Spindle speed max. 42,000 rpm Tool holder HSK-E32 Tool magazine 24 Rotary table Ø 190 mm Table load capacity, center 10 kg A-axis -5° / +130° C-axis 360° Rapid traverse 40 m/min Footprint L × W × H 2,020 × 2,196 × 2,385 mm Fuse rating 63 A Feed drive X / Y / Z Synchronous linear motors Feed rate max. 40,000 mm/min Input resolution 0.001 mm C-axis speed max. 150 rpm Table clamping Pneumatic / mechanical Tool length max., from spindle nose 200 mm Tool diameter max., automatic tool changer 40 mm Compressed air supply 6–10 bar Air consumption without tool blowing 12 m³/h Additional consumption with continuous tool blowing 25 m³/h Connection, weight, and dimensions Electrical connection 400 V / 50–60 Hz Machine weight 3,900 kg Tool weight max., automatic tool changer 1 kg Total weight of magazine tools max. 24 kg Compressed air connection min. Ø 12 mm Equipment and scope of supply Iodoz Tc Tvjpfx Acpobc 15 tool holders and other related accessories as shown in the offer photos are included. Technical data is subject to change without notice. Errors and prior sale are reserved. The specifications and scope of supply agreed upon in the purchase contract shall be the basis.

Condition: excellent (used), Year of construction: 2008, functionality: fully functional, machine/vehicle number: 86966, travel distance X-axis: 2,600 mm, travel distance Y-axis: 700 mm, travel distance Z-axis: 800 mm, controller model: Siemens 840D, total height: 3,850 mm, total length: 8,350 mm, total width: 4,200 mm, overall weight: 35,000 kg, spindle speed (min.): 30 rpm, spindle speed (max.): 4,000 rpm, spindle motor power: 57 W, spindle nose: SK50, number of slots in tool magazine: 30, Equipment: chip conveyor, documentation/manual, For sale is an AXA VHC50-2600 XTS, including a KUKA robotic system with conveyor belts (partial sale possible). Iodpsz S T Rcefx Acpsbc An spare parts package worth approximately €180,000 is also included. The price is including delivery to your location – within Germany. For more detailed technical specifications, please see the attached documents. An inspection can be arranged at any time. Installation and recommissioning can also be organized.

Condition: excellent (used), Year of construction: 2017, functionality: fully functional, Equipment: documentation/manual, We offer you: Manufacturer: Chiron Type: FZ08 MT Precision+ high speed plus Year of manufacture: 2017 Control system: Fanuc 31i-B5 Technical data: Travel ranges: X-axis: 210 mm Y-axis: 200 mm Z-axis: 360 mm B-axis: -10° to +100° C-axis: 360° Main spindle: Speed range – main spindle: max. 54,000 rpm Drive power – main spindle (100/25%): 3.5 / 5.2 kW Torque: max. 2 Nm Turning spindle: Max. bar diameter: 32 mm Speed range: 15 – 8,000 rpm Drive power (100/15%): 9 / 12 kW Torque: max. 14.3 Nm NC 2-axis swiveling unit: Swiveling angle: -60° to +180° NC rotary table diameter: 170 mm Tool changer: Tool holder: HSK-E 32 Number of tool positions: 40 Max. tool diameter: 45 / 100 mm Max. tool length: 200 mm Max. tool weight: 1.2 kg Tool change time: approx. 0.8 sec Chip-to-chip time: approx. 2.5 sec Feed rates: Rapid traverse (x/y/z): 75 m/min Operating hours: approx. 37,280 h Spindle hours: approx. 11,360 h Please refer to the PDF in the attachment for technical features and accessories. Ibedpfxsz I U D Us Acpjc Accessories, tools shown in the images, and clamping devices are only included in the scope of delivery if this is noted in the additional information. Subject to change and errors in technical data and specifications, as well as prior sale!

Condition: used, Year of construction: 1990, operating hours: 70,042 h, functionality: fully functional, machine/vehicle number: 120035, travel distance X-axis: 1,200 mm, travel distance Y-axis: 600 mm, travel distance Z-axis: 600 mm, total height: 2,645 mm, total length: 3,560 mm, total width: 2,840 mm, overall weight: 11,000 kg, Equipment: chip conveyor, Control system: 432, software version 700 (4th axis = rotary table) 60-position tool changer (tool length/diameter/weight = 315 mm/125 mm/10 kg) Clamping surface of the CNC rotary table: D1000 x 820 mm Table load capacity: 1000 kg Travel distance, longitudinal (X-axis): 1200 mm Travel distance, transverse (Z-axis): 600 mm Travel distance, vertical (Y-axis): 600 mm Spindle mount: ISO40 Spindle speed, continuously variable in 2 ranges: 20-6300 rpm Feed rates, X, Y, and Z axes: 1-4000 mm/min Rapid traverse, X and Z axes: 12 m/min Ibodpjz Ngqqjfx Acpec Rapid traverse, Y axis: 10 m/min Feed rate, rotary table movement (B-axis): 1-1500 °/min Rapid traverse, rotary table movement: 10 rpm Spindle drive: 15 kW Total connected load: 40 kVA Weight, approx.: 11000 kg Space requirement, approx. (L x W x H): 3560 x 2840 x 2645 mm Technical data subject to change without notice. Errors and prior sale excepted.

Condition: ready for operation (used), Year of construction: 2017, functionality: fully functional, machine/vehicle number: 172822005, travel distance X-axis: 600 mm, travel distance Y-axis: 500 mm, travel distance Z-axis: 500 mm, controller model: Heidenhain TNC530i, spindle speed (max.): 18,000 rpm, TECHNICAL DETAILS Travel range, X-axis: 600 mm Travel range, Y-axis: 500 mm Travel range, Z-axis: 500 mm Swivel axis A: ±120° Rotary axis C: 360° Rotary table diameter: 500 mm Spindle speed (max.): 18,000 rpm Rapid traverse rate, X-axis: 36 m/min Rapid traverse rate, Y-axis: 36 m/min Rapid traverse rate, Z-axis: 36 m/min Number of tool slots in the tool magazine: 24 Positioning accuracy: 0.01 / 300 mm Repeatability: ±0.01 mm MACHINE DETAILS Control system: Heidenhain TNC530i Coolant supply: 20 bar Dimensions & Weight Dimensions (L x W x H): 3,015 x 5,050 x 3,000 mm Total weight: 9,000 kg Type of input current: Three-phase Power: 60 kVA Ibsdpjy S Ua Nsfx Acpoc Frequency: 50 Hz Rated voltage: 400 V Number of phases: 3 + PE Rated current at full load: 100 A Short-circuit strength: 25 kA Maximum load current: 200 A Fuse protection / rated current: 80 A Operating hours Spindle hours: 6,940 h Program runtime: 7,686 h Machine operating hours: 17,193 h Control system operating hours: 19,880 h EQUIPMENT Chip conveyor

Condition: excellent (used), Year of construction: 2016, operating hours: 12,158 h, functionality: fully functional, machine/vehicle number: UT 0871, spindle speed (max.): 12,000 rpm, spindle nose: SK 40, number of slots in tool magazine: 32, 5-axis machining center Iodpfxjz N Ipuo Acpobc

Condition: good (used), Year of construction: 2004, functionality: fully functional, Universal machining centre Deckel Maho DMU 50 M with Heidenhain TNC 310 CNC control. Swivel-rotary table, SK 40 spindle taper with hydraulic drawbar. In good working condition, can be inspected under power. Iodpfxeytpy Ee Acpebc

Condition: good (used), Year of construction: 1998, CNC milling machine Deckel Maho DMU 80 T Control system: Heidenhain TNC426 Spindle speed: 20-6300 rpm Feed rate x, y, z: 20-10000 mm/min Rapid traverse rate x, y, z: 15000 mm/min Work area: x 800 mm, y 650 mm, z 550 mm Tool holder: SK40 DIN 2079 Clamping bolt DIN 69 872 Tool changer: 25 positions Isdpsz Suqqjfx Acpsbc Max. tool diameter 160 mm Max. overhang length from the spindle nose 315 mm Work table: Dimensions 1100 x 600 mm T-slots 9 x M14 Permissible weight 500 kg Transport data: Weight 5800 kg Dimensions (length x width x height) 3.05 x 2.40 x 2.45 m

Condition: used, Year of construction: 2002, operating hours: 41,612 h, DMG DMU 60 T CNC Universal Milling Machine Ibsdoz Ih Erjpfx Acpec For sale is a DMG DMU 60 T universal milling machine in fully functional condition. The machine operates without any errors and is being sold solely due to the purchase of a new machine. Technical specifications: Travel in X-axis: 630 mm Travel in Y-axis: 560 mm Travel in Z-axis: 560 mm B-axis: -90° to +12° Spindle speed: up to 12,000 rpm Tool holder: SK40 Tool changer: 2 x 12 positions / total of 24 tool positions Spindle hours: approx. 12,700 hours Control system: Heidenhain MillPlus, V420–V500 Equipment: Chip conveyor Internal coolant system Cleaning gun Coolant tank on wheels Automatic tool changer with 24 positions Condition: The machine is in operational condition and is currently running without any known errors or malfunctions. A test run or on-site inspection while the machine is powered on is possible upon agreement. Year of manufacture 2002, 41612 spindle hours, 12789 machine operating hours. Reason for sale: Purchase of a new machine.

Condition: ready for operation (used), Year of construction: 2013, operating hours: 7,358 h, functionality: fully functional, machine/vehicle number: 6LUD00036, travel distance X-axis: 620 mm, travel distance Y-axis: 520 mm, travel distance Z-axis: 460 mm, feed length X-axis: 620 mm, feed length Y-axis: 620 mm, feed length Z-axis: 460 mm, feed rate X-axis: 36,000 m/min, feed rate Y-axis: 36,000 m/min, feed rate Z-axis: 36,000 m/min, torque: 108 Nm, controller manufacturer: Heidenhain, controller model: iTNC530, workpiece length (max.): 500 mm, workpiece width (max.): 400 mm, workpiece height (max.): 350 mm, workpiece diameter (max.): 680 mm, workpiece weight (max.): 300 kg, total height: 3,400 mm, total length: 4,600 mm, total width: 2,700 mm, table width: 600 mm, table height: 755 mm, table length: 600 mm, table load: 300 kg, rotary table diameter: 600 mm, rotational speed (min.): 20 rpm, rotational speed (max.): 12,000 rpm, overall weight: 8,500 kg, spindle speed (min.): 20 rpm, spindle speed (max.): 12,000 rpm, operating hours of spindle: 5,303 h, coolant supply: 18 bar, distance table center to spindle nose: 50 mm, spindle motor power: 17,000 W, spindle nose: SK40, number of spindles: 1, number of slots in tool magazine: 100, input voltage: 400 V, type of input current: three-phase, Equipment: chip conveyor, documentation/manual, Commissioned 4/2014 Table rotation, C-axis: 360° Table swivel, B-axis: -50° to +110° Distance from spindle nose to table: 150 mm Table clamping surface: Ø 650 Table load capacity, max.: 300 kg Table slots: 5 x 18H7 x 100 mm Centering bore: Ø 50 H7 x 30 mm Workpiece size, max.: Ø 520 x 330 mm Machine accuracy: VDI I DGQ 3441* Positioning accuracy: +/- 0.006 mm* Axis resolution: 0.001 mm* *determined at a constant ambient temperature of 20°C +/- 1°C Main spindle: Main drive, AC motor, direct drive Drive power (100% / 25% ED): 10.0 / 17.0 kW Speed range, stepless: 20 - 12000 rpm Spindle taper: SK 40 DIN 69871 Torque at (100% / ED): 63.7 / 108.6 Nm Axis drives: Axes X, Y, Z: AC motors Axes B, C: AC motors Travel speeds: Rapid traverse in axes X, Y, Z: 36 m/min Speed, max. B-axis: 25 rpm Speed, max. C-axis: 25 rpm Acceleration X, Y, Z: 6.5 m/s² Coolant system: External tool cooling via external nozzles Coolant tank: 280 l Operating pressure, external: 0.9 bar Coolant system, internal tool cooling DIN 69871 Form A Operating pressure, internal coolant supply: 18.0 bar Manual rinsing of the work area via an additional gun Standard accessories: - CNC control: Heidenhain iTNC 530, full simultaneous 5-axis version - Handwheel 410 (Heidenhain) - Digital axis drives - Digital spindle drive - Swarf conveyor with discharge height 800 mm • Spindle cooling – radiators – plate cooling for spindle motor - Full protective enclosure with cabin roof Tool magazine VZG 65 5A by Indunorm: Number of tools: 100, with a tool length of up to 320 mm / can be converted to 125 tools, then a tool length of only 200 mm is possible. Tool diameter, max.: 80 mm Tool diameter, max.: 130 mm (with free adjacent positions) Tool change with double gripper - Linear path measuring system in axes X / Y / Z (glass scale) - Direct encoder in axes B / C - Temperature compensation - IR measuring probe – 3D Software - Option - iTNC 530 Kinematic-Opt • Calibration software Internal tool cooling 18 bar • Coolant tank • Internal tool cooling: 280 L DIN 69871 Form A • Double-circuit filter • Switchable filter cartridges • Filtration rate: 10 µm Band filter system PRODUCTION - LINE - RT 100 Automatic pallet changing system Loading and unloading via a linear axis system: Handling data: Handling weight, max.: 100 kg (35 kg) Pallet capacity: 6 pallet positions up to 400 x 400 mm: Control: Ibsdsz Diq Uopfx Acpsc PLC control with integrated control cabinet incl. switching and control components incl. software for the automatic sequence Zero point clamping system 320 x 320 x 60 mm - Clamping via 4 clamping bolts - Axis distance: 180 mm - Clamping force: 4 x 12500 N - Repeatability: 0.005 mm - Axial load, max.: 4000 kg • Zero point clamping plate 320 x 320 - Automatic door Interface for automation and clamping systems Universal interface for automatic pallet changing systems, force clamping devices and zero point clamping systems • for pneumatic clamping systems • 2-channel rotary feedthrough integrated in the table • Pneumatic lines led to the outside • Pneumatic maintenance unit • Control via M commands logical inputs and outputs prepared incl. 7 pallets 320x320 with 6 vices and one 3-jaw chuck !!without tool holders and without tools!! Machine ex works, without delivery and assembly, all information without guarantee, price plus statutory value-added tax.

Condition: excellent (used), Year of construction: 2020, Traverses X Y Z: 500 x 450 x 400mm, Table size 500 x 630mm, C axis 360, B Axis -5 / +110°, maximum workpiece diameter 630mm, maximum workpiece height 550mm table load 200kgs, Spindle taper BT40, 19kW Spindle Motor, Spindle Speed 12,000rpm, Heidenhain Control, 30 Station ATC, spindle probe, Swarf conveyor, through spindle coolant Ibodpfx Acjz R Nv Hopec

Condition: used, Year of construction: 2001, Manufacturer: DECKEL MAHO (DMG) Model: DMU 70 VL Year of Manufacture: 2001 Control Unit: HEIDENHAIN TNC 430 Machine Type: 5-Axis Universal Machining Center Working Range / Travels: X-axis: 710 mm Y-axis: 520 mm Z-axis: 520 mm B-axis (Swivel range): -10° / +95° (NC-controlled) C-axis (Rotary table): 360° (NC-controlled) Work Table: Table Type: NC Swivel-Rotary Table Clamping Surface: Ø 700 x 500 mm Max. Table Load: 350 kg Milling Spindle: Max. Spindle Speed: 12,000 RPM (Motor Spindle) Drive Power (40% / 100% ED): 15 kW / 10 kW Tool Taper: SK 40 (DIN 69871) Tool Changer: Magazine Positions: 30 slots Max. Tool Diameter: 80 mm / 160 mm (with empty adjacent pockets) Max. Tool Length: 315 mm Max. Tool Weight: 6 kg Feed Rates & Motion: Rapid Traverse (X/Y/Z): 30 m/min Max. Feed Rate: 20,000 mm/min Weight & Footprint: Machine Weight: approx. 5,500 kg Total Power Requirement: 40 kVA Space Requirements: approx. 4.0 m x 3.0 m x 2.8 m Equipment & Features: High-End Control: Heidenhain TNC 430 5-Axis Capability: Full NC swivel/rotary integration. Ijdpfx Aeyh Nm Socpobc

Condition: ready for operation (used), Year of construction: 1998, Available for immediate pickup at our location: Vertical machining center ZPS Depo Type MCTV 1060 NT Year of manufacture 1998 Heidenhain iTNC 426 M Table 1270 x 590 mm Travel distances X/Y/Z 1016/610/760 mm SK 50 Iedpfjz Ixq Esx Acpebc Spindle speeds up to 8000 rpm Table load max. 900 kg Drive power 11 kW Tool changer, 24 positions Distance spindle – table 80 – 840 mm Weight 6700 kg Price: Euro 4,000.00 plus VAT, pickup at our location.

Condition: used, Year of construction: 1986, BAZ Axa VSC1 3000, year of manufacture 1986 Ibjdpfx Aexurgiscpec

Condition: not inspected (used), Year of construction: 1986, travel distance X-axis: 850 mm, travel distance Y-axis: 700 mm, travel distance Z-axis: 600 mm, overall weight: 6,000 kg, Heidenhain TNC 426 900x700 mm universal table Ibsdpfxeyt Nxue Acpoc Travel: 850x700x600 mm Max spindle speed: 6000 rpm Weight: 6000 kg

Condition: used, Year of construction: 2017, Control Heidenhain TNC 640 x-travel 600 mm y-travel 450 mm z-travel 450 mm b-axis ° c-axis 360 ° Ibjdpfx Aoz Ic Afecpoc spindle tunring speed 20.000 U/min Drive power at S1/S6 (40% duty cycle) 23/36 kW Torque at S1/S6 (40% duty cycle) 77/120 Nm tool taper HSK-A63 number of tool places 170 Pos. tool changing time

Condition: good (used), Year of construction: 2011, functionality: fully functional, controller manufacturer: Heidenhain, overall weight: 8,400 kg, number of slots in tool magazine: 30, Equipment: chip conveyor, documentation/manual, Wemas VZG 65A Year of manufacture: 2011 Heidenhain iTNC 530 control system 30-position tool changer, SK40 Coolant system with strip-type filter Ijdpfxoz Hx N So Acpjbc Chip conveyor

Condition: used, Year of construction: 2014, x-travel 2000 mm Ibedpfx Aceyan Rcepsc y-travel 630 mm z-travel 550 mm Control Siemens 840 D total power requirement 7,5 - 22,5 kW weight of the machine ca. 10,5 t Maximum table load:1,000 kg / m table length Movement range: X-axis:2000 mm Y-axis:630 mm Z-axis:550 mm Speed range up to:12,000 min-1 Maximum speed range:140 Nm Drilling power:average 42 mm (with insert drill) Milling power:600 cm³/min Tool places:24 Tool shaft:HSK A 63 DIN 69893 Tool average:max. 75 mm Tool average with: free neighbouring places:max. 160 mm Tool length:max. 320 mm Tool weight:max. 8 kg (max. magazine load 100 kg Tool change time:approx. 1.5 s (depending on control

Condition: good (used), Year of construction: 2014, Ref. -No.: 10553 Manufacturer: HANDTMANN / BAVIUS Type: HBZ Trunnion 120 Year of construction: 2014 Type of control: CNC-Steuerung Control: Heidenhain TNC 640 Storage location: Halberstadt Country of origin: Germany Machine-No.: 200XXXXX X-Travel: 1270 mm Y-Travel: 1100 mm Z-Travel: 900 mm Table Height: Ø 1200 mm Table Load: 2000 kg Max. Tool Weight: 20 kg Max. Tool Length: 90 x 200 / 24 x 400 mm Ibedpfxezc D Aao Acpoc Max. Tool Diameter: Ø 130 mm Tool Taper: HSK 100 Numbers Of Tools In Magazin: 40 Tool Piece Magazine With: 140 Pcs./pcs. Spindle Turning Speed - Stepless: 14.000 RPM Max. Torque: 15000 Nm Rapid Traverse X-Axis: max. 60 m / min Rapid Travel Y-Axis: max. 60 m / min Rapid Traverse Z-Axis: max. 60 m / min Machine length: 7500 mm Machine width: 5500 mm Machine Height: 3500 mm Weight Of The Machine Ca.: 26 t Rapid traverse C-axis: max. 25 RPM Rapid traverse A-axis: max. 20 RPM A-axis (swivel axis): - 30 / + 120 ° C-axis (rotary table axis): 360 ° Further information: - Horizontal machine, Y-axis arranged vertically - Machine stand designed as a welded construction - set up on height-adjustable precision wedge shoes, chip tray with cooling lubricant device, for external splash water cooling capacity: approx. 400 liters, with clean water pump, LP circuit, approx. 40 1/min at approx. 5 bar and rinsing nozzles on the Z-axis and/or the spindle - Complete safety housing - Stainless steel interior lining - Work area lighting - Manual loading door to the work area with polycarbonate safety window with glass front panel - Side viewing window to the work area with polycarbonate safety pane with glass front pane - Maintenance area freely accessible - HSK 100 hollow shank taper - Tool clamping via springs, tool release hydraulically - Tool clamping control - Cone cleaning - incl. spindle orientation The machine can be viewed under power by arrangement.

Condition: excellent (used), Year of construction: 2011, operating hours: 4,450 h, functionality: fully functional, travel distance X-axis: 500 mm, travel distance Y-axis: 240 mm, travel distance Z-axis: 360 mm, feed rate X-axis: 60 m/min, feed rate Y-axis: 60 m/min, feed rate Z-axis: 60 m/min, controller manufacturer: Heidenhain, controller model: iTNC530i, table load: 25 kg, rotational speed (min.): 250 rpm, spindle speed (max.): 42,000 rpm, operating hours of spindle: 4,400 h, coolant supply: 4 bar, number of spindles: 1, number of slots in tool magazine: 66, input voltage: 400 V, type of input current: three-phase, Equipment: chip conveyor, documentation/manual, HSC milling machine HSM 400 U LP Milling spindle Steptec 42,000 rpm, 2 years old ITC & ITCX 5-axis thermal control Heidenhain TNC 530i control system Tool magazine 66X HSK40E Ibsdpfozzknxex Acpoc Rotary table ITS 148 Minimum quantity lubrication Oil-mist extraction system Chip conveyor, manufacturer Phoenix Metall Water/water heat exchanger Measuring probe, infrared, manufacturer M&H 40.01 TX/RX Pallet magazine, 20 x ITS 148 Coolant and air supply from outside

Condition: good (used), Year of construction: 2021, functionality: fully functional, Matec HV 700, Year of manufacture 2021, Heidenhain TNC 640 control system, Travel range X/Y/Z 2600/700/950 horizontal, Travel range X/Y/Z 2600/700/950 vertical, 50-position tool changer, HSK 63 tool holder, Spindle speed up to 15,000 rpm, NC swivel milling head +/- 105°, Swivel radius 250 mm, Iedjy Thxzspfx Acpsbc NC rotary table Ø 750 mm, IKZ (internal cooling) 20 bar, Paper band filter, Direct measuring systems, Chip conveyor, Electr. handwheel, Dynamics package, Software Kinematics Option, Measuring probe, Partition, S1 approx. 2000 total spindle hours, S2 approx. 25 total spindle hours.
