Used Mikromat 20G for sale (157)

Year of construction: 2016, condition: ready for operation (used), Offered is a high-precision worm and thread grinding machine MIKROMAT 20G, used as a test and trial machine, nearly all available options included, technically flawless condition. Capabilities: external thread grinding, internal thread grinding, whirling Whirling, grinding length max. 2000mm, workpiece diameter max. 320mm, distance between centers: 2250mm NC tailstock option: 2050mm, workpiece weight max. 200kg 350kg NC tailstock, pitch range: 0-400mm, 7-axis system, feed speed: up to 15000mm/min, setting angle: +/-40°, positioning accuracy: uncertainty 0.0024mm P, upgrade to 23.5kW continuous power/45kW maximum power, grinding wheel speed: up to 50m/s, special equipment internal grinding: internal thread diameter up to 100mm, length up to 50mm, coolant system: KNOLL compact unit vacuum rotary filter, 2500l tank volume and oil cooling, installation dimensions X/Y/Z: approx. 6500mm/4000mm/3000mm, total weight: approx. 13000kg, inspection possible by arrangement. Gbedpfxeylbr De Aagsn

Condition: used, Year of construction: 1986, Technical details: turning diameter over bed: 315 mm turning diameter over support: 200 mm Gbjdpfx Aaou Ix Hqegjn turning length: 500 mm turning diameter over bed: 315 mm swing diameter over face slide: 200 mm center height measured in bed: 180 mm spindle passage: Ø 32 mm range of revolution per miute: 56...2.800 / nur only 6 step links-rechts U/min range of feed in x - axis: längs: 0,02..0,8 m/min range of feed in y - axis: plan: 0,01..0,4 m/min tailstock quill taper MT: MK 4 tailstock quill adjustment:: 140 mm total power requirement: 5,5 kW weight of the machine ca.: 2,0 t dimension machine xH: 2,1x 1,1 x 1,4 m -Workpiece pick-up via collet chuck -travels longitudinal slide= 580mm and cross slide=170mm -incl. tooling device lathe support -incl. change gears -steady rest Ø 100mm -fourfold tool holder The machines functionality is limited ! 6 speeds are currently selectable! (224/1800 ; 280/2240; 355/2800 rpm.) i.D. *

Condition: used, Technical details: turning diameter over bed: 350 mm turning diameter over support: 200 mm turning length: 560 mm centre height: 170 mm spindle bore: Ø 32 mm range of revolution per miute: 36...1.800 / 8 step U/min range of feed in x - axis: längs: 0,02..0,8 m/min range of feed in y - axis: plan: 0,01..0,4 m/min tailstock quill taper MT: MK 4 tailstock quill adjustment:: 140 mm Gedpfsvadd Isx Aagobn total power requirement: 5,5 kW weight of the machine ca.: 2,0 t dimension machine xH: 2,1x 1,1 x 1,4 m -Working stroke longitudinal support=580mm; plan support=170mm; top support 130mm; -Workpiece support via 3-jaw chuck Niles Ø 160mm, speed 2,800 rpm. -Tool holder quick change steel holder Multifix. Equipment: Cooling water pump 4 pieces machine feet Copying device *

Condition: used, Technical details: z-travel: 400 mm range of revolution per miute: max. 3.000 / steples U/min feed continuous: keine Angaben quill stroke vertical: 100 mm spindle taper: MK2 table surface area: 445 x 315 mm distance table - lower edge spindle: max. 520 mm table travel: längs: 250 mm table travel: quer: 330 mm table height over floor: 920 mm total power requirement: 1,6 kW weight of the machine ca.: 1500 kg Gjdov A S Efepfx Aagjbn machine dimensions LxWxH: 1,3 x 1,1 x 2,0 m Application: Milling and drilling slotted holes There is a precision dial gauge for depth display on the drill spindle head. 5x T-slots to DIN 650: a=10; h=18; b=18; c=8mm Features: Two-way digital ACU-RIDE display *

Condition: used, Year of construction: 1976, Technical details: grinding length: 600 mm grinding width: 200 mm workpiece height: 400 mm table speed: 2 - 18 m/min magnetic plate size: 600 x 200 mm Max. Table-movement horizontal: 700 mm Max. Table-movement across: 230 mm table adjustment: Quervorschub: 0,1 - 2 mm/Hub ° table speed: 2 - 18 m/min Gsdpfx Aeu Ngl Dsagebn dimensions of grinding wheel: max. Ø 200 x 20 x Ø 51 mm grinding spindle speed: 2800 U/min feed of spindle: vertical 0,01 total power requirement: 3,0 kW weight of the machine ca.: 1,0 t dimension machine xH: 1,8 x 1,2 x 1,9 m dimension coolant device LxWxH: 0,8 x 0,4 x 0,2 m Currently there is a grinding wheel size Ø 160 x 18mm on the machine. There is a dressing device (without diamond) on the spindle. Magnetic clamping plate progress type FE 200/600; 220V / 110V coolant tank div. foot blocks Toothed rail 1000mm *

Condition: used, Year of construction: 1974, Technical details: grinding length: 600 mm grinding width: 200 mm workpiece height: 400 mm magnetic plate size: 630 x 200 mm Max. Table-movement horizontal: X-Richtung max. 710 mm Max. Table-movement across: Y-Richtung max, 250 mm table load capacity: 110 /1100N) kp table speed: 1,5 - 18 m/min dimensions of grinding wheel: max. 200 x 20 x Ø 51 mm grinding wheel dimensions:: gespannt: Ø 142 x 20mm grinding spindle speed: 2800 U/min feed of spindle: 0,01 mm Gedpfxju Ngmbs Aagjbn total power requirement: 5,0 kW weight of the machine ca.: 1,0 t dimension machine xH: 1,8 x 1,2 x 1,9 m dimensions: Behälter Absaugung: 420 x Ø 350 x 680 mm The machine was used for dry grinding. -very good condition -without dressing device -dust extraction -machine lamp *

Condition: ready for operation (used), Year of construction: 1998, total height: 4,900 mm, overall weight: 51,000 kg, controller manufacturer: SIEMENS, controller model: SINUMERIK 840D, This 4-axis MIKROMAT 20V gantry milling machine was manufactured in 1998. Ideal for precision milling, it offers robust construction and reliable performance. Consider the opportunity to buy this MIKROMAT 20V gantry milling machine. Contact us for more information. Additional equipment • Automatic Tool Changer: Included / Number of Places in the Magazine: 90 / Max. Tool Diameter: 125 mm (300 mm with free secondary positions) / Max. Tool Length: 450 mm/ Max. Tool Weight: 30 kg /Tool Change Time: Approx. 5 sec • Compressed Air Connection / Air Volume: 6 bar - 5 m³/h / Nominal Voltage: 3 AC 400 V / Control Voltage: DC 24 V / Connected Load: Basic machine 65 kW • Cooling Lubricant Supply and Filter System: Included / Tank Capacity: 1500 l / Pump for External Cooling: Q= 20/40/60 l/min switchable / Pump for Internal Cooling: Q= 35 l/min at 50 bar Work Area Guard with Lighting: Included / Set of Chip Conveyors: Included, with scraper belt type, discharge height 1000 mm Machine Benefits Technical Machine Benefits • Traverse path: x (table): 5200 mm/ y (slide): 3400 mm /z (spindle): 1250 mm Gedpfox D Hcwox Aagobn • Traverse path: x (table): 5200 mm y (slide): 3400 mm /z (spindle): 1250 mm • Max. Feed force (x, y, z): 15 kn • Clamping surface: 2000 x 5000 mm / max. Table load: 100 kn / width / spacing of table grooves: 22 / 160 mm / passage width: 2400 mm / distance between spindle nose and table surface: 500 to 1750 mm • Spindle speeds: 10 to 5000 rpm / max. Power of the spindle motor: 37/46 kw / max. Spindle torque: 1000/1250 nm / spindle head for tool shank: sk 50 • Control type: microprocessor control siemens sinumerik 840d / screen: colour screen 10. 4 inch tft display / number of axes: 3 (x, y, z) • Control system: integrated with various functionalities including spindle orientation, interpolation, and an electronic handwheel • Programming and data transfer: includes comprehensive programming capabilities and data transfer options via the universal interface v24/rs-232 • Accessories: multiple accessories and additional device functionalities included, focusing on enhanced efficiency and safety Dimensions Machine Depth 10500 mm

Year of construction: 1990, condition: ready for operation (used), Workpiece diameter range: 2mm-320mm, max. grinding length: 500mm, center distance: 1000mm, max. workpiece weight: 150kg. On-site inspection is possible. Gedpfx Aajwmqxwegjbn

Condition: excellent (used), Very good surface grinding machine Gjdpfx Aajrbzahsgebn Table surface / working area 200 x 600 mm Technical description as attachment in PDF.

Condition: used, turning length 600 mm turning diameter over bed 360 mm turning diameter over slide rest 190 mm bed width 295 mm number of spindle speeds 45 - 2240 U/min. spindle bore 33,0 mm tailstock quill taper MT MK 3 feed Längs 0,02-0,8 mm/U feed Quer 0,0125-0,5 mm/U total power requirement 5,5 kW weight of the machine ca. 1900 kg Gbjdpoxaamusfx Aagsn range L-W-H 2050 x 950 x 1280 mm Refurbished and repainted in 2013 Costs around 16.000 euros Furnishing: - WNW NILES 3-jaw chuck Ø 200 mm - Multifix steel holder size B with inserts - revolving center points - chuck key - Movable tailstock - Operation manual

Condition: like new (used), CNC vertical jig boring machine WMW MIKROMAT Travel X: 1120 mm Travel Y: 710 mm Spindle travel Z: 315 mm Travel W: 630 mm Numerical Command: CNC NUM 1060 Spindle: Ø 125 mm Cone: SA40 Gjdpsgy E Dpjfx Aagsbn Rotation: from 36 to 2240 RPM Table size: 1400 x 900 mm Distance between colums: 1080 mm Maxi distance spindle nose/table: from 0 to 900 mm max Maxi eligible load on table: 1000 kg max Separate electrical panel Machine renewed in 2000 with CN NUM1060 Voltage: 380 V Dimensions (L x W x H): 4000 x 2460 x 3030 mm Weight: approx. 9 T

Condition: used, Year of construction: 2011, workpiece diameter 320 mm threading length 570 mm thread pitch 315 mm Godpfot Hxbdsx Aagjbn total power requirement 17 kW weight of the machine ca. 12 t dimensions of the machine ca. m

Condition: good (used), Stock number: 3071 Manufacturer: WMW Mikromat Machine number: 3402-1/21.29 Type / Model: SFW 200 x 600 Gedpfeygl Tnox Aagsbn Table size: 200 x 600 mm Grinding area: 600 x 200 mm Maximum grinding height: 400 mm Magnet: 600 x 200 mm Grinding wheels: 200 x 20 x 51 mm Table speed: 2 to 18 m/min Automatic cross feed of table: 0.1 to 2 mm Max. distance table to spindle center: 500 mm Grinding wheel speed: 2,800 rpm Power connection: 3.5 kW Accessories/Equipment: Electromagnet Condition: Good Weight: 1.1 t Machine dimensions: 1,600 x 1,000 x 1,800 mm Dimensions incl. control panel: 2,400 x 1,000 x 1,800 mm

Condition: good (used), Machine number: 8025 Type / Model: DZFG 200 x 500 Control: conventional Centre distance: 500 mm Spindle bore: 32 mm Centre height: 160 mm Swing diameter over bed: over cross slide: 315 mm 200 mm Speed range: 56 to 2,800 rpm Feed long: face: 0.02 to 0.8 mm/rev 0.01 to 0.4 mm/rev Godpfoykt Dvjx Aagobn Connection: 5.5 kW Accessories / Equipment: Condition: good Weight: 1.9 t Dimensions: 2,100 x 1,100 x 1,400 mm

Condition: good (used), Multivac thermoformer currently setup to produce ‘hotel style’ jam packs, 14g and 20g. 32 portions per cycle. Could also be used to produce ice cubes, sauce packs, ketchup, stock etc. Can also be supplied as a line with M&P 32 head filler and end of line tray wrapper if required (at extra cost). Gedpfx Ajtp N Ddsagobn

Condition: good (used), Stock number: 3062 Manufacturer: Mikromat Model: SWPO 50 Year of manufacture: Machine number: 389236 Directly machinable area: 10 x 10 mm Indirectly, via workpiece shifting: 250 x 60 mm Gbodjydhn Nopfx Aagon Maximum thickness: 48 mm Grinding wheels: 150 mm Spindle speed: 3,500 rpm Drawing table: 156 x 120 mm Table movement x-y: mm Grinding wheel support x-y: 130 – 150 mm Support rotation: 90° left/right Support swivel range: 10° left/right Grinding head rotation: 35° left/right Grinding head swivel: 30° / 10° Grinding motor speed: 2,800 rpm Equipment: Projector, 25x magnification Accessories: Total power requirement: 1.3 kW Weight: 0.9 t Dimensions: 1,600 x 1,200 x 1,600 mm Condition: Good

Year of construction: 1987, condition: used, grinding length max. 630 mm grinding width max. 200 mm workpiece height . mm x-axis max. 250 mm y-axis max. 710 mm distance spindle center to table max. 500 mm table surface area 0,25 mm table load max. 1,1 t table speed -stepless- 2 - 18 m/min cross feed autom. . dust exhaust 0,25 kW coolant pump 0,09 kW total power requirement ca. 4,5 kW weight of the machine ca. 1,3 t dimensions of the machine ca. 2400 x 1600 x 1900 mm Adjustments Y axis: 1 scale value = 0.005 mm Z axis: 1 scale value = 0.002 mm Manual adjustment (within the range of 250 mm of the Y axis): 80 mm Gbodpfegbgawex Aagon Speeds: automatic cross feed Adjustment path in Y direction: - intermittent 0.2 - 20 mm per stroke; - continuous: 0 - 4 m/min Grinding wheel Ø max. 200 mm Grinding wheel bore: 51 mm Grinding wheel width: 20 mm Diamond dressing unit Digitaldisplay for 2 advertisement vertical infeed

Year of construction: 2015, condition: excellent (used), VMC 3 axis AMS super dart year of production 2015 Control FANUC MACHINE CAPACITY X - Axis Travel mm 600 Y - Axis Travel mm 450 Z - Axis Travel mm 500 Godpjkvpnmjfx Aagjbn Dist. From Spindle Face To Table Top mm 235 - 735 Table size mm 900 x 450 Max. load on table kgf 400 max spindle speed 15000rpm BT30 high cooling through the spindle automatic tool changer 20 tools weight machine 4500kg with machine chip conveyor with pomps low hours machine

Condition: ready for operation (used), Indramat KDV 2.2-100-220/300-220 Power Supply, serial no. according to photo, professionally completely overhauled and tested with 12 months warranty, 100% functional, scope of delivery according to photos Gsdpfx Aei Ebi Uoagjbn

Condition: ready for operation (used), Bosch SM 4.7/20-G16 Servo Control Module 1070917161, serial number as per photo, used, professionally completely overhauled and tested with 12 months warranty, 100% functional, scope of delivery as per photos Godoi D Ud Ispfx Aagobn

Condition: ready for operation (used), Bosch SM 4.7/20-G16 Servo Control Module 1070917161, serial number as per photo, used, minor signs of wear, 100% functional, scope of delivery as per photos Gsdji D Ufaepfx Aagebn

Condition: ready for operation (used), Beckhoff Model: AM3042-0G41-0000 Servo motor Serial number: 154767650, used, good condition, 100% functional, scope of delivery as per photos Gbjdpfx Ajtqqwgeagon

Condition: ready for operation (used), Beckhoff AM3042-0G40-0000 servo motor SN: 1738102399 - IP54, used, good condition, 100% functional, scope of delivery as per photos Gjdpfot Hzlfjx Aagobn

Condition: ready for operation (used), Fanuc A06B-6096-H103 Servo Amplifier Module, Version: D, SN: EA910920, professionally fully refurbished and tested with 12 months warranty, 100% functional, scope of delivery as per photos. Gjdpfxex Dwnks Aagjbn

Condition: ready for operation (used), Bosch SM 4.7/20-G16 Servo Control Module 1070917161, serial number as per photo, used, minor signs of wear, 100% functional, scope of delivery as per photos Gbjdpfx Aoi D Ud Sjagon
