Used Mikron Tcd 22 for sale (9,089)

Condition: excellent (used), PLC controller, electronic modules, PLC module, plug-in card circuit board, circuit board -Manufacturer: Mikron, Electronic module circuit board for operating unit TCD22, original packaging -Type: WW TCD 22 . 104.73.20.041 -Cardboard dimensions: 410/310/H65 mm Kedpfx Abok Aua No Iolu -Weight: 0.6 kg

Condition: used, CNC control, control panel, machining center operator panel, control unit, control panel, control unit -Manufacturer: Mikron, operating unit from CNC milling machine Mikron UME 600 -Type: TCD 22 - DIN 8659 -Printed circuit board: WW TCD 22 control unit 104.73.20.042 -Individual components: see photos -Dimensions: 480/240/H160 mm -Weight: 5.3 kg Kedpsrcnmwefx Ab Iolu

Condition: used, CNC control, control panel, machining center operator panel, control unit, control panel, control unit -Manufacturer: Mikron, operating unit -Type: TCD 22 - DIN 8659 -Printed circuit board: WW TCD 22 control unit 104.73.20.042 -Individual components: see photos -Dimensions: 480/130/H240 mm Kledpfx Asprb Dveb Ieu -Weight: 5 kg

Condition: good (used), Tool changer chain, chain magazine, tool changing system, tool magazine Kedpfx Aberb E E Nj Ielu -Manufacturer: Mikron, tool changer from CNC machining center Mikron UME 600 -for: max. 22 shots -Intake: SK40 -Dimensions: 1200/1150/H860 mm -Transport weight: 294 kg

Condition: used, EQUIPMENT - With automaton Zellio SR3 type - Tilting loader no. 11 and vibratory bowl - part diameter 2.50 to 12.5 [mm] - part length 0.30 to 30 [mm] Kedpfxjuhbqps Ab Iolu

Condition: used, Year of construction: 2005, machine/vehicle number: 107.32.99.158, travel distance X-axis: 530 mm, travel distance Y-axis: 450 mm, travel distance Z-axis: 450 mm, controller model: Heidenhain iTNC 530, spindle speed (max.): 12,000 rpm, No minimum price – guaranteed sale to the highest bidder! Kledpezara Uefx Ab Iou The machine spindle was replaced in July 2025! TECHNICAL DETAILS Travel range X-axis: 530 mm Travel range Y-axis: 450 mm Travel range Z-axis: 450 mm Rotary table Table diameter: 400 mm Table load: 200 kg Swivel range: degrees Swivel speed: 20 rpm Rotational speed: 30 rpm Tool holder: SK40 Maximum speed: 12,000 rpm Recommended maximum working feed rate: 15 m/min Rapid traverse speed: 22 m/min Feed force X and Y/Z: 5,000 N Magazine capacity: 30 Maximum tool diameter: 90 mm Maximum tool length: 250 mm (manually 350 mm) Maximum tool weight: 6 kg MACHINE DETAILS Control system: Heidenhain iTNC 530 with digital control Positional tolerance according to DIN/ISO 230-2/97: 0.008 mm Machine weight: 6,500 kg EQUIPMENT RENISHAW MP 12 measuring probe Blum tool monitoring system

Condition: used, Year of construction: 1985, x-travel 500 mm y-travel 500 mm z-travel 350 mm table surface area 800 x 450 mm spindle taper: ISO 40 quill stroke mm feed - longitudinal/cross mm/min feeds vertical mm/min turning speed range max. 3150 U/min voltage 380 V / 50 Hz power capacity 4 kW Klodjtv Ia Topfx Ab Iou weight of the machine ca. 1,7 t dimensions of the machine ca. 2,5 x 2,3 x 2,0 m • HEIDENHAIN TNC 155 - control, • with electrical hand wheel, • several tool tapers, • new set of bevel gears,

Year of construction: 1999, condition: excellent (used), Working travels 710x500x500mm Table size 1080x580mm Spindle taper 40 Spindle speeds -10000 rpm Tool changer 30 Pos. Control HEIDENHAIN TNC-430 Coolant through spindle MARCELS MASCHINEN CH Kledjd Hftxjpfx Ab Iou

Condition: used, Year of construction: 2006, x-travel 600 mm y-travel 500 mm z-travel 540 mm Control Heidenhain TNC530 spindle tunring speed 12.000 U/min tool taper SK 40 number of tool places 24 Pos. Number of working hours ca. 41.344 h In our assessment, the machine is in good used condition and can be inspected under power by appointment. Technical features & accessories: - Handwheel - Chip conveyor - Coolant system - Machine documentation - Control system documentation - 3D probe - Air purifier Kedpjzd Hflofx Ab Ielu - Tool setter Accessories, tools, and workholding devices shown are included in the scope of delivery only if specified in the additional information. Subject to change, errors in technical data and specifications, and prior sale.

Condition: good (used), Year of construction: 1997, travel distance X-axis: 1,000 mm, travel distance Y-axis: 750 mm, travel distance Z-axis: 750 mm, CNC control Heidenhain TNC426 30-fold tool changer Kedpfx Aboua S Hro Ielu electronical handwheel chip screw coolant device Technische Daten / technical details: Verfahrweg X / X-Travel 1000 mm Verfahrweg Y / Y-Travel 750 mm Verfahrweg Z / Z-Travel 750 mm Tischgröße / table size 1150x700 mm Werkzeugschaft / spindle taper SK40 Drehzahlbereich / spindle speed 12000 UpM /rpm Anzahl der Werkzeugplätze / tool places in ATC 30 Gewicht der Maschine ca. / weight ca. 10500 kg Technische Daten, Zubehör und Beschreibung der Maschine sind unverbindlich - Technical data, accessories and description of the machine are not binding.

Condition: good (used), Parts on table not come. Marked with red. Kjdpowxdyxsfx Ab Islu

Condition: good (used), Year of construction: 2007, Machine is in good condition, Parts shown by hand not come. SK 40, 24 tool places in tool changer. Kedpowk Nm Ijfx Ab Ijlu 10.000 rpm

Condition: good (used), Year of construction: 1995, travel distance X-axis: 1,000 mm, travel distance Y-axis: 600 mm, travel distance Z-axis: 600 mm, x-travel 1000 mm y-travel 600 mm z-travel 600 mm Control: Heidenhain TNC 426 Spindle nose: 100–700 mm Work table: 1,080 x 580 mm Max. workpiece weight: 550 kg T-slots: 7 pcs. T-slot width: 14 mm Tool magazine with 36 positions Max. tool weight: 8 kg Max. tool length: 340 mm Kjdpfx Abjzd Dv Is Ijlu Machine weight approx. 6.2 t Space requirement approx. 4,790 x 5,330 x 2,905 mm

Condition: good (used), Year of construction: 1991, travel distance X-axis: 560 mm, travel distance Y-axis: 500 mm, travel distance Z-axis: 400 mm, X-travel: 560 mm Y-travel: 500 mm Z-travel: 400 mm Control: TNC 360 Kjdjzd Dcbopfx Ab Ielu Spindle speed: 40-4,000 rpm Total power requirement: 7.5 kW Machine weight approx.: 2.6 t Space requirement approx.: 2.6 x 1.8 x 2.2 m

Condition: excellent (used), Year of construction: 2005, functionality: fully functional, machine/vehicle number: Serien-Nr.: 107.84.00.188,, CNC machining center, manufacturer: Mikron, type: HSM 400, year of manufacture: 2005 Serial number: 107.84.00.188, travel ranges (x/y/z-axis): 400x450x350 mm, tool holder: HKS40E, max. spindle speed: 30,000 rpm, spindle drive: 13 kW, recorded operating/load hours: 44,899/32,369 (13,350 spindle hours since replacement) CNC control system: HEIDENHAIN iTNC530 Pallet table PPC 320x320 mm, 7-position pallet changer, 68-position tool changer, 1 Ksdpfx Abozdtacj Iolu Cooling unit BURN, 1 extraction system KELLER L-Cut, year of manufacture: 2012, Setup probe PS 32 (WITHOUT any further accessories)

Condition: used, Year of construction: 2001, Technical data: Tool holder: SK 40 Travels: X-axis: 530 mm Y-axis: 450 mm Z-axis: 450 mm Max. Tool weight: 260 kg Spindle speed: 12000 1/min Max. Table load: 380 kg Weight, approx.: 6500 kg Dimensions (DxWxH), approx.: 2000 x 2200 x 2400 mm Equipment: Kodpfx Ajt Hr Ahob Ielu - Control Heidenhain TNC 430 - 4-axis from SMP (France)

Condition: used, Year of construction: 1992, max. wheel diameter 150 mm gear width 300 mm max. module 4,5 min. module total power requirement 20 kW weight of the machine ca. 6 t dimensions of the machine ca. m Klodjt Hwxbjpfx Ab Ieu

Condition: used, Year of construction: 1985, max. wheel diameter 80 mm gear width 150 mm max. module 2,5 min. module total power requirement 10 kW weight of the machine ca. 2400 kg M I K R O N (Switzerland) Fully Automatic Gear Hobber for Worm Gears Model A 33 / 1 Year 1985 Ser.-No. 14.06/14.07/14.15 _____ max. gear- without feed magazine approx. 80 mm max. gear- with feed magazine approx. 50 mm Module max. 2, / 2,5 Axial milling length approx. 150 mm max. workpiece-mounting length approx. 200 mm Milling slide can be swivelled up to 90 degrees Milling cutter - 24 - 50/63 mm Max. radial distance of milling slide 0-14/18 mm Milling cutter adjustment max. 25 mm Milling cutter speed 212 - 2.000 rpm Axial feed range infinitely adjustable 0,05 - 4,0 mm/workpiece rotation radial infinitely adjustable 0,2 - 200 mm/min. Milling spindle drive 3 kW Total electrical load approx. 10 kW - 50 Hz - 380 Volt Weight approx. 2.400 kg Accessories/Special Features: " Fully automatic operation cycle and minimum idle times due to programmable SIEMENS Program Controls S 5 for all machining steps i.e. rapid gear, feed, milling cutter on/off for the loading device, tailstock, possibly shifting, etc. with unit counter, program numbering including 30 different numeric error displays Pneumatic workpiece-loading and unloading facility parallel to work piece axis upright for rod workpieces approx. 140 mm long x 8 mm , including pneumatic double gripper for Klodpfx Abst Hw D Ro Iju loading and unloading of work pieces. Raw parts are inserted into change cassettes externally and then placed into the loading device. The double gripper places the parts between workpiece spindle and tailstock, the tailstock spindle sleeve pushes the parts in the main spindle collet and clamps them simultaneously. The finished parts are ejected from the main spindle, then placed back again into the finished parts cassette by the gripper. The whole process is electrically monitored and checked. The complete loading facility is encased by plexiglass. " Hydraulic work piece clamping device including collets and hydraulic ejector " separate cooling system with magnetic separator * separate hydraulic system * various change gears This machine is set up for worm gears/armature shafts that can be used for adjustable car seats, window lifters, etc.

Condition: used, Year of construction: 1982, x-travel 400 mm y-travel 400 mm Kodpou U Sabofx Ab Islu z-travel 380 mm total power requirement 2,6 kW weight of the machine ca. 1,5t t

Condition: good (used), Mikron WF 41C CNC Universal Milling and Boring Machine Professional, extremely robust MIKRON WF 41C CNC universal milling and boring machine. Thanks to its sturdy construction, the machine is ideally suited for workshops, prototype manufacturing, maintenance, or demanding toolmaking applications. Ksdpfx Abezcqf Io Ijlu The machine is equipped with the proven HEIDENHAIN TNC 155 contouring control. It is extremely easy to program directly at the machine thanks to plain-language conversational guidance; it supports graphic simulations and allows for the easy loading of external CNC programs via the serial interface (ideal for CAD/CAM applications). Technical Data Overview CNC Control Model: HEIDENHAIN TNC 155 Operating modes: Manual operation (like digital readout), positioning with manual input, single block, block sequence, program test (graphic simulation) Interface: V.24 / RS-232-C for data transfer Feed Drives & Travel Ranges X-axis travel (table longitudinal, automatic): 630 mm Y-axis travel (spindle slide transverse, automatic): 500 mm Z-axis travel (table vertical, automatic): 460 mm Feed rate: Infinitely variable from 1 – 3000 mm/min in all 3 axes Rapid traverse speed: X- and Y-axis: 6000 mm/min | Z-axis: 4000 mm/min Max. vertical installation height: 559 mm (between vertical milling head and angle table) Milling spindle drive Spindle speeds: 21 gear stages Speed ​​range: 31.5 – 3150 rpm Spindle motor power: 6.0 / 8.0 kW Tool holder: ISO 40 / M16 with pull stud groove (SK 40 DIN 2080) Quill travel (vertical): 90 mm Table geometry & workpiece capacity Angle table clamping surface: 500 x 1000 mm T-slots: 7 (spacing: 63 mm, width: 14-H7 mm) Vertical clamping surface: 397 x 550 mm (with 4 x 4 M16 threaded holes, 90 mm spacing) Max. recommended workpiece weight: 500 kg Electrics & cooling Electrical connected load: 13.5 kW Coolant tank volume: approx. 100 liters Dimensions & weights Machine dimensions (machine only): 1745 mm (L) x 1501 mm (W) x 2124 mm (H) Max. operating footprint (incl. control arm): 2930 mm (L) x 2115 mm (W) x 2125 mm (H) Machine weight (net): 3100 kg (incl. vertical milling head and angle table) "Everything from a single source: We would be happy to offer you suitable bank financing for your project." komplett-konzept.leasingo.de You can find more items—new and used—in our shop! International shipping costs on request!

Condition: good (used), Year of construction: 1998, Mikron UM 710/900 Universal Milling Machine High-precision universal tool milling machine from the renowned Swiss manufacturer MIKRON, model UM 710/900. The machine comes from a well-maintained environment and stands out for its hallmark Mikron precision and generous working area (up to 900 mm travel in the X-axis). It is ideally suited for toolmaking, prototyping, training purposes, or demanding repair workshops. Technical specifications at a glance (manufacturer data): Working range & axes: Longitudinal travel (X-axis): 710 / 900 mm Cross travel (Y-axis): 630 mm Vertical travel (Z-axis): 500 mm Work spindle: Tool holder: SK 40 / DIN 69871 Gear stages: 4 Speed ​​range: variable (vertical & horizontal) Main drive & feed: Ksdpfx Abezcqcgj Iolu Spindle drive power: 11 kW (at 44% duty cycle) / 7.5 kW (at 100% duty cycle) Feed rate (X, Y): 0 – 10,000 mm/min (programmable) Feed rate (Z): 0 – 8,000 mm/min (programmable) Rapid traverse (X, Y / Z): 10 m/min / 8 m/min Clamping table (angle table): Clamping surface: 600 x 1,200 mm T-slots: 9 (14-H7, 63 mm spacing) Max. table load: 500 kg Electrics, dimensions & weights: Connected load: Total installed nominal power 21.5 kW Operating voltage: 3 x 400 V - 50 Hz Coolant system: 150-liter capacity Machine weight: approx. 4,300 kg (incl. protective enclosure) "Everything from a single source: We would be happy to offer you suitable bank financing for your project." komplett-konzept.leasingo.de You can find more items – new and used – in our shop! International shipping costs on request!

Condition: good (used), Year of construction: 2004, operating hours: 90,000 h, functionality: fully functional, machine/vehicle number: 6010.0176, Technical Data Manufacturer: MIKRON Model: UCP 800 Duro Year of construction: 2004 Control system: Heidenhain iTNC 530 Travel in X-axis: 800 mm Ksdpfx Abjzc Hqae Ijlu Travel in Y-axis: 650 mm Travel in Z-axis: 500 mm Rotary table 600 x 600 mm Max. table load: 500 kg Rotation range C-axis: 360° Tilting range A-axis: +120° / -100° Rapid traverse X/Y/Z: 30 m/min Spindle manufacturer: Step-Tec AG Spindle type: HVCS212-S-12-1.7/20-2F-HSK-A63 Max. spindle speed: 20,000 rpm Tool interface: HSK-A63 Spindle power: 12 kW (S1) Machine weight: approx. 9,900 kg Connection power: 18 kW Operating voltage: 3x 400V + PE / 50Hz Description For sale is a high-precision 5-axis vertical machining center from the Swiss quality manufacturer MIKRON, model UCP 800 Duro. The machine is in good, well-maintained condition and is equipped with a powerful Step-Tec motor spindle up to 20,000 rpm and a reliable Heidenhain iTNC 530 control system. An integrated BLUM LaserControl system ensures precise tool measurement and breakage monitoring. Special advantage for buyers: The machine is currently still installed and operational. An inspection and a function test can be carried out after prior appointment. Equipment / Highlights ( )5-axis simultaneous machining for complex components Heidenhain iTNC 530 CNC control system with hand-held device Step-Tec high-speed spindle (max. 20,000 rpm) BLUM LaserControl (laser tool monitoring) Chip conveyor including chip cart CE marking available Delivery conditions Condition: Used, fully functional, can be tested while powered on. Location: Sinn, Germany Availability: By arrangement. Dismantling & Transport: The buyer bears the costs for dismantling, loading and transport (ex works / EXW).

Condition: used, x-travel 450 mm y-travel 400 mm z-travel 400 mm Ksdpfx Ajxv D U Ijb Iolu Control Heidenhain TNC 355 turning speed range 40 - 4000 U/min number of speeds 21 tool taper ISO 40 quill stroke 90 mm feed speeds 2-3000 mm/min rapid traverse longitudinal and cross 6000 m/min rapid traverse Z-axis 5000 m/min distance spindle nose and table 450 mm table travel 495 mm table surface area vertikal 300 x 450 mm fixed clamping table 460 x 800 mm max. loading 350 kp dimensions ca. 3150 x 1800 x 2125 mm weight - pallet system ca. 2380 kg weight of the machine ca. 2,4 t incl. variois tool holders SK 40 manual included

Year of construction: 1987, condition: good (used), Mikron WF2SA tool milling machine with 3-axis Heidenhain active digital readout. Fixed angle table, SK 40 spindle holder. Ready for operation . Machine ready for demonstration under power by arrangement. Kedpjqttt Tsfx Ab Islu

Condition: good (used), Year of construction: 2014, Universal Machining Center Machine type: Mikron HPM 1350 U Control system: Heidenhain iTNC 530 Year of manufacture: 2014 TECHNICAL DATA: Travel ranges: X-axis: 1,350 mm Y-axis: 1,150 mm Z-axis: 700 / 895 mm B-axis: +16°/-120° A-axis: 360° Swiveling head Number of controlled axes: 5 Spindle speed range: 15,000 rpm Drive power: 38 kW Tool interface: HSK 63 Tool changer Number of tool positions: 48 Kedpfx Abezarxqo Iolu NC rotary table Table size: Ø 1,100 mm Equipment features: Chip conveyor Internal cooling (IKZ): bar Air through spindle center Oil mist extraction Tool measurement Measuring probe
