Used Monoprecis Surface Grinding Machine for sale (66,135)

Condition: ready for operation (used), Year of construction: 2013, functionality: fully functional, machine/vehicle number: 52.362, input voltage: 400 V, MACHINE DETAILS Type of input current: Alternating current (AC) Input voltage: 400 V Operating voltage: 400 V AC Hjdpfx Aey A Ipfol Sjl Frequency: 50 Hz Total connected load: 50 A Max. feed current: 22 A

Condition: excellent (used), Year of construction: 2019, functionality: fully functional, Technical details grinding length 600 mm grinding width 400 mm workpiece height 400 mm total power requirement 23 kVA weight of the machine ca. 4,5 t dimensions of the machine ca. 3592 x 3519 x 2203 mm Additional information Horizontal surface grinder in almost new condition Operating hours: CNC on: 1198 hours Machine on: 1117 hours Automatic operation: 509 hours Grinding operation: 228 hours Okamoto Touch Screen Control Hedpey Idnuefx Al Sol Travel X-axis: 600 mm Travel Y-axis: 22.5 – 497 mm Travel Z-axis: 400 mm Grinding wheel dimension 355 x 38 x 127 mm Speed range rpm: 1-2800 (stepless) Rapid traverse mm/min: 4000 Main drive kW: 7.5 Maximum table load in kg: 1000 Accessories: - Electro-permanent magnetic clamping plate: 400 x 600 P13 mm, height 80 mm (make Wagner) - 2 grinding wheel flanges (without grinding wheel) - Table dresser - Automatic straight dresser, spindle box mounted - Automatic compensation of the wheel dressing amount - Automatic central lubrication - Ball screw in the Y and Z axes with AC servo motor and measuring system - Coolant system with belt filter system

Condition: used, Year of construction: 2008, functionality: fully functional, machine/vehicle number: 146978, Knuth Surface Grinding Machine Flat HFS 2500C Working Area & Capacities Table dimensions: 250 x 500 mm Grinding area (max.): approx. 500 x 250 mm Maximum workpiece weight: 180 kg Distance spindle center to table surface: 450 mm Travel Distances & Feeds Longitudinal travel (X-axis): 560 mm Hedpoy H Dg Iofx Al Sel Cross travel (Y-axis): 275 mm Hydraulic table feed (X): 7 – 23 m/min Rapid traverse cross (Y): 990 mm/min Rapid traverse vertical (Z): 460 mm/min Spindle & Grinding Wheel Grinding spindle motor power: 2.2 kW Grinding wheel dimensions: 200 x 20 x 31.75 mm Graduation: Y-axis 0.02 mm / Z-axis 0.005 mm Dimensions & Weight Machine dimensions (LxWxH): approx. 2650 x 2150 x 1675 mm Total weight: approx. 1800 kg

Condition: good (used), Year of construction: 1983, operating hours: 15,870 h, functionality: fully functional, grinding length: 600 mm, grinding width: 200 mm, table load: 100 kg, overall weight: 2,000 kg, distance stand to spindle center: 500 mm, input voltage: 400 V, Surface grinding machine Jung JF520 Year of manufacture: 1983 Operating hours: 15,870 h Grinding area: 600x200 mm Distance table to grinding spindle center: 500 mm Max. table load: 100 kg Automatic table cross feed Automatic grinding head height adjustment Rapid traverse Central lubrication Required floor space: 3,100x1,700 mm Weight approx. 2,000 kg - complete documentation - extensive accessories: grinding wheels Hedpfx Aloyxcm Rs Ssl dresser angle table balancing scale

Condition: used, Year of construction: 2007, functionality: fully functional, Magnetic table: 1000 x 500 mm Longitudinal traverse: 1140 mm Cross traverse: 540 mm Grinding spindle speed: 1450 rpm Distance spindle center to table: 584 mm Table load capacity incl. magnetic table: 1000 kg Automatic increment on all axes Installation area (mm): 4445 x 2200 Packing dimensions: 3440 x 2260 x 2250 mm Net weight of machine: approx. 5800 kg Hsdpey Hqg Usfx Al Sjl

Condition: used, Year of construction: 1989, MAKE GER, MADE IN SPAIN MODEL RS 10/60 YEAR TABLE LENGTH 1300.0 mm TABLE WIDTH 600.0 mm TRAVEL X AXIS: 1600.0 mm Y AXIS: 600.0 mm MAX DISTANCE (TABLE TO WHEEL) 800.0 mm MAX WORKPIECIE WEIGHT 1000 KGS GRINDING WHEEL SIZE 400.0 x 100.0 x 127.0 mm SPINDLE SPEED MAX 1500 RPM MACHINE DIMENSIONS 4600.0 x 2700 x 2600.0 mm MACHINE WEIGHT 7600 KGS PLUS ELECTROMAGNETIC CHUCK SIZE: 1000.0 X 600.0MM HYDRAULIC PACK COOLANT SYSTEM Hjdpfxoy Du N Us Al Sel WHEEL MOUNTED DRESSER

Condition: used, Year of construction: 1987, grinding length 1250 mm grinding width 400 mm workpiece height 550 mm table surface area 1720 x 400 mm dimensions of grinding wheel 400 x 50 x 127 mm 1250 x 600 mm Hjdpfsy Ezz Tsx Al Sol grinding spindle speed 3000 U/min table load capacity 1100 kp total power requirement 13,8 kW weight of the machine ca. 6,0 t dimensions of the machine ca. 5,0 x 3,4 x 2,4 m Surface grinding machine - Magnetic grinding wheel - Coolant system - Documentation

Condition: ready for operation (used), Year of construction: 2020, Immediately available ex location: Horizontal surface grinding machine, make Holzmann Model SPM 30 FUM Year of manufacture: 2020 Grinding length: 400 mm Grinding width: 200 mm Table: 600 x 300 mm Hsdpfxoy E I I Ts Al Sjl Automatic feed Magnetic chuck Coolant system Weight: 2 t Offered at a price of EUR 2,250 plus VAT ex location.

Condition: ready for operation (used), Year of construction: 1988, Horizontal surface grinding machine Okamoto Type PSG 63 – UAN Year of manufacture: 1988 Grinding length: 600 mm Grinding width: 320 mm Max. workpiece height: 500 mm Table travel (longitudinal): 750 mm Table travel (cross): 340 mm Grinding wheel diameter: 350 mm Grinding wheel width: 40 mm Spindle speed: 1500 rpm Rapid vertical feed: 400 mm/min Power: 3.7 kW Automatic feed Magnetic chuck Coolant system Weight: 2500 kg Price: EUR 2,000—plus VAT, ex location Hedpfoy E I Iysx Al Sol

Condition: used, Year of construction: 2012, functionality: fully functional, machine/vehicle number: 92060, grinding length: 650 mm, grinding width: 230 mm, total height: 2,276 mm, total length: 3,030 mm, total width: 1,784 mm, workpiece weight (max.): 200 kg, grinding height: 397 mm, feed rate X-axis: 25 m/min, feed rate Y-axis: 25 m/min, feed rate Z-axis: 25 m/min, grinding wheel diameter: 205 mm, table speed: 25,000 mm/min, table length: 2,000 mm, table load: 20,000 kg, type of input current: AC, table width: 2,000 mm, spindle speed (max.): 3,000 rpm, overall weight: 2,100 kg, table height: 250 mm, grinding spindle motor power: 1,500 W, travel distance X-axis: 8,000 mm, travel distance Y-axis: 2,500 mm, travel distance Z-axis: 700 mm, rotational speed (max.): 300 rpm, rotational speed (min.): 5 rpm, grinding spindle speed: 3,000 rpm, input voltage: 380 V, disc diameter: 205 mm, Equipment: documentation/manual, rotational speed infinitely variable, The Okamoto ACC52SA is a precision surface grinding machine featuring a horizontal grinding spindle and hydraulic longitudinal feed, primarily used in toolmaking, jig and fixture manufacturing, and small batch production. The machine is distinguished by its robust cast construction, precise guideways, and user-friendly operation. It is especially suitable for high-precision grinding of flat surfaces and for machining hardened workpieces. Hsdpfx Aljyt Dm He Sjl Typical for the ACC series are sturdy double-V guideways and automatic feed systems, ensuring uniform surface quality and high repeat accuracy. Okamoto SA Control (MDI control) Cycle control and manual operation The quoted price is exclusive of dismantling, packaging, and shipping. Sale from site, subject to prior sale. The machines are sold in used condition; any warranty or guarantee is excluded.

Condition: good (used), . dimensions of the table 5000x550 mm . maximum rectifiable length 5000 mm . maximum transversal stroke 600 mm . Z axis travel 600 mm . grinding wheel dimensions 420x127x100 mm . manual type head for inclined planes . tank with paper purifier . magnetic separator . magnetic plate with n° 3 units of 1.000x500 mm . length dimension 12000 mm . width dimension 2500 mm Hodpfx Asip Dxwel Sel . height dimension 3500 mm . weight 15000 Kg . complete machine manuals .CE certificate

Condition: good (used), Year of construction: 2007, functionality: fully functional, Technical details grinding length 600 mm grinding width 400 mm workpiece height 375 mm Additional information CNC Precision Surface and Profile Grinding Machine Grinding area: 600 x 400 x 375 mm Grinding spindle motor: 3.7 kW Table drive: hydraulic Cross-axis drive: electromechanical Grinding wheel: 300 x 50 x 76.2 mm Peripheral speed: 10 - 32 m/s Electromagnetic plate: 600 x 400 mm with holding force control and automatic magnetic pole reversal for demagnetizing Hsdpfx Alsy Ew N He Ssl Features: Partially enclosed, open-topped loading compartment with a sliding door Cleaning kit for cleaning the work area with hand-held impulse nozzle Holder for prism arm with single-point diamond, MK 0 Grinding spindle speed control with V-constant controller Universal paper filter unit UPF 100, tank capacity approx. 280 liters Coolant pump: 20 liters/minute at 1.5 bar With mud box Machine light Grinding wheel flanges

Condition: used, functionality: fully functional, grinding height: 256 mm, grinding length: 800 mm, grinding width: 400 mm, Wiring diagrams are available in digital format. Hedoy Hfcwepfx Al Sjl

Condition: new, neu ca. 6 Monate ab Auftragse Taiwan 84310 € 1593.46 € 460 mm 395 mm 460 x 200 mm 450 x 200 mm 0 - 20 m/min 0 - 3000 mm/min 0,001 mm 220 mm 290 mm 0 - 3000 mm/min 0.001 mm 1000 - 7000 1/min 3 kW 2280 mm 2205 mm 2020 mm 1500 kg 1060 mm 175 kg 210 kg Dm. 205 x 12,7 x 31,75 mm 1,1 kW 2.4 kW 0,004 mm 0,003 mm Smart i control with 10.4" touchscreen on a swiveling panel, with electronic wired handwheel - RS232, USB I/O connection Hjdpfx Asynnc Iel Sjl - SMART Grind Cam (dxf transfer in G code) -PC based control with graphical dialog programming or G-code programming Infinitely variable speed Surface grinding cycle, cross grinding cycle, plunge grinding cycle, multiple groove grinding cycle, contour grinding cycle, dressing cycle Spindle with 4 angular contact ball bearings (P4, checkout 7) Longitudinal guides with double V shape, with Turcite-B coating All 3 axix with precision ball screws (class C2) and AC servo motors Fully enclosed splash guard with lamp Electromagnetic chuck plate Coolant system with automatic paper filter and magnetic separator autom. dressing attachment table mounted with compensation * Grinding wheel Grinding wheel flange Grinding wheel balancing stand Machine and equipment in accordance with CE regulations Operating manual in GERMAN or ENGLISH * The exact configuration of the dresser must be clarified before ordering

Condition: new, neu ca. 6 Monate ab Auftragse Taiwan 195350 € 3692.12 € 2000 mm 730 mm 2000 x 600 mm 2x 1000 x 600 mm 2100 mm 5 - 30 m/min 0 - 2250 mm/min Hodsxpizmspfx Al Sol mm 685 mm 0 - 675 mm/min 0.001 - 0.04 mm 560 mm 500 - 2200 1/min 11 kW 5.5 kW 6225 mm 07 mm 2305 mm 6530 × 00 ×3350 (brutto mm 10200 kg 1600 kg 1150 kg 1600 kg Dm. 405 x 75 x 127 mm je 3,1 kW 10.4" graphic NC control on a swivel arm with touchscreen for: Operating mode selection Cycle selection and program creation Surface grinding Cross grinding Plunge grinding Dressing with automatic compensation Semi-automatic balancing in the machine Automatic spindle speed for constant surface speed Spindle load visualization Unbalance control Graphical status monitoring Alarm list Max. table speed 30 m/min Integrated machine body temperature control Turbide-coated double V-guides Hydraulic table drive with cooling Linear guides with recirculating ball screws and AC motors for precise positioning in the X and Z axes Automatic lubrication with a pressure switch for automatic stop in case of pressure drop Electro-magnetic chuck 2x 1000 x 600 mm Coolant system with automatic paper filter and magnetic separator (500 l) Automatic dressing device mounted on the table, without diamond, with automatic compensation Grinding wheel flange with 1 grinding wheel Grinding wheel balancing stand LED machine light Machine and equipment according to CE regulations Operating manual in GERMAN or ENGLISH OPTIONS (PRICES ON REQUEST): Complete enclosure of the work area Oil mist extraction

Condition: new, neu ca. 6 Monate ab Auftragse Taiwan 156560 € 2958.98 € 1200 mm 850 mm 1200 x 500 mm 1200 mm 1200 500 mm 5 - 30 m/min 0 - 5000 mm/min 0,001 mm 560 mm 0 - 2000 mm/min 0.001 mm 500 - 2200 1/min 11 kW 3.7 kW 3.1 kW 2.4 kW 4600 mm 2950 mm 2745 mm 4610 x 2290 x 2500 mm 6400 kg 900 mm 930 kg 1250 kg 405 x 50 x 127 mm Smart i control with 10.4" touchscreen on a swiveling panel, with electronic wired handwheel - RS232, USB I/O connection - SMART Grind Cam (dxf transfer in G code) -PC based control with graphical dialog programming or G-code programming Infinitely variable speed Surface grinding cycle, cross grinding cycle, plunge grinding cycle, multiple groove grinding cycle, contour grinding cycle, dressing cycle Spindle with 6 angular contact ball bearings (P4, checkout 7) Air purge spindle Longitudinal guides with double V shape, with Turcite-B coating Transverse and vertical feed with precision ball screws (class C2) and servo motors Longitudinal feed hydraulically Linear scale on Y-axis 675mm Fully enclosed splash guard with lamp Electromagnetic chuck plate 1200 x 500 mm Coolant system with automatic paper filter and magnetic separator automatische Abziehvorrichtung am Tisch montiert, ohne Diamant, mit automatischer Kompensation * Grinding wheel Grinding wheel flange Grinding wheel balancing scale Heat exchanger for electric cabinet Machine and equipment in accordance with CE regulations Operating manual in GERMAN or ENGLISH PRICE FOB TAIWAN * The exact configuration of the dresser must be clarified before ordering Hedpfx Alowiryzs Ssl

Condition: new, neu ca. 6 Monate ab Auftragse Taiwan 48720 € 930.55 € 610 mm 600 mm 610 x 305 mm 300 x 600 mm 650 mm 700 mm 5 - 25 m/min 1.100 mm/min 1 - 12 mm 370 mm 1.5 kW 0.004 kW 0.19 kW 7,4 kW 2670 mm 1810 mm 2050 mm 2100 kg 355 x 50 x 127 mm 1.450 U/min 3,7 kW 4 mm 0,02 mm 0,2 mm 0,002 mm control panel on swiveling arm aut. vertical feed hardened slide ways in all 3 axes with needle rollers grinding wheel spindle on 4 high precision angular contact bearings electro-magnetic chuck coolant equiptment with aut. paper filter and magnetic separator manual extractor with diamond grinding wheel grinding wheel flange grinding wheel balancing scale balance arbor LED machine lamp Hjdpfx Alswirh So Ssl machine and equipment according to the CE-regulations user manual in GERMAN and ENGLISH

Condition: new, neu ca. 6 Monate ab Auftragse Taiwan 73460 € 1388.39 € 610 mm 600 mm 600 x 300 mm 600 x 300 mm 420 kg 700 mm 5 - 25 m/min 0 - 2.250 mm/min mm 350 mm 440 mm 0 - 675 mm/min 0.001 - 0.04 mm 500 - 2000 1/min 5,5 kW 0.75 kW 1.1 kW 1.1 kW 2710 mm 2428 mm 2200 mm 3500 kg 975 mm 355 x 50 x 127 mm 10,4" grafic NC-control on swiveling arm with touch screen for: - seletion of working mode, program creation, graphic condition control, alarm list aut. vertical feed servo drive for grinding wheel feed and table cross feed hardened slide ways in all 3 axes with needle rollers electro-magnetic chuck coolant equiptment with aut. paper filter and magnetic separator autom. dressing attachment table mounted with compensation * Hjdpfxswirc No Al Sol fully enclosed splash guard protection of working area grinding wheel grinding wheel flange grinding wheel balancing scale balance arbor LED machine lamp machine and equipment according to the CE-regulations user manual in GERMAN and ENGLISH autom. dressing attachment table mounted with compensation *

Condition: new, Year of construction: 2026, neu 2026 050163 Mai 2026, Zwischenverkauf Taiwan 86130 € 1627.86 € 1015 mm 600 mm 1000 x 400 mm 1000 x 400 mm 670 kg 1100 mm 5 - 25 m/min 0 - 2.250 mm/min mm 450 mm 440 mm 0 - 675 mm/min 0.001 - 0.04 mm 500 - 2.000 1/min 5,5 kW 1.5 kW 1.1 kW 1.1 kW 3630 mm 2682 mm 2200 mm 4400 x 2300 x 2400 mm 4800 kg 423 kg 670 kg 355 x 50 x 127 mm 10,4" grafic NC-control on swiveling arm with touch screen for: - seletion of working mode, program creation, graphic condition control, alarm list aut. vertical feed servo drive for grinding wheel feed and table cross feed Hedewircijpfx Al Sel hardened slide ways in all 3 axes with needle rollers electro-magnetic chuck coolant equiptment with aut. paper filter and magnetic separator oil mist collector autom. dressing attachment table mounted with compensation fully enclosed splash guard protection of working area grinding wheel grinding wheel flange grinding wheel balancing stand balance arbor LED machine lamp machine and equipment according to the CE-regulations user manual in GERMAN and ENGLISH

Condition: new, neu ca. 6 Monate ab Auftragse Taiwan 119350 € 2255.72 € 610 mm 600 mm 600 x 300 mm 600 x 300 mm 0 - 20 m/min 0 - 3000 mm/min 0,001 mm 350 mm 440 mm Hsdpfx Alswirb Se Sel 0 - 3000 mm/min 0.001 mm 500 - 1800 1/min 11 kW 3160 mm 2450 mm 2080 mm 3400 x 2200 x 2530 mm 4000 kg 975 mm 195 kg 370 kg 355 x 50 x 127 mm 1,1 / 1,1 kW 3.9 kW 0,005 mm 0,003 mm Smart i control with 10.4" touchscreen on a swiveling panel, with electronic wired handwheel - RS232, USB I/O connection - SMART Grind Cam (dxf transfer in G code) -PC based control with graphical dialog programming or G-code programming Infinitely variable speed Surface grinding cycle, cross grinding cycle, plunge grinding cycle, multiple groove grinding cycle, contour grinding cycle, dressing cycle Spindle with 4 angular contact ball bearings (P4, class 7) Longitudinal and cross guides with heavy duty needle roller bearing for low friction, better accuracy and lower maintenance costs All 3 axix with precision ball screws (class C2) and AC servo motors Fully enclosed splash guard with lamp Electromagnetic chuck plate Coolant system 120 lt with automatic paper filter and magnetic separator Automatic diamond roller dresser mounted on the table, with automatic compensation * Grinding wheel Grinding wheel flange Grinding wheel balancing scale Machine and equipment in accordance with CE regulations Operating manual in GERMAN or ENGLISH Accuracy standard ISO 1986-1 * The exact configuration of the dresser must be clarified before ordering

Condition: new, neu ca. 6 Monate ab Auftragse Taiwan 111220 € 2102.06 € 400 mm 500 mm 400 mm 225 mm 400 mm 50 kg 450 mm 500 - 2200 1/min 5,5 kW 19 kW 2800 mm 2800 mm 2610 mm 2850 x 2000 x 2470 mm 3450 kg Dm. 355 x 38 x Dm. 127 mm 0,001 mm 1.7 kW 2.4 kW 10 - 150 1/min 0.005 mm 0.003 mm iSurface control with 10,4" touchscreen for fully automatic grinding in machine manual wheel balancing traveling column rib structure Hsdswiq U Repfx Al Sol AC servo motors für Y/Z axes and rotary table 1 pc. wheel flange 1 pc. grinding wheel Dm. 355 x 38 x Dm. 127 mm Coolant equipment with automatic paper filter and magnetic separator automatic dresser on the table, with compensation fully enclosed splash guard electromagnetic round chuck, fine pole pitch (1+3 mm) working lamp warning lamp operating manual in German and English ALTERNATIVE: model version FRG-400S with Smart iControl for profile grinding price on request (symbol photos - showing model FRG-600)

Condition: new, neu ca. 6 Monate ab Auftragse Taiwan 123650 € 2336.99 € 1015 mm 600 mm 1.000 x 400 mm 1.000 x 400 mm 1100 mm 5 - 25 m/min 0 - 3000 mm/min 0,001 mm 450 mm 440 mm 0 - 3000 mm/min 0.001 mm 500 - 1800 1/min 11 kW 2.2 kW 1.1 kW 1.1 kW 4450 mm 2655 mm 2080 mm 4200 kg 250 kg 470 kg 355 x 50 x 127 mm 0,005 mm 0,003 mm Smart i control with 10.4" touchscreen on a swiveling panel, with electronic wired handwheel Hsdpfxowiq Tao Al Sel - RS232, USB I/O connection - SMART Grind Cam (dxf transfer in G code) -PC based control with graphical dialog programming or G-code programming Infinitely variable speed Surface grinding cycle, cross grinding cycle, plunge grinding cycle, multiple groove grinding cycle, contour grinding cycle, dressing cycle Spindle with 4 angular contact ball bearings (P4, checkout 7) Longitudinal guides with double V shape, with Turcite-B coating Transverse and vertical feed with precision ball screws (class C2) and AC servo motors Longitudinal feed hydraulically Fully enclosed splash guard with lamp Electromagnetic chuck plate Coolant system with automatic paper filter and magnetic separator Automatic diamond roller dresser mounted on the table, with automatic compensation * Grinding wheel Grinding wheel flange Grinding wheel balancing scale Machine and equipment in accordance with CE regulations Operating manual in GERMAN or ENGLISH * The exact configuration of the dresser must be clarified before ordering

Condition: new, neu ca. 6 Monate ab Auftragse Taiwan 122120 € 2308.07 € 600 mm 500 mm 600 mm 325 mm 600 mm 205 kg 450 mm 500 - 2200 1/min 5,5 kW 19 kW 2800 mm 2800 mm 2610 mm 2850 x 2000 x 2470 mm 3500 kg 820 mm Dm. 355 x 38 x Dm. 127 mm 0,001 mm 1.7 kW 2.4 kW 10 - 150 1/min 0.005 mm 0.003 mm iSurface control with 10,4" touchscreen for fully automatic grinding in machine manual wheel balancing traveling column rib structure AC servo motors für Y/Z axes and rotary table 1 pc. wheel flange 1 pc. grinding wheel Dm. 355 x 38 x Dm. 127 mm Hsdpfx Alewiq Nns Ssl Coolant equipment with automatic paper filter and magnetic separator automatic dresser on the table, with compensation fully enclosed splash guard electromagnetic round chuck, fine pole pitch (1+3 mm) working lamp warning lamp operating manual in German and English ALTERNATIVE: model version FRG-600S with Smart iControl for profile grinding moreprice € 3.600,00

Condition: new, neu ca. 6 Monate ab Auftragse Taiwan 108950 € 2059.16 € 610 mm 600 mm 600 x 300 mm 600 x 300 mm 5 - 25 m/min 0 - 3000 mm/min 0,001 mm 350 mm 440 mm 0 - 3000 mm/min 0.001 mm 500 - 1800 1/min 11 kW 2.2 kW 4020 mm 2450 mm 2080 mm 3400 x 2220 x 2530 mm 3700 kg 975 mm 195 kg 370 kg 355 x 50 x 127 mm 1,1 / 1,1 kW 0,005 mm 0,005 mm Hodpfx Alowiq H Tj Sol Smart i control with 10.4" touchscreen on a swiveling panel, with electronic wired handwheel - RS232, USB I/O connection - SMART Grind Cam (dxf transfer in G code) -PC based control with graphical dialog programming or G-code programming Infinitely variable speed Surface grinding cycle, cross grinding cycle, plunge grinding cycle, multiple groove grinding cycle, contour grinding cycle, dressing cycle Spindle with 4 angular contact ball bearings (P4, class 7) Longitudinal and cross guides with heavy duty needle roller bearing for low friction, better accuracy and lower maintenance costs Transverse and vertical feed with precision ball screws (class C2) and AC servo motors Longitudinal feed hydraulically Fully enclosed splash guard with lamp Electromagnetic chuck plate Coolant system 120 lt with automatic paper filter and magnetic separator Automatic diamond roller dresser mounted on the table, with automatic compensation * Grinding wheel Grinding wheel flange Grinding wheel balancing scale Machine and equipment in accordance with CE regulations Operating manual in GERMAN or ENGLISH Accuracy standard ISO 1986-1 * The exact configuration of the dresser must be clarified before ordering

Condition: new, neu ca. 6 Monate ab Auftragse Taiwan 118700 € 2243.43 € 1200 mm 730 mm 1.200 x 500 mm 1.200 x 500 mm max. 30 m/min 3.7 kW 27 kVA kW 4600 mm 3040 mm 2200 mm 6400 kg 990 mm 930 kg 1250 kg 405 x 50 x 127 mm 0,001 mm 500 - 2.000 U/min 11 kW 10.4" graphic NC control on a swivel arm with touchscreen for: Operating mode selection Cycle selection and program creation Surface grinding Cross grinding Plunge grinding Dressing with automatic compensation Semi-automatic balancing in the machine Automatic spindle speed for constant surface speed Spindle load visualization Unbalance control Graphical status monitoring Alarm list Max. table speed (X axis) 30 m/min vertical feed by servo drive and ballscrew spindle transversal feed by servo motor and ballscrew spindle double V-slide wasy (turcite-B) for table longitudinal move grinding wheel spindle on 6 high precision angular contact bearings electro-magnetic chuck coolant equiptment with aut. paper filter and magnetic separator autom. dressing attachment table mounted with compensation * grinding wheel grinding wheel flange grinding wheel balancing stand balance arbor LED machine lamp machine and equipment according to the CE-regulations user manual in GERMAN and ENGLISH * The exact configuration of the dresser must be clarified before ordering Hsdpfx Alewiq Hmo Sol
