Used Punching Cylinders for sale (9,062)

Condition: used, This Krause C64-50 Autofeed Die Cutter is a powerful machine designed for precise and efficient die cutting work. With a maximum format of 600 x 500 mm, it offers the flexibility to handle a wide range of materials. The machine is currently located in the Netherlands and is standing still, which represents an ideal opportunity for those looking for a high-quality die cutting machine. Format: 600 x 500 mm Equipment: Krause autofeed die cutter Max. Size: 60 x 50 cm (23 x 19 inch) Pjdpfxovfx Ulj Afljpw

Condition: used, Year of construction: 1959, The Heidelberg OHT, manufactured in 1959, is a machine with an A4 format. It is currently in production and located in Germany. The delivery terms are FCA. Format: A4 Equipment: Letter Press Tiegel - DIE Cutter Punching force 40 tons Ppsdpfx Aovfxwtefljw Size min.: 40 x 70 mm Standard chase: 260 x 340mm Speed min.: 2.200 sph - max. 5.500 sph

Condition: used, Year of construction: 1973, The Heidelberg OHT, manufactured by Heidelberg in 1973, is a robust machine designed for printing and die-cutting operations. With a format of A4, it is currently in storage in Germany. Identified by the machine number T 184634 H, this press has a punching force of 40 tons and can handle a minimum format of 40 x 70 mm. It operates at a speed ranging from a minimum of 2,200 revolutions per minute to a maximum of 5,500 revolutions per hour. The machine includes a skeleton chase of 260 x 350 mm and a standard chase of 260 x 340 mm, with a maximum format of 260 x 380 mm. It comes complete with accessories and a closing frame, and features a letterpress platen and a die-cutting platen. The delivery condition is FCA. Ppjdpfx Aevfxu Eofljw Format: A4 Speed: 5500 Power: 380 V 1,25 KW Net Weight: 1100 KG Measurements: L1,68 x B1,24 x H1,85m Equipment: Skeleton chase: 260 x 350mm Speed min.: 2.200 sph - max. 5.500 sph Size max. 260 x 380 mm Letter Press Tiegel - DIE Cutter Punching force 40 tons Size min.: 40 x 70 mm Complete with tools and accessories include frame Standard chase: 260 x 340mm Machines No T 184634 H

Condition: used, Cylinders, bottles used for gas transport 20/40/50 L, 200/300 bar Psdpfx Aeyfpg Neflopw T50 steel gas cylinder, bottle 50 L 200 bar 288 pieces T40 steel gas cylinder, bottle 40 L 200 bar 288 pieces T23 steel gas cylinder, bottle 20 L 300 bar 288 pieces All bottles are complete, empty and ready for export.

Condition: excellent (used), Year of construction: 2010, functionality: fully functional, operating hours: 9,800 h, Description EDEL - STANZTECH PROFILTEC - 2030 WITH LOW HOURS - 9800 HOURS MACHINE RUN PER DAY 2 TO 3 HOURS ONLY MACHINE IS ECELLENT CONDITION Ppsdpsvk R Rpsfx Aflow LENGTH OF WORKING 3000mm tubes TECHNICAL DETAILS Riexinger control system: V1.0 Punching force: 260kN Drive system: hydraulic Stroke sequences: max. 50 1/min Feed length: 3,000 mm Max. Lifting height: A-axis 60 mm Max. Positioning speed: X-direction programmable up to max. 64 Smallest programmable linear axis travel: 0.1 mm MACHINE DETAILS Hydraulic operating pressure: 190 bar Nominal power of the pump motor: 15kW Pump capacity: 2 x 48 l/min Tank capacity of hydraulic unit: 200 l Connected load: kVA 22 Operating pressure: min. 6 bar EQUIPMENT - Standard accessories - Hydraulic unit - Switch cabinet - Roller conveyor - Documentation MACHINE WEIGHT 2000 KG

Condition: ready for operation (used), Year of construction: 1998, functionality: fully functional, punching force: 20 t, sheet thickness steel (max.): 6 mm, punching diameter: 105 mm, workpiece length (max.): 1,000 mm, workpiece width (max.): 2,500 mm, No minimum price – guaranteed sale to the highest bidder! TECHNICAL DETAILS Punching force: 20 t Sheet metal thickness (steel, max.): 6 mm Max. sheet metal dimensions: 1,000 mm x 2,500 mm Punching force: 200 kN Max. punching diameter: 105 mm Max. sheet metal thickness: 6 mm Max. stroke rate: 180 strokes/min MACHINE DETAILS Mains voltage: 3 x 400 V / 50 Hz Pjdpfszkvpaex Afljpw Connected load: 10 kVA Control voltage: 24 / 230 V Required fuse rating: 3 x 20 A

Condition: new, functionality: unexamined, Year of construction: 2024, machine/vehicle number: 16.41-PS0382, control type: CNC control, degree of automation: automatic, actuation type: electric, sheet thickness (max.): 8 mm, input voltage: 400 V, input current: 20 A, type of input current: three-phase, 2024 Pima Power PS 1225 Brand new Complete machine. Machine was tipped on its side during transit and was damaged. Machine is stored in Our warehouse in California USA. Pedpjw Nbh Hsfx Aflopw Contact to set up in person inspection.

Condition: excellent (used), Year of construction: 2016, Ref:11127 . 2016 SCS Automaberg Trim & Perf Die-cut, Trim, Split, Cut, Perforate, Punch System, handling any material. Recently serviced (at a cost of £5k). A highly versatile and productive line which is a genuine “ALL-IN-ONE” solution for finishing operations. The line can include different workstations for multiple tasks and process optimization. The combination of TRIM & PERF with complementary modules offers high quality products combined with reliability, allowing the needs of digital systems to be met, as well as those for binding, in particular, the production of products for single and multi-up work IN A SINGLE PASS. Features: Easily moveable. In-feed belt height adjustable for easy connection with upstream machines. A simple push button transforms TRIM & PERF into a regular conveyor belt, no bypass or similar equipment needed. ‘CONTINUOUS FEEDER’ Top loading, bottom feeding, rubber belt type feeder for single or folded sheets, saddle stitched products and perfect bound books. ‘3 WAY’ This module allows perfect alignment of digital sheets to a print reference mark. ‘GRIPPER’ Electronic system for pass die-cutting: reduces machine set-up times and overlaying, allows a high level of product repeatability and reduces costs of American style dinking dies. Waste ejection system allows for die cutting without waste, clean shape products. ‘THERMO STICK’ holds some sheets together on the ink reference sides by ‘thermo’ welding - improving the die cutting process. Pedpfx Afezmx Scolepw ‘PRE-CUT DEVICE’ Perfect 'spine' cutting system up to 14 mm thickness. ‘TEAR OFF - PULL AWAY’ The system pulls away mingled perforation sheets in preparation for the sewing step. ‘SIMPLE DECK’ Collects cards in series after die cutting. ‘EXIT BELT’ Shingle delivery belt with batch counter. DIE CUTTING No nicks! Connections between the cut product and the waste are not required. Automatic waste ejection. 'Clean' shapes ready to be packed. TRIMMING-SPLITTING Superior quality in splitting and trimming - also for very small dimensions. ROUND CORNER CUTTING Cutting including all four corners in a single pass. PERFORATING PUNCHING Combined perforating-punching jobs in a single pass to optimize production process efficiency. IDEAL FOR:- Flat cardboard, also laminated up to 2 mm thickness, and on plastic material up to 1 mm thickness. Folded and stitched product die cut without waste. Pre-cut device for perfect spine cutting up to 14 mm thickness. Standard corner radii from 3 to 15 mm. Stamp perforating, wire-comb perforating, tear-off perforating, single hole punching, file hole punching, euro hole. TOOLING, PLEASE NOTE: The machine only comes with the pre trim device. Also includes the metal caddie to hold various dies so you can easily swap in different wooden steel rule dies as required. Specifications: Product size untrimmed (LxW) (sizes subject to jobs) Standard max. 500 x 600 mm Standard min. 50 x 50 mm Product thickness, Standard max. 4mm (optional max.) 14mm Mechanical speed, max. 9.000 cycles/hr Compressed air requirement: 200 l/min at 6 bar.

Condition: used, Year of construction: 2015, functionality: fully functional, overall weight: 24,000 kg, sheet thickness steel (max.): 60 mm, cutting length (max.): 6,000 mm, cutting width (max.): 2,540 mm, drill diameter: 40 mm, FICEP TIPO B254 - CNC PUNCHING, DRILLING & THERMAL CUTTING CENTER | YEAR 2015 The Ficep Tipo B254 is a CNC-controlled punching, drilling and thermal cutting center for the complete processing of steel plates and flat products in a single pass. Punching, drilling, countersinking, tapping, marking and thermal cutting via plasma and oxy-fuel are carried out on one machine without intermediate handling. CONDITION Pjdpfx Asxn T H Djflopw Used - technically sound. The machine is currently in productive operation and CAN BE INSPECTED UNDER POWER (by appointment). Handover as preferred: directly from ongoing production (cleaned and serviced) or - at additional cost - reconditioned by ASM. Details on the technical condition are disclosed individually upon serious interest. FUNCTION & APPLICATION The system combines three processing units in one CNC-controlled line: hydraulic punching unit (1000 kN), drilling head (20.1 kW) and thermal cutting unit with plasma torch (Hypertherm HPR 260) plus oxy-fuel torch. All processes run via the Mitrol CNC as automated machining cycles; the machine processes steel plates up to 2540 x 6000 mm. Typical applications: structural steel fabrication, structural engineering and prefabrication of gusset plates, end plates and connection plates. TECHNICAL DATA - Machine type: Automatic CNC punching and thermal cutting system for plates - Year: 2015 | Serial number: 34201 | Machine weight: 24,000 kg - Working height: approx. 1,090 mm | Max. positioning weight (plate): 5,000 kg - Max. plate size: 2540 x 6000 mm | Min. plate width: 508 mm - Punching force: 1000 kN | Stripping force: 100 kN | Punching tools: 8 - Max. punch diameter: 32 mm | Max. punching thickness: 20 mm - Drilling heads: 1 | Drilling tools per head: 8 - Max. drilling diameter: 40 mm | Max. drilling thickness: 100 mm - Spindle power: 20.1 kW | Max. spindle speed: 4000 rpm - Plasma torches: 1 | Oxy-fuel torches: 1 | Plasma source: Hypertherm HPR 260 - Max. plasma cutting thickness: 35 mm (pierce start) / 60 mm (edge start) - Max. longitudinal feed speed: 30 m/min - CNC control: Mitrol CNC (master/slave), online remote diagnostics - Processes: punching, drilling, countersinking, tapping, milling, marking, scribing, oxy-fuel and plasma cutting Min. plate length, max. overall material thickness and cross positioning speed are confirmed during inspection. SCOPE OF DELIVERY - 1 x Ficep Tipo B254 plate processing center (year 2015) - 1 x Hydraulic punching unit 1000 kN with 8-position tool changer - 1 x Drilling unit 20.1 kW with 8-position tool changer - 1 x Plasma cutting torch | 1 x Oxy-fuel cutting torch - 1 x Hypertherm HPR 260 plasma cutting system - 1 x Marking unit (configuration to be confirmed during inspection) - 1 x Chip conveyor - 1 x Donaldson Torit dust extraction system | 1 x Punching tool set LOGISTICS & LOCATION Location: Ulft (Netherlands), directly at the German border. Dismantling, transport, installation and commissioning by ASM by arrangement - individually calculated upon request. ABOUT ASM Arendsen Steel Machinery (ASM) specializes in Ficep structural steel machines. Further Ficep machines on request. CONTACT / INQUIRY Arrange a viewing under power | Price on request | Request a callback. Sale exclusively to commercial customers (B2B).

Condition: new, Year of construction: 2026, functionality: fully functional, pressing force: 25 t, stroke length: 400 mm, reverse speed: 20 mm/s, table width: 1,000 mm, table length: 600 mm, table height: 1,000 mm, For sale is a hydraulic sub-platen press from the manufacturer DURENDUS with a maximum pressing force of 25 tons. The machine has a table size of 1,000 × 600 mm, a maximum installation height of 600 mm, and a stroke of 400 mm, making it suitable for assembly, straightening, pressing, and forming operations in industrial applications. ##### Technical data + information: Sub-platen press – 25 T – 1,000 × 600 mm ==== General information - Reference ID: DE-2026-HB-227-01 - Design: 4-column sub-platen press - Manufacturer: DURENDUS - Pressing force: 25 T (adjustable) - Table size: 1,000 × 600 mm - Maximum installation height: 600 mm - Working height: 1,000 mm Ppodpfx Afjzp Ex Ujlsw - Overall height: approx. 1,850 mm - Overall width: approx. 1,750 mm - Overall depth: approx. 1,200 mm - Total weight: approx. 2,000 kg ==== Hydraulic cylinder - Stroke: 400 mm - Cylinder diameter: Ø 115 mm - Piston rod diameter: Ø 90 mm - Working pressure: 250 bar - Return speed: 20 mm/s - Idling speed: 10 mm/s ==== Hydraulics & drive - Hydraulic pump: 6 l/min - Motor power: 3 kW - Tank volume: 30 l - Pressure accuracy: ±5 bar - Hydraulic block and valves: DUPLOMATIC - Air and oil filter: FILTREC - Pressure gauge for pressure indication - Hydraulic unit: mounted at the bottom of the press - Hydraulic oil: HLP46 (not included) ==== Control - Operation: hand valve - Operating mode: manual - Pressure adjustment: rotary control - Stroke limitation: manual via sensor - Siemens components in the control cabinet ==== Safety - 4-column guidance with Ø 60 mm guides - Safety monitoring - CE-compliant design ==== Electrical connection - Main supply: 400 V AC - Control voltage: 24 V DC - Frequency: 50 Hz - Main motor connection power: 4 kW - Total connection power: approx. 5 kW - Protection class of the control cabinet: IP54 ##### Application areas: pressing, forming, straightening, assembly work, jig and fixture construction, toolmaking, metalworking, mechanical engineering, maintenance, small series production (Sub-platen press, hydraulic sub-platen press, hydraulic press, 25 T press, 25 ton press, 4-column press, column press, assembly press, straightening press, pressing press, forming press, industrial press) Are you looking for a hydraulic press tailored to your specific application? Contact us for an individual offer. Our hydraulic presses are manufactured according to German and European Machinery Directives (Directive 2006/42/EC), EC standards, and EU safety regulations. Furthermore, our presses exceed Canadian and European safety requirements, as they comply with all points of the national Brazilian safety directive NR 12, which is based on these. Our strength lies in the design and manufacture of special machines and the automation of presses. We distribute custom-made hydraulic presses at surprisingly affordable prices. Predominantly, components from leading European manufacturers are used for the hydraulics of the presses.

Condition: good (used), Triangular notching tool, notching side knife, die holder, separating tool, punching tool, punch, punching die, corner notching punch, punching punch, square notching punch, notching punch, notching tool -Punching tool: Holder for punching tool -Holes: Ø 60 mm -Dimensions: see photos -Dimensions: 253/71/H104 mm -Weight: 6.6 kg Podpfjzpwq Njx Aflepw

Condition: good (used), functionality: fully functional, Amada LC 2012 C1 NT / Punch-Laser Machine, Year of manufacture 2012, Ppedpozp D H Dsfx Aflow Control system: AMNG - Fanuc Series, Punching force: 200 kN, Punching area: 2,500 x 1,270 mm, Laser power: 2,500 W, Laser cutting area: 2,000 x 1,270 mm, Z-axis travel: 100 mm, Max. table load: 150 kg, Revolver turret: 46 stations.

Condition: new, functionality: fully functional, machine/vehicle number: 102164, screw diameter: 20 mm, Brand new injection unit for ARBURG machines – fully equipped and ready for immediate use For sale is a completely new injection unit for ARBURG machines, comprising: Ppedpfx Ajwlcf Hjflsw Cylinder with check valve Heating bands Nozzle Screw The unit was originally purchased as a spare cylinder for cleanroom production and was stored exclusively in a cleanroom warehouse. To protect against possible moisture it was permanently wrapped in oil paper and never used. Condition: unused, as new Storage: cleanroom, protected in original packaging Application: ideal as an immediately available replacement or exchange unit Perfect for anyone who needs a high-quality injection unit quickly and without lead times. Please feel free to contact me if you have any questions or are interested! I purchase all machines and peripheral equipment directly from customers at a fair price. The subsequent selling price is calculated reasonably so that all three parties – seller, buyer, and I as the intermediary – can conclude a fair transaction. Unscrupulous offers from various used machinery dealers are therefore not welcome.

Condition: excellent (used), We have five ARBURG cylinders available: 1 x 18 mm Ppjdpfx Asxy Sx Nsflsw 2 x 20 mm 1 x 30 mm The price is per piece.

Condition: used, Year of construction: 1994, KAISER Press Pressing force 4,000 kN Ppedozp Ed Rspfx Aflow Stroke adjustment 40-200 mm Ram adjustment 150 mm Stroke rate 20-80 1/min Table area 2,340 x 1,600 mm Ram area 2,000 x 1,500 mm Installation height 550 mm

Year of construction: 2011, condition: ready for operation (used), A Trumpf CNC punching machine is offered. Max. punching force: 180kN, working range X/Y: 2500mm/1250mm, max. sheet thickness: 6.4mm, max. workpiece weight: 160kg, max. punching diameter: 76.2mm, axis speed: approx. 100m/s, max. punching stroke rate: approx. 1000 strokes/min, max. marking stroke rate: approx. 2500 strokes/min, tool magazine: 18, clamps: 2, max. part size X/Y: 500mm/500mm, operating hours: 22146h. Including tool cassettes, various punches and dies, a MultiTool, and Easy Type. Weight: approx. 9.8t, machine dimensions X/Y/Z: approx. 6500mm/6203mm/2252mm. Documentation available. An on-site inspection is possible. Psdpfx Afjzpyygslspw

Condition: excellent (used), Year of construction: 2002, Model .Amada. Vipros 368 King Stock number 01967 Year of manufacture 2002 Frame Construction ... Bridge Type Press Capacity ... 30 Tonnes (294 kN) Press Type ... High Speed Hydraulic Servo Ram Axis Traverse Distance ... 1525 x 2000 mm Workable Max. Sheet Size ... 1525 x 4000 mm (with auto repositioning) Max. Material Thickness ... 3.2 mm mild steel Max. Hole Dia. Max. Material ... . (shearing strength 36 kg/mm2) 82 mm dia Max. Material Weight ... 75 Kg Max. Material weight ( Max. Speed) ... 60 Kg Max. Hole Dia. ... 114.3 mm Number Of Stations ... 58 stations:24 x 12.7 mm 24 x 31.7 mm 4 x 50.8 mm 2 x 88.9 mm Auto Index 2 x 31.7 mm 2 x 114.3 mm Axis Speed ... 113.0 m/min Hits Per Minute (2mm pitch) ... 860 H.P.M./3 mm stroke (8mm pitch) ... 560 H.P.M./3 mm stroke (25mm pitch) ... 460 H.P.M./3 mm stroke Turret Speed Bi-Directional ... 30 R.P.M. Punching Accuracy ... ± 0.1 mm (incl. 1 reposition) Ram Stoke Length (maximum) ... 40 mm Tool Lubrication ... Air Blow System Axis Drive ... AC Servo Motor Turret Drive ... AC Servo Motor Electric Power Required ... 28 kVA 400V +/- 10% 50Hz Air Pressure Required ... 5.0 Kgf/cm2 Air Flow ... 250 1/min Cooling Water Flow ... Min 40 1/min. Machine Length ... 5025 mm Machine Width ... 4120 mm Machine Height ... 2630 mm (3190 mm to mirror) Machine Weight ... 18000 Kg Ppjdevn D Tfspfx Afljw

Condition: excellent (used), Year of construction: 2007, AMADA LKI MP 300 LOAD UNLOAD AUTOMATION Year 2007 LKI MP 300M automatic sheet loader / manipulator with 3000mm x 1500mm sheet capacity. Pjdpfx Asyylqbeflepw

Condition: good (used), pressure 100 t punching cross-cut in cmm 40.0 in 22.0 mm ST stroke 120 mm column arm 760 mm total power requirement 8.5 kW weight of the machine ca. ca. 3.800 kg dimensions of the machine ca. ca. 2500 x 1700 x 2000 mm Original price, including stop system: approx. 45.000 euros Special price available upon request Features: - Robust / heavy-duty hydraulic hole punch - Punch stroke continuously adjustable Psdpfozn Ahkox Aflopw - NC stop system "MUBEA MATIC 82" * Travel range in X and Y axes * With "FAGOR" control unit * Includes large support table * Separate control cabinet - Various (custom) punching tools (see Figure 9) - Front safety guard, including sheet metal scraper - 1 freely movable foot switch - Operating instructions for machine and stop system

Condition: good (used), Separating tool, punching tool, punch, punch die, punch stamp, -Stamping tool: Die holder with fine adjustment Pjdpeznu Ayofx Afljpw -Bore: Ø 25 mm -Dimensions: see photos -Dimensions: 300/250/H210 mm -Weight: 32.1 kg

Condition: good (used), Pneumatic cylinder, air cylinder, pneumatic piston, air piston -Manufacturer: Festo, standard cylinder type DNB-32-40-PPV-A -Stroke travel: 40 mm -Piston: Ø 32 mm -Piston rod: Ø 12 mm -Max. pressure: 12 bar Pedpfxsznt Dps Afljpw -Quantity: 1 cylinder available -Dimensions: 255/45/H70 mm -Weight: 0.8 kg

Condition: good (used), Year of construction: 2001, Punching machine, Boschert EL300 Tooling system: AMADA Pedpfx Aodnny Roflopw Up to tool station D, diameter 88.9 mm New tool adapters for stations A/B/C Punching force: 280 kN (28 tons) Punching arm outreach: 350 mm Side stop: 500 mm, right/left Depth stop with digital display Side stops: new Total weight: 2300 kg

Condition: used, Year of construction: 1994, Product information "Boschert Hydraulic CNC Punching Machine" Type / Model: Boschert EL 750 digital Condition: Used Year of manufacture: 1994 Technical data Working area & dimensions Overhang (Y-axis): 750 mm Travel range (X-axis): 1500 mm Max. sheet size (without repositioning): 720 x 1700 mm Performance data & capacity Max. hydraulic punching force: Standard 280 kN Max. sheet thickness*: up to 12.7 mm Max. punching diameter: Ø 105 mm Stroke rate: max. 100 strokes/min Tooling: Original Trumpf® tool system Positioning accuracy with 2-axis digital display: ± 0.1 mm Connection power: 4 kVA Control voltage: 220 V Required fuse rating: 3 x 16 A Installation dimensions (W x D x H): approx. 3400 mm x 1580 mm x 1600 mm Weight: approx. 3400 kg Ppsdpezp Raqofx Afljw Equipment - includes various tools / accessories * Material-dependent, usually designed for thin sheet metal up to 6 mm at full diameter or any shape that fits into a circle of Ø 105 mm Inquiry item: Transportation costs in individual offer.

Condition: excellent (used), Year of construction: 2010, Boschert TRI 1500 CNC Z Rota Revo TRUMPF quick tool change system Punching force: 3 x 280 kN (28 tons) Station 1 Trumpf system tool - size 3 (105 mm) with spray device Station 2 Trumpf system tool - size 3 (105 mm) with freely indexable rotation Station 3 Trumpf system tool / Boschert Revotool - size 3 (105 mm) incl. Revotool with 8-position tool holder Travel distances x- 3000 mm (repositioning up to 9999 mm) y- 1580 mm Punching arm overhang: 1730 mm Tool system Trumpf size 1-3 (105mm) Labod 32060 graphic control / workshop programmable Max. sheet metal thickness: 6 mm (clamp opening) Max. stroke height: 90 mm, continuously programmable upwards and downwards. Punching scrap extraction Ball bearings in the machine table Table width left + right: 3200 mm each Table depth: 2810 mm Table height: 900 mm Overall width: 6482 mm Overall depth: 4600 mm Overall height: 2110 mm Drive power: 25 kVA Machine weight: 15,800 kg Ppodpfxeid I D Ae Afljw Hydraulic oil capacity: 160 l Color: Blue RAL 5017 / Light gray RAL 7035 Machine year of manufacture: 2010 Very well-maintained condition - Overhauled with a large amount of accessories

Condition: excellent (used), Year of construction: 2003, Boschert EL500 Digital punching machine TRUMPF quick tool change system up to tool size III = diameter 105 mm Punching force: 280 kN (28 tons) Punching arm overhang 560 mm Side stop 1000 mm right/left Equipped with digital display for X-axis (left) and Y-axis (left) Ppedpfoid I Hhex Aflsw Stroke: 40 mm Total weight: 2700 kg including tool cabinet with tools and accessories
