Used Punching Machine for sale (72,436)

Condition: new, functionality: fully functional, Year of construction: 2026, control type: CNC control, degree of automation: automatic, actuation type: electric, controller manufacturer: Raytools, controller model: Raytools, laser type: fiber laser, laser source manufacturer: Raycus, laser source model: Raycus, laser power: 3,000 W, laser wavelength: 1,080 nm, punching diameter: 1 mm, stroke rate (min.): 60 1/min, stroke rate (max.): 65 1/min, working length: 3,000 mm, working width: 1,500 mm, sheet thickness (max.): 20 mm, sheet thickness steel (max.): 20 mm, sheet thickness stainless steel (max.): 12 mm, sheet thickness aluminum (max.): 9 mm, sheet thickness brass (max.): 7 mm, sheet thickness copper (max.): 7 mm, input voltage: 380 V, input frequency: 50 Hz, type of input current: three-phase, overall weight: 2,200 kg, total length: 3,100 mm, total width: 1,600 mm, warranty duration: 12 months, Equipment: CE marking, cooling unit, documentation/manual, emergency stop, safety light barrier, The Digima F1530 3kW is an advanced open-type fiber laser cutting machine designed for precise sheet-metal processing in manufacturing plants, metalworking companies and modern fabrication workshops. It is intended for businesses that require high cutting quality, strong performance and stable, repeatable operation in every The Digima F1530 3kW is equipped with branded components that enhance durability and cutting performance. The machine includes a RAYCUS laser source, a Raytools AUTO FOCUS cutting head, a Raytools control system, a Schneider servo system, a Japanese Shimpo reducer, H-class linear rails and an industrial TONGFEI / S&A cooling system. The entire unit is built on a heavy-duty industrial steel frame that has been heat-treated for improved stability and long-term resistance to deformation. Itjdpfxezlr Syj Ag Aon The machine also provides flexible use of assist gases, allowing the cutting process to be adapted to the material type and the expected edge quality. Oxygen at 1 MPa can be used for carbon steel, nitrogen at 2.5 MPa is intended for stainless steel and aluminium, and compressed air at 1.4–1.6 MPa offers a more economical option for thinner parts. This gives the user better control over cutting quality, process speed and operating costs. As standard, the machine includes features that improve operator safety and protect key components. A laser-head cover helps protect the cutting head from dirt and mechanical damage, while safety barriers create an additional protective zone around the working area, improving safety during intensive production work. The Digima F1530 3kW is powered by a 3P 380 V / 50 Hz supply, and the machine itself weighs 2000 kg. It is a modern and efficient fiber laser cutter for companies looking for a solution that combines a large working area, high precision, fast operation and industrial-grade durability. This model is a strong choice wherever reliable production, high cutting quality and future production growth are important.

Condition: good (used), Year of construction: 1999, operating hours: 52,324 h, functionality: fully functional, X working area max.: 1270 mm Y working area max.: 1270 mm Control: Bosch Type 3 Basic Standard equipment: - Robust C-frame - Safety light barriers - Coordinate guide with integrated linear magazine - 2 clamping claws - Automatic tool changer - Automatic repositioning - Tool length compensation Iedsz Rl T Tepfx Ag Ajtn - Forming capability - Mono tool holder with 360° rotation for all tools - Programmable hold-down device - Multitool drive - Punch slug extraction - Brush tables - Part chute 200 x 200 mm, sorting of parts into 2 containers - NC-controlled, digital, maintenance-free three-phase drives - Network interface RJ34 - 3.5" floppy disk drive - TOPS 2000 graphical programming - Online diagnostics via modem - Operating manual + Vibration-damped installation + Multitool + Thread forming + Start post

Condition: good (used), Year of construction: 2006, operating hours: 47,962 h, functionality: fully functional, type of input current: three-phase, overall weight: 18,000 kg, input current: 40 A, input frequency: 55 Hz, input voltage: 380 V, Equipment: safety light barrier, We are selling: Isdsz R Atqopfx Ag Aotn a well-maintained Amada punching and nibbling machine, used only for thin sheet metal applications. Maintenance was performed by AMADA. Without tooling. The machine is being sold due to a new investment. The buyer must dismantle and collect the machine in DE-84051 Mettenbach. The machine can be inspected in operational condition in DE-84051 Mettenbach by appointment. Sale only to commercial customers and with the exclusion of any warranty!

Condition: used, functionality: fully functional, Year of construction: 1994, machine/vehicle number: 070027, control type: CNC control, punching force: 150 t, punching diameter: 76 mm, sheet thickness (max.): 6 mm, overall weight: 8,000 kg, input voltage: 380 V, input frequency: 50 Hz, type of input current: three-phase, Equipment: CE marking, documentation/manual, emergency stop, foot remote control, Trumpf Trumatic 200 CNC punching machine For sale: a Trumpf Trumatic 200 CNC punching machine (internal designation TC 200 R), manufactured in Germany in 1994. Well-maintained, fully operational, and available for inspection at our facility in Zaragoza, Spain. Type: 9095 — Serial number: 070027 Year of manufacture: 1994 Isdpfx Aoz E R S Aog Ajtn Max. punching force: 150 kN Machine weight: 8,000 kg Power supply: 380V / 50Hz — Connected load: 14 kVA — Control voltage: 24V DC Required fuse protection: 3x25A Compressed air connection: 6 bar Comes complete with tooling and cassettes. For reference, standard specifications of this model: working area 2,070 x 1,280 mm, max. sheet thickness 6.4 mm, max. punch diameter 76.2 mm, X-axis speed 80 m/min, Y-axis speed 55 m/min. For technical questions or to arrange a visit, please contact us by email – we will be happy to answer any questions or send further photos/videos of the machine in operation.

Condition: used, total length: 2,100 mm, total width: 1,000 mm, total height: 2,450 mm, Colour: White Empty weight: 4.600 kg Isdpo Aatr Uofx Ag Astn Iron worker, punch press and section shear  Including Length-Stop Hersteller: Mubea / Muhr & Bender Type: Hydraulic Type: KBLH 1000 Capacity: 110 ton Shear plate: 200x26mm, 500x20mm Notching: 85x75x16mm Throat: 510mm Machine-weight: 4600kg - Documentation available: Yes - Drive system: Conventional - Drive: Hydraulic - Punching force [ton]: 110 - Punch throat depth [mm]: 510 - Notching width [mm]: 200 - Shearing width [mm]: 500 - Max. plate thickness shearing [mm]: 2.5 - Options: Length stop - Transport dimensions: 2100mm x 1000mm x 2450mm (l x w x h) - Transport weight [kg]: 4600kg - Transport packages [pcs.]: 1 Financial information VAT: The price shown is exclusive of VAT VAT/margin: VAT deductible for entrepreneurs Delivery and trade-in always possible for everything in the industrial sectors Lukas van Rossum

Condition: used, Year of construction: 2021, functionality: fully functional, machine/vehicle number: A/18031, SCHULER - MSP2-800- 4,5x1,8-400 Isdpfx Agjzxqz Ts Aotn Kapasite: 800 ton Hava Tüketimi: 30 m³/saat Güç: 296 kW Üst Tabla Ebatları: 4500 mm x 1700 mm Alt Tabla Ebatları: 4500 mm x 1800 mm Pres Yükseklik: 7,5 m Pres En: 6,50 m Pres Genişlik: 4,50 m Dakikadaki Vuruş Sayısı(maksimum): 70 spm Çalışma Reglajı: 300 Kurs Değeri: 80-360 Used machine

Condition: excellent (used), functionality: fully functional, Year of construction: 2006, operating hours: 83,800 h, Equipment: CE marking, LVD STRIPPIT GLOBAL 30 1225 turret press The machine is in very good technical condition and was used by Alsanit. It has been regularly serviced exclusively by the manufacturer's service department. Only new and original spare parts are used during service. The turret press is currently in continuous production use. If you are interested, we encourage you to schedule a visit to confirm the technical condition and technological capabilities of the machine. General data: Location: Alsanit Sp. z o.o., ul. Wieleńska 2, 64-980 Trzcianka, Poland Province: Wielkopolskie Year of manufacture of the turret press: 2006 Date of purchase and installation of the machine: June 2019 Machine operating hours: 83584 cycles Maximum pressing force: 300 kN (30 tons) Maximum sheet thickness: 6.4 mm Turret system type: Thick Turret Control unit: CNC: GE FANUC 180 IP Maximum travel in the X-axis: 2,576 mm Maximum travel in the Y-axis: 1,337 mm Maximum table load (uniform): 145.6 kg Simultaneous speeds: 110 m/min Number of strokes per minute (punch diameter 25 mm): ±2% 400 min-1 Number of strokes per minute (nibbling function - 2 mm): 1000 min-1 Number of strokes per minute (marking/0.5 mm): 1700 min-1 Maximum slide speed in the X-axis: 83 m/min Maximum slide speed in the Y-axis: 73 m/min Number of tool stations in the turret: 30 pcs Station A – max. diameter 12.7 mm: 8 pcs Station B – max. diameter 31.7 mm: 16 pcs Station C – max. diameter 50.8 mm: 2 pcs Station D – max. diameter 88.9 mm: 4 pcs Number of indexed (rotary) stations in the turret: 4 pcs (stations D) Note: Each station D can accommodate a multi-tool (1 multi-tool contains 3 to 8 tools), which increases the number of tools from 12 to 32 pcs. Machine height: 2,325 mm Machine length: 5,584 mm Machine width: 5,160 mm Machine weight: 13,750 kg Sheet size: 1250 x 2500 mm Iodpfxszxzagj Ag Aetn Number of sheet clamps (individually programmable): 3 pcs Tilting scrap collector for cut parts: 450 x 500 mm Brush table protecting against scratching the sheets CE certificate Electrical power supply: 380/415 Volt, 35.5 kVA, 63 A, cable cross-section (3+1)x16 mm2 Additional equipment: Scrap conveyor; Brush table MACHINE SPECIFICATION The machine is constructed as a closed bridge frame. The rigid construction ensures stability, reduces noise, vibrations, and oscillations during operation, which in turn has a positive effect on the long service life of both the tools and the machine. The sheet clamps are controlled by a foot switch, and the pin that extends from the table for positioning allows the operator's hands to remain free for proper placement of the sheet on the table. The turret drum of the LVD Strippit Global 30 punch press is made as a cast monoblock, mounted in the machine structure and supported by high-quality and precise bearings. In addition, inside the turret drum, in each tool station, there are hardened and improved sleeves, which can be easily replaced if necessary. The servo drive of the turret ensures precise bidirectional rotation of the turret and the indexing stations (which are locked by a ball head pin after reaching the required angular position, and the accurate linearity and perpendicularity are ensured by tapered, hardened sleeves).

Year of construction: 1993, condition: used, Year of construction: 1993 Empty weight: 9.300 kg Dimensions (LxBxH): 442 x 280 x 195 cm Serial number: 210045 Year of manufacture: 1993 Cutting force: 20 metric tons, 200 kN Maximum sheet thickness for punching and nibbling: 6.4 mm Maximum punch diameter: 88.9 mm Working range in the transverse direction (X-axis): 1,270 / 2,540 mm Working range in the longitudinal direction (Y-axis): 1,000 mm Control system: Fanuc 16P Ijdsz R S Thjpfx Ag Astn Tool changer: yes Number of tool stations: 19 positions (16 fixed + 3 index) Required power capacity: 23 kVA Turret revolver with 16 + 3 x Auto Index Holders Length: 4,425 mm Width: 2800 mm Height: 1950 mm Weight: 9300 kg Central lubrication: yes Condition: fully serviced and overhauled Additional loading charges may apply Online auction of metalworking machines, woodworking machines, overhead cranes, workshop equipment, and lumber inventory, including an AMADA Arcade 210 CNC punch and nibbler, MAZAK VTC-41L and MT-V-515 vertical CNC machining centers, MAZAK Super Turbo-X 48 Mk II CO₂ laser cutting machine, BYSTRONIC Byjet 4022 CNC waterjet cutting machine, TECNOMA profiling and roll forming machines, ELUMATEC and EMMEGI aluminum sawing machines, HACO ERMS 200-metric-ton CNC press brake, ADIRA CNC press brake, LEFORT C 265T hydraulic scrap baler/shear combination, ESAB Pegasus CNC plasma cutting machine, GEMA powder coating machine with drying oven and exhaust system, EURO-MAC punching and nibbling machine, various KONE and DEMAG overhead cranes, VECOPLAN industrial shredder, NEDERMANN filter unit, METORA band saw, various metalworking and woodworking machines, panel saws, edge banders, milling machines, drills, compressors, workbenches, teak beams, sawn logs, and various accessories, etc. The online auction opens Wednesday 14 October and closes Tuesday 24 November. Register your account via our website and place your bid. For viewings and inspections check the auction information on the website. Viewing day is on: - Tuesday 17 November Pickup days are on: - Tuesday 1 December - Thursday 3 December Dome Auctions is an innovative auction platform dedicated exclusively to the industrial sector. By focusing on machinery sales from business closures, restructurings, and bankruptcies, we provide a trusted marketplace where buyers and sellers connect with confidence. Unlike general auction houses, Dome Auctions specializes in selling complete industrial assets directly from factories, ensuring quality and reliability. With a commitment to transparency, industry expertise, and tailored service, we streamline the sales process and maximize value for all parties. As online auctions continue to grow in the European industrial market, Dome Auctions offers a professional and efficient solution for companies seeking high-quality machinery at competitive prices.

Condition: ready for operation (used), functionality: fully functional, Year of construction: 1994, EDEL - Stanzprofi 250 / Punching machine -CE marking -Year of manufacture 1994 Ijdsz Dq S Topfx Ag Aotn -Depth stop approx. 250 mm -Length stop approx. 500 mm -Working area 1000x500 mm -Tool area up to max. 100 mm -Material thickness up to approx. 10 mm -Punching example - diameter 70 mm in 3 mm sheet metal -Punching example - diameter 25 mm in 8 mm sheet metal -Punching sequence / time interval 1 second -Drive power 1.5 kW -Table dimensions approx. 1350x700 mm -Operating pressure 6 bar -F-Max. 250 KN / (25 MP) -Various punching dies -Machine feet -Documentation Dimensions approx. 1.6x2x1.8 meters / Weight approx. 1400 kg Subject to errors and omissions.

Year of construction: 1987, condition: excellent (used), functionality: fully functional, 1987 Finzer ZUB 250 Multislide Punching & Forming Machine Itedoz S T Inepfx Ag Aon Used 1987 Finzer ZUB 250 multislide machine for sale. 250kN press unit, 6 forming slides, manual decoiler and 250mm feed. Very good condition. Manufacturer: Finzer Model: ZUB 250 Machine Type: Multislide Punching & Forming Machine Year: 1987 Condition: Very Good Machine Description The Finzer ZUB 250 is a heavy-duty mechanical multislide stamping, punching and forming machine designed for the high-volume production of complex components from strip and wire. This machine is equipped with a 250kN / 25-tonne press unit, a set of six forming slides and a manual decoiler, providing a versatile production system capable of combining punching, blanking, bending and forming operations within one production cycle. Multislide technology is particularly effective for components requiring several bends or forming operations from different directions. Compared with conventional single-slide power presses, the multiple independently arranged forming slides allow complex parts to be produced efficiently with reduced secondary operations. Main Specifications Manufacturer: Finzer Model: ZUB 250 Year: 1987 Machine Type: Multislide Punching & Forming Machine / Stamping & Bending Machine Press Capacity: Approx. 250kN / 25 tonnes Number of Forming Slides: 6 Maximum Feed Length: Approx. 250mm Maximum Strip Width: Approx. 60mm Maximum Wire Diameter: Approx. 3mm Forming Slide Capacity: Approx. 30kN per slide Forming Slide Stroke: Approx. 0–50mm Maximum Production Speed: Up to approx. 400 strokes/minute, depending on tooling, component and material Machine Weight: Approx. 4,000kg 250kN / 25 Ton Press Unit The machine incorporates an approximately: 250kN / 25-tonne press station The press operation can then be combined with movements from the surrounding forming slides to produce complex finished components in a continuous cycle. Six Forming Slides This Finzer is supplied with a complete set of six forming slides. The multiple-slide arrangement is one of the main advantages of the ZUB system, allowing tooling to approach the component from several directions during the same production cycle. Forming capacity per slide: 30kN Slide stroke: Adjustable up to approximately 50mm The slides can be tooled for sequential bending, forming and positioning operations. Manual Decoiler Included The machine is supplied with a manual decoiler for coil-fed production. Coil & Strip Feed Capability Comparable Finzer ZUB250 machines are specified with: Maximum Strip Width: Approx. 60mm Maximum Wire Diameter: Approx. 3mm Maximum Feed Length: Approx. 250mm Feed length is typically adjustable to suit the individual component and tooling setup. High-Speed Production Depending on component design and tooling, period ZUB250 specifications quote operating speeds of approximately: 25–400 strokes per minute This makes the Finzer particularly suitable for repetitive, high-volume manufacture where several conventional press and forming operations might otherwise be required. Mechanical Cam-Controlled Multislide System The Finzer ZUB series uses a mechanically controlled cam-driven forming system. Cam-controlled multislide machines are particularly effective for repeat production because the motions of the forming tools can be precisely coordinated with the press and material feed.

Condition: ready for operation (used), functionality: fully functional, control type: manual, actuation type: hydraulic, Geka (Spain) Hydraulic Punching, Shearing, and Notching Machine Model: Hydracrop–55/110A Year of Manufacture: 2001 Flat Bar Shear Capacity: 300 x 15 mm / 200 x 20 mm Blade Length: 305 mm Square: 25 mm Working Height: 880 mm Angle Shear Capacity: 1100 kN Deformation-free Angle Iron: 120 x 120 x 10 mm Angle Iron 45° Shear: 70 x 70 x 7 mm Round and Square Bar Shear Round Steel: 40 mm Square Steel: 40 mm Notcher Sheet Thickness: 10 mm Angle Iron: 100 mm Notch Depth: 90 mm Notch Width: 42 mm Punching Station Capacity: 550 kN Maximum capacity with quick-change system: Ø 40 x 10 mm / Ø 20 x 20 mm Throat Depth: 250 mm Stroke Length: 60 mm Working Height: 1085 mm General Specifications Number of strokes per minute at 20 mm stroke: 25 Power: 3 kW Net weight: 1320 kg Gross weight: 1518 kg Dimensions (L x W x H): 1600 x 1100 x 2000 mm Machine Details - 2 cylinders: one for the punching side, one for the shearing side - Punching unit with quick-change system - C-frame die holder + extra support - Nipple and die up to Ø 40 mm selectable - Flat bar shear incl. support table and 45° and 90° guides - Angle shear - Round and square bar shear (suitable for mounting U and I profiles as well) - Rectangular notcher - Emergency stop - Key switch for notcher safety - Selector switch for deep or shallow punch/shear operation Isdpfeyxpawex Ag Aetn - Selector switch for foot pedal / back gauge - Stroke adjustment for punch and shear side - 2 foot pedals - Scrap collection tray for punch slugs - Dutch instruction manual Includes: Punch table incl. back stops Notching table incl. back stops Electric length stop 1000 mm 30 sets of punch nipples Price of the Geka Hydraulic Punch/Shear/Notch Machine: €16,500 Machine is as new, original paint, like new, original finish Delivery conditions: Delivery time: from stock, subject to prior sale Delivery: ex works Baarle-Nassau Payment: before collection Prices: net, excluding VAT Machinehandel De Leeuw BV cannot be held liable for discrepancies between the technical specifications in this offer and the actual machine, accessories, and/or parts. Machines, accessories, and parts are sold as-is and as known to the buyer. We cannot provide a warranty for used machines, accessories, and parts. Delivery terms: Delivery time: ex stock, excluding VAT Delivery: ex works Baarle-Nassau Payment: before collection Prices: net, excluding VAT Machinehandel De Leeuw BV is one of the few companies in Europe that stocks and sells primarily used Kardex Remstar automatic lift and rotating warehouse systems. We install and/or dismantle these systems safely with VCA-certified engineers and have been doing so for more than 33 years. Best regards, Antoine de Leeuw Machinehandel De Leeuw BV Oordeelsestraat 7-B 5111 PA Baarle-Nassau The Netherlands VAT No.: NL800103026B01 Chamber of Commerce Tilburg 18034279

Condition: good (used), functionality: fully functional, Year of construction: 2017, laser power: 3,000 W, X Working area max.: 2500 mm Y Working area max.: 1250 mm Control system: Basic Rexroth IndraMotion MTX Laser power: 3000 watts Standard equipment: Machine - Closed machine frame Ijdpfx Asz Rl Hyjg Aotn - Hybrid axis system - Linear magazine with 20 slots for clamping jaws and tools - Drives with maintenance-free three-phase motors - Follow-up device with programmable clamping beam - Foot pedal for clamping jaw closure - Beam protection - Dividing chute on the right - Part flap on the left - Sensor for part flap - Work area lighting - FocusLine - Protective tool TRUMPF Laser - Solid-state laser TruDisk 3001 with one laser beam cable (LBC) output - LBC according to standard layout (10 m) - Laser power control - Laser logbook function - Enclosed beam guidance via laser beam cable (LBC) The TruDisk laser is subject to international export control. According to EC Dual-Use Regulation 428/2009 (lasers covered under 6A005). Compact cutting unit - Solid-state laser compact cutting unit - Protective glass - Collision protection - ControlLine Punch head - Delta Drive - Rotatable mono-tool holder - Programmable clamping beam position - Tool length compensation - Spray lubrication for the punch - Scrap extraction - Forming function - Stroke counter for the punch Control system - TRUMPF control system based on Rexroth IndraMotion MTX - Touch panel with 19'' TFT color display - Integrated technology data - Programmable cutting gas pressure - Teleservice interface via Internet - Automatic shutdown including wake-up function - Program management - Production plan Data transfer - USB interface - RJ45 network connection - Central Link Safety - CE marking - Multi-beam light curtains - Protection against scattered radiation Extended laser equipment - Copper cutting package - Brass cutting package Extended punching equipment - MultiTool function - MultiBend function - Thread forming function with thread counter - Signing/fast beading function - Engraving function - Deburring and rolling technology function - Adaptive stroke calibration - Spray lubrication for the die and level monitoring - Smart Punch Monitoring Part removal - Integrated sorting function for dividing chute - Sensor for dividing chute - Container track for 4 standard containers - Containers supplied by the customer Special sheet metal processing - Brush tables - Loading and unloading aid for brush tables Options Compact dust collector - CO2 extinguishing system for the compact dust collector Data transfer - Wireless operation point SheetMaster Compact 2500x1250mm (AK05) - Suction frame - Unloading trolley for scrap grid and microjoint sheets - Loading station with spreader magnet for separating sheets - Double sheet detection - Vacuum sensor - 2nd operator station for loading and unloading - Compact installation (double-wing swing doors) - Peeling system

Condition: excellent (used), Year of construction: 2015, functionality: fully functional, 1 unit of Flexor 380 2C, used, factory-reconditioned Machine speed max. 300 m/min Web width max. 380 mm Web width min. 190 mm Unwind diameter max. 800 mm Unwind shaft, pneumatic, D 76 mm Punching unit with re-register – 2 units Punching width max. 380 mm Magnetic cylinder, circumference min. 10” (80T) Magnetic cylinder, circumference max. 24” (192T) Matrix strip unwinding, max. D 600 mm Slitting unit with 7 blade holders 1 Rewinder, max. D 550 mm Spindle, D 76 mm Year of manufacture 2015 Accessories (optional): Used magnetic cylinders: 80, 87, 92, 94, 95, 98, 96, 100, 102, 104, 106, 112, 116, 120, 132, 136, 138 Itedpfx Aez Sriqjg Ajn

Condition: excellent (used), Year of construction: 2024, operating hours: 3,540 h, functionality: fully functional, punching force: 280 t, X working area max.: 3080 mm Y working area max.: 1540 mm Operating hours: 3540 hrs Control: CNC control LABOD with graphics Standard equipment Hydraulic punching machine - Punching force: approx. 280 kN (28 tons) - Throat depth: approx. 1750 mm - Max. punching diameter: 70.0 mm - Max. stroke height: 90 mm, steplessly programmable up and down via control - Table width left + right: 3430 mm each - Table depth: 3160 mm - Table height: 900 mm + 8 easily exchangeable cassette holders + Rotary drive, tool holders top and bottom continuously rotatable 360° + 1 piece, indexable Revotool tools + Programmable clamp positioning + Scrap slug extraction system + Spray device + Brush table + Brush table extension tables Itedpjz Rmansfx Ag Aen + Multitalk, USB, SD memory card and network connection + Digital stroke height adjustment + Three-sided safety light barrier + Various intermediate matrix plates for Trumpf tooling sizes 1 and 2 + Tooling package + 1 set of keys and operating manuals + Boschert EasySharp tool grinding device

Condition: used, functionality: fully functional, Year of construction: 1998, machine/vehicle number: 070691, control type: CNC control, actuation type: mechanical, punching force: 165 t, punching diameter: 76 mm, sheet thickness (max.): 6 mm, table length: 2,070 mm, table width: 1,280 mm, overall weight: 8,000 kg, power: 14 kW (19.03 HP), input voltage: 220 V, input frequency: 50 Hz, type of input current: three-phase, Equipment: CE marking, emergency stop, foot remote control, Trumpf Trumatic 200 CNC punching machine (with Multitool) For sale: a Trumpf Trumatic 200 CNC punching machine (internal designation TC 200 R), manufactured in Germany in 1998. Well maintained, fully operational, and available for inspection at our facility in Zaragoza, Spain. Itjdpsz E Sa Isfx Ag Ajn Type: 9095 — Serial number: 070691 Year of manufacture: 1998 Max. punching force: 165 kN Machine weight: 8,000 kg Power supply: 220V / 50Hz — Connected load: 14 kVA — Control voltage: 24V DC Required fuse protection: 3x25A Compressed air connection: 6 bar Comes complete with tooling, cassettes, and Multitool. For reference, the standard specifications for this model are: working area 2,070 x 1,280 mm, max. sheet thickness 6.4 mm, max. punch diameter 76.2 mm, X-axis speed 80 m/min, Y-axis speed 55 m/min. For technical questions or to arrange a visit, please contact us by email. We will be happy to answer any questions and provide further photos or videos of the machine in operation.

Year of construction: 1986, condition: ready for operation (used), We offer this ready for use K. Widmann 0271E.20 Punched pockets machine, year of construction 1986. Control voltage: 220 V Frequency: 50 Hz Operating voltage: 380 V Serial number: 89024E011 Circuit diagram number: A Ijdpfxoz Akq Nj Ag Astn If you have any questions or need more information, feel free to send us a message or give us a call.

Condition: ready for operation (used), Year of construction: 1996, functionality: fully functional, machine/vehicle number: 040808, punching force: 220 t, sheet thickness copper (max.): 8 mm, overall weight: 11,050 kg, table width: 1,250 mm, table length: 2,500 mm, control type: CNC control, degree of automation: automatic, actuation type: hydraulic, TC500 R Punching Center with Sheetmaster Medium format 2500mm x 1250mm A large tool arsenal is also available for separate sale. Iedpfx Agsx Th R Ds Aotn Additionally, there is a Quick Sharp and Multiset available. The set can also be purchased together with the machine and the basic tool kit. Price to be negotiated. We are looking to sell our used Trumpf TC 500R punching center. The reason is that the machine has hardly been in use for years, and we need the space. This is a complete punching center with Sheetmaster and scrap disposal system. We took over the machine in 2008. Under our ownership, the punching unit has run a maximum of two shifts per week. Since 2015, it has operated roughly once a month, as the corresponding products were discontinued. The machine is offered with a standard tooling set and is fully functional. Additional tools and a Trumpf QuickSharp are available separately.

Condition: refurbished (used), Year of construction: 1990, machine/vehicle number: 77168, functionality: fully functional, pressing force: 63 t, stroke length: 165 mm, table width: 650 mm, table length: 1,600 mm, total length: 2,300 mm, total width: 1,650 mm, total height: 2,220 mm, overall weight: 3,800 kg, year of last overhaul: 2026, Equipment: documentation/manual, safety light barrier, Hubtischstanzmaschine (Hydraulic table punching machine) - Punching force 630 kN Isdpsz Rmyhjfx Ag Ajtn - Table dimensions 1600 x 650 mm - Activation via push button or single-stroke safety curtain - Oil filter new, hydraulics inspected, piston seals new - Electrical system completely repaired and partially renewed - Mechanics completely overhauled - Condition like new, new paint RAL 6011 green - Incl. punching plate P1/78NE, 10 mm thick - Without hydraulic oil Price on request

Condition: good (used), Perforator JBI AlphaDoc Mk4 Automatic Punching Machine The machine is in very good condition and ready for production. Isdpfjz S Uxbsx Ag Aotn This is a versatile, automated punching unit designed to handle a wide range of paper sizes and thicknesses, as well as various punching patterns. Punching modules can be swapped quickly and easily, without the need for additional tools. Supports various formats, cover types, and paper stocks Simple operation via a touchscreen control panel Side guides for aligning sheets prior to punching Compact, mobile design ensures optimal space utilization Empty-feeder sensor to prevent paper jams Punching modules can be changed in a matter of seconds Throughput of up to 80 cycles per minute Maximum format: 350 x 330 mm Weight: 350 kg

Condition: reconditioned (used), Year of construction: 1968, functionality: fully functional, machine/vehicle number: 7923278, type of input current: three-phase, total width: 2,440 mm, total length: 3,320 mm, total height: 2,130 mm, overall weight: 8,200 kg, input frequency: 50 Hz, input current: 30 A, nominal power: 7.5 kW (10.20 HP), rotational speed (max.): 4,600 rpm, rotational speed (min.): 1,500 rpm, space requirement width: 2,440 mm, 72x102 cm die cutter for thin paper and light carton up to 600 gsm. Exceptionally stable and very silent fast cylinder press. Floor anchoring is not necessary. Iedpfex Hzm Sex Ag Aotn

Condition: used, functionality: fully functional, Year of construction: 1989, For sale: TRUMPF MINIMATIC 100 punching machine. Lightly used, in excellent condition, and comes with many tools. The machine is connected and can be tested. Itjdpfjy Udrmjx Ag Asn We can provide training on how to use the machine; all instructions are available. Specifications: Make: TRUMPF MINIMATIC 100 Made in: Germany Year: 1989 Capacity: 15 T / 150 kN Other: Automatic 9-tool changer Weight: 5T If you have any further questions, please do not hesitate to ask.

Condition: good (used), functionality: fully functional, Year of construction: 2009, controller model: Siemens Sinumerik 840D, laser type: CO₂ laser, laser power: 3,200 W, punching force: 22 t, Standard equipment: Machine - Working area 3050 x 1550 mm - Hi-Las high-pressure cutting - Cutting head quick-change system - Programmable cutting gas selection/pressure adjustment Itodpfjz Rl Uqjx Ag Asn - Capacitive height control APC - Function: ContourLas - Slag cone detection - Compact dust extraction system - Tank heating - Automatic tool changer with 19 stations (21 – clamping jaws) - 2 clamping jaws - Rotation of all tools - NC-controlled, digitally operated, maintenance-free three-phase drives - Automatic repositioning - Tool length compensation - Rapid shutdown of the hydraulics - Automatic shutdown - Automatic indexing slides, each 500 x 500 mm - Sensors for both indexing slides - Slug extraction - Forming capability - Programmable stamping tool lubrication - Programmable clamping device - Adaptive stroke length control - Safety devices - RJ 45 network connection - 3.5'' floppy disk drive + 5'' cutting head + 9" cutting head + FocusLine + MultiTool function + Thread forming function + Signing/quick beading function + Deburring and rolling technology function + Softpunch function + Additional clamping jaw + Repositioning cylinder + Vibration-damped installation + Blow-out device for small parts + Chip conveyor with tilting container

Year of construction: 2008, condition: ready for operation (used), We are offering this ready-to-use Roll-o-Matic roller die-cutting machine, roller size 0.932/3000, manufactured in 2008. Usable roller width: 3000 mm. The upper roller has a diameter of 320 mm and is equipped with a PA or cast nylon cutting sleeve. The roller gap can be adjusted independently on both sides and is equipped with an absolute value display for the roller gap. Operating modes: setup operation; semi-automatic operation; fully automatic operation with a light barrier and time control. Includes 5 conveyor belts, a counter, and additional equipment: support rollers for the lower roller to reduce deflection under high load. Chain drive and more powerful motor. Includes control buttons on both sides. If you have any questions or require more information, please send us a message or call us. Itjdpoz Ag Ukefx Ag Ajn

Condition: like new (used), Year of construction: 2023, functionality: fully functional, total height: 5,300 mm, ram adjustment: 150 mm, installation height: 570 mm, total width: 3,300 mm, total length: 5,250 mm, pressing force: 250 t, type of input current: three-phase, stroke length: 35 mm, input voltage: 400 V, distance between side stands: 820 mm, overall weight: 58,000 kg, control voltage: 24 V, input frequency: 50 Hz, HR 250/2200 SL – Punching Line (Demonstration and Trial System) Press frame + ram in cast design with optimal damping properties Turnkey complete system for: • Production of electrical sheet metal parts • Flat stamped parts • Flat progressive die-cut parts EQUIPMENT + ACCESSORIES: • Punching machine HR 250/2200 SL [ZEULENRODA] 2,500 kN | Stroke rate 80…250 min-¹ >also available without accessories/peripherals upon request< • Roller feed “push-pull”, [ZEHNDER & SOMMER] • RAZIOL roller strip lubricator • Strip thickness measuring device • Punching package control [UNIDOR / TRsystems] • Unwinding reel 3.0t [KOHLER] • 21-roll fine leveling machine, deburring attachment [KOHLER] • Motorized tool changing system with hydraulic lifting bars + insertion clamp • Scrap and parts removal • Servo punching shear • Control cabinet platform • Operator platform • Soundproof cabin • Safety fence TECHNICAL DESIGN: Stroke rate of the press: 80 - 250 min-¹ Ram stroke: 35 mm Quick lift: 75 mm Installed height: 570 mm at max. stroke (fixed 35 mm) at the bottom, ram adjustment (150 mm) at the top Table surface: 2300 x 1100 mm Clamping plate: 2300 x 1100 mm T-slots DIN 650: 22 mm Itedpfxjzu Ryhj Ag Aen Table opening: 2020 x 400 mm Ram surface: 2240 x 900 mm Ram stroke, fixed: 35 mm Quick lift: 75 mm Height above floor: 1380 mm (including clamping plate 200 mm) Strip inlet height: 200 - 400 mm (above the clamping plate) Stand opening, side: 820 x 500 mm (W x H) Recommended max. upper tool weight: 2200 kg Recommended upper tool weight: 1950 kg - Control system SIEMENS S7-1500 - 15’’ touch panel + two-hand control panel - Remote maintenance DESCRIPTION: - Press frame in gray cast iron design - Press ram in cast design - Direct drive with electro-pneumatic clutch-brake combination - Fully eccentric two-point eccentric shaft, forged - Power transmission via two connecting rod joints - Roller guide, 8-fold for precise ram guidance - Rotating mass balancer - Ram weight compensation by means of pneumatic bellows cylinder - Quick Lift 75 mm (quick lift function for fast tool access) - Condition monitoring (forces, temperatures, lubrication, pneumatics)

Condition: excellent (used), A robust machine designed for punching holes in steel, aluminum, and other metals. Thanks to its foot control, it provides convenient and safe operation. Its compact design makes it suitable for both a locksmith's workshop and a production facility. Technical specifications: Manufacturer: Mubea (Muhr und Bender) Model: KL30 Year of manufacture: 1975 Machine number: 38601 Country of manufacture: Germany (West Germany) Ijdpez Snchsfx Ag Astn Power supply: 3× 220/380 V Frequency: 50 Hz Motor power: 1.5 kW Rated current: 5.8 / 3.4 A Protection rating: IP44 Control: foot pedal Punching capacity: Ø 30 mm in sheet metal with a thickness of 8 mm Ø 20 mm in sheet metal with a thickness of 12 mm (Parameters correspond to the manufacturer's nameplate for a material with a strength of approximately 45 kp/mm².) Condition: Used machine. Visual condition matches the photos. Robust, heavy-duty industrial design. Ideal for locksmith workshops, steel structure production, and workshops involved in metalworking.
