Used Quick Kq-62Lite for sale (4,977)

Condition: new, Six-sided drilling machine Manufacturer: Quick Type: KQ-62Lite New machine Pgodpfx Aszvgndob Ser Technical data: - Workpiece length: 70 - 2,400 mm - Workpiece thickness: 9 - 60 mm - Workpiece width: 30 - 1,220 mm - Min. processing size: 50 x 70 mm - Transport speed in X: 138 m/min - Transport speed in Y: 90 m/min - Transport speed in Z: 28 m/min - Machine control: Higerman - Working height: 890 mm - Milling spindle: 2 x 3.5 kW, 18,000 RPM, manual tool change - Drilling unit: Top 9 vertical and 4 horizontal / Bottom 7 vertical - Positioning accuracy: 0.03/1000 - Repeatability: 0.02/1000 - Power consumption: 25.8 kW Optional - Machine including workpiece return Other configurations available upon request.

Condition: new, 6-sided drilling machine Manufacturer: Quick Type: KQ-63E New machine Technical data: - Workpiece length: 70 - 2800 mm - Workpiece width: 50 - 1220 mm - Workpiece thickness: 9 - 60 mm - Min. workpiece to be processed: 70 x 50 mm - Feed rate in X: 135 m/min - Feed rate in Y: 90 m/min - Feed rate in Z: 25 m/min - Individually controllable spindles: Top: 2 x 12 vertical, 4 horizontal / Bottom: 1 x 7 vertical - Machine control: Higerman (German) - Milling spindle (top): 9 kW, 24000 rpm - Tool changer (top): 5-position - Milling spindle (bottom): 3.5 kW, 18000 rpm - Motors: Brushless servo motors - Positioning accuracy: 0.03/1000 - Repeatability: 0.02/1000 Optional: - Machine with workpiece return Quickly found Pgjdpszvgn Dsfx Ab Sor Offer machines Register for newsletter Unsubscribe from newsletter Contact us Overview

Condition: excellent (used), Year of construction: 2016, operating hours: 5,000 h, functionality: fully functional, machine/vehicle number: 60022, turning length: 250 mm, turning diameter: 42 mm, spindle speed (min.): 6,000 rpm, travel distance X-axis: 150 mm, travel distance Y-axis: 385 mm, travel distance Z-axis: 250 mm, spindle motor power: 7,500 W, total height: 1,900 mm, total length: 3,500 mm, total width: 1,900 mm, overall weight: 4,200 kg, i-42 Ultimate lathe Podpfx Abezwmkns Segr • Number of controlled axes: 10 • Number of driven tools: 12 • Max. diameter: 42 mm • Max. length: 250 mm Includes a feeder – max. length 1 m.

Condition: repair required (used), functionality: not functional, cnc lathe Pedpfxjumlwxo Ab Sogr

Condition: ready for operation (used), Year of construction: 2008, operating hours: 10,294 h, functionality: fully functional, machine/vehicle number: P087WH855, travel distance X-axis: 700 mm, travel distance Y-axis: 400 mm, travel distance Z-axis: 300 mm, table load: 300 kg, spindle speed (max.): 10,000 rpm, TECHNICAL DETAILS Travel range, X-axis: 700 mm Travel range, Y-axis: 400 mm Travel range, Z-axis: 330 mm Rapid traverse speed: 54 m/min Spindle speed: 100–10,000 RPM Distance spindle–baseplate: 250–580 mm Main spindle power: 5.5 kW Table area: 650 × 400 mm Table load: 300 kg Tool positions: 21 MACHINE DETAILS Dimensions & Weight Dimensions: 1,565 × 2,027 × 2,336 mm Machine weight: approx. 2,200 kg Control system operating hours: 24,164 h Operating hours: 10,295 h EQUIPMENT Central oil interval lubrication 100 mm column extension Interior lighting 16 additional I/O Rapid traverse with bell-shaped acceleration and deceleration Manual handwheel feed Directory display from memory card 1,000 storable programs Multilingual display Thermal compensation of XYZ axes Parameter back-up function Retraction cycle for tapping without a collet MANUAL GUIDE Background editing Extended part program editing Coordinate system selection G92 Workpiece coordinate system G52–G59 48 additional workpiece coordinate systems G54.1 Return to reference point G28 Quick Editor Setup file Production counter Tool correction memory C for D/H code and wear Thread cutting without a collet M29 Subprogram call M98/M198/M99 Customer macro B G65, G66/G67 Drilling cycles G73, G74, G76, G81, G89/G80 Coordinate system rotation G68/G69 Circular interpolation with R programming AI Contour Control I G05.1 Helical interpolation Skip function G31 Podezul Tcspfx Ab Sogr Multi-step skip G31 P1–P4 Check of travel limit before movement Check of stored travel limit 1 Check of stored travel limit 2 G22/G23 Customer PMC Real-time customer macro

Condition: used, 4-axis CNC milling machine Manufacturer: Quick Type: UA-481 New machine Technical data: 380 V-3-phase Working area: 2100 x 3050 x 400 mm 9 kW HSD/HSK-F-63 spindle Pedpfx Abjzvgmyj Ssgr NC Studio control 10 linear tool changers Double-layer vacuum table with 6 zones Yaskawa servomotor 2 Becker pumps (250 m³/h) NC Studio control with German language Optionally available at an extra charge: - 10-position rotary tool changer on the gantry - 12-position rotary tool changer on the gantry - 2 pneumatic pressure rollers for multiple part clamping - Vacuum table with T-slot for manual fixing of components Other configurations available upon request.

Condition: ready for operation (used), functionality: fully functional, Oil Quick Pins ØShank Pin Distance Price: OQ70 60/60 280 330 €3,000.00 OQ80 90/90 345 510 €3,500.00 OQ80 90/90 353 515 €3,500.00 QO80 90/90 355 510 €3,500.00 OQ80 100/90 387 530 €3,500.00 OQ80 100/100 420 610 €3,500.00 OQ80 90/90 350 510 €3,500.00 OQ80 90/90 350 500 €3,500.00 OQ80 90/90 350 510 €3,500.00 OQ80 80/80 310 475 €3,500.00 OQ90 110/100 440 595 €18,000.00 OQ90 without mount €15,000.00 OQ90 110/110 470 590 €18,000.00 Verachtert Pins Ø Shank Pin Distance CW40 80/80 310 445 €2,000.00 Lehnhoff Pins Ø Shank Pin Distance HS21 80/80 465 333 €2,000.00 HS21 80/80 305 475 €2,000.00 Pedpfexhdh Sox Ab Ssgr Additionally, adapter plates available Liebherr Pins Ø Shank Pin Distance SWA 48 65/65 253 370 €2,000.00 SWA 48 80/70 350 420 €2,000.00 SWA 48 80/80 327 460 €2,000.00

Condition: ready for operation (used), Year of construction: 2011, functionality: fully functional, overall weight: 4,400 kg, Equipped with Iemca Boss 545 barfeed and Mitsubishi M700 Control - the lathe has always operated with oil, in regular working order (bearings and ball screws of the X1/Z1 axes and 2 drives have just been replaced). Pgodpfx Abjynt U Ao Sor

Condition: ready for operation (used), Year of construction: 2015, operating hours: 5,159 h, spindle motor power: 7,500 W, spindle speed (max.): 6,000 rpm, overall weight: 4,200 kg, total width: 1,900 mm, total height: 1,900 mm, bar diameter (max.): 100 mm, travel distance X-axis: 150 mm, travel distance Y-axis: 385 mm, controller manufacturer: MITSUBISHI, product length (max.): 3,500 mm, number of axes: 7, This 7-axis Quick-Tech I-42U was manufactured in 2015. It features a maximum bar diameter of 42 mm and a maximum machining length of 250 mm. The machine is equipped with a powerful spindle speed of 6000 rpm and includes an automatic bar feeder. If you are looking to get high-quality turning capabilities, consider the Quick-Tech I-42U swiss type turning machine we have for sale. Contact us for further details. • Control • Mitsubishi M720 CNC • 15" color LCD display • Door with LED indicators • Operational signaling and automatic alarm switch • Built-in communication/interface with bar feeder • CE mark • Guide/manual • Main spindle • Bearing diameter: 100.0 mm • Max bar dia.: 42 mm • Max machining length: 250.0 mm • Collet: DIN-173E42B • Spindle nose: A2-5 • Spindle bore: 44.0 mm • C axis: 0.001° • Counter spindle • Max bar dia.: 42 mm • Max machining length: 100 mm • Collet: DIN-173E-42B • Spindle nose: A2-5 • Speed: 4000 rpm • Power: 3.7 kW • C1 axis: 0.001° • Travels and axes • X: 150.0 mm | Y: 385.0 mm | Z: 250.0 mm | B: 360° • X1: 400.0 mm | Y1: 400.0 mm | Z1: 300.0 mm • Servo motors (X, Y, Z, X1, Y1, Z1): Mitsubishi AC Servo, 1.5 kW each • Indexing from tool position: 0.3 s • Tool change time (cut/cut): 0.6 s • Tool head (main) • Combined type • Tools: 6 external, 5 internal • External tool size: 20.0 × 20.0 mm • Max internal tool: ER20 / 20.0 mm • Driven tools (main) • B axis with 12 driven tools • Power: Mitsubishi AC Servo, 15 kW • Speed: 4000 rpm • Max tool size: ER-20 • Max drilling dia.: 12 mm • Max thread: M10 × 1.5 • Tool head (counter) • Combined type • Tools: 5 external, 9 internal • External tool size: 20.0 × 20.0 mm • Max internal tool: ER20 / 20.0 mm • Driven tools (counter) • Number: 6 (3 axial, 3 radial) • Power: Mitsubishi AC Servo, 1.5 kW • Speed: 4000 rpm • Max tool size: ER-20 • Max drilling dia.: 12 mm • Max thread: M10 × 1.5 • Hydraulic system • Hydraulic motor: 0.75 kW • Max system pressure: 50 kg/cm3 • Lubrication system • Lubrication motor: 25 W • Tank capacity: 2 l • Cooling system • Coolant tank: 200 l • Coolant motor: 1/4 HP • Coolant pressure: 2.5 MPa • Length: 2900 mm (3500 mm including chip conveyor, which is part of the machine) • Standard equipment included • Basic equipment with tools • Tool holder and collet set • Automatic lubrication • Chip remover/chip conveyor (integrated, per dimensions note) • Workpiece removal (shovel) – if integrated • 15" color LCD display • Operational signaling and automatic alarm switch • Guide/manual Pgjdpfx Aszcwxnob Ssr • Door with LED indicators Additional equipment • Automatic bar feeder, 1200 mm length • Workpiece removal conveyor • Workpiece removal shovel (if provided as an external unit) • Transformer 380–440 V, 60/50 Hz Technical Specification Counter Spindle Yes Driven Tools Yes

Condition: ready for operation (used), Year of construction: 2020, functionality: fully functional, overall weight: 300 kg, LANG Clamping Tower 70850 with Grid Plates 75710 and Arbor Clamps 48155-125 2 towers with plates and arbor clamps are available! We offer a high-quality LANG Clamping Tower 70850 with matching Grid Plates 75710 and Arbor Clamps 48155-125. This clamping system is ideally suited for precise and efficient 5-axis machining as well as multi-sided machining on CNC machining centers. Technical data: Manufacturer: LANG Technik Type: Clamping Tower 70850 Accessories: 8 x Grid Plate 75710 Clamping system with grid hole pattern High repeatability Robust design for industrial use Ideal for automated manufacturing and setup time optimization Condition: Used, technically perfect. Normal signs of wear and tear consistent with age and use. Scope of delivery: 1 x LANG Clamping Tower 70850 8 x LANG Grid Plates 75710 4 x Arbor Clamps 48155-125 The clamping tower enables optimal use of the machine's working area and increases productivity by machining multiple workpieces in a single setup. Pjdpfx Ajztzi Reb Ssgr Inspection possible by appointment. Shipping or collection by arrangement.

Condition: used, power: 1 kW (1.36 HP), Year of construction: 2017, operating hours: 1 h, Drive: Wheel Empty weight: 12.200 kg Please contact Emal Jaweed for more information Pjdpfsyuvd Tjx Ab Ssgr

Condition: ready for operation (used), Year of construction: 2001, A CNC vertical machining center Quick Jet is offered. Travel X/Y/Z: approx. 1200mm/800mm/700mm, spindle taper: HSK-A80, max. spindle speed: 14000rpm, spindle power: 25kW, spindle torque: 170Nm, tool magazine: 16, max. tool length: approx. 300mm, max. tool diameter: 100mm, max. tool weight: 7kg, rapid traverse X/Y/Z: 24m/min, distance between table surface and spindle nose: 100mm-800mm, table size X/Y: 1350mm/1300mm, max. workpiece weight: 8000kg, control: Heidenhain TNC 530. Including HSK-A80 tool holder inventory. Machine dimensions X/Y/Z: approx. 3335mm/2780mm/3595mm, weight: approx. 11050kg. Inspection possible by appointment. Psdpfx Aezi Eh Ajb Sogr

Condition: ready for operation (used), Year of construction: 2007, functionality: fully functional, working width: 1,650 mm, wire diameter (max.): 7 mm, Schlatter MG930, quick change, DC welding machine with 5 DC transformer, 1092 kVA. Schlatter control from 2007 with S7-300 PLC. Automatic line wire loader up to 3m, automatic line wire channel positioning, open portal DC welding machine, quick change cross wire hopper, MLV1 pullout and stacker. Pgodozd Sulopfx Ab Ssr

Condition: excellent (used), Year of construction: 2021, operating hours: 8,000 h, functionality: fully functional, turning diameter: 380 mm, spindle motor power: 22,000 W, spindle speed (max.): 5,000 rpm, spindle bore: 65 mm, travel distance X-axis: 234 mm, travel distance Y-axis: 100 mm, travel distance Z-axis: 625 mm, mount diameter: 40 mm, rapid traverse X-axis: 30 m/min, rapid traverse Y-axis: 21 m/min, rapid traverse Z-axis: 33 m/min, rotational speed (max.): 5,000 rpm, torque: 465 Nm, bar passage: 65 mm, workpiece weight (max.): 300 kg, total height: 1,857 mm, total length: 2,760 mm, chuck outer diameter: 203 mm, total width: 1,835 mm, bar diameter (max.): 65 mm, swing diameter over bed slide: 695 mm, overall weight: 5,600 kg, Equipment: chip conveyor, fume extraction, CNC lathe MAZAK Quick Turn 200MY (year of manufacture 2021) You are welcome to inspect the machine while it is powered on at our facility. If you are interested, we will send you demonstration videos of the machine. The MAZAK Quick Turn 200MY is a powerful CNC lathe for the precise and efficient machining of chucked parts in a universal application (500U). With a maximum swing diameter of approximately 695 mm and a maximum machining diameter of approximately 380 mm, the machine is particularly suitable for demanding turning operations in general mechanical engineering as well as in series and single-part production. The robust design with travels of 234 mm in the X-axis and 625 mm in the Z-axis, as well as a bar capacity of approximately 65 mm, enables the flexible accommodation of a wide variety of workpiece geometries – with a maximum payload in chucking operations of 300 kg and a maximum loading weight of 500 kg. The powerful main spindle with an 8″ chuck size and up to 5,000 rpm ensures high cutting performance and precision. Pjdpfxezkbfgj Ab Sjgr The machine is equipped with a modern MAZATROL SmoothG control system, which offers intuitive operation, fast programming, and high process reliability. The 16-tool turret (VDI 40, quick-change function) enables flexible and efficient machining processes, even for complex manufacturing tasks. The tailstock (MT No. 5, 550 mm travel) provides additional secure support for long workpieces. For further process reliability and automation, the machine has an automation package (part catcher as well as interface/connection option for robots and bar feeders). An LLS coolant mist extraction system (low maintenance costs) and a chip conveyor from Mayfran also ensure optimal production conditions. With a machine weight of approximately 5,600 kg, the Quick Turn 200MY offers high stability and vibration damping, which has a positive effect on surface quality and dimensional accuracy. Overall, it is a modern and versatile CNC lathe that guarantees high precision, performance, and reliability in industrial production. On request, we offer delivery as well as commissioning of the machine in a comprehensive, worry-free package. You are in the best hands with us – professional, reliable, and with a passion for machines! PS CNC Service Germany GmbH & Co. KG All information is subject to change without notice.

Condition: used, Year of construction: 2003, functionality: fully functional, Mazak Quick Turn Nexus 150/500 YOM 2003 Mazatrol PC Fusion Control Mazak Tool Length Measuring System Serial Number 166285 Main Spindle has been fully refurbished 8 Station Turret Programable Tailstock Parts Catcher Swarf Conveyor RH exit Machine has been fully serviced Complete set of Machine Manuals Pjdpfeyplgtjx Ab Sjgr UK buyers - Price £19,995 + VAT

Condition: excellent (used), Year of construction: 2018, functionality: fully functional, input voltage: 400 V, input current: 32 A, input frequency: 50 Hz, type of input current: three-phase, pressing force: 560 t, stroke length: 500 mm, operating speed: 10 mm/s, reverse speed: 30 mm/s, table width: 1,400 mm, clearance between the columns: 1,260 mm, total length: 2,010 mm, total width: 1,600 mm, total height: 2,200 mm, overall weight: 4,800 kg, year of last overhaul: 2026, Equipment: CE marking, documentation/manual, safety light barrier, We are offering this very good Boschert Quick-Bend 56 CNC press brake, manufactured in 2018. Pgodpfxoy Nbw Ae Ab Sor Manufacturer: Boschert Model: Quick-Bend 56 CNC Year of manufacture: 2018 Condition: very good Category ID: 1466 Type ID: 1717 Machine type: press brake If you have any further questions or need more information, please send us a message or give us a call.

Year of construction: 2016, condition: ready for operation (used), Control Unit Brand MITSUBISHI Model M70 Main Drive Number of axis 6 Podpjx D Iftsfx Ab Sjgr Spindle Speed 4000 RPM Technical Specification Counter Spindle yes Driven Tools yes This 6-axis Quick-Tech i60 twin was manufactured in 2016, featuring a CNC turning center with B-axis and driven tools. It includes a main spindle bore of 60 mm, sub spindle bore of 42 mm, and a maximum turning length of 300 mm. The machine offers 4-axis simultaneous machining, full axis programming, and a Mitsubishi M70 control system. Consider the opportunity to buy this Quick-Tech i60 twin horizontal turning machine. Contact us for more information about this machine. Application Types Turning

Year of construction: 2015, condition: excellent (used), functionality: fully functional, The machine is powered on and can be inspected. It is equipped with a Kitagawa 200BB chuck. Additionally, the machine has a high-pressure pump. Tools can be provided for an additional fee. Pgjdpjztl Ikofx Ab Ssr Further questions can be answered during the inspection.

Condition: new, 3-axis CNC milling machine Manufacturer: Quick Type: UE-481PL New machine Technical data: - PC with Windows 11 - CAD-CAM connection as desired - NC Studio control software Pgjdpfx Aszvgmtjb Sjr - Heavy-duty machine base - Working area: 2100 x 3050 x 200 mm - Double-layer phenolic resin table - grid table - 9 kW HSD milling spindle with 24,000 RPM - 9-position HSD drilling unit - 90° rotatable sawing unit - 12-position linear tool changer - Automatic tool length measurement - Wireless control panel - 3 stops in X, 2 in Y - 2 units of 250 m3/h Becker vacuum pump - Automatic central lubrication - Safety via light curtain - Lifting table loading - Unloading table

Condition: excellent (used), Year of construction: 2013, MAIN INFORMATION Capacity and Working Area • Model: Mazak Quick Turn Smart 200 • Control: Mazatrol Smart • Year: 2013 • Serial No.: 249187 • Accumulated operating time: 11,755 hours • Cutting time: 1,561 hours • Network: LAN connection • Condition: The machine is in very good technical condition, clean, precise, and very well maintained. • Max. swing diameter: 530 mm • Max. swing over cross slide: 343 mm • Bar capacity: 65 mm • Spindle bore: 76 mm • Axis travels: X-axis: 195 mm Z-axis: 560 mm • Rapid traverse: X-axis: 30,000 mm/min Z-axis: 33,000 mm/min Spindle and Tooling • Spindle speed: 5,000 rpm • Spindle power: 15 kW • Selectable threading start position • Through-tool coolant • Tool turret: 12 positions Indexing time: 0.17 sec / 1 step • Tailstock: MT5 Auto • Tool measuring arm: Yes • Parts catcher: Yes • Robot interface: Additional M-function (1 pair) • Smartshift BASE quick coupling: Yes • Chuck: SMW AUTOBLOK collet chuck Automation and Additional Equipment Integrated Automation Solution with UR5e • Model: Universal Robots UR5e (demo use only) • Type: Collaborative robot (cobot) • Year: 2021/01 • Condition: Fully integrated and operational with the Mazak Smart 200 • Payload: 5 kg • Reach: 850 mm • Repeatability: ±0.03 mm • Working envelope: 2.6 m³ • Max. TCP speed: 1,000 mm/s • Joint speed: 180°/s • Robot weight: 21 kg • Mounting: Floor, ceiling, wall, or inclined Pedpfx Ajzwhc Eob Sjgr • Power supply: 100–240 V AC, approx. 200 W • Controller: UR control box (e-Series) • Programming: URScript + graphical block programming • Safety: ISO 10218-1, ISO/TS 15066, PLd Cat. 3 • Fieldbus: PROFINET, EtherNet/IP, Modbus TCP • Digital I/O: 16 inputs / 16 outputs • Analog I/O: 2 inputs / 2 outputs • Tool flange: ISO 9409-1-50-4-M6 Integration with Smart 200 • Smartshift BASE quick coupling • Additional M-function (robot interface) • Pre-programmed sequences • Quick changeover between manual and robot operation • Video available showing the robot and machine in operation • Fully tested and used in production Condition Description • The machine is fully operational and functions as it should. • No alarms or critical faults. • Smooth movement on all axes. • Spindle runs smoothly without vibration. • Linear guides and ball screws are in good condition. • Hydraulic and pneumatic systems operate normally. • Regular in-house servicing. • Lubrication system OK. • The machine has been used for light production (aluminium/plastic). • Robot and machine are fully integrated and tested.

Condition: excellent (used), Year of construction: 2007, functionality: fully functional, MAZAK QUICK TURN NEXUS 100-II Max. machining diameter: 280 mm Pgjdpfx Abozv D H Re Ser Max. machining length: 300 mm Max. spindle speed: 6,000 rpm Max. bar diameter: 42 mm The machine is equipped with: - CNC control system: Mazatrol Matrix - KITAGAWA 3-jaw chuck BB-06, diameter 169 mm - Tool Eye - Interface for bar feeder - Automatic parts catcher - NC tailstock - Reinforced coolant pump - Chip conveyor, discharge to the side - 1 set of tool holders for a 12-position turret

Condition: used, Year of construction: 1996, operating hours: 7,827 h, functionality: fully functional, machine/vehicle number: 119713, turning diameter over cross slide: 160 mm, turning length: 244 mm, turning diameter: 160 mm, spindle bore: 45 mm, spindle speed (max.): 6,000 rpm, spindle speed (min.): 1 rpm, travel distance X-axis: 155 mm, travel distance Z-axis: 290 mm, spindle motor power: 10,000 W, rapid traverse X-axis: 30 m/min, rapid traverse Z-axis: 30 m/min, rotational speed (max.): 6,000 rpm, total height: 1,780 mm, total length: 2,000 mm, total width: 1,330 mm, quill travel distance: 150 mm, quill diameter: 55 mm, quill stroke: 150 mm, workpiece weight (max.): 25 kg, overall weight: 2,700 kg, bar passage: 40 mm, chuck outer diameter: 154 mm, bar diameter (max.): 45 mm, spindle diameter: 50 mm, Equipment: documentation/manual, rotational speed infinitely variable, The Mazak Quick Turn 10 is a compact CNC lathe manufactured by the Japanese company Mazak. It has been specifically developed for the precise machining of small and medium-sized turned parts and is widely used in mechanical engineering, toolmaking, as well as in series production. The machine features a robust slant-bed design, a tool turret, and the dialog-based Mazatrol control system, which enables fast programming directly at the machine. This makes it suitable both for single parts and small series production. Control: Mazatrol T-Plus Podsyt E Nvepfx Ab Sogr Standard chuck: Kitagawa N-06A0515 The quoted price does not include dismantling, packaging, or shipping. Sale ex location, subject to prior sale. The machines are sold in used condition; any warranty and guarantee are excluded.

Condition: good (used), Year of construction: 1988, functionality: fully functional, total height: 1,800 mm, total length: 2,550 mm, total width: 1,600 mm, overall weight: 4,300 kg, Model: MAZAK QUICK TURN 15-U Year of manufacture: 1988 Control system: Mazatrol CAM T2 Working area: max. swing diameter: 440 mm max. turning diameter: 270 mm max. turning length: 500 mm bar work up to a diameter of max. 51 mm Main spindle: speed range: 36 – 3,600 rpm main drive power: 15 kW Pjdpfezvf H Sex Ab Sjgr constant torque: 230 Nm spindle nose: A2 – 6 inches spindle bore: 61 mm Tool turret: standard version: 8-position turret indexing time: - 1st station: approx. 0.5 s Travel ranges: turret – travel range: x-axis: 155 mm z-axis: 510 mm Rapid traverse rate: x-axis: 12 m/min z-axis: 24 m/min Tailstock: tailstock travel: 460 mm tailstock spindle: MK 4 tailstock quill stroke: 130 mm Machine data: total connected load: 31.3 kVA machine weight: 4,300 kg machine dimensions: L x W x H: approx. 2.55 x 1.60 x 1.80 m

Condition: good (used), Year of construction: 1991, functionality: fully functional, total height: 1,850 mm, total length: 3,450 mm, total width: 1,800 mm, overall weight: 5,200 kg, Model: MAZAK QUICK TURN 28 N Year of manufacture: 1991 Control system: Mazatrol CAM T32-2 Technical data Work area Max. swing diameter: 510 mm Max. turning diameter: 320 mm Max. turning length: 972 mm Pgsdpozvf S Uofx Ab Sjr Bar work up to diameter: 70 mm Main spindle Speed range: 30 – 3,000 rpm Main drive power: 22 kW Constant torque: 432 Nm Spindle nose: A2 – 8 inches Spindle bore: 80 mm Tool turret Number of tool positions: 8/16 Travel distances X-axis: 200 mm Z-axis: 1,020 mm Rapid traverse rate Rapid traverse: X-axis: 18 m/min Z-axis: 24 m/min X/Z-axis: 0 - 5,000 mm/min Tailstock Mount: MK 5 Tailstock travel: 835 mm Quill stroke: 130 mm Machine data (with standard equipment) Total connected load: 41 kVA Machine weight: 5,300 kg Machine dimensions (L x W x H): 3.45 x 1.80 x 1.85 m

Condition: like new (used), Year of construction: 2024, MAZAK QUICK TURN 200MSY Max. machining diameter: 380 mm Max. machining length: 575 mm Max. milling speed: 5,000 rpm Max. spindle speed: 5,000 rpm Max. bar diameter: 65 mm Machine is equipped with: - CNC control: Mazatrol SmoothG - Hydraulic KITAGAWA 3-jaw chuck BB-208 for main spindle, diameter 210 mm - Hydraulic KITAGAWA 3-jaw chuck B-206 for 2nd spindle, diameter 169 mm - Tool Eye - C-axis - C-axis counter-spindle, input accuracy 0.0001° - Y-axis - Interface for bar feeder - Automatic parts catcher - Robot interface Podezgw Icjpfx Ab Segr - Reinforced coolant pump - MAYFRAN chip conveyor - 8 pcs. fixed tool holders - 2 pcs. driven tool holders
