Used Radial Arm Drilling Machine for sale (67,678)

Condition: used, Radial drilling machine CSEPEL type RFh 75 / 1500 Machine no. No. 13704 Year of construction 1985 Drilling capacity in steel Ø 75 mm Drilling capacity in cast iron Ø 90 mm Spindle holder MK 5 Nominal throat depth 1500 mm Largest projection of the spindle 1500 mm (to the column) Smallest projection of the spindle 440 mm (to the column) Rsdolhwr Rspfx Aizst Distance spindle nose - clamping surface 370 - 1700 mm Cantilever height adjustment 950 mm Table size / clamping surface 1800 x 1100 mm Column diameter 450 mm Pinol stroke 380 mm Spindle speed 19-1900 rpm 21 steps Feed rate 0.047-2mm/rev. 12 steps Motor power 11 kW Mains connection 380 Volt, 50 Hz, 15 kW - Clockwise/anticlockwise rotation of the drilling spindle via hand lever switch - Hydr. gear shift for spindle speed and feed speed - Hydro-mechanical central clamping - Motorized boom height adjustment - Without coolant device - Machine light - Operating instructions Space requirement: Length 2720 mm x width 1170 mm x height max. 3770 mm Transport height with motor on the column: 3500 mm Transport height without motor on the column: 3250 mm Weight: 6.3 tons good condition

Condition: used, Radial drilling machine WEBO Type R4bR Serial No. 15 / E195 Year of manufacture: approx. 1965 Drilling capacity: 50 mm Spindle taper: MT 5 Maximum spindle outreach: approx. 1250 mm (to column) Clamping surface: 1400 x 1000 mm Column diameter: 315 mm Spindle speed: 30 - 1325 rpm, 9 steps Feed: 0.12 - 2 mm/rev, 9 steps Electrical connection: 380 Volt, 50 Hz - Spindle speed in 9 steps - Motorized height adjustment of the boom Required floor space for operation (L x W x H): 220 x 100 x 285 cm Transport dimensions (L x W x H): 220 x 100 x 260 cm (without motor for height adjustment) Rodeu T Ty Hepfx Aizot Weight: approx. 2.8 t.

Year of construction: 1981, condition: used, machine/vehicle number: 77-8101, Lg-Nr. 01501, Technical data: - Drilling capacity in steel 28 mm - Thread cutting device - Drilling spindle holder MK 3 - Drilling spindle stroke 160 mm - Table dimension approx. 750 x 500 mm - projection up to approx. 620 mm - Vertical stroke of the boom 600 mm - column diameter 250 mm - spindle speeds in 12 switching steps 80 - 2800 rpm - 3 feeds 0,1 + 0,15 + 0,25 mm/rev - drilling spindle drive 400 V / 5,5 kW - cooling device - space requirement approx. W 1100 x H 1550 - 2150 x D 950 mm - Weight approx. 1200 kg Rjdpfeb Ennkex Aizjt - Instruction manual

Condition: used, Year of construction: 1984, machine/vehicle number: 84043, Order No. 20218 Technical Specifications: - Drilling capacity in wood: 40 mm - Drilling capacity in steel: 18 mm - Drill spindle mount: MT 2 - Spindle stroke: 120 mm - Drill spindle speeds continuously adjustable in steps: 60 - 2840 rpm - Max. distance between table and drill spindle: 600 mm - Boom/unit tiltable left and right by 45° each - Boom/unit pivotable left and right Rjdpfswf Iqnjx Aizjt - Table size: 450 x 450 mm - Drive: 400 V / 0.33 / 0.55 kW - Space required: approx. W 500 x H 1870 x D 1200 mm - Weight: approx. 150 kg

Condition: used, Year of construction: 1987, functionality: fully functional, Drilling capacity in steel (diameter) 80 mm Arm reach 2000 mm Workpiece height - approx. 1300 mm Boring diameter in steel 100 mm Boring diameter in cast iron 115 mm Thread cutting in ST 60 M 68 mm Spindle speeds 16 - 1250 rpm Rjdpfx Aijy H Dauszot Number of spindle speeds 32 Spindle stroke 550 mm Number of feeds 18 Feed range 0.06 - 3.0 mm/rev Distance spindle/baseplate 480 to 1800 mm Column diameter 500 mm Spindle motor 11 kW Lifting motor 4 kW Total power requirement 15 kW Machine weight approx. 8,500 kg Footprint 3200 x 1250 x 3600 mm with work table 1500 x 1000 x 500 mm

Condition: reconditioned (used), functionality: fully functional, Drilling Machine Brand: GSP Model: 407C22 Reach: 2250 mm Drilling capacity (steel): - Normal feed: 70 mm diameter - Slow feed: 90 mm diameter Rsdpfxsy D Hr Us Aizst Carriage travel on arm: 1900 mm Drilling radius (min. - max.): 630 - 2500 mm Height (min. - max.): 500 - 1750 mm Vertical arm travel: 850 mm Spindle stroke: 400 mm Spindle speeds: 25 to 1400 rpm Motor power: 6 kW Spindle taper: MT 5

Condition: ready for operation (used), Year of construction: 1975, arm 1200MM stroke head on bench 1400MM universal head portable radial Redpfx Aisvm Akgjzet

Condition: good (used), Drilling capacity: Ø 50 mm Spindle fitting: MT5 Spindle speeds: 18 - 2,000 rpm Spindle stroke: 400 mm Rjdpfxoy Ia Aze Aizet Maximum horizontal arm travel: 1,250 mm Maximum spindle to floor plate distance: 1,600 mm Equipped with: - Thread-cutting device - Drilling table Machine weight: 4,500 kg Machine dimensions (LxWxH): 2,800 x 1,000 x 3,500 mm

Condition: excellent (used), Metra TRL1000 Radial Drill – Power, Precision and Reliability for Your Workshop Metra TRL1000 radial drilling machine in excellent condition, ideal for those seeking a robust, precise machine ready to handle large workpieces. Perfect for mechanical workshops, steel fabrication, and maintenance departments looking to increase capacity and productivity. Main technical features: • Radial arm: 1000 mm • Column rotation: 360° • Vertical arm travel: wide adjustment for tall workpieces • Spindle stroke: long, ideal for deep drilling • Drilling capacity: suitable for steel, stainless steel, and alloys • Spindle speed: multi-range mechanical selection • Automatic feeds: for drilling and tapping • Heavy cast-iron frame: maximum stability and rigidity Redpfx Asy Ib Tnjizst • Large base: perfect for bulky components • Power supply: industrial three-phase Machine is ready to use, very quiet and stable. (Detailed photos available)

Condition: used, Year of construction: 1994, functionality: fully functional, throat depth: 1,250 mm, Radial drilling machine Fab. Breda type. R 55-1250 Year of manufacture 1994 Technical details Make: BREDA Type: R 55-1250 Throat: 1250 mm Drilling capacity in steel: 55 mm Drilling capacity in cast iron: 70 mm Tapping capacity in steel: M 50 Tapping capacity in cast iron: M 65 Drill spindle mount: MT 5 Throat: 1250 mm Cross travel of headstock: 930 mm Minimum/largest distance from base plate: 5360 – 1375 mm Vertical travel of the boom: 705 mm Spindle stroke: 310 mm Number of spindle speeds: 12 Spindle speeds: 30 – 1200 rpm Number of feeds: 8 Feeds: 0.06 – 1.0 mm/rev Base plate 2070 x 910 mm Clamping area base plate 1325 x 910 mm Motor power 4.4 kW - 380 volts Dimensions (L x W x H) 2.1 x 1.0 x 2.5 m Weight 3 t Accessories Drilling table 750 x 600 x 550 mm Cooling Hydraulic clamping All information is subject to change. Rsdpjv Rpf Sjfx Aizst A demonstration is available at any time in our showroom.

Condition: used, Year of construction: 1999, bore capacity in steel (diameter) 50 mm arm length 1250 mm bore capacity in cast iron 60 mm quill stroke 300 mm tool taper MK 5 speeds 25 - 1440 U/min feeds 0,08 bis 0,58 mm/U thread cutting attachment ja Boring motor 4,0 kw weight of the machine ca. 2,4 t dimensions of the machine ca. 2,0 x 0,75 x 2,15 m Radial drilling machine Redpfx Ajy Ehxrjizjt - Mounting cube 800 x 600 x 500mm - Coolant system - Good condition

Condition: used, Year of construction: 1980, functionality: fully functional, functions perfectly The machine weighs approximately 4 tons. Rsdpox Eigzofx Aizst

Condition: ready for operation (used), Year of construction: 1984, total width: 1,600 mm, overall weight: 5,500 kg, arm 1600 mm; drilling capacity 55 mm; hydraulic clamping; stroke 6000 mm; weight 5500 kg. Redpsy Dqy Nsfx Aizjt

Condition: good (used), Year of construction: 1989, Ref. -No.: 10600 Manufacturer: G.BREDA Type: R 55 2000 Year of construction: 1989 Storage location: Halberstadt Country of origin: Italy Machine-No.: 16XXXXX Spindle Taper: MK 5 Clamping Area: 1000 - 1700 mm Automatic feeds: 0,06 - 1,00 mm / rev Spindle Speed: 30 - 1200 RPM Drive Capacity - Spindle Motor: 400 V / 5,5 kW Bore Capacity In Steel (Diameter): 55 mm Redpfxsy Ed I Ao Aizjt Weight Of The Machine Ca.: 4800 t Dimensions Of The Machine Ca.: 2,99 x 1,12 x 2,85 m Drill spindle stroke: 240 mm Drilling performance reaming: 80 mm Thread cutting: M 40 approx. Further information: - Reach min. / max. / 320 / 2005 mm - Column diameter 360 mm - Boom stroke 855 mm - Spindle - base plate approx. 1000 - 1700 mm - E - Central clamping - Cube table - Hydraulic vice - Coolant device The machine can be viewed under power by arrangement.

Condition: good (used), Year of construction: 1999, Drilling capacity in steel (diameter): 60 mm / MK5 Quill stroke: 310 mm Spindle speed: 28...2500 rpm Rjdjy Em U Espfx Aizet Table size: 1470 x 986 mm Total power requirement: 4 kW Machine weight approx.: 4.6 t

Condition: good (used), functionality: fully functional, Radial Arm Drilling Machine, CZ production, with few boxes of various drills and parts, solid and very heavy. Rodoxfda Aopfx Aizot

Condition: good (used), functionality: fully functional, Radial drilling machine BWF BR40 * 15 speeds * min. speed: 22.4 rpm * max. speed: 2800 rpm T slot table: * Length: 1600mm * Width: 800mm Redjviu Nmjpfx Aizot Machine dimensions: * Length: 2500mm * Height: 2800mm * Width: 1000mm

Condition: used, y-axis 1.000 mm table dimensions 1.000 x 600 mm bore depth 150 mm bore diameter 32 mm spindle tunring speed 30 - 2.650 U/min output 6 kw In our assessment, the machine is in good used condition and can be inspected under power by appointment. Accessories, tools, and clamping devices shown are only included in the scope of delivery Redpfx Asy A Tc Dsizet if this is noted in the additional information. Technical data and specifications are subject to change without notice and errors. Prior sale is reserved.

Condition: used, Year of construction: 1987, We are offering this used Donau DR 40-Z high-speed radial drilling machine, year of manufacture 1987. Manufacturer: Donau Redpfxey Dn E Ns Aizot Model: DR 40-Z Serial number: 1146-3 If you have any questions or require further information, please feel free to send us a message. The machine is located in Osterode/Harz. Viewing can be arranged by appointment. This is a used machine, therefore we sell under exclusion of any warranty.

Condition: refurbished (used), Year of construction: 2026, functionality: fully functional, For sale: radial drilling machine currently undergoing a complete overhaul in our facility. After completion, the machine will meet all technical standards and parameters comparable to a new machine. The machine will be fully operational and available for testing under power. Redpfjy D Sr Hsx Aizet ✅ 12-month full warranty covering all mechanical components and electrical system Technical specifications: Max drilling capacity steel / cast iron: 75 / 85 mm Max tapping capacity steel / cast iron: M56 / M68 Max distance spindle – table: 2000 mm Min distance spindle – table: 390 mm Spindle taper: MK5 Spindle speed range: 12.5 – 1600 rpm Spindle stroke: 350 mm Mechanical spindle feed Power supply: 400V / 3-phase Electrically raised/lowered arm Electric arm clamping Motor power: 5.5 kW Dimensions & weight: Weight: approx. 7000 kg Dimensions (L x W x H): 3275 x 1170 x 3280 mm Machine condition: Fully rebuilt and modernized Condition comparable to a new machine Available for inspection under power ✅ 12-month full warranty covering all mechanical components and electrical system Terms of sale: Location: Poland Delivery: FCA Bydgoszcz Loading included in price

Condition: used, Year of construction: 2006, Radial drilling machine Manufacturer: Valmer Model: TR 80/2500 SP Year of manufacture: 2006 Table dimensions: 1,000 x 800 x 560 mm Max. drilling diameter: 80 mm Max. tapping diameter: 42 mm Max. distance spindle axis/column: 2,500 mm Min. distance spindle axis/column: 500 mm Horizontal head travel: 2,000 mm Max. distance spindle nose to working surface: 2,000 mm Min. distance spindle nose to working surface: 550 mm Spindle stroke: 450 mm Morse taper: MT 6 Power: 7.5 kW Rodpjw Dbgyjfx Aizet Machine dimensions: 3,730 x 1,400 x 3,825 mm Weight: 11,000 kg

Condition: used, Year of construction: 1989, bore capacity in steel (diameter) 32 mm arm length 1230 mm table surface area 1200 x 500 mm bore stroke 180 mm feed - independent 0,10 - 0,15 - 0,20 - 0,30 mm turning speeds 60 - 1800 U/min taper MK 4 total power requirement 2,7 kW weight of the machine ca. 1,8 t dimensions of the machine ca. 2,2 x 1,8 x 2,3 m Quick radial with: - Feed - Thread cutting device Rodpfx Ajy Aa H Noizst

Condition: ready for operation (used), Year of construction: 1994, overall weight: 7,000 kg, Arm length 1800 mm, drilling capacity 80 mm, weight 7000 kg Rsdpfxjyzq Dpo Aizst

Condition: excellent (used), Radial Drilling Machine EMA - arm lenght - 1220 mm - bore capacity in steel (diameter) - 50 mm - dimentions: 200X77X240, weight: 2250 kg Rodpfx Aish Hnrbjzst - accessories included Made in Italy

Condition: excellent (used), Radial drilling machine Brand: UCIMU Model: MS R1200 Voltage: 380V three-phase Dimensions: 210cm x 90cm x 248cm Dimensions of the vertical row: 55 cm Redpfxsi If I Ro Aizst Dimensions of the horizontal row: 76 cm
