Used Ras Hydraulic Guillotine Shear for sale (15,935)

Condition: ready for operation (used), functionality: fully functional, Year of construction: 2007, machine/vehicle number: 621307509, actuation type: hydraulic, controller model: Delem DAC-350, working width: 3,080 mm, sheet thickness (max.): 10 mm, TECHNICAL DETAILS Max. sheet thickness: 10 mm Max. working width: 3,080 mm Cutting speed: 20 mm/min MACHINE DETAILS Control: Delem DAC-350 Drive type: Hydraulic Power: 30.0 kW Dimensions & Weight Transport dimensions (L x W x H): 4,985 x 2,400 x 2,200 mm Weight: 11,500 kg Ledpfx Aksy Avu Neyshf Transport packages: 1 pc. EQUIPMENT Backgauge type: Electric Sheet support system: Pneumatic Finger guard: Fixed with flip-up safety guard Angle adjustment: Motorised Cutting gap adjustment: Motorised Table type: Ball table Documentation CE marking

Condition: excellent (used), Year of construction: 1999, actuation type: hydraulic, working width: 3,050 mm, sheet thickness (max.): 6 mm, sheet thickness steel (max.): 6 mm, sheet thickness stainless steel (max.): 4 mm, back gauge adjustment: motor-driven, back gauge: 1,000 mm, back gauge speed R-axis: 100 mm/s, power: 5.5 kW (7.48 HP), Equipment: documentation/manual, We offer this very good AMADA PROMECAM GS 630 hydraulic guillotine shear, year of construction 1999. If you have any questions or need more information, feel free to send us a message or give us a call. CUTTING LENGTH: 3050 MAX THICKNESS MS: 6mm MAX THICKNESS SS: 4mm BACK GUAGE LENGTH: 1000mm BACK GUAGE: PROGRAMMABLE POWER SPEED 100M/PER/MIN MOTOR POWER: 5.5KW Lhodpfxoy Ax N No Akyjf

Condition: used, LVD Shear Type HST C-10/31 Lodpox Tqtbsfx Akyehf Capacity 3000 x 10

Condition: used, functionality: fully functional, Guillotine Shear Brand: SAGITA Capacity: 4000 x 8 mm Lhodpfx Aeynglnjkysf Backgauge capacity: 1100 mm Dimensions: 4750 x 2250 x 1850 mm Weight: 12 t Blade gap adjustment ELGO backgauge Rear sheet support

Condition: excellent (used), functionality: fully functional, Year of construction: 2001, control type: manual, sheet thickness (max.): 8 mm, back gauge adjustment: motor-driven, back gauge: 1,000 mm, power: 15 kW (20.39 HP), input voltage: 400 V, operating pressure: 180 bar, overall weight: 5,000 kg, total length: 2,700 mm, total width: 2,450 mm, total height: 1,800 mm, number of support arms: 3, Equipment: angle stop, documentation/manual, emergency stop, finger protection, foot remote control, safety light barrier, type plate available, Hydraulic guillotine shear in excellent condition! Capacity: 2000 x 8 mm. Easy operation. Electric back gauge. Max. 1000 mm. Switch with mains connection at the rear of the machine. 32 A, 3 x 400 V + N Ljdpoy Ecgqjfx Akyjhf Transport can be arranged. Loading onto truck included in the price. Transport dimensions: 2700 x 2450 x 1800 mm, 5000 kg. The angle stop is removable, reducing the transport dimensions to approx. 2700 x 1950 x 1800 mm.

Condition: ready for operation (used), Year of construction: 1993, Immediately available ex location: Hydraulic guillotine shear Steiner, type HTS 30 113, year of manufacture 1993. Controlled digital backgauge 1000 mm, light barriers. Cutting length 3200 mm, material thickness up to 13 mm, throat depth 300 mm, stroke 300 mm, drive 15 kW, weight 15 t. Price: EUR 7,500 excl. VAT ex location. Lhodpfey E Naqex Akyef

Condition: used, Cutting length: 3100 mm Steel cutting capacity: 12 mm Backgauge: 1000 mm Lodpfx Akexuh Ipeyshf

Condition: excellent (used), functionality: fully functional, Year of construction: 1997, max. sheet thickness steel (450N/mm²): 6.5 mm max. cutting width: 3080 mm Lsdpfx Aey Edf Iskyjhf machine weight: 5600 kg Very good, ready-to-use condition.

Condition: like new (used), functionality: fully functional, Year of construction: 2021, machine/vehicle number: 23708, power: 7.5 kW (10.20 HP), HACO TS 3006 Atlantic - Working length: 3050 mm - Mild steel capacity: 6 mm (400N/mm2) - Min. cutting angle: 0.5° - Max. cutting angle: 3.0° - Number of hold-downs: 18 Lhedpsy Dpzfjfx Akyjf - Strokes per minute at smallest angle: 14 - Strokes per minute at largest angle: 8 - Working height: 770 mm - Motor power: 7.5 kW - Total length: 3800 mm - Total height: 1750 mm - Total width without CE guard: 1650 mm - Total width with CE guard: 2700 mm - Control: SP9 Robosoft - Weight approx. 4500 kg

Condition: good (used), functionality: fully functional, Year of construction: 2002, machine/vehicle number: 7106, working width: 3,000 mm, sheet thickness (max.): 4 mm, Equipment: type plate available, hydraulic swing beam shear HERA TS 3000x4 with feed unit Lsdpsx Td Aiofx Akyjhf Year of manufacture: 2002

Condition: good (used), Year of construction: 1995, Sheet width 6040 mm Sheet thickness 4 mm Total power requirement 12 kW Machine weight approx. 22 t Ljdpfx Akey Encdeyjhf Additional information - Specification - Back stop - Roll shelf

Condition: used, functionality: fully functional, Year of construction: 2020, Guillotine Shear / Sheet Metal Shear - Safan Darley M-Shear 310-6 TS200 – Year 2020 Lhodpsy Em Sksfx Akyjf

Condition: good (used), functionality: fully functional, Year of construction: 2015, Very nice 4-meter Safan M shear Type: M Shear 430 6 Lodpfx Ajycwalskyjhf Capacity: 4300 x 6 mm High hold-down system Scrap flap system Return-to-sender system Year of manufacture: 2015

Condition: excellent (used), functionality: fully functional, Manufacturer/Type: Wieger 10 / 30 Short description: Guillotine shear Description: Immediately available from location: Guillotine shear Wieger Type 10 / 30 Ledpfey D A I Eox Akyshf Year of manufacture: 1991 Cutting length: 3100 mm Material thickness: 10 mm Frame throat: 300 mm Electric backgauge: 1000 mm Drive power: 11 kW Weight: 7500 kg

Condition: excellent (used), functionality: fully functional, Year of construction: 1991, Technical data: Maximum pressing force Working length between frames Horn length left + right Maximum horn load Total working length Throat depth Table width Ram width Maximum stroke Ram tilt adjustment (Y1/Y2) Rapid approach speed Return speed Working speed (approx.) Maximum distance between table and ram Rear stop (X) adjustment Rear stop (X) adjustment speed Backgauge height adjustment (R) Height adjustment travel of backgauge Backgauge height adjustment speed Adjustment of backgauge fingers (Z1/Z2) Adjustment speed Drive power Required oil filling Space requirements above floor Length: Width: Height (approx.) Weight (approx.) Press control - DNC 74 PS-Hydraulic Tool clamping: HKI/V-2 Lifting aid 1500 lg. with support consoles Tools: A4-T2-B-Sp 63 / A4-T3-M51 Die displacement with counter BLATT 631.00-1 KN mm 3150 3050 mm KN mm mm mm mm mm 3620 350 290 100 250 20 mm mm/sec. mm/sec. mm/sec. mm 90 . 75 0-8.5 593 0-700 mm mm/sec. 50 mm mm/sec. - mm/sec. - KW 30 1 420 mm mm 3900 2800 mm 3900 29500 Electric-hydraulic. Manufacturer/Type: Wieger 315 / 35 Short description: CNC press brake Description: Immediately available ex site: CNC press brake Wieger Type 315 / 35 Year of manufacture 1991 CNC control Cybelec Ljdpsy D A Ixefx Akyohf Weight 28 t

Condition: good (used), functionality: fully functional, Year of construction: 1998, Hydraulic Guillotine Shear Lhsdpjy Dr N Eofx Akyef Make: HERA Model: TK 3000 x 10mm Year: 1998 Technical Data Brand: HERA Model: TK 3000 x 10 Year of manufacture: 1998 Sheet size: 3050 x 10 mm Passage: 3080 mm Cutting angle: 1-3° Working height: 900 mm Strokes per minute: 14 1//min Motor power: 15 kW Dimensions: approx. L 4.15 x W 2.96 x H 2.20 m Weight: approx. 8.5 t Equipment • Siemens Simatic OP7 control unit • NC-controlled rear gauge • Full-length folding finger guard • Angle stop • Ball rollers in the support table • Cutting line illumination • Support arms • Automatic cutting angle adjustment • Automatic blade gap adjustment • Operating manual All information subject to change and without guarantee. A demonstration is possible at any time in our showroom.

Condition: good (used), functionality: not functional, Year of construction: 2008, control type: NC control, working width: 3,200 mm, sheet thickness brass (max.): 10 mm, overall weight: 11,500 kg, The machine is disconnected and ready for loading. Ljdpfx Aey E Inajkyehf

Condition: good (used), Year of construction: 1986, Max. working width: 4000 mm for sheets with tensile strength of 40 kg up to: 3 mm Table width: 470 mm Backgauge adjustment: 1000 mm Fixed cutting angle: 1°30' Ledpfxoy A Eg Uo Akyjhf Frame throat depth: 200 mm Hydraulic drive: 380 V, 7.5 kW Required space: 4650 x 1830 x 1420 mm (height) Weight: 5.7 t

Condition: used, Year of construction: 1993, Guillotine Shear Manufacturer: LVD Model: MVSB 62/8 Year of manufacture: 1993 Max. working length: 6,200 mm Sheet thickness: 8 mm Weight approx.: 13,000 kg Lhodpfxsy Atn Ho Akysf ä16426

Condition: excellent (used), Year of construction: 1998, AMADA MODEL GPN 630 HYDRAULIC SHEAR PNEUMATIC REA SHEET SUPPORTS ELECTRONIC REAR SAFETY GUARD Max. cutting width: 3050 mm Max. cutting capacity for steel: 0.4 - 6.0 mm Max. cutting capacity for stainless steel: 4.0 mm Max. cutting capacity for aluminium: 8.0 mm Adjustable back gauge: 1050 mm NC control Cutting gap adjustment via control Cutting angle adjustment via control: 0.4 – 2.2° Sheet holding function Strokes per minute: 33 cuts Motor power: 5.5 kW Dimensions (L x W x H): approx. 3800 x 2300 x 1950 mm Weight: approx. 6.5 tons STANDARD EQUIPMENT PROGRAMMABLE MOTORISED BACK GAUGE 2.0 METRE SIDE GAUGE 1.5 METRE FRONT SUPPORTS SHADOW LINE LIGHT AUTOMATIC HYDRAULIC HOLD DOWN CLAMPS CENTRALISED LUBRICATION FOOTSWITCH SHADOW LIGHT BEAM CYCLE COUNTER BLADE GAP AND RAKE ANGLE ADJUSTMENT ONE SET OF BLADES 4 CUTTING EDGES ADJUSTABLE STROKE PNEUMATIC SHEET SUPPORTS HOUR COUNTER AUTO-DIAGNOSTICS Lhjdeyypb Repfx Akyjf

Condition: good (used), functionality: fully functional, Year of construction: 1990, Used Safan guillotine shear with discharge unit Type VS 430 3 Ledpfx Aeyzgdrekyehf Capacity: 4300 x 3 mm Electrically adjustable back gauge Manually adjustable cutting angle and blade gap Equipped with lift/discharge device at the rear

Condition: good (used), functionality: fully functional, Year of construction: 2001, Neatly used Safan guillotine shear Type HT 310 4 (M Shear) Capacity: 3100 x 4 mm Adjustable backgauge, cutting angle, and blade gap Includes Theis stacking unit Lhodoyzgcujpfx Akyef

Condition: good (used), Year of construction: 1993, Used Darley guillotine shear Ledpfjyzf Snsx Akyehf Type VS 6008 Capacity 6050 x 8 mm Machine fully operational, frame needs to be welded (see last photo)

Condition: used, functionality: fully functional, Year of construction: 2008, Used Darley guillotine shear Type GS 4113 CL Lhjdpfxeyzf Eue Akyjf Capacity 4050 x 13 mm Year of manufacture 2008

Condition: good (used), functionality: fully functional, Year of construction: 2008, Used 4-meter guillotine shear by Darley Lsdeyzd Ihjpfx Akyehf Model: GS 4113 CL Capacity: 4100 x 113 mm Delem DAC 350 CNC control CNC backgauge High support table Year of construction: 2008
