Used Scm Evolution C for sale (54,965)

Condition: used, machine/vehicle number: 007966, Position 1: Panel Feeding and Loading SCM-EVOLUTION C Gjdewu Agpopfx Aagobn undefinedPosition 3: Panel Stacking and Offloading SCM-EVOLUTION C

Condition: excellent (used), Double side - Independent Machine (or 1st and/or 2nd in a line) Edges (band in rolls) thickness (Min/Max) mm 0,4 / 3 Panels thickness (min/max) mm 14 / 60 Working width (min/max) mm mm 260 (ca.) / 3200 Numerical Control /Software MAESTRO PRO EDGE Adjustable feeding speed (m/min) 10- 40 Safety sound-proof enclosures/cabins + Distance (center-axes) of Disappearing Dogs (mm) 400 SIZING PART (for each side): Anti-chipping Milling Unit AS (1 x Kw 4) Hogging Units DTR (2 x Kw 8) Spraying unit (Anti-sticking liquid) AAR EDGE-BANDING PART (for each side): Lamps to heat the workpieces side Glueing Unit (Hot Melt Glue + Quick Melt system) Band Pressure zone (N.C. adjustment) Edge coils support (No 2 reels) motorized Snipping (end-cutting) unit YU/SP-750 (30 m/min) Rough Trimming unit RSP Fine Trimming unit (Multi-profile, by N.C.) RI/S 2P Corner Rounding unit ( Contour Trimming) C1+C2 (4 x Kw 0,35) ED-SYSTEM e Fast-Release Gbedpjwhi Slsfx Aagen Profile Scraping unit RAS/S Glue scraping unit RCA/2C Spraying Unit (for polishing liquid) Buffing unit SPE Milling grooving unit U (1 SX + 1 DX) 2 x Kw 5,5

Condition: used, machine/vehicle number: 008108, Max width workable: 1050 mm Max length workable: 2400 mm Gjdpfew Idduox Aagjbn Max height workable: 250 mm

Condition: ready for operation (used), SCM T 120 C without feed mechanism. Gedpfsyw Sydex Aagobn

Condition: new, Year of construction: 2026, Combined saw-milling machine minimax st 3c F 16 Swiveling saw blade, swiveling milling spindle and format sliding carriage made of anodized aluminum Sturdy cast steel construction Large support surface and precise cast table High-precision sliding carriage made of anodized aluminum (travel 2250 mm) Large trimming frame (900 x 600 mm) with telescopic aluminum fence extendable up to 2660 mm with professional stop flaps Max. Saw blade Ø 315 mm with scoring device, tiltable from 90° - 45 Saw parallel fence with fine adjustment Stable saw unit and large dimensioned double cradle milling unit guarantee highest stability, precision, smooth running and long service life Solid and precise machine table made of stress-free gray cast iron Three milling speeds, manually adjustable from 3500 - 10000 min-¹ With right-left rotation of the milling spindle Standard arc milling protection hood Safety turning stop jaws made of aluminum Two motors with high power reserves Two plug-in handwheels for convenient and quick operation Dimensions and weights Weight approx. 470 kg Connection suction Suction port diameter 2 x 120 mm Suction port diameter saw blade guard 60 mm Gedshp Rdlepfx Aagobn Electrical data Power drive motor 2 x 5,0 kW Supply voltage 400 V Mains frequency 50 Hz Milling spindle spindle inclination 0 - -45 ° useful length of spindle 100 mm spindle speeds 3500/7000/10000 min-¹ Milling tool diameter max. not lowerable 210 mm lowerable 180 mm tenon milling 275 mm K

Condition: as good as new (ex-display), Year of construction: 2026, minimax c 26g TERSA - multiple combination for sawing, milling, planing-thicknessing. The work tables made of heavily ribbed cast iron and the base frame made of welded steel guarantee torsional rigidity and vibration-free working. Unique in this performance class: lightweight aluminum sliding table, anodized, with ball contact system. Gjdjdqzh Tjpfx Aagjbn Swiveling saw blade from 90° - 45 Table extension arm with aluminum crosscut fence for panels and large workpieces Planing unit with TERSA quick change system with three planing knives Helical toothed steel infeed roller for constant workpiece infeed during thickness planing Curved milling hood for profiling, standard with fine adjustment Milling unit with two speeds Three independent motors for each working unit Quality Made in Europe Equipment details Aluminum sliding carriage With millionfold proven ball contact system Insensitive to dust and dirt due to minimal contact point between ball and trapezoidal rail Durably lightweight Saw unit adjustment Manual height and angle adjustment of the saw unit via star knob Precise positioning by means of a scale TERSA planer cutterhead No more adjusting and screwing Change of planing knives in seconds Self-locking Particularly low noise Table planer The milling unit has two speeds for flexible tool use. The machine is equipped with a finely adjustable bow cutter for profiling. With the aluminum slide tenoning is possible without any problems. Thickness planer With the powerful thickness feed, workpieces up to 200 mm high can be planed. The helical toothed infeed roller guarantees constant infeed. The planing table can be folded towards the inside of the machine to save space. The changeover from planer to thicknesser is done in seconds with one handle. Surface planer Standard with TERSA planer blade quick change system Large dimensioned jointer tables The planing and thicknessing tables are made of grey cast iron and guarantee the smoothest running and vibration-free operation. Saw unit Saw swivels up to 45 With saw blade 250 mm Ø at max. 80 mm cutting height On the rip fence can be cut up to 500 mm width. Table extension With degree scale and aluminum fence for angular cuts on panels and large workpieces Scope of delivery: Tersa quick-change planer cutterhead Anodized aluminum format sliding carriage Miter fence with one folding stop Multifunctional fence for parallel cutting and planing Eccentric clamping arm Model minimax c 26g TERSA Article no. 5500027 Cutting length 1200 mm Cutting width with rip fence 500 mm Max. Cutting width left of saw blade 1200 mm saw blade inclination 90 - 45 degrees Max. Cutting height at 90° 80 mm sliding carriage length 1140 mm Format sliding carriage width 201 mm Height of sliding table 70 mm Saw table length 1024 mm saw table width 224 mm saw table height 900 mm Cutterblock type TERSA Cutterblock diameter 62 mm Number of planing knives 3 pcs Planing table width 260 mm Dressing table length 1040 mm Angle of inclination of sawing/planing fence 90/45 degrees Dressing chip removal max. 3 mm Thicknessing table length 450 mm Thicknessing table width 260 mm Thickness working height min. 3 mm Location: Ex stock 54634 Bitburg - immediately available -

Condition: used, Year of construction: 2011, AXES Working Range X-Y-Z Axes * mm 3050-1300-180 Workpiece length for pendulum operation mm 1390 Stroke X-Y-Z Axes mm 3460-1735-250 Gbjdpfxsyymz Us Aagjn Max. traverse speed of X-Y axes m/min 60 WORK TABLE Number of workpiece supports and vacuum cups 6 / 2 standard type Standard end stops / position 1 / rear Vacuum pump m3/h 90/108 DRILLING UNIT Vertical spindles std/quantity/speed 1/min 12 (8X-5Y) / 4000 Horizontal spindles std/quantity/speed 1/min 6 (4X-2Y) / 4000 Integrated grooving / saw unit in X Ømm/1/min 120 / 6000 Motor power kW (HP) 2.2(3) ELECTROSPINDLE Motor power std./opt. (S6) kW (HP) 7.5(10) / 11(15) Max. speed 1/min 24000 Tool changer traveling with unit carrier in X 4 places, pneumatic INSTALLATION Installed power KVA 23÷28.5 Compressed air requirement Nl/min 450 Extraction air requirement m3/h 1900+1900 (3400) Required extraction air velocity m/sec 30 Extraction connection diameter mm 150+150 (200) Machine weight Kg 3000 * X: distance between stops; Y: milling center as reference point; Z: workpiece passage GENERAL FEATURES CNC-controlled drilling and milling center, C-frame design, and worktable with adjustable workpiece supports and vacuum suction cups, for: - Vertical drilling on the panel surface - Horizontal drilling on all four workpiece sides - Groove milling with disc cutter in the “X” direction - General milling work Self-supporting structure and work table Structure made from welded steel construction with control cabinet integrated into the machine frame. Available in two different lengths and with standard workpiece supports or TV carrier options. Box construction made from cold-rolled steel with internal stiffening ribs and protective devices comprising a drilling head with vertical spindles, horizontal spindles, an integrated grooving and saw unit, and an SCM electrospindle with HSK 63 F quick-change tool system. Movement paths of the portal and unit carrier Movement in the X, Y, and Z axes is via linear prismatic guideways with preloaded ball bearings. The X-axis movement (moving gantry) uses a preloaded, backlash-free rack-and-pinion drive with helical gearing. Movement of the unit carrier in Y and Z directions is also preloaded for precision. Positioning of the working units and machine function control is through "brushless" AC servo motors and digital drives. CNC CONTROL The control unit comprises a numerical control for the milling and drilling machines and a PC with a graphical user interface "XILOG PLUS". PC office operating system Windows XP - 17" LCD color screen - QWERTY keyboard - Swiveling control panel - Machine interface: Xilog Plus software Xilog Plus Features Programming - Parametric, graphical, and ISO programming - Import of DXF and ASCII files - Linear or circular interpolation on three axes, spatially linear, spirally on selected plane - Supported programming with graphical and syntax assistance for drilling and milling operations - Automatic optimization of drilling operations and tool change cycles - Possibility to shift panel zero point for drilling on slanted or curved panel sides - Full compatibility with CAD/CAM Routocam (SCM) – AlphaCam Integrated additional functions - Calculator for direct transfer of computed data - S

Condition: excellent (used), Year of construction: 2018, functionality: fully functional, Equipment: documentation/manual, SCM - STEFANI AUTOMATIC DOUBLE-SIDED FORMATING & EDGEBENDING LINE consist of: 1. SCG vacuum feeder / loader and conveyor 2. SCM STEFANI EVOLUTION SSB 1 automatic double-sided formating and edgebending machine − clean pack L − anti adhesive unit AAR − crushing unit − automatic milling unit − EVA glue module − SLIM LINE module − NORDSON units for PU glue − end trimming unit − horizontal sawing unit − fine trimming unit − milling unit for edge rounding of solid wood − multiedge scraping unit − brushing unit Total lenght: 9750 mm 3. PANEL TURNER GP DC / BOR 4. SCM STEFANI EVOLUTION SSB 2 double-sided automatic formating and edgebending machine − clean pack L − anti adhesive unit AAR − crushing unit − automatic milling unit − EVA glue module − SLIM LINE module − NORDSON units for PU glue − end trimming unit Gbedpfx Aszb Eu Usagen − horizontal sawing unit − fine trimming unit − ROUND 4 unit with Zero lock − milling unit for edge rounding of solid wood − multiedge scraping unit − brushing unit 5. BIESSE Techno Logic - automatic throughfeed drilling machine 6. SCG vacuum feeder / loader and conveyor Total lenght: cca 23 m Year of production: 2018

Condition: excellent (used), Year of construction: 2005, functionality: fully functional, Cutting length: 4500 mm Cutting depth: 4300 mm Cutting height: 100 mm Main saw unit Main saw motor: 11 kW Scoring saw unit Cutty cutting optimizer Grooving capabilities 1 fixed front table with air cushion system Gbsdpfx Ajzbrnnsagon 3 mobile front tables with air cushion system Pusher carriage with 9 clamps Software: WinCut Label printer Approximate weight: 3700 kg Available from the end of September 2026.

Condition: good (used), Code: 0321 Brand: SCM Model: MULTIFLEX C - CE Standard Automatic working center for window frames for tenoning, profiling and contouring - Max workpiece thickness mm 140 - CE Standard Technical data Automatic carriage with chipbreaker Max working length 2800 mm Gbjdpfx Aasytn U Iegjn Min/max workpiece thickness 30/140 mm End cutting saw diameter 400 mm - Motor Hp 4 Tenoning spindle useful length mm 320 - Motor Hp 10 Spindle diameter mm 50 Max tool diameter mm 350 Profiling spindles: 1° Anti-splinter profiling spindle length 320 mm - Motor Hp 7,5 - Tool diameter mm 220 2° profiling spindle length mm 320 - Motor Hp 7,5 - Tool diameter mm 220 Min and max diameter of profiling spindles tools mm 100/220 Profiling spindles diameter 50 mm Tool group Zuani Variable speed feed Glazing bead recovery group - Motor Hp 3 - Diameter of suction mouth mm 50 Overall dimensions mm 2400 x 3300 x 2000 h Weight kg 2200

Condition: used, Year of construction: 2006, · Working area: 2,650 x 1,240 mm Gjdpfx Aasx Twccegjbn · X-Y travel: 2,995 x 1,385 mm · Z-axis travel length: 200 mm · Clearance height: 180 mm C-axis deactivated – 3-axis machine The base structure is a monolithic construction made of thick-walled steel. It is reinforced throughout the entire machine bed with welded-in triangular plates, which makes it extremely stable. The use of the triangle shape with a broad base for load-bearing parts is the key to lasting precision and stability. The machine layout allows the operator an optimal workflow despite minimal space requirements. The resulting base frame thus provides the machining unit with a balanced and secure foundation, ensuring excellent load distribution. The mobile unit carrier is built as a solid monoblock. It is positioned in X-direction on ground prismatic guides with recirculating ball carriages. The working unit is again mounted on ground prismatic guides and a recirculating ball carriage on this mobile unit carrier. Description of aggregates and accessories (basic equipment) Drilling unit: Drill head with 12 + 6 spindles · 7 individually selectable vertical spindles in X · 5 individually selectable vertical spindles in Y · 4 horizontal spindles in X (2+2) · 2 horizontal spindles in Y (1+1) · Speed: 4,000 rpm · Power: 2.2 kW · Grid: 32 mm · Drill interface: M 10 with 11 mm fitting Grooving saw unit in X: · Integrated in drill head · Grooving saw blade with max. diameter 120 mm Main milling unit (Position 2): · Tool holder HSK 63F · Speed: 1,500 - 24,000 rpm stepless via inverter · Motor power 4.4 kW (6 HP) from 12,000 rpm (S1) · Motor power 6.6 kW (9 HP) from 12,000 rpm (S6) · Clockwise/counterclockwise rotation · Ceramic bearings · Includes: 4 pcs. tool holders (right) without collet Tool changer R8L: Automatic tool changer for 8 tools. Mounted on the rear unit carrier for quick tool access. · Number of tool stations: 8 · Max. tool diameter: 120 mm · Max. weight per tool: 4.5 kg · Max. total weight all tools: 22 kg · Holder for 1 angle gear · Moves in X direction Horizontal milling unit (Position 1): Horizontal unit with two opposing outputs for milling and grooving. · Speed: 9,000 – 18,000 rpm stepless via inverter · 1 output for collet 3-20 mm (ER 32) · 1 output for saw/collet 3-12 mm (ER20) (for saw D=120 mm / bore 50 mm) · Motor power: 3 kW (4 HP) · Max. front milling tool diameter: 20 mm · Max. front milling tool length: 110 mm · Max. rear milling tool diameter: 12 mm · Max. rear milling tool length: 80 mm · Max. saw blade diameter: 100 mm · Saw blade bore (ER 32): 50 mm · Saw blade arbor diameter (ER 20): 12 mm Work table: The work table is designed to guarantee the operator maximum freedom of movement. The quick vacuum clamping system provides maximum flexibility for precise positioning and optimal holding of workpieces. · 6 supports, 1000 mm, steplessly adjustable pneumatically in X direction · 12 round vacuum cups D = 110 mm, steplessly adjustable in Y (2 pcs. per support) · 2 stops in X (1 left / 1 right) · 1 stop in Y per support (6 in total) · Retractable reference stops are CNC controlled · Pendulum machining standard (2 work zones) --- other clamping systems available as options --- Axis movement: The drive system in X, Y and Z is via ground recirculating ball screws...

Condition: new, Year of construction: 2023, Stable cast iron construction Milling spindle can be swiveled backwards from 0° to -45° Right-left rotation of the milling spindle Generously dimensioned milling unit made of cast iron, attached directly to the table Solid and precise cast iron table Standard curved milling protection hood Aluminum sliding carriage ball contact system Torsion-resistant, highly precise, smooth-running and problem-free in daily use 10-year SCM guarantee on wear of the guideways Milling spindle mounted high up with precision ball bearings, resulting in the lowest possible bearing load and the longest possible service life Exact router fence with quick adjustment and fine adjustment with a scale on the stop jaw Integrated suction connection Large milling table opening allows the use of larger tools Weight approx. 290 kg Extraction connection diameter 2 x 120 mm Working table L x W = 1000 x 435 mm Table height 900 mm Sliding carriage length 1000 mm Sliding carriage width 270 mm Drive motor power 5.0 kW, 400 V, 50 Hz Milling spindle inclination 0 to -45 ° Spindle usable length 100 mm Gbodpfjiknp Rjx Aagen Overhang max. above table 130 mm Spindle speeds 3500/7000/10000 rpm Mandrel diameter 30 mm Tool diameter max. lowerable 180 mm

Condition: used, Year of construction: 1989, With sanding units consisting of: - 1 calibration roller - 1 combination unit with rigid pad Used Manufacturer: SCM Model: UNO C-CS Year of manufacture: 1989 Machine no.: AE005036 REF.: 030514 Sanding width: approx. 920 mm Pass-through height: approx. 3-160 mm Number of units: 2 pcs., 1x15 kW Units from above: 2 pcs Belt dimensions (L x W): 1525 x 930 mm 2x feed speed: 4.5 / 9.0 m/min Gbjdpfx Ajy H N Tasagon 1 pc calibration roller - grooved / rubber-coated 1 pc combination unit with rigid sanding pad - rubber-coated roller Extraction connection: D 2 x 160 mm Required space: approx. 1600 x 1500 x 1800 mm Weight: approx. 1200 kg Location: 97447 Gerolzhofen, free loaded, unpacked Transfer in as-is condition as inspected, without warranty or guarantee

Year of construction: 2010, operating hours: 540 h, condition: ready for operation (used), travel distance X-axis: 3,060 mm, travel distance Y-axis: 1,735 mm, travel distance Z-axis: 250 mm, overall weight: 2,000 kg, number of axes: 4, This 4-axis SCM TECH Z2-27-C wood boring machine was manufactured in 2010. It features a maximum workpiece height of 160 mm, length of 2700 mm, and width of 1300 mm. The machine includes a routing spindle and a horizontal boring unit, ensuring versatility in operations. If you are looking to get high-quality wood processing capabilities, consider the SCM TECH Z2-27-C machine we have for sale. Contact us for further details. • Electrical: 400 V, 3 + N, 33 A, 50 Hz, breaking capacity 10 kA Gjdey Dd R Ijpfx Aagjbn • Control: Xilog Plus • Machining units: saw unit (included), horizontal boring unit (included), routing spindle: 1 • Workpiece capacity: max height 160 mm; max length 2700 mm; max width 1300 mm; max width (double posts) 1210 mm • Max travel speed: 60 m/min • Clamping system: pneumatic locking bars; number of clamping bars: 6 • Suction cup sizes: 120x120 mm and 55x120 mm • Machine on: 5.500 h

Condition: new, - New -Description:- For sawing, milling, surface planing, thickness planingand optional slot drilling- The work tables made of heavily ribbed gray cast ironand the underframe made of welded steel guaranteeTorsion resistance and vibration-free work- Unique in this performance class: smootherAluminum format slide, anodized, with ball contact system- Swiveling saw blade from 90 ° - 45 °- Table bracket with graduated scale and aluminum crosscut fencefor angled cuts on plates and large workpieces- Planing unit with TERSA quick change systemwith three planer knives- Helical-toothed steel feed roller for constantWorkpiece infeed when thicknessing- curved milling protection hood for profiling,with fine adjustment as standard- Milling unit with two speeds- The units are driven by three independent motors- Made in Italy qualityTechnical specifications:Dimensions and weightsWeight (net) approx. 245 kgDressingPlaning table width 300 mmPlaning table length 1200 mmAngle of inclination saw / planer fence 90/45 °Chip removal ssing 3 mmConnection suctionExtraction nozzle diameter 4 x 120 mmSuction nozzle diameter of the saw blade guard 60 mmInstallation informationRequired space length 2460 mmSpace requirement width / depth 2155 mmExplanation of space requirements: Take the dimensions into accountmaximum travels or useful cknessThickness table length 450 mmThickness table width 300 mmWorking height thickness min. 3 mmWorking height thickness max. 200 mmChip removal max. Thickness 3 mmElectrical dataConnection voltage 400 VMains frequency 50 HzNominal operating mode drive motor S6Duty cycle of drive motor 40%Drive motor power 3 x 1.8 kWSliding carriage and tableFormat sliding carriage length 1140 mmFormat sliding carriage width 201 mmFormat sliding carriage height 70 mmTable length 1024 mmTable width 224 mmTable height 900 mmMilling spindleSpindle inclination 0 °Spindle mandrel diameter 30 mmUsable length of the spindle 75 mmSpindle speed (s) 5000 - 7500 min? ¹Milling tool diameter l diameter max. 160 mmTool diameter can be lowered 180 mmTool diameter max. Tenon milling 275 mmPlaner knife shaftPlaner shaft type TERSAPlane shaft diameter 62 mmNumber of planing knives 3 pcsCircular saw unitTrimming length 1200 mmCutting width with rip fence 540 mmMax. Cutting width to the left of the saw blade 1200 mmSaw blade inclination 90 - 45 °Max. Cutting height at 90 ° 67 mmMax. Cutting height at 45 ° 40 mmMax. Saw blade projection 90 ° 75 mmMax. Saw blade projection 45 ° 60 mmFeedFeed speed 6 m / minScope of delivery:- Tersa quick-change planer knife shaft- anodized aluminum sliding table- Multifunctional stop for parallel cuts and surface planing- Table extension arm with crosscut fence and stop jaw- Eccentric clamping armItem no .: 5500030 Gedpovwf Enofx Aagjbn

Condition: used, SCM Selecta C edge banding machine Gedpfoddn Svsx Aagjbn Edge banding height 10-60 mm edge banding thickness 0,4-25 mm Caps Overlapping edgebanding bevels - 25 mm for solid wood Pivoting edgebanding unit for foil and ABS edges Radius scraper chamfering Buffing unit Space requirement Length 6345 Height 1530 Depth 1106 mm scm_selecta (1)

Condition: ready for operation (used), Year of construction: 2015, machine/vehicle number: AA1/018167, functionality: fully functional, workpiece length (max.): 3,300 mm, workpiece width (max.): 1,400 mm, workpiece height (max.): 180 mm, number of axes: 5, number of slots in tool magazine: 26, TECHNICAL DETAILS Workpiece length (max.): 3,300 mm Workpiece width (max.): 1,400 mm Workpiece height (max.): 180 mm Number of axes: 5 Number of tool slots in the tool magazine: 26 MACHINE DETAILS Control system & software: Maestro Version 1.00.022.1034 Input voltage: 400 V Input current: 59 A Dimensions (L x W x H): 6,000 x 3,500 x 3,500 mm EQUIPMENT Documentation/Manual Includes Clemex system Additional licenses: 1 3D dongle, 2 2D dongles Tool package with approx. 20 milling cutters (including DIA milling cutters, indexable insert milling cutters, roughing milling cutters, T-slot milling cutters, and rounding milling cutters) Palette CAD Gbjdpfxszarfds Aagon Two licenses for Palette CAD Vacuum pump: Type Q2EFA132M6C-34

Condition: used, machine/vehicle number: 008132, Type of edging: Thin edge, Thick edge Gluing System: EVA Hotmelt Premilling Unit: yes Corner Rounding Unit: yes Max feed speed: 18 m/min Gbodpfxsw Idc Rj Aagen Maximum panel thickness: 60 mm Operating Units: 7 nr

Condition: new, Year of construction: 2023, functionality: fully functional, input voltage: 230 V, input current: 16 A, input frequency: 50 Hz, travel distance X-axis: 915 mm, travel distance Y-axis: 610 mm, travel distance Z-axis: 176 mm, number of axes: 3, table length: 1,170 mm, table width: 760 mm, rotational speed (max.): 24,000 rpm, Equipment: CE marking, documentation/manual, european tool clamping system, Compact 3-axis SCM Startech CN K CNC machining center for milling, engraving, sign making, and 3D prototyping. Work table of 1,170 x 760 mm, X-Y-Z travel of 915/610/176 mm, and Hiteco 2.4 kW milling head up to 24,000 rpm with ER25 tool holder. Gbsdpfx Aaszcfwrjgon Equipped with: - Full safety enclosure - LED lighting - Numerical control with interpolation - HICAM2 interface - Ethernet connection - Pneumatic suction cup kit - Tool height sensor - 4th interpolating axis for lathe work - Base with wheels and adjustable feet Single-phase 230V power supply. Ideal for carpentry, engraving, machining, and prototype manufacturing.

Condition: good (used), Year of construction: 2017, NUMERICALLY CONTROLLED EDGE BANDER WITH PRE-MILLING (SPINDLES) & CORNER ROUNDING UNIT Brand: SCM Model: K 360 HP-T-ER1 Serial No.: AH/120944 Ref: 123304 Year: 2017 WORKING CAPACITIES: - Panel height to be machined: 8 - 58 mm Thickness 10 to 45 mm when using rounding unit - Panel length for edgebanding: 210 to 2500 mm - Minimum panel width to be machined: 90 to 1100 mm - Edge thickness in coil: 0.4 to 3 mm without rounding max 3 mm with rounding unit - Edge thickness in strips: max 6 mm without rounding max 3 mm with rounding unit - Edge width: panel thickness + 2 mm each side - Feed rate: 11 m/min - Minimum gap between panels: 600 mm - Panel overhang beyond the transfer chain: 30 mm MACHINE CONFIGURATION: - StarTouch control - Prepared for barcode reader - Reel holder table Ø800 mm - Front extension table - Easy size: digital positioning of infeed fence and panel passage height - Anti-adhesive spray unit Gbedporx S Ipefx Aagsn - Pre-milling unit (RT-V trimmer) 12,000 RPM - Infrared panel preheating at infeed - Glue application unit (VC-VM) with interchangeable glue pot for granules, capacity: 1 kg. Heating time: 12 minutes Pneumatic pre-cut guillotine Digitally positioned pressure station with 3 rollers (1 roller powered and with timer) - Trimming unit (end cutting) tiltable 0-20° 12,000 RPM - Top/bottom flush trimming unit with digital positioning and copying system. 2 mm radius (or chamfer) router 12,000 RPM - Corner rounding unit R2 mm, 12,000 RPM, digital positioning - Top/bottom R1 & R2 mm radius scrapers with digital positioning - Top/bottom straight scrapers - Edge finishing spray device (Nebulizer) OTHER FEATURES: - Pre-milling group motors: 2x2 kW - End trimming motors: 2x 0.19 kW - Lift/lower motor: 0.30 kW - Feed motor: 1.1 kW - Flush trimming group motors (milling): 2x 0.65 kW - CE Marked - Lockable isolator, emergency stop buttons - Power supply: 380 V, three-phase, 50 Hz - Pneumatic supply: 8-10 bar max, dry air - Extraction: 1x Ø100 mm and 5x Ø80 mm Spindles: 780 m³/h Edge trimming: 360 m³/h Scrapers: 2x360 m³/h Max. footprint in working order: 10.80 x 2.40 m Dimensions for transport (LxWxH): 4.85 x 1.20 x 1.70 m Weight: 1568 kg Machine supplied with mounted tools, manual, spare parts list and diagrams.

Condition: used, Year of construction: 2014, machine/vehicle number: AH /117836, functionality: fully functional, year of last overhaul: 2025, Equipment: documentation/manual, Ideal machine for edge banding of solid wood panels MACHINING CAPABILITIES: - Panel height (thickness) to be machined: 8 to 60 mm - Router pass: max. 90mm², 0 to 3 mm - Minimum panel length to be machined: 140 mm with an edge thickness >3 mm 200 mm with an edge thickness between 3 and 12 mm - Panel width to be machined: up to 2000 mm - Edge thickness: 0.4 to 3 mm in coil form, up to 12 mm in strip form Panel overhang relative to the chain (part protrusion): min. 30 mm - Edge width: recommended overhang: panel thickness + 4 mm - Feed system (2 feed speeds) 18 m/min for thin edges 12 m/min for strip edges (solid wood) - Distance between parts (depending on feed speed): recommended min. 800 mm MACHINE COMPOSITION: - Unwinding table, useful diameter: Ø780 mm - Electric positioning infeed guide - Chain conveyor belt, work surface height from the ground: 96 cm - Front extension table with rollers (serves as a support up to 2 m) - RT-E sanding unit (edge trimmers or routers) 2 x 4 kW, 9000 rpm - VC gluing unit Infrared preheating of the edge Pre-feeder for EVA granules, indicative consumption 8.5 kg/h "Fastblock" glue pot, pneumatic pre-cutting shear Pressing with 4 rollers, including 1 motorized roller, pressure with electric adjustment - K-SEL end trimming unit Rotation speed: 12000 rpm, motor inclination from 0 to 15° - RFK top/bottom flush trimming unit Rotation speed: 12000 rpm - RI 800 chamfering/flush trimming unit with copy pad Rotation speed: 12000 rpm, spindle inclination from 0 to 25° - GLC compact sanding unit, 1400 rpm Gjdpezcpixsfx Aagebn Belt: 75 x 2700 mm, inclination from 0 to 5°, adjustable pneumatic pressure - SPN polishing station with textile polishing brush - Motorized operator return, useful width 1 m, with 2 roller tracks, spacing 34 cm Air cushion track and belt conveyor. Arrival height from the ground: 79 cm OTHER CHARACTERISTICS: - General power supply: 400 V, three-phase + N + T, 50 Hz - Installed power: IN 52 A nominal - Pneumatic supply: 8 - 10 bars, dry air, working pressure: 6 bars - Extraction: 6 x Ø50 mm, 1 x Ø80 mm, minimum flow rate 3000 m3/h - CE marking, lockable disconnect switch, emergency stop buttons

Condition: ready for operation (used), Year of construction: 2012, functionality: fully functional, Equipment: CE marking, Model Accord 30 FX Year November 2012 - First time installed in 2013 Machine type 3-axis CNC machining center for solid wood, doors, windows, stairs, and joinery Working feld: X 3680 by Y 1680 mm. Z-axis travel 250 mm BRC multifunction unit for cutting, routing and boring both vertically DUO HT 12 Machining Head Syncron 8 Frontal and rear row of stops H50 for plates Prearrangement for clamps and for pneumatic clamps for plate Automatic positions system for placemant of the support beams and vacuum cups. Gbjdpfx Aaszbz Htegsn 16 adjustable suction cup H50 145x145 mm. 8 adjustable suction cup H50 145x55 8 adjustable suction cup H50 180x65 Nr 8 Lifting supporters Motoriserd belt for wastes removal. Main electro spindle power 12 kW Maximum spindle speed 20,000 rpm Tool holder HSK-F63 Tool changer for 12 tools Vertical drilling spindles 10 X-Y rapid speed Up to 90 m/min Vacuum pump capacity 250 m³/h Maximum workpiece height 250 mm Supplementary base for bar Matic TecPad mobile console Pro-Speed Safety system XiLog Maestro soft wear Approximate machine weight 5 000 kg Volt 400 AC 50 Hz This machine still is in daily use to the end of week no. 24 Machine first time installed in 2013 and it is working on its orginal place. Come from Norway also low number of workin hours during the years. Rekman Maskin & Service - service of cnc woodworking machines since 1986

Condition: ready for operation (used), Year of construction: 2008, machine/vehicle number: A3347169, functionality: fully functional, number of axes: 3, CNC machine SCM, Record 100 AL action line, 3-axis woodworking line, 400V, year of manufacture 16/07/2008, electrical cabinet, control with safety mat, partition wall, working area 305 x 122 cm, total machine dimensions: approx. 565 x 250 x 260 cm, self-dismantling required 3 axes In perfect working condition 1 large vacuum with details of white panel and 1 small vacuum: Year 2019 / N°A3347169 Gjdjxg El Aopfx Aagjbn Type VTLF2.250/0-79 Frequency 50/50Hz Speed 950/1150min-1 Power required 5.5/6.4kW Inlet capacity 244/286m³/h Max vacuum 200/200mbar Video available.

Condition: used, Year of construction: 2006, operating hours: 14,808 h, total height: 2,850 mm, total length: 9,000 mm, total width: 2,450 mm, Colour: White Empty weight: 4.000 kg Price: On request - Machine available from: 2026-07-10 - Year: 2006 - Documentation available: Yes - CE marking present: Yes - CE certificate present: Yes - Serial number: AA1/015406 - Operating hours: 14808 - Number of milling spindles [pcs.]: 1 Gbjdpfxsx Hfiks Aagjn - └ Milling spindle 1: - - Number of controlled axes [pcs.]: 5 - - Min. spindle speed [rpm]: 600 - - Max. spindle speed [rpm]: 24000 - - Main motor power [kW]: 11 - - C-axis present: Yes - Type milling table: Beam table - Tool clamping system: HSK-F63 - Material clamp system: Pneumatic - Drilling unit present: Yes - └ Horizontal drill spindles [pcs.]: 6 - └ Vertical drilling spindles [pcs.]: 12 - Saw unit present: Yes - Tool changer positions [pcs.]: 16 - System/software: Xilog plus - Safety feature: Safety mat - Vacuum pump present: Yes - └ Number [pcs.]: 1 - └ Brand: Becker - └ Main motor power [kW]: 5.5 - └ Capacity [m³/h]: 250 - CNC options: Offcut conveyor, Manual control - CNC documentation available: User keys/licenses - Table length [mm]: 3050 - Table width [mm]: 13 - Working range X [mm]: 3110 - Working range Y [mm]: 1300 - Z-axis working range [mm]: 200 - X-axis maximum stroke [mm]: 3500 - Y-axis maximum stroke [mm]: 1815 - Z-axis maximum stroke [mm]: 440 - Installed length [mm]: 4600 - Installed width [mm]: 6500 - Installed height [mm]: 3400 - Transport dimensions: 9000mm x 2450mm x 2850mm (l x w x h) - Transport weight [kg]: 4000kg - Transport packages [pcs.]: 1 Financial information VAT: The price shown is exclusive of VAT VAT/margin: VAT deductible for entrepreneurs Delivery and trade-in always possible for everything in the industrial sectors Glenn Smeets

Condition: used, Year of construction: 2014, total height: 2,800 mm, total length: 10,300 mm, total width: 2,450 mm, Colour: Grey Empty weight: 6.600 kg Price: On request - Year: 2014 - Documentation available: No - CE marking present: Yes - CE certificate present: No - Serial number: AA2/002546 - Number of milling spindles [pcs.]: 1 - Type milling table: Beam table - Tool clamping system: HSK-F63 - Material clamp system: Pneumatic - Drilling unit present: Yes - Tool changer positions [pcs.]: 24 - System/software: Xilog plus - Safety feature: Safety light curtain, Door interlock switches, Enclosed fence - Vacuum pump present: Yes - └ Number [pcs.]: 1 - └ Brand: Becker - └ Type: Vtlf 250 - └ Year of manufacture: 2008 - └ Main motor power [kW]: 5.5 - └ Connection diameter [mm]: 70 - └ Oil free: Yes - Tools included: Yes - CNC options: Offcut conveyor, Manual control - CNC documentation available: USB stick - Table length [mm]: 5200 - Table width [mm]: 1300 - Voltage [V]: 400 - Current consumption [A]: 64 - Transport dimensions: 10300mm x 2450mm x 2800mm (l x w x h) - Transport weight [kg]: 6600kg - Transport packages [pcs.]: 1 Financial information VAT: The price shown is exclusive of VAT Gbodpfeytcl Ijx Aagsn VAT/margin: VAT deductible for entrepreneurs Delivery and trade-in always possible for everything in the industrial sectors Glenn Smeets
