Used Shaublin Schaublin 102N Lathe for sale (5,535)

Condition: excellent (used), Year of construction: 2005, Schaublin 102N-VM-CF high precision Swiss lathe Year: 2005 max. admitted diameter over the bed 200 mm max. admitted diameter over the slides 120 mm Height of centers 102 mm Distance between centers 450 mm Bed length 1000 mm Dcodpfx Asw N Rh Aed Nog Bed height 168 mm Power 4.2 KW Spindle speed 100 - 3000 RPM Spindle W25 Transverse stroke, X axis 100 mm Resolution, X axis (radius) 0,01 mm Longitudinal stroke, Z axis 90 mm Resolution, X axis (radius) 0,01 mm Lead screw - 8 longitudinal feeds - Larger feeds possible when using the thread control for turning Max. cross section of tool shank (Multifix system) 10x10 mm Bar holder (MULTIFIX system) diameter 20 mm Height and side-adjustable tailstock: Internal taper of the sleeve Mk2 Spindle OD 30 mm Spindle stroke 80 mm Coolant tank capacity 23 L Electrical power supply voltage 400 V Overall dimensions: length x depth x height: 1500 x 510 x 1550 mm Accessories / options: - ACU-RITE digital readout unit, 3 axis X-Z-Z1 X resolution 0.001[mm] Z resolution 0.005[mm] Z1 resolution 0.005[mm] - Coolant system - Rear sheetmetal guard - Double Start/Stop pedal and spindle rotation direction inversion - Schaublin W25 collet set - Cast iron chuck W25 Ø110[mm] with jaws - Quick-change toolholder turret MULTIFIX-A with holders - Driving system for auxiliary equipment with BELT adjustable and swivelling belt-tensioning attachment drive device complete with motor belt Ø6x2’500[mm] - Tailstock - etc... Under power in our warehouse.

Year of construction: 1987, condition: used, Schaublin 102N lathe with various tools Dcsdpsyhyt Aofx Ad Njg

Year of construction: 1980, condition: used, Schaublin 102N lathe Dcjdsyacuvspfx Ad Neg

Year of construction: 1997, condition: ready for operation (used), - USED - CONVENTIONAL LATHE CENTRE HEIGHT: 102 mm DISTANCE BETWEEN CENTRES: 450 mm MAX TURNING DIAMETER OVER BED: 200 mm MAX TURNING DIAMETER OVER CARRIAGE: 120 mm BAR CAPACITY: 25 mm SPINDLE: 50 - 5000 rpm; 3 kW TAILSTOCK TAPER: CM 2 QUILL DIAMETER: 30 mm QUILL TRAVEL: 80 mm TURRET HEAD: MULTIFIX OVERALL DIMENSIONS: 1500 x 510 x 1550 mm Dcodpfx Aeyvlxqod Nsg

Condition: refurbished (used), Year of construction: 2026, functionality: fully functional, machine/vehicle number: 310435, Completely overhauled - new painting New workbench - new geometry Manufacturing origin Swiss Voltage 380V 50Hz 3Ph Dodpfx Aedr R Tcjd Njcg Customs position 8458.1930 TECHNICAL DATA Capacities : - height of centres 102 mm - distance between centre, standard headstock type W 470 mm - distance between centres, headstock type W with reduction unit 375 mm - swing over bed 200 mm - swing over carriage 120 mm Bed : - height-width-length 168-100-1000 mm cast-iron bed with ground inverted-V profile Headstocks : - spindle nose for collets W-25 - maximum bore through collet 19.0 mm - headstock with reduction unit, ratio 1:5 Carriages : - stroke of longitudinal tool slide 90 mm - stroke of transverse tool slide 100 mm - size of tools 12x12 mm Tailstocks : - internal taper of tailstock spindle Morse 2 - spindle stroke, screw- and handwheel-operated 80 mm errors and omission excepted-data given without obligation Inventory no. 2250023, machine comprising: 1 NEW workbench 2000x800 mm with blue Urphen worktop 2000x800x50 mm 1 leg, 1 B750 cabinet with 7 drawers 1xD50/2xD75/2xD100/1xD150/1x200 1 bench for overhead control 1 W-25 workpiece holder without gear reducer with clamping key, serviced 1 serviced cross slide 1 reconditioned aligned tailstock 1 380V/50Hz/3ph motor. 2 speeds 1 used W-25 solid centre 1 set of used W25 collets 1 used Reishauer ZMG 2x3 jaw chuck Ø 110 mm on w-25 flange 1 new set of used Multifix tool holders including -1 type A turret with AG20 stud -2 AD1675 chisel holders -2 AD2090 chisel holders 1 Albrecht self-tightening drill chuck, cap 1-13 mm on CM2 tenon, used 1 used CM2 solid centre point OPTION 1 used tensioner with new belt CHF 1000 + VAT 1 AS TYPE B-8 GRINDING MACHINE with 360° swivel quill max. speed 28,000 rpm, adjustable height, adjustment, ref. 800053 CHF 1,325 + VAT

Condition: excellent (used), functionality: fully functional, High-Precision Leadscrew Lathe Schaublin 102N-VM Technical Data: >> Machine No. 283152 >> Centre height: 102 mm >> Centre distance: 450 mm >> Spindle bore: 25 mm >> Longitudinal feeds: 8 steps from 0.02 to 0.3 mm/rev >> Metric threads: 20 pitches from 0.25 to 4 mm >> Imperial threads: 25 pitches from 80 to 6 TPI Djdpfxowvq Tme Ad Nocg >> Tailstock: Morse taper 2 >> Infinitely variable speeds from 270–3000 rpm >> Weight: approx. 700 kg Accessories: >> 3-jaw chuck, 2 sets of jaws >> Tool post with 6 tool holders >> Quick-clamping device, draw tube and 34 collets >> Coolant system >> Cutting tools, drill chuck (see images) >> Operating manual with spare parts list About the machine: For sale is a Schaublin 102VM leadscrew lathe in very good condition. The machine is, of course, fully functional. All slides operate smoothly and evenly. The 102VM runs quietly even at high speeds. The gear set for thread cutting is present, but is probably not complete. Take the opportunity to view and test the machine under power on site and see its good condition for yourself.

Condition: good (used), Schaublin 102 N, machine number BL 329218, year of manufacture approx. 1998, center height 102 mm, center distance 375 mm, max. turning diameter over bed 200 mm, max. turning diameter over cross slide 120 mm, spindle speed up to 2,800 rpm, tailstock, accessories, Dcsdpfxjy Hip Io Ad Neg

Condition: good (used), Schaublin 102 N - VM, Machine number BL 330699, Year of manufacture approx. 1993, Machine with leadscrew, Centre height 102 mm, Leadscrew: diameter 40 mm, hardened and thread ground. Leadscrew pitch: 4 mm. Feeds: 8 longitudinal feeds from 0.02 to 0.3 mm/rev. Threading range: Metric: 20 pitches from 0.25 to 4 mm. Imperial (inch): 25 pitches from 80 to 6 tpi. Centre distance 450 mm, max. turning diameter over bed 200 mm, max. turning diameter over cross slide 120 mm, Spindle speed up to 2,800 rpm, Djdpfx Adey Hin Rs Necg Tailstock, Accessories,

Condition: used, centre height 102 mm Dedswbi Hpopfx Ad Njcg centre distance 450 mm spindle bore 25 mm spindle speed: 220 - 2600 Accessories were not checked for completeness Cabinets are not included in the scope of delivery

Condition: used, TECHNICAL DETAILS - center height : 102 [mm] Djdpfx Asw Ihttod Nscg - Max. diameter on bench : 200 [mm] - Distance between centers : 470 [mm] - Type of spindle clamp : W20 - Boring : 20 [mm] - Passage of bar in clamp : 14.5 [mm] WEIGHT & DIMENSIONS - Machine floor space : 1500 x 800 [mm] - Machine height : 1300 [mm] - Machine weight : 500 [kg]

Condition: good (used), Center height: 102mm Distance between centers: 450 mm Spindle bore: 32mm reduction gear left.- Right running 2-stage drive Vario Speed: 270-3000 U / min knee circuit Turning diameter over bed: 200 mm Spindle nose: W 20 Tailstock: MK 2 Dimension (LxWxH): approx 140x56x123 cm Weight: approx 550 kg Accessories available Dodscpznhspfx Ad Njcg Guide available Different "Schaublin 102" models in stock!

Condition: good (used), Center height: 130 mm Distance between centers: 450 mm Speed: about 55-3000 U / min Pneumatic clamping system Spindle nose: W 25 Div. W25 collets available Div. holder available BERGER LAHR axis motors Combitec EIP E-500 Control Manual control available Coolant system available Machine lamp available Machine feet Available Dcsdscuhvuopfx Ad Nog Dimension (LxWxH): approx 1400x560x1230 mm Weight: approx 550 kg Different "Schaublin 102" models in stock!

Condition: excellent (used), The used SCHAUBLIN 102N bench lathe is a small-sized Swiss precision manual lathe, 102mm center height, 400mm center distance, 20mm spindle hole. Djdpfx Aewqxcxjd Njcg 2 similar machines available (one with short bed and quick tooling and the other with long bed and gear head); already complete with electrical panel and safety devices; equipment and conditions as per photo.

Condition: used, total height: 1,700 mm, total width: 1,600 mm, total length: 1,800 mm, Colour: Grey Empty weight: 1.650 kg - Documentation available: Yes - CE certificate present: No - Drive system: Conventional Djdpfx Aoymfn Ejd Njcg - Horizontal/vertical: Horizontal - Power [kW]: 4.0 - Number of axes [pcs]: 3 - X-axis travel [mm]: 700 - Y-axis travel [mm]: 550 - Z-axis travel [mm]: 430 - Table length [mm]: 1100 - Table width [mm]: 255 - Tool holder: ISO40 - Min. spindle speed [rpm]: 38 - Max. spindle speed [rpm]: 1500 - Options: Digital readout - └ Type of digital readout: Sony - Transport dimensions: 1800mm x 1600mm x 1700mm (l x w x h) - Transport weight [kg]: 1650kg - Transport packages [pcs.]: 1 Financial information VAT: The price shown is exclusive of VAT VAT/margin: VAT deductible for entrepreneurs Delivery and trade-in always possible for everything in the industrial sectors Lukas van Rossum

Condition: good (used), functionality: fully functional, pneumatic collet clamping device with collets Dcedpfx Asy N N N Ted Neg

Condition: excellent (used), With DRO With step-down gear for spindle speeds Center height150 mm Distance between centers 630 mm Turning diameter over bed 340 mm Spindlespeeds 55-3000 rpm Dsdpfx Adsy Iz Ixo Njcg Spindle bore 40 mm Pitch of leading screw 4 mm Tail stock MK5 Misc.accessories MARCELS MASCHINEN CH

Condition: excellent (used), Year of construction: 1978, functionality: fully functional, machine/vehicle number: BL278700, spindle bore: 40 mm, spindle nose: Camlock D1-4, spindle speed (max.): 55 rpm, spindle speed (min.): 3,000 rpm, empty load weight: 1,250 kg, For sale is a Schaublin 150 in very good refurbished condition. Fully operational. The spindle was overhauled in 2021, with the spindle bearing set ordered directly from Schaublin. The guideways have been scraped and adjusted. The machine turns very accurately, with cylindrical deviation of only 1-2 thousandths over 200 mm. The machine can be inspected under power in 5023 Salzburg. Dcodpfx Asy Iu Nvjd Neg

Condition: excellent (used), Swing over bed 330 mm Distance between centers 650 mm Djdpfxey H Dkmj Ad Njcg Spindle speeds 30-5000 rpm Spindle taper ASA A2-5 Control: FANUC 18i-T Misc. accessories MARCELS MASCHINEN CH

Condition: excellent (used), For sale is a Schaublin 125 precision lathe in exceptionally good condition with extensive accessories. The machine was never used in production and shows barely any noticeable wear. Radial and axial runout at the spindle nose is less than 0.001mm. In terms of condition, this machine is almost as new. Naturally, the machine is fully functional and has been thoroughly checked. The brake and the feed control board were recently replaced. This is a rare opportunity to acquire one of the most precise conventional lathes in outstanding condition. TECHNICAL DATA: - Centre height: 125 mm - Centre distance: 500 mm - Maximum workpiece diameter over bed: 270 mm - Maximum workpiece diameter over cross slide: 120 mm Dodpfxoy Hnuce Ad Nocg - Infinitely variable spindle speeds: 225–3000 rpm - Spindle nose: Camlock D1-3 - Spindle bore: 32 mm - Collets: Schaublin B32 - Collet pass-through: 24 mm - Chuck pass-through: 28 mm - Bed travel: 440 mm - Carriage travel: 90 mm - Cross slide travel: 130 mm - Tailstock quill taper: Morse 2 - Tailstock quill travel: 100 mm - Automatic feeds, longitudinal & cross: 4–260 mm/min, stepless Weight approx. 950 kg Accessories: - Röhm 160 mm 3-jaw chuck - Reishauer 160 mm 4-jaw independent chuck - 160 mm 4-jaw self-centering chuck - 6x Multifix tool holders - Change gears for thread cutting - B32 collet set from 1 to 24 mm with draw tube - Machine mounts - Complete documentation including original brochure

Condition: ready for operation (used), functionality: fully functional, travel distance X-axis: 700 mm, travel distance Y-axis: 250 mm, travel distance Z-axis: 490 mm, table width: 305 mm, table length: 1,100 mm, overall weight: 2,000 kg, input voltage: 400 V, Schaublin 53 in good condition. ISO-40. 5.1 kW. Dedpfjy A Nbisx Ad Necg

Condition: excellent (used), Year of construction: 1997, Control Fanuc Series 20-T Dcjdpfxey Ehi Rs Ad Nog Turning diameter 330 mm Bar diameter 42 mm Turning length 650 mm Speed 5,000 min-1 8-position turret Minimum quantity lubrication

Condition: used, Mechanic's Lathe SCHAUBLIN Type 102 Mach. No. 1998 Centre distance: 350 mm Bed length overall from headstock: 635 mm Swing over bed: 200 mm Centre height over bed: 102 mm Swing over cross slide: 120 mm Centre height over cross slide: 61 mm Spindle bore: 18/20 mm Spindle speed, gear stage 1: approx. 120 / 190 / 320 rpm Spindle speed, gear stage 2: approx. 590 / 970 / 1500 rpm Chuck mounting: external thread M38 x 3 mm Tailstock taper: MT 1 Djdpjy Dvf Rsfx Ad Njcg Drive motor: 0.55 kW, 920 rpm Power supply: 380 Volt, 50 Hz - Spindle speeds adjustable via 2 gearbox stages and 3-step drive belt shifting - Main spindle with forward and reverse operation - Spindle mount with M38 x 3 mm thread - 3-jaw scroll chuck Ø 128 mm with stepped jaws - Collet clamping system with 6 round collets Ø 3 / 4 / 5 / 6 / 8 / 20 mm - Integrated dividing plate on main spindle with 48 / 60 / 100 holes - Toolholder slot approx. 10 x 18 mm with clamping screw - Sturdy wooden base with 42 mm laminated board Required space (with stand): L x W x H: 1160 x 750 x 1300 mm Weight with stand: 150 kg Good condition

Condition: as good as new (ex-display), Schaublin lunette steady rest glasses 102VM Dedpfx Ajkw Drzjd Njcg

Condition: excellent (used), Very good condition Digital, Multifix, collets W32 Dodpfx Adey Al Uxs Nscg

Condition: ready for operation (used), functionality: fully functional, machine/vehicle number: 160378, spindle bore: 40 mm, center height: 160 mm, center width: 750 mm, spindle speed (max.): 3,000 rpm, workpiece diameter (max.): 375 mm, No reserve price – guaranteed sale to the highest bidder! By placing a bid, you are obligated to collect the item within the specified timeframes: either between 11/05/2026 and 13/05/2026 or between 18/05/2026 and 21/05/2026. TECHNICAL DETAILS Centre height: 160 mm Centre distance: 750 mm Maximum workpiece diameter over bed: 375 mm Maximum workpiece diameter over cross slide: 180 mm Spindle speeds: 38 to 3,000 rpm Spindle taper: Morse 5 Spindle bore: 40 mm Collet capacity: 24 mm Fine feeds longitudinal and cross: 0.015 to 0.21 mm/rev Longitudinal and cross feeds: 0.025 to 0.35 mm/rev Cross slide travel on bed: 750 mm Compound slide travel: 120 mm Cross slide travel: 215 mm Centre height above tool slide: 32 mm Tool section: 20 x 20 mm Tailstock quill taper: Morse 3 Quill travel: 120 mm Lateral adjustment: +/- 10 mm MACHINE DETAILS Operating voltage: 380 V Dcedpfx Adeym Nkko Njg Dimensions & Weight Dimensions (L x W x H): 2,500 x 1,000 x 1,500 mm Weight: 2,500 kg EQUIPMENT Including documentation Matching tool cabinet with accessories included External reference: Showroom
