Used Slotting Machine - Vertical for sale (66,803)

Condition: used, Vertical Slotting Machine GSP M 743 3-jaws chuck Ø 360 mm Klodpfx Aozmx N Ijh Aow Table travel: X = 500 mm / Y = 450 mm Slide travel: 300 mm Throat depth: 500 mm Rotary table: Ø 690 mm Slide tilting: + 8° Rotative table/slide maxi height: 450 mm Motor power: 8 CV Rapid feeds on X - Y - W axes Strokes/min.: from 3 to 300 strokes/min. Equipped with one tool removal system upon lifting Voltage: 380 V Length: 2000 mm Depth: 2500 mm Total height: 2200 mm Weight: approx 4 T

Condition: used, Vertical Slotting Machine GSP M 743 3-jaws chuck Ø 360 mm Table travel: X = 500 mm / Y = 450 mm Slide travel: 300 mm Throat depth: 500 mm Rotary table: Ø 690 mm Slide tilting: + 8° Rotative table/slide maxi height: 450 mm Motor power: 8 CV Kledpfx Ahszlhfpe Aow Strokes/min.: from 3 to 300 strokes/min. Equipped with one tool removal system upon lifting Voltage: 380 V Length: 2000 mm Depth: 2500 mm Total height: 2200 mm Weight: approx 4 T

Condition: used, Year of construction: 1954, Technical details: max. ram stroke: 220 mm workpiece diameter - max.: 400-450 mm Ksdpfx Aev Ty R Doh Aelw total power requirement: 1,5 kW work table:: 650x250 mm ram adjustment: 100 Manuell mm no. of ram strokes: 45/78/125 table adjustment: 400 längs mm table adjustment: 150-170 quer mm table adjustment: ca. 360 vertikal mm tool - head swivelling: +/- 10 Grad total power requirement: 1,5 kW weight of the machine ca.: 0,9 t dimension machine xH: 1,2 x 0,9 x 1,8 m

Condition: new, Year of construction: 2026, Brand new precision vertical slotting machine – a machine of exceptionally high quality. CNC-controlled vertical slotting machine with two, three (or four) CNC axes and electronic rotary table control with a positioning accuracy of 0.001°. Ideal for the efficient production of keyways (including tapered and tangential slots), spline hubs, internal and external gears, racks, etc. CNC control with 10" color display and touchscreen – software for roughing, finishing, and fine finishing (enabling surfaces of the highest possible quality). Stroke range of slotting ram: 10 to 250 mm Slotting ram speeds: 22 to 90 strokes/min, infinitely adjustable Slotting ram swivel range: +/- 20° Rotary table diameter: 450 mm Rotary table bore Ø: 135 mm Maximum table load: 1,250 kg Table travel (X/Y): 250 x 225 mm Ram drive servomotor power: 3 kW Machine dimensions without control console: 1.3 x 1.45 m x approx. height 2.6 m Machine weight approx. 1,700 kg - Automatic electronically monitored central lubrication system for the guideways - Cutting oil system for coolant supply to the slotting tools Ksdozhkkyjpfx Ah Aslw Other models available.

Year of construction: 2011, condition: excellent (used), functionality: fully functional, Tool travel : 0-315 mm Strokes per minute : 14 - 60 Ram adjustment : 235 mm Swivel angle of head : ±45° Head to table distance : 510 mm Tool to column distance : 460 mm Diameter of rotating table : 450 mm Diameter of central hole of rotating table : 80 mm Number of fixed positions of rotating table : 24 Longitudinal travel of worktable : 265 mm Kjdpfjvfctfex Ah Aelw Transverse travel of worktable : 200 mm Self-breaking main motor : 4 kW / 5.5 h Weight : 1310 kg Overall dimensions : 1000 x 1500 x 2250 mm

Condition: good (used), max. ram stroke 230 mm throat 230 mm table diameter 0 mm are offered : 2 pieces of shaping spindle for Lorenz gear shaping machines type LS 630 to LS 1250 Klsdpow Ny S Refx Ah Ajw 1x overhauled new 1x has to be overhauled. Year of manufacture: unknown

Condition: good (used), Year of construction: 2000, max. ram stroke 2 - 300 mm groove width 2 - 32 mm power capacity 8 kW no. of strokes 2 - 300 Hub/min throat ca. 300 mm Max. installation height ca. 450 mm automatic feeds 0,01 - 0,15 mm work speed 0 - 30 m/min Kodpfx Ajuayibeh Aslw return speed 30 m/min weight of the machine ca. 2,2 t dimensions of the machine ca. 2,5 x 1,5 x 2,2 m The BALZAT keyway jointing machine is characterised by the following advantages: - Infinitely variable adjustment of the jointing speed with constant return, even during the work process - Simple clamping of the workpieces with standard clamping devices, without additional tool holders - Extreme dimensional accuracy thanks to self-centring, centrally arranged blade holders - Feed rate can be changed during the programme sequence - Machine base is also a container for cutting oil - all components are easily accessible and replaceable

Condition: used, Keyway milling head for milling machine, milling head, CCCP / USSR STANKO Type 1502 No.: 200 Year of manufacture: 1974 Stroke size: max. 60 mm Stroke rate: approx. 200 - 500 strokes/min. Tool holder: 12 x 17 mm with clamping plate Hole spacing machine flange plate: 245 x 185 mm Mounting hole: Ø 17 mm Centering diameter on the machine flange plate: 190 mm - Stroke size adjustable via eccentric adjustment - The drive is the same as for the standard vertical head, driven by the machine gearbox - Drive via a drive pin, centered within the centering diameter Kledpsd Dk A Aofx Ah Asw - Graduated scale on the flange plate, +/- 45° infinitely adjustable - This keyway milling head is flanged in place of the standard vertical milling head (Mounting in place of the vertical milling head) Weight: 42 kg Good condition Keyway milling head, bearing number 58166, and vertical milling head, bearing number 58164, from an identical STANKO milling machine.

Condition: excellent (used), Year of construction: 2019, XYZ UMC-5X 5 Axis CNC Vertical Machining Centre Heidenhain iTNC 640 HSCI Control Model UMC-5X Control Heidenhain iTNC 640 HSCI X Axis Travel 600 mm Y Axis Travel 600 mm Z Axis Travel 500 mm A Axis Travel +120° / -120° C Axis Travel 360° Table Size 600 mm Diameter Maximum Table Load 600 kg Spindle Speed 24,000 rpm Direct Drive Spindle Taper BBT40 Rapid Traverse 36 m/min Kodpfx Aszi Awheh Aelw Feed Rate 1 - 36,000 mm/min Tool Changer 60 Station Automatic Maximum Tool Length 300 mm Through Spindle Coolant 70 Bar Machine Weight 9,500 kg Machine Fitted With: Heidenhain iTNC 640 HSCI CNC Control, 24,000 rpm Direct Drive High Speed Spindle (20kW S6 Rated), 60 Station Automatic Tool Changer, 70 Bar Through Spindle Coolant, Fixed Roof for High Pressure Coolant System, Renishaw RMP600 Strain Gauge Wireless Workpiece Probe, Laser Tool Setting System, Kinematic High Accuracy Machine Setup, Kinematic Reference Ball, Thermal Spindle Compensation, Linear Scales on X, Y & Z Axes, Direct Drive C Axis Rotary Table, Swarf Conveyor & Bin. Features: Simultaneous 5 Axis Machining Centre, Gantry Frame Construction, Direct Drive High Torque Rotary Table, High Precision Linear Roller Guideways, Dynamic Collision Monitoring, High Accuracy Machine with Linear Scales, Ideal for Aerospace, Medical, Precision Engineering & Complex Multi-Sided Components. For sale with Jet Machinery Ltd Jet Machinery Stock No: TBC Machine Serial Number: TBC Cost: £120,000.00 Whilst every effort has been made to ensure that the above information is accurate it is not guaranteed. We advise prospective purchasers to inspect the machine prior to purchase. Whilst every effort has been made to ensure that the above information is accurate it is not guaranteed. We advise prospective purchasers to check any vital details. Health and Safety At Work Act 1974: It is not reasonably practical for ourselves as suppliers to ensure that for your application the goods comply with requirements of the Act with respect to guarding etc. Prospective purchasers should ensure that a guarding specialist inspect the goods prior to use.

Condition: new, functionality: fully functional, Year of construction: 2025, The VSI (Vertical Shaft Impactor) sand making machine is a type of crusher designed to accelerate the crushing of aggregate and produce cubical-shaped sand. It is widely used in the field of construction, mining, and other similar industries. Here are key features and information about VSI sand making machines: 1. Working Principle: - The VSI sand making machine operates on the principle of stone impacting stone or stone impacting iron. Material is fed into the center of the rotor, which accelerates to high speed to throw the material outward against a wear-resistant lining. 2. Rotor and Crushing Chamber: - The rotor is a crucial part of the VSI machine and is often designed with multiple pockets to facilitate material throwing and crushing. - The crushing chamber is lined with wear-resistant materials to endure the impact and abrasion during the crushing process. 3. Feedstock Control: - The feedstock (material to be crushed) can be controlled using a variable speed control system, allowing for adjustments to achieve the desired particle size. 4. Material Types: - VSI machines are suitable for processing various materials, including hard and abrasive materials such as rocks, ores, and minerals. Kljdpfoq Nd U Hox Ah Asw 5. Cubical Shaping: - One of the significant advantages of VSI machines is their ability to produce cubical-shaped end products, which is desirable for high-quality concrete and asphalt production. 6. Adjustable Discharge: - The machine usually has an adjustable discharge opening, allowing for customization of the final product size. 7. Sand Production: - VSI sand making machines are primarily used to produce manufactured sand (M-sand) and crushed sand, which are essential components in the construction industry. 8. Maintenance: - Regular maintenance is required to ensure optimal performance and extend the machine's lifespan. This includes checking wear parts, lubrication, and addressing any issues promptly. 9. Variations: - Different manufacturers may offer variations of VSI machines with unique features or specifications. Common variations include open rotor and closed rotor designs. 10. Environmental Considerations: - VSI sand making machines are generally considered environmentally friendly as they produce less dust and noise compared to traditional crushers. 11. Manufacturers: - Well-known manufacturers produce VSI sand making machines, and it's crucial to choose a reputable supplier with a track record of providing reliable equipment. When considering a VSI sand making machine, factors such as feed size, capacity, and the desired end product specifications should be taken into account. Additionally, check the reputation of the manufacturer, and consider customer reviews and feedback regarding the specific model you are interested in.

Condition: used, Year of construction: 2011, operating hours: 5,000 h, machine/vehicle number: M344Z16201031AHC, travel distance X-axis: 2,032 mm, travel distance Y-axis: 660 mm, travel distance Z-axis: 610 mm, table load: 2,700 kg, spindle speed (max.): 12,000 rpm, The following repairs were carried out: Defective inverter identified and replaced Bearings in the Y-axis replaced; bearing set VTXZ Y-axis (5 pieces, 35x72) Rotary table adjusted Orientation adjusted TECHNICAL DETAILS Travel range X-axis: 2,032 mm Travel range Y-axis: 660 mm Travel range Z-axis: 610 mm Spindle speed: 12,000 rpm Spindle cooling: Internal cooling Rapid traverse rate X/Y/Z: 35 m/min Power: 18 kW Tool holder: SK 40 Tool positions: 40 Tool diameter with full occupancy: 75 mm Maximum tool weight: 10 kg Maximum tool length: 300 mm Table load: 2,700 kg Table clamping area: 2,285 x 660 mm T-slots in the table according to DIN 650: 5 Slot width: 18 mm H8 Slot spacing: 125 mm Klsdpfezka Hiox Ah Asw Positional accuracy X, Y, Z: 0.02 mm Repeatability X, Y, Z: 0.01 mm MACHINE DETAILS Footprint W x D x H, doors open / with control / chip conveyor: 6,950 x 5,150 x 3,700 mm Transport weight: 20,000 kg Machine weight: 18,000 kg Operating hours Machine hours: 11,417 hours Spindle hours: approx. 5,000 hours Further technical data can be found in the attached documents.

Condition: used, Year of construction: 2004, operating hours: 28,082 h, travel distance X-axis: 800 mm, travel distance Y-axis: 620 mm, travel distance Z-axis: 520 mm, controller model: Siemens 840 D, spindle speed (max.): 13,000 rpm, The control system (PCU 50) was replaced in March 2024! The machine spindle was replaced after approximately 5,500 operating hours! TECHNICAL DETAILS Travel range X-axis: 800 mm Travel range Y-axis: 620 mm Travel range Z-axis: 520 mm Spindle speed: 13,000 rpm Ksdpfx Ahjzka Akj Aelw Number of tool slots in the tool magazine: 30 MACHINE DETAILS Control system: Siemens 840 D Operating hours Control system operating hours: 60,150 h Machine operating hours: 56,860 h Spindle operating hours: 28,082 h Spindle replacement at: 5,500 h EQUIPMENT Tools 4th axis Hofmann RW/NC160 Oil mist extraction system Strip filter system with internal cooling, 20 bar, with dual switching filter Documentation: Hedelius + Siemens Sinumerik Infrared probe: Renishaw

Condition: ready for operation (used), Year of construction: 2023, functionality: fully functional, machine/vehicle number: PR721523001, travel distance X-axis: 1,300 mm, travel distance Y-axis: 650 mm, travel distance Z-axis: 600 mm, controller model: Heidenhain TNC-460, spindle speed (max.): 15,000 rpm, The new price of the machine was approximately €140,000 in 2023! No tools or a vise are included. However, these can be purchased separately upon request. TECHNICAL DETAILS Travel range X-axis: 1,300 mm Travel range Y-axis: 650 mm Travel range Z-axis: 600 mm Spindle speed: 15,000 rpm Main spindle servo motor Siemens: 20/53 kW Main spindle servo motor Fanuc: 15/30 kW Spindle taper: SK 40 Work table Table dimensions: 1,500 × 650 mm Table load: max. 1,200 kg T-slots: 18 × 5 × 100 mm Distance spindle to table surface: 150–750 mm Distance spindle center to Z-axis cover: 697 mm Rapid traverse X/Y axis: 36 m/min Rapid traverse Z axis: 36 m/min Working feed rate: max. 1–12,000 mm/min Feed motors X/Y/Z: 3.2/3.2/4.3 kW Torques of the feed motors X/Y/Z: 20/20/27 Nm Tool positions: 28 Tool length: max. 300 mm Tool diameter: max. 75 mm Tool diameter with free auxiliary positions: max. 125 mm Klodpfx Aszlh S Aeh Asw Tool weight: max. 8 kg Tool change time: 1.6 s MACHINE DETAILS Control system: Heidenhain TNC-460 Accuracy without linear glass scales Positioning accuracy over the entire travel range: 0.012 mm Repeatability accuracy over the entire travel range: 0.008 mm Accuracy with linear glass scales Positioning accuracy over the entire travel range: 0.008 mm Repeatability accuracy over the entire travel range: 0.006 mm Cooling and power supply Coolant tank volume: 250 l Coolant flow rate: 40 l/min Mains voltage: 400 V ± 10 % Number of phases: 3 Mains frequency: 50 Hz Connected power: 85 kVA Dimensions and weight Dimensions (L × W × H): 4,025 × 3,090 × 3,185 mm Weight: 8,000 kg EQUIPMENT Direct drive Double-arm tool changer O-BLUM tool measuring system Lasercontrol NT O-BLUM workpiece measuring system TC50 Electronic handwheel (MPG) Thread drilling without compensation chuck USB interface CF card interface Ethernet interface HIWIN linear guides with roller guides in all axes HIWIN ball screws Directly driven main spindle NSK/FAG main spindle bearings Separate oil-air spindle cooling unit Fully enclosed tool changer for protection against chips Pneumatic intermediate tank for the tool changer as a backup in case of pressure drop Fully enclosed splash guard Separate air conditioning system for heat dissipation from the control cabinet Siemens electrical components Automatic, path- or time-controlled central lubrication system Kyarow telescopic covers in all axes Coolant system with adjustable nozzles as a coolant ring around the spindle Chip flushing system in the interior for optimal chip collection Spiral chip conveyor working in the Y-direction for removing chips from the machining area Rear chain chip conveyor

Condition: used, Year of construction: 2005, machine/vehicle number: 107.32.99.158, travel distance X-axis: 530 mm, travel distance Y-axis: 450 mm, travel distance Z-axis: 450 mm, controller model: Heidenhain iTNC 530, spindle speed (max.): 12,000 rpm, Re-auction due to buyer’s payment default! The machine spindle was replaced in July 2025! TECHNICAL DETAILS Travel range X-axis: 530 mm Travel range Y-axis: 450 mm Travel range Z-axis: 450 mm Klodpfxsziz Nce Ah Ajw Rotary table Table diameter: 400 mm Table load capacity: 200 kg Swivel range: degrees Swivel speed: 20 rpm Rotational speed: 30 rpm Tool holder: SK40 Maximum speed: 12,000 rpm Recommended maximum working feed rate: 15 m/min Rapid traverse speed: 22 m/min Feed force X and Y/Z: 5,000 N Magazine capacity: 30 Maximum tool diameter: 90 mm Maximum tool length: 250 mm (manual 350 mm) Maximum tool weight: 6 kg MACHINE DETAILS Control system: Heidenhain iTNC 530 with digital control Positional tolerance according to DIN/ISO 230-2/97: 0.008 mm Machine weight: 6,500 kg EQUIPMENT RENISHAW MP 12 measuring probe Blum tool monitoring system

Condition: ready for operation (used), Year of construction: 2002, functionality: fully functional, machine/vehicle number: 008078, travel distance X-axis: 850 mm, travel distance Y-axis: 550 mm, travel distance Z-axis: 630 mm, controller model: Fanuc O-M, rotational speed (max.): 8,000 rpm, TECHNICAL DETAILS Travel range, X-axis: 850 mm Travel range, Y-axis: 550 mm Travel range, Z-axis: 630 mm Spindle mount: ISO40 Speed: 8,000 rpm Table surface area: 1,000 x 540 mm MACHINE DETAILS Control system: Fanuc O-M Kodszi D Rpepfx Ah Ajlw Tool changer magazine positions: 24 Weight: 5,500 kg EQUIPMENT Electric handwheel Chip tray

Condition: ready for operation (used), Year of construction: 1997, functionality: fully functional, travel distance X-axis: 1,000 mm, travel distance Y-axis: 750 mm, travel distance Z-axis: 750 mm, controller model: Heidenhain TNC426, rotational speed (max.): 12,000 rpm, No minimum price – guaranteed sale to the highest bidder! TECHNICAL DETAILS Travel range, X-axis: 1,000 mm Travel range, Y-axis: 750 mm Travel range, Z-axis: 750 mm Table size: 1,150 x 700 mm Tool shank: SK40 Spindle speed range: 12,000 rpm Kedpfszi D Rcex Ah Aslw MACHINE DETAILS Control system: Heidenhain TNC426 Machine weight approx.: 10,500 kg EQUIPMENT 30-position tool changer Electronic handwheel Chip conveyor Coolant system

Condition: ready for operation (used), Year of construction: 1997, functionality: fully functional, machine/vehicle number: 179, travel distance X-axis: 510 mm, travel distance Y-axis: 510 mm, travel distance Z-axis: 510 mm, controller model: MSC 803, rotational speed (max.): 8,000 rpm, No minimum price – guaranteed sale to the highest bidder! TECHNICAL DETAILS Travel range, X-axis: 510 mm Travel range, Y-axis: 510 mm Travel range, Z-axis: 510 mm Kljdpfx Aozi D E Tsh Ajw Table size: 750 x 550 mm Spindle speed range: 8,000 rpm Spindle mounting: BT40 MACHINE DETAILS Control system: MSC 803 Weight: 4,500 kg EQUIPMENT 25-position tool changer Coolant system

Condition: ready for operation (used), Year of construction: 2015, functionality: fully functional, travel distance X-axis: 600 mm, travel distance Y-axis: 400 mm, travel distance Z-axis: 500 mm, controller model: Mitsubishi M70, spindle speed (max.): 12,000 rpm, TECHNICAL DETAILS Travel range, X-axis: 600 mm Travel range, Y-axis: 400 mm Travel range, Z-axis: 500 mm Klodpfxezi D Emj Ah Aew Spindle mounting: SK40 Spindle speed: 12,000 rpm Spindle drive power: 7.5 kW Table clamping area: 2x 700x400 mm MACHINE DETAILS Control system: Mitsubishi M70 Tool changer magazine slots: 24 Weight: 6,600 kg EQUIPMENT Pallet changer 4th axis (rotary table) 24-tool automatic tool changer IKZ (integrated coolant supply) Chip conveyor

Condition: ready for operation (used), Year of construction: 2004, operating hours: 77,374 h, functionality: fully functional, machine/vehicle number: 419-01, travel distance X-axis: 6,000 mm, travel distance Y-axis: 630 mm, controller model: Siemens 840D, spindle speed (max.): 12,000 rpm, The machine spindle was replaced in 2021 (spindle operating hours approx. 7,300 h)! The machine underwent a major overhaul in 2013! The machine has been continuously serviced and repaired annually by the manufacturer and kept up to date with the latest technology (preventive maintenance). The last service was performed in January 2024. TECHNICAL DETAILS 4 axes Travel range X-axis: 6,000 mm Travel range Y-axis: 630 mm Travel range Z-axis: 550 mm Swivel range B-axis: ± 100° Spindle speed: 12,000 rpm Spindle torque: 140 Nm Rapid traverse rate in X/Y/Z: 60 m/min Chip-to-chip time vertical: 3.0 sec. (3.3 sec. DIN) Chip-to-chip time horizontal: 4.7 sec. (5.0 sec. DIN) MACHINE DETAILS Control system: Siemens 840D Power type: 3/N/PE Mains frequency: 50/60 Hz Operating voltage: 400 V Control voltage: 220/24 V Connected load: 52 kVA Rated current: 75 A Fuse rating: 80 A Weight: 19,500 kg Operating hours: 77,374 h EQUIPMENT Ksdpfxszlnm He Ah Ajlw 5-axis milling package (simultaneous milling on up to 5 axes) Chip conveyor, discharge height: 1,050 mm Coolant through spindle (CTS) preparation Vacuum rotating filter KNOLL VRF250 (steel, cast iron, aluminum, plastic, brass) High pressure 70 bar with HD pump and servo valve Coolant nozzle per swivel field Emulsion mist extraction, 2 extraction fans at 800 m³/h each Rotating viewing window on the left and right (1,400 mm from the center of the machine) Automatic loading doors Center partition for pendulum machining 92 tool positions HSK-A63 (rear magazine) Blow-off air Tool life monitoring Additional V24 RS232 in the control cabinet BDE/MDE interface (states: machine on, machine running, piece counter) Marposs (Brankamp) collision monitoring CMS100 3D machine model for kinematic simulation in the CAM programming system Hydraulic unit 210 bar, 2 clamping circuits, separate system clamping pressure per swivel field, clamping pressure control Linear clamping system KOHN 8 hydraulic clamping cylinders KOHN Multi 2000 MFS 125/680 HD Two-part grating floor for the operator across the entire operating width of 6,000 mm

Condition: used, machine/vehicle number: 006488, X axis working area: 2500 mm Y axis working area: 850 mm Main Electrospindle power: 5 KW Kodpfxswuclxj Ah Aolw Number of controlled axes: 3 axes Total number of drilling spindles: 11

Year of construction: 2012, condition: ready for operation (used), functionality: fully functional, machine/vehicle number: BCOR12150, BIESSE BREMA EKO 902 CNC and vertical dowel insertion machine for reduced cycle times Equipment Features Kjdpfx Ahjw Nytnj Aolw - Clamping grippers measure the thickness to adjust drilling depth - Laser-based measuring system for detecting the front and rear panel edges - Length tolerance compensation correcting the workpiece length in X - 5-position tool changer - Drilling head with individually retractable spindles and grooving saw - Diameter: 120 mm - Gluing and dowel insertion units mounted on Y and Z axes Options - 4.5 kW electrospindle; 18,000 rpm - Special drilling unit for hinges Technical Data - Panel length: 160 - 3200 mm - Panel width: 35 - 900 mm - Panel thickness: 8 - 80 mm - X/Y/Z axis speed: 100 / 60 / 30 m/min - X axis travel: 3200 mm - Y axis travel: 900 mm - Main spindle power: 4.5 kW - Number of controlled axes: 3 axes - Number of drilling spindles: 20 - Number of tool positions: 5

Condition: excellent (used), Year of construction: 2018, Hartford LG-500 Vertical Machining Centre Year: 2018 (only 400 working hours) Model: LG-500 Ksdowif R Tepfx Ah Ajlw Control: Hartford Plus 3 Table Size: 620 x 420mm Table Load: 300 kgs Axis Travels X/Y/Z: 620 / 420 / 450mm Spindle Nose to table: 100 – 550mm Spindle Taper: 40 INT Spindle Speeds: 12,000 RPM 12 station ATC Machine as new

Condition: used, Year of construction: 1997, functionality: unexamined, Bridgeport VMC 600 vertical machining centre Year (1997) with GE Fanuc Series O-M control, 22 ATC, Cromar swarf conveyor Kjdpfx Ahjzmaf Rj Ajlw

Condition: used, Year of construction: 2007, Technical Specifications – STAMA MC 334 Manufacturer: STAMA Maschinenfabrik Model: MC 334 Year of Manufacture: 2007 Machine No.: KMM 334 2052 Electrical Data Connection Voltage: 400 V / 3 Phase / 50 Hz Nominal Current: 65 A Recommended Fuse: 3 × 80 A Minimum Connection Cable Cross Section: 35 mm² Total Connected Load: 125 kVA Total Power Requirement: 110 kW Spindle Tool Interface: HSK 63 Spindle Bearing Diameter: 65 mm Spindle Arrangement: a = 400 mm Maximum Torque: 200 Nm (20% duty cycle) Spindle Speed: 20 – 15,000 rpm Travels X-Axis: approx. 900 mm Y-Axis: approx. 900 mm Z-Axis: approx. 1,125 mm Feed Rates Feed Rate (X/Y/Z): 1 – 10,000 mm/min Rapid Traverse: Kljdpeznc I Defx Ah Aew X-Axis: 60 m/min Y-Axis: 60 m/min Z-Axis: 60 m/min Maximum Feed Force X-Axis: 7,000 N Y-Axis: 7,000 N Z-Axis: 8,000 N Tool Magazine Magazine Capacity: 90 tools Tool Clamping Force: 8,000 N Maximum Tool Diameter: 160 mm Maximum Tool Length: 350 mm Tool Data Tool Dimensions: Standard Tool Weight: 1.8 kg Maximum Tool Weight: 12 kg (with every other pocket free) Maximum Tool Diameter: 300 mm Machining Capacity Maximum Milling Capacity: 600 cm³ Maximum Drilling Diameter: Ø40 mm Maximum Thread Size: M30 Machine Dimensions Length: 2,500 mm Width: 2,060 mm Height: 3,300 mm

Condition: ready for operation (used), Year of construction: 2004, machine/vehicle number: B-7270, travel distance X-axis: 1,000 mm, travel distance Y-axis: 500 mm, travel distance Z-axis: 610 mm, TECHNICAL DATA Manufacturer: KONDIA Model: B-1050 Year: 2004 Control unit: Heidenhain iTNC530 Serial number: B-7270 TABLE DIMENSIONS Work area: 1200 x 500 mm. T-slots (Nº x Width x Distance): 5 x 18 x 100 mm. Table to floor height: 885 mm. TRAVEL X: 1,000 mm. Y: 500 mm. Z: 610 mm. SPINDLE Spindle taper: BT40 Speed range: 12,000 rpm Klsdpfxozlycye Ah Aow Distance spindle to table surface: 140-750 mm. FEEDS Cutting feed rate: 0-30,000 mm/min Rapid traverse rate: 30,000 mm/min ACCURACY Position accuracy (scales): 0.01 Repeatability: 0.006 Resolution: 0.001 MOTOR Spindle motor: 7.5 Kw. AUTOMATIC TOOL CHANGER Nr. of tools: 18 Max. Ø (adjacent tools): 85 mm. Max. Ø (non-adjacent tools): 135 mm. Max tool length: 250 mm. Max. tool weight (1 tool): 6 Kg. Tool taper: ISO 7.388 / BT40 Pull stud bolt: ISO 7388-1 / 2-AJIS B 6.339 WEIGHT Aprox. Weight: 5,500 Kg.
