Used Tschudin Grinding Machine for sale (65,743)

Condition: ready for operation (used), functionality: fully functional, DESCRIPTION OF MACHINE INCLUDED A LOT BELTS A Löser abrasive belt grinding machine offers the most flexible grinding / linishing on the market today. The combination of basic machine plus a variety of contact arms and attachments offers dozens of possible applications for many different purposes. There are over 20 standard attachments available for this machine allowing it to be used for centerless grinding, internal polishing, grinding of hollow bodies and small radius and turbine blade finishing to name but a few. Fields of application of these abrasive belt grinding machines include: *Foundries *Medical engineering *Aircraft industry *Vehicle construction *Mechanical engineering *Specifications Abrasive belt grinding machine, type KS 350 *Grinding belt length 3000-4000 mm *Grinding belt width 5 - 75 mm Loser KS 350 Belt design features:: *Drive motor 4 kW (standard design) with fitted variable speed inverter drive *Drive wheels of 100 - 280 mm diameters = 3 - 46 mtr./sec. belt speed *Mechanical belt tensioning *In case of a belt break the drive is immediately disconnected. Therefore, the risk of an accident is eliminated. *Contact disks of 50 - 400 mm diameters, with a wide choice of grinding attachments for any kind of surface finishing * DC injection breaking unit fitted. Lrsdpfx Aajwxrnwe Rsr *Maintenance-free, dust-proof contact disk bearing with permanent lubrication, contact disk change in less than 1 minute. *LÖSER abrasive belt grinding machines open up new fields of application for belt linishers that in the past could not be processed with normal belt grinders. *When using 3 to 4 m long grinding belts, the 3-contact wheel system ensures the constant and optimal belt speed no matter which contact disk diameter is being used. *Driven by the motor pully, the three pully system allows the belt which is constantly tensioned a higher degree of torque at the same motor rating. *When working with Scoth-Brite disks or belts or with felt polishing belts, the drive can be infinitely adjusted even for speeds as low as 3 mtr. /sec. Due to the advantages offered by the 3-contact point system, any required surface finishing is possible using contact disks from 50 to 400 mm, contact rolls or contact rollers from 15 to 50 mm, contact belts of 6 or 30 mm width, polishing brushes, polishing disks and polishing belts.

Year of construction: 1976, condition: ready for operation (used), functionality: fully functional, center height: 125 mm, center width: 600 mm, year of last overhaul: 2026, The machine underwent a comprehensive retrofit in 2026! New centering point with carbide insert on the workpiece spindle stock Tailstock with MK-3 mount and air lift Adjuster on the tailstock New centering point with carbide insert on the tailstock 2 grinding wheel flanges 1 new grinding wheel 1 internal grinding spindle Completely renewed paper band filter with new filter fleece and circuit Completely overhauled, steplessly adjustable grinding spindle motor Automatic grinding cycle with dwell time and shut-off Machine geometrically completely overhauled Guides ground and scraped Hydraulic cylinder overhauled New piston rod and seals Machine body and assemblies blasted, primed and completely painted TECHNICAL DETAILS Center height: 125 mm Center distance: 600 mm Grinding wheel flange dimensions: 400 × 50 × 127 mm Speed of internal grinding spindle: 14,000 rpm EQUIPMENT Workpiece spindle stock standard with MK-5 mount, swiveling Lsdpfxezr Ep Ej Aa Rorr Stepless speed control via potentiometer

Condition: ready for operation (used), functionality: fully functional, grinding wheel diameter: 355 mm, spindle speed (max.): 1,500 rpm, travel distance X-axis: 750 mm, travel distance Z-axis: 340 mm, controller manufacturer: Fanuc, TECHNICAL DETAILS Travel range, X-axis: 750 mm Travel range, Z-axis: 340 mm Table width: 600 mm Table depth: 300 mm Magnet width: 600 mm Magnet depth: 300 mm Lrjdpezuw Dmefx Aa Rer Max. grinding wheel diameter: 355 mm Max. spindle speed: 1,500 rpm MACHINE DETAILS Drive system: CNC Control system: Fanuc DIMENSIONS & WEIGHT Dimensions (L x W x H): 3,500 x 2,300 x 2,400 mm Net weight: 2,500 kg Shipping packages: 3 units EQUIPMENT CE marking

Condition: ready for operation (used), Year of construction: 2002, overall weight: 7,000 kg, center height: 160 mm, distance between centers: 2,000 mm, controller model: Siematic Rack PC 840, positioning accuracy: 0.001 mm, Automatic reamer tool grinding machine / reaming cutter grinding machine! For grinding the chip chamber and chip face on round reaming tools. TECHNICAL DETAILS Tooth length: 1,700 mm Center distance: 2,000 mm Center height: 160 mm Resolution X-axis: 0.001 mm Resolution Y-axis: 0.001 mm Resolution Z-axis: 0.001 mm Resolution W-axis: 0.001 mm MACHINE DETAILS Axis control: 4 axes Control system: Siemens Rack PC 840 Ljdpfx Aaozt Si Uo Rsrr Processor: Pentium 3 Program memory: 20 GB Operating system: Windows 2000 Weight: 7,000 kg EQUIPMENT Simultaneous machining via 2 handwheels

Condition: not inspected (used), machine/vehicle number: 23095, type of input current: three-phase, overall weight: 4,500 kg, input frequency: 50 Hz, input voltage: 380 V, input current: 17 A, No minimum price – guaranteed sale to the highest bidder! TECHNICAL DETAILS Power supply: 3~ Frequency: 50 Hz Operating voltage: 380 V Control voltage: 220 V Rated current: 17 A Fuses Lsdpfx Aszt Sfpja Rerr Rated current main fuse, fast-blow: 35 A Rated current main fuse, slow-blow: 25 A Dimensions & Weight Dimensions (L x W x H): 3,800 x 2,100 x 2,000 mm Machine weight: approx. 4,500 kg

Condition: excellent (used), Year of construction: 2003, 2003 Mitsubishi CNC Shaving Gear cutter grinder Model ZA30CNC, Year 2003, With Fanuc Series 16i-M HMI, Includes Lrodpfx Aeywftkja Rjr FN-0013 Dust Collector, Power 200/220 Volts / 3 Phase , Weight 15000 Lbs.

Condition: good (used), Jones and Shipman Suprema 650 M Easy Universal OD/ID Cylindrical Grinder s/n SO19131, w/ J&S PLC Control, 12" Swing x 25" Centers, Swivel Wheelhead w/ OD & ID Capability, Internal Spindle, Hydromation Coolant System, Heidenhain DRO, Workholding NOT Included Lsdpfxeywfyqj Aa Rorr

Condition: used, Year of construction: 2001, 2001 Kellenberger CNC Grinder KEL-VARIA RS175/1000 Ljdpfx Aaeywftdj Rsrr

Condition: used, Year of construction: 2005, machine/vehicle number: 25748, Equipped with: Central Lubrication Machine Flushing Coolant Filtering Equipment 480V, 60 Hz Electrics Lrjdpfx Aaszn Az Dj Rer Headstock W/Center Tailstock W/Center Auto Loading Hydraulic System Pneumatic System Central Lubrication Coolant Filtering Equipment Specifications: Working Range of the Machine: -Centering Width: 600 - 1250 mm -Maximum Workpiece Diameter: 320 mm -Oscillation Stroke: +/-1 mm in relation to the oscillation frequency -Oscillation Frequency: 0-200 double strokes/min infinitely adjustable -Spindle Rotation Speed: 0-150 min -1 infinitely adjustable -Loading Height Above Floor: 1,050 mm Horizontal Axis Machine Column Travel: 1650 mm Headstock - Rotation: -Workpiece Rotational Speed: n2= 0-200 min-1 limited to n2=0-150 min -1 Headstock - Oscillation: -Oscillation Frequency: n2 = 800 double strokes/min -Oscillation Amplitude: =/- 1 mm Tailstock - Hydraulic Axis: -Stroke: 250 mm -Analog Transducer: Measuring length 300 mm Machine Weight: Approximate 8 Tons Approximate Space Requirements (Width x depth x height): -Machine: 3,6 x 3,3 x 3,3 meters -Switch Cabinet: 2,4 x 0,6 x 2,1 meters -Hydraulic Aggregate: 0,9 x 1,3 x 1,9 meters -Coolant Filtering Equipment: 1,3 x 1,0 x 2,0 meters Approximate Total Space Requirements: 35,5 meters

Condition: good (used), Year of construction: 1998, grinding wheel diameter: 915 mm, overall weight: 14,000 kg, GIUSTINA Grinder R242 to ground big bearings (up to 800mm). All machine's actions are controlled by Bosch Control. Beside controlling parts grinding process, the NC programs are also an operator guide for the machine set up and a source of information about wheel wear, thus allowing the operator to check wheels without opening the hood. Equipped with: Bosch CNC Control Specifications: Lrsdpfx Aaertr D Ij Ror Wheel Rotation Axis: Horizontal Grinding Wheel Size (OD): 915 mm Grinding Wheel Size, Usable Width: 65 mm Grinding Wheel Size, Peripheral Speed: 30 ms Spindle Motors: 75 kw Grinding Feedrate: 0.1 - 1000 mm/min Spindle Type: Moving Quill Angular Contact Spindle Bearings (Precision): ABEC-7 (ISO4) Slide Position Accuracy: 0.001 mm Coolant Flow Rate: 600 l/min Work Capacity (Approx) Rotary: 20 -200 Dia. In.

Condition: good (used), Year of construction: 2011, LANDIS LT-2 TWIN WHEEL CNC ORBITAL CRANK GRINDER Equipped with: Landis 6400 CNC Control Siemens TOUCH HMI Arobetech Steady Rest Lsdpfjrtrxxjx Aa Rjrr Marposs P7 Gage System Lateral Locator Twin CBN Grinding Wheels Rotary Dresser Headstock Tailstock Rittal AC Units Specifications: Maximum Center Distance: 680 mm

Condition: used, Year of construction: 2012, Control Siemens 840 D weight of the machine ca. 13,5 t dimensions of the machine ca. 7m x 4m x 2,75m m Accessories: Coolant tank Grinding wheels Various spare parts Operating and maintenance instructions CE conformity Dimensions: 7x4x2.75 m ( LxWxH) TECHNICAL DATA: Workpiece data: max. outer diameter: 250 mm with max. grinding wheels Ø 450 mm max. diameter to be machined over table: 375 mm Profile depth for dressable grinding wheels: 40 mm max. workpiece length: 3,600 mm max. distance between centers (1): 2,800 mm max. bevel angle: +/- 90° Number of teeth of the workpiece: 1 - 999 max. weight of the workpiece: 250 kg Working area: Ljdpjxh Rqtefx Aa Rsrr Center distance between workpiece and tool spindle: 355-170 mm Radial travel: 185 mm Axial travel: 3,000 mm Swivel angle: +/- 90°

Condition: used, Year of construction: 2001, functionality: fully functional, OKAMOTO ACC 64 DX Surface Grinding Machine Year: 2001 Lrjdpfxozv Ef Uj Aa Ror Servo Automatic Downfeed Electromagnetic chuck Coolant filtraion system

Condition: excellent (used), PERFECT PFG-70150AHRD Surface Grinding Machine Year 2014 Table size 700 x 1500 mm Maximum longitudinal travel 1650 mm Maximum cross travel 760 mm Maximum distance table surface to spindle centre 600 mm Table speed 5 – 25 m/min Magnetic chuck size 700 x 1500 mm Lrsdozuxt Aspfx Aa Rsr Spindle speed 1450 rpm Spindle motor 7.5 kW (10 HP) Grinding wheel size 355 x 40 x 127 mm Floor space required 4810 x 2550 mm Weight 7800 kg Supplied with: Automatic Downfeed System, 1500 x 700 mm Electromagnetic Chuck, Demagnetising Unit, 2 Axis Digital Readout, Remote Handwheel, Spindle Motor Speed Inverter Control, Automatic Paper Strip Filter & Magnetic Separator, Machine Pads & Levelling Bolts, Low Voltage Work Light. For sale with Jet Machinery Ltd Jet Machinery Stock No: #27039 Machine Serial Number: 1485022 Cost: £49,950.00 + VAT Whilst every effort has been made to ensure that the above information is accurate it is not guaranteed. We advise prospective purchasers to check any vital details. Health and Safety At Work Act 1974: It is not reasonably practical for ourselves as suppliers to ensure that for your application the goods comply with requirements of the Act with respect to guarding etc. Prospective purchasers should ensure that a guarding specialist inspect the goods prior to use.

Condition: used, Year of construction: 2003, CNC External Cylindrical Grinding Machine: total connected load 67 kW, voltage 3x400V 50Hz, nominal current 121A, weight approx. 9500 kg Lredpfszwf Uxsx Aa Rjr Data Kelvin Chiller (Model KRA45): serial number 0304666, year 2003, cooling capacity 4500W Data Ritz Coolant Pump (Type F2506): serial number 3196140, manufactured in 1994, 2.9kW

Condition: used, Year of construction: 2003, Machine no.: 675157 Max. weight: approx. 3,500 kg (approx. 4,300 kg incl. packaging) Supply/working voltage: 3x400 V, 50 Hz Control voltage: 24 V Nominal current: 20.5 A Main fuse: 25 A (T) CNC control: GE Fanuc Series 21i-T Grinding wheel speed indicator: make EWL, type 4444 Max. peripheral grinding wheel speed: 30 m/s (ø300 mm/12"), 40 m/s (ø400 mm/16"), 45 m/s (ø450 mm/18") Grinding head drive power: 5.0 kW Grinding wheel head R (left-mounted wheel): approx. ø450 x 80 mm Grinding wheel head RS (right-mounted wheel): approx. ø450 x 80 mm Grinding wheel head UR: left standard approx. ø400 x 63 mm, left max. (option) approx. ø400 x 80 mm, right additional max. (option) approx. ø300 x 40 mm; internal grinding attachment bore approx. ø80 mm Sub-table (Z-axis): distance between centers approx. 1000 mm, max. travel approx. 1150 mm, max. speed 12 m/min, resolution approx. 0.1 µm Top table swivel range (at 1000 mm centers): 0 to +6° (0 to +9° with workpiece length under approx. 800 mm) Grinding carriage (X-axis): max. travel approx. 320 mm, max. speed 6 m/min, resolution approx. 0.1 µm Pneumatics: min. connection pressure 6 bar, air consumption approx. 2.5 m³/h Drive motors: X-axis slide 2000 rpm/0.3 kW; grinding spindle (R/UR, ø400 mm wheel) 800-1900 rpm [40-95 Hz]/5.0 kW; sub-table (Z-axis) 2000 rpm/0.3 kW; workpiece headstock 2000 rpm/1.0 kW; automatic indexing (UR machine) 3000 rpm/0.5 kW; lubrication/hydraulic pump 1500 rpm [50 Hz]/0.12 kW or 1800 rpm [60 Hz]/0.15 kW Noise emission: equivalent continuous sound pressure level approx. 70 dB(A) Ambient conditions: max. room temperature +40°C, max. humidity 75% Data Coolant Filtration Unit Lredpfx Aaozwf R Te Rer Max. connection pressure: 3 bar / 1 bar (two circuits) Max. flow rate: 80 l/min / 160 l/min (corresponding to the two circuits)

Condition: used, Year of construction: 2003, Surface and Profile Grinding Machine table clamping surface approx. 600 x 250 mm grindable workpiece area (including 25 mm wheel width) approx. 600 x 300 mm max. permissible table load including magnetic plate approx. 130 kg height above floor approx. 1085 mm main spindle drive speed range 800-4200 rpm drive power 10 kW cutting speed 35 m/s grinding wheel diameter 300 mm, width 25/30 mm, bore 76.2 mm X-axis pendulum grinding travel speed (hydraulic, infinitely variable) 1000-24000 mm/min X-axis creep-feed grinding travel speed (AC servo motor) 5-1000 mm/min usable pendulum stroke 630 mm machine weight approx. 3400 kg, total weight approx. 3800 kg Lrsdpfx Ajzwfzloa Rjr electrical supply 400V, 3-phase, 50Hz, rated current 30A, connected load 16kVA, supply fuses 35A

Condition: used, Year of construction: 2004, CNC Surface Grinding Machine CNC control Siemens Sinumerik with handwheel, GRIPS 32 control software spindle drive motor type MS501/5 machine weight approx. 2300 kg, total weight approx. 3500 kg electrical supply 400V, 3-phase, 50Hz, rated current 29A, connected load 20kVA, supply fuses 50A Table clamping surface (standard): approx. 500 x 250 mm, other sizes available upon request Grindable workpiece area incl. 25 mm wheel width: approx. 600 x 300 mm Grindable workpiece area with VJCE cover incl. 25 mm wheel width: approx. 600 x 290 mm Distance from table top to upper limit switch (Y) at 250 mm wheel diameter: approx. 366 mm Max. permissible table load incl. magnetic plate: approx. 130 kg Height above floor: approx. 1085 mm Main spindle drive speed range: 800-4200 rpm, other options available upon request Main drive power: 10 kW at max. rpm, option 5 kW at max. rpm Cutting speed: 35 m/s, other options available upon request Grinding wheel diameter: 300 mm, option 250 mm Grinding wheel width: 25/30 mm, option 50 mm Grinding wheel bore: 76.2 mm, option 50.8/51 mm available upon request Radial wheel wear allowance: approx. 45 mm X-axis pendulum grinding speed (hydraulic, infinitely variable): 1000-24000 mm/min X-axis creep-feed grinding speed (AC servo motor): 5-1000 mm/min X-axis travel between limit switches: approx. 660 mm X-axis usable pendulum stroke: approx. 630 mm Y-axis travel speed: 0.1-2000 mm/min Y-axis travel between limit switches: approx. 360 mm Y-axis measuring system resolution: 0.0002 mm Z-axis travel speed: 0.1-2000 mm/min Z-axis travel between limit switches: approx. 280/275 mm Z-axis travel between limit switches with JC/JCE cover: approx. 270/265 mm Z-axis measuring system resolution: 0.0002 mm Installation length: approx. 3400 mm Installation width: approx. 2700 mm Installation depth (without control pendant): approx. 2440 mm Machine weight without full enclosure and control cabinet: approx. 3000 kg Machine weight with full enclosure and control cabinet: approx. 3700 kg Supply voltage: 400V AC -5% to +10%, 50 Hz, option 60 Hz Control voltage: 230V AC / 24V DC Connected load at 5 kW / 10 kW grinding power: 13.5 / 20 kVA Fuse protection: 35 A Data Cooling Unit (Erba/Schüler): equipment no. 85056334 Data Cooling Unit (Hyfra Pedia TRK 20-EF): equipment no. 85056333, year 2004 Lrodszwfmhepfx Aa Rsr Data Filter Unit (Airtech MFE 20-SP): serial no. 393196, year 06/2004, rated voltage 230/400V, rated current 3.0A

Condition: good (used), functionality: fully functional, Mitutoyo length measuring system, model KA 12 (for longitudinal and transverse movement) Retrofitting with a CNC control system for the draw-in device, including air conditioning unit, Center distance: 630 mm, the machine has no tailstock and was specifically used for chucking operations, Max. grinding diameter: 280 mm, Max. grinding wheel size: 400 x 40 x 127 mm (not included in the scope of supply), Grinding spindle speed: 2040 rpm, 6 speed stages of the tool spindle: 22.4 to 280 rpm, Lodpfx Aajzv Uhre Rorr Drive motor: 4 kW, Accuracy / smallest division value: 0.001 mm, Taper in tailstock and tool spindle: Morse 4 Largest table longitudinal travel: 760 mm, Weight between centers: 120 kg, Total power consumption: approx. 9.3 kW, Machine weight: approx. 2600 kg, Machine dimensions: L 3075 x W 1650 x H 1500 mm Year of manufacture: corresponds to the serial number: 1989 - 1991 Swiveling headstock (± 90°) and grinding head (± 45°), Hydraulic table movement and automatic feed, Cooling system, Machine lighting, Operating manual in German and electrical diagrams.

Condition: used, Technical details: grinding length: 600 mm centre height: 180 mm swing dia.: 360 mm workpiece weight: 80 kg max. dia. of grinding wheel: 500 mm grinding wheel width: 80 mm grinding wheel hole diameter: 203,2 mm Lrjdpferkr U Ejx Aa Rsr peripheral speed: 45 m/sec There is also a 3200 liter coolant tank including cooling unit + fire extinguishing system. *

Condition: excellent (used), Year of construction: 2015, functionality: fully functional, machine/vehicle number: FPS-20-RS, Schiatti Angelo FPS 20 RS 2015 Lrjdpfx Aozrx Inja Rer Excellent condition 10 spindle glass edging machine including cerium wheel Can dismantle and load for buyer

Condition: excellent (used), Year of construction: 2013, functionality: fully functional, Verticale glass grinding line for max. glass sizes : 1500 x 3300 mm Ljdpfx Aaozvw Ius Rjrr 2 vertical glass grinding machines Bottero 111 F + Kuka robot + vertical glass wasching machine Bottero min. glass size : 200 x 300 mm

Condition: used, Surface Grinding Machine BLANCHARD type 20D Shelf diameter: Ø 915 mm Shelf speed: from 5 to 27 RPM Grindstone diameter: Ø 500 mm Maxi height under wheel: 450 mm Ledpfozwgumjx Aa Rjrr Spindle motor: 30 CV - 715 RPM Electromagnetic chuck Rapid Up/Down Voltage 220 V Tri Dimensions (L x W x H): 3700 x 2000 x 2600 mm Weight: 6 T

Condition: used, Surface Grinding Machine HARIG Super 612 - No 1 Travel X: 300 mm Travel Y: 170 mm Travel Z: 250 mm Grinding wheel: Ø 200 mm Spindle motor: 3600 RPM Manual movement X - Y - Z Manual magnetic tray 345 mm x 145 mm Auto lubrication axes X and Y Delivered with 2 new grinding wheels Lredszwgr Ejpfx Aa Rer 1 vacuum cleaner Voltage: 380 V Width: 1400 mm Depth: 1500 mm Total height: 1900 mm Weight: approx 1 T

Condition: used, Year of construction: 1986, Surface Grinding Machine MONOPRECIS 1DR - #2 Lrodpfx Aezwgrrsa Ror Travel X: 400 mm Travel Y: 150 mm Maxi grinding height (Z): 220 mm Year of construction: 1986 Axes X - Y - Z manual Magnetic chuck: manual / tilted Magnetic chuck dimensions: 255 x 130 mm Grinding wheel dimensions: Ø max 170 mm Voltage: 380 V Dimensions (L x W x H): 1300 x 1100 x 1600 mm Weight: approx 500 kg
