Used Weiler Center Lathe for sale (17,837)

Condition: like new (used), functionality: fully functional, Weiler Primus Lead and Pull Spindle Bench Lathe – Like New Condition!!! Technical Data: >> Year of manufacture approx. 1990, machine no. 4472 >> Center height 120 mm >> Distance between centers 430 mm >> Speed: 60 - 3000 rpm in 18 gear stages >> Spindle bore 23 mm >> Short taper spindle head DIN 55027 >> Tailstock MK 2 >> Feeds from 0.03 to 0.15 mm/rev >> Possible threads: Metric, inch, module, and diametral pitch >> Metric thread pitches from 0.25 to 2.5 mm >> Length 1.2 m, height 1.3 m, depth 0.65 m Accessories and equipment: >> 1 three-jaw chuck, 125 mm, like new, with 2 sets of jaws >> Collet chuck with collets from 2 mm to 12 mm, increasing in 1 mm increments >> Mulifix size A with 3 steel holders >> Change gears >> Fixed steady rest >> Faceplate >> Spindle guard >> Operating manual, electrical diagrams, and much more About the machine: A Weiler Primus Lead and Pull Spindle Bench Lathe with a workbench is offered in like-new condition. The machine is, of course, fully functional. All slides run very smoothly and evenly. Even at high speeds, the Weiler runs quietly. This Primus model comes from the German Armed Forces, where it was used very little (almost new). This newer generation of Weiler lathes is very user-friendly and can produce surfaces that are as smooth as if they were ground. Take advantage of the opportunity to inspect this machine on-site and under power to convince yourself of its condition. Kdodpoz A Tgqefx Akwet Digital display available for an extra charge.

Condition: good (used), Year of construction: 1989, 1 used lathe with lead screw and feed spindle Manufacturer: Weiler Type: Condor B Year of manufacture: 1989 Serial number: 89-1314 Technical data: Center distance: 750 mm Center height: 165 mm Spindle bore: 40 mm Speed: 22 – 2800 rpm Tailstock: MK 3 Drive power: 1.6 / 3.2 kW Weight: 1040 kg Dimensions: 1,850 x 880 x 1,290 mm Equipped with: Kdodpfxez Adv Ej Akwet 3-axis digital display Lever collet chuck Chuck guard

Condition: good (used), Year of construction: 1987, functionality: fully functional, overall weight: 1,650 kg, spindle mount: MK 6, L&Z Lathe Weiler Commodor B The machine has been cleaned and inspected by us. It runs smoothly; measured runout is < 0.01 mm. Upon request, a coolant system and tool guard with a microswitch can be retrofitted. For sale only to businesses as defined in § 14 BGB. Technical data: Kodpfez A Ah Rex Akwjdt Year of manufacture: 1987 Turning length: 1000 mm Turning diameter over bed: 380 mm Turning diameter over cross slide: 190 mm Spindle speed: 25 - 2000 rpm Spindle bore: Ø 56.0 mm / MK6 Tailstock quill: MK 4 Quill stroke: 150 mm Bed width: 310 mm Spindle mounting: DIN 55027 Size 6 Feeds - longitudinal: 0.022 - 0.8 mm/rev Feeds - transverse: 0.011 - 0.4 mm/rev Threads: M 0.3 - 10.0 mm Operating voltage: 380 V Total power consumption: 4 kW Weight approx. 1650 kg Accessories: • 3-axis digital display • Multifix quick-change tool holder B • 3-jaw chuck Forkardt 200 • 4-jaw chuck Röhm • Operating manual • Chip tray with integrated coolant pump for connecting a coolant system • Various accessories (set of soft jaws, turning tools, etc.)

Condition: good (used), Year of construction: 1989, 1 used lead screw and spindle lathe Manufacturer: Weiler Type: Condor B Year of manufacture: 1989 Technical data: Center distance: 750 mm Center height: 165 mm Spindle bore: 40 mm Spindle speed: 22 – 2800 rpm Tailstock: MK 3 Drive power: 1.6 / 3.2 kW Weight: 1040 kg Dimensions: 1,850 x 880 x 1,290 mm Kdedpfx Akezuthhowot Equipped with: 3-axis digital display Lever collet chuck Chuck guard

Condition: like new (used), Year of construction: 2013, Weiler Praktikant VCD Precision Lathe (2013) Manufacturer: Weiler Type: Praktikant VCD Precision Lathe Year of Manufacture: 2013 Condition: used, very good, like new, no signs of wear, including new maintenance and inspection report prior to sale. Distance between centers: 650 mm Swing over bed: 160 mm Swing over cross slide: 320 mm Swing over compound slide: 190 mm Cross slide travel: 150 mm Compound slide travel: 110 mm Compound slide swivel range: +/-65° Bed carriage travel: 350 mm Bed width: 205 mm Tool holder cross-section (height x width): 20 x 20 mm Height from top slide to center line: 30 mm Spindle head according to ISO DIN 702-3 (DIN55027) size 5 Spindle diameter in the front bearing: 70 mm Spindle bore: 43 mm Internal taper of the main spindle: Metric 50 Drive power: 6 kW Spindle speed range: 30 - 4000 rpm Number of gear stages: 1 Number of spindle speeds: infinitely variable Number of feeds: 24 Longitudinal: 0.02 - 0.63 mm/rev Cross: 0.006 - 0.2 mm/rev Tailstock diameter: 40 mm Tailstock travel: 85 mm Internal taper of the tailstock: 3 MK Kdjdjzza Nropfx Akwst Weight, without packaging and accessories: approx. 1150 kg Length / Width / Height, net: 1720x890x1700 mm Headstock / Back wall / Sliding guard: Light grey RAL 7035 Machine base / Machine bed: Basalt grey RAL 7012 Housing of the display screen: Blue NCSS 4550-R80B.

Condition: ready for operation (used), L & Z lathe WEILER MATATOR incl. Heidenhain digital display ND 780 -Center height approx. 150mm Ksdpfxozpba Uo Akwsdt -Swinging diameter over carriage approx. 160mm -Swinging diameter over bed approx. 300mm -Distance between centers approx. 500mm -Three-axis digital display / Heidenhain -Collets / quick-change tool holder & various collets -Chuck guard -Chip guard -Multifix base plate & inserts -Spindle bore 36mm -Speed range 30 - 3500 rpm -Automatic longitudinal / cross feeds -Tailstock MK 3 -Three-jaw chuck -Documentation Dimensions: L x W x H 1.6 x 0.7 x 1.6 meters / Weight 600 kg Errors and omissions excepted.

Condition: good (used), Year of construction: 2012, functionality: unexamined, machine/vehicle number: HK06, spindle bore: 48 mm, total length: 1,600 mm, total width: 900 mm, total height: 1,600 mm, spindle speed (max.): 2,500 rpm, spindle speed (min.): 48 rpm, overall weight: 800 kg, input voltage: 400 V, input frequency: 50 Hz, input current: 7 A, WEILER PRAKTIKANT GS Lead and Feed Spindle Lathe - Connection: 5.5 kVA - Distance between centers: approx. 700 mm - Center height above bed: 160 mm - Turning diameter above bed: 320 mm - Center height above cross slide: approx. 100 mm - Turning diameter above cross slide: approx. 200 mm Kodpfezxzmyox Akwjdt The machine is equipped with a tailstock, a Multifix tool holder, and a quick-change chuck, including a three-axis digital display from the manufacturer FAGOR. FCA D-72589 Westerheim - loaded onto a truck.

Condition: ready for operation (used), Year of construction: 1996, functionality: fully functional, Weiler Condor B universal lathe in excellent condition, ex-educational use, equipped with a new 3-axis digital readout and accessories. Original paintwork. Machine No. 96-2374 with CE certification. Technical specifications: - Year of manufacture: 1996 - Machine number: 96-2374 - Centre height: 165 mm - Distance between centers: 750 mm - Spindle speeds: from 22 to 2800 rpm - Spindle bore: 40 mm - Spindle nose: DIN 55027-5 with bayonet lock - Tailstock: Morse Taper 3 - Feed rates: from 0.016 to 0.5 mm/rev - Thread cutting: metric, imperial, module, and diametral pitch - Metric thread pitch: from 0.18 to 28 mm - Weight: approx. 1100 kg - Switchable spindle brake - Required space: LxWxH 183 x 88 x 129 cm Accessories and equipment: - Rhom steel 3-jaw chuck - New collet set 5C 1-28 mm in 0.5 mm steps with new drawbar - New drill chuck 1-13 mm Kedpfx Akoyuyrujwodt - Multifix toolpost with 4 steel holders - Bed stop - New live centre - Change gears - Faceplate - Coolant system - Chip guard - Spindle cover with emergency stop - German instruction manual

Condition: excellent (used), Year of construction: 1988, functionality: fully functional, Weiler Matador VS-2 lathe with lead screw and tailstock, featuring a 3-axis digital display from Elesta, from a training workshop!! Technical data: >> Machine no. 88-8115, year of manufacture 1988 >> Center height 140 mm >> Center distance 500 mm >> Speed: 15 – 3550 RPM Kjdpfxey Tmkvo Akwedt >> Spindle bore 36 mm >> Short taper spindle head DIN 55022-5 with bayonet lock >> Tailstock MK 3 >> Feeds from 0.012 to 0.9 mm/rev >> Possible threads: metric, inch, module, and diametral pitch >> Metric thread pitches from 0.25 to 12 mm >> Brake motor >> Weight approx. 700 kg >> Length 1.4 m, height 1.2 m, depth 0.55 m Accessories and equipment: >> 3-axis digital display Elesta >> Quick-change tool post, internal and external collets (see picture) >> 1 three-jaw chuck, 1 set of jaws >> Mulifix size A with 3 steel holders >> Spindle guard >> 1 bed stop >> Change gears >> Follow rest >> Machine feet About the machine: A Weiler Matador VS-2 in very good condition is offered for sale. The machine is fully functional. The slides all move smoothly and evenly. Even at high speeds, the Weiler runs smoothly. The original location of the Weiler was a training workshop. The machine is equipped with a wide range of accessories. Take the opportunity to inspect this machine on-site while it is powered up and to convince yourself of its very good condition.

Condition: excellent (used), Year of construction: 1995, functionality: fully functional, Weiler Praktikant 160 AC Precision center lathe, 3-axis digital display, Weiler with AC drive, stepless speed control, CE marking!!!!! Technical data: >> Year of construction 1995, Machine No. 3820 >> Center height 160 mm >> Distance between centers 650 mm >> Spindle speeds: up to 3000 rpm, stepless Kjdpsy Ulqwsfx Akwedt >> Spindle bore 40 mm >> Short taper spindle head DIN 55027, size 5 with bayonet lock >> Tailstock MK 3 >> Feeds from 0.02 to 0.63 mm/rev >> Possible threads: metric, inch, module, and diametral pitch >> Metric thread pitches from 0.25 to 8 mm >> Weight approx. 1000 kg >> Spindle brake can be activated >> Machine dimensions approx. 1.4 m x 1.55 m x 0.95 m, length 1.6 m Accessories and equipment: >> 3-axis digital display Weiler >> Quick-change toolholder system with toolholders from 2 to 28 mm, in 1 mm increments >> 3-jaw chuck 160 mm, new, with 2 sets of jaws >> Mulifix size A with 3 steel holders >> Electronic chip guard >> Machine feet >> Splash guard >> Bed stop For safety: Electronic chip guard for the main spindle, cover for the lead and feed screw, brake motor, 2 emergency stop switches, electrical safety switch for the gearbox About the machine: Offered is a Weiler Praktikant AC center lathe with lead screw and feed screw, year of construction 1995, in very good condition. A very nice lathe with AC drive and stepless speed control of the main spindle. The slides all run very smoothly and evenly. Even at high speeds, the Weiler runs quietly. The Weiler has a CE marking. The machine comes from a training workshop. This newer generation of Weiler lathes is very user-friendly, and surfaces can be produced with a ground finish. The digital display makes working even easier and more precise. Take advantage of the opportunity to inspect this machine on-site while it is powered on and convince yourself of its condition.

Condition: used, Year of construction: 2002, Weiler Praktikant VC Precision Lathe Manufacturer: Weiler Type: Weiler Praktikant VC Precision Lathe Year of Manufacture: 2002 Condition: Used, very good, maintained and inspected according to Weiler's factory specifications, with inspection report. Technical Details: Turning diameter 250 mm Turning length 650 mm Center height 160 mm Swinging diameter over cross slide 320 mm Swinging diameter max. over compound slide 190 mm Main spindle: Speed range – main spindle 30 – 4,000 min/-1 Drive power – main spindle 10 / 6.0 kW Gear stages 1 Spindle nose: 5 / DIN 55027 Spindle diameter in the front bearing 70 mm Spindle bore 40 mm Usable bar diameter 40 mm Tailstock: Quill stroke 85 mm Quill diameter 40 mm Tailstock mounting MK 3 Feeds: Number of feeds 24 Longitudinal feed 0.02 – 0.63 mm/rev Cross feed 0.006 – 0.2 mm/rev Thread cutting: Metric 0.25 – 8 mm Inch 80-2 1/2" Module 0.25 – 4 mm Kdjdpezza Uzofx Akwot Travel paths: Compound slide travel 150 mm Top slide travel 110 mm Swiveling movement 180 ° Total power consumption 15 kVA Machine weight approx. 1.0 t Space requirement approx. 2.5 x 2.0 x 2.0 m Scope of delivery: – Weiler Praktikant VC Precision Lathe – Machine light – Documentation – Tailstock – 8x Machine feet – Coolant system

Condition: good (used), Year of construction: 1988, functionality: fully functional, machine/vehicle number: 1105, spindle bore: 48 mm, center height: 170 mm, total length: 1,800 mm, total width: 900 mm, total height: 1,600 mm, spindle speed (max.): 2,800 rpm, spindle speed (min.): 22 rpm, overall weight: 1,500 kg, input voltage: 380 V, input frequency: 50 Hz, WEILER CONDOR B – Guide and Feed Spindle Lathe - Connection: 4 kW Kedpfx Akoztwwkjwedt - Rated current: 9.5 A - Distance between centers: approx. 900 mm - Distance between centers above the bed: approx. 170 mm - Swing over bed: approx. 340 mm - Distance between centers above the carriage: approx. 90 mm - Swing over carriage: approx. 180 mm - Spindle bore: approx. 48 mm The machine is equipped with a tailstock, a Multifix tool holder, and a digital display from the manufacturer ACU-RITE. The machine comes from a training workshop; therefore, the guide and feed spindle are covered. FCA D-73235 Weilheim Teck – loaded onto a truck.

Condition: excellent (used), functionality: fully functional, Weiler Matador VS-2 lathe with lead screw and tailstock, equipped with a 3-axis digital display from Heidenhain ND 780, from a training workshop!! Technical data: >> Machine No. 7702, year of manufacture approx. 1990 >> Center height 140 mm >> Center distance 500 mm >> Speed: 15 – 3550 RPM >> Spindle bore 36 mm >> Short taper spindle head DIN 55022-5 with bayonet fitting >> Tailstock MK 3 >> Feeds from 0.012 to 0.9 mm/rev >> Possible threads: metric, inch, module and diametral pitch >> Metric thread pitches from 0.25 to 12 mm >> Brake motor >> Weight approx. 700 kg >> Length 1.4 m, height 1.2 m, depth 0.55 m Accessories and equipment: >> 3-axis digital display Heidenhain ND 780 >> Quick-change tool holder, internal and external collets (see picture) >> 1 three-jaw chuck, 3 sets of jaws >> Mulifix size A with 3 steel holders >> Spindle guard >> 1 bed stop >> Change gears >> Machine feet Kdodpey T Hqcefx Akwet About the machine: Offered is a Weiler Matador VS-2 in very good condition. The machine is, of course, fully functional. All slides move smoothly and evenly. Even at high speeds, the Weiler runs quietly. The original location of the Weiler was a training workshop. The machine is equipped with a wide range of accessories. Take the opportunity to inspect this machine on-site while it is powered up and to convince yourself of its very good condition.

Condition: used, Year of construction: 2012, functionality: fully functional, Weiler Primus VC Precision Lathe, manufactured in 2012. 3-axis digital display from Siemens with AC drive and stepless speed control. CE certified. Technical specifications: >> Year of manufacture: 2012, Machine No. HB 01 >> Center height: 140 mm >> Distance between centers: 500 mm >> Spindle speeds: up to 4000 rpm, stepless >> Spindle bore: 40 mm >> Short taper spindle head, DIN 55027, size 5, with bayonet lock >> Hand lever tailstock, MK 3 >> Feeds from 0.02 to 0.63 mm/rev >> Possible threads: metric, inch, module, and diametral pitch >> Metric thread pitches from 0.25 to 8 mm >> Weight: approx. 800 kg >> Spindle brake can be activated >> Machine dimensions: approx. 1.4 m x 1.55 m x 0.95 m Accessories and equipment: >> 3-axis digital display from Siemens >> Quick-change tool holder with collets (see pictures) >> Tool cabinet >> 3-jaw chuck, 160 mm, with 7 sets of jaws >> Stop >> Mulifix, size A, with 4 steel holders Kdjdpfx Akjzl T Hxjwet >> Electric chip guard >> Machine lamp >> Spindle stop, drill chuck, center >> Change gears >> Splash guard About the machine: Offered for sale is a Weiler Primus VC lead screw and draw spindle lathe, manufactured in 2012, in very good condition. The control system, in combination with a precision lathe from Weiler, performs the following functions: graphical display of travel paths and travel direction, graphical representation of the coordinate system on the lathe, compensation of tool corrections, zero point shift to compensate for workpiece position, radius/diameter switching, graphical display of the main spindle direction of rotation, and graphical display of the position of the machine's speed potentiometer. This is a very nice lathe with AC drive and stepless speed control of the spindle. All slides move very easily and smoothly. Even at high speeds, the Weiler runs quietly. This newer generation of Weiler lathes is very user-friendly and allows for the production of surfaces that are as smooth as ground surfaces. The digital display from Weiler makes working even easier and more precise. Take advantage of the opportunity to inspect this machine on site while it is powered up and to convince yourself of its condition.

Condition: excellent (used), Year of construction: 2008, functionality: fully functional, Weiler Primus VC precision center lathe, year of manufacture 2008, 3-axis digital display, Siemens, with AC drive, stepless speed control, CE compliant! Technical data: >> Year of manufacture 2008, machine no. DB-01 >> Center height 140 mm >> Center distance 500 mm >> Spindle speeds: up to 4000 rpm, stepless >> Spindle bore 40 mm >> Short taper spindle head, DIN 55027, size 5, with bayonet lock >> Hand lever tailstock, MK 3 >> Feeds from 0.02 to 0.63 mm/rev >> Possible threads: metric, inch, module and diametral pitch >> Metric thread pitches from 0.25 to 8 mm >> Weight approx. 800 kg >> Spindle brake can be activated >> Machine dimensions approx. 1.4 m x 1.55 m x 0.95 m Accessories and equipment: >> 3-axis digital display, Siemens >> Quick-change tool holder with collets (see pictures) >> Tool cabinet >> 3-jaw chuck 160 mm with 5 sets of jaws >> Stop >> Mulifix size A with 4 steel holders >> Electric chip guard Kjdpfszl T Trsx Akwedt >> Machine lamp >> Drill chuck, centering point >> Change gears >> Splash guard About the machine: Offered is a Weiler Primus VC lead screw and draw spindle lathe, year of manufacture 2008, in very good condition. The control system, in combination with a precision center lathe from Weiler, performs the following functions: graphical display of travel paths and direction, graphical representation of the measuring system on the lathe, compensation of tool corrections, zero point adjustment to compensate for the workpiece position, radius/diameter switching, graphical display of the main spindle rotation direction, graphical display of the position of the machine's speed potentiometer. A very nice lathe with AC drive and stepless speed control of the working spindle. All slides move very smoothly and evenly. Even at high speeds, the Weiler runs quietly. This newer generation of Weiler lathes is very user-friendly and allows surfaces to be produced with a ground finish. The digital display from Weiler makes working even easier and more precise. Take advantage of the opportunity to inspect this machine on-site under power and convince yourself of its condition.

Condition: excellent (used), functionality: fully functional, Weiler Praktikant R 500 lathe In very good condition, turning test: 100mm, runout 0.005 parallel. Guideways and smooth running in all speeds are flawless. Turning diameter: 280 x 500 Spindle speeds: 42 - 2000 Spindle bore: 36 3-jaw chuck Röhm 160, live center, quick-change drill chuck, lighting, coolant system. Multifix A with 4 holders, additional accessories available upon request. Dimensions: L 1.42m, W 0.6m, H 1.24m, weight approx. 600 kg Can be inspected while powered on. Free loading at D - 88433 Schemmerhofen. Kdjdpfx Ajzbhnqskwjt

Condition: used, Year of construction: 1981, machine/vehicle number: 283, Item No. 26208 Technical Data: - Maximum turning height 120 mm - Maximum turning diameter 450 mm - Maximum swing over bed 250 mm - Spindle bore 23 mm - Spindle mounting with threaded nose DIN 55027 - Taper of tailstock spindle MK 2 - 20 spindle speeds 60 - 3000 rpm - Feeds - longitudinal 0.03 - 3.0 mm - transverse 0.015 - 0.150 mm Kdsdpfx Ajzyl H Hekwjt - Thread pitches 0.25 - 5 mm - Drive 400 V / 1.1 / 1.5 kW - Footprint approx. approx. W 1200 x H 1250 x D 650 mm - Weight approx. approx. 700 kg - Including: - 3-jaw chuck - Quick-change tool holder - Rotating center - Separate tool cabinet with various accessories

Condition: good (used), Year of construction: 1979, functionality: fully functional, Lead and Feed Spindle Lathe Manufacturer: WEILER, Type: COMMODOR Year of manufacture: 1979 Technical data Manufacturer: Weiler Type: Commodor Swing over bed: 400 mm Distance between centers: 1000 mm Spindle bore: 50 mm Spindle speed range: 63-2000 rpm Drive power: 4 kW Ksdpfx Aez Ahuxjkwjdt Dimensions: approx. L 2.2 x W 1.0 x H 1.7 m Weight: approx. 1.5 t Equipment • 3-axis digital display • Drill chuck • 3-jaw chuck, manufacturer: Röhm, D200mm • Multifix holder • Additional 3-jaw chuck that is on the machine is not included in the scope of delivery! All information is subject to change without notice. A live demonstration is possible at any time in our showroom.

Condition: excellent (used), functionality: fully functional, Weiler Primus lathe in excellent condition. Can be inspected while powered on. Technical data: Center distance: 450 mm Center height: 120 mm Spindle bore: 23 mm Speed: 30 – 3000 rpm Tailstock: MK 2 Kdjdpfxsx Htf Ho Akwjt Drive power: 1.5 kW Weight: 350 kg Dimensions: 1200 x 650 x 1550 mm Price reduced!

Condition: reconditioned (used), Year of construction: 2001, Universal lathe with guide and lead screw Manufacturer: WEILER Model: Praktikant 160 B Year of manufacture: 2001 – partially overhauled Newly painted RAL 7035 light grey Machine No.: 4790 Center height: 160 mm Distance between centers: 650 mm Warranty: 6 months on the mechanics, which have been partially overhauled by us. The warranty does not cover the electrical and electronic components, as they have only undergone a functional test. For machines located outside our North Bavarian sales area, the travel costs must be borne by the customer. Geometric acceptance with test report Accessories: - 3-axis digital display Ksdozy Ngqjpfx Akwsdt FAGOR Innova 30i T, new - Lever-type collet quick-change chuck for collet type K32 (386E) - Covered guide and lead screw - Braked drive motor - Coolant system - Electrically secured chuck guard, new - Quick-change tool holder size A - Simple bed stop - Chip guard - Operating manual Used, as is The machine is technically in the condition corresponding to its original year of manufacture.

Condition: excellent (used), Year of construction: 1993, 1 used lathe with guide and draw spindle Manufacturer: Weiler Type: Praktikant 160 B Year of manufacture: 1993, with 3-axis digital display, very good condition, CE compliant Technical data: Center height: 160 mm Center distance: 650 mm Spindle speeds: from 24 to 2500 rpm Spindle bore: 40 mm Short taper spindle head, DIN 55027, size 5, with bayonet lock Tailstock: MK 3 Feeds: from 0.02 to 0.63 mm/rev Possible threads: metric, inch, module, and diametral pitch Metric thread pitches: from 0.25 to 8 mm Weight: approx. 680 kg Spindle brake can be engaged Length: 1.6 m, height: 1.25 m, depth: 0.7 m Accessories and equipment: 3-axis digital display The machine comes from a vocational training center and is in very good condition. Kdsdpjzq R Ecefx Akwet

Condition: used, Year of construction: 1992, functionality: fully functional, Weiler Praktikant 160 B Lead and Draw Spindle Lathe, built in 1992, with a new 3-axis digital display from K&C, from a vocational training workshop! Technical data: >> Year of manufacture 1992, Machine No. 92-160-2994 >> Center height 160 mm >> Distance between centers 650 mm >> Spindle speeds: from 24 to 2500 rpm >> Spindle bore 40 mm >> Short taper spindle head, DIN 55027, size 5, with bayonet lock >> Tailstock, MK 3 >> Feeds from 0.02 to 0.63 mm/rev >> Possible threads: metric, inch, module, and diametral pitch >> Metric thread pitches from 0.25 to 8 mm >> Weight approx. 680 kg >> Spindle brake, switchable >> Length 1.6 m, height 1.25 m, depth 0.7 m Accessories and equipment: >> 3-axis digital display from K&C with operating manual Functions: Switching mm/inch, coordinate selection ABS/INC, halving of the display value, reference mark, tool programming 200 pieces, taper calculation, radius/diameter, quick zeros, switching of the counting direction >> 3-jaw chuck 160 mm with 1 set of jaws >> Tool clamping system with 2 steel holders >> Bed stop >> Centering point >> Coolant system >> Rear panel >> Machine feet >> Electronic spindle protection >> Operating manual Additional accessories such as collets, 4-jaw chucks, steady rests, and more are available at an extra charge. For safety: Electronic spindle protection, cover for the lead and draw spindle, 2 emergency stop buttons, spindle brake, electronic door protection for the change gears. Kedpfjzd Tycex Akwodt About the machine: Offered is a Weiler Praktikant 160 B lead and draw spindle lathe in very good condition. All slides run smoothly and evenly. Even at high speeds, the Weiler runs quietly. This newer generation of Weiler lathes is very user-friendly and allows surfaces to be produced that are as smooth as if they had been ground. Take advantage of the opportunity to inspect this machine on-site while it is powered up and see its condition for yourself.

Condition: refurbished (used), functionality: fully functional, spindle bore: 40 mm, center height: 165 mm, center width: 750 mm, quill stroke: 85 mm, total length: 1,800 mm, total width: 1,300 mm, spindle speed (max.): 2,800 rpm, spindle speed (min.): 22 rpm, overall weight: 1,100 kg, Dear Sir or Madam, We are offering for sale a Weiler Condor B lead and draw spindle lathe in fully refurbished condition! This model is particularly distinguished by its extremely user-friendly operation and its excellent ratio of footprint to center height/center distance. The Condor B is in the size range between the Weiler Praktikant and the Weiler Commodor and is therefore a true all-rounder in any workshop. The machine will undergo extensive refurbishment in our workshop, so that it will be in like-new condition both technically and visually! The following work will be carried out during the refurbishment of the machine: - Basic cleaning - Repainting - Overhaul of the guideways - Replacement of all lubricants - Replacement of all standard parts such as handles, buttons, screws, etc. - Replacement of all wear parts such as belts, chains, wipers, etc. - Replacement of all electronic components such as contactors, transformers, switches, etc. - Documentation with test report, parts list, and geometry report Availability: upon request Center height: 165mm Center distance: 750mm Spindle bore: Ø 40mm Tailstock taper: MK3 Chuck mounting: short taper DIN55027 size 5 with bayonet lock Quill stroke: 85mm Spindle speeds: 22-2800 rpm Possible thread types: metric, inch, module, diametral pitch Ksdpsztf A Uofx Akwodt Metric thread pitches: 0.18 - 28mm Spindle brake: can be switched on Voltage: 400V Dimensions: approx. 1.80x1.30x0.9m (LxHxW) Weight: approx. 1100kg Additional equipment and accessories: chuck guard (NEW), coolant system, 2x emergency stop, lead and draw spindle cover (optional), K+C digital display NEW (optional), operating manual, technical documents, and much more on request... Our service promise to you: - We are a certified master workshop in the field of mechanical engineering - All machines are workshop-tested at least. - All lubricants and any worn parts will be replaced beforehand - If desired, we will completely or partially overhaul the machine of your choice - If desired, we will repaint the machine of your choice in your desired color - If desired, you can order additional accessories such as tools, etc. directly with your order - If desired, we can install additional accessories such as safety devices, etc. - We will be happy to take care of the shipping and/or delivery

Condition: used, Year of construction: 1999, turning diameter over bed 280 mm turning diameter over slide rest 150 mm turning length 500 mm center height over bed 140 mm centre distance 500 mm bed width 205 mm spindle bore 40 mm turning speed range - stepless 30 - 4.000 U/min 3-jaw-chuck diameter 140 mm quick change toolholder MULTIFIX Typ A drive capacity - spindle motor 4,0 kW Kodpfsz Abw Hex Akwsdt taper in tailstock-quill MK 3 dia. of quill 40 mm quill stroke 85 mm voltage 400 V total power requirement 7,5 kW weight of the machine ca. 800 kg dimensions of the machine ca. 1,40 x 0,95 x 1,55 m - Serial-No.: 154 - SIEMENS 3-axis digital display - MULTIFIX quick-change tool holder - rotating centering tip

Condition: ready for operation (used), functionality: fully functional, WEILER COMMODOR lathe, from an educational institution -Maximum turning height 180mm -Maximum turning length 1000 mm Ksdpfxezww D Ej Akwsdt -Spindle bore 56 mm -Speed range 56 - 2000 RPM -Automatic longitudinal/facing feeds -Threading capabilities / Metric / Inch etc. -Tailstock MK 4 -Three-jaw chuck 200mm -Multifix base with inserts -Electric chuck guard -L & Z spindle cover -Work light -Coolant system -2 x Emergency stop -Machine documentation Dimensions: L x W x H 2.5 x 1.1 x 1.7 meters / Weight 1500 kg Errors and omissions excepted.
