Used Weiler Cycle-Controlled Lathe for sale (46,386)

Condition: good (used), Year of construction: 2006, control FANUC 21i-TB Control Laodovzln Ropfx Am Nsa x-axis 390 mm z-axis 780 mm spindle taper A2-11 number of spindle speeds 2000rpm engine output 37 kW weight of the machine ca. 9000 kg dimensions of the machine ca. 1905,0 × 2720,0 × 3260,0 m The machine has chucks that can produce gears from 100 to 500 mm. Special chuck is available

Condition: used, YOM 2013 Chuck Size – 150mm Bar Capacity – 53mm Swing – 430mm Spindle Speed - 4,000 RPM Control - Siemens 802D Distance Between Centers – 1000mm Ledpfx Aoy Dtuiom Neaa X-Axis Travel – 220mm Z-Axis Travel – 1065mm Swing Over Cross Slide – 200mm Motor – 10 HP 4-Way Tool Post Tailstock Over Dimensions (Approx.) 2.75m x 1.3m Weight (Est.) 2800kgs

Condition: good (used), Year of construction: 1999, functionality: fully functional, Gildemeister NEF 320 / Cycle Lathe, Year of manufacture: 1999, Control: Manual Plus, Centre distance: 750 mm, Swing diameter over bed: 320 mm, Spindle speed up to 4,000 rpm, 2 gearbox stages, Multifix toolholder, Tailstock, Ljdpoy Ev I Uofx Am Noaa 2 steadies, Accessories,

Condition: ready for operation (used), Year of construction: 2017, functionality: fully functional, turning diameter over cross slide: 310 mm, turning length: 2,000 mm, turning diameter: 540 mm, spindle bore: 85 mm, spindle speed (max.): 2,250 rpm, travel distance X-axis: 350 mm, travel distance Z-axis: 1,850 mm, rapid traverse X-axis: 5,000 m/min, rapid traverse Z-axis: 8,000 m/min, total height: 2,235 mm, total length: 3,840 mm, total width: 1,925 mm, quill travel distance: 210 mm, quill diameter: 75 mm, overall weight: 4,200 kg, chuck outer diameter: 315 mm, spindle nose: D1-8, center height: 270 mm, Siemens 828D control with ShopTurn Max. turning diameter over bed: 540 mm Max. turning diameter over carriage: 310 mm Center height: 270 mm Distance between centers: 2000 mm X / Z-axis travel: 350 / 1850 mm Chuck diameter: 315 mm Spindle bore: 85 mm Spindle speed: 2250 rpm Tailstock quill diameter: 75 mm Tailstock quill stroke: 210 mm Tailstock taper: MT5 Feed rate: 5000 mm/min Rapid traverse X / Z-axis: 5000 / 8000 mm Lodpfxjy Ey Eds Am Noaa Workpiece weight: - Chuck only: 300 kg - With tailstock: 700 kg - With tailstock and steady rest: 1200 kg Machine dimensions without chip conveyor (L x W x H): 3840 x 1925 x 2235 mm Machine weight: 4200 kg Includes: 2 steady rests, 2 Multifix toolholders, Schunk Rota-S315 3-jaw chuck, chip conveyor, manuals

Condition: good (used), Year of construction: 1999, Ref. -No.: 10365 Manufacturer: MONFORTS Type: KNC 8 S - 3000 Year of construction: 1999 Type of control: CNC Control: MTC K Storage location: Halberstadt Country of origin: Deutschland Machine-No.: 178.05 X stroke: 455 mm Z - stroke: 2850 mm Chuck diameter: 315/400/500 mm Centre Distance: 3000 mm Feed Capacity - Z: 23,9 kN Feed Capacity - X: 11,3 kN Rapid Travel Speed X-Axis: 6,8 m / min Rapid Travel Speed Z-Axis: 4 m / min Circumferential diameter over radial slide: 540 mm Max swing diameter: 830 mm travel of the cross slide: 450 mm Spindle head max. passage for violent material: 88 mm Spindle head max. passage for bare material: 90 mm Tailstock outside diameter of the quill: 125 mm Tailstock maximum quill stroke: 200 mm Tailstock inner cone: MK6 Type hydraulic tank: 15 L. coolant reservoir: 220 L. Coolant tank at chip conveyor: 160 L. Ledey Edz Aepfx Am Nsaa Machine length: 5200 mm Machine width: 2110 mm Machine Height: 1995 mm Weight Of The Machine Ca.: 6,850 (Ohne Späneförderer und Kühlmittelbehäter) t Headstock Spindle Head: DIN 55027 - 11x290 Further information: Additional lubricating oil tank approx. 6l incl. tools Machine is under power and can be inspected by arrangement.

Condition: excellent (used), Year of construction: 2014, VDF 400 DUS ti Lsdpfjy Emvijx Am Neaa Year of manufacture: 2014 Siemens 840 D sl Swing diameter: 420 mm Turning length: 1000 mm Spindle speed: 10-3000 rpm, 11 kW gearbox, 2-speed Parat Gr.2, 4-position turret Tailstock Drill rest Coolant system 5 bar Chuck Schunk Rota -S 250 mm Extraction unit by Bristol LED light Memory expansion Loading and transport possible Available immediately. For questions and an exact price, please send a message with your address and email.

Condition: used, Year of construction: 2000, Technical details: turning diameter: 800 mm turning length: 2965 mm max. turning dia. over saddle: 520 mm spindle bore: 92 mm turning speed range: 3 - 1800 U/min spindle head: Größe 11 total power requirement: 37 kW weight of the machine ca.: 6,5 t dimensions of the machine ca.: 5,2 x 2,2 x 1,9 m Teach In Control MTC-K 3-jaw chuck ROTAS Dia. 400 mm Lsdpexxig Uofx Am Neaa face plate RÖHM Dia. 630 mm 4-station toolholder system PARAT 1 fixed steady coolant attachment and chip conveyor *

Condition: used, Year of construction: 1996, Technical details: turning diameter: 500 mm turning length: 1500 mm turning diameter over bed slide: 290 spindle bore: 71 mm turning speed range: 3 - 2800 U/min rapid speed: 10 / 5 m/min feed speeds: 1 - 2000 mm/min total power requirement: 22 kW Lodpfx Amowwlvle Njaa weight of the machine ca.: 3,2 t dimensions of the machine ca.: 3,0 x 1,6 x 2 m with Teach In controll R&D MTC-K PARAT toolpost 1 fixed steday dia. 100 mm 4 jaw face plate dia. 500 mm coolant attachment *

Condition: used, Year of construction: 1998, Technical details: turning diameter: 830 mm turning length: 4000 mm turning diameter over bed slide: 540 mm spindle bore: 130 mm turning speed range: 2 - 1600 U/min rapid speed: 4 / 5 m/min feed speeds: 1 - 2000 mm/min total power requirement: 55 kW Ljdpfx Aowwlt Rsm Noaa weight of the machine ca.: 7,5 t dimensions of the machine ca.: 7 x 2,2 x 2 m with Teach In controll R&D MTC-K MULTIFIX toolpost size D coolant attachment *

Condition: excellent (used), Year of construction: 1998, turning diameter 570 mm turning length 1000 mm Ljdpfoy D T Uvex Am Njaa control Siemens / Weiler D2 weight of the machine ca. 3,2 t dimensions of the machine ca. 3,0 x 2,0 x 1,9 m

Condition: good (used), Year of construction: 2004, functionality: fully functional, Technical details turning diameter 570 mm turning length 2000 mm control Heidenhain Lasdpey Dpvvofx Am Noa turning diameter over bed slide 340 spindle turning speed range 1 - 2500 U/min weight of the machine ca. 3,6 t Additional information Features: 2 steady rests Manual chuck with jaws Tool holder with inserts

Condition: excellent (used), GILDEMEISTER Cycle Lathe Model NEF 320 Year of manufacture: 2003, with only 5,653 power-on hours (spindle hours approx. 1,200 estimated!) CNC Control: SIEMENS 810 D with Manual Turn software Work Area: Centre height: 160 mm Centre distance: 750 mm Swing diameter over bed: 320 mm Swing diameter over cross slide: 150 mm Chuck diameter: 200 mm Cross travel: 185 mm Spindle: Spindle nose DIN 55027: Size 6 Spindle bore: 50.8 mm Spindle taper: MK 6 Spindle diameter in front bearing: 85 mm Main Drive (AC): Main drive: 100% duty cycle, 9.0 kW Max. torque: 100% duty cycle, 410 Nm Speed range: 10 – 4,000 rpm Speed control: stepless Gear stages: 2 (ZF gearbox) Feed Drives (AC): X-axis feed force: 100% duty cycle, 3,000 N Z-axis feed force: 100% duty cycle, 6,000 N X rapid traverse / feed speed: 8 m/min Z rapid traverse / feed speed: 10 m/min Tailstock: Quill diameter: 70 mm Quill stroke: 120 mm Quill taper: MK 5 Machine Dimensions: Length: 2,450 mm Height: 1,825 mm Width/depth: 1,815 mm (2,400 mm with electrical cabinet doors open) Weight: 2,000 kg Connected load: 14 kVA Lodpey D Eplefx Am Noaa Includes: SCHUNK ROTA-Plus 3-jaw wedge-bar power chuck Ø 200 mm Multifix quick-change tool post size B 5 MULTIFIX tool holder cassettes size B Live centre Quick-action drill chuck Removable chip tray Coolant unit Electrically interlocked chuck guard Machine leveling feet Operating manual Condition / Description: +++ Very good +++ The NEF 320 comes from a vocational training institute and has seen very little use (see power-on hours). It was mainly used for training and demonstration purposes—no production workload! The machine bed is essentially in as-new condition. Backup battery replaced; data backup performed. The machine is impressive thanks to its performance and the professional SIEMENS 810 D control with user-friendly MANUAL TURN software. Function videos can be provided upon request.

Condition: repair required (used), Year of construction: 2002, functionality: not functional, turning length: 750 mm, swing diameter over bed slide: 320 mm, type of input current: three-phase, We offer this used Gildemeister NEF 320 cycle-controlled lathe, year of manufacture 2002. Control system: Heidenhain 4110 Control does not boot up, see error message in the photo. A floppy disk with the machine data is available. Other condition unknown, as it comes from the closure of a model making company. Laodpfeypwhvex Am Nja Machine is still under power. Crane loading onto your truck is possible.

Condition: used, Year of construction: 2004, control Heidenhain Ljdpfx Amey A Tdbj Nsaa turning length 1.000 mm turning diameter over bed 500 mm turning dia. over slide 290 mm centre distance 1.500 mm x-axis 260 mm z-axis 1.000 mm spindle bore 70 mm spindle tunring speed 3.000 U/min spindle motor 12 kW In our assessment, the machine is in good used condition and can be inspected under power by appointment. Accessories, tools, and clamping devices shown are only included in the scope of delivery if this is noted in the additional information. Technical data and specifications are subject to change without notice and errors. Prior sale is reserved.

Condition: good (used), Year of construction: 2000, Spindle module replaced in 2008 Lodpey A I I Iefx Am Njaa Swing diameter over bed: 630 mm Swing diameter over support: 370 mm Spindle bore: 105 mm The machine is supplied with a 250 mm manual chuck. Spindle speed range 1: 4 - 430 rpm. Spindle speed range 2: 430 - 2500 rpm. Main motor power: 18.5 kW S6-40%

Condition: excellent (used), Year of construction: 2004, Year of manufacture: 2004 Sauter 8-position VDI 20 turret with all stations powered tools Spindle holding brake Interpolating C-axis Reinforced coolant pump 2.3 bar / 28 l/min Control: Heidenhain MANUAL PLUS (cycle control) Monitor: 10.4" TFT VGA color display Working area & capacity Swing diameter: 320 mm (over bed) / 150 mm (over cross slide) Distance between centers: 750 mm Cross travel: 185 mm Spindle bore: 56.6 mm Spindle nose: Size 6 (according to DIN 55027) / Mount MK 6 (AC) Drive power: 9 kW (at 100% duty cycle) Max. torque: 410 Nm Speed range: 20 – 4,000 rpm (2 gear stages) Stage 1: 20 – 1,000 rpm Stage 2: 40 – 4,000 rpm Feed & axes Rapid traverse (X/Z): 8 / 10 m/min Feed speed: 5 m/min Feed force: 300 daN (X) / 600 daN (Z) C-axis: Interpolating (option included) Tool turret & tailstock Turret: 8-station disc turret (Sauter), all stations powered Speed for driven tools: Max. 6,000 rpm (3.8 kW) Tooling system: VDI 20 (DIN 69880) Ljdpfsy Dckaox Am Noaa Tailstock: Quill diameter 70 mm, stroke 120 mm, MK 5 mount Dimensions & capacities Footprint: approx. 2,600 x 1,915 x 1,730 mm Weight: approx. 2,200 kg Coolant tank: approx. 70 liters Fixed steady rest with rollers, guide diameter 10-115 mm Travelling steady rest with rollers, guide diameter 10-115 mm Three-jaw chuck Schunk Rota Splus 200-52 J 6, high precision Quick-action chuck with lever, SSF 40/6 Ortlieb, collet 173 E Preparation for faceplate operation, includes speed monitoring with separately adjustable speed supervision. Tooling equipment: fixed turning tool holders and driven tool holders Jaws / hard and soft Collets 173 E The machine was used in single-part production for prototype manufacturing. Low spindle running hours Available immediately.

Condition: used, Year of construction: 1995, turning diameter over cross slide: 515 mm, spindle bore: 128 mm, turning length: 2,000 mm, turning diameter: 820 mm, quill stroke: 280 mm, quill diameter: 125 mm, quill travel distance: 280 mm, feed length X-axis: 520 mm, workpiece weight (max.): 3,150 kg, rotational speed (max.): 1,600 rpm, workpiece weight between centers: 3,150,000 g, Technical data in the attachment. Laodpfx Amoy Emrdo Nja

Condition: used, Year of construction: 1998, turning diameter 555 mm turning length 4000 mm control Monforts Control System type MTC-K CCUO turning diameter over slide rest 290 mm cross movement . mm Lajdeyqv N Uspfx Am Nja spindle passage . mm turning speeds 1600 U/min transmission ratio . quill stroke . mm rapid traverse . m/min main drive motor . kW 3-jaw chuck Rotha-S Plus 3-jaw-chuck diameter . mm total power requirement . kW weight of the machine ca. . t dimensions of the machine ca. . m Serial number: 262/01 Machine number: Quick-change tool post Coolant system Monitor Chip conveyor The tech. Data are manufacturer or operator information and therefore non- binding. We reserve the right to prior sale; Our terms and conditions of sale apply exclusively. About us More than 400 of our own machines in stock Over 15,000 m² of storage space, 70 t crane capacity More than 10,000 items and accessories for your workshop If you are interested in selling machines, production lines, or your business, please contact us. You can find further offers on our website. Tours are possible by appointment. We look forward to your visit. Your Markus Hirsch Team

Condition: ready for operation (used), Year of construction: 2006, spindle bore: 130 mm, turning length: 600 mm, turning diameter: 1,800 mm, Turning diameter 1800 mm Turning length 600 mm Siemens control 6-jaw chuck Spindle bore 130 mm Lajdpfx Aey Aw Svsm Nsa Spindle nose DIN 55027 size 11 Speed range 1 - 400 rpm Spindle torque 9000 Nm Total power requirement 38 / 52 kW Machine weight approx. 25 t

Condition: excellent (used), Year of construction: 1998, turning diameter 410/ 440 mm turning length 950 mm control Siemens / Weiler D2 workpiece weight max 900 kg spindle head Gr 6 MK 6 spindle bore 54 mm Lasdpfxsyrh Apo Am Nea face stroke 230 dia. of quill MK 4 mm quill stroke 120 mm centre height 200 mm thread pitch max. in mm 0,1 - 250 mm spindle turning speed - stepless 1 - 3000 U/min total power requirement 12 kW weight of the machine ca. 2,1 t dimensions of the machine ca. 2,3 x 1,5 x 1,8 m

Condition: repair required (used), Year of construction: 2003, Kern lathe CD 402 Baij 2003 in top condition but with control system issues. Ljdpjxn Axcefx Am Nsaa

Condition: good (used), Year of construction: 2001, functionality: fully functional, turning diameter over cross slide: 370 mm, spindle bore: 80 mm, turning length: 2,000 mm, turning diameter: 610 mm, spindle speed (max.): 1,800 rpm, Swing diameter over bed 610 mm, over cross slide 370 mm. Distance between centers 2000 mm. Spindle bore 80 mm. Speed range 40 - 1800 rpm. Tailstock: quill travel 150 mm, Morse taper 5. Includes Siemens 810D manual turn control, steady rest, Parat toolpost, coolant system. Three-jaw chuck D 315 with various jaws, chuck mounted on spindle rear side. Manual, CE declaration. Laedpfx Aeyzmk Esm Nea

Condition: good (used), Year of construction: 2005, 1 used, well-maintained high-performance cycle lathe with FAGOR 8055 control, 8-position VDI 40 tool turret, constant cutting speed, pneumatic 3-jaw front chuck, and chip conveyor Manufacturer: MICROTURN, Origin Taiwan Model: Challenger BNC 2680X Year of manufacture: 2005 / Commissioned in 2006 Technical data: Center height: 325 mm Distance between centers: 2150 mm Swing diameter over bed: 650 mm Swing diameter over cross slide: 410 mm Swing diameter in gap: 870 mm Spindle speeds: 0 – 2,400 rpm Spindle bore: 82 mm Spindle motor: 15 / 22 kW Machine weight: 4,800 kg Accessories / Special Features: • Cycle control FAGOR 8055 with alphanumeric keypad o LCD color monitor o Graphical cycle simulation o 2 electronic handwheels • Pneumatic 3-jaw front chuck, make SMW, Ø 315 mm o By using this pneumatic front chuck, the entire spindle bore of Ø 82 mm remains available. With hydraulic chucks, the spindle bore is reduced by the required draw tube. • 8-position tool turret VDI 40 • Hinged belt chip conveyor • Fixed steady rest • Automatic headstock lubrication • Automatic lubrication of longitudinal and cross slides • Tailstock • Coolant system • CE compliant Siegfried Volz Werkzeugmaschinen Rüschebrinkstr. 151-153 DE - 44143 Dortmund - Wambel / Germany Ledjyy N Rfepfx Am Neaa

Condition: good (used), Year of construction: 2008, Centre height: 445 mm Centre distance: 4000 mm Swing diameter over bed: 890 mm Swing diameter over cross slide: 550 mm Swing diameter in gap: 1150 mm Spindle speeds: 0 – 1480 rpm Spindle bore: 106 mm Spindle motor: 22 / 33 kW continuous duty / S6 (40%) Machine weight approx. 12,500 kg Accessories / Special features: • Cycle control FAGOR 8055 T with alphanumeric keypad o 10.4" LCD color monitor o Graphic simulation of cycles o Electronic handwheel for manual machine operation • 3-jaw chuck • 8-position tool turret • 2 fixed steadies with rollers • Movable control panel • Automatic lubrication of the headstock • Automatic lubrication of longitudinal and cross slides • Tailstock with hydraulically actuated quill • Coolant system • CE-compliant Siegfried Volz Werkzeugmaschinen Ljdpfx Amsyy Nlps Noaa Rüschebrinkstr. 151-153 DE - 44143 Dortmund - Wambel / Germany

Condition: used, Year of construction: 2003, centre height 255 mm centre distance 1.080 mm turning diameter over bed 500 mm turning diameter over slide 290 mm turning length 1.000 mm control EuroTurn spindle bore 70 mm spindle taper KK 8 DIN 55027 3-jaw-chuck diameter 250 mm bed width 360 mm turning speed range 2 - 2.800 U/min rapid travel - longitudinal/face 10 / 5 m/min quick change toolholder PARAT Gr. 2 drive capacity - spindle motor 11,0 kW taper in tailstock-quill MK 5 dia. of quill 80 mm quill stroke 160 mm voltage 400 V total power requirement 16,0 kVA weight of the machine ca. 3,0 t dimensions of the machine ca. 2,85 x 1,60 x 1,80 m - Serial-No.: 495 / 03 Lodpfjwizltex Am Njaa - control: EuroTurn - quick change tool holder PARAT - coolant equipment - machine lamp
