Vertical machining centerMAKINO
D500
Machine data
- Machine type:
- Vertical machining center
- Manufacturer:
- MAKINO
- Model:
- D500
- Year of construction:
- 2011
- Condition:
- like new (used)
Price & Location
- Location:
- Fortuna Park, Flinger Broich 203, Halle 7-K, 40235 Düsseldorf, Alemania
Technical details
- Travel distance X-axis:
- 550 mm
- Travel distance Y-axis:
- 1,000 mm
- Travel distance Z-axis:
- 500 mm
- Feed length X-axis:
- 550 mm
- Feed length Y-axis:
- 1,000 mm
- Feed length Z-axis:
- 500 mm
- Controller manufacturer:
- FANUC Professional 5
- Workpiece length (max.):
- 650 mm
- Workpiece width (max.):
- 500 mm
- Workpiece weight (max.):
- 350 kg
- Total height:
- 3,200 mm
- Total length:
- 3,550 mm
- Total width:
- 3,200 mm
- Overall weight:
- 15,700 kg
- Spindle speed (min.):
- 20,000 rpm
- Tool length:
- 300 mm
- Tool diameter:
- 70 mm
- Tool weight:
- 8,000 g
Details about the offer
- Listing ID:
- A217-28703
- Reference number:
- CNC0246
- Update:
- 16.04.2026
Description
Axes
X-axis travel mm: 550
Y-axis travel mm: 1000
Z-axis travel mm: 500
C-axis degrees: 360 (continuous rotation) / rotary encoder
A-axis degrees: 150 (+30 120º) rotary encoder
Feed rates m/min: X:32; Y,Z:40;
Rapid traverse m/min: X,A,C:48; Y,Y:50; A,C:18
Worktable
Table dimensions mm: 500
Maximum workpiece size (D x H) mm: 650x500
Max. workpiece weight kg: 350
T-Slot version: 4x185H8
Spindle
Spindle speed rpm: 20000
Tool system
Tool holder: HSK-A63
Tool magazine slots: 323
Tool changer: pinza doble
Max. Tool Diameter: 70
With occupied neighboring places mm: 140
Hsdoy Ddq Uepfx Ad Hoff
Tool Magazine: Matrix
Max. Tool Length mm: 300
Max tool weight kg: 8
Equipment
Electronic Handwheel
Chip conveyor
Custom Macro common variables (100)
Synchronized tapping
Preparación para trabajar con robot
Robot EROWA
Helical interpolation
Custom Macro common variables (100)
Machine running times
Spindle Working: 0h (Retrofited)
Basic machine dimensions / weight
Length mm: 3550
Width mm: 2900
Height mm: 3200
Weight kg: 15700
