Parquet production line

Marinus PROMAX

Condition: reconditioned (used), Year of construction: 2007, functionality: fully functional, total length: 2,000 mm, total width: 1,250 mm, total height: 2,000 mm, type of input current: three-phase, input voltage: 400 V, power: 40 kW (54.38 HP), saw blade diameter: 450 mm, workpiece width (max.): 300 mm, workpiece height (max.): 30 mm, air pressure: 6 bar, extraction connection diameter: 200 mm, hone diameter: 125 mm, number of spindles: 2, MARINUS PROMAX - Endmatcher and defect saw. The machine is according to following specifications: - Stable and heavy construction, dimensions LxDxH = 2080x1260x2000 mm. - Continuous feeding system with accurate positioning (servo). - Pneumatic sidepushers for guaranteed square angle. - PLC-steering. - Operating by terminal. - Modem for programming at distance. - 2 servomotors for maximum dynamics. - 2 sawingmotors (3,0 kW). - 2 high-speed millingmotors with inverter (7,5 kW each /200 Hz/n=12.000). - 1 motorgearbox with inverter. - 2 drummotors. - 26 pneumatic cylinders with valves. - 1 luminescence-sensor - 6 inductive-sensors - Bandconveyor for waste, height 1,3 mtr. - Machine completely closed by safety-doors. - Machine according to CE-requirements. Length-measuring system: A lenght-measuring-system displays the total lenght and square meters of the boards on the display during production. Tooling: We can offer tooling (tongue and groove) with disposable knives and 2 crosscutsawblades as an option for the machine. Standard Programming: The machine is equipped with 2 main programs: 1 Endmatching 2 Cutting Both main programs have 2 sub programs: Dcedpfx Ajq Auhdsgdjp 1. Variable lenghts: defects are cut out, endproducts are of all variable lenghts. 2. Fix lenghts: boards will be produced at a fixlenght, infeedlenght has an oversize of max +200 mm. Cutting out defects is not possible. - Min. Width 60 mm - Max. Width 300 mm - Min. Length 500 mm - Max. Length 6000 mm - Min. Thickness 10 mm - Max. Thickness 30 mm
