Vertical machining center

Mazak VTC-800/20SR

Condition: used, Year of construction: 2010, x-travel 730 mm y-travel 730 mm z-travel 730 mm control Matrix Nexus Mazatrol Main spindle: turning speed range - main spindle 35 - 18.000 min/-1 power capacity - milling spindle 35 / 26 kW tool taper ISO 40 DIN 69871A transmission ratio 2 pallet changer: numbers of pallets 6 (5+1) size of pallet 500 x 500 mm max. workpiece weight 700 kg max. workpiecediameter 800 mm max. workpiece height 1.000 mm change time of pallets 7 sec B-axis (table) 0,001 ° Tool-Presetter: number of toolpositions 160 pos. tool taper ISO 40 DIN 69871A max. tool diameter 95 mm max. tool-dia with free toolbox 150 mm max. tool length 420 mm max. tool weight 12 kg change-time tool to tool 2,7 / 3,2 sec feeds: rapid traverse 60 m/min feed speeds max. 60.000 mm/min total power requirement 78,5 kVA weight of the machine ca. 16,4 t dimensions of the machine ca. 7,5 x 3,5 x 3,0 m CNC - MachiningCenter Horizontal MAZAK - Nexus 5000 II - palletchanger 6(5+1) pos. Iodpfx Adjup H Dre Dstp - WITHOUT tools

Year of construction: 2006, condition: ready for operation (used), A Mazak CNC 5-axis turning and milling center with counter spindle is available. Swing diameter: 820mm, machining diameter: 820mm, machining length: 1500mm, max. workpiece weight in chuck/between centers: 650kg/150kg, main spindle speed: 1600rpm, spindle bore: 185mm, power: 30kW/40kW, tailstock force: 15kN, quill stroke: 1466mm, tool holder: BT50, spindle speed: 10000rpm, travel X/Y/Z: 870mm/500mm/1600mm, rapid traverse: 40m/min. Machine dimensions X/Y/Z: approx. 6500mm/3700mm/3200mm, weight: approx. 26000kg, control: Mazatrol Matrix. Documentation available. An on-site inspection is possible. The machine is located in China. Iedpfx Adjxf Iklj Dstp

Condition: used, MAZAK Integrex 100 III ST CNC: MAZATROL 640 MT PRO Swing over Cross Slide: 545 mm Maximum Machining Diameter (Milling Head): 545 mm Maximum Machining Diameter (Lower Turret): 400 mm Maximum Machining Length: 753 mm X-Axis Travel: 410 mm Z-Axis Travel: 805 mm Y-Axis Travel: 140 mm X2-Axis Travel: 220 mm Z2-Axis Travel: 780 mm W-Axis Travel: 795 mm Rapid Traverse (X/Z-Axis): 30/33 m/min Rapid Traverse (X2/Z2-Axis): 30/33 m/min Rapid Traverse (Y-Axis): 26 m/min Rapid Traverse (W-Axis): 30 m/min Main Spindle Bore Diameter: 51 mm Sub Spindle Bore Diameter: 51 mm Main Spindle Speed Range: 35 – 6,000 rpm Sub Spindle Speed Range: 35 – 6,000 rpm Main Spindle Motor Power: 11 kW Sub Spindle Motor Power: 11 kW Main Spindle Maximum Torque: 16.4 kgf·m Sub Spindle Maximum Torque: 16.4 kgf·m Itjdpexl Eq Aofx Ad Dep Tool Magazine: 40 tools, KM63 Milling Spindle Speed: 15–12,000 rpm Lower Turret Stations: 8 C-Axis on Main Spindle C-Axis on Sub Spindle C-Axis Indexing: 0.001 degrees Driven Tools Main Spindle Chuck: KITAGAWA B-206, Ø170 mm Sub Spindle Chuck: KITAGAWA B-206, Ø170 mm Tool Presetter Chip Conveyor Machine Weight: 7,600 kg

Condition: ready for operation (used), Year of construction: 2012, operating hours: 17,547 h, Main Drive Spindle speed range 4000 Tool taper HSK-63 Number of axis 7 Movement X-Axis Movement 615 mm Y-Axis Movement 250 mm Z-Axis Movement 1585 mm V-Axis Movement 230 mm W-Axis Movement 1539 mm 1-AXIS Movement 30-210 Tools Slots in storage 72 Media Chip conveyor Yes Additional Equipment Mist filter unit High pressure cooling (14 bar) Work space rinse cleaning (2.7 bar/60 l) RMP600-Radio/Radio probe Preparation for 70 bar cooling through spindle Programmable overload detector C-axis on second spindle MO321 - Gear milling without tool TE810 - Preparation for Multi and Flash tools NO117 - Tool edge control for 5-axis continuous / Axes movements: X / Y / Z / X2 / Z2 615 / 250 / 1585 / 230 / 1388 mm / W 1539 mm / C-axis indexing 0.0001° Itodpfx Aexa H S Rod Dsp This 7-axis Mazak Integrex i-300ST-1500U lathe was manufactured in 2012. It features a main spindle bar passage of 80mm, a tool changer with a capacity of 72 tools, and a milling spindle speed of 12,000 rpm. Additional highlights include a high-pressure cooling system at 14 bar, a chip conveyor, and a mist filter unit. Ideal for prototype production, the machine includes tooling, chucks, and jaws. For more information about this lathe, please reach out to us. Application Types Turning

Condition: ready for operation (used), Year of construction: 2006, operating hours: 20,695 h, Control Unit Brand MAZATROL Model Matrix Movement X-Axis Movement 630 Y-Axis Movement 230 Z-Axis Movement 1585 W-Axis Movement 1546 Itsdpfx Adoxbumfj Djp Additional Equipment Options Screen: Picture available This 5-axis Mazak Integrex 400 IV was manufactured in 2006. It features a Mazatrol Matrix control, a 12-inch chuck, and a steady rest supporting 70-230mm. The machine offers a milling spindle speed of 12000rpm and a turning spindle speed of 2800rpm. If you are looking to get high-quality turn-mill capabilities, consider the Mazak Integrex 400 IV machine we have for sale. Contact us for more information about this machine. Application Types Turning

Condition: used, Year of construction: 2018, This machine will soon be in our warehouse! X- 350 mm Y- 550 mm Z- 510 mm A-axis -120° to +30° C-axis, table's rotation movement: ±360° Year: 2018-08 Working Time: 7190H Spindle motor: AC 11 kW (40% ED) Rapid feed X, Y, and Z axis: 30 m/min Tool magazine: 30 places Spindle taper: ISO 40 Spindle motor: AC 11 kW (40% ED) Spindle bearing inner/outer diameter: Ø 70 / 110 mm Speed range: 35-12000 rpm Itedpfx Adoxl Rkze Dop Max torque: 65 Nm (40% ED) Floor area of standard machine: approximately 1900 x 3060 mm Height of standard machine: approximately 2857 mm Weight: approximately 7000 kg Total circuit breaker: 37 kVA

Condition: excellent (used), Year of construction: 2014, functionality: fully functional, DOOSAN PUMA 700LY HEAVY DUTY CNC TURNING CNETRE FANUC 32i A CONTROL YEAR 2014 Y AXIS C AXIS + DRIVEN TOOLS TRAVELS ON AXIS – 400 X / 200 Y / 3100 Z STANDARD TURNING 750 MM DIA SWING OVER BED 1140 MM SWING OVER SADDLE 1000 MM BORE 165 MM ----- this is now correct 610 MM HYD CHUCK SPINDLE MAX RPM 1500 Itodpfsxvqc Eex Ad Dsp PRGRAMABLE TAILSTOCK TELBROOK MANUAL STEADY – STEADY RANGE 390 – 700 DIA 45 KW CUTTING HOURS – 3955 RUN TIME 4877 SWARF CONVEYOR OVERALL DIMS – 7350 MM X 2710 MM X 2590 MM WEIGHT 22 TON MORE PHOTOS TO FOLLOW VIDEO ON REQUEST

Condition: ready for operation (used), Year of construction: 2016, General Data Measurements width 4210 Measurements depth 6900 mm Measurements height 3400 mm Machine weight 21500 kg Control Unit Brand MAZATROL Model SMOOTH G Main Drive Spindle speed range 10000 Number of axis 4 Movement X-Axis Movement 1050 mm X-Axis Rapid Traverse 60 m/min Y-Axis Movement 900 mm Y-Axis Rapid Traverse 60 m/min Z-Axis Movement 980 mm Z-Axis Rapid Traverse 60 m/min Workpiece Iodpfexmlkxox Ad Djtp Workpiece X 1050 mm Workpiece Y 1300 mm Table Min distance between vertical spindle and table 100 mm Max distance between vertical spindle and table º1000 mm Table load 1500 kg Tools Max weight 30 kg Max tool diameter 125 (250) mm Max tool length 630 mm Additional Equipment Chip Conveyor Tool Presetting Air Blow on the Spindle Remote Handwheel This 4-axis Mazak HCN-6800 horizontal machining center was manufactured in 2016. Ideal for precision machining, it offers robust construction and reliability. Consider the opportunity to buy this Mazak HCN-6800 horizontal machining center. Contact us for more information. Application Types Milling

Condition: good (used), Year of construction: 2012, Turning length: 505 mm Turning diameter: 360 mm Iodpexqxg Ujfx Ad Dotp Spindle bore: 76 mm Max. spindle speed: 3500 rpm Turret: 12 positions, driven tools Control: Fanuc 32I
