Rotary Welding Table

MB ECO S 300

table diameter 500 mm
table load 300 horizontal kg
table load 150 vertikal kg
swivelling range 0 - 90.0 Grad
turning speeds 0.2 - 2.5 U/min
bore 90.0 mm
table height ~ 650 mm mm
motor 230 Volt
weight of the machine ca. 90.0 kg.
range L-W-H 385 x 340 x 375 mm
Features:
- The table can be tilted and locked at angles ranging from 0° to 90°
- Manual tilting
- Start/stop via a foot switch that can be used from any location
- Selectable rotation direction: clockwise/counterclockwise
- Rotation time adjustable
- Welding machine controlled via control unit
- 350-amp ground connection

Scope of Delivery:
- Control unit (integrated)
- Foot switch

THE ROTARY TABLE HOUSING MUST BE CONNECTED DIRECTLY TO THE BUILDING GROUND!
Tsdpfxsxabl Se Anteb
CAUTION!! Vertical load limit: 150 kg only
