Tool measuring instrument

Mitutoyo Quickset R

Condition: excellent (used), Year of construction: 1972, machine/vehicle number: 42 473, Manufacturer: Meuser Type: M 70 R Year of manufacture: 1970 Condition: very good, fully functional Technical data: Overhang: 1800 mm Gujdslp Iqmspfx Af Uei Drill spindle mount: MK6 Drilling capacity, max.: 120 Table size: 2000 x 1100 mm Rotary table: 700 x 700 x 500 mm Weight: 8000 kg With support column Hydraulic and electrical diagrams are available.

Year of construction: 2001, condition: excellent (used), Splash guard Diameter 600 mm Gedpfx Asd Tyvfof Uoui Height 130 mm Mounting hole circle diameter: 128.5 mm Groove width 16 mm Securing thread 200 x 4 mm

Condition: used, Internal micrometer, internal measuring instrument, internal dial gauge, internal micrometer screws, micrometer screw, internal diameter, internal micrometer, cylinder gauge Gedpfsl Ha R Hsx Af Ueui -Handover: in its current condition as inspected -Condition: incomplete, see pictures -Measuring range: -150 mm -Dimensions: 280/450/H60 mm -Weight 2 kg

Condition: used, Internal micrometers, micrometer screw, internal diameter, internal precision measuring device, cylinder gauge, -Measuring range: 35-60mm -Dimensions: 115/450/H60 mm -Weight 1.6kg Gsdpfxjl Ha R Re Af Ueui

Condition: used, Year of construction: 1976, functionality: fully functional, machine/vehicle number: 4218/ 12035, Axis height over bed: 1500 mm Speed: 0 - 315 rpm Gedpfx Afjwqk Umj Uoui Range of diameters and length of drilling on one side:. D 35 – 45 mm L = 4000 mm D 46 – 65 mm L = 6000 mm D 66 – 85 mm L = 8000 mm D 86 – 105 mm L = 12,000 mm D 106 – 125 mm L = 16,000 mm D 126 – 200 mm L = 24,500 mm D 201 – 250 mm L = 24,500 mm D 251 – 555 mm L = 18,000 mm

Condition: excellent (used), Year of construction: 2001, AN VERY RARE OPORTUNETEY TO BUY AN EXCELLENT MACHINE WITH HUGE AMOUT OF TOOLINGS, DRAWERS, CLAMPING EQUIPMENT... OWER 400 EXPENSIVE TOOLINGS CNC BORING MILL WOTAN RAPID 1 RETRIFITTED 2001 WITH HUGE AMOUNT OF OVER 450 TOOLING VERY LOW HOURS WORKING TIME DATA: CONTROL ON: 8001 H MACHINE POWER ON: 13692H PROGRAM RUN: 4650 H SPINDLE S1 TIME: 4690 H Gedevkkf Hjpfx Af Uoui AXIS TIME: 4568H HYDRAULIC ON TIME: 12702 H WE OFFER AN STUNNING EXCELLENT CONDITION WOTAN CNC RAPID 1 WITH HUGE AMOUNT OF TOOLINGS, FOR A SPECIAL STAINLESS WORK. MACHINE HAVE HEIDENHAIN 530 CONTROLS TECHNICAL DETAILS: SPINDLE SPEED : 6,3-1600 U/Min SPINDLE MOVE : Y AXIS : 1250 mm DRILLING SPINDLE MOVE: Z AXIS: 600 mm W : 1000 mm X : 2000 mm B: 360.000 DEGREE SPINDLE DIAMETER: 105mm TOOL HOLDER: ISO 50 WITHOUT TOOL CHANGER CLAMPING: HIDRAULIC MAX TABLE LOAD: 6000 KG TABLE: 1120 X 1400 NUT -BILD 7 ; 22H7 INDEXING 4 X 90 DEGREE TOTAL WEIGHT: 16000 KG DIMENSION OF MACHINE: LENGHT 4800 X BREIT 4665 X HEIGHT 4200

Condition: good (used), Depth gauge, dial gauge, depth gauge, depth caliper, caliper, vernier caliper -Measuring range: 0-100 mm -Fine-tuning -long measuring jaws -Transport box -Dimensions: 365/180/H40 mm -Weight: 1.15 kg Godpsb E N Ubofx Af Ueui

Condition: used, Height gauge, parallel gauge, height gauge -Manufacturer: Mitutoyo, height gauge type 192-104 -Max. Working height: 600 mm -Dial indicator: measuring accuracy 0.01 mm Godpfxsk Nfpge Af Uoui -Analog display: double counter -Dimensions: 275/120/H795 mm -Weight: 8.7 kg

Condition: used, Vernier caliper, caliper, vernier caliper -Manufacturer: Holex, digital caliper .: 41 5528 800 -Measuring range: 0-300 mm Gedpfx Ajr A H Sqsf Ueui -Measurement accuracy: 0.01 mm -Quantity: 1x calipers available -Dimension case: 1060/280/H50 mm -Weight: 3,3 kg.

Condition: used, Year of construction: 1987, turning height: 5,000 mm, workpiece weight (max.): 80,000 kg, turning diameter: 5,000 mm, Technical data SIEMENS SINUMERIK 840 Dsl control system Main dimensions and travels Face plate diameter 4,000 mm Rotation diameter (max.) 5,000 mm Workpiece height (max.) 5,000 mm Total height of the machine 9,250 mm Maximum workpiece weight 80,000 kg Table base Y Horizontal table displacement 2,500 mm Cross beam Vertical adjustment of the cross beam in 50 steps 3,200 mm Gjdpfx Afeu R Etpo Usui Crossbeam support (right) Horizontal adjustment of support - 2740 + 2740 mm Vertical displacement of the chisel slide 1,800 mm Cross-section of the chisel slide 250x210 mm Tool positions 0 without vertical support (left) Lateral support (right) Vertical adjustment of support -25 + 2170 mm Horizontal displacement of the chisel slide 1,000 mm Cross section of the chisel slide 250x210 mm Turning diameter max./min. 4,500/2,500 mm Tool changer Main drive: Power of the main motor 100 kW Speed range of the faceplate 0.63 - 63 rpm Maximum torque on the faceplate 160 kNm Drilling and milling drive side support: Power of the drive motor 22.5 kW Maximum torque 900 Nm Connected loads of the machine Connection Voltage of the machine 380 Volt / 50Hz Control voltage 220V AC / 24V DC Total connected load 150 kVA Required back-up fuse 400 A Equipment and accessories: Operator platform Chip conveyor Cooling lubricant system Tool changer Tool measuring probe RENISHAW
