CNC lathe

Mori Seiki NL 1500 SY / 500

Condition: used, Year of construction: 2005, Technical details: turning diameter: 356 mm turning length: 705 mm control: MSX 850 MAPPS II swing dia.: 755 mm standard turning diameter: 275 mm travel -x axis: 260 mm travel -y axis: 100 (+-50) mm travel -z axis: 795 mm rapid travel - longitudinal/face: 30 / 30 m/min rapid traverse Y-axis: 10 m/min Rapid travel B-axis (parts transfer subspindle): 30 m/min Spindle 1 RPM: 4000 1/min Spindle 1 Power: 18,5/18,5/15 kW Spindle 1 max. bar diameter: 80 mm Spindle 2 RPM: 6000 1/min Spindle 2 power: 11 / 7,5 kW turret stations / rotary tool stations: 16 / 16 VDI 30 : 5.5/5,5/3,7 kW speed of driven tools: 6000 1/min total power requirement: 39,2 kVA Cedpfx Apey H R D Tjpsgu weight of the machine ca.: 6,2 t dimensions of the machine ca.: 3,1 x 2,0 x 2,2 m Accerories Chip conveyor Spindle 1 Chuck Kitagawa B 210 (250 mm) Spindle 2 Chuck Kitagawa B 206 (160 mm) High precision Turning and Milling Centre with Y-axis and sub spindle. Easy programming by MAPPS II Control. *

Condition: used, Year of construction: 2001, - Fagor 8055 CNC control - Operating modes: manual/cycle-controlled - 8-fold tool turret VDI30 - Overhauled 2023 - Year of construction 2001 Technical data Capacity: - Center height: 200 mm - Center width: 1000 mm - Permissible Ø over guide bed: 400 mm - Permissible Ø over longitudinal slide: 370 mm - Permissible Ø over cross slide: 210 mm - Bed width: 300 mm Headstock: - Bore of main spindle: 65 mm - Main spindle nose: Camlock-n°6 / DIN 55027-n°6 - Morse taper of the main spindle: MK5 - Spindle speeds: 2 Codpfx Apsvf I Diopsgu - Constant cutting speed: 0-750 / 750-3000 rpm Feed rates: - Working feed Z/X: 0 - 7000 mm/min - Rapid traverse Z/X: 10 m/min Tailstock: - Tailstock shank Ø: 58 mm - Tailstock shank travel: 155 mm - Morse taper tailstock: 4 Motors: - Main motor power: 7.5 kW - DC motor Z-axis power: 6.8 Nm - DC motor X-axis power: 3.4 Nm - Motor pump power: 0.57 kW Dimensions: - Machine weight: approx. 2300 kg - Dimensions WxHxD: 2980 x 1730 x 1610 mm

Condition: used, Year of construction: 2011, turning length: 705 mm, turning diameter: 356 mm, travel distance X-axis: 260 mm, travel distance Z-axis: 795 mm, rapid traverse X-axis: 30,000 m/min, rapid traverse Y-axis: 10,000 m/min, rapid traverse Z-axis: 30,000 m/min, Mori Seiki NL2500SY-700 Brand: Mori Seiki Model: NL2500SY-700 Category: CNC Lathe Year: 2011 CNC Control: Mori Seiki MSX-850 IV Machine weight: 6.2 tons Capacity Max. swing over bed: Ø 579.8 mm Max. swing over carriage: Ø 755 mm Max. turning diameter: Ø 356 mm Max. turning length: 705 mm Bar capacity: Ø 80 mm Axis travels X-axis: 260 mm Y-axis: ± 50 mm (100 mm total) Z-axis: 795 mm C-axis: ± 360° Main spindle Spindle diameter: 254 mm Speed: 4,000 rpm Spindle nose: ASA-8 C-axis indexing: 0.001° Power: 18.5 kW (cont./30 min) Sub spindle Speed: 5,000 rpm Spindle nose: ASA-6 C-axis indexing: 0.001° Power: 15 kW (cont./30 min) Turret 12 driven tool stations Tool speed: 6,000 rpm Tool power: 5.5 kW Turning tools: 25x25 mm Boring: Ø 50 mm Feed rates Rapid traverse X-axis: 30,000 mm/min Rapid traverse Y-axis: 30,000 mm/min Rapid traverse Z-axis: 10,000 mm/min C-axis: 400 rpm Accessories Static toolholders + 4 driven (2 radial, 2 axial) Chip conveyor + tank Top Automazioni – Magic bar feeder Csdpfx Aeyxmh Soppogu Electrical transformer Part unloading arm 250-liter coolant tank Manuals + electrical diagrams CE Declaration

Condition: excellent (used), Year of construction: 2011, operating hours: 7,000 h, functionality: fully functional, travel distance X-axis: 1,100 mm, travel distance Y-axis: 600 mm, travel distance Z-axis: 560 mm, rapid traverse X-axis: 42 m/min, rapid traverse Y-axis: 42 m/min, rapid traverse Z-axis: 42 m/min, controller model: FANUC 21iMB, overall weight: 7,500 kg, spindle speed (max.): 12,000 rpm, spindle nose: BT-40, number of slots in tool magazine: 30, Equipment: documentation/manual, rotational speed infinitely variable, The used VICTOR A110 vertical machining center is a small/medium-sized 3-axis continuous CNC machining center; table size 1350×600 mm, X travel 1,100 mm, Y 600 mm, Z 560 mm, year of manufacture 2011 (installed in 2013), CE-compliant, equipped with FANUC 21i-MB CNC with Manual Guide i, rapid feed of 42 m/min, axis acceleration of 0.75G, working feed of 12 m/min, weight 7,400 kg. It is equipped with a BT-40 milling spindle, 12,000 rpm, 15 kW, cooled by dedicated chiller, belt-type chip conveyor, double internal auger, tank washing system, high-pressure through-spindle coolant, 32-position random tool changer, door, memory card slot, Ethernet RJ 45 port, and RS 232 serial port. Csdpsx Hap Eefx Appogu Only just over 13,000 power-on hours and 7,000 spindle hours (original). PERFECT WORKING CONDITION!

Condition: excellent (used), Year of construction: 1999, • FANUC 210i - T control (cycles) Cgodpfx Apjw S E R Rspou • Max. distance between centers: 1,250 mm • Max. turning diameter: 400 / 585 mm in offset • Spindle speed: 12 . . . 2,500 rpm • Spindle bore: 54 mm • X-axis: 210 mm • Z-axis: 1,181 mm • Cutting gap adjustment: 0.05 – 0.8 mm • Motor power: 7.5 kW • Weight: approx. 2,700 kg

Condition: used, Year of construction: 2004, Technical details: turning diameter over bed: 610 mm turning dia. over face-slide: 350 mm swing diameter over bed: 610 mm centre distance: 1390 mm control: Fanuc 0i-Mate TC x-axis: plan: ca. 305 mm z-axis: längs: ca. 1350 mm revolution per minute: 22 - 2200 U/min feed:: X + Z-Achse: 5 / 10 m/min. spindle bore: Ø 70 mm tool turret - number of stations: 6 tailstock quill taper MT: MK5 tailstock quill stroke: 150 mm Weight approx.: 2,7 t total power requirement: 15 kW dimension machine xH: 3,7 x 1,7 x 1,7 m dimensions of hydaulic: 630 x 460 x 900 mm other features: -hydr. chuck TONFAU Ø 300mm -hydraulics -Coolant system -control panel -double foot switch accessories: -div. mold jaws -div. soft jaws -6 footrests Cgjdsu Ix I Uepfx Appju *

Condition: used, Vertical machining center LEADWELL MCV 610 CR CNC Fanuc 0M X 610 Y 510 Z 410 6000RPM ISO 40 The machine is in our warehouse in Gussago BS, under power Mimu Machine Tools Gussago BS Italy The machining center is a machine tool equipped with numerical control capable of performing multiple mechanical operations with a single set-up on multiple surfaces of the same work piece. It is generally equipped with multiple axes of motion and a automatic tool exchange system and sometimes multiple pallets X axis: 610 Y axis: 510 Z axis: 410 CNC type: Fanuc Spindle revolutions: 6000 Codpotrbb Esfx Appsgu

Condition: good (used), Year of construction: 1999, Parts shown by hand not come. Cgedpfxow Uiguo Appeu Technical details shown on picture.

Condition: used, Year of construction: 2000, operating hours: 17,200 h, functionality: fully functional, machine/vehicle number: T 90077, turning length: 450 mm, turning diameter: 230 mm, travel distance X-axis: 200 mm, travel distance Z-axis: 450 mm, rotational speed (max.): 4,000 rpm, overall weight: 2,800 kg, - Year of manufacture: 2000 - Single owner, used in-house - Fully functional, under power, ready for demonstration - Operating hours: 17,200 h - X-axis travel: 200 mm - Z-axis travel: 450 mm - Turning diameter: 230 mm - Turning length: 450 mm - Spindle speed: 4,000 rpm Cgodpfxsxgtrko Appeu - Spindle bore: 52 mm - Spindle motor power: 11 kW - Control: Fanuc 21 i - Tailstock - 12-station VDI 30 turret - Chip conveyor - Weight: 2,800 kg Net price ex-works, unloaded, from location Luckenwalde (Germany), excluding transport

Condition: excellent (used), Year of construction: 2013, CNC Control: M730BM X mm: 1,050 Y mm: 530 Z mm: 510 Worktable dimensions mm: 1,350 x 600 Table load capacity kg: 1,200 Distance spindle nose to table mm: - Cutting feed mm/min X,Y,Z: - Max. rapid traverse m/min X, Y, Z: 30,30,30 Spindle speed rpm: 12,000 Spindle power HP: - Taper type: BT-40 Torque Nm: - Tool changer type: - Tool changer positions: 30 Max. tool diameter mm: 80 Max. tool diameter with adjacent positions empty: 150 Max. tool length mm: 300 Max. tool weight kg: 8 Coolant tank capacity l: - Through-spindle coolant bar: - Cgjdpfx Apsymxbfepsu EQUIPMENT Chip conveyor Work light Electronic handwheel BT-40 taper
