1000/445 HP

NETSTAL

Condition: excellent (used), Year of construction: 2004, operating hours: 97,919 h, Operating pressure (bar): 210 Injection force (kN): 450 Closing force (kN): 2400 Opening stroke (mm): 0-510 Mold installation height: 460-800 mm Nominal voltage (V / Hz): 400/50 Nominal current (A): 136 Rated power (kW): 75 Screw diameter (Ø): 55 Air valves: 4 Controllable Lodpfx Aoyhnrpom Noaa

Condition: excellent (used), Year of construction: 2008, operating hours: 75,851 h, Operating pressure (bar): 210 Injection force (kN): 450 Closing force (kN): 2400 Ljdpfx Ameyh Ha Ae Nsaa Opening stroke (mm): 0-510 Mold installation height: 260-600 mm Nominal voltage (V / Hz): 400/50 Nominal current (A): 100 Rated power (kW): 55 Screw diameter (Ø): 55

Condition: good (used), Year of construction: 2000, operating hours: 132,186 h, Absolute cycle counter: C120 = 062077965 Operating pressure (bar): 210 Injection force (kN): 450 Lodpfx Aeyhnvhom Neaa Closing force (kN): 3000 Opening stroke (mm): 0-700 Mold installation height: 400-750 mm Nominal voltage (V / Hz): 400 / 50 Nominal current (A): 99,5 Rated power (kW): 55 Screw diameter (Ø): 55 Air valves: 4 Controllable -With dosing system -Handling robot Wittman, available as an option upon customer request Condition: good condition (Oil leak, original monitor defective)

Condition: defective spare-parts repository (used), Year of construction: 2004, Operating pressure (bar): 210 Injection force (kN): 450 Closing force (kN): 2400 Opening stroke (mm): 0-510 Mold installation height: 460-800 mm Lajdpeyhn Tgefx Am Nja Condition: Defective – for spare parts (Circuit board removed, hydraulic valve removed)

Condition: ready for operation (used), Year of construction: 2000, operating hours: 82,489 h, clamping force: 1,500 kN, Hydraulic injection moulding machine manufactured in 2000. This Netstal Synergy 1500-460 features a clamping force of 1500 kN and an injection force of 279 kN. It offers an opening stroke of 0–450 mm and a mould height range of 400–700 mm. If you are looking to get high-quality moulding capabilities, consider the Netstal Synergy 1500-460 machine we have for sale. Contact us for further details. • Hydraulics and clamping • Operating pressure: 210 bar • Injection force: 279 kN • Opening stroke: 0–450 mm • Mould height: 400–700 mm • Electrical supply • Supply 1 (3L+PE) • Nominal voltage: 400 V / 50 Hz • Nominal current: 63 A • Motor protection: 55 A • Motor power: 30 kW • Cable cross-section: 16 mm² Lasdpfxey Dr Tds Am Nsa • Nameplate values: Nominal current 55 A; Nominal power 30 kW • Supply 2 (heating/control) (3L+N+PE) • Nominal voltage: 400 V / 50 Hz • Nominal current: 100 A • Total connected load (heating/control): 67.6 kW • Cable cross-section: 35 mm² • Nameplate values: Nominal current 97.7 A; Nominal power 67.6 kW • Control voltages • AC: 230 V • DC: 5 V / ±15 V / 24 V • Auxiliaries and drives • Oil filter motor: 400 V / 0.6 A • Central lubrication (slow): 400 V / 0.9 A • Central lubrication (fast): 400 V / 3.0 A • Central lubrication (F110): 230 V / 1.0 A / 0.10 kW • Heating/plasticizing and outlets • Plasticizing 1: 230 V / 20.9 kW • Plasticizing 2: 230 V • Mould heating: 230 V • Socket outlets: 230 V / 57.7 kW

Condition: ready for operation (used), Year of construction: 2016, operating hours: 600,230 h, clamping force: 600 kN, overall weight: 6,300 kg, Hydraulic injection moulding machine manufactured in 2016. This Netstal Synergy 600-230 features a clamping force of 600 kN and an injection force of 182 kN. It has an operating pressure of 210 bar and an opening stroke of 0-350 mm. If you are looking to get high-quality injection moulding capabilities, consider the Netstal Synergy 600-230 machine we have for sale. Contact us for further details regarding this machine. • Operating pressure: 210 bar • Injection pressure: 150 bar • Injection force: 182 kN • Opening stroke: 0–350 mm • Mould installation height: 200–500 mm • Protection class: IP54 • Power supply 1: 3PH+E, 400 V, 50 Hz • Nominal current supply 1: 29 A • Short circuit current (supply 1): 20 kA • Power supply 2: 3PH+MP+E, 400 V, 50 Hz • Nominal current supply 2: 120 A • Short circuit current (supply 2): 20 kA • Pump motor power: 15 kW Laodpfx Aey Dr Nfem Nea • Heating power: 13.66 kW • Total connected load: 65.1 kW • Total connected load (alternative): 62.4 kW • Socket F11: 400 V, 9 A • Socket F12: 230 V, 20 A • Socket F110: 230 V, 10 A

Condition: ready for operation (used), Year of construction: 2021, operating hours: 5,797 h, clamping force: 800 kN, screw diameter: 40 mm, total width: 2,042 mm, total height: 1,711 mm, overall weight: 8,200 kg, product length (max.): 4,545 mm, This Netstal Elion 800-270 was manufactured in 2021. It features a robust AXOS control system and a high-speed injection unit capable of 450 mm/s. The machine includes a screw diameter of 40 mm and a fully integrated 9 kW hydraulic unit. It supports a tool installation height range of 200–500 mm and is equipped with a Euromap 67 robot interface. If you are looking to get high-quality injection molding capabilities, consider the Netstal Elion 800-270 machine we have for sale. Contact us for more information. Lodpex D Rlpofx Am Noaa Additional information inclusive Wittmann Primus 16T robotTravel ranges: Z: 1250 mm, Y: 800 mm, X: 590 mm5 kg payloadControl system: Wittmann CNC8, Primus R8.3 softwareR8 Teachbox TouchVacuum circuit with additional 5/2-way valve • Injection Unit: 270 Powermaster with injection speed of up to 450 mm/s • Screw Diameter: 40 mm, type B, 3-zone screw • Nozzle Type: Pneumatically controlled needle valve nozzle with additional heating zone • Minimum Installation Height: 200 mm • Maximum Installation Height: 500 mm • Clamping Force: 800 kN • Minimum Installation Height: 200 mm • Maximum Installation Height: 500 mm • Hydraulic Unit: Fully integrated hydraulic unit 9 kW with 140 bar operating pressure • Pneumatics: 1 Air valve to 890 Liter, 1 additional Air valve to 890 Liter • Safety Cover Execution: Locked doors, top • Operator Identification: User recognition via PIN • EUROMAP 67: Standard + dynamic retractionInterfaces: Colour feeder, Freely Configurable DIO: 4x Output/2x Input • Tool Monitoring: Available on DFP • Voltage Fluctuation Compensation: UPS presentExtrasSocket box 1:X2510, Cekon, 16A /400V, 3P-N-PE via HSX2511, Cekon, 16A /400V, 3P-N-PE via HSX2512, Cekon, 16A /400V, 3P-N-PE via HSX2513, Cekon, 16A /400V, 3P-N-PE via socket contactor(Function 0060)Sockets for colour dispenser:1X2507 / 1W7145, Schuko 10A / 230V, 1P-N-PE, via HSplus 1X9507 / 1W9507, Schuko 10A / 230V, 1P-N-PE, via HSMount sockets and base housings on bracket 110.180.6902(Function 0060)1X3123, Zone 12 HAN 4A screw-in, power only1X9123, Zone 12 HAN 4A screw-in, sensor only(Function 0110)Pneumatics 1, 1x3/2WV 890L, mounted on DAP, W2008(Function 0470)Pneumatics 9, 1x3/2WV 890L, mounted on BAP, W2016(Function 0470)Cooling water 1:X4051 W9088 Flow measurement B1135 - B1138 (return),Pressure measurement B1211 (flow)X4060 W9260 HAN16E Temperature measurementB0801 (flow), B0832 (return)(Function 0490)Cooling water 2:X4050 W9086 Flow measurement B1147 - B1150 (return),Pressure measurement B1212 (flow)X4059 W9259 HAN16E Temperature measurementB08813 (Flow), B0814 (Return)(Function 0490)Dosing 1C:1x suction conveyor and 1x paint dosing1X2018/1W7146, HAN 4A for paint dosing1X9191/1W9946, HAN 3A for suction conveyormount sockets and base housings on holder 110.180.6902(Function 0550)

Condition: used, Year of construction: 1950, pressure 120 t draw back pressure 20 t piston stroke 500 mm dayligth 600 mm usable table size 800 x 800 mm range L-W-H ca. 2,55 x 1,14 x 3,34 m Laodpfx Amox Sr Evj Noa weight ca. 3,5 t In our assessment, the machine is in good used condition and can be inspected under power by appointment. Accessories, tools, and clamping devices shown are only included in the scope of delivery if this is noted in the additional information. Technical data and specifications are subject to change without notice and errors. Prior sale is reserved.

Condition: good (used), Year of construction: 2001, Injection Molding Machine NETSTAL S 6000-5500E Basic Information Manufacturer: Netstal Model: S 6000-5500E Year of Manufacture: 2001 Operating hours: 88,933 h Clamping Unit Clamping force: 6,000 kN Mounting plate dimensions (H × W): 1,620 × 1,550 mm Tie-bar spacing (H × W): 1,020 × 1,020 mm Minimum mold height: 500 mm Maximum mold height: 1,000 mm Maximum mold opening: 1,950 mm Centering ring diameter: 160 mm Maximum ejector stroke: 280 mm Injection Unit Screw diameter: 90 mm L/D ratio: 27 Injection volume: 2,290 cm³ Shot weight (PS): 2,196 g Lodpfx Amjyugcgo Neaa Maximum injection pressure: 2,410 bar Maximum injection speed: 4,453 cm³/s Machine Dimensions and Weight Clamping unit dimensions: 7.21 × 2.40 × 2.50 m Injection unit dimensions: 4.60 × 2.61 × 2.50 m Total machine weight: 62,000 kg (62 t) Optional Energy Saving System ESS (Energy Saving Systems) The machine can be equipped with a modern ESS servo drive system that enhances the energy efficiency of hydraulic injection molding machines. The system controls the operation of the hydraulic pump motor using a frequency inverter, which adjusts the motor speed to the actual requirements of the production cycle. As a result, electrical energy is only consumed when the machine actually requires it. Benefits of the ESS System - Up to 30% reduction in electricity consumption - Servo drive technology for the hydraulic pump - World-class and proven technology used in the plastics processing industry - Reduced energy losses during idle operation - Lower heating of the hydraulic system - Extended service life of hydraulic components - Can be retrofitted to existing hydraulic injection molding machines The ESS system allows for significant reduction of machine operating costs while maintaining full production parameters.

Condition: ready for operation (used), We are offering the following fully operational NETSTAL MPS injection moulding machines for sale: NETSTAL N115/60 MPS Year of manufacture: 1987 Operating hours: 149,000 h NETSTAL N115/60 MPS Year of manufacture: 1987 Operating hours: 147,000 h Ledpfeyl Umbox Am Njaa NETSTAL N115/60 MPS Year of manufacture: 1987 Operating hours: 148,000 h NETSTAL N350/150 MPS Year of manufacture: 1987 Operating hours: 131,000 h Further information available upon request.
